Syncronorm V:Server4 User manual

V:Server4
User Manual & Terms of Use
www.syncronorm.com [email protected] #liquidinspiration

Version : November 2020
[phone]
[phone]
www.syncronorm.com
[email protected]m
Syncronorm GmbH
Graf-Gottfried-Strasse 122
59755 Arnsberg | Germany
ABOUT US
Syncronorm GmbH are highly motivated producers of high-end multimedia show design software,
which features a most unique real-time 3D visualizer. Our dynamic & experienced team thereby
to your dedicated project. From show-design, training-programs, instant support & consulting
to continuously soft- & hardware development, the team at Syncronorm is eager to realize your
visions. Syncronorm provide the most established & renowned products for the entertainment- &
water-show sectors within the industry and beyond.

TABLE OF CONTENTS
1. WELCOME TO SYNCRONORM S. 5
Preface
Checking the Scope of Delivery
Intended Use
2. SAFETY INSTRUCTIONS S. 6
Safety Information
Correct electrical Installation
Save Operation
Dangers resulting from non-adherence to the Safety Information S. 7
Safety-conscious Operation
Safety Information regarding Maintenance, Inspection and Installation Work
3. OVERVIEW S. 8
Front
Back
Technical Data S. 9
Connectors Pin Out S. 10
4. GETTING STARTED S. 11
Connecting the V:Server4
First Start-Up
5. MAINTENANCE & CLEANING S. 12
Important Information
6. GUARANTEE S. 13
Guarantee Conditions

(C) 2020 Syncronorm GmbH 5
WELCOME TO SYNCRONORM
You made a great choice by purchasing Syncronorm‘s V:Server4 hardware unit. Prior to
commissioning the unit, please read the following instructions of use carefully and fully familiarise
instructions. Adhere to the safety information for the correct and safe use of the unit. Keep these
instructions in a safe place! Please also hand over the instructions, when passing the unit on to a new
owner.
Preface
This document is a guideline for controlling the hardware of Syncronorm‘s show design & control soft-
device only occasionally must read and understand this manual before beginning to work. This manual
of the location of the manual.
Checking the Scope of Delivery
Please check that the scope of delivery is complete. Keep the packaging for later transport. If
components are damaged or missing, contact your Syncronorm supplier. To download the current
www.syncronorm.com.
Intended Use
• For controlling DMX and DMX-RDM compatible devices.
• For playback of multimedia shows created with Depence.

(C) 2020 Syncronorm GmbH
6
SAFETY INSTRUCTIONS
Safety Information
Danger to persons and assets may emanate from this unit, if it is used in an improper manner or not
in accordance with its intended use, or if the safety instructions are ignored. This unit must not be used
by persons under the age of 18. Persons with impairments or lack of experience and knowledge may
use the unit, as long as they are supervised and instructed on how to use the unit safely and are able to
understand the potential risks. Do not allow children to play with this unit. Do not allow children to clean
or maintain the unit.
Correct electrical Installation
electrician.
experience, he or she is capable of and authorized to judge and carry out the work commissioned
to him/her. This also includes the recognition of possible dangers and the adherence to the pertinent
regional and national standards, rules and regulations.
• The unit may only be connected when the electrical data of the unit and the power supply coincide.
The unit data is to be found on the unit type plate or on the packaging, or in this manual.
current protection device.
Save Operation
• Never operate the unit, if either the electrical cables or the housing are defective!
• Do not carry or pull the unit by its electrical cables.
• Route cords/hoses/lines in a way that they are protected against damage, and ensure that they do
not present a tripping obstacle.
• Only open the unit housing or its attendant components, when this is explicitly required in the opera-
ting instructions or approved/prescribed by Syncronorm‘s technical support service.
• Only execute work on the unit that is described in this manual. If problems cannot be overcome,
please contact an authorized customer service point or, when in doubt, the manufacturer.
• Only use original spare parts and accessories for the unit.
• Only operate the unit, if no persons are in the water!
• The unit, the connections and the plugs are not water-proof and must not be routed or installed in
water.
specialists of Syncronorm GmbH or personnel with suitable training.

(C) 2020 Syncronorm GmbH 7
SAFETY INSTRUCTIONS
Dangers resulting from non-adherence to the Safety Information
Please note that Syncronorm GmbH assumes no liability for damage, downtimes or malfunctions resul-
ting from non-adherence to this installation and operating manual. By ignoring or not adhering to all of
the safety information contained in this manual, you could endanger people, the environment and the
system of this unit. For example, non-adherence to the safety information contained in this manual can
lead to the following dangerous occurrences:
• A malfunction of important features of this unit
• Danger for persons due to electric shock
Safety-conscious Operation
As a user of this unit, ensure that you follow all safety information contained in this manual. Follow the
accident prevention regulations at all times. If the unit is used in a location where internal regulations,
operating and safety instructions apply, ensure that these regulations and instructions are also adhered
to.
Safety Information regarding Maintenance, Inspection and Installation Work
It is the owner/user ‘s responsibility to ensure that all maintenance, inspection and installation work is
pressure is applied to the unit and it is disconnected from the power supply (voltage-free) before carry-
ing out maintenance or repair work.
damage, malfunctions and/or downtimes of the unit system. Certain maintenance work may require
safety barriers to be removed and/or deactivated. If this is the case, ensure that all safety and protective
devices/guards are re-installed and/or reactivated after completing the maintenance work.
Original spare parts and accessories approved by the manufacturer provide safety. We wish to stress that
all parts and accessories not supplied by Syncronorm GmbH have neither been tested nor approved
by Syncronorm GmbH. For this reason, the installation and/or use of such products can, under certain
active and/or passive safety of the device. Syncronorm GmbH assumes no liability for damage resulting
from the use of parts and accessories other than original Syncronorm GmbH parts.
In this case all guarantee expires.
• The combination of water and electricity can lead to death or severe injuries from electrocution, if the
unit is incorrectly connected or misused.

(C) 2020 Syncronorm GmbH
8
Front
OVERVIEW
MULTICOLOR LED 7“ TOUCH DISPLAY USB 2.0
POWER BUTTON
Back Connectors
USB 2.0
ETHERNET
AUDIO OUT
SMPTE
4x DMX-RDM INPUT/OUTPUT
DVI-D OUT
EMERGENCY STOP
RS232
POWER SUPPLY
DIGITAL INPUT/OUTPUT
ANALOG INPUT/OUTPUT

(C) 2020 Syncronorm GmbH 9
OVERVIEW
Dimensions
Weight
Protection Class
Power Supply
DMX Output
Digital Output
Digital Input
Analaog Ports (I/O)
Connectors
Memory
Display
Synchronization
Scope of delivery
8.2kg
IP20
0...40° / 0...80% humidity
110V / 230V 50/60Hz AC max. 350W
2048 Channel 4 Universes DMX-RDM
4096 Channel (U8), 8192 Channel (U16), 24576 Channel (U48)
8x 12...24V DC max. 1A
8x 12...24V DC
12x 0...10V DC 25mA Current Drive Capability with Overcurrent Protection
4x DMX-RDM Neutrix XLR 5pin male optical isolated
2x Audio output symmetric stereo XLR 3pin male
1x DVI-D Monitor output
3x USB 2.0 (1x front, 2x back)
1x RS232 9pol SUB-D male
1x Digital Output 25pol SUB-D female (provides 8 outputs)
1x Digital Input 25pol SUB-D male (provides 8 inputs)
1x Analog Port 37pol SUB-D female (provides 12 inputs or outputs)
8GB RAM, 256GB internal NVMe M.2 SSD
7“ internal Touch Display
Server, Powercable, Documentation

(C) 2020 Syncronorm GmbH
10
OVERVIEW
Connectors Pin Out

(C) 2020 Syncronorm GmbH 11
GETTING STARTED
Connecting the V:Server4
Unpack carefully and get the V:Server4 device out of the cardboard box. Remove the packing material
from the device. Place the device on a secure & stable surface or directly mount the device into a 19”-
rack system.
1.
2.
3.
4. Connect an USB keyboard, mouse or touch screen to one of the available USB ports.
5. Optionally connect a second monitor on the DVI connector.
6. Connect your DMX devices.
First Start-Up
1.
2.
3.
4. As soon as you can see the information page pop up on the screen, the server has started up com-
pletely.

(C) 2020 Syncronorm GmbH
12
MAINTENANCE & CLEANING
The device requires regular maintenance.
Carry out maintenance in accordance with the maintenance schedule:
• If necessary, update your software version.
• Check, if all installed fans are working properly.
• Remove dust, if necessary.
• Check, if all external cables are working properly.
Important Information!
For the transport and Protective packaging, environmentally friendly
materials have been choosen that can be supplied normaly recycling.
Do not just dispose of these materials with your normal household waste,
but make sure that they are collected for recycling

(C) 2020 Syncronorm GmbH 13
-
as follows:
The guarantee period starts with the purchase from a Syncronorm GmbH specialist dealer. In the event
of a resale, the guarantee period will not start again.
If services by Syncronorm GmbH are provided under the terms of this guarantee, this does not lead to
extension or renewal of the guarantee period. Your legal rights as a purchaser, especially those ensuing
from the warranty, persist. They are not restricted by this guarantee.
Syncronorm warranties are limited to our product only and do not extend to any
direct, indirect or subsequential loss under any circumstances.
Misusage of the device leads to a loss of guarantee!
Guarantee Conditions
SYNCRONORM GmbH guarantees impeccable, purpose-related properties and workmanship,
expert assembly and proper functionality. Subject to our discretion, the guarantee refers to
free-of-charge repair or free-of-charge supply of spare parts or of a replacement unit respectively.
Should the unit type concerned no longer be manufactured, we reserve the right, at our discretion, to
supply a replacement unit from our range that is closest to the type subject to complaint. Claims, the
origin of which can be traced back to installation and operating faults as well as lack of care, e.g. the use
of unsuitable cleaning materials or negligent maintenance, use other than that intended, damage due
attempts to repair the unit, are not covered by our guarantee. We hereby refer to the proper use as spe-
etc. are exempted from the guarantee.
-
ted from the guarantee together with further reaching claims for damages and loss of whatever nature
caused by the unit or its use. The guarantee is only valid in the country in which the unit was purchased
from a Syncronorm GmbH dealer. This guarantee is governed by German law under the exclusion of the
agreement of the United Nations covering contracts, governing the international sale of goods (CISG)
regulations. Guarantee claims can only be brought forward by presenting the sales receipt to
Syncronorm GmbH
Graf-Gottfried-Strasse 122
59755 Arnsberg | Germany
by returning the unit or part of the unit‘s subject of complaint to us, freight free, at your own risk, ac-
companied by a copy of the original purchase receipt from the Syncronorm GmbH specialist dealer, this
guarantee document and written information of the fault encountered.
GUARANTEE

(C) 2020 Syncronorm GmbH
14
Please visit the Syncronorm V:Server4 Online Manual to get further
information & detailed operational advice.
http://vserver4.manual.syncronorm.com/
