Introduction and General Notes
Introduction
About This Document
The purpose of this document is to introduce the Symetrix
Control Protocol for Composer. This document defines and
illustrates the protocol used to communicate with Edge,
Radius, Radius AEC, xControl, or other compatible Symetrix
units via a third-party control interface using RS-232, TCP/IP,
or UDP/IP.
Compatible units can be controlled by third-party controllers
such as AMX or Crestron models, or any RS-232 or Ethernet
equipped unit that can be adapted to the Composer control
protocol. The protocol consists of human-readable text
commands and responses.
Control is achieved by using a scheme of user-assigned
controller numbers. Nearly anything that can be adjusted
from the Composer control and configuration application
can be controlled externally by referencing the appropriate
controller numbers that are defined using Composer.
Conventions Used In This Document
Values enclosed in [square brackets] are optional parameters
and do not need to be included. If omitted, default values
will be used as described for each command.
The term “control application” is used to refer to Composer
software provided by Symetrix to configure and control
Symetrix units.
General Notes
Connections
Units are equipped with an Ethernet port and one or more RS-
232 ports. Either port may be used to control the unit. Ethernet
is generally preferred because of the simplified set-up and
higher data rates.
RS-232 Port Configuration
Connect your RS-232 based accessory remote to the
RS-232 port. For testing purposes, a terminal emulation
program such as HyperTerminal, TeraTerm, or puTTY can
be run on a PC instead. Typically this connection requires
a “straight through” cable, but a null-modem cable may be
required depending on the manufacturer. In general, if the
genders of the two connectors you are trying to connect
are the same, a “null modem” cable is required. Set up the
controller for baud: 57600, data bits: 8, stop bits: 1, parity:
NONE. No handshaking or flow control is used. The straight-
through pin out for a typical application is shown in the
following figure.
The commands Set Baud, Set Quiet Mode and Set Echo
affect the RS-232 port. Composer determines the start-up
values of these settings, though this can be changed during
a session. The unit’s default settings (Baud 57600, Quiet
Mode ON, Echo OFF) are typical for most applications.
These commands are documented for reference on page
18.
Ethernet Port Configuration
Generally, no special configuration is required for the
Ethernet port. The Ethernet port on the unit may be used
for both the Composer control application and for external
control.
Take note of the unit’s IP address (listed in the System
Manager), as you will need to send all commands to this
address.
The commands Set Quiet Mode and Set Echo affect the
Ethernet port. Composer determines the start-up values
of these settings, though this can be changed during a
session. The unit’s default settings (Quiet Mode ON, Echo
OFF) are typical for most applications.These commands are
documented for reference on page 18.
Ethernet Control
The Ethernet protocol uses the same RS-232 command
protocol over an Ethernet network. Both TCP/IP and
UDP can be used to control the system. TCP/IP control
functionality was added in Composer 3.0. TCP/IP control
does not use any of the options or escape sequences found
in Telnet. Up to six TCP/IP telnet sessions can be active at
one time (four with versions prior to Composer 6.0).
If a seventh TCP/IP connection is initiated, the least recently
used session will be automatically closed. Sessions may also
be closed manually with the Q! command described later in
this document.
Control systems should avoid closing and re-opening TCP
connections if possible. Keeping a single TCP session open
to send multiple commands through will result in much
better performance than opening and closing a session for
each command.
To control the system with Ethernet, command strings are
sent as the payload of a UDP/IP or a TCP packet. The
following rules should be observed in sending commands:
Pin 3Pin 1
Pin 2
Pin Signal
1 Ground
2 RX
3 TX
Terminal Block
Pin 5Pin 1
Pin 6 Pin 9
Control System (DB9 Male)
Symetrix (Terminal Block Female)
Pin Signal
1
2 TX
3 RX
4
5 Ground
6
7
8
9
DB9 Male
3 25
of
www.symetrix.co | T+1.425.778.7728

General Notes
• Commands should be sent to UDP or TCP port number 48631
of the Edge or Radius unit’s IP address. The IP address may be
found using the Connection Wizard or on some units’ front panel
displays.
• Commands should be formatted exactly as defined in this
document and include a carriage return that terminates the
command.
• Command strings may or may not include a zero termination
character.
• Commands should not be broken up across multiple packets.
• If high reliability communications are required, responses to
commands should be analyzed for success.
Responses to commands will exhibit the following behavior:
• Responses to each command issued are returned in a single
packet unless the response is larger than a single packet
can hold. Responses will not have any single carriage return-
terminated line broken up across packets unless there is no
carriage return in the data of the response.
• Responses are returned only to the IP address and source
port number that sent the packet. Other connections will see
responses if the particular control numbers are ‘push’ enabled.
• Responses follow the configuration of the port, just as if it were
an RS-232 port. For example, echo mode and quiet mode are
kept independently for the RS-232 port, the UDP port and the
TCP port.
• Responses do not include a zero-termination character.
• All transmissions originating from units will either be responses to
commands or pushed data.
Each command sent to a Symetrix unit contains information
in the Ethernet packet header as to who sent the command,
and hence, where a response will be sent. This source
information is saved when a packet is received by a Symetrix
unit. For UDP, all responses go to the last received IP
address and port and this IP address and port number are
saved in non-volatile memory across power cycles. For TCP,
the control system must re-initiate the TCP connection after
a power cycle.
Until the first command is received, responses will not know
where they are supposed to be sent. This normally is not an
issue as communication from the Symetrix unit is generally
a response to a command. However, if the Symetrix unit is
set up to push control data, it will also be pushed out the
TCP and UDP ports. If no valid packets have ever been
received by a Symetrix unit and no TCP/IP connections are
active, pushed data will not be sent out the Ethernet port. If
a Symetrix unit and a TCP connection is active, then pushed
data will be transmitted over TCP. If valid packets have been
received over UDP by a Symetrix unit, then pushed data will
be transmitted over UDP.
Pushing of data can be controlled independently for RS-232
and Ethernet ports.
Note: The RS-232 serial port and the Ethernet port are
essentially independent. They maintain separate settings
for quiet and echo modes. Commands sent to one port are
not echoed out the other, and responses are sent only to
the port from which the command was received. Hence, the
two ports will not necessarily send out the same data. One
exception to this is push data and strings, which are sent
out both RS-232 and Ethernet ports in parallel.
RS-485 Control
RS-485 control is generally done using one or more of the
Symetrix ARC (Adaptive Remote Controller) units. Further
discussion of RS-485 and the ARCs can be found on the
Symetrix web site.
Site Identifier
By default, any control data sent to a Symetrix unit (via
ARC, RS-232, UDP/IP, or TCP/IP) will be re-broadcast over
Ethernet by the unit that receives the command to all units
that are connected via Ethernet. This ensures that multiple
Symetrix units with the same Site Identifier that are using
the same control numbers will also receive and interpret the
command and respond to the command appropriately (i.e.,
adjust faders, button states, etc).
When the system consists of multiple independent site files
on the same network and you do not want control data
for common control numbers to be shared between these
different site files, each site file must have a unique site
identifier set in Composer. Unique Site Identifiers in the site
file inform other systems with different site identifiers on the
same network to ignore the re-broadcasted commands.
Using unique Site Identifiers for different site files on the
same network does not require any change in how the
systems are controlled from a third-party control system.
The third-party control system continues to send commands
to the Symetrix device to be controlled and that device
re-broadcasts that command along with the additional
information of the site identifier onto the network. Symetrix
units with Site Identifiers that are different from the site
identifier in the re-broadcasted command will simply ignore
the re-broadcasted command.
4 25
of
www.symetrix.co | T+1.425.778.7728

Parameter Notes
To set the identifier, within Composer, navigate to Tools >
Site Preferences and change the site identifier as shown in
the following figure.
Parameter Notes
Faders
Faders can be controlled to the limits of their minimum
and maximum values shown in the Design View screens in
Composer. A controller position of zero (0) will cause the
minimum fader position to be realized. A controller position
of 65535 will cause the maximum fader position to be
realized. Increasing positions will move the fader linearly in
dB.
Most volume faders have a range of -72dB to +12dB. In
these cases, the following formula can be used to convert
from controller position to dB:
Volume dB = -72 + 84*(CONTROLLER POSITION/65535)
If CONTROLLER POSITION = 0, Volume dB = OFF
For these faders, a value of 780 is approximately equal to a
1dB change in gain.
Note that some faders have a different range than –72 to
+12dB. In this case, the formula will depend upon the actual
fader range. The more general formula is shown below:
Volume dB = MINIMUM VALUE + (MAXIMUM VALUE – MINIMUM
VALUE)*(CONTROLLER POSITION/65535)
Where MINIMUM VALUE is the fader’s lower limit in dB and
MAXIMUM VALUE is the fader’s upper limit in dB.
Faders with User Min and User Max Limits
There are some applications where it is desired to limit the
range of adjustments for an end user, perhaps to allow a
more useable range of adjustment than the full range of the
fader or to prevent the system from getting too loud. To
limit the gain range of a fader to a user minimum and user
maximum range, the following formulae may be used.
In the following discussion, it is assumed that the range of
the variables (in dB) are as follows:
MAXIMUM VALUE ≥ User Maximum ≥ User Volume ≥ User
Minimum ≥ MINIMUM VALUE
The controller position is calculated the same as described
previously:
To determine the controller position based on a desired
User Volume in dB, then the controller value is calculated as
follows:
Controller Position = (User Volume in dB – MINIMUM VALUE) *
65535 / (MAXIMUM VALUE – MINIMUM VALUE )
The percentage value of the fader control relative to the User
Min and User Max values is computed as:
Volume Percent = (User Volume in dB – User Min) / (User Max –
User Min)
The controller position required to set the fader to a
percentage of the user min and user max may be computed
as follows:
Controller Position = (Volume Percent * (User Max – User Min)
+ (User Min – MINIMUM VALUE)) * 65535 / (MAXIMUM VALUE –
MINIMUM VALUE)
For example, if the Maximum and Minimum Values are +12
and -72, respectively, and the desired User Max and User
Min are +6 and -30 respectively, then the controller value for
setting the fader to -8dB is:
Controller Position = ((-8) – (-72))* 65535 / ((+12) – (-72)) =
49931
The controller position corresponding to 35% volume with
the same User Max and User Min range would be:
Controller Position = (35% * ((+6) - (-30)) + ((-30) - (-72))) *
65535 / ((+12) - (-72)) = 42598
5 25
of
www.symetrix.co | T+1.425.778.7728

Calculating the Volume in dB from the Volume Percentage
would be done as follows:
Volume in dB = (Volume Percent * (User Max – User Min)) + User Min
In this example, the volume in dB corresponding to 50% of
the volume would be calculated as:
Volume in dB = 50% * ((+6) – (-30)) + -30 = -12 dB
Buttons
Buttons such as a mute or bypass can be controlled
similarly with controller positions by sending the minimum
value (0) to turn the switch off (button not pushed) and
sending the maximum value (65535) to turn the switch on
(button pushed).
Input and Output Selectors
A value of zero (0) will select the first input or output and a
value of (65535) will select the last input or output. Other
values are selected by sending evenly spaced (linear) values
as shown by the formula below:
Controller Value = (INPUT NUMBER - 1)
*65535/(NUMBER OF INPUTS - 1)
Note: for an output selector, replace “INPUT” with
“OUTPUT” above.
Meters
Meters can be read via RS-232 or Ethernet. The read back
value will be linear in dB with 65535 representing +24 dBu (0
dBFS) and 0 representing -48 dBu (-72 dBFS) (or less). The
formula below can be used to calculate a dB reading from a
controller value:
Level dBu = 72*(CONTROLLER VALUE/65535) - 48
If CONTROLLER VALUE = 0, Level dBu <= -48 dBU
Input and output meters in some other modules such as
Compressors and AGCs can also be read. In this case, the
read back value will be linear in dB with 65535 representing
the maximum value shown on the meter and 0 representing
the minimum value shown on the meter (or less). The
formula below can be used to calculate a dB reading from a
controller value:
Level dB = (MAXIMUM VALUE - MINIMUM VALUE)
*(CONTROLLER VALUE/65535) + MINIMUM VALUE
If CONTROLLER VALUE = 0, Level dB <= MINIMUM VALUE
Where MINIMUM VALUE is the meter’s lower limit in dB and
MAXIMUM VALUE is the meter’s upper limit in dB.
Control meters in dedicated control meter modules can
also be read. In this case, the read back value will be linear
with 65535 representing 100% and 0 representing 0%.
The formula below can be used to calculate a percentage
reading from a controller value:
Level % = 100*(CONTROLLER VALUE/65535)
Note: Meters are a “read-only” parameter. Attempting to
change the meter value will have no effect.
LEDs
LEDs in various modules can be read via the control
protocol. The read back value will be either 65535 if the LED
is on or 0 if the LED is off.
Note: LEDs are a “read-only” parameter. Attempting to
change the LED value will have no effect.
Diagnostic Controls
Connected LED
The read back values are:
0 = Disconnected
65535 = Connected
Network Diagnostics Panel
DHCP Enabled LED - Only DHCP Enable can be read unless
using SymVue. The read back values are:
0 = DHCP Disabled
65535 = DHCP Enabled
Power Supply Diagnostics Panel
All voltages are in .001V increments offset by 32768. The
read back values of 0-65535 translate to -32.768V-32.767V.
Status LED - The read back values are:
0 = OK
65535 = Failed
Thermal Diagnostics Panel
Peak temperature date and time can only be read in
SymVue. All temperatures are in .01 degree C increments
offset by 32768. The read back values of 0-65535 translate
to -327.68V-327.67V.The Fan speed is 0-65535 Hz.
Status LED – Send -65535 to clear, The read back values are:
0 = OK
65535 = Failed
Control Diagnostics Panel
All read back values:
0 = Inactive/Off
65535 = Active/On
Parameter Notes
6 25
of
www.symetrix.co | T+1.425.778.7728

Getting Started and Control Commands
Other Parameters
Many other parameters such as compression ratios,
delay times, EQ settings and pans can also be controlled
externally. In fact, almost any DSP parameter in Composer
can be controlled. For other parameter types, as in the
above examples, sending a value of zero (0) will set the
parameter to its minimum value and sending a value of
(65535) will set it to its maximum value. Ratios, frequencies,
width/Q, and attack/release/hold times all use a logarithmic
scale. Pans and delay times use a linear scale. Quantities
expressed in dB such as gains, volumes, thresholds and
depths are linear in dB. When in doubt, experiment by
changing a value from the control application and reading it
back via RS-232 or Ethernet.
Parameters That Cannot Be Controlled
Externally
The following Composer features cannot be controlled
externally. In some cases, work arounds are suggested.
FUNCTION DESCRIPTION
1. Oscilloscope: Trigger and Auto-Range
controls
2. Parametric/British EQ: Flatten All and Octaves/Q
buttons
3. Graphic EQ: Flat button
4. Feedback Fighters: Response Preset buttons
5. Matrix: Mute All and Disconnect
All buttons (use individual
mute or disconnect buttons
instead)
6. Mixers: Link buttons (assign same
controller to all linked faders
instead)
7. SPL Computers: Calibrate button
8. Loudspeaker
Managers:
Flatten All
9. Send/Return: Meters (use meters inside
I/O blocks)
10. Delay: Default temperature button
11. Meter Bar: All meters
12. Fader Control Input: Log/linear buttons
13. String Output: All parameters
14. RS-232/485 Input: Controller number
Getting Started
Protocol
The Control Protocol is a text-based (ASCII string) protocol.
Commands are sent with simple character strings with terms
separated by spaces and completed with a carriage return
character <CR> (ASCII code decimal 13). The general form
for commands is:
<COMMAND> <PARAMETER1> <PARAMETER2> … <CR>
A white space character (space or tab) must be included
between the command and each parameter. Extra white
space characters can be sent for readability if desired. In
this document a single space will be used. If a command
is accepted, the unit will respond to each command with
an acknowledgement string whose syntax varies with each
command.
Control Commands
(CS) Controller Set
Use this command to move a controller position to a new
absolute value. The command must specify the controller
number and the new controller position. The syntax of the
command is:
CS <CONTROLLER NUMBER> <CONTROLLER
POSITION><CR>
Where <CONTROLLER NUMBER> is the decimal
controller number (1-10000) assigned in Composer, and
<CONTROLLER POSITION> is a 16-bit number in decimal
(0-65535).
If the command is accepted, the unit will respond with the
string:
ACK<CR>
If the command is interpreted but fails for any reason the unit
will respond with the string:
NAK<CR>
A typical reason for failure is that the specified controller
number does not exist.
7 25
of
www.symetrix.co | T+1.425.778.7728

Control Commands
(CSQ) Controller Set Quick
Use this command to move a controller position to a new
absolute value quicker than using the CS command. The
CS command may take up to 40ms before responding
with an ACK because the unit is verifying that the specified
<CONTROLLER NUMBER> exists in the site. The CSQ
response will be sent with 5-10ms for a single operation and
within 2ms each for single burst operations. The command
must specify the controller number and the new controller
position. The trade off is that the CSQ command will not
check to see if the specified <CONTROLLER NUMBER>
exists in the site. Note: It will always respond with an ACK
even if it does not. If your control system does not need to
check that the controller number was correctly set, the CSQ
command may be used without any downside.
The syntax of the command is:
CSQ <CONTROLLER NUMBER> <CONTROLLER POSITION><CR>
Where <CONTROLLER NUMBER> is the decimal
controller number (1-10000) assigned in Composer, and
<CONTROLLER POSITION> is a 16-bit number in decimal
(0-65535).
The device will respond with the string whether it recognizes
the controller number or not:
ACK<CR>
(CC) Change Controller
Use this command to move a controller to a new relative
value. This command will increment or decrement a
controller by a specified amount. The command must
specify the controller number, whether it should be
incremented or decremented, and the amount to change by.
The syntax of the command is:
CC <CONTROLLER NUMBER>
<DEC/INC> <AMOUNT><CR>
Where <CONTROLLER NUMBER> is the decimal controller
number (1-10000) assigned in Composer, <DEC/INC> is
0 to decrement and 1 to increment, and <AMOUNT> is
the amount to increment or decrement (a decimal number,
0-65535). If the amount to be decremented or incremented
causes the parameter to exceed its minimum or maximum
value, the value will be limited to its minimum or maximum
value. For example, if you increment a parameter by 10 and
its current value is 65530, the new value will be limited to
65535.
If the command is accepted, the unit will respond with the
string:
ACK<CR>
If the command is interpreted but fails for any reason the unit
will respond with the string:
NAK<CR>
A typical reason for failure is that the specified controller
number does not exist.
(GS) Get Controller
This command will return the controller position (value)
associated with a specific controller number. The command
must specify the controller number. The syntax of the
command is:
GS <CONTROLLER NUMBER><CR>
Where <CONTROLLER NUMBER> is the decimal controller
number (1-10000) assigned in Composer.
If the command is accepted, the unit will respond with the
string:
<CONTROLLER POSITION><CR>
Where controller position is a 16-bit number in decimal (0-
65535)
If the command is interpreted but fails for any reason the unit
will respond with the string:
NAK<CR>
A typical reason for failure is that the specified controller
number does not exist.
If the value being requested is a button that only has
two states, the returned values will be either 0 or 65535,
regardless of the actual value sent to the controller. For
example, assume controller number 1 controls a mute
button. If you send
CS 1 754 <CR>
and then
GS 1 <CR>
the response will be
0<CR>
not
754<CR>.
More generally, if the parameter you are controlling has
granularity coarser than the 16-bit values used, the returned
values will be quantized to the granularity of the parameter.
Controls where you might observe this effect are buttons as
mentioned above and input selectors.
If the same controller number is controlling multiple
parameters in Composer, only one acknowledgement value
is returned from the system.
8 25
of
www.symetrix.co | T+1.425.778.7728

Control Commands
(GS2) Get Controller with Controller
Number
This command will return the controller number with
controller position (value) associated with it together in the
same string. This command is provided at the request of
third-party control programmers, including AMX/Crestron
programmers, to make it easier to interpret and parse
returned controller positions. The command must specify
the controller number. The syntax of the command is:
GS2 <CONTROLLER NUMBER><CR>
Where <CONTROLLER NUMBER> is the decimal controller
number (1-10000) assigned in Composer.
If the command is accepted, the unit will respond with the
string:
<CONTROLLER NUMBER> <CONTROLLER POSITION><CR>
Where controller position is a 16-bit number in decimal
(65535).
For example, sending the command
GS2 368 <CR>
Will return the response in the format below when the
parameter value is 47114:
368 47114 <CR>
If the command is interpreted but fails for any reason the unit
will respond with the string:
NAK<CR>
A typical reason for failure is that the specified controller
number does not exist.
(GPR) Get Preset
This command will return the last preset that was loaded.
The syntax of the command is:
GPR<CR>
If the command is accepted, the unit will respond with the
string:
<PRESET NUMBER><CR>
The <PRESET NUMBER> return value will be 0-1000. A
return value of 0 indicates that no preset has been recalled.
The value for the preset number will always be 4 digits, with
leading zeros added as necessary (e.g. 7 would be returned
as 0007).
If the command is interpreted but fails for any reason the unit
will respond with the string:
NAK<CR>
(GSB) Get Controller Block
This command will return the controller position (value) of
a specific range of consecutive controller numbers. The
command must specify the starting controller number and
the number of consecutive controllers to return. The syntax
of the command is:
GSB <CONTROLLER NUMBER> <BLOCK SIZE><CR>
Where <CONTROLLER NUMBER> is the decimal controller
number (1-10000) assigned in Composer and <BLOCK
SIZE> is the number of consecutive controllers. Note that
<BLOCK SIZE> can be at most 256.
If the command is accepted, the unit will respond with the
string:
<CONTROLLER POSITION1><CR>
<CONTROLLER POSITION2><CR>
<CONTROLLER POSITION3><CR>
…
<CONTROLLER POSITIONn><CR>
Where <CONTROLLER POSITIONn> is a 16-bit number
in decimal (0-65535), or -1 if a controller does not exist. The
values will always be five digits, with leading zeros added as
necessary (e.g. 7 would be returned as 00007<CR> and -1
would be returned as -0001<CR>.)
If the command is interpreted but fails for any reason the unit
will respond with the string:
NAK<CR>
A typical reason for failure is that the requested block size
is larger than 256. For more information and tips on reading
back controller numbers, see the GS command.
Example command sent:
GSB 9 3<CR>
Example Response:
32321<CR>
00256<CR>
00003<CR>
9 25
of
www.symetrix.co | T+1.425.778.7728

Control Commands
(GSB2) Get Controller Block with Controller
Number
This command will return the controller number with
controller position (value) associated with it for a specific
range of consecutive controller numbers. The command is
very similar to GSB described above, but the return string
may be easier to process in some systems. The command
must specify the starting controller number and the number
of consecutive controllers to return. The syntax of the
command is:
GSB2 <CONTROLLER NUMBER> <BLOCK SIZE><CR>
Where <CONTROLLER NUMBER> is the decimal controller
number (1-10000) assigned in Composer and <BLOCK
SIZE> is the number of consecutive controllers. Note that
<BLOCK SIZE> can be at most 256.
If the command is accepted, the unit will respond with the
string:
#<CONTROLLER NUMBER1>=
<CONTROLLER POSITION1><CR>
#<CONTROLLER NUMBER2>=
<CONTROLLER POSITION2><CR>
#<CONTROLLER NUMBER3>=
<CONTROLLER POSITION3><CR>
…
#<CONTROLLER NUMBERn>=
<CONTROLLER POSITIONn><CR>
Where <CONTROLLER NUMBERn> is the decimal
controller number (1-10000) assigned in Composer and
<CONTROLLER POSITIONn> is a 16-bit number in
decimal (0-65535), or -1 if a controller does not exist. The
values for the controller number and position will always be
five digits, with leading zeros added as necessary (e.g. 7
would be returned as 00007 and -1 would be returned as
-0001).
If the command is interpreted but fails for any reason the unit
will respond with the string:
NAK<CR>
A typical reason for failure is that the requested block size
is larger than 256. For more information and tips on reading
back controller numbers, see the GS command.
Example command sent:
GSB2 9 3<CR>
Example Response:
#00009=32321<CR>
#00010=00256<CR>
#00011=00003<CR>
(GSB3) Get Controller Block with Controller
Number
This command will echo the command and then return the
controller number with controller position (value) associated
with it for a specific range of consecutive controller numbers.
The command is very similar to GSB2 described above, but
the return string includes the original command followed by
the GSB2-style response. The syntax of the command is:
GSB3 <CONTROLLER NUMBER> <BLOCK SIZE><CR>
Where <CONTROLLER NUMBER> is the decimal controller
number (1-10000) assigned in Composer and <BLOCK
SIZE> is the number of consecutive controllers. Note that
<BLOCK SIZE> can be at most 256.
If the command is accepted, the unit will respond with the
string:
GSB3 <CONTROLLER NUMBER> <BLOCK SIZE> <CR>
#<CONTROLLER NUMBER1>=
<CONTROLLER POSITION1><CR>
#<CONTROLLER NUMBER2>=
<CONTROLLER POSITION2><CR>
…
#<CONTROLLER NUMBERn>=
<CONTROLLER POSITIONn><CR>
Where <CONTROLLER NUMBERn> is the decimal
controller number (1-10000) assigned in Composer and
<CONTROLLER POSITIONn> is a 16-bit number in
decimal (0-65535), or -1 if a controller does not exist.
If the command is interpreted but fails for any reason the unit
will respond with the string:
NAK<CR>
A typical reason for failure is that the requested block size is
larger than 256.
Example command sent:
GSB3 140 3<CR>
GSB3 00140 00003<CR>
00140=00000<CR>
00141=65535<CR>
00142=32768<CR>
10 25
of
www.symetrix.co | T+1.425.778.7728

Control Commands
(LP) Load Preset
This command will load the specified preset (1-1000). The
syntax of the command is:
LP <PRESET NUMBER><CR>
Where <PRESET NUMBER> = 1-1000
If the command is accepted, the unit will respond with the
string:
ACK<CR>
If the command is interpreted but fails for any reason the unit
will respond with the string:
NAK<CR>
A typical reason for failure is that the specified preset has not
been defined.
(FU) Flash Unit LEDs
This command momentarily flashes the front panel LEDs of
the unit. This command can be used as a quick test to verify
communications. The syntax of the command is:
FU [<cycles>] <CR>
<cycles> indicates the number of times to cycle the LEDs
on and off. If <cycles> is set to zero, it halts the flashing
immediately. If not specified, it defaults to 8 cycles.
If the command is accepted, the LEDs will flash and the unit
will respond with the string:
ACK<CR>
If the command is interpreted but fails for any reason the unit
will respond with the string:
NAK<CR>
(SSYSS) Set System String
This command sets a system string such as a speed dial
name or number. The syntax of the command is:
SSYSS <unit>.<resource>.<enum>.<card>.<channel>
=[<value>]<CR>
Sets the string resource defined by the 5 parameters above
to <value>. Supported values for <resource> are shown in
the following table:
Resource Number Resource Name
1000 Speed dial number
1001 Speed dial name
1004 Number to dial (VoIP only)
<unit> is the unit enumerator after the dash shown in
Composer above each unit, e.g. “Edge-1” means <unit> = 1.
<enum> is zero based, 0-19 for speed dials 1-20.
<card> is 0-3 for plug-in slots A-D.
<channel> is zero based and 0 where not applicable.
The following example sets the name of speed dial #3 on
card A of unit 1 to ‘Acme Inc.’
SSYSS 1.1001.2.0.0=Acme Inc.
This example sets the number of speed dial #20 on card D
of unit 1 to ‘555-1234’.
SSYSS 1.1000.19.3.0=555-1234
Below is an example of using the SSYSS command to dial
telephony digits directly.
If the command is accepted, the unit will respond with the string:
ACK<CR>
If the command is interpreted but fails for any reason the unit
will respond with the string:
NAK<CR>
As an example, consider a Radius AEC that is labeled as
Radius AEC-1 as shown in the following figure. The “-1” at
the end of the unit name indicates this is unit ID 1.
To set the speed dial name and number of location 12, to
“Conference Rm 1” and “555-1234”, respectively, use the
following commands:
SSYSS 1.1001.11.3.0=Conference Rm 1<CR>
SSYSS 1.1000.11.3.0=555-1234<CR>
11 25
of
www.symetrix.co | T+1.425.778.7728

Push Commands
And to dial Speed Dial 12, use the following command
assuming the speed dial 12 button has control number 112
assigned to it:
CS 112 65535<CR>
To enter a number to dial directly by entering the digits
14257787728, send the command
SSYSS 1.1004.0.3.0=14257787728<CR>
And to dial the digits, send the following command
assuming the connect/disconnect has control number 140
assigned to it:
CS 140 65535<CR>
Dialing VoIP Strings
When using the 1004 resource to dial strings with the VoIP
interface, the maximum length phone number that may be
directly dialed is 63 characters. Valid characters include
0-9, #, *, ., and letters (for SIP URI dialing). The digit pause
character ‘,’ to generate 2 seconds of pause in a dialing
string is not supported for the VoIP interface. Direct dial is
not supported for the ATI card.
(GSYSS) Get System String
This command gets a system string such as a speed dial
name or number. The syntax of the command is:
GSYSS <unit>.<resource>.<enum>.<card>.<channel> <CR>
Gets the string resource defined by the 5 parameters above.
Supported values for <resource> are shown in the following
table:
Resource Number Resource Name
1000 Speed dial number
1001 Speed dial name
1002 Dialed number
1003 Caller ID
1004 Number to dial (VoIP only)
1005 Call status (VoIP only)
1006 Elapsed time in a call (VoIP only)
<unit> is the unit enumerator after the dash shown in
Composer above each unit, e.g. “Edge-1” means <unit> =
1.
<enum> is zero based, 0-19 for speed dials.
<card> is 0-3 for A-D.
<channel> is zero based and 0 where not applicable.
For example:
GSYSS 1.1001.11.3.0<CR>
Returns the name of speed dial #12 on unit 1, card D. No
channel specification is necessary.
GSYSS 2.1003.0.3.1<CR>
Returns the caller ID on unit 2 for line 2 on card D.
If the command is accepted, the unit will respond with string:
ACK<CR>
If the command is interpreted but fails for any reason the unit
will respond with the string:
NAK<CR>
Other examples from an existing system are shown below:
GSYSS 1.1003.0.3.0<CR>
Returns: 710 ‘Room 710’ 4/15 7:15
GSYSS 1.1005.0.4.0<CR>
Returns: In Call: 710
GSYSS 1.1006.0.3.0<CR>
Returns: Time 0:00:35
Valid values of Resource Number 1005 are shown in the
following table. The parameter <dialed number> represents
the digits that were dialed, if any, to initiate the call.
Telephony
Interface
Status
Message Description
VoIP
Interface
Busy: The call appearance is busy
Dialing: The call appearance is being dialed.
Hold: The call appearance is in hold mode
Idle The call appearance is in idle state.
In Call: The remote caller has answered and a call is
connected.
Remote
Hold: The remote caller has placed the call on hold.
Ringing The call appearance is ringing.
Unavailable: The call appearance cannot connect.
Analog
Telephone
Interface
Reset The telephone line has been reset.
Ready The line onhook and ready for a call.
Outgoing Call The line is dialing a call
Ringing The line is actively ringing.
Ring Silence The line is quiet between active rings.
Incoming Call An incoming call has dialed the telephony
interface.
Disconnect The call has been disconnected.
In Use The telephone line is already in a call – perhaps
due to a shared line with another phone.
No Line There is no analog phone line connected.
12 25
of
www.symetrix.co | T+1.425.778.7728

Push Commands
Pushing GSYSS String Values
To have changes in the GSYSS string values automatically
sent to the control system, enable the option “Enable System
String Pushing” under the Tools->Site Preferences menu and
re-push the configuration file to the device. Afterwards, any
changes in the values will be automatically sent to the control
ports.
Push Commands
Units can send out unsolicited RS-232 and Ethernet data as
a result of parameter values changing within the unit.
All parameters that can be externally controlled can be
configured to automatically send out their values whenever
they change. This method, referred to as pushing data, can
be used instead of, or in addition to, polling (asking for data).
When using this feature, ensure that your system can handle
the volume of data you set up and that it can differentiate
between responses to commands and pushed data.
Commands used to control the push feature are described
below. Also, the following questions and answers provide
a detailed discussion of this feature, including real-world
problems and solutions.
When is data pushed?
For data to be pushed
1) a controller number must be enabled for push in
Composer
2) individual parameters must be enabled to push using the
Push Enable command.
Then, the controller value will be sent out
1) whenever the control’s underlying parameter changes or
2) when a refresh command is issued via RS-232 or
Ethernet.
Regardless of if the parameter change is made via the
control application, RS-232, RS-485, preset recall, analog
control or any other method, the data will be pushed. This
means for example that if your control system changes a
controller value set up for push, you will immediately receive
notification of that change.
Where (out what port) is the data pushed?
The data is sent out the RS-232 port and the Ethernet port
(both UDP and TCP) of the Symetrix unit.
What does the pushed data look like?
The format for unsolicited or “push” data is the same as the
GSB2 command. Strings consist of the controller number
and its value in the following format:
#<CONTROLLER NUMBER>=<CONTROLLER POSITION><CR>
Where <CONTROLLER NUMBER> is the decimal
controller number (1-10000) assigned in Composer and
<CONTROLLER POSITION> is a 16-bit number in decimal
(0-65535). The values for the controller number and position
will always be five digits, with leading zeros added as
necessary (e.g. 7 would be returned as 00007).
13 25
of
www.symetrix.co | T+1.425.778.7728

Up to 64 strings, separated with a <CR> as shown, may be
sent out together.
Example:
#00007=12321<CR>
#00324=00128<CR>
#10000=65535<CR>
Should I use the push feature or poll for
parameter changes?
The decision is up to you. Use whichever method makes
more sense for your application and control system. Manual
polling is often simpler to implement initially because all data
from the unit is a direct response to command you send
it, simplifying parsing. However, in situations where a large
number of parameters that change infrequently need to be
monitored, pushing may make more sense. You may also
prefer the convenience of not needing to set up a timer
to continually poll parameters for changes. Use whatever
method is appropriate for your situation.
How often is data pushed?
If there is data to be pushed, it is normally sent out every
100 milliseconds. This is called the push interval. While 100
ms is the default, the push interval can be changed via a Set
Push Interval (PUI) command.
Can I push meter data?
Yes, meters can be enabled for push. Keep in mind that
with normal audio signals connected to a meter, the meter
value will most likely be changing constantly, so you will
typically see the meter data being pushed at every 100 ms
interval. However, a Set Push Threshold command can be
used to prevent pushes until the data differs by a specified
amount (by default, this amount is 1). Another option is to
use an LED display, peak detector, and/or threshold detector
modules instead of directly pushing the meter date.
How can I control the amount of data
pushed?
There are several methods for controlling pushed data. First,
since pushed data is enabled on a per-control basis, your first
line of defense is to limit it to only certain controls. Second,
pushing can be globally turned on and off using this protocol.
Third, pushing can be enabled for just a range of controller
numbers. Fourth, the Set Push Threshold command can be
used to prevent pushes until the data changes by a specified
amount. Fifth, the Set Push Interval command controls how
often the data is pushed, useful for meters and other data that
changes frequently. Finally, the Push Refresh and Push Clear
commands provide additional methods of control.
I want to refresh everything to make sure
my control system is synchronized to the
hardware. How can I receive all data even if
it hasn’t changed?
Use the Push Refresh (PUR) (GC) command. Alternatively,
you could use the Get Controller commands to manually ask
for the controls you are concerned with.
Sometimes my control system turns off
push for an extended period of time. When
I turn it on, will I be notified of all changes
that occurred while push was turned off?
Yes, by default, all changes made while push was off will be
immediately reported as soon as it is turned on. This applies
to both turning push off globally or for individual controllers
via the Push Disable command. Take care that your system
can handle the potentially large amount of data that can
be generated. It may be helpful to “gradually” turn on the
push feature, enabling a small range of controller numbers
at once. You can also use the Push Clear command to
deal with this scenario. It allows you to effectively ignore all
previous unreported changes.
What is the difference between the Global
Push Enable/Disable (PU) command
and the Push Enable (PUE) and Push
Disable (PUD) commands? Why are there
2 different ways to specify a range of
controllers?
The Global Push Enable/Disable command can be used to
completely turn off push, or turn on push for all or a single
contiguous range of controller numbers. In contrast, the
Push Enable/Disable command allows much finer control.
Individual (non-contiguous) controllers can be turned on and
off, hence multiple ranges are supported.
The reason both methods are provided is for backwards
compatibility. The less flexible “single range” global PU
command was added first. Later, the more flexible PUE and
PUD commands were added as an enhancement. The older
global method was left in so existing programs wouldn’t
need to be modified. We recommend that you use either
one system or the other exclusively. Do not combine them.
New designs should use the PUE and PUD commands and
never use the PU command with a range specified.
Push Commands
14 25
of
www.symetrix.co | T+1.425.778.7728

Commands Related to Push
What is the difference between the Push
Enable (PUE) and Push Disable (PUD)
commands and the and the “Enable Push”
button in Composer?
Both of these methods can be used to enable or disable an
individual controller for push. The difference is that changing
the setting in Composer requires you to push to the design to
hardware again, whereas the Push Enable and Push Disable
commands take effect immediately and are intended to be
used for “on the fly” changes. In addition, Composer settings
are permanent across power cycling, whereas changes made
with the Push Enable and Push Disable commands are reset
by a power cycle (all controllers default to enabled). Please
note that the “Enable Push” button acts as an override so it
must be enabled for a controller ever to push. You cannot
issue a Push Enable command for a parameter that doesn’t
have the “Enable Push” setting active.
How does push work at power-up?
When a unit is first powered up, push is globally turned
on and all controllers are individually enabled. All controller
numbers are assumed to have changed. This means that
after power-up, you will immediately receive all current values.
What about pushed system strings?
The pushing of system strings enabled/disabled in the Site
Preferences. When enabled, any changes made to speed
dials, etc. will be pushed out the RS-232 port and the
Ethernet port of the Symetrix unit. They also push on a Site
File push and unit power up.
I’m not receiving unsolicited data. Any
suggestions for troubleshooting?
First of all, make sure that general communication is working
between your control system and the Symetrix RS-232 port
or Ethernet port. Make sure you can send commands and
receive ACK messages. Try the Flash Unit (FU) command.
Make sure the parameters you want pushed have the
“Enable Push” setting active in Composer. You can verify
this using the Controller Manager, and making sure there is
a ‘Yes’ in the Push column. Be sure you Go On-Line (Push
Design To Hardware) or F4 after making any changes in
Composer.
For Ethernet, make sure the Ethernet port is connected
to the same network as the control system. Verify the
connection LED on the Ethernet jack and/or switch is lit.
Verify you can “ping” the unit using its IP address.
Make sure the push feature has been globally enabled using
the Global Push Enable/Disable command. Push is globally
enabled on power-up, but may be turned off via RS-232 or
Ethernet. Power cycling the unit is a quick way to verify this.
Make sure the individual controllers have been enabled
using the Push Enable command. Push is disabled for all
controllers on power-up, and must be turned on via RS-232
or Ethernet. Sending a PUE command is a quick way to
enable all controllers.
Make sure the parameter to be pushed is changing. Change
the parameter via the control application, a Controller Set
command, or other method. You can also use the Push
Refresh command to force the data to be sent. If you have
changed the push threshold, make sure the parameter is
changing by an amount larger than the threshold.
For Ethernet, the unit needs to know the proper IP address
to send the data. Make sure at least one command has
been sent from the control system to the unit. If the control
system ever changes IP addresses, another command must
be sent to establish the new address.
What are the limitations of this feature?
If multiple parameters change at the same time, up to 64
controller numbers will be sent out during each push interval
(default 100 ms) until all have been sent out. This maximum
rate may be further limited by your RS-232 baud rate. If a
large amount of data is being pushed, we recommend using
the highest baud rate your system can support. A baud
rate of 115200 is sufficient to prevent further limiting of the
throughput.
Commands Related to Push:
(PU) Global Push Enable/Disable
This command enables or disables the push feature. When
enabling, a range of controllers can be specified to allow
pushing only certain values. Disabling is always global and
prevents any unsolicited data from being pushed. The syntax
of the command is:
PU <ON/OFF> [<LOW> [<HIGH>]]<CR>
Where <ON/OFF> is 0=OFF and 1=ON, <LOW> is the
optional lowest controller number to push (only valid when
enabling) and <HIGH> is the optional highest controller
number to push (only valid when enabling). <LOW> and
<HIGH> are both decimal controller numbers (1-10000)
assigned in Composer. If no controller numbers are
specified, the entire range of 1-10000 will be enabled for
push. If only one controller number is specified, it is assumed
to be the <LOW> value and the range from that number,
up to 10000, will be pushed. If two controller numbers are
specified, the range formed by those values (including the
values themselves) will be enabled for push. <LOW> must
be less than or equal to <HIGH>. When enabling, the range
specified overrides any previous ranges, i.e. it replaces the
range, rather than adding to it.
15 25
of
www.symetrix.co | T+1.425.778.7728

If the command is accepted, the unit will respond with the
string:
ACK<CR>
If the command is interpreted but fails for any reason the unit
will respond with the string:
NAK<CR>
At power-on, push is always enabled. Remember that
individual controller numbers must be enabled using the
Push Enable command as well. Data is pushed whenever a
change in that controller occurs or if forced to refresh using
the Push Refresh command.
Note: Global Push Enable with a range specified, e.g.
PU 1 100 200<CR> is not recommended. Instead, we
recommend always globally enabling the entire range using
PU 1<CR> and using the Push Enable command for
individual control.
(PUE) Push Enable
This command enables the push feature for an individual
controller or range of controllers. The syntax of the
command is:
PUE [<LOW> [<HIGH>]]<CR>
Where <LOW> is the optional lowest controller number to
push and <HIGH> is the optional highest controller number
to push. <LOW> and <HIGH> are both decimal controller
numbers (1-10000) assigned in Composer. If no controller
numbers are specified, the entire range of 1-10000 will be
enabled for push. If only one controller number is specified,
only that controller number is enabled. If two controller
numbers are specified, the range formed by those values
(including the values themselves) will be enabled for push.
<LOW> must be less than or equal to <HIGH>. Multiple
PUE commands can be used to enable non-contiguous
controller numbers since changes are additive.
If the command is accepted, the unit will respond with the
string:
ACK<CR>
If the command is interpreted but fails for any reason the unit
will respond with the string:
NAK<CR>
At power-on, push is enabled for all controllers in Composer
systems. Remember that individual controller numbers must
have the Enable Push setting active in Composer. Data is
pushed whenever a change in an enabled controller occurs
or if forced to refresh using the Push Refresh command.
Changes that happen while a control is disabled will be
pushed immediately upon enabling that control. The Push
Disable command is the inverse of this command and
provides a way to turn off controllers for push.
(PUD) Push Disable
This command enables the push feature for an individual
controller or range of controllers. The syntax of the
command is:
PUD [<LOW> [<HIGH>]]<CR>
Where <LOW> is the optional lowest controller number
to stop pushing and <HIGH> is the optional highest
controller number to stop pushing. <LOW> and <HIGH>
are both decimal controller numbers (1-10000) assigned
in Composer. If no controller numbers are specified, the
entire range of 1-10000 will be disabled for push. If only one
controller number is specified, only that controller number is
disabled. If two controller numbers are specified, the range
formed by those values (including the values themselves) will
be disabled for push. <LOW> must be less than or equal to
<HIGH>. Multiple PUD commands can be used to disable
non-contiguous controller numbers since changes are
subtractive.
If the command is accepted, the unit will respond with the
string:
ACK<CR>
If the command is interpreted but fails for any reason the unit
will respond with the string:
NAK<CR>
At power-on, push is enabled for all controllers in Composer
systems. Remember that individual controller numbers must
have the Enable Push setting active in Composer. The
Push Enable command is the inverse of this command and
provides a way to turn on controllers for push.
(GPU) Get Push-enabled Controllers
This command returns a list of all controllers currently
enabled for push. A range may optionally be specified to
limit the display to controllers enabled for push within that
range. The syntax of the command is:
GPU [<LOW> [<HIGH>]]<CR>
Where <LOW> is the optional lowest controller number
to inquire about and <HIGH> is the optional highest
controller number to inquire about. <LOW> and <HIGH>
are both decimal controller numbers (1-10000) assigned in
Composer. If no controller numbers are specified, the entire
range of 1-10000 will be inquired about. If only one controller
number is specified, it is assumed to be the <LOW> value
and the range from that number up to 10000 will be inquired
about. If two controller numbers are specified, the range
formed by those values (including the values themselves) will
be inquired about.
<LOW> must be less than or equal to <HIGH>.
Commands Related to Push
16 25
of
www.symetrix.co | T+1.425.778.7728

If the command is accepted, the unit will respond with a list
of enabled controller numbers separated by <CR>. If no
controllers are enabled, it returns the string:
ACK<CR>
If the command is interpreted but fails for any reason the unit
will respond with the string:
NAK<CR>
Special case: Entering GPU 0<CR> will return a list settings
related to push. It begins with Global=<0/1> to show if push
is globally enabled (1) or disabled (0).
This is followed by five 5-digit values showing the settings of
1) the global lower limit,
2) the global upper limit,
3) the threshold for parameters,
4) the threshold for meters, and
5) the push interval in milliseconds.
The default printout would look like this:
Global=1<CR>
00001 10000 00001 00001 00100<CR>
(PUR) Push Refresh
This command causes data to be pushed immediately even
if it hasn’t changed (assuming push is enabled). This may
be useful when trying to synchronize a control system to the
unit. A range of controllers can be specified to refresh only
certain values. The syntax of the command is:
PUR [<LOW> [<HIGH>]]<CR>
Where <LOW> is the optional lowest controller number
to refresh and <HIGH> is the optional highest controller
number to refresh. <LOW> and <HIGH> are both decimal
controller numbers (1-10000) assigned in Composer. If no
controller numbers are specified, the entire range of 1-10000
will be refreshed. If only one controller number is specified,
it is assumed to be the <LOW> value and the range from
that number up to 10000 will be refreshed. If two controller
numbers are specified, the range formed by those values
(including the values themselves) will be refreshed. <LOW>
must be less than or equal to <HIGH>.
If the command is accepted, the unit will respond with the
string:
ACK<CR>
If the command is interpreted but fails for any reason the unit
will respond with the string:
NAK<CR>
At power-on, all controller values are assumed to have
changed, so it acts as if a full refresh was performed.
Remember that individual controller numbers must have
the Enable Push setting active in Composer. In addition,
push must be enabled for the range of controllers you are
refreshing (see Push Enable/Disable). Controller numbers
that don’t meet this criterion will not be affected by the Push
Refresh command. In other words, if a controller is not
enabled for push, refreshing it won’t cause the value to be
pushed even if that controller is later enabled. The controller
must be enabled for push at the time the Push Refresh
command is issued.
(PUC) Push Clear
This command causes previous changes in data to be
ignored and not pushed. It may be desirable to issue
this command when first enabling push to prevent being
swamped by the flood of incoming data. A range of
controllers can be specified to clear only certain values. The
syntax of the command is:
PUC [<LOW> [<HIGH>]]<CR>
Where <LOW> is the optional lowest controller number to
clear and <HIGH> is the optional highest controller number
to clear. <LOW> and <HIGH> are both decimal controller
numbers (1-10000) assigned in Composer. If no controller
numbers are specified, the entire range of 1-10000 will
be cleared. If only one controller number is specified, it
is assumed to be the <LOW> value and the range from
that number up to 10000 will be cleared. If two controller
numbers are specified, the range formed by those values
(including the values themselves) will be cleared. <LOW>
must be less than or equal to <HIGH>.
If the command is accepted, the unit will respond with the
string:
ACK<CR>
If the command is interpreted but fails for any reason the unit
will respond with the string:
NAK<CR>
It may be useful to issue this command if push has been
disabled for a long time and then is about to be re-enabled.
Otherwise, you will immediately receive notification for all
changes that occurred during the disabled time.
Commands Related to Push
17 25
of
www.symetrix.co | T+1.425.778.7728

(PUI) Set Push Interval
This command changes the minimum length of time
between consecutive pushes of data. (See “How often is
data pushed?” above for more information.) At power-up,
this value defaults to 100 milliseconds. The syntax of the
command is:
PUI <MILLISECONDS><CR>
where <MILLISECONDS> is the push interval in
milliseconds, between 20 ms and 30,000 ms (30 seconds).
If the command is accepted, the unit will respond with the
string:
ACK<CR>
If the command is interpreted but fails for any reason the unit
will respond with the string:
NAK<CR>
While setting a short interval can speed up the push
response, it may have a negative impact on overall system
performance. The shorter the interval, the more time will be
spent looking for push data. This can slow down responses
to other RS-232 commands and Composer. Therefore,
we recommend using the longest interval that is practical,
especially if data is being pushed while Composer is on-line.
The default value of 100 milliseconds usually provides a
good compromise between prompt reports of changing data
and overall system performance.
Note that in cases where many controllers are changing
rapidly, the serial baud rate may ultimately limit the update
rate. Using the highest possible baud rate is recommended.
(PUT) Set Push Threshold
This command changes the push threshold value. Recall
that data is only pushed when it changes. The threshold is
the amount a value must change from the previous push
before it is pushed again. For example, if a controller value
was 10,000 and the threshold was 1,000, the data would
not be pushed again until the value rose to at least 11,000
or fell to 9,000 or below.
Units maintain two different thresholds: one for parameter
data such as faders and buttons, and another for meters
(including LEDs). These two thresholds can be set to the
same value or be different. It may be desirable to use a
fairly large threshold for meters to avoid constant pushing of
values. The power-on default for both of these values is 1.
The syntax of the command is:
PUT [<PARAMETER THRESH>] [<METER THRESH>]]<CR>
Where <PARAMETER THRESH> is the optional threshold
for parameters other than meters (e.g. faders and buttons)
and <METER THRESH> is the optional threshold for
meters. Both values must be between 0 and 65535. If
neither threshold is specified, both thresholds are set to the
default of 1. If only one threshold is specified, that value is
used for both the parameter and meter thresholds.
If the command is accepted, the unit will respond with the
string:
ACK<CR>
If the command is interpreted but fails for any reason the unit
will respond with the string:
NAK<CR>
Technical Note: The threshold is a “greater than or equal
to” type parameter, meaning it must be met (or exceeded)
to trigger a push. For example: if the threshold is 1 and the
last value pushed was 10,000, then a new value of 10,001
or 9,999 would cause a push to occur. A threshold of 0 acts
just like 1.
Setup Commands
18 25
of
www.symetrix.co | T+1.425.778.7728

Setup Commands
The defaults for the Set Baud and Set Echo Mode
commands are configured in Composer via the Unit
Properties dialog. Settings made via these Control Protocol
commands will be overridden by the values in the last
pushed Site File on the next hardware reboot or push. To
establish the permanent state, right-click on each unit and
select Unit Properties, then click Configure Remote Control
Port(s). Settings may be set independently for the Ethernet
and RS-232 ports.
Note: If you ever find yourself in a situation where you
are not sure of the RS-232 port settings, you can use
Composer to return the unit to default values. Simply open
the Hardware->Upgrade Firmware/Hardware Settings dialog
and click on the Erase Memory button. You can then select
to erase the Accessory Port Settings. Doing this will set
the baud rate, echo mode and quiet mode settings to the
factory default values.
Alternatively, the rear panel reset button can be used to
return the settings to factory defaults. However, that should
be only used as a last resort since it also resets many other
settings.
(SB) Set Baud
The Set Baud command controls the RS-232 port’s baud
rate.
The syntax of the command is:
SB <BAUD><CR>
Where <BAUD> is 1200, 2400, 4800, 9600, 19200, 38400,
57600, or 115200.
If the command is accepted, the unit will respond with the
string:
ACK<CR>
If the command is interpreted but fails for any reason the unit
will respond with the string:
NAK<CR>
The baud rate is saved in non-volatile memory so it is
retained across power cycles. This command can be sent
to either the Ethernet or RS-232 port, but only affects the
RS-232 port.
Note: New units default to a baud rate of 57600.
(SQ) Set Quiet Mode
The Set Quiet Mode command controls the text output
of the control port during responses. When quiet mode is
turned on, it restricts the output to just ACK, NAK or simple
values. All command descriptions above assume that quiet
mode is turned ON. Quiet mode ON should generally be
used for normal operation.
When quiet mode is set to OFF, lengthy strings intended to
be read by humans are sent in response to commands. This
mode is useful when using a terminal program for testing or
debugging.
The syntax of the command is:
SQ <ON/OFF><CR>
Where <ON/OFF> is 0 = OFF, 1 = ON.
If the “SQ 0” command is accepted, the unit will respond
with the string:
Setting Quiet Mode to false.<CR>
If the command is interpreted but fails for any reason the unit
will respond with the string:
NAK<CR>
The quiet mode state is kept separately for the Ethernet port
and the RS-232 port. A Set Quiet Mode command received
on the Ethernet port does not affect the RS-232 port and
vice versa. The quiet mode state is saved in non-volatile
memory, so it is retained across power cycles.
Note: New units default to quiet mode ON.
(EH) Set Echo Mode
The Set Echo Mode command controls the text output of
the control port during commands. When echo mode is
turned on, all characters that are received on the RS-232 or
Ethernet port are sent or “echoed” back. This mode is useful
when using a terminal program for testing or debugging.
When echo mode is turned off, the characters received are
not echoed back. All command descriptions above assume
that echo mode is turned off. Echo mode OFF should
generally be used for normal operation.
The syntax of the command is:
EH <ON/OFF><CR>
Where <ON/OFF> is 0 = OFF, 1 = ON.
If the command is accepted, the unit will respond with the
string:
ACK<CR>
If the command is interpreted but fails for any reason the unit
will respond with the string:
NAK<CR>
The echo mode state is kept separately for the Ethernet port
and the RS-232 port. A Set Echo Mode command received
on the Ethernet port does not affect the RS-232 port and
vice versa. The echo mode state is saved in non-volatile
memory so it is retained across power cycles.
Note: New units default with echo mode OFF.
Setup Commands
19 25
of
www.symetrix.co | T+1.425.778.7728

System Commands
NOP (No Operation)
The NOP command will always return an ACK in Quiet mode
to indicate that the system has received the command. The
NOP command can be used to keep a TCP connection
active or as a simple check of whether a system is up and
running and responding to commands.
Q! (Quit TCP/IP Session)
The Q! command will close the current TCP/IP session. If
the command is accepted, the unit will respond with the
string:
ACK<CR>
If the command is interpreted but fails for any reason the unit
will respond with the string:
NAK<CR>
A typical reason for failure is that the command was not sent
over a TCP/IP connection.
RI (IP address)
The RI command returns the IP address of the unit.
As an example:
RI<CR>
192.168.100.150
V (Version)
The V command returns the version of the software in the
unit. Up to thirteen different versions of software will be
returned corresponding to different subsystems within the
devices. For this command to be useful, it is recommended
to run the command while verbose mode is turned on
or temporarily turned on with the $v command prefix
(described in Special Command Prefix section).
As an example:
$v V <CR>
Firmware Version: V3.000
Build Date: Tue Apr 8 12:36:30 PDT 2014
Internal Build: V8.00
Linux Version: V3.2.0
Dante firmware: F:3.6.4 Sym:5.42
Startup firmware: V2.18
Front panel firmware: V2.29
RS-485 firmware: V1.25
RS-232 firmware: V1.55
TCP/IP firmware: V1.02
ARC-Web firmware: V1.10
ARC-Web executable: V1.09
ARC-Web CGI firmware: V1.09
Dialer CGI firmware: V1.55
Additional Info:
Linux version 3.2.0-ADI-2012R1-pre-9-pae+
(uclinux-devel@linux-tclw)
(gcc version 4.3.5 (ADI-2010R1-RC4) ) #3119 Tue
Nov 19 17:13:55 PST 2013 TCP/IP instance #1 of 4
>
R! (Reboot device)
The R! command will reboot the unit.
Special Command Prefixes
20 25
of
www.symetrix.co | T+1.425.778.7728
