Lofrans 636305 User manual

MINI RADIO REMOTE CONTROL
INSTALLATION OPERATION MAINTENANCE
Via Philips 5, 20900 Monza (MI), Italy
Tel: [phone] - Fax: [phone]
Email: [email protected] - www.lofrans.com
USER MANUAL
THIS MANUAL MUST BE KEPT ON BOARD AT ALL TIMES

2
Contents
Section Title Page
1 DESCRIPTION 3
2 TECHNICAL SPECIFICATIONS 3
3 PRODUCT REFERENCES 4
4 PACKAGING CONTENTS 4
5 GENERAL DIMENSIONS 5
6 INSTALLATION AND CONNECTIONS 5
7 SET UP INSTRUCTIONS 6
8 RESSETING 8
9ADDING EXTRA TRANSMITTERS 8
10 WIRING EXAMPLES 8
11 REPLACING THE BATTERIES 11
12 TROUBLESHOOTING 12
13 PRECAUTIONS 12
14 WORLDWIDE DISTRIBUTION 12
15 WARRANTY 13
It is strongly advised that only qualied marine electricians should install this equipment.
For any boat requiring ocial classication, bodies of approval should also be consulted at
the earliest opportunity. In any case, all other bodies, governmental or otherwise, should
be contacted to ensure conformity with legal regulations relating to the boat in question.
IT IS ESSENTIAL TO READ THE FOLLOWING MANUAL CAREFULLY
BEFORE INSTALLING THIS EQUIPMENT

3
TRANSMITTER RECEIVER
Power supply 1 lithium battery 3V (CR2032) Up to 36V DC
Power consumption in standby 0mA 9mA @ (12V DC)
Power consumption when in use 7mA @ 3V DC max 160mA @ 12V DC max
Operating temperature -15o/ +55o C -15o/ +55o C
Dimensions (mm) 71.8 x 37.9 x 17.7 100 x 65 x 26
Weight (g) 31 g (w/ battery) 95 g
Frequency (MHz) 433 (EU/US regulation) 433 (EU/US regulation)
ETSI EN 300 220-1 V3.1.1:2017
ETSI EN 300 220-2 V3.2.1:2019
ETSI EN 301 489-1 V2.2.3:2019
ETSI EN 301 489-3 V2.1.1:2019
EN 60950-1:2016+A11:2009+A1:2010+A12:2011+A3:2013
EN62479:2010
FCC ID:2AUL7-03736
1- DESCRIPTION
2- TECHNICAL SPECIFICATIONS
The Lofrans’ mini radio remote control is designed to work with Lofrans’ and Max Power’s
entire product lines. The mini remote control can also be used to operate any other onboard
equipment for which it may be useful.
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions (1) This
device may not cause harmful interference and (2) this device must accept any interference received including
interference that may cause undesired operation
This product is in compliance with the following regulations:

4
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.These limits are designed to provide reasonable
protection against harmful interference in a residential installation.This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment o and on, the user is encouraged to try to correct
the interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit dierent from that to which the receiver
is connected.
- Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept an interference received, including interference that may cause
undesired operation.
FCC Caution: Any changes or modications not expressly approved by the party responsible
for compliance could void the user’s authority to operate this equipment.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. To maintain compliance with FCC RF exposure compliance requirements,
please follow operation instruction as documented in this manual.

5
The mini remote control is available as a kit including both the transmitter and the receiver.
Additional transmitters are also available independently.
 •Theminiremotecontroltransmitterisoatingonthewater.
 •Eachtransmitterincludesitsbatteries(1xCR2032)
The Remote Control packaging includes:
*Transmitters are available as individual spare parts.
Please contact Lofrans’customer support at www.lofrans.com for any assistance
636305 (EU/US)
MINI REMOTE CONTROL
91 Transmitter
91 Receiver
91 String
91 User manual
9Dual lock tape
433 MHz
(EU/US regulation) 636305
3- PRODUCT REFERENCES
4- PACKAGING CONTENTS

6
All dimensions are in mm
5- GENERAL DIMENSIONS
6- INSTALLATION AND CONNECTIONS
100,5 mm
87 mm 25 mm
17,7 mm
38 mm
71,8 mm
61 mm
1. Turn OFF the power supply to the thruster or the equipment being connected.
2. Fit the receiver in a dry and accessible area (preferably not in the bilge). For mounting,
use the dual lock tape provided. If necessary, you can also use the 2 receiver’s bracket with
2 screws. In case of thruster installation, an ideal location is behind one of its control panels.
3. Connect the receiver to the power supply (12Vdc or 24Vdc)
4. CAUTION: ENSURE THE POLARITIES ARE RESPECTED.
5. Protect the positive supply cable of the receiver by means of a 1A fuse.
6. The receiver already has an integrated protection.
7. To access the outputs of the receiver in order to make the wiring, you must remove with a
cross screwdriver the two screws at the bottom of the box.
8. Connect the 4 outputs of the receiver’s terminal blocks (channels 1, 2, 3 & 4) to the
equipment that is to be operated. In the case of a bow thruster or windlass, see the annexed
diagrams for precise instructions.
9. The outputs (channels 1, 2, 3 & 4) are isolated volt free contacts with a load switching
capacity of up to 30V and 10A
10. Follow the set up instructions (cf. chapter 7)

7
In order to set up the receiver press the learning key button depicted in the above picture
(yellow arrow). The dierent functional mode can be selected by pressing this button.
Working Modes:
1. Momentary:
- Keep pressing one button on the remote control to turn ON the corresponding channel
of the receiver.
- Release your nger to turn OFF the receiver’s channel.
2. Toggle/Self-Locking:
- Press one button on the remote control for one time to turn ON the corresponding
channel of the receiver.
- Press again the same button to turn OFF the receiver’s channel.
3. Latched/Interlocking outputs:
- Press one button on the remote control for one time to turn ON the corresponding
channel of the receiver.
- Press another button on the remote control to turn OFF the receiver’s output.
7 – SET UP INSTRUCTIONS
CAUTION:
Fit the receiver as far as possible from large metallic objects, electric motors or high current
cables. Please connect the radio receiver’s power supply to the yacht’s main service battery
bank. The battery pack powering the receiver must be suciently charged (refer to the battery
supplier’s recommendations).
Learning Key
LED indicator

8
Setting of Working Modes:
1. Momentary Mode:
Pressing the learning key button on the receiver board once (g.A) and the LED indicator on
receiver board will signaling simultaneously. Then press any of the remote control button
(g.B)asaresulttheLEDonthecontrolboardashes3timesinsuccessionmeaningthatthe
setting of the Momentary Mode is successfully.
The corresponding output is ON by pressing a remote control button and only when you
release the remote control button the output turns o. If the remote button key is not
released, the relay is always on.
2. Toggle Mode (Self-locking):
Pressing the learning key button on the receiver board twice (g.A) and the LED indicator
on receiver board will signaling simultaneously. Then press any of the remote control button
(g.B)asaresulttheLEDonthecontrolboardashes3timesinsuccessionmeaningthatthe
setting of the Toggle Mode is successfully.
All outputs work as self-locking. Pressing a remote control button once, the relay is on and the
corresponding output is activated. By pressing the same button again, the output turns o.
3. Latched Mode (Interlocking):
Pressing the learning key button on the receiver board three times (g.A) and the LED
indicator on receiver board will signaling simultaneously.Then press any of the remote control
button(g.B)asaresulttheLEDonthecontrolboardashes3timesinsuccessionmeaning
that the setting of the Latched Mode is successfully.
All outputs work as interlocking. Press the ‘’Down’’ button on the remote control button to
activate the rst output which stays on. By pressing the ‘’Up’’ button on the remote control
Figure A Figure B

9
button, the rst output is o and the second output is activated, the relay of which remains
on and so on.
4. 2CH Momentary + 2CH Toggle:
Pressing the learning key button on the receiver board four times (g.A) and the LED indicator
on receiver board will signaling simultaneously. Then press any of the remote control button
(g.B)asaresulttheLEDonthecontrolboardashes3timesinsuccessionmeaningthatthis
setting is successfully.
Up and down outputs work as momentary and left and right work as self-locking outputs.
5. 2CH Momentary + 2CH Latched:
Pressing the learning key button on the receiver board ve times (g.A) and the LED indicator
on receiver board will signaling simultaneously. Then press any of the remote control button
(g.B)asaresulttheLEDonthecontrolboardashes3timesinsuccessionmeaningthatthis
setting is successfully.
Up and down outputs work as momentary while left and right work as interlocking outputs.
6. 2CH Toggle + 2CH Latched:
Pressing the learning key button on the receiver board six times (g.A) and the LED indicator
on receiver board will signaling simultaneously. Then press any of the remote control button
(g.B)asaresulttheLEDonthecontrolboardashes3timesinsuccessionmeaningthatthis
setting is successfully.
Up and down outputs work as self-locking while left and right work as interlocking outputs.
7. 2CH Latching + 2CH Latched:
Pressing the learning key button on the receiver board seven times (g.A) and the LED
indicator on receiver board will signaling simultaneously.Then press any of the remote control
button(g.B)asaresulttheLEDonthecontrolboardashes3timesinsuccessionmeaning
that this setting is successfully.
Up and down outputs work as inverted interlocking while left and right work as interlocking
outputs. Press the‘’Up’’button on the remote control to activate the down output the relay of
which remains on. By pressing the ‘’Up’’ button on the remote control the down output is o
and the up output is activated, the relay of which stays on.

10
CAUTION: WHEN USING THE PRODUCT ON A THRUSTER OR A WINDLASS,
INTERLOCKING MODE MUST BE AVOIDED IN ORDER TO AVOID DAMAGING YOUR
EQUIPMENT OR CAUSING INJURY.
10 – WIRING EXAMPLES
9 – ADDING EXTRA TRANSMITERS
To add an extra transmitter, follow the instructions of step 2 (Chapter 7 Set-up instructions)
and congure the additional remote control.
In case of error or doubt concerning the conguration, clear the receiver’s memory (Chapter
8) and start from the beginning.This will require the reconguration of all remote controls.
* Receivers and transmitters are available as individual spare parts. Please contact Lofrans’
customer support at www.lofrans.com for any assistance.
8 – RESETTING
In order to reset all the previous setups, press the learning key button on the receiver board
(g.A)eighttimesinarow.Atthistime,theLEDindicatoronreceiverboardwillash8times.
It means that the existing remote controls are deleted successfully and the reset has now
completed. Turn the receiver’s power supply OFF, wait 5 seconds and then return to step 2
(Chapter 7 Set-up instructions).
•”NO”terminalsstandforNormallyOpen.
In the corresponding terminal, connect a load that needs to be turned on when the button
is pressed.
•”NC”terminalsstandforNormallyClose.
In the corresponding terminal, connect a load that needs to be turned o when the button
is pressed.

11
•“COM”terminalsstandforCommon
In the corresponding terminal, connect the voltage supply for the corresponding load
The table below with the matching gure shows the correspondence of the mini remote
control buttons with the corresponding outputs on the receiver.
1 DC 12V Positive power supply input (V+)
2 Negative power supply input (V-)
3 Channel D - Normal Closed of relay (NC)
4 Channel D - Common of relay (COM)
5 Channel D - Normal Open of relay (NO)
6 Channel C - Normal Closed of relay (NC)
7 Channel C - Common of relay (COM)
8 Channel C - Normal Open of relay (NO)
9 Channel A - Normal Closed of relay (NC)
10 Channel A - Common of relay (COM)
11 Channel A - Normal Open of relay (NO)
12 Channel B - Normal Closed of relay (NC)
13 Channel B - Common of relay (COM)
14 Channel B - Normal Open of relay (NO)

12
Example 1 (g.1):
A thruster and a windlass need to be operated through
the mini remote.
The logic of the conguration is that a product
operates when the circuit is closed. In such a case,
themachineshouldbewiredintothe“NO”terminals
because the machine operates when the button of the
mini remote is pressed.
The voltage supply for operating the load should be
connected on the common terminal.
(g.1)
Example 2 (g.2):
Four products with single commands need to be
operated through the mini remote control.
The logic of the conguration is the same as in the
above example. The products will operate when the
button of the mini remote is pressed.
The voltage supply for operating the load should be
connected at the common terminal.
(g.2)

13
(g.3)
Example 3 (g.3):
Two products with inverse logic are needed to be
operated from the mini remote control. The product
should always operate, and by the pressing the
appropriate button should make the corresponding
output stop working. The voltage supply for operating
the load should be connected at the common terminal.
11 – REPLACING THE BATTERIES
CAUTION: ENSURE THAT THE EQUIPMENT’S POWER SUPPLY IS SWITCHED OFF
BEFORE REPLACING THE BATTERIES IN ORDER TO AVOID ACCIDENTAL ACTIVATION OF
THE EQUIPMENT.
CAUTION: THERE IS A RISK OF EXPLOSION IF A BATTERY IS REPLACED WITH
AN INCORRECT TYPE. DISPOSE OF THE USED BATTERIES ACCORDING TO THEIR
INSTRUCTIONS.
1. Remove the silicon protection case from the transmitter.
2.Useaatscrewdriverontheedgeoftheremoteonthetopandtwistitinordertoremove
the back part of the transmitter.
3. Remove the battery from the electronic control card.
4. Replace the battery with a new CR2032 battery. Ensure the polarities are correct.
5. Replace the back part of the transmitter and GENTLY TIGHTENTHE CAP while ensuring that
the rubber seal is correctly positioned so that the product remains waterproof.

14
13 – PRECAUTIONS
1. Operate the product only with the recommended voltage and wiring.
2. When the remote control voltage is insucient, please change the battery in time (when
the remote control battery voltage is insucient, the general remote control distance
becomes shorter).
3. When using wireless electronic products, care should be taken to avoid metal masks, large
electronic equipment, electromagnetic elds, etc., which strongly interfere with the remote
control. The RF communication distance of the transmitter and receiver might shorten or not
work properly.
4. Do not use this electronic product abnormally. Abnormal use will reduce the product’s
performance and longevity.
5. In the process of using the product, if you have any questions, please contact us any time.
To locate the nearest Lofransdistributor,pleaseconsultthesection“WorldwideDistribution”
on our website: www.lofrans.com
14 – WORLDWIDE DISTRIBUTION
Before contacting Lofrans, please consult the following trouble shooting guide.
Problem Check
The receiver’s LED doesn’t light up Check the power supply of the receiver
The transmitter’s LEDs do not light up Check the transmitter’s battery and the polarity
The remote control doesn’t work Check the connections of the receiver’s relay
outputs
The remote control works intermittently Check the voltage of the battery pack powering
the receiver
12- TROUBLE SHOOTING

15
15- WARRANTY
Warranty coverage
The equipment is guaranteed to be free of manufacturing and operation defects under
normal usage conditions for a period of 2 years from the date of purchase by the end user
(upon production of sales receipt or other proof of purchase). This warranty is transferable to
subsequent owners of this equipment during the period of coverage.
If the remote control is used for any purpose other than leisure boat equipment, the warranty
is limited to 6 months.
ANY MODIFICATION OF THE PRODUCT
WILL RESULT IN THE ANNULMENT OF THE WARRANTY
NOTIFICATIONS
UNSCREWING THE RECEIVER IN ORDER TO COMPLETE THE WIRING, WILL NOT VOID THE
WARRANTY
Warranty Exclusions
The manufacturer’s warranty does not cover:
• Damage caused by modications or an installation contrary to published specications
• Damage due to repairs performed by an unauthorized service centre
• Damage due to lack of normal maintenance
• Damage due to water
• Cost of hauling the boat
• Parts replaced due to normal wear and tear
• Repairs performed without the knowledge of the manufacturer (please contact dealer
to receive Repair Authorization Number)
• Cost of travel to and from the job site
• Repairs due to an incorrect installation
• Repairs carried out by the end user on the equipment
• Tampering of equipment by the end user
• Cost of economic loss, including injury to any person, damage to property, loss of
income or prot, communication, lodging, inconvenience
• Consequential damage due to failure, including those arising from collision with other
vessels or objects

16
CONTROL BOX AND REMOTE CONTROL RECEIVER SUPPLY:
To be connected to seperate battery bank (advised)
ELECTRICAL WIRING CONNECTION
Examples given for:
• Max Power BowThruster CT60/CT80
• Max Power Stern Thruster CT60/CT80
• LofransWindlass (3 terminals motor)
For other makes and models of equipment please
refer to the manufacturer’s wiring diagram

17

Via Philips 5, 20900 Monza (MI), Italy
Tel: [phone] - Fax: [phone]
Email: [email protected]om - www.lofrans.com
