Synergy Global Technology LCDK1001 User manual
User Manual
1U Short Depth Keyboard Drawer
LCDK1001
Legal Information
First English printing, November 2020
Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness
of the contents. The information in this document is subject to change without notice. We are not liable for any injury or
loss that results from the use of this equipment.
Safety Instructions
Please read all of these instructions carefully before you use the device. Save this manual for
future reference.
■Unplug equipment before cleaning. Don’t use liquid or spray detergent; use a moist cloth.
■Keep equipment away from excessive humidity and heat. Preferably, keep it in an air-conditioned environment with
temperatures not exceeding 40º Celsius (104º Fahrenheit).
■When installing, place the equipment on a sturdy, level surface to prevent it from accidentally falling and causing dam
age to other equipment or injury to persons nearby.
■When the equipment is in an open position, do not cover, block or in any way obstruct the gap between it and the
power supply. Proper air convection is necessary to keep it from overheating.
■Arrange the equipment’s power cord in such a way that others won’t trip or fall over it.
■If you are using a power cord that didn’t ship with the equipment, ensure that it is rated for the voltage and current
labeled on the equipment’s electrical ratings label. The voltage rating on the cord should be higher than the one listed
on the equipment’s ratings label.
■Observe all precautions and warnings attached to the equipment.
■If you don’t intend on using the equipment for a long time, disconnect it from the power outlet to prevent being dam
aged by transient over-voltage.
■Keep all liquids away from the equipment to minimize the risk of accidental spillage. Liquid spilled on to the power
supply or on other hardware may cause damage, fire or electrical shock.
■Only qualified service personnel should open the chassis. Opening it yourself could damage the equipment and invali
date its warranty.
■If any part of the equipment becomes damaged or stops functioning, have it checked by qualified service personnel.
What the warranty does not cover
■Any product, on which the serial number has been defaced, modified or removed.
■Damage, deterioration or malfunction resulting from:
□Accident, misuse, neglect, fire, water, lightning, or other acts of nature, unauthorized product modification, or
failure to follow instructions supplied with the product.
□Repair or attempted repair by anyone not authorized by us.
□Any damage of the product due to shipment.
□Removal or installation of the product.
□Causes external to the product, such as electric power fluctuation or failure.
□Use of supplies or parts not meeting our specifications.
□Normal wear and tear.
□Any other causes which does not relate to a product defect.
■Removal, installation, and set-up service charges.
Regulatory Notices Federal Communications Commission (FCC)
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the
FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential instal-
lation.
Any changes or modifications made to this equipment may void the user’s authority to operate this equipment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment offand on, the
user is encouraged to try to correct the interference by one or more of the following measures:
■Re-position or relocate the receiving antenna.
■Increase the separation between the equipment and receiver.
■Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
www.RackmountMart.com
Contents
< Part. 1 > LCDK1001
1.1 Package
Content P.1
1.2 Structure Diagram & Dimension P.1
1.3 Installation P.3
1.4 Connection P.4
< Part. 2 > Specifications
2.1 Keyboard / Mouse Specifications P.5
2.2 Environmental Conditions P.8
www.RackmountMart.com
P.1
LCDK1001 unit X 1
- Pair of L-bracket with fastener screws X 1
■It is very important to mount the equipment in a suitable cabinet or on a stable surface.
■Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive
dust, dirt, heat, water, moisture and vibration.
The equipment comes with the standard parts shown in package content. Check and make sure they are
included and in good condition. If anything is missing, or damaged, contact the supplier immediately.
Unpacking
Before Installation
2
1
4
Adjustable rear mounting L-bracket
104-key keyboard
Mouse interchangeable module kit
Key lock for extra security
1
2
3
4
3
< Part 1 > LCDK1001
< 1.1 > Package Content
< 1.2 > Structure Diagram
www.RackmountMart.com
P.2
Front View
< 1.2 > Dimension
Side View UNIT : mm
1mm = 0.03937 inch
Top View
Model Product Dimension
(W x D x H) Net Weight
LCDK1001 441.6 x 400 x 44 mm
17.4 x 15.7 x 1.73 inch 8.6 kg
18.9 lb
* All dimensions stated are subject to change if options are selected / integrated to base model part codes
Rear View
KB / MS
Power
www.RackmountMart.com
P.3
■Install left & right rear L-brackets with two fasteners
shown above.
■Leave the fasteners slightly loose.
■Measure the depth of the front and rear mounting
rails.
■Align each rear L-bracket to a suitable length and
tighten the fasteners.
■Fix the keyboard drawer into the rack.
M6 mounting screws & cage nuts are not provided.
Step 1
Step 2
Step 3
< 1.3 > Installation- How to install L-bracket
www.RackmountMart.com
P.4
Caution : The keyboard drawer is hot-pluggable, but components of connected devices, such
as the servers and KVM switch, may not be hot-pluggable. Plugging and unplugging cables
while servers and KVM are powered on may cause irreversible damage to the servers, KVM and
keyboard drawer. Before attempting to connect anything to the keyboard drawer, we suggest
turning offthe power to all devices. Apply power to connected devices again only after the
keyboarddrawerisreceivingpower.Thecompanyisnotresponsiblefordamagecausedinthisway.
< 1.4 > Connection to USB Server
< 1.4 > Connection to external KVM
Keyboard Drawer
Keyboard Drawer
USB server
USB console KVM
attached 2-in-1
K/B cable
USB
attached 2-in-1
K/B cable
www.RackmountMart.com
P.5
Key force 55 ± 5g
Travelling distance 3 ± 0.3mm
Switch life > 10 million life cycle time
OS support Windows / Linux / Unix / Mac OS
< Part 2 > Specifications
< 2.1 > Standard Keyboard / Mouse Specifications
Supporting layouts
America United States
EMEA United Kingdom Germany France Spain Italy
Asia Japan Korea
www.RackmountMart.com
keyboard integrated with trackball
B
keyboard integrated with touchpad
N
P.6
How to Use "MAC" Keyboard
Keyboard Features
F1
Decrease display brightness F9
Fast-forward
F2
Increase display brightness F10
Mute sound
F3
Mission control
* Only works with OS X Lion
default Keyboard Shortcuts.
F11
Decrease volume
F4
Dashboard F12
Increase volume
F7
Rewind Eject disc
F8
Play / Pause Command
Supporting layouts
America United States
< 2.1 > MAC Keyboard / Mouse Options
www.RackmountMart.com
MAC keyboard integrated with trackball
Mb
MAC keyboard integrated with touchpad
Mn
P.7
< 2.1 > SUN Keyboard / Mouse Options
Audio / Display Keys * Please ask your supplier for full details
F9
Audio : Mute
Display : Degauss
F11
Audio : Decrease volume
Display : Decrease contrast
F12
Audio : Increase volume
Display : Increase contrast
Num LED in Green mode
Key pad behaves as a normal key
pad mode
Num Cap s Scro ll Comp oseNum Cap s Scro ll Comp ose
■Incorporates SUN keys, including Stop, Cut, Paste, Compose, Copy and Help
■104 key notepad keyboard with full numerical pad and SUN function
■USB interface
■US layout only
Num LED in Offmode
Key pad behaves as a SUN Solar
system administration command mode
www.RackmountMart.com
SUN keyboard integrated with touchpad / trackball
How to Use "SUN" Keyboard
SUN keyboard integrated with trackball
Sb
SUN keyboard integrated with touchpad
Sn
P.8
Operating Temperature 0 to 55°C degree
Humidity 20~90%, non-condensing
Altitude 16,000 ft
Storage / Non-operating Temperature -20 to 60°C degree
Humidity 5~90%, non-condensing
Altitude 40,000 ft
Shock 10G acceleration (11ms duration)
Vibration 10~300Hz 0.5G RMS random vibration
< 2.2 > Environmental Conditions
The company reserves the right to modify product speciÞ cations without prior notice and assumes no responsibility
for any error which may appear in this publication.
All brand names, logo and registered trademarks are properties of their respective owners.
Copyright 2020 Synergy Global Technology Inc. All rights reserved.
