Safety Precaution
Warning: To reduce therisk of fireor electric shock,do not exposethis apparatus torain
or moisture.
1) Please readthe instruction manualcarefully and followall the requirementsof safe
operation to operatethe device.
2) Do notuse this unitnear water.Do not placeover the unitany container withliquid
inside.
3) Do notinstall near anyheat sources suchas radiators, heatregisters, stoves, orother
apparatus (including amplifiers)that produce heat.
4) Unplug thisunit during lightningstorms or whenunused for longtime.
5) AboutCleaning: Unplug thesystem, use onlywet cloth toclean. Do notuse liquid
detergent or aerosol.
6) Only useaccessories specified bythe manufacturer.
7) Refer allservicing to qualifiedservice personnel, servicingis required whenthe unit
has been damagedin any way, such as power supply cord or plug is damaged, liquid
has been spilledor objects havefallen into theunit, exposed tomoisture, does not
operate normally.Don't try torepair the machineby yourself becauseof the dangerof
high voltage andelectric shock.
8) Do notuse irregular shapeddiscs such asheart or star-shapeddiscs as theymay
cause the unitto malfunction.
Thank you forchoosing our portableDVD player.It includes a7” wide screen anda DVD
player. Theunit applies thelatest state ofart electronics andis designed foruse at home,
in hotels andin offices etcfor relaxation. Thecompact size makescarrying easier as
well as installation.Please read themanual carefully prior to use and keep it well for later
consultation.
Table Of Contents
Safety Precaution 1
Package 2
Main Features 2
Main Unit Controls 3
System Connection 4
The Remote Control 7
Basic operation 9
System Setup 14
Specification 17
Troubleshooting 18

32
Main Features
High brightness color7”LCD screen
Compatible with disc of DVD, VCD,MP3, CD,JPEG, etc.
Built-in stereo speaker
Built-in rechargeable Lithiumpolymer battery
Support PALor NTSC system
Support Multi-language OSD,speed forward/backward, repeatfunction
Zoom in/out function
Main Unit Controls
1
1
1
1
1
1
1
DVD Player
Remote Control withbattery
Audio/Video Cable
AC/DC Power Adapter
Cigarette LighterAdapter
User Manual
Earphone
Package
1
2
3
4
5
6
7
9
17
11
12
13
14
15
16
8
10
1. button
2. button
3. ENTER button
4. MENU button
5. MUTE button
6. SETUP Button
7.STOP Button
8. PLAY/PAUSE Button
9. MODE Button
10.Open knob
11. DC IN 9-12V
12. Power ON/OFFswitch
13. AV OUT
14. SD cardslot
15.Earphone jack
16. Volumeknob
17. USB port
Carrybag 1

Notice:
1.Car cigarettelighter adaptor can'tbe used torecharge the battery.
2.Car cigarettelighter adaptor isavailable to useonly when thecarpower supply is9-12V
negative grounding.
Connecting to TV
You can also connect the unit to a TV toenjoy high qualitypicture and stereosound.
Please refer tothe following illustration:
Please useAV cableto connect the machine and the TV. Make sure it is connected
correctly.
Powering and installation
Plug one endof theAC/DC power adaptorinto the DCIN 9-12V jackon the right of the
machine, then plugthe other endinto theAC power receptacle. Please refer tothe
following illustration
If using carcigarette lighter adaptorto connect tothe power:
Plug one endof the cigarettelighter adaptor intothe DC IN9-12V jack onthe unit, plug
the other endinto the carcigarette lighter socket.See illustration below.
TV
AUDIO IN VIDEO IN
AV CABLE
System Connection
5
4
Not supplied
Using SD/MMC card
Upon using anSD or MMCcard, insert itinto the correspondingslot flatly withthe label
side upward untilyou hear aclick.
Using USB
Upon using anUSB, insert itinto the USBslot directly.

76
Connecting with externalSpeaker
The unit canbe connected withexternal speaker.Please see thefollowing illustration
AMPLIFIER
TV
SUBWOOFER
Left front speaker Right front speaker
Center speaker
Left rear speaker Right rear speaker
Notice:There is no 5.1channel in the unit,however, after connectingto APM itis available to
output audio in5.1 channel
AUDIO IN
VIDEO IN
AV CABLE
1. Number button
2. TITLE (To display title information)
3. AUDIO(Toselect audio language)
4. SETUP (To go toor exit setup menu)
5. Previous/Next button(Togo to
previous/next chapter orscene during
playing)
6. Fast forward/backwardbutton (To
scan forward/backward at2, 4, 8,16,
or 32 times)
7.OSD ( To display discinformation
during playing suchas elapsed and
remaining time)
8. Play/pause
9. Stop (press once tostop playback, then
press to resumeplayback from the
point where youstopped; press stop
button twice tostop playback completely)
10. MODE (To select thesource)
The Remote Control
11. ZOOM(To zoom in/outthe image during
the playback)
12. Menu (To enter orexit menu root)
13. Subtitle (To select subtitlelanguage
when playing DVDdisc)
14. Angle(Tochange viewing anglewhen
playing disc withmulti-angle)
15. A-B(Repeat a specificportion from
point Ato B, pressit again tocancel
repeat playing)
16. Repeat (To repeat playingtitle,
chapter or track)
17. Return (To return tothe main menu)
18. MUTE(To turn tomute)
19. VOL +/- (To adjust thevolume)
20: Enter (Toconfirm)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
Not supplied

8
Playing disc ofDVD, MPEG4, SVCD, VCD, CD, MP3, Xvid
1. Afterconnecting power to the unit, turn on the unitby sliding the ON/OFF
switch to ON,
2. Open thedisc door and insert a disc into the doorwith the label side facing
up.
3. Close thedisc door. The unit will load thedisc and start playing.
4. Press toonce to stop playback; then press to resume playback from
the point whereyou stoped; press twice to stop playback completely.
5. During playback,press to pause; press it again to resume playback.
6. When theplaying is finished,please turn off the powerby sliding ON/OFF
switch to OFF.
7. For someDVD disc with Title or Chapter menu, press “ MENU” button to
enter menu page,and use to select. Press ENTER to confirm.
the source menuwill be displayed on the screen:
Basic Operation
Press to enterDVD mode or Media mode and press OK button to confirm.
When selecting “Media”,ensure to insert USB or SD/MMC card properly
play/pause
DVD MPEG4 SVCD VCD CD MP3 Xvid
DVD
MEDIA
Cursor button
ENTER
Title Menu
9
Note: Please donot disconnect USB devices or plug out SD/MMC cards
while they areworking with the unit. Functional failure may occur in
case of wrongoperations.
1
2
CR2025 CR2025
0
30
0
30
Please put thebattery into theremote control asper below illustration
When using remotecontrol, make surethe
infrared window ispointed to infraredreceiving
window of themachine. The distancebetween
machine and remotecontrol must bewithin 3
metres. Please referto the followingillustration.
Notice
1.To avoid fallingoff or placenear damp environment.
2.To avoid infraredreceiving window ofthe unit beingunder direct sunlight
3.Please usea new batteryto replace old one if the remote control doesn't work.
The Use ofRemote Control

10
DVD MPEG4 SVCD VCD CD
2X 4X
8X16X32X
2X 4X
8X16X32X
DVD MPEG4 SVCD VCD CD
Search forward
Fast forward andfast backward
When playing discof DVD, MPEG4,SVCD,VCD, CD, theunit can searchforward or
backward.
1. Press ,the unit willsearch forward. Pressit repeatedly ,theunit will playat 2, 4,8, 16,
32 times ofspeed.
2. Press ,the unit willsearch backward. Pressit repeatedly ,
the unit willplay at 2,4, 8, 16,32 times ofspeed.
Repeat playing
When playing discof DVD, MPEG4,SVCD, VCD, CD, user can repeatplaying one
chapter, titleor all thewhole disc.
For DVD disc,press “repeat” button, user can repeat playing one Chapter; press it
again to repeatplaying Title;press it thethird time torepeat playing thewhole disc.
For MP3 disc,press “repeat” to repeat playing present file; press it again to repeat
playing the folder;press it thethird time tocancel repeat playing.
Search backward
Chapter Title All
Repeat off
Repeat one Repeat folder
Repeat off
When playing discof DVD, MPEG4,SVCD, VCD, CD,Mp3, user canrepeatedly
play a specificsection.
During playback, press“A-B” button at apoint A,then press
this button againin point B,the unit will automatically repeat
playing the partbetween A-B
Press it thethird time, theunit will returnto normal playback.
1 /4
2 /4
3 /4
4 /4
AB
A
Number
Angle
During playing DVDdisc with multi-angle,press “Angle”
button, the followingswill be displayedon screen:
Press number buttonsto select theangle you desire
Toreturn to normalplaying, please press“Angle” .
The unit willplay the discin the defaultangle.
Notice
The function isavailable only fordiscs with multi-angle.
Angle
A-B
11
Repeat playing offavorite scene
MP3CDVCD
SVCD
MPEG4
DVD

DVD MPEG4 SVCD VCD
2X
3X
4X
1 /2X
1 /3X
1 /4X
Zoom in/out
12
Zoom in/ out
When playing discof DVD, MPEG4,SVCD, VCD,
user can zoomin or zoomout the image.
During playback, press“Zoom ” button, the image will be
enlarged; press itagain the imagewill be enlargedagain;
press it fourthtime, the imagewill zoom out,press it
repeatedly and theimage will returnto normal status.
When the imageis enlarged, usercan press tomove
the image
13
Playing JPG file
1. Place aJPG disc intothe tray,the unit will start reading and play.
2. Press “MENU” to browse JPG files.
3. Press to select aJPG file andpress “ ENTER” button to confirm.
Note: you canpress MENU toreturn to thefolder list. Press or “ ” to
preview the fileselected
4. Torotate the picturecounter-clockwise, press “ ”;Press “ ”to rotate thepicture
clockwise
5. Press OSD buttonwhen viewing pictures,you can selectdifferent refresh modeas
follows:
. from topto bottom
. from bottomto top
. from leftside to rightside
. from rightside to leftside
. from lefttop to rightbottom
. from righttop to left bottom
. from leftbottom to righttop
. from rightbottom to lefttop
. from horizontalcenter to both sides
. from verticalcenter to both sides
from top andbottom to center.
. from rightand left to center.
. from fourwindow's top sideto bottom side.
. from fourwindow's left sideto right side.
. from 4edges to center.
6. During viewingfiles, “ “ may appear when pressing or "Subtitle"or "Audio"
or "A-B" or"Title" etc; in this situation these options are unavailable to operate.
7. When viewingJPG files, press" " ,pictures will bedisplayed in thumbnailmode,
press or “"button to selectone picture toview
Playing MP3 files
1.Place MP3disc into thedisc door or insert USB disc, SD card to USB port or SD card slot.
Press “ ” or “ ” button to choosea MP3 file; Press “ ” or “ ” button to
play the fileselected.
ENTER
ENTER
ENTER ENTER
00 36 03 43
Dir 001
\Ctyy\
......
Mp3 TRACK01
Mp3 TRACK02
Mp3 TRACK03
Mp3 TRACK04
Mp3 TRACK05
"Angle”
/

14
General Setup Page
Angle Mark:
Enter this option toset the angle duringplayback.
Optional setting: ON, OFF
The default is: ON
Screen Saver
Enter this option toset whether to activatethe screen saver
function.
The default is ON.
--General Setup Page--
TV Display Wide
Angle Mark ON
TV Type NTSC
Screen Saver ON
OSD Lang ENG
Normal/PS
Normal/LB
Wide
--General Setup Page--
TV Display Wide
Angle Mark ON
TV Type NTSC
Screen Saver ON
OSD Lang ENG
On
Off
--General Setup Page--
TV Display Wide
Angle Mark ON
TV Type NTSC
Screen Saver ON
OSD Lang ENG
PAL
NTSC
--General Setup Page--
TV Display Wide
Angle Mark ON
TV Type NTSC
Screen Saver ON
OSD Lang ENG
On
Off
TV display:
Enter this option,user canset screen display format
(Nomal/PS,Nomal/LB,Wide)
The default is "Wide"
Note
The function depends onthe display ratio withwhich the
DVD disc is recorded.
Please choose “Wide(16:9)"when using a16:9 widescreen
TV set
TV Type:
Enter this option toselect TV type(PAL,NTSC)
The default is PAL.
System Setup
--General Setup Page--
TV Display Wide
Angle Mark ON
TV Type NTSC
Screen Saver ON
OSD Lang ENG
Press”Setup”button,the main menu willbe displayed on the
screen
In the General SetupPage, Press button tohighlight this
item.
Press ENTER button toaccess.
Press button to selectthe setting.
Press ENTER button toconfirm your selection.
Press button to exit.
Audio:
Enter this option, usercan select your preferredaudio
language for DVDs.
The default is English
Note
The audio language dependon the material oneach disc.
User can also changethe audio language duringplayback
by pressing theAudio button.
Subtitle
Select your preferred languageto show the subtitles
on the screen.
The default is OFF
The subtitle languages dependon the
information available on eachdisc,You canalso change the
subtitle language during playbackby press the SUBTITLE
button.
Enter this option, usercan adjust picture qualityof video
output. There are itemsavailable to be adjusted:
Brightness, Contrast, Hue andSaturation.
For all these itemsthe default is 00
Enter this option,you canset a password(four numbers).
All parental Control featuresare password protected.
The default is 8888.
15
Password Setup Page
English
French
German
Italian
Video Setup Page
Preference Page
--Password Setup Page--
Go To Password Setup Page
--Video Setup Page--
TV Display Wide
Angle Mark ON
TV Type NTSC
Screen Saver ON
OSD Lang ENG
Preferred Audio Language
Audio ENG
Subtitle OFF
Disc Menu ENG
Parental
Default
Preferred Subtitle Language
Audio ENG
Subtitle OFF
Disc Menu ENG
Parental
Default
Go to Video Setup Page
--General Setup Page--
--Preference Page--
--Preference Page--
Panel Quality
Password
English
French
German
Italian
English
French
German
Italian
Off
Go to General Setup Page
Set TV Display Mode
Set Angle Mark
Set TV Standrd
Set Screen Saver
Set OSD Language
OSD Language:
In the option usercan set OSD menulanguage(English,
French,German,Italian).
The default:English

Disc Menu
This function allows youto choose the menulanguage
stored on the disc.
The default is English.
Note: the disc menulanguages depend on the
information available on thedisc.
Parental:
Enter this option toset the parental controllevel to some
unsuitable disc scenes beingwatched by the children.
Optional parental control levels:KID SAFE, G, PG,PG 13, PGR,
R, Nc17, ADULT.
The default of thisoption is ADULT.
Default:
Select this item andpress ENTER button toreset
all settings to theoriginal factory settings.
--Preference Page--
Preferred Menu Language
Audio ENG
Subtitle OFF
Disc Menu ENG
Parental
Default
--Preference Page--
Set Parental Control
Audio ENG
Subtitle OFF
Disc Menu ENG
Paretal
Default
1 KID SAFE
2 G
3 PG
4 PG 13
5 PGR
6 R
7 NC 17
8 ADULT
--Preference Page--
Load Factory Setting
Audio ENG
Subtitle OFF
Disc Menu ENG
Parental
Default Reset
The unit utilizeslong-life Li polymerbattery for portablepower supply.The battery has
no "Memory Effect"and thus can be recharged safely regardless of whether the battery
is fully orpartially discharged. It'senough to rechargeno longer than6H each time,fully
recharged battery canlast about 2hours.
The battery canbe only rechargedwhen turning powerto OFF state,and keep continuous
power supply,the red light will be on, and the light will turn yellow when it's fully charged.
1. The normalworking temperature is: 0 ~40 ;
2. Alwaysunplug AC/DCpower supply forthe unit whennot in use;
3. Heat willcreate during playing,it's normal, whileavoid long timeplaying and
unattended;
4. Avoidhaving the unit collide with any objects, and place away from all possible heat
sources or dampareas.
°C °C
Using and MaintainingRechargeable Battery
Specification
Compatible disc: DVD/VCD/CD/MP3/MPEG4
Signal system: PAL/NTSC
Panel size: 7inch
Picture resolution: 480x234(RGB)
Frequency response: 20Hz to 20 kHz
Video output: 1Vp-p/75 Ohm, unbalanced
Audio output:1.4Vrms/10kOhm
Audio S/N:Better than 80dB
Dynamic range: Betterthan 85 dB
USB: support USB1.1
Laser: Semiconductor Laser, Wave Length: 650 nm/795 nm
Power source: DC9-12V
Power consumption: 10W
Operating temperature: 5~40°C
Weight: 0.82kg
Dimensions (W xD x H):213 x 175.5x 42 mm
Battery Type:Li Polymer
Precautions related toBattery Recharge
17
Rechargeable battery use
16
English
French
German
Italian

18
Troubleshooting
PROBLEM SOLUTION
No sound or
distorted sound
Make sure themachine is connectedproperly.
Make sure allcables are securelyinserted into
the appropriate jacks.
The icon
appears on
screen
Can't advance
through a movie
Picture is distorted
No forward or
reverse scan
You can't advance through the opening credits
and warning informationthat appears atthe
beginning of moviesbecause the discis
programmed to prohibitthat action.
The feature oraction cannot becompleted at
this time because:
1. The disc'ssoftware restricts it.
2. The disc'ssoftware doesn't support the
feature (e.g., angles)
3. The featureis not available at the moment.
4. You've requested a title or chapter number
that is outof range.
Some discs havesections that prohibitrapid
scanning or chapterskip;
If you tryto skip throughthe warning information
and credits atthe beginning ofa movie, you
won't be ableto. This partof the movie is often
programmed to prohibitskipping through it.
The disc mightbe damaged. Try another disc;
It is normalfor some distortionto appear during
forward or reversescan.
Owing to continuous improvement, no prior notice will be given regarding changes on above
feature and spec.
