System air VTR 100/B LITE Manual

Document in original language | 212962 · v02
VTR 100/B LITE
Installation and Service GB

212962 | v02
© Copyright Systemair AB
All rights reserved
E&OE
Systemair AB reserves the rights to alter their products without notice.
This also applies to products already ordered, as long as it does not affect the previously agreed specifications.

212962 | v02
Contents
1 Overview ......................................................1
1.1 General Description ................................1
1.2 Warranty..............................................1
1.3 Type label.............................................1
1.4 Important Safety Information ........... ....... ..1
1.4.1 Intended Use.............................1
1.4.2 Admonitions .............................2
1.4.3 Declaration of Conformity ............3
2 Technical Data ................................................4
2.1 Electrical data........................................4
2.2 Dimensions and Weight ...........................4
2.3 Duct connections....................................5
3 Delivery, Transport, Storage...............................6
3.1 Transport and storage .............................6
3.2 Delivery/Unloading.................................6
4 Installation.....................................................6
4.1 Unpacking ............................................6
4.2 Installation with 251-10/B cooker
hood ...................................................7
4.2.1 Wall preparation for mounting
bracket ....................................9
4.2.2 251-10/B cooker hood
installation.............................. 10
4.2.3 Unit mounting and cooker
hood wiring ............................ 11
4.3 Installation with 392–10/B cooker
hood .................................................12
4.3.1 Wall preparation for mounting
bracket .................................. 13
4.3.2 392–10/B cooker hood
installation.............................. 14
4.3.3 Unit mounting and cooker
hood wiring ............................ 16
4.4 Installation of a kitchen furniture
panel.................................................18
4.4.1 Mounting the kitchen furniture
panel directly on the unit ........... 18
4.4.2 Mounting the kitchen furniture
panel on sides of
cabinets ................................. 19
4.4.3 Fitting the kitchen furniture
panel as a door ........................ 21
5 Commissioning ............................................. 21
5.1 Control panel....................................... 21
5.1.1 Display symbols ....................... 22
5.2 Start up wizard .................................... 22
5.2.1 Procedure............................... 23
5.2.2 Perform Factory reset ............... 23
5.3 System curves ..... ........... ........... .......... 24
5.3.1 Flow settings supply air, G3/
Coarse 50% type filter .............. 24
5.3.2 Flow settings exhaust air, G3/
Coarse 50% type filter .............. 25
5.4 Airflow settings ................................... 25
5.4.1 Setting the airflow.................... 25
5.5 Moisture transfer control........................ 26
5.6 Defrost level settings ............................ 26
5.6.1 Setting the defrost level............. 27
5.7 Programming the Week schedule ............ 27
5.8 Ext/Force run ...................................... 28
5.9 Extra functions..................................... 28
6 Electrical connections ............. .......... ........... .. . 29
6.1 Print card layout................................... 29
6.2 External connections on the print
card ..................................................30
6.3 External connections on top of the
unit...................................................31
7 Before Starting the System.............................. 31
8 Operation....................................................32
8.1 Setting the temperature......................... 32
8.2 Manual setting of airflow ....................... 32
8.3 Manual and automatic summer
mode ................................................32
8.4 Cool recovery ...................................... 33
8.5 Service menu overview ......................... 33
9 Service .......................................................42
9.1 Warnings............................................ 42
9.2 Internal components ............................. 43
9.3 Component descriptions ........................ 43
9.3.1 Fans ...................................... 43
9.3.2 Filters .................................... 44

212962 | v02
Contents
9.3.3 Heat exchanger ....................... 44
9.3.4 Print card................................ 44
9.3.5 Temperature sensors ................ 44
9.3.6 Humidity sensor....................... 44
9.4 Trouble shooting .................................. 44
9.5 Alarm list............................................ 46
9.6 Replacing rotor drive belt ....................... 47

Overview |1
1 Overview
1.1 General Description
This installation manual concerns air handling unit type VTR 100/B LITE manufactured by Systemair.
The manual consists of basic information and recommendations concerning the design, installation, start-up and opera-
tion, to ensure a proper fail-free operation of the unit.
The key to proper and safe operating of the unit is to read this manual thoroughly, use the unit according to given
guidelines and adhere to all safety requirements.
1.2 Warranty
For the assertion of warranty claims, the products must be correctly connected and operated, and used in accordance
with the data sheets. Further prerequisites are a completed maintenance plan with no gaps and a commissioning re-
port. Systemair will require these in the case of a warranty claim.
1.3 Type label
Before calling your service representative, make a note of the specification and production number from the type label,
which can be found next to the external connections and inside of the unit.
Fig. 1 Type label
Position Description
1Product code (product specification)
2Product item number
3Production order number
4Serial number
5Production date (YY.MM.DD)
6QR code for manufacturing order (MO) number and software version
7QR code for the spare parts list and documentation
1.4 Important Safety Information
• Observe and respect local conditions, regulations and laws.
• Safety elements may not be dismantled, circumvented or deactivated.
• Wear protective equipment during all work in the vicinity of the unit.
• Do not allow children to play with the device.
1.4.1 Intended Use
• Abide by the system-related conditions and requirements of the system manufacturer or plant constructor.
• Keep all the warning signs on the device and in a legible condition.
212962 | v02

2|Overview
• The device is not to be used by persons (including children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given supervision or instruction.
• The system should operate continuously, and only be stopped for maintenance/service.
• Do not connect tumble dryers to the ventilation system.
• Make sure that filters are mounted before starting the unit.
1.4.2 Admonitions
Danger
• Make sure that the mains supply to the unit is disconnected before performing any maintenance or
electrical work!
• All electrical connections and maintenance work must be carried out by an authorized installer and in
accordance with local rules and regulations.
Warning
• This product must only be operated by a person who has suitable knowledge or training within this field
or carried out with the supervision of a suitably qualified person.
• Beware of sharp edges during mounting and maintenance. Use protective gloves.
Warning
• Risk of injury due to rotating parts that have not come to a complete standstill after mains supply to the
unit have been disconnected.
212962 | v02

Overview |3
1.4.3 Declaration of Conformity
Manufacturer
Systemair UAB
Linų st. 101
LT–20174 Ukmergė, LITHUANIA
Office: [phone] Fax: [phone]
www.systemair.com
hereby confirms that the following product:
Heat recovery ventilation unit: VTR 100/B LITE
(The declaration applies only to product in the condition it was delivered in and installed in the facility in accordance
with the included installation instructions. The insurance does not cover components that are added or actions carried
out subsequently on the product).
Comply with all applicable requirements in the following directives:
• Machinery Directive 2006/42/EC
• Low Voltage Directive 2014/35/EU
• EMC Directive 2014/30/EU
• Ecodesign Directive 2009/125/EC
• RoHS Directive 2011/65/EU
The following regulations are applied in applicable parts:
1253/2014 Requirements for ventilation units
1254/2014 Energy labelling of residential ventilation units
327/2011 Requirements for fans above 125 W
The following harmonized standards are applied in applicable parts:
EN ISO 12100:2010 Safety of machinery - General principles for design - Risk assessment and risk reduction
EN 13857 Safety of machinery – Safety distances to prevent hazard zones being reached by upper or
lower limbs
EN 60 335-1 Household and similar electrical appliances – Safety Part 1: General requirements
EN 60 335-2-40 Safety of household and similar electrical appliances – Part 2-40: Particular requirements
for electrical heat pumps, air-conditioners and dehumidifiers
EN 62233 Measurement methods for electromagnetic fields of household appliances and similar
apparatus with regard to human exposure
EN 50 106:2007 Safety of household and similar appliances – Particular rules for routine tests referring to
appliances under the scope of EN 60 335-1 and EN 60967
EN 61000-6-2 Electromagnetic compatibility (EMC) – Part 6-2: Generic standards – Immunity for industrial
environments
EN 61000-6-3 Electromagnetic compatibility (EMC) – Part 6-3: Generic standards – Emission standards for
residential, commercial and light-industrial environments
Skinnskatteberg, 30-03-2017
Mats Sándor
Technical Director
212962 | v02

4| Technical Data
2 Technical Data
2.1 Electrical data
Model Fans (W) Heater (W) Total (W) Fuse (mains) (A)
Standard 70 -83 10
With heater 70 250 333 10
Voltage 230V 1~, 50Hz
2.2 Dimensions and Weight
Fig. 2 Dimensions of left hand unit
212962 | v02

Technical Data | 5
Fig. 3 Dimensions of right hand unit
The unit weight is 48 kg.
2.3 Duct connections
Fig. 4 Duct connections
Symbol Description Symbol Description Symbol Description
Supply air Outdoor air Cooker hood air
212962 | v02

6| Delivery, Transport, Storage
Exhaust air Extract air
Duct connections: Ø 125 mm
3 Delivery, Transport, Storage
3.1 Transport and storage
The VTR 100/B LITE should be stored and transported in such a way that it is protected against physical damage. It
should be covered so dust, rain and snow cannot enter and damage the unit and its components.
Important
• Use the packaging exclusively as transport protection and not as a lifting aid.
• Load and unload the air handling unit carefully.
3.2 Delivery/Unloading
The appliance is delivered in one piece containing all necessary components, wrapped in plastic on a pallet for easy
transportation.
Checking delivery
• Check the packaging and the air handling unit for transport damage. Any findings should be noted on the cargo
manifest.
• Check completeness of the delivery.
Verify that all ordered equipment is delivered before starting the installation. Any discrepancies from the ordered
equipment must be reported to the supplier of Systemair products.
Warning
When opening the transport packaging, there is a risk of damage from sharp edges, nails, staples, splinters
etc.
Unpacking
• Check the air handling unit for visible transport damage.
• Only remove the packaging shortly before assembly.
• Beware of sharp edges during mounting and maintenance. Use protective gloves.
4 Installation
4.1 Unpacking
Verify that all ordered equipment are delivered before starting the installation. Any discrepancies from the ordered
equipment must be reported to the supplier of Systemair products.
Table 1 Included parts
Sticker for kitchen
furniture panel x 1
Brackets for panel
mounting x 2
Screw (bolt) M6x30
DIN 7985 x 4
Nut M6 DIN934 x 4 Modular hook for
kitchen furniture panel
x 4
212962 | v02

Installation | 7
Included parts cont'd
Screw 3,5x16 /13
SPAX for modular
hookx 12
Spacer for cooker
hood x 4
Screw (bolt) M5x25
DIN7985 for 392–10/
B mounting x 4
Cooker hood circular
insulation x 1
Fig. 5 Sticker dimensions
Dashed lines mark the outline of VTR 100/B LITE unit.
4.2 Installation with 251-10/B cooker hood
The VTR 100/B LITE is to be mounted above a stove.
Continue to follow instructions how to find the correct height and depth for mounting bracket installation.
212962 | v02

8| Installation
Fig. 6 VTR 100/B LITE in a kitchen environment
AMinimum distance between cabinets (mm) 600
BVTR 100/B LITE unit width (mm) 561
C, Electrical stove Minimum distance between stove surface and cooker
hood (mm)
450 (Recommended 500)
C, Gas stove Minimum distance between stove surface and cooker
hood (mm)
650
DWhen flexible duct is used, distance between the unit
and cooker hood is decided by the installer (minimum
100 mm).
100
EThe cooker hood height (mm) 150
FTotal height of the unit with cooker hood connected by
minimum 100 mm flexible duct distance (D)
850
GDistance to the mounting bracket from the underside
of the cooker hood or underside of the cupboard if it is
aligned with the cooker hood (mm)
Note:
This distance must be increased according to
the increased measurement Dif flexible duct is
used.
815
Important!
• The unit requires regular maintenance and therefore kitchen furniture panel between cabinets where the unit is lo-
cated must be removable.
• Depending on the cupboard depth and selected kitchen furniture panel installation method, the VTR 100/B LITE unit
may have to me shifted forward using wood blocks at the back.
• Solutions how to hang this panel are described further in this document, see 4.4 Installation of a kitchen furniture
panel, page 18.
Make sure to find a correct depth for installation of the VTR 100/B LITE unit before proceeding with the mounting
bracket installation on the wall.
The VTR 100/B LITE is supplied with approximately 1 m of power cable and fitted with a plug for 230 V~, single phase
earthed connection located at the top of the unit.
212962 | v02

Installation | 9
Recommended installation location for the outdoor air intake is the northern or eastern side of the building and with a
distance to openings for discharge of stale ventilation air, kitchen ventilator, central vacuum system, waste water drain-
age and other pollution sources like exhaust from traffic etc. Stale discharge air should ideally be led via a roof unit to
the outside and with a good distance to any outdoor air intake, windows etc.
4.2.1 Wall preparation for mounting bracket
The unit should be installed in such a way that there is no
vibration noise coming from the wall on which the unit is
installed.
Important
Make sure to read all instructions before
proceeding with installation procedure.
Installation steps can vary depending on the
type of installation.
1. Prepare the surface where the unit is to be mounted. Make sure that the surface is flat, vertical and that it supports
the weight of the unit. Perform the installation in accordance with local rules and regulations.
Fig. 7 Surface preparation.
C — concrete/bricks, W — wood block, G — gypsum, M — mineral wool
If the wall is from a thick concrete or bricks, no special preparation is needed (figure 7, pos. A), otherwise make nec-
essary adjustments (figure 7, pos. B). The unit weights 48 kg.
Make sure there is a power socket is located nearby the unit, preferably above it. It must be earthed. VTR 100/B LITE
power cable length is 1 m and it comes out from the top left side in right version units and from the right top side in
left version units. Choose power socket location accordingly.
212962 | v02

10 | Installation
Fig. 8 Installation of mounting bracket without or with wooden blocks
2. Screw the mounting bracket (pos. 1) with the anti-vibration pad (pos. 2) to the wall (figure 8, pos. A). Screws are not
included, choose them based on your wall type. Use appropriate holes to screw the bracket firmly to the wall. Bottom
side of bracket should be 40 mm (H) below top of unit position.
Leave 15 mm gap between the mounting bracket and the cupboard for the cooker hood wires.
Note:
Make sure that the mounting bracket is completely horizontal once mounted on the wall. Check with a spirit
level.
In case the depth of cabinets is much greater than the unit, install wooden blocks (pos. W) to compensate the missing
distance (figure 8, pos. B). Then install the mounting bracket on the upper block. Choose thickness of blocks according
to your needs.
Thickness of wooden blocks should be 25–100 mm. If needed distance is lower than 25 mm, adjust bolts instead of us-
ing wooden blocks (see figure 20).
Caution
Be sure to select the appropriate type and length of the screws so that they could hold additional wood
blocks and the unit itself.
4.2.2 251-10/B cooker hood installation
Fig. 9 Installation of the cooker hood
Product name and number
• 251-10/B White Cookerhood – 96698
• 251-10/B Stainless Cookerhood – 96699
The cooker hood must be installed to the wall/cupboards
first before it can be mounted on the wall because the
cooker hood power supply and control cables at the back
must be led to the top and already mounted VTR 100/B
LITE unit will block access.
212962 | v02

Installation | 11
Follow instructions delivered with the cooker hood how to prepare it before installation.
1. Connect the cooker hood to the unit via a flexible duct. Use mounting mechanism which is delivered together with
the cooker hood (figure 9, pos. X).
4.2.3 Unit mounting and cooker hood wiring
1. Pull the cooker hood power supply and control cables to the top since the mounted VTR 100/B LITE unit will block ac-
cess to the back.
Fig. 10 Placing the unit on the mounting bracket (the cooker hood is not shown)
2. Once all cooker hood cables at the back are led to the top, lift the unit and hang it on the mounting bracket.
Warning
Beware of sharp edges during mounting and maintenance. Use protective gloves.
Consider the unit weight when mounting!
Note:
Make sure that the unit is completely vertical and horizontal once mounted on the wall. Check with a spirit
level.
Make sure there is at least 2 mm gap between the unit and the cupboard to prevent vibration noises.
4.2.3.1 Wiring and configuration
1. Lead the cooker hood cables through a rubber grom-
met on top of the unit.
2. Connect control signal wires from the cooker hood to
digital input 2 (DI2) on the main board.
Note:
DI2 is pre-configured for cooker hood function.
Check and adjust airflow if necessary.
212962 | v02

12 | Installation
4.3 Installation with 392–10/B cooker hood
The VTR 100/B LITE is to be mounted above a stove.
Continue to follow instructions how to find the correct height and depth for mounting bracket installation.
Fig. 11 VTR 100/B LITE in a kitchen environment
AMinimum distance between cabinets (mm) 600
BVTR 100/B LITE unit width (mm) 561
C, Electrical stove Minimum distance between stove surface and cooker
hood (mm)
450 (Recommended 500)
C, Gas stove Minimum distance between stove surface and cooker
hood (mm)
650
DDistance between the unit and the cooker hood when
it is inserted directly into the unit (mm)
Note:
When flexible duct is used, distance between
the unit and cooker hood is decided by the
installer (minimum 100 mm).
10
EThe cooker hood height (mm): 97
FTotal height of the unit with inserted cooker hood
(mm):
707
GDistance to the mounting bracket from the underside
of the cooker hood or underside of the cupboard if it is
aligned with the cooker hood (mm)
Note:
This distance must be increased according to
the increased measurement Dif flexible duct is
used.
670
Important!
• The unit requires regular maintenance and therefore kitchen furniture panel between cabinets where the unit is lo-
cated must be removable.
• Depending on the cupboard depth and selected kitchen furniture panel installation method, the VTR 100/B LITE unit
may have to me shifted forward using wood blocks at the back.
212962 | v02

Installation | 13
• Solutions how to hang this panel are described further in this document, see 4.4 Installation of a kitchen furniture
panel, page 18.
Make sure to find a correct depth for installation of the VTR 100/B LITE unit before proceeding with the mounting
bracket installation on the wall.
The VTR 100/B LITE is supplied with approximately 1 m of power cable and fitted with a plug for 230 V~, single phase
earthed connection located at the top of the unit.
Recommended installation location for the outdoor air intake is the northern or eastern side of the building and with a
distance to openings for discharge of stale ventilation air, kitchen ventilator, central vacuum system, waste water drain-
age and other pollution sources like exhaust from traffic etc. Stale discharge air should ideally be led via a roof unit to
the outside and with a good distance to any outdoor air intake, windows etc.
4.3.1 Wall preparation for mounting bracket
The unit should be installed in such a way that there is no
vibration noise coming from the wall on which the unit is
installed.
Important
Make sure to read all instructions before
proceeding with installation procedure.
Installation steps can vary depending on the
type of installation.
1. Prepare the surface where the unit is to be mounted. Make sure that the surface is flat, vertical and that it supports
the weight of the unit. Perform the installation in accordance with local rules and regulations.
Fig. 12 Surface preparation.
C — concrete/bricks, W — wood block, G — gypsum, M — mineral wool
If the wall is from a thick concrete or bricks, no special preparation is needed (figure 12, pos. A), otherwise make nec-
essary adjustments (figure 12, pos. B). The unit weights 48 kg.
Make sure there is a power socket is located nearby the unit, preferably above it. It must be earthed. VTR 100/B LITE
power cable length is 1 m and it comes out from the top left side in right version units and from the right top side in
left version units. Choose power socket location accordingly.
212962 | v02

14 | Installation
Fig. 13 Installation of mounting bracket without or with wooden blocks
2. Screw the mounting bracket (pos. 1) with the anti-vibration pad (pos. 2) to the wall (figure 13, pos. A). Screws are
not included, choose them based on your wall type. Use appropriate holes to screw the bracket firmly to the wall.
Bottom side of bracket should be 40 mm (H) below top of unit position.
Leave 15 mm gap between the mounting bracket and the cupboard for the cooker hood wires.
Note:
Make sure that the mounting bracket is completely horizontal once mounted on the wall. Check with a spirit
level.
In case the depth of cabinets is much greater than the unit, install wooden blocks (pos. W) to compensate the missing
distance (figure 13, pos. B). Then install the mounting bracket on the upper block. Choose thickness of blocks according
to your needs.
Thickness of wooden blocks should be 25–100 mm. If needed distance is lower than 25 mm, adjust bolts instead of us-
ing wooden blocks (see figure 20).
Caution
Be sure to select the appropriate type and length of the screws so that they could hold additional wood
blocks and the unit itself.
4.3.2 392–10/B cooker hood installation
Product name and number
• 392-10/B Slimline — 77265
The cooker hood must be attached to the sides of cupboards or directly to the VTR 100/B LITE unit first before it can be
mounted on the wall because cooker hood power supply and control cables at the back must be led to the top and al-
ready mounted VTR 100/B LITE unit will block access.
There are two options how to install the cooker hood:
• The cooker hood is attached directly to the bottom of the unit. This option can be used when the whole unit with a
cooker hood will be shifted forward using wood blocks to be alighted with the cupboards or when the cupboard size
matches the unit and no adjustments are needed. This way the unit can be simply mounted directly on the wall with
already attached cooker hood.
• The cooker hood is attached to the sides of cupboards using included brackets. If the unit and cooker hood is not
aligned, a flexible duct must be used since it will be impossible to insert the cooker hood directly into the unit.
Follow instructions in the manual delivered with the cooker hood.
212962 | v02

Installation | 15
4.3.2.1 Installation between or in a cupboard without a base with a cooker hood attached
directly to the unit
Fig. 14 Attaching the cooker hood directly to the unit
1. Remove the cooker hood filter to access holes at the top of the cooker hood from inside.
Insert included screws (figure 14, pos. 2) into the cooker hood holes, place included plastic spacers on the each pro-
truding screw to prevent over-tightening (figure 14, pos. 3).
2. Place a circular insulation on the cooker hood connector to prevent air leaking (figure 14, pos. 4).
3. Insert the cooker hood duct connector into the unit and tighten the screws.
Screw the cooker hood directly to the bottom of the unit using prepared holes (figure 14, pos. 1).
4.3.2.2 Installation between or in a cupboard without a base using brackets
When the cooker hood cannot be attached directly to the unit, use included brackets. Flexible duct is needed to connect
the cooker hood with the VTR 100/B LITE unit when using this type of installation.
1.
Fig. 15 Installation using brackets
Mark out and fasten screws so that they protrude a few millimetres from both cupboard sides (figure 15, pos. A). If it
is intended to align the underside of the cooker hood with the underside of the row of cupboards, use the upper
measurement 102; see figure 15, pos. A. The cooker hood brackets are adjustable to fit various cupboard depths (fig-
ure 15, pos. B).
2. Move the cooker hood brackets without fully tightening the screws and adjust the brackets so that they fit the sides
of the cupboards (figure 15, pos. C). Hang the cooker hood in the pre-installed screws in the side of the cupboard.
212962 | v02

16 | Installation
Tighten the screws in the bracket and on the wall (figure 15, pos. D). Lock the brackets into position using the locking
screws (figure 15, pos. E).
4.3.2.3 Optional installation in a cupboard with a base
1.
Fig. 16 Dimensions of a hole in the base of the cupboard
Using a saw, cut out a hole in the base of the cupboard. When the VTR 100/B LITE unit is mounted directly on the wall,
the minimum distance from the wall to the hole has to be 55 mm (figure 16, pos. A).
Note:
Be sure to add the thickness (dimension X) of your wooden blocks if they were used (figure 16, pos. B).
Fig. 17 Installation using brackets
2. Attach the brackets as far into the cooker hood as pos-
sible. Insert the cooker hood up into the hole in the
base of the cupboard. Pull out (figure 17, pos. A) and
use screws to fasten the brackets to the sides of the
cupboard (figure 17, pos. B). Tighten the brackets in
the cooker hood.
4.3.3 Unit mounting and cooker hood wiring
Mounting the unit with attached cooker hood
1. Pull the cooker hood power supply and control cables to the top since the mounted VTR 100/B LITE unit will block ac-
cess to the back.
212962 | v02
