Symphony 0-10V System User manual
760903-00-00
NOV 2020
Kirlin Lighting | 3401 E. Jefferson Ave., Detroit, MI 48207-4232, USA | P: 313.259.6400 | www.kirlinlighting.com
Installation Guide/Owner’s Manual
Symphony 0-10V System
Technical Support: 313-259-6400, Press 5
1.0 Scope ..............................................2
2.0 Owner/User Responsibilities..........................2
3.0 Safety Requirements.................................2
4.0 Input Electrical Specication..........................3
5.0 Standards and Compliance ...........................3
6.0 Dimming Control Characteristics......................3
7.0 Environmental Conditions ............................4
8.0 Cabinet and Module Installation .....................4-8
9.0 Output Cabling to Fixtures............................9
10.0 LED Load Congurations .............................9
11.0 Wiring Example.....................................10
12.0 Compatible 0-10V Dimmers & Controls ................11
13.0 Output Wire Requirements and Recommendations ......11
14.0 Inverter Connections................................ 12
15.0 Troubleshooting ..................................12-13
16.0 User Notes......................................... 14
Symphony
REMOTE DRIVER SYSTEM
760903-00-00
NOV 2020
INSTALLATION GUIDE/OWNER’S MANUAL
Symphony
REMOTE DRIVER SYSTEM
2
1.0 SCOPE
The KIRLIN Symphony 0-10V System is intended for installation and use in areas with large spaces
and where servicing lights is dicult. The system includes a Symphony 0-10V Remote Driver Cabinet,
Symphony 0-10V Remote Driver Module, and Symphony Luminaire (sold separately) that work in
harmony to provide a quality lighting experience.
This manual provides general installation, use, and application guidelines. Specications are subject
to change without prior notice.
This lighting system is Class 2 low voltage and can be installed in plenum or non-plenum locations in
accordance with required local, state, provincial, country and NEC/CEC regulations. Only output cables
marked with “CMP” may be installed in plenum locations.
2.0 OWNER/USER RESPONSIBILITIES
It is the responsibility of the contractor, installer,buyer, owner and user to install, maintain, and operate
the KIRLIN Symphony 0-10V System in accordance with all applicable laws, regulations and local
electrical safety authority requirements.
This product is only to be installed by a qualied electrician.
3.0 SAFETY REQUIREMENTS & IMPORTANT INFORMATION
Risk of electrical shock. May result in serious injury or death. Disconnect power
before servicing or installing.
The Symphony 0-10V Remote Driver Module may only be connected and installed by
qualied electrical. All applicable regulations, legislation, and building codes must be
observed. Incorrect installation of the LED driver can cause irreparable damage to
the Symphony 0-10V Remote Driver Module and the connected LEDs.
Pay attention when connecting the LEDs: polarity reversal results in no light output
and often damages the LEDs.
Connecting xtures with power ON will “hot plug” the LEDs and cause damage.
Must use Kirlin supplied driver modules, and light xtures to maintain warranty.
Requires #16 AWG minimum twisted pair shielded wire for all driver module wiring.
All system wiring must have a UL electrical rating of 300V.
The maximum total wire length from the cabinet to light xture is 250 feet.
760903-00-00
NOV 2020
INSTALLATION GUIDE/OWNER’S MANUAL
Symphony
REMOTE DRIVER SYSTEM
3
4.0 INPUT ELECTRICAL SPECIFICATION (Per Installed DVR Module)
Nominal input voltage range AC 120 - 277V
Absolute input voltage range AC 108 - 306V
Input frequency range 50 - 60Hz
Maximum wattage 50W
Eciency at full load 85%
Power factor at full load > 0.95
THD at full load < 20%
Maximum inrush current < 200mA2s @ 120V / 60Hz
< 200mA2s @ 277V / 60Hz
Surge protection 2kV dierential mode (DM)
2kV common mode (CM)
Maximum standby power 0.5W
5.0 STANDARDS & COMPLIANCE (Per Installed DVR Module)
This Low Voltage Luminaire System complies with UL 2108
UL Listed, Class P, Class 2 UL 1310
UL 8750
Conducted emissions FCC title 47 CFR part 15 class B
Radiated emissions FCC title 47 CFR part 15 class B
Electrostatic discharge EN 61000-4-2
0-10V IES/EN 60929 annex E
NOTE: From 0.6V to 10V drivers comply with IEC/
EN 60929 annex E. Below 0.6V Symphony 0-10V
Remote Driver Module comply with ABL 0-10V
Design Spec v1.2 enabling standby mode.
Surge protection ANSI 62.41 1991 category B1: 2.5kV DM, 2.5kV CB @
30 Ohm 0-10V input 0.5kv DM, 1kV CM surge
Restriction of hazardous
substances RoHS3 (Directives 2011/65/EU-2015/863/EU)
6.0 DIMMING CONTROL CHARACTERISTICS
Control protocol 0-10V
Dimming range 100% - 0.4%, o
Dimming curve Linear
760903-00-00
NOV 2020
INSTALLATION GUIDE/OWNER’S MANUAL
Symphony
REMOTE DRIVER SYSTEM
4
7.0 ENVIRONMENTAL CONDITIONS
Cabinet is intended for use in ambient temperature of 25°C max.
Module operating ambient temperature (Ta) range -20°C to +50°C
Acoustic noise - steady state < 24dBa (Class A)
All components Dry location only
8.0 CABINET & MODULE INSTALLATION
Before you begin
• Shut OFF power at fuse box or circuit breaker before installation, inspection or removal.
• Properly ground cabinet to main earth ground.
• To reduce the risk of re or electric shock, NEVER interconnect or short output
terminations.
Electrical requirements
• This driver cabinet is intended for connection to a 20A branch circuit and an appropriate
disconnect device shall be provided as part of the building installation.
• All secondary output circuits are class 2 low voltage.
Mounting and environmental requirements
• This driver cabinet is rated for dry locations only and is designed to be wall mounted.
• This driver cabinet is rated for operation at a maximum ambient temperature of 25ºC.
• Allow sucient spacing around driver cabinet for convection air ow.
760903-00-00
NOV 2020
INSTALLATION GUIDE/OWNER’S MANUAL
Symphony
REMOTE DRIVER SYSTEM
5
8.0 CABINET & MODULE INSTALLATION (continued)
Mechanical detail
GND
2X 3/4" - 1" TRADE SIZE
KNOCKOUTS EACH SIDE
4X 1/2" - 3/4" TRADE SIZE
KNOCKOUT EACH SIDE
2X 1" - 1 1/4" TRADE SIZE
KNOCKOUTS EACH SIDE
4x MOUNTING
4.50"
.13"
21.00" 24.13"
18.13"
15.00"
760903-00-00
NOV 2020
INSTALLATION GUIDE/OWNER’S MANUAL
Symphony
REMOTE DRIVER SYSTEM
6
8.0 CABINET & MODULE INSTALLATION (continued)
Mounting cabinet
1. Loosen the 4 screws that mount the cover panel; lift cover to align key hole slots, remove and
set aside.
2. Place the cabinet in the desired location and mount using the 4 designated locations.
3. After system installation is complete, replace the cover panel and tighten the 4 mounting
screws.
17.13"
21.00"
18.13"
24.125"
4x MOUNTING
760903-00-00
NOV 2020
INSTALLATION GUIDE/OWNER’S MANUAL
Symphony
REMOTE DRIVER SYSTEM
7
8.0 CABINET & MODULE INSTALLATION (continued)
Install modules
1. Each module is mounted in the cabinet via two threaded studs. Remove the keps-nuts
installed on each stud, insert module, and replace both keps-nuts.
2. Repeat for each module to be installed.
760903-00-00
NOV 2020
INSTALLATION GUIDE/OWNER’S MANUAL
Symphony
REMOTE DRIVER SYSTEM
8
8.0 CABINET & MODULE INSTALLATION (continued)
Input connections
NOTE: Eachcabinetshipswith a jumperwirekittoallowfast&easyinstallation. Thekitallows
installer to customize dimming & switching zones by daisy chaining modules as
needed. All system wiring must have a UL electrical rating of 300V minimum.
1. Install the AC line through the desired knock-out in the cabinet.
2. Install the 0-10V dimming wires in the desired knock-out in the cabinet.
3. Connect the AC Line and Neutral wires to the terminal block as shown.
4. Connect the AC Ground wire to the supplied green ground wire located in the cabinet.
5. Connect the 0-10V Violet and Gray dimming wires.
Output connections
NOTE: Requires #16 AWG minimum twisted pair shielded wire. All system wiring must have
a UL electrical rating of 300V minimum.
1. Install the LED load wires through the desired knock-out in the cabinet.
2. Connect the twisted shielded pair wires to the terminal block as shown. DO NOT
connect the shield wire at the other end of the run.
SHIELD GROUND
NEGATIVE LED LOAD
POSITIVE LED LOAD
0-10V GRAY
0-10V VIOLET
LINE
NEUTRAL
760903-00-00
NOV 2020
INSTALLATION GUIDE/OWNER’S MANUAL
Symphony
REMOTE DRIVER SYSTEM
9
9.0 OUTPUT CABLING TO FIXTURES
Output cabling must be #16 AWG (minimum) twisted pair shielded wire to minimize cross talk
between channels and minimize Electromagnetic Interference (EMI). Total cable length must not
exceed 250’. See section 13 for cable suggestions.
10.0 LED LOAD CONFIGURATIONS
Light Description LED Driver Module
DVR-1400A DVR-1050A
-1500L Luminaire Up to 2 in series (diagram 1)
-2500L Luminaire 1 xture per driver (diagram 2)
-4000L Luminaire 1 xture per driver (diagram 2)
-5000L Luminaire 2 drivers per xture (diagram 3)
-6500L Luminaire 2 drivers per xture (diagram 3)
SmartLED™
Driver Module
RED (+)
BLUE (-)
SmartLED™
Driver Module
RED (+)
BLUE (-)
RED (+)
BLUE (-)
Diagram 1
Diagram 2
RED (+)
BLUE (-)
Diagram 3
SmartLED™
Driver Module
RED (+)
BLUE (-)
SmartLED™
Driver Module
760903-00-00
NOV 2020
INSTALLATION GUIDE/OWNER’S MANUAL
Symphony
REMOTE DRIVER SYSTEM
10
11.0 WIRING EXAMPLE
BLUE (-)
RED (+)
BLUE (-) RED (+)
BLUE (-)
BLUE (-)
CH 3
CH 2
CH 1
CH 4
CH 5
CH 6
Electrical Input: 120-277VAC /
50-60Hz stand alone circuit only.
Two 1500L luminaires in series
on one circuit (use DVR-1400A)
One 1500L or
2500L luminaire
on one circuit
(use DVR-1400A)
One 4000L
luminaire
on one circuit
(use DVR-1050A)
One 5000L or
6500L luminaire
on two circuits
(use 2 x DVR-1400A)
Requires 16 AWG twisted pair
shielded wire from driver
module to luminaire(s). See
owner’s manual for
recommended cables.
For Symphony Installations,
use of Symphony 0-10V Driver
Modules are REQUIRED or
Kirlin warranty is null and void.
DO NOT CONNECT
wire shields to the luminaires.
DO NOT CONNECT
LED luminaries to energized driver
Symphony 0-10V Remote Driver Cabinet
(SYM-CABNT)
DVR-1400A/DVR-1050A
DVR-1400A/DVR-1050A
DVR-1400A/DVR-1050A
DVR-1400A/DVR-1050A
DVR-1400A/DVR-1050A
DVR-1400A/DVR-1050A
SPACE FOR FUTURE USE
1
2
3
4
5
6
7
8
RED (+)
RED (+)
RED (+)
BLUE (-)
SPACE FOR FUTURE USE
760903-00-00
NOV 2020
INSTALLATION GUIDE/OWNER’S MANUAL
Symphony
REMOTE DRIVER SYSTEM
11
12.0 COMPATIBLE 0-10V DIMMERS & CONTROLS
COMPATIBLE 0-10V DIMMERS and SWITCHES
Dimmer Manufacturer Type Dimming Curve
Busch-Jaeger 2112U-101 Logarithmic
Jung 240-10 Logarithmic
Leviton Lighting Controls IllumaTech - IP710-DLZ / IP710-LFZ Logarithmic
Lightolier Controls ZP600FAM120 Logarithmic
Lutron Electronics Diva: DVTV, DVSTV, NFTV /Nova-T; NTSTV Linear
Merten 5729 Logarithmic
Pass & Seymour CD4FB-W Logarithmic
The Watt Stopper DCLV1 Logarithmic
Sensor Switch n|O EZ Linear
Synergy ISD BC Logarithmic
COMPATIBLE DIMMING CONTROL SYSTEMS
Control Manufacturer Type
Lutron Electronics
GraphicEye - GRX-TVI w GRX3503,
Linear Energy Savr Node - QSN-4T16-S,
TVM2 Module
Crestron
GLX-DIMFLV8, GLXP-DIMFLV8, GLPAC-DIMFLV4-*,
GLPAC-DIMFLV8-*, GLPP-DIMFLVEX-PM, GLPP-1DIMFLV2EX-
PM, GLPP-1DIMFLV3EX-PM, DIN-AO8, DIN-4DIMFLV4,
CLS-EXP-DIMFLV, CLCI-1DIMFLV2EX
ABB SD/S 2.16.1
Note: Some dimmers may cause reduced stability at the lowest dim level setting; this is normal and
maybe resolved by increasing the lowest dim level setting if your selected dimmer allows
13.0 OUTPUT WIRE REQUIREMENTS and RECOMMENDATIONS
ALL WIRES MUST BE: #16 AWG minimum, twisted pair shielded with drain wire, UL rated for 300V
RECOMMENDED WIRE
CMP Versions (PLENUM) CM Versions (OPEN AIR)
Belden #16 AWG Part # 83702 Belden #16 AWG Part # 8719
ADC #16 AWG Part # 911602SD
760903-00-00
NOV 2020
INSTALLATION GUIDE/OWNER’S MANUAL
Symphony
REMOTE DRIVER SYSTEM
12
14.0 INVERTER CONNECTIONS
EMI-03120
The EMI-03120 will power up to 3 DVR modules during a power failure. Please see the installation
manual supplied with the EMI-03120 for its specic wiring diagrams.
EMI-21220
The EMI-21220 will power up to 8 DVR modules during a power failure. Please see the
installation manual supplied with the EMI-21220 for its specic wiring diagrams.
15.0 TROUBLESHOOTING
Fixtures Do Not Illuminate
1. Check to make certain that the dimmer is not set to its lowest position (depending on dimmer
module, the system may dim to “o”).
2. Verify that the cabinet is powered on. Each module has an LED indicator that will illuminate
continuously when power is applied.
3. Conrm that all input and output connections are correct and secure. All wiring from the
driver module to the LED xture(s) is polarized; reversed connections may result LED light
failure.
4. Verify that the number of xtures per module and wiring connections are correct per diagram
located on panel cover or section 11.0 of this manual.
5. Disconnect the LED xture(s) not illuminating at the xture junction box.Use a DC volt meter
to measure the voltage at the xture and driver module. Voltages should be approximately
55VDC. Lower voltages my indicate a short in the wiring or a failed driver module.
Fixtures Are Pulsing, Strobing or Flickering
1. Conrm the installed parts are approved Kirlin parts.
2. Check all wire connections. The most common reason for pulsing / strobing xtures is a
loose wire connection.
3. Verify that #16 AWG (minimum) twisted pair shielded wire is used and properly grounded.
4. Verify the installed 0-10V dimmer is approved for use in section 12.0 of the owner’s manual.
Note: Some dimmers may cause reduced stability at the lowest dim level setting; this is
normal and maybe resolved by increasing the lowest dim level setting if your selected dimmer
allows.
5. Conrm that the supply line to the cabinet is a dedicated circuit (all xtures ickering at
the same time).
760903-00-00
NOV 2020
INSTALLATION GUIDE/OWNER’S MANUAL
Symphony
REMOTE DRIVER SYSTEM
13
15.0 TROUBLESHOOTING (continued)
Fixtures Do Not Dim (Full Output Only)
1. Verify the installed 0-10V dimmer is approved for use in section 12.0 of the owner’s manual.
Note: Some dimmers may cause reduced stability at the lowest dim level setting; this is
normal and maybe resolved by increasing the lowest dim level setting if your selected
dimmer allows.
2. Check all dimming wire connections for a disconnected splice or open connection.
Fixtures Are Stuck in Dim (Low Output Only)
1. Verify the installed 0-10V dimmer is approved for use in section 12.0 of the owner’s manual.
Note: Some dimmers may cause reduced stability at the lowest dim level setting; this is
normal and maybe resolved by increasing the lowest dim level setting if your selected dimmer
allows.
2. Check all dimming wire connections for a short between the violet and gray wire or a
reversed connection.
760903-00-00
NOV 2020
Kirlin Lighting | 3401 E. Jefferson Ave., Detroit, MI 48207-4232, USA | P: 313.259.6400 | www.kirlinlighting.com
INSTALLATION GUIDE / OWNER’S MANUAL
Symphony
REMOTE DRIVER SYSTEM
16.0 USER NOTES
Table of contents
