Syscom Video WIFI User manual

Quick Installation Guide
PT Mini Dome
Full HD
Network Camera
Please read this manual thoroughly before use, and keep it handy for future reference.

1. Description
The Network Camera supports the network service for a sensor image with progressive scan, which
can be monitored on a real-time screen regardless of distances and locations. By using its dedicated
program, many users are able to have an access to the Network Camera at once or a single user can
monitor various network cameras at the same time. It also enables users to play, store and retrieve a
monitoring image by using a PC. All the settings and real-time monitoring screens are also provided
through an access to the web.
The Network Camera is fully featured for security surveillance and remote monitoring needs. It is
based on the DSP compression chip, and makes it available on the network as real-time, full frame
rate Motion JPEG and H.264 (or MPEG-4) video streams.
1.1 Components
The system comes with the following components:
Mini Camera Installation CD Installation Guide
Accessory Kit Template sheet
Note 1: Check your package to make sure that you received the complete system, including all
components shown above.
Note 2: Adapter for DC 12V is not supplied.
2

1.2 Layout
Connection Cable
NO Wire Color Description
1 Gray Audio line output, RCA Jack
2 Red: DC12V
White: GND
Main Power, 2pin terminal
3
Blue: GND
Gray: ALARM INPUT
Brown: GND
Yellow : ALARM OUT
Ethernet, RJ-45 port compatible with 10/100Mbps having
PoE functionality. Modular Jack
3

Camera Dimension
See the diagrams below for the exact dimension
- WIFI MODEL
Dimensions Unit: mm
- Non WIFI MODEL
Dimensions Unit: mm
4

2. Installation
• Camera Installation
Carefully remove the contents from the box, and verity that nothing was damaged in shipment.
1) Make screw holes for camera on the ceiling with Template Sheet
2) Disassemble a camera by Camera Cover
3) Fix the camera set using Anchors(2x) and Screws(2x) to the ceiling.
•Connecting to the RJ-45
Connect a standard RJ-45 cable to the network port of the network camera. Generally a
cross-over cable is used for directly connection to PC, while a direct cable is used for connection
to a hub.
Micro SD memory slot
Insert the SD memory card.
• Connecting the Power
Connect the DC 12V power adaptor to the camera.
5

• Connecting the Wireless using WPS function (wifi model only)
Follow steps for a proper operation.
1. Make sure your AP (Access Point) and Operating System support WPS (Wi-Fi Protected Setup)
functions. WPS enables easy setup with compatible APs.
2. Press the WPS button on the camera board. You can then see the Status LED is blinking.
4. Press and hold down the WPS button on your AP (some router/AP will have a virtual button on
their management software instead). Refer to your AP's documentation for details using its WPS
functions
When WPS configuration is done, wireless connectivity will be established and the security
encryption, such as WEP or WPA-PSK, will be synchronized with the AP.
As for IP setting, the camera's use of DHCP or static IP is determined by your configuration on the
network camera via the web- based configuration of firmware. The camera's default is DHCP.
Notes:
1. WPS may not work if your AP is configured with a "hidden" SSID.
2. If any WPS-enabled AP is not detected, the camera will search APs for 60 seconds after
pressing the WPS button, and if the camera still can not detect an AP after 1 minute, the
wireless setup will be cancelled.
3. If a camera is assigned with a fixed IP outside the AP's network segment, wireless setup will
fail.
4. A wired connection always has a higher priority, and hence wireless setup will not take effect
when the RJ45 LAN port is connected.
6

2.2 Network Connection and IP assignment
The Network Camera supports the operation through the network. When a camera is first connected
to the network it has no IP address. So, it is necessary to allocate an IP address to the device with the
“Smart Manager” utility on the CD. (Default IP 192.168.30.220)
1. Connect the Network Camera / device to the network and power up.
2. Start SmartManager utility (Start>All programs>SmartManager>SmartManager), the main
window will be displayed, after a short while any network devices connected to the network will
be displayed in the list.
3. Select the camera on the list and click right button of the mouse. You can see the pop-up menu
below.
4. Select Assign IP. You cam see a Assign IP window. Enter the required IP address.
Note: For more information, refer to the Smart Manger User’s Manual.
7

3. Operation
The Network Camera can be used with Windows operating system and browsers. The recommended
browsers are Internet Explorer, Safari, Firefox, Opera and Google Chrome with Windows.
NOTE: To view streaming video in Microsoft Internet Explorer, set your browser to allow ActiveX
controls.
3.1 Access from a browser
1. Start a browser (Internet Explorer).
2. Enter the IP address or host name of the Network Camera in the Location/Address field of your
browser.
3. You can see a starting page. Click Live View or Setup to enter web page.
4. The network camera’s Live View page appears in your browser.
8

3.2. Access from the internet
Access from the internet once connected, the Network Camera is accessible on your local network
(LAN). To access the network camera from the Internet you must configure your broadband router to
allow incoming data traffic to the network camera. To do this, enable the NAT-traversal feature, which
will attempt to automatically configure the router to allow access to the network camera. This is
enabled from Setup > System > Network > NAT.
For more information, please see “3.5.6 System>Network>NAT” of User’s Manual.
3.3 Setting the admin password over a secure connection
T
o
g
ain access to the product, the password for
the default administrator user must be set. Thi s
is done in the “Admin Password” dial og, which is
displayed when the n etwork camera is accessed
for the setup at the first time. Enter your admin
name and password, set by the administrator.
Note: The default administrator username is
admin and password is admin. If the password is
lost, the Net work Camera must be r eset to the
factory default settings. See “3.8 Resetting to the
Factory Default Settings”.
3.4 Live View Page
The live view page comes in several screen
modes: 1920x1080, 1280x1024, 1280x720,
800x600, 704x480(576), 640x480,
352x240(288) and 320x240. Users are
allowed to select the most suitable one out
of those modes. Please, adjust the mode in
accordance with your PC specifications and
monitoring purposes.
1) General controls
Live View Page Search & Playback Page Setup Page Help Page
The video drop-down list allows you to select a customized or pre-programmed
video stream on the live view page. Stream profiles are configured under Setup > Basic
Configuration > Video & Image. For more information, please see “3.5.1 Basic Configuration >
Video & Image” of User’s Manual
9

The resolution drop-down list allows you to select the most suitable one
out of video resolutions to be displayed on live view page.
out of video resolutions to be displayed on live view page.
The protocol drop-down list allows you to select which combination of
protocols and methods to use depends on your viewing requirements, and on the properties of
your network.
2) Control toolbar
The live viewer toolbar is available in the web browser page only. It displays the following
buttons:
The Stop button stops the video stream being played. Pressing the key again toggles the
start and stop. The Start button connects to the network camera or start playing a
video stream.
The Pause button pause the video stream being played.
The Snapshot button takes a snapshot of the current image. The location where the
image is saved can be specified.
The digital zoom activates a zoom-in or zoom-out function for video image on the live
screen.
The Full Screen button causes the video image to fill the entire screen area. No other
windows will be visible. Press the 'Esc' button on the computer keyboard to cancel full
screen view.
The Manual Trigger button activates a pop-up window to manually start or stop the event.
The PT button activates a pop-up window for Pan, Tilt and Zoom control.
Use this scale to control the volume of the speakers.
Use this scale to control the volume of the microphone.
Use this scale to control the volume of the speakers and microphones.
3) Video Streams
The network camera provides several images and video stream formats. Your requirements and
the properties of your network will determine the type you use.
The Live View page in network camera provides access to H.264, MPEG-4 and Motion JPEG video
streams, and to the list of available video streams. Other applications and clients can also access
these video streams/images directly, without going via the Live View page.
10

3.5 Network Camera Setup
This section describes how to configure the network camera, and is intended for product
Administrators, who have unrestricted access to all the Setup tools; and Operators, who have access
to the settings for Basic, Live View, Video & Image and System Configuration.
You can configure the network camera by clicking Setup in the top right-hand corner of the Live View
page. Click on this page to access the online help that explains the setup tools
When accessing the Network Camera for the first time, the
“Admin Password” dialog appears. Enter your admin name and
password, set by the administrator.
Note: If the password is lost, the Network Camera must
be reset to the factory default settings.
See “3.6 Resetting to the Factory Default Settings”.
3.6 Resetting to the factory default settings
To reset the Network Camera to the original factory settings, go to the Setup>System> Maintenance
web page or use the Reset button on the network camera, as described below:
•Using the Reset Button
Follow the instructions below to reset the Network Camera to the factory default settings using
the Reset button.
1. Switch off the Network Camera by disconnecting the power adapter.
2. Press and hold the Reset button with a straightened paperclip while reconnecting the power.
3. Keep the Reset button pressed during about 2 seconds.
4. Release the Reset button.
5. The network camera resets to factory defaults and restarts after completing the factory
reset.
Caution: When performing a Factory Reset, you will lose any settings you have saved.
(Default IP 192.168.30.220)
3.7 More Information
For more information, please see the Network Camera User’s Manual, which is available on the CD
included in this package.
11
