Swisher QUADBOSS COMMERCIAL PRO QBRC14544CP User manual

COMMERCIAL PRO
44” COUNTRY CUT
TRAIL CUTTER
OWNER’S
MANUAL
SWISHER ACQUISITION INC.
1602 CORPORATE DRIVE, WARRENSBURG, MISSOURI 64093
PHONE [phone] FAX [phone]
Assembly
Operation
Service and Adjustment
Repair Parts
MODEL NO.
STARTING SERIAL #:
L118-023001
QBRC14544CP
QBRC14544CP-CA
20949 REV 18-023
Read and follow all
Safety Precautions
and Instructions
before operating this
equipment.
IMPORTANT
Read and follow all
Safety Precautions
and Instructions
before operating this
equipment.
IMPORTANT
Made In The
USA
of US and Global Parts

LIMITED WARRANTY
The manufacturer’s warranty to the original consumer purchaser is: This product is free from
defects in materials and workmanship for the period's shown below beginning from the date
of purchase by the original consumer purchaser. We will repair or replace, at our discretion,
parts found to be defective due to materials or workmanship. This warranty is subject to the
following limitations and e clusions:
As required by CFR § 1060.120, the fuel system related components, hich have been
certified to this equipment by SAI are to be free of defects in material and orkmanship for a
period of t o (2) years from the date of purchase by the original consumer purchaser.
1) Engine Warranty All engines utilized on our products have a separate warranty
e tended to them by the individual engine manufacturer. Any
engine service warranty is the responsibility of the engine
manufacturer and in no way is Swisher or its agents responsible
for the engine warranty. The Kawasaki Engine Service Hotline is
1-877-364-6404 or email [e-mail]
2) Commercial Use This product has a 1yr Limited Commercial - 2 Year
Limited Consumer on All Non-Engine Parts from the date
of purchase.
3) Limitations This arranty applies only to products, hich have been
properly assembled, adjusted, and operated in accordance ith
the instructions contained ithin this manual. This arranty
does not apply to any product of S isher that has been subject
to alteration, misuse, abuse, improper assembly or installation,
shipping damage, or to normal ear of the product.
4) Exclusions Excluded from this arranty are normal ear, normal
adjustments, and normal maintenance.
In the event you have a claim under this arranty, you must return the product to an
authorized service dealer. All transportation charges, damage, or loss incurred during
transportation of parts submitted for replacement or repair under this arranty shall be borne
by the purchaser. Should you have any questions concerning this arranty, please contact us
toll-free at 1-800-222-8183. The model number, serial number, date of purchase, and the
name of the authorized S isher dealer from hom you purchased the mo er ill be needed
before any arranty claim can be processed.
THIS WARRANTY DOES NOT APPLY TO ANY INCIDENTAL OR CONSEQUENTIAL
DAMAGES AND ANY IMPLIED WARRANTIES ARE LIMITED TO THE SAME TIME
PERIODS STATED HEREIN FOR ALL EXPRESSED WARRANTIES. Some states do not
allo the limitation of consequential damages or limitations on ho long an implied arranty
may last, so the above limitations or exclusions may not apply to you. This arranty gives
you specific legal rights and you may have other rights, hich vary from state-to-state. This is
a limited arranty as defined by the Magnuson-Moss Act of 1975.
2

SAFETY PRECAUTIONS
This Safety Alert Symbol indicates im ortant messages in this
manual. When you see this symbol, carefully read the message that
follows and be alert to the ossibility of ersonal injury.
Read this manual com letely. This machine can am utate hands and feet, and
throw objects. Failure to observe the following safety instructions could result in
serious injury or death.
Thank you for choosing Swisher’s 44” Trail Cutter. Before operating
your cutter, please read, understand and follow all of the safety precautions
and other instructions explained in this manual. s with all power
equipment, lawn mowers and cutters can be potentially dangerous if
improperly used.
3
• Read the manual. Learn to operate this machine safely.
• Always disconnect the spark plug wire and place the wire where it cannot contact the
spark plug, to prevent accidental starting the engine when setting up, transporting,
adjusting or making repairs.
• Keep all shields and guards in place.
• Understand the speed, steering and sta ility of this machine. Know the positions and
operations of all controls efore you operate this machine. Check all of the controls in
a safe area efore starting to work with this machine.
• Allow only responsi le adults who are familiar with these instructions to operate this
machine. Never allow children to o erate this machine.
• Clear the area of o jects such as rocks, toys, wire, etc. that can e picked up and
thrown y the lade.
• Be sure the area is clear of other people efore mowing. Be aware of the cutters
discharge direction and do not point at anyone. Sto the machine if anyone enters the
cutting area. Children are often attracted to the machine and the mowing activity.
Never assume that children will remain where you last saw them. Keep children
under the watchful care of another responsi le adult.
•No riders!
• Do not put hands or feet near or under rotating parts.
• Do not mow in reverse. Always look down and behind before and during backing.

• Insert 5/8-11 X 2 ½ olt through the top of pivot assem ly and top link and secure with 5/8-11
nut. Insert 5/8-11 x 2½ olt through the ta s on the top of the Hitch ar and Top Link. Secure with
a 5/8-11 lock nut.
• Place 2” Hitch Coupler on the end of the Hitch Bar. Align Holes with Hitch Bar and Coupler.
Fasten using (2) 3/8-11 x 3 Bolts, (4) 3/8 Washers, and (2) 3/8-11 Locknuts. Tighten nuts securely.
• The hitch can e adjusted up or down to level the deck from front to ack. (See figure 2 page 11)
• Check engine oil. All engines are filled with oil at the factory. Verify oil level and
add if necessary efore starting engine. (See Engine Owner’s Manual)
• Verify fuel level and add if necessary efore starting engine.
Electric Start Models (U1 battery not included):
• Check the attery. If the attery is put into service after the “month and year” of the
date on the attery, it may need to e charged with a 12 volt attery charger for a
minimum of 1 hour, ut no more than 2 hours at a rate of 6 to 10 am
• Battery is located inside of the attery ox. Secure attery with ru er strap provided.
Connect strap hooks into holes in motor ase. (See figure 14 page 19)
• Attach attery ca les to the attery, making sure to attach the red wire to the positive
terminal first and the lack wire to the negative terminal second.
• Reconnect spark plug wire.
• Refer to Owner’s Manual pg 5 for proper operating procedures.
• Turn off the lades when not cutting. Before leaving the machine, turn off the lades
and stop the engine.
• Watch for traffic when operating near or crossing roadways.
• Do not operate the cutter if it has een dropped or damaged in any manner or if the
mower vi rates excessively. Excessive vi ration is an indication of damage.
Repair cutter as necessary.
• Dress properly. Do not operate the cutter when arefoot or wearing open sandals.
Wear only solid shoes with good traction when cutting.
• Never allow operation y untrained persons.
• Do not operate the machine while under the influence of alcohol or drugs.
• Do not operate on slopes greater than 15 degrees.
• Never tamper with safety devices. Check their proper operation regularly.
• Stop and inspect the equipment if you strike an o ject. Repair, if necessary, efore
restarting. Never make adjustments or repairs with the engine running.
• Cutter lades are sharp and can cut. Wrap the lades or wear gloves, and use extra
caution when servicing them. Do not operate at too fast a rate.
4
ASSEMBLY
Wrench/Socket
Qty. Size
(1) 1-1/8”
(1) 1-1/16”
(2) 15/16”
(2) 9/16”
Tools Required:• Disengage spark plug wire and place where it cannot make a
connection.
•Refer to Fig. 1 g. 11. Attach hitch assem ly parts to front of
mower using 3/8-16 X 1¼ olts and secure with 3/8-16 locknuts.
Insert 3/4-10 x 4 ½” olt through the ottom hole of the pivot
assem ly, (2) 3/4 washers, and hitch tu e and secure with 3/4-10
nut. Tighten nut tight until tu e is clamped tight, then ack off 1/4
turn to allow tu e to pivot.

5
OPERATING YOUR TRAIL CUTTER
The operation of any mower can pro uce foreign objects to be thrown into the eyes, resulting in severe eye
amage. Always wear certifie safety glasses or wi e-vision safety goggles over spectacles before starting
any cutting machine an while operating such a machine.
The operation of any mower pro uces soun waves that are amaging to the human ear. Ear protection is
recommen e .
CAUTION! Tragic acci ents can occur if the operator is not alert to the presence of chil ren.
Chil ren are often attracte to the machine an the mowing activity. Never assume that children will
remain where you last saw them.
STOPPING THE ENGINE
• Make sure the tow vehicle parking rake is set.
• Disengage cutting lades.
• Reduce engine to idle speed and allow engine to run momentarily for cooling.
• Turn the key to the off position.
INTENDED USE
The 44” Trail Cutter is designed to clear dense areas of grass and cut saplings up to 3” thick
on meadows and small estates. It is not intended to create a finish cut on lawns. Your
Trail Cutter should e towed ehind an ATV, golf cart, lawn tractor or other approved
vehicle. It is not recommended for speeds exceeding 5 MPH.
ATTACHING TRAIL CUTTER TO TOW VEHICLE
• Back vehicle up to desired towing position.
• Offset the Trail Cutter to the side opposite the tow vehicle discharge (if any).
This prevents the tow vehicle from throwing grass into Trail Cutter engine.
• Using the 7365 2” all coupler, connect the hitch to the vehicle your machine
will e towed with. Once attached adjust the level of the mower y rotating the
adjustment rod (See figure 2 page 11).
TRANSPORTING CUTTER
• Stop Trail Cutter.
• Place Trail Cutter deck in its highest position.
• When transporting without the use of a tow vehicle, remove spark plug wire
and place it where it cannot contact the spark plug.

6
ENGAGING BLADES
Note: Do not attempt to start the unit with the PTO switch in the “ENGAGED” position.
• Engage lades y pulling out on the PTO switch.
• Push PTO switch in to disengage lades. See detail on page 17 figure – 10
• The raking system is applied when the lades ecome disengaged. It is designed to ring
the lades to a quick stop (approximately 10 seconds). The electric clutch comes with an
internal rake.
BREAKING IN YOUR CUTTER
• Set the vehicle parking rake and chock the wheels to prevent accidental rolling.
• While engine is running, engage the lade control.
• In a safe environment, (i.e. no children or pets) allow the lades to rotate and the engine to
run at full throttle for 5 minutes, reaking in the elt for longer life.
• Disengage the lades and shut off the engine.
STARTING THE ENGINE
See engine manufacturer’s recommendations for the type and amount of oil and fuel used. Trail Cutters
equipped ith an electric start engine ill need a battery (sold separately). S isher recommends using a
standard “U1” battery.
• Make sure the tow vehicle parking rake is set, mower is level, and lades are
disengaged. Engine must e level to accurately check and fill oil. Do not overfill.
• Check spark plug wire, oil, and fuel.
• Check all electrical connections for uildup of de ris.
• Set engine idle to “CHOKE” position.
• Turn key to the “RUN” position, then to the “START” position.
• Set engine idle at maximum RPM for est performance.
• Allow engine to run a few moments efore engaging lades.
AUTION: SHUT OFF THE UTTER ENGINE AND REMOVE SPARK
PLUG WIRE FROM SPARK PLUG BEFORE MAKING ANY
ADJUSTMENTS TO THE UTTER.
IMPORTANT: This engine is not equipped with a spark arrester muffler. It is a violation of
California Public Resource Code Section 4442 to use or operate the engine on any forest-covered,
brush-covered, or grass-covered land. Other states or federal areas may have similar laws.

7
CUTTER HEIGHT ADJUSTMENT
• There is approximately 4” of height adjustment.
• Rotate height adjust crank handle in a clockwise direction to lower the mower deck.
Rotate counterclockwise to lift the mower deck.
• Dense areas should e cut twice.
• Push handle down to lock height position.
• Adjust the top link located on the front of the hitch to level the mower after
adjusting the cutting height (See figure 2 page 11).
TOW HITCH OFFSET
• When offsetting the cutter do so to the side opposite the discharge of the tow
vehicle if towing with a mower.
• Swisher recommends if the tow vehicle is equipped with a mid-mount mower to
overlap the cut approximately 6”. This may vary depending on mowing terrain,
o stacles, and/or tow vehicle. Always keep safety the first priority.
STOPPING THE CUTTING SESSION
• Bring tow vehicle to a complete stop, set the parking rake and disengage lades.
• Turn key switch to the “OFF” position.
• Always remem er to remove keys to avoid irresponsi le usage.
SUGGESTED CUTTING PRACTICES
• Operate cutter engine at full throttle to assure the est cutting performance and
maximum material discharge.
• Allow wet grass to dry. Wet grass will clump and collect under the mowing deck.
• Cutter should e started with tow vehicle in low gear and increased only as safe
mowing conditions permit. Cutting speed should not exceed 5 MPH.
• Cutting conditions and the types of grass will vary from place to place. You may
find when cutting dense areas that the pressure of the wheel tracks may cause the
grass to e pushed down and not effectively mowed. If this happens you may want
to mow the area twice. Once with the cutter raised and the second cutting at the
desired height. The second cutting should e at a right angle from the previous for
est results.

CAUTION: DO NOT HANDLE CUTTER BLADES WITH BARE HANDS.
CARELESS OR IMPROPER HANDLING MAY RESULT IN SERIOUS
INJURY.
8
CUTTER MAINTENANCE
• Reducing the travel speed will help cut dense growth. This allows the lades the
time necessary to make its initial cut, and regain momentum to continue cutting.
The engine may stall if you are mowing too fast!
• Do not attempt to cut areas that the tow vehicle cannot maneuver through and/or
slopes that you do not feel comforta le riding.
GENERAL RECOMMENDATIONS
The warranty on this cutter does not cover items that have een su jected to operator
a use or negligence. To receive full value from the warranty, operator must maintain
unit as instructed in this manual.
Some adjustments will need to e made periodically to maintain your unit properly.
Refer to your engine manual for recommended fuel, oil, and service parts.
BEFORE EACH SEASON
A new spark plug and clean air filter assure proper air fuel mixture and help your engine
run etter and last longer.
• Replace the spark plug.
• Clean or replace the air filter.
• Check lades and elts for wear.
BEFORE EACH USE
• Check engine oil level. Do this twice to ensure an accurate reading.
• Check condition of air filter and clean or replace if necessary.
• Check lade operation.
• Check for loose fasteners.
• Lu ricate threads of adjustment rod P/N 4006. See Fig 5 pg 13.
DAILY MAINTENANCE
Make sure all nuts and olts are tight and cotter pins and retainer springs are secure.
Keep lades sharp. O serve all safety precautions.
BLADE CARE AND SERVICE
For est results cutter lades must e kept sharp. The lades can e sharpened with a
few strokes of a file or grinding wheel. Do Not attempt to sharpen while on the cutter.
Impor an : Re lace blades that have been damaged or dee ly nicked.
Impor an : Check blade and s indle hardware on a regular basis to make sure
nuts are tight.

The unit is not cutting level.
• Level deck. Check air pressure of all tires; make sure they are equal. See
tires for maximum inflation.
• Without the engine running, make certain lades are installed identically.
The engine will not start.
• Disengage lades, turn key switch to the “OFF” position, check attery and
all other electrical connections and inspect spark plug and wire.
• Contact engine manufacturer or qualified mechanic.
Engine runs oorly.
• See engine manual.
• Check the throttle adjuster.
• Replace fuel, check fuel filter and fuel line.
• Check spark plug and gap.
Cutter bounces excessively while towing.
• Decrease tire pressure.
• Tow at a lower speed.
IF PROBLEMS PERSIST HAVE A QUALIFIED ME HANI SERVI E
THE UTTER. NEVER ATTEMPT TO MAKE AN ADJUSTMENT THAT
YOU ARE NOT SURE IS ORRE T. DOING SO AN AUSE OTHER
PROBLEMS.
9
GENERAL TROUBLESHOOTING

SAFETY AND OPERATIONAL DECALS
Replace decal immediately if damaged. Order by part number from
Swisher. 1-8 -222-8183, 8-5 CT M-F
OD29-DANGER DECAL
OD33-5MPH DECAL
OD36-DEFLECTOR DECAL
OD55-DANGER DECAL
OD45-WARNING DECAL
OD10-ENGAGE DECAL
OD28-OFF/RUN/START DECAL
10
19976-SWISHER FLAG DECAL

11
UNCRATING & SET-UP DIAGRAM
DECK LEVELING DIAGRAM
FIGURE 1
FIGURE 2
FRONT TO BACK ADJUSTMENT
For est cutting results, the cutter deck should e parallel to the ground. To check parallel
adjustment, measure the distance from the ottom edge of the deck in oth the front and rear of the
deck. This adjustment is est done while the tow vehicle and Trail Cutter are connected.
12
Nut - 3/8-16 Lock
NB182
13
Bolt - Hex, 3/8-16 X 1 1/4
NB618
14
Bolt - Hex, 3/8-16 X 3"
NB150
15
Washer - 3/8 AE Flat
NB272
Item #
Description
Part #
1
Bolt - Hex, 5/8-11 X 2 1/2"
NB667
2
Bolt - Hex, 3/4-10 X 4 1/2"
21130
3 Weldment - Hitch Mo nt; RC44 21114*
4
Top Link - Cat 0 W/ Adj sting Rod
21103
5
Weldment - Hitch Bar Lower Arm
21108*
6
Pin - Clevis 3/8 X 3 ZP
21131
7
Pin - #39 Hair Pin (A155H)
NB127
8
Washer - 3/4 ID 18 GA
NB179
9
N t - 3/4-10 Lock
21132
10
N t - 5/8-11 Lock
21138
11
Washer - 3/4" SAE Flat
NB146

When ordering replace ent parts
* = USE PAINT CODE: TK=BLACK
Item # Description Part #
1 Nut - Serr Flange, 1/4-20 Grade 5 ZY NB524
2 Rubber Flapper 10384
3 Wa her - Fender, 1/4X1 1/4OD Gr 2 ZY 11520
4 Bolt - Serr Flange, 1/4-20 X 3/4 GR5 ZY NB690
5 Nut - Serr Flange, 1/4-20 Grade 5 ZY NB180
6 Plate - Harne , Mount 20910*
7 Plate - Harne , Mount Support 20911*
8 Bolt - 1/4-20 X 1 3/4 GR2 ZY NB278
FRONT SKIRT ASSEMBLY
FIGURE 3
12
HITCH ASSEMBLY
FIGURE
Note: Apply a lubricating grease to all oving parts.
Item #
Description
Part #
1
Weldment - Pivot Bracket Assembly
21102*
2
Weldment - Hitch Mount; C44
21114*
3
Spring - Compression
12364
4
Pin - 1/8" X 1" Cotter
NB126
5
Washer - Flat, 1/2"-12Ga
18823
6
Pin - Pivot Latch
21118
7
Nut - Hex Lock 1"-8
21163
8
2" Ball Coupler
7365
9
Bolt - Hex, 3/8-16 X 3"
NB150
10
Washer - 3/8 SAE
NB272
11
Nut - 3/8-16 Lock
NB182
12
Bolt - 3/4-10 X 3 3/4"
21129
13
Nut - 3/4-10 Lock
21132
14
Washer - 3/4" SAE
NB146
15
Nut - 5/8-11 Lock
21138
16
Weldment - Hitch Bar Lower Arm
21108*
Item # Description Part #
17 Weldment - Upper Hitch Arm Assembly 21117*
18
Pin - Clevis 3/8 X 3 P
21131
19
Bushing - Machine; 1" ID
21121
20
Washer - Uss Flat, Ø1" X Ø2.5"
NB569
21
Plug - 1 1/2" X 2", End Cap
21127
22
Botl - 5/8-11 X 2 1/2"
NB667
23
Top Link - Cat 0 W/ Adjusting Rod
21103
24
Washer - 1" Belleville
NB738
25
Bolt - 3/4-10 X 4 1/2"
21130
26
Pin - #39 Hair Pin (A155H)
NB127
27
Bolt - 3/8-16 X 1 1/4
NB618
28
Washer - 3/4 ID X 1 1/4 OD 18 GA
NB179

Item # Description Part #
1
Nut - 5/16-18 Serrated Flange
NB170
2
Nut, Push - 5/16
NB117
3
Knob eight Adjustment
7K
4 eight Adjust Rod 4006
5 Bolt - 1/2-13 X 1 1/2 10046
6 1/2-13 Jam Nut NB118
7 Washer - Bellville, .512x1.26x .138 10291
8 1/2 NR Mach Bushing 14 GA NB177
9
Screw - .312-18 x .75
26X249
10
Front Battery Cover
21210*
11
Bolt - 5/16" X 18 UNC X .75" Flange ead
NB596
12
Single Point Pivot Block
4007*
13 Crank Rod ES214
14
1/2-13 2-Way Jam Lock Nut
NB121
15 Weldment - Axle Bar, Right 10356*
16 Washer - Nylon 1/4 NB194
17 Motor Base 20908*
FIGURE 5
MOTOR BASE, WHEEL & HEIGHT
ADJUSTMENT ASSEMBLIES
13
When ordering replace ent parts
* = USE PAINT CODE: TK=BLACK
Item # Description Part #
17 Motor Base 20908*
18
Cover - Rear, RC14544CPKA
20941*
19 Belt - B X 55" 20937
20 1/2-13 yloc ut B281
21 Spacer 10290
22
5/8 ID X 1 OD 14 GA Washer
B149
23
Washer - 13/16 ID X 1 1/4 OD X 1/8
B195
24 Bolt - 1/2-13 X 2 1/2 Hex Tap B588
25 Weldment - Axle Bar, Left 10355*
26 Tube - Front Weldment 10342*
27
5/16-18 X 1 Serrated Flange Bolt
10548
28 Wheel/Tire - 4.8 X4-8 17383K
29 1/8" X 1" Cotter Pin B126
30 Shield - Heat 6052*
31
Guard - Fuel
20938*
32
ut - 1/4-20 KEP
B203
33 Bolt - Flange 1/4-20 x 1/2 B109

14
Item # Description Part #
1 Deck - Weldment 15727*
2 Screw - .312-18 x .75 26X249
3 Side Gu et - Left 15056*
4 Nut - 5/16-18 Serrated Flange NB170
5 Side Gu et - Right 15057*
6 Z Bracket, Jack Support 15055*
7 Front Rail/Deck Support 15054*
8 Rail - RT44, Right 17358*
9 Weldment - Blade Mount 15058*
10 Rear Z Rail Brace - RT44 16371*
11 Rail - RT44, Left 17357*
DECK ASSEMBLY
FIGURE 6
When ordering replace ent parts
* = USE PAINT CODE: TK=BLACK

Item # Description Part #
1 Nut - Nyloc 1"-8 NB612
2 Washer - 1" X 2" X 14GA NB738
3 Pulley - Blade, 12" 20 20
4 Spacer - Pulley 1 822
5 Bearing - Blade 4845
6 Shaft - Blade 18844
7
Nut - Nyloc 1/2"-13
NB281
8 Washer - USS Flat, 1/2" NB555
Blade Driver Housing 4858*
10 Bolt - 1/2"-13 X 2" NB50
11 Washer - 1" X 1 1/2" X 10GA NB614HT
12 Nut - Nyloc 3/4"-10 NB60
13 Weldment - Stump Jumper 485 *
14 Blade 10358
15 Washer - 3/4" X 1 1/4" X 18GA NB17
16 Bolt - 3/4"-10 X 2" 11431
17 Nut - Nyloc 1"-14 18850
18 Kit - Replacement, Blade Driver 18 05
When ordering replace ent parts
* = USE PAINT CODE: TK=BLACK
Note: The pulley, stump jumper, blades, blade hardware
and housing hardware are not included with the 189 5
replacement blade driver kit.
FIGURE 7
BLADE DRIVER ASSEMBLY
15

16
Item # Description Part #
1 Engine (Reference Model Shown) N/A
2Spacer - 1.25OD X 1.032 ID X .90 Txt Blk 20572*
3 Wa her - Split Lock, 3/8 ZY, Medium NB711
4 Bolt - 3/8-16 X 1 1/4 GR5 ZY NB618
5 Nut - Nyloc 5/16-18 ZY NB181
6 Nut - Lock, 5/16-18 ZY 2 Way Grade A NB558
7 Bolt - 5/16-18 X 3 HCC GR5 ZY NB563
8 Clutch - Electric; 1" Crank ZTR 50 3813
9 Wa her - Belleville 7/16 X 1 1/4 699
10 Bolt - 7/16-20 X 2 1/2 HCS GR5 ZP Nyloc NB685
11 Muffler - Kawa aki, 14.5HP FS481V 20919
12 Belt - B X 56" 20937
PARTS NOT SHOWN
Valve - Oil Drain 16000
Adapter - Oil Drain, Kawa aki 18810
When ordering replace ent parts
* = USE PAINT CODE: TK=BLACK
IDLER CONFIGURATION
FIGURE 9
Item # Description Part #
1 Nut - Nyloc 3/8-16 ZY NB182
2 Washer - SAE Flat 3/8 ZY Carbon Steel NB2 2
3 Pulley - Idler, OD3.25" ID3/8" B52
4 Nut - HNC, 3/8-16 GR2 ZY NB212
5 Spring - Clutch Rod; T60 682S
6 Nut - Nyloc 3/8-16 ZY NB182
Eyebolt - Turned 3/8-16 X 5 ZY STD 11223
8 Bolt - 1/2-13 X 2 1/2 HCC GR5 ZY NB510
9 Idler - Weldment, Flush 6681*
10 Nut - Jam Lock, 1/2-13 2-Way Gr A NB121
11 Bolt - 3/8-16 X 2 1/2 HTC GR5 ZY NB619
ENGINE PULLEY/BELT ASSEMBLY
FIGURE 8
P/N 20920
P/N 20937
P/N 3813
P/N B527

17
CONSOLE ASSEMBLY
When mounting the console assembly it may be necessary to mount it directly to the hitch tube
depending on the vehicle you are to ing it ith. Some vehicle configurations ill allo the
console to be mounted to the vehicle (i.e. ATV rack). Make sure the iring harness is secure
and ill not drag the ground. Periodically check to make sure all hard are is tight and the
iring harness is secure. NEVER operate this machine ithout the iring harness being secure.
When ordering replace ent parts
* = USE PAINT CODE: TK=BLACK
5
12
3
4
6
7
8
Item No. Description Part #
1 THROTTLE KNOB 686K
2 PTO SWITCH 3605
3 KEY SWITCH 3623
4 PLASTIC CONSOLE COVER 686C mod
5 8-32 X KEP N T NB201
6 1/4'' SAE WA SHER NB274
7 8-32 X 1/2'' PHIL TR SS NB197
8 CONSOLE PLATE WELDMENT 6108TK
9* THROTTLE CABLE 20915
1-9 CONSOLE & WIRING HARNESS 20897
PARTS NOT SHOWN
WIRING HARNESS ONLY 20901
9
*Item 9 is part of Wiring Harness 20901.
WIRING DIAGRAM
FIGURE 11
FIGURE 10

18
REPAIR PARTS
Your 44’’ Trailcutter has been produced ith components designed specific to this machine. Although standard V-
belts, springs, bearings, blades, pulleys, hard are, etc. look similar to parts used on other machinery, they may in
some cases be made of a different construction and/or materials.
Mowers equipped with a 14.5HP engine
have a separate 2.5 gallon fuel tank.
When ordering replace ent parts
* = USE PAINT CODE: TK=BLACK
California compliant mowers are
equipped with a car on canister.
Item # Description Part #
1 Bolt - Serr Flange 1/4-20 X 1 3/4 18236
2 Cap - Fuel 18221
3 Bracket - Fuel Tank 18225
4 Fuel Tank - 2.5 Gallon 18214
5 asher - SAE Flat 1/4 NB274
6 Nut - Nyloc 1/4-20 NB180
7 Cable Tie - Carbon Canister 18219
8 Carbon Canister - 2.50 Gallon 18224
9 Bolt - 10-24 X 3/4 024203
10 Bracket - Carbon Canister 17127
11 Nut - 10-24 Nylon Lock 024900
FIGURE 12 FIGURE 13

Item # Description Part #
1 Guard - Battery Box Lid 21211*
2 Bolt - Flange 5/16-18 NB743
3 T umb Screw - 5/16-18 18802
4 Rubber Pad BATPAD
5 U1 Battery (not included) N/A
6 Rubber Strap AS013
7 Strap Hook AS049
8 Screw - 5/16-18 26X249
9 Nut - 5/16-18 Lock NB181
10 Was er - 5/16 Flat NB275
11 Guard - Battery Box Base 21210*
12 Cage Nut - 5/16-18 21087
13 Bolt - T read Cutting 1/4-20 NB114
14 Solenoid Assembly 12 Volt 1002004
Not S own Battery Cable (Black 10") BCS
Not S own Battery Cable (10" Red) BCSR
Not S own Battery Cable Small Rubber Boot BCBT
BATTERY HOLDER CONFIGURATION
When ordering replace ent parts
* = USE PAINT CODE: TK=BLACK
Note: Use Thum screw [item #3] to hold
lid in the open position as shown in
illustration a ove.
19
Lid Closed Position
Lid O ened Position
FIGURE 1
FIGURE 15
Mower require a U1 attery (not included).

RECOMMENDED HITCH
CONFIGURATIONS AND POSITIONS
FIGURE 19
Unlocked
FIGURE 20
Locked
FIGURE 16
FIGURE 17
FIGURE 18
20
