SYNCROSWITCH
The SyncroSwitch unit features six independently controllable outputs which can output 16amps
@230V AC (resistive load). This makes the SyncroSwitch a suitable tool for all your switching needs:
High Power, Low Power, Audio or Lighting Signal, Motor Control, Valves or Power of VFD´s.
Intelligent internal signal routing, Exclusive switching Options, Momentary or Latching output: Many
combinations are possible and can be set from the Syncronorm RDM Browser. The DMX address is
set remotely (SyncroTools Address Board required) and stored electronically onto non volatile
memory and can be adjusted from the Syncronorm RDM Browser.
DMX-RDM High Power Contact Relay Module 6x

(C) 2020 Syncronorm GmbH
4
You made a great choice by purchasing Syncronorm‘s SyncroSwitch hardware unit. Prior to
commissioning the unit, please read the following instructions of use carefully and fully familiarise
yourself with the unit. Ensure that all work on and with this unit is only carried out in accordance to these
instructions. Adhere to the safety information for the correct and safe use of the unit. Keep these
instructions in a safe place! Please also hand over the instructions, when passing the unit on to a new
owner.
Preface
This document is a guideline for controlling the hardware of Syncronorm‘s fountain control systems. The
information contained in this manual will give you a sucient understanding of this product, helping you
to use the unit correctly and eectively. Adhere to all instructions contained in this manual, when
installing and operating this unit. Every person working with this equipment must read this manual
before installation and commissioning of the equipment/device. Every person working with this device/
equipment must read the manual before starting to work. Even personnel working with this device only
occasionally must read and understand this manual before beginning to work. This manual must always
be available at the site, where the device is located. Every user of this device must be aware of the
location of the manual.
Technical Data
WELCOME TO SYNCRONORM
Dimensions
Weight
Protection Class
Power Supply
Operation Temperature
Certification
Outputs
Inputs
Order Number
160x90x58 mm DIN RAIL
0.33 kg
IP 20
24V DC*
0.. 40° / 0.. 80% humidity
CE
6x Contact Relay with max. 16A@230VAC (res. load)
DMX512 RDM
SN-STSW24
SyncroSwitch
*This unit requires the SyncroTools DMX address board (SN-STADRB).

(C) 2020 Syncronorm GmbH 5
Checking the Scope of Delivery
Please check that the scope of delivery is complete. Keep the packaging for later transport. If
Scope of delivery:
1x SyncroSwitch DMX-RDM High Power Contact Relay Module 6x
1x Interface Card
Please note that a programming adaptor (3000P) is not included with DIN rail mount devices. A
programming adaptor (required to set DMX start addresses and operating options) must be ordered
separately.
Intended Use
The SyncroSwitch, in the following referred to as „unit“, may only be used as specied as follows:
The DMX-RDM High Power Contact Relay Module 6x is an intelligent DMX demultiplexer, which decodes
digital data complying with standards USITT DMX512 and DIN 56930-2. The card drive changes over six
contact relay outputs.
The DMX-RDM High Power Contact Relay Module 6x is suited for all kinds of signal switching applicati-
ons. It features six potential-free high-power changeover output contacts and high noise immunity.
Safety Information
Danger to persons and assets may emanate from this unit, if it is used in an improper manner or not
in accordance with its intended use, or if the safety instructions are ignored. This unit must not be used
by children under the age of 18. Persons with impairments or lack of experience and knowledge may
use the unit, as long as they are supervised and instructed on how to use the unit safely and are able to
understand the potential risks. Do not allow children to play with this unit. Do not allow children to clean
or maintain the unit.
Correct electrical Installation
• Electrical installations must meet the national regulations and may only be carried out by a qualied
electrician.
• A person is regarded as a qualied electrician, if, due to his/her vocational education, knowledge and
experience, he or she is capable of and authorized to judge and carry out the work commissioned
to him/her. This also includes the recognition of possible dangers and the adherence to the pertinent
regional and national standards, rules and regulations.
• For your own safety, please consult a qualied electrician.
• The unit may only be connected when the electrical data of the unit and the power supply coincide.
The unit data is to be found on the unit type plate or on the packaging, or in this manual.
• Ensure that the unit is fused for a rated fault current of max. 3A on the mains side by means of a fault
current protection device.
SAFETY INSTRUCTIONS

(C) 2020 Syncronorm GmbH
6
SAFETY INSTRUCTIONS
Save Operation
• Never operate the unit, if either the electrical cables or the housing are defective!
• Do not carry or pull the unit by its electrical cables.
• Route cords/hoses/lines in a way that they are protected against damage, and ensure that they do
not present a tripping obstacle.
• Only open the unit housing or its attendant components, when this is explicitly required in the ope-
rating instructions or approved/prescribed by Syncronorm‘s technical support service.
• Only execute work on the unit that is described in this manual. If problems cannot be overcome,
please contact an authorized customer service point or, when in doubt, the manufacturer.
• Only use original spare parts and accessories for the unit.
• Never carry out technical modications to the unit.
• Only operate the unit, if no persons are in the water!
• The unit, the connections and the plugs are not water-proof and must not be routed or installed in
water.
Qualications and Training of Employees
• Ensure that installation personnel have the required technical qualications.
• Also ensure that all operating personnel are suciently qualied.
• Ensure that maintenance work is only performed by personnel authorized for this purpose, e.g.
specialists of Syncronorm GmbH or personnel with suitable training.
Dangers resulting from non-adherence to the Safety Information
Please note that Syncronorm GmbH assumes no liability for damage, downtimes or malfunctions resul-
ting from non-adherence to this installation and operating manual. By ignoring or not adhering to all of
the safety information contained in this manual, you could endanger people, the environment and the
system of this unit. For example, non-adherence to the safety information contained in this manual can
lead to the following dangerous occurrences:
• A malfunction of important features of this unit
• Danger for persons due to electric shock
Safety-conscious Operation
As a user of this unit, ensure that you follow all safety information contained in this manual. Follow the
accident prevention regulations at all times. If the unit is used in a location where internal regulations,
operating and safety instructions apply, ensure that these regulations and instructions are also adhered
to.

(C) 2020 Syncronorm GmbH 7
Optional retrotting and Production of Spare Parts
Safety Information regarding Maintenance, Inspection and Installation Work
Changes or modications to the device are only permitted after consultation with the manufacturer.
Original spare parts and accessories approved by the manufacturer provide safety. We wish to stress that
all parts and accessories not supplied by Syncronorm GmbH have neither been tested nor approved
by Syncronorm GmbH. For this reason, the installation and/or use of such products can, under certain
circumstances, negatively aect the specications for the device. This could also lead to restrictions of the
active and/or passive safety of the device. Syncronorm GmbH assumes no liability for damage resulting
from the use of parts and accessories other than original Syncronorm GmbH parts.
In this case all guarantee expires.
It is the owner/user‘s responsibility to ensure that all maintenance, inspection and installation work is car-
ried out by authorized and qualied personnel, who have read and understood this manual.
Only carry out maintenance work on this unit, when the unit system is switched o. Ensure that no
pressure is applied to the unit and it is disconnected from the power supply (voltage-free) before carry-
ing out maintenance or repair work.
Ensure that small malfunctions are immediately rectied by authorized personnel to avoid possible future
damage, malfunctions and/or downtimes of the unit system. Certain maintenance work may require
safety barriers to be removed and/or deactivated. If this is the case, ensure that all safety and protective
devices/guards are re-installed and/or reactivated after completing the maintenance work.
Dangers encountered by the Combination of Water and Electricity
• The combination of water and electricity can lead to death or severe injuries from electrocution, if the
unit is incorrectly connected or misused.
• Prior to reaching into the water, always switch o the mains voltage to all units used in the water.
SAFETY INSTRUCTIONS

(C) 2020 Syncronorm GmbH
8
CONNECTION
The decoder SyncroSwitch consists of the following input and output connectors:
CN13 POWER SUPPLY 230V AC
grey L, 230V AC
blue N, 230V AC
CN8 Switching output 1 (3-pin spring terminal, light grey, grey, dark grey)
1 light grey COMMON
2 grey NC
3 dark grey NO
CN7 Switching output 2 (3-pin spring terminal, light grey, grey, dark grey)
1 light grey COMMON
2 grey NC
3 dark grey NO
CN6 Switching output 3 (3-pin spring terminal, light grey, grey, dark grey)
1 light grey COMMON
2 grey NC
3 dark grey NO
CN5 Switching output 4 (3-pin spring terminal, light grey, grey, dark grey)
1 light grey COMMON
2 grey NC
3 dark grey NO
CN4 Switching output 5 (3-pin spring terminal, light grey, grey, dark grey)
1 light grey COMMON
2 grey NC
3 dark grey NO
CN3 Switching output 6 (3-pin spring terminal, light grey, grey, dark grey)
1 light grey COMMON
2 grey NC
3 dark grey NO
CN10 DMX Input / Output
1 grey GND
2 blue DMX - (signal complement)
3 orange DMX + (signal true)

(C) 2020 Syncronorm GmbH 9
CONNECTION
6x Contactor 230V/16A
DMX-IN 24V DC PowerStart-Adr
Modul
Signal Indicators
The state of the demultiplexer card is signalled with two indicator LEDs.
green: OPERATION
red: ERROR (blinking)
Error blinking at data errors or loss of communication.
Wiring
To put the DMX relay interface SyncroSwitch to work, it must be wired properly. We strongly
recommend to use fused line and load connections.
Output connectors: CN8 CN7 CN6 CN5 CN4 CN3
1 2 3 4 5 6
CN10: DMX IN CN13: 230V AC
CN2
Connector for Startadressboard

(C) 2020 Syncronorm GmbH
10
CONNECTION
Start Address Switches
The DMX relay decoder SyncroSwitch has been preset to DMX start address 001. If another start
address is required, it must be set using a start address board 3000P or 3003P. This start address board
is optionally available. The SyncroSwitch can be operated with or without start address board attached.
Use the BCD switches to set the DMX start address, that is the address of the rst DMX channel (DMX
data slot) used to switch relay output #1. setting is straightforward, no binary calculation required as is
with DIP switches.
S3: Hundreds
S2: Tens
S1: Ones
Setting address 000 will disable all outputs and sett all outputs to OFF regardless of data received. To set
a start adress other than 001 proceed as follows:
- unpower the unit
- open the interface by removing the top cover
- connect the address board 3000P or 3003P using the 10pin connector CN2
- set the desired address
- power up the decoder
- succesful programming will be indicated by the status LEDs, which should blink red - green four
times. Similarly, the DIP settings (see below) must be programmed to the decoder.
DIP Switches
The interface can be congured using the start address board DIP switches. With start address board
3003P, DIP switch settings conform to functions F1..F4.
DIP SWITCH 1 DMX HOLD: default: o = no
When setting HOLD, the last valid setting will be retained at control signal loss. If DMX HOLD is not set,
settings of DIP switch #2 will apply. S3 S2 S1
DIP SWITCH 2 OFF value: default: o = all outputs OFF
When DMX HOLD is not set, all outputs will be driven to the OFF state at loss of the DMX512 control
signal. Setting DIP switch #2 will drive all outputs to ON instead.
DIP SWITCH 3, 4 Hysteresisdefault: o/o = trip point 50%/51%
These switches determine the ON and OFF trip points. Four settings are available:
DIP switch 3 4 trip points
OFF OFF 50% / 51%
ON OFF 25% / 75%
OFF ON 3% / 97%
ON ON 0% / 1%

(C) 2020 Syncronorm GmbH 11
Relay Types
This decoder is tted with contact relays designed for a switching current of max 10A at 230V (resistive
load only!). When selecting and ordering the appropriate relay card, please note, that all data given by
the relay manufacturers are for RESISTIVE LOAD only. Incandescent lamps may be considered resistive
loads. Switching inductive loads, such as transformers or solenoids, requires lower loads - we strongly
recommend not to exceed 50% of the resistive load data. Besides, contacts may burn due to inductive
spikes and sparks. Make sure to add protective circuitry (RC combinations, VDR resistors) if switching
inductive loads. Switching inductive loads on the mains power supply may also generate high
requence noise and degrade the power supply quality. If switching capacitive loads (electronic ballasts or
psu) inrush current limiting devices may be required to prevent contact damage. If in doubt pls consult
the relay maker data sheet (OMRON, Type G2R-1-ASI, available at
DMX/RDM
The SyncroSwitch 6x RDM is compatible with ANSI E1-20 DMX RDM Version 1.0. Please note some
special properties of devices complying with DMX RDM:
DMX HOLD properties are not supported by RDM standard ANSI E1-20. A factory specic command
(DMX HOLD) has been added to compensate these restraints. Use parametrs 0...2 to set the desired
HOLD mode:
0: no HOLD, all outputs OFF upon loss of signal
1: no HOLD, all Outputs ON upon loss of signal
2: DMX HOLD (last look remains active)
Setting the DMX personality reects setting of DIP switches 3 and 4 (and vice versa).
NOTE: Once settings have benn changed using DMX RDM, the address switches become inactive
(blocked). To re-enable start address switsches, temporarily set any address from 900...999 (simply set
the „900“ digit). This will re-enable switches.
CONNECTION

(C) 2020 Syncronorm GmbH
12
The device requires regular maintenance.
Carry out maintenance in accordance with the maintenance schedule:
- If necessary, update your software version.
- Check, if all external cables are working properly.
Important information!
Maintenance must be carried out by qualied personnel only!
Protecting the environment
For the transport and Protective packaging, environmentally friendly
materials have been choosen that can be supplied normaly recycling.
Do not just dispose of these materials with your normal household waste,
but make sure that they are collected for recycling
This product is subject to the European Waste Electrical and Electronic
Equipment Directive (WEEE).
FCC Statement
This product has been tested and complies with the specications for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used according to the instructions, may cause harmful inter-
ference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which is found by turning the equipment o and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment or devices
• Connect the equipment to an outlet other than the receiver‘s
• Consult a dealer or an experienced radio/TV technician for assistance
FCC Caution: Any change or modication to the product not expressly approved by SLH could void the
user’s authority to operate the device.
Maintenance and Cleaning
MAINTANANCE & DISPOSAL

(C) 2020 Syncronorm GmbH 13
Syncronorm GmbH assures a 12 month manufacturer ‘s guarantee for this specic Syncronorm unit, pur-
chased by you. This guarantee only exists in accordance to the specic guarantee conditions lad down
as follows:
The guarantee period starts with the purchase from a Syncronorm GmbH specialist dealer. In the event
of a resale, the guarantee period will not start again.
If services by Syncronorm GmbH are provided under the terms of this guarantee, this does not lead to
extension or renewal of the guarantee period. Your legal rights as a purchaser, especially those ensuing
from the warranty, persist. They are not restricted by this guarantee.
Syncronorm warranties are limited to our product only and do not extend to any
direct, indirect or subsequential loss under any circumstances.
Misusage of the device leads to a loss of guarantee!
Guarantee Conditions
SYNCRONORM GmbH guarantees impeccable, purpose-related properties and workmanship,
expert assembly and proper functionality. Subject to our discretion, the guarantee refers to
free-of-charge repair or free-of-charge supply of spare parts or of a replacement unit respectively.
Should the unit type concerned no longer be manufactured, we reserve the right, at our discretion, to
supply a replacement unit from our range that is closest to the type subject to complaint. Claims, the
origin of which can be traced back to installation and operating faults as well as lack of care, e.g. the use
of unsuitable cleaning materials or negligent maintenance, use other than that intended, damage due
to accidents, falls, impact, eect of frost, cutting plugs, shortening cables, calcium deposits or improper
attempts to repair the unit, are not covered by our guarantee. We hereby refer to the proper use as spe-
cied in the instructions of use that form an integral part of the guarantee. Wearing parts such as bulbs
etc. are exempted from the guarantee.
The refund of costs for removal and installation, checks, claims for lost prot and damages are exemp-
ted from the guarantee together with further reaching claims for damages and loss of whatever nature
caused by the unit or its use. The guarantee is only valid in the country in which the unit was purchased
from a Syncronorm GmbH dealer. This guarantee is governed by German law under the exclusion of the
agreement of the United Nations covering contracts, governing the international sale of goods (CISG)
regulations. Guarantee claims can only be brought forward by presenting the sales receipt to
Syncronorm GmbH
Graf-Gottfried-Strasse 122
59755 Arnsberg | Germany
by returning the unit or part of the unit‘s subject of complaint to us, freight free, at your own risk, ac-
companied by a copy of the original purchase receipt from the Syncronorm GmbH specialist dealer, this
guarantee document and written information of the fault encountered.
GUARANTEE

Table of contents
Other Syncronorm Industrial Equipment manuals
Popular Industrial Equipment manuals by other brands

aquamundus
aquamundus GreaseShield 1000 AST-PF installation guide

Oriental motor
Oriental motor K II Series operating manual

FRONIUS
FRONIUS Selectiva Li 8 kW 2200 operating instructions

Powerplus
Powerplus POWX902 manual

EGAmaster
EGAmaster 55815 operating instructions

Carbide 3D
Carbide 3D Shapeoko HDZ 4.0 Assembly guide

Strack
Strack PowerMax SN5650-PMO-0260-V04 operating instructions

EL-CELL
EL-CELL ECC-Opto-Std user manual

3-form
3-form SimpleSpec 250.02 installation manual

RYNO WORX
RYNO WORX RY10MA-Elite Operator's manual

Energy Absorption
Energy Absorption Safe-Stop 180 TMA 9181 Installation and operation manual

ABB
ABB HT606349 Operation manual
