SYSOLUTION L20 User manual

LCD Controller
L20 Instructions
Version：Ver.1.0

Statement
Dear user friend, thanks for choosing Shanghai Xixun Electronic Technology Co., Ltd.
(hereinafter referred to as Xixun Technology) as your LED advertising equipment control
system. The main purpose of this document is to help you quickly understand and use
the product. We strive to be precise and reliable when writing the document, and the
content may be modified or changed at any time without notice.
Copyright
The copyright of this document belongs to Xixun Technology. Without the written
permission of our company, no unit or individual may copy or extract the content of this
article in any form.
Trademark
is a registered trademark of Xixun Technology.

Update Record
Note:The document is subject to change without prior notice.
No. Version Details Date
1 Ver.1.0 Initial 18th Sep 2020

Catalogue
Statement ............................................................................................................................................2
Copyright.............................................................................................................................................2
Trademark ...........................................................................................................................................2
Overview .......................................................................................................................................................1
Functions And Features ...........................................................................................................................2
Interfaces.......................................................................................................................................................3
Technical Parameters ................................................................................................................................4
Software Operation Procedures............................................................................................................6
Hardware Connection Diagram ............................................................................................................7
Software Connection ................................................................................................................................8
LedOK System Parameters......................................................................................................................9
LED full screen width and height settings ................................................................................9
LedOK Configuration Network...........................................................................................................11
Method 1: Wired network configuration ...............................................................................11
Method 2: WiFi enabled...............................................................................................................12
Method 3: 4G configuration .......................................................................................................13
AIPS Cloud Platform Register .............................................................................................................15
Cloud platform account registration .......................................................................................15
Cloud platform account binding...............................................................................................16
End Page.....................................................................................................................................................17

Overview
L20 board integrates multimedia decoding, LCD driver, Ethernet, HDMI, WIFI, 4G,
Bluetooth, supports most of the current popular video and picture format decoding,
supports HDMI video output/input, dual 8/10-bit LVDS Interface and EDP interface, can
drive various TFT LCD displays, greatly simplify the system design of the whole machine,
TF card and SIM card holder with lock, more stable, very suitable for high-definition
network playback box, video advertising machine and picture frame Advertising
machine.
Note：
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation. Operation is
subject to the condition that this device does not cause harmful interference.
www.sysolution.net 1

Functions And Features
1. High integration: Integrate USB/LVDS/EDP/HDMI/Ethernet/WIFI/Bluetooth into one,
simplify the design of the whole machine, and can insert TF card;
2. Save labor costs: The built-in PCI-E 4G module supports various PCI-E 4G modules
such as Huawei and Longshang, which is more suitable for remote maintenance of
advertising all-in-one machine and saves labor costs;
3. Rich expansion interfaces: 6 USB interfaces (4 pins and 2 standard USB ports), 3
expandable serial ports, GPIO/ADC interface, which can meet the requirements of
various peripherals in the market;
4. High-definition: Maximum support 3840×2160 decoding and LCD display with
various LVDS/EDP interfaces;
5. Complete functions: Support horizontal and vertical screen playback, video split
screen, scrolling subtitles, timing switch, USB data import and other functions;
6. Convenient management: The user-friendly playlist background management
software is convenient for advertising playback management and control. it is easy
to understand the playback situation through Play log;
7. Software: LedOK Express.
www.sysolution.net 2

Interfaces
www.sysolution.net 3

Technical Parameters
Main Hardware Indicators
CPU
Rockchip RK3288 is the strongest quad-core 1.8GHz Cortex-A17
quad-core GPU Mail-T764
RAM 2G (default) (up to 4G)
Built-in
Memory
EMMC 16G(default)/32G/64G(optional)
Built-in ROM 2KB EEPROM
Decoded
Resolution
Supports a maximum of 3840 * 2160
Operating
System
Android 7.1
Play Mode Supports multiple playback modes such as loop, timing, and insertion
Network
Support
4G, Ethernet, support WiFi/Bluetooth, wireless peripheral expansion
Video
Playback
Support MP4 (.H.264, MPEG, DIVX, XVID) format
USB2.0
Interface
2 USB host, 4 USB sockets
Mipi Camera 24 pin FPC interface, support 1300w Camera (optional)
www.sysolution.net 4

Serial Port Default 3 TTL serial port sockets (can be changed to RS232 or 485)
GPS External GPS (optional)
WIFI、BT Built-in WIFI, BT (optional)
4G Built-in 4G module communication (optional)
Ethernet 1, 10M/100M/1000M adaptive Ethernet
TF Card Support TF card
LVDS Output 1 single/dual channel, can directly drive 50/60Hz LCD screen
EDP Output Can directly drive EDP interface LCD screen with various resolutions
HDMI
Output
1, support 1080P@120Hz, 4kx2k@60Hz output
HDMI Input HDMI input，30pin FPC custom interface
Audio and
video output
Support left and right channel output, built-in dual 8R/5W power
amplifier
RTC real time
clock
Support
Timer Switch Support
System
Upgrade
Support SD card/computer update
www.sysolution.net 5

Software Operation Procedures
www.sysolution.net 6

Hardware Connection Diagram
www.sysolution.net 7

Software Connection
Confirm the hardware connection, open the LedOK Express software, and the sending
card can be automatically detected in the device management interface. If the sending
card cannot be detected, please click the refresh button on the right side of the software
interface. If it is connected by a network cable, please open the "RJ45 Cable directly
connected" in the lower left corner of the software interface.
www.sysolution.net 8

LedOK System Parameters
LED full screen width and height settings
Click Terminal control and select the controller，go to Advanced parameters and input
password 888 to enter setup interface.
In the advanced configuration interface, enter the LED screen width and height
parameters and click "Set" to prompt success.
www.sysolution.net 9

www.sysolution.net 10

LedOK Configuration Network
There are three ways for the control card to access the network, namely, network cable
access, WiFi access, 3G/4G network access, and different types of control cards can
choose the network access method according to the application (choose one of the
three).
Method 1: Wired network configuration
Then open the network configuration interface, the first is the wired network, you can
set the IP parameters of the selected control card.
Control card access network priority wire network.
When selecting wireless WiFi or 4G network access, the wired network must be
unplugged, and the IP address of the sending card is obtained automatically.
www.sysolution.net 11

Method 2: WiFi enabled
Check WiFi Enable and wait for about 3 seconds, click Scan WiFi to scan available WiFi
nearby, select the WiFi and enter the password, click Save to save the WiFi configuration
to the control card.
After about 3 minutes, the control card will automatically search for the WiFi hotspot
connected to the configuration, and the "internet" light on the control card will flash
uniformly and slowly, indicating that it has connected to the cloud platform. At this time,
you can log in to the cloud platform www.m2mled.net to send the program.
Tips
If the WiFi cannot go online, you can troubleshoot the following situations:
1. Check whether the WiFi antenna is tightened;
www.sysolution.net 12

2. Please check if the WiFi password is correct;
3. Check whether the number of router access terminals has reached the upper limit;
4. Whether the E-card code is in the wifi location;
5. Re-select a WiFi hotspot to configure the connection;
6. Is the Y/M series wired network unplugged (priority wired network).
Method 3: 4G configuration
Check Enable 4G, the country code MMC can be automatically matched by the Get
Status button, and then select "Operator" to get the corresponding APN information, if
the operator cannot be found, you can check the "Custom" checkbox, Then manually
enter the APN information.
After setting the 4G parameters, wait for about 5 minutes for the control card to
www.sysolution.net 13

automatically dial the 3G/4G network to access the network; observe the "internet" light
of the control card flashing uniformly and slowly, which means that the cloud platform
has been connected, and you can log in to the cloud platform at this time.
www.ledaips.com to send programs.
Tips
If 4G cannot go online, you can check the following situations:
1. Check whether the 4Gantenna is tightened;
2. Is the Y series wired network unplugged (priority wired network);
3. Check whether the APN is correct (you can consult the operator);
4. Whether the status of the control card is normal, and whether the available flow of
the control card in the current month is greater than 0M;
5. Check whether the 4G signal strength is above 13, and the 3G/4G signal strength
can be obtained through "Network Status Detection".
www.sysolution.net 14

AIPS Cloud Platform Register
Cloud platform account registration
Open the cloud platform login interface, click the registration button, input information
according to the relevant prompts and click submit. After receiving the confirmation
email, click the link to confirm and complete the registration.
www.sysolution.net 15

Cloud platform account binding
Enter the web server address and company ID and click Save.
The foreign server address is: www.ledaips.com
www.sysolution.net 16
