SWIT CURVE500 Tx User manual

CURVE500 Tx
CURVE500 Rx
500ft Wireless HD
User Manual
Please read this user manual throughout before using
Ver：A
SWIT ELECTRONICS CO., LTD. Model：

Preface
All internal technologies of this product are protected, including device, software and trademark.
Reproduction in whole or in part without written permission is prohibited.
All brands and trademarks of SWIT Electronics Co., Ltd. are protected and other relative
trademarks in this user manual are the property of their respective owners.
Due to constant effort of product development, SWIT reserves the right to make changes and
improvements to the product described in this manual without prior notice.
The warranty period of this product is two years, and does not cover the following:
(1) Physical damage to the products
(2) Any damage or breakdown caused by use, maintenance, or storage not according to the user
manual’s introductions.
(3) The attenuation of signal quality resulting from being used in any special environments.
(4) Any damage caused by not powering the product by package supplied power adaptor.
(5) Any damage or breakdown not caused by the product’s design, workmanship,
manufacturing, quality, or unauthorized repairs or parts replacement or other operations.
For any suggestions and requirements on this products, please contact us, please contact us
through phone, fax, Email, etc.
SWIT Electronics Co., Ltd.
Address: 10 Hengtong Road, Nanjing Economic and Technological Development Zone,
Nanjing 210038, P.R.China
Tel: [phone]
Fax: [phone]
Email: cont[email protected]c
http://www.swit.cc

Safety Precautions
Please follow the safety precautions before using. The following conditions are not covered by
warranty.
1. Unauthorized repairs or other Unauthorized operations.
2. Inappropriate placement including but not limited to lighting, fire, exposure to rain, water or gas.
3. Using the wrong power supply.
Warning
Do not get any liquid inside the products
Do not block the ventilation openings or put substances inside, in order to avoid short circuit,
fire or electric shock.
Do not place the product in the rain or moisture to avoid electric shock or fire.
Danger
Switch the power off before connecting other devices.
Power socket: Make sure the power socket under the voltage range of the product to avoid
short circuit, electric shock and fire.
Power cable: Make sure the power cable is not pressed or tightened by any items or weights.
Power Load: Do not exceed the load on the wall outlet, extension cable or other porous receptacle
to avoid fire or electric shock.
Lightning: Disconnect the power cable if it is lightning or not using in a long period of time.
Working environment
Please don't lay the product on any unstable place to avoid fallen damage.
Please don’t use the product in a place overheating, undercooling or with lots of moisture,
or near by strong magnetic devices.
Please don’t lay the product on metal shelf, in order to ensure the effective wireless transmission.
No.
1
2
3
4
5
6
7
Packing details
Transmitter
Receiver
Antenna
D-tap to lockable pole cable (0.6m)
Power adaptor
User manual
Warranty card
Quantity
X 1
X 1
X 4
X 1
X 1
X 1
X 1
Packing list

1. Product Introduction
2. Features
CURVE500 includes transmitter and receiver，adopts the latest encrypted transmission technology，
Supports HDMI wirelessly transmitted in 150 meters scale(Line-of-sight), 1 channel HDMI digital video
transmission, auto pairing. CURVE500 is equipped with DC power connector, compact size, portable,
and the receiving signal is very stable.
Remark:
1. The transmission distance may be different, and depend on surroundings, radio wave conditions,
buildings, etc., the 150 meters transmission distance may be not guaranteed.
2. The wireless transmission might be interrupted if there’re other devices of 5GHz wireless
bandwidth Used in the same location.
3. Signal reception may be affected by the position, height and angle of devices. If reception video is
not stable, please physically adjust placement for the optimized signal.
4. Set the antennas straight up and set receiver higher to enhance the transmission efficiency.
5. The product offers the AES 128-bit encryption to protect the wireless transmission. Please still be
aware of the intentional signal interception from third person. Do not use it for important
communication.
HDMI Wireless transmission
Support up to 1080P50/60Hz HDMI wireless transmission.。
150 meters transmission distance
In open outdoor area, the effective transmission distance is approx. 150 meters (line of sight).
Wireless frequency
The system adopts 5180~5220MHz and 5760~5820MHz Wireless frequency band(CURVE500 Tx).
Pairing mode
Support auto pairing connection and manual switching of frequency points.
Encryption
Support AES 128-bit encryption to protect the transmission.
All-Metal Shell
Both the transmitter and receiver adopt metal shell which is durable and solid.
All hardware design
The wireless system is hardware and plug-and-play designed, without installing software,
easy to set up.
Frequency Band and Frequency Point
CH00
CH01
CH02
CH03
5180MHz
5200MHz
5220MHz
5760MHz
CH04
CH05
CH06
/
5780MHz
5800MHz
5820MHz
/
Frequency Band and Frequency Point
CH00
CH01
CH02
CH03
5182.5MHz
5202.5MHz
5222.5MHz
5762.5MHz
CH04
CH05
CH06
/
5782.5MHz
5802.5MHz
5822.5MHz
/
The system adopts 5182.5~5282.5MHz and 5762.5~5822.5MHz Wireless frequency band(CURVE500 Rx)。

3. Appearance Instruction
Transmitter CURVE500
⑴ Antenna
⑵ Product label
⑶ Link：Wireless status indicator
⑷ Video：Video signal indicator
⑸ Power：Power status indicator
⑹ Pair：0.96-inch OLED
⑺ Installation thread：1/4”-20 thread. Use the package supplied articulating arm trestle to install
the device to the camera.
⑻ USB：Micro USB，software upgrade interface
⑼ HDMI in：HDMI input (standard HDMI-A type connector).
⑽ Battery plate：“F” plates can be used. We recommend SWIT batteries like: S-8972, S-8970,
S-8770, S-8975 compatible with SONY “ L” series NP-F770/970.
⑾ HDMI LOOP：HDMI loop out (standard HDMI-A type connector).
⑿ ON/ OFF：Power switch
⒀ DC in：Support DC 7～17V input,5.5mm(outer diameter)/2.1mm(inner diameter)
Outside: negative, Inside: positive
Status
Constant On
Off
Constant On
Flash
Constant On
Flash
Description
Power connected and switched on
Power disconnected and switched off
There is recognizable video signal input
There is no recognizable video signal input
The wireless network connection is normal
The wireless network connection is abnormal
Device
CURVE500
Transmitter
LED indicator
Power
Video
Link
The description of LED status indicator
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(10)
(11)
(12)
(13)

Receiver CURVE500
⑴ Antenna
⑵ Product label
⑶ Link：Wireless status indicator
⑷ Video：Video signal indicator
⑸ Power：Power status indicator。
⑹ Pair：Pair button。
⑺ Installation thread：1/4”-20 thread, Use the package supplied articulating arm trestle to install the
device to the camera
⑻ USB：Micro USB，software upgrade interface
⑼ HDMI OUT：HDMI output (standard HDMI-A type connector).
⑽ Battery plate：“F” plates can be used. We recommend SWIT batteries like: S-8972, S-8970, S-8770,
S-8975 compatible with SONY “L” series NP-F770/970/.
⑾ HDMI OUT：HDMI output (standard HDMI-A type connector).
⑿ ON /OFF：power switch
⒀ DC in：Support DC 7～17V input,5.5mm(outer diameter)/2.1mm(inner diameter)
Outside: negative, Inside: positive
Status
Constant On
Off
Constant On
Flash
Constant On
Flash
Description
Power connected and switched on
Power disconnected and switched off
There is recognizable video signal input
There is no recognizable video signal input
The wireless network connection is normal
The wireless network connection is abnormal
Device
CURVE500
Receiver
LED indicator
Power
Video
Link
The description of LED status indicator
(1)
(2)
(3)
(4)
(5)
(6)
(8)
(9)
(10)
(11)
(12)
(13)
(7)

4. Setup connection
5. Pairing
⑴ Connect the HDMI in interface of the CURVE500 transmitter to the HDMI out of the camera or video
output device.
⑵ Connect the HDMI out interface of the CURVE500 receiver to the HDMI in of the monitor or switch station.
⑶ Connect the power supply of CURVE500 transmitter and receiver, the “power” indicator will light up,
“Link” and “Video” indicator light up when the transmitter and receiver have identifiable signal
inputs and connections，“Link” and “Video” indicator will flash if transmitter and receiver have no
identifiable signal input。
Tips：1.
put the power switch to “ON” when connect the power supply of CURVE500 transmitter and receiver.
2. The curve500 transmitter only supports the HDMI video input interface, and the system
automatically detects the input video interface。
⑴ Connect the HDMI in interface of the CURVE500 transmitter to the HDMI out of the camera or video
output device.
⑵ Connect the HDMI out interface of the CURVE500 receiver to the HDMI in of the monitor or switch station.
⑶ Connect the power supply of CURVE500 transmitter and receiver, the “power” indicator will light
up “Video” and “Link” indicator will flash.
⑷ Long pressing the “pair” button in both transmitter and receiver，The “Link” indicator of transmitter
and receiver flash and pair, “Link” indicator lights up，the automatic pairing is successful and
enters the encrypted transmission state.
(5) Press the “Pair” button twice apartly to upgrade the firmware, the “Video” indicator quickly
lashing during upgrade process，“Video” “Link” indicator light up with red, the firmware upgrade
successfully. The “Video” “Link” indicator flash when upgrade is failure
Tips：1.When pairing, the transmitter and receiver need to be paired Simultaneously.
2.During normal use, ensure that the wireless device used has been paired and successfully paired.
3.The paired transmitter and receiver will be automatically connected after booting up. It is no
need to pair again.
4.Please keep the transmitter and receiver in distance of 1-2m to avoid pairing failure.

6. The way to get the best effective of Wireless Transmission
Fig.1
⑴ Set the antenna on both transmitter and receiver vertically straight up. No request to spread. (Fig.1)
⑵ Set the receiver as high as possible to avoid interference.
⑶ Avoid walls, trees and water to reduce signal attenuation.

7. Trouble shooting
If the receiver failed to output video correctly, the possible causes are as below; please find the solution
from following chart:
8. Specification
The receiving
video
No display
Poor
Video quality
Possible causes
The transmitter or the receiver is not
powered on
The antennas are not installed
properly and screwed tightly
Bad connection of video cable
Video format is not supported
Bad connection with video cable
The wireless transmission is
disturbed by environment
The transmission distance is out of
effective range
Solution
Check power connection and switch on
the transmitter and receiver
Install the antennas properly and screw
tightly of both transmitter and receiver
Check video cable connection of both
transmitter and receiver
Change the output video format of the
camera
Reconnect reliably
Wait for 1 minute or reboot the transmitter
and receiver
Put the transmitter closer to the receiver
Model
Input
Output
Video format
Wireless frequency
Modulation mode
Transmission distance
Power consumption
Input voltage
Working environment
Dimension
Net weight（Without antenna）
Net weight（With antenna）
CURVE500 Transmitter CURVE500 Receiver
HDMI×1
HDMI×1
1080I（60/59.94/50）/1080PsF（24/23.98）/720P（60/59.94/50)/1080P
（60/59.94/50/30/29.97/25/24/23.98）
FULL:5180-5220MHz and 5760-5820MHz
OFDM Support 16QAM、64QAM、QPSK、BPSK modulation mode
150m（Line of sight）
≤7.5W
DC/Battery：7～17V
Temperature：0℃~+40℃
114.18×69.55×28（mm）
190.7g
198.6g
/
HDMI×2
≤7W
DC/Battery：7～17V
114.18×69.55×28（mm）
193.3g
201g

FCC Statement
Any Changes or modifications not expressly approved by the party responsible for compliance could void
the user’s authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired
operation.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment .
This equipment should be installed and operated with minimum distance 20cm between the radiator&
your body.
Note : This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates,uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio or television recep-
tion, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
SWIT Electronics Co., Ltd.
Address: 10 Hengtong Road, Nanjing Economic and Technological Development Zone,
Nanjing 210038, P.R.China
Tel: [phone]
Fax: [phone]
Email: cont[email protected]c
http://www.swit.cc
