System air NOVA drive 370 Technical specifications

Systemair NOVA drive 370
Product Description

Product Desctription for Systemair NOVA drive 370
This system is designed and optimized to drive rotary heat exchangers. The system consist of a controller and 3 motor
models: 3Nm, 90 TYD-M-214, max shaft speed 250rpm. 6Nm, 120 TYD-M-214, max shaft speed 350rpm. 10Nm, 120
TYD-L-214, max shaft speed 350rpm. All have a minimum shaft speed of 0.2rpm. By external gear wheel it can run
exchangers from 0.02-20rpm. Control signal 0-10V (Modbus RTU) have an un-linear function to ensure a linear heat
transfer Extract/supply air. The system has a number of functions directed towards this type of application. Among
these, rotary guard function to check if exchanger is actually moving, purge function to ensure that the exchanger is
not getting full of particles when not in operation and many more described in this manual.

1 Safety information . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2 Product description . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3 Environmental constraints . . . . . . . . . . . . . . . . . . . . . . . . 4
4 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
5 Mechanical and electrical installation . . . . . . . . . . . . . . . . . . 7
6 Motor parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
7 LED behaviour . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
8 Fault behaviour . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
9 RHC features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
10 Modbus control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Contents

4| Systemair NOVA drive 370
1 Safety information
Before the installation and power supplying the drive, carefully read the instructions. The manufacturer is not responsi-
ble for incorrect installation and use of device. Please refer to section 6 for mechanical and electrical installation guide-
lines.
The appliance is intended to be installed only by a qualified person. Do not install or use a device which appears to be
damaged.
When connected to power the appliance must be grounded. Make sure the electrical installation on the rating plate
matches the power supply. Please refer to Table 2 for maximum fuse ratings and type.
CAUTION: Risk of hot surfaces and electric shock if the unit has been running! If service is required, please wait mini-
mum 5 minutes after power is disconnected before operating the unit.
2 Product description
Figure 1 – Illustration of the NOVA RHC 370 enclosure.
3 Environmental constraints
Storage Environment
Ambient temperature ºC -40°C to +70°C
Ambient humidity % RH 10% to 95% RH (Non condensing)
Altitude m0 to 2000 m
Working Environment
Ambient temperature ºC -40 ºC to +40 ºC
Ambient humidity % RH 10% to 95% RH (Non condensing)
Altitude m0 to 2000 m
Table 1: Environment

Systemair NOVA drive 370 |5
4 Technical data
Unit NOVA 370 (Item No. 90801116)
Overall ratings
Power level W50 - 450W
Motors used Inverter output power
90-TYD-S214-M W50 - 220 W
120-TYD-S214-M W50 - 370 W
120-TYD-S214-L W50 - 450 W
This configuration can only be used in professional equipment with a
total power greater than 1kW.
Efficiency %> 94%
@ 230VAC rms, 50Hz in; nominal power and current output; Ta 25°C
PFC strategy -Passive
Power factor @ max load Cos > 0.7
Ambient temperature ºC -40 to +40
Leakage current mA < 3.5
RCD Type A, B or F
Input supply (grid)
Nominal voltage Vrms 1 x 230 Vrms +10%/-20%
Supply connection -Single phase (phase-to-neutral or phase-to-phase) + earth/ground
Frequency Hz 50 Hz ±2 Hz
Max input current @ 230V supply Arms 3.6
External input fuse size Type MAX C16
Minimum supply without speed
reduction
Vrms 207
Minimum supply at reduced
speed
Vrms 184
Fuse -All inverters includes a PCB fuse on the input
EMC filter -Integrated
Inverter output
Maximum output current Arms 2.6
Maximum output frequency Hz 250 Hz (V/F mode)
Output voltage Vrms 0-230 Vrms (input supply dependent)
Motor type -Self – synchronous motor
Motor control
input reference
Minimum rpm 0.2
Maximum rpm 350
Motor control method -V/F control
Features -- V/F mode
- Minimum and maximum speed
- Ramping functions
- HMI (LED control, dip switches, power inputs, alarm relay)
- Fault management
- Analog control
- Modbus control
- Brake/hold function
- Scaled speed calculation
- Run data (counters, histograms, faults)

6| Systemair NOVA drive 370
Protection
Protection functions -Check Table 9
Module tem-
perature pro-
tection
Derate ºC 90 ºC
Shutdown 100 ºC
Circuit board
temperature
protection
(enclosed tem-
perature)
Derate ºC 75 ºC
Shutdown 80 ºC
Motor control method -V/F control
Output overcurrent shutdown (by
software)
Arms 3 Arms
Input over and under voltage Vrms 253 Vrms and 184 Vrms
Motor re-start -Restart on failure according to number of retries specified in Table 9
Control interface
Analog input Volt 0-10V, non-linear, incl start/stop hysteresis
Analog input impedance Ohm Approx. 15 kOhm
Digital input -1 x Digital input – Set Direction
1 x Digital input – Rotation sensor
Communication interface -1 x Modbus RTU (on RS485), 24V protected
Control interface alarm -1x Alarm relay NC/C/NO
Maximum: 2A/250Vac or 6A/24Vdc
Indicators -Red/Green/Yellow LED on the PCB, check Figure 6 for position
Settings -Dipswitch for Motor setting, reset and test function
Galvanic isolation -Reinforced Insulation
Auxiliary power supply
External auxiliary power supply V10 volt DC (@ input: 230 VAC +/-10%)
External auxiliary power supply mA Maximum 10mA
Enclosure
Material -Aluminium Alloy - No painting – Polymer cover (PC/ABS 5VA)
Mounting -4 x Ø5.5mm holes
Mounting direction -Vertical
Protection Ingress IP 54
Size L x W x
H
209x158x73 [mm]
Weight Kg 1.4
Connections -- Spring terminals for wires
- Bracket for Motor Cable shield
- Screw terminals for PE conductors
Cable fixing/fastening -Cable Glands
Cable glands -2 x M16
2 x M20
Service
Discharge time Minutes 5
Cooling time Minutes 5
Power-up Initialisation time Sec Max 12.5 s.
Table 2 – Product overview

Systemair NOVA drive 370 |7
5 Mechanical and electrical Installation
In this chapter the installation of the inverter is depicted, starting with mechanical installation guidelines including ori-
entation and mounting torque and finnishing with electrical installation guidelines. For the electrical installation, differ-
ent configurations are presented in details: such as connections in case of Analogue control or ModBus control.
5.1 Mechanical Installation
5.1.1 Drive mounting orientation
The drive mounting orientation shall be vertical, with the cable glands facing downwards. This is to ensure the best
thermal performance of the product. For reference, please refer to Figure 2.
Figure 2 – Mounting orientation of NOVA inverter family
5.1.2 Drive maximum mounting torque and allowed wire dimensions
A visual represenation of the mounting torque and allowed wires can be seen in Figure 3. Required tools for mounting
are presented in Table 3 together with the recommended torque.
Component Mouting tools Torque [Nm]
Motor cable shield PZ1 screwdriver 0.8 – 1.2
Earth connector PZ2 or Flat blade 6mm screwdriver 1.2
Top cover PZ2 or Flat blade 6mm screwdriver 0.8 – 1.2
Table 3 - Tools required for mounting and torque recommendation

8| Systemair NOVA drive 370
The connectors for the inverter come in 2 sizes. A larger one for the power (motor + supply) and alarm relay and small-
er ones for the signal wires. Detailed information regarding allowed wire termination or wire types can be seen in Table
4.
Connector Connection type Size
Motor (U,V,W);
Supply (N,L);
Alarm (NC, COM, NO)
Solid wire(1),(2) 0.2 – 4.0 mm2 (26 – 12 AWG)
Stranded wire(1) 0.2 – 2.5 mm2 (26 – 14 AWG)
Flat blade max. 3.5 mm
Analogue Control (0V, Uin, Uout);
Rotary Sensor (0V, RUN, DIR);
MODBUS (0V, B, A)
Solid wire(1) 0.2 – 1.5 mm2 (26 – 16 AWG)
Stranded wire(1) 0.2 – 1.5 mm2 (26 – 16 AWG)
Flat blade max. 2.5 mm
NOTE:
(1): Max length of wire strip is 9 – 10 mm.
(2): Solid wire connection not allowed for Motor Connector!
Table 4 – Connector connection types
Figure 3 – Drive mounting torque and allowed wire dimensions

Systemair NOVA drive 370 |9
5.2 Electrical Installation
When installing the product, means of power disconnection shall be incorporated in the fixed wiring in order to ensure
all pole disconnection from supply mains. A fuse shall be installed in front of the inverter, with the following character-
istic: max C16.
5.2.1 Earthing / Grounding
Ground the drive properly. Refer to Figure 5 for ground connector marked with PE for its placement. Use the mounting
torque specified in section 6.1. Do not rely only on the conduit connecting to the drive case as a replacement for a
ground wire. Do not ground one inverter to another in a ”daisy-chain” manner.
WARNING: Earthing/Grounding hazard
For the operator safety it is important to ground the drive properly and follow the provided grounding guidelines.
RCD compatibility
For extra safety protection a Residual Current Device (RCD) shall be used with the inverter, provided that the local safe-
ty regulations are complied with.
Leakage current in the inverter is measured to be less than 3.5mA therefore the following RCD types can be used: A, F
or B.
Power supply system
The device is designed to be operated in a TN earthing systems. It can be used in either of the TN-C, TN-C-S and TN-S
earthing systems. For a view over the allowed power supply systems refer to Figure 4.
Figure 4 – Power supply systems
TN – S TN – C – S TN – C
5.2.2 Overview of general electrical connections
A general diagram on how to connect NOVA RHC is depicted below. Detailed instructions are given below, in steps.

10 | Systemair NOVA drive 370
Analog control
The speed reference is given as 0-10V to the NOVA drive.
Modbus
As soon as a valid message is received trough Modbus, the NOVA drive will switch from analogue to Modbus commu-
nication and will continue operating in this manner until power is reset.
Enable rotary guard
To use the rotary guard, the sensor must be supplied with 10 V from Uout 10V and connected to ground, 0V. The out-
put from the sensor must be connected to RUN.
Disable rotary guard
If you do not wish to use the rotary guard feature, disable it by connecting the RUN terminal to Uout 10V. To re-enable
it you must power reset NOVA and connect according to described earlier.
DIR
RUN
0V
U out 10V
U in 0-10V
0V
Modbus
B
A
0V

Systemair NOVA drive 370 |11
DIR
0V
Direction
CW/CCW
Motor parameters
Break
Reset / Automatic test
B
A
0V
Pot. meter
C
A
B
DF E
5.2.3 Motor settings and direction
Figure 11 – Motor settings and direction
The dip settings (A) of the motor must be set accordingly:
• Dips 1-3 are used for motor selection. Refer to Table 5 for more information.
• Dip 4 is used for break functionality. When set to ON when the motor is stopped it will break by shorting the wind-
ings making it harder to rotate. When set to OFF it is easier to turn the rotor, when the motor is not running.
• Dip 5 must be set to OFF. The usage is reserved for fault reset.
When DIR in (B) is left unconnected the motor will rotate in one direction. If DIR is connected to 0V it will rotate in the
opposite. Connect DIR to 0V if you wish to change the direction the motor rotates. Note that the direction will change
the next time the motor starts, not when it is already rotating.
Maximum speed can be reduced and set as 50-100% of the maximum speed given by the dip switch settings. This
can be done using the potentiometer in (C).
It is possible to reset faults and warnings by toggling dip switch 5 (off->on->off) in less than 5 seconds. This will also
set the inverter to use analog control unless new Modbus messages are received.
If using the alarm signal in the relay connect it in (E).
6 Motor parameters
Motor parameters are set using dip switches 1-3. A table is depicted bellow with the correspondence between dip
switches and motor parameters selected.
Dip switch (123) Id Motor MaxSpeed (RPM)
000 090TYD-S214-M 200
100 190TYD-S214-M 250
010 2120-TYD-S214-M 250
110 3120-TYD-S214-M 300
001 4120-TYD-S214-M 350
101 5120-TYD-S214-L 300
011 6120-TYD-S214-L 350
Table 5 – Motor parameters selection

12 | Systemair NOVA drive 370
7 LED behaviour
The three LEDs in NOVA RHC (red, yellow, green) behaviour is depicted below.
Start/Stop signals
Stopped and ready to start The inverter indicates it is stopped but ready to start (no faults prevent starting).
In this case the green LED flash slowly (500ms on, 500 ms off). If the inverter
has warnings or errors, then it will not show this.
Running When the inverter is running, the green LED is ON all the time. If the inverter has
warnings or errors then it will show those instead.
Retrying When the inverter has been stopped due to a fault and try to start again on its
own, it flash green fast (200 ms on, 200 ms off). It stops flashing when it has
reached the setpoint. As the control strategy is V/f, tolerance for reaching the
setpoint is 0. If the inverter has warnings or errors it will overwrite those and not
show those warnings and errors until the retry has reached the setpoint.
Faults and warnings
Warnings When the inverter has a warning it flashes the yellow LED as many times as the
warning code and then pauses (400 ms on, 400 ms off, 2000 ms pause at the
end). The action is repeated until the warnings are cleared. If more than one
warning is activated the latest warning is the one shown.
Faults When the inverter has an error that prevents it from starting then it flashes red
as many times as the error code and then pauses (400 ms on, 400 ms off, 2000
ms pause at the end). The action is repeated until the errors are cleared. If a
warning appears after an error the inverter will still show the latest error as it
has higher priority.
Rotary guard
Rotary guard passed When the rotary guard passes it shows the red-green-red-green sequence
(200ms each LED). If the inverter has no warnings or faults then this sequence
will override any LED indication immediately. If there are warnings or faults it will
wait for the fault sequence to stop toggling the LEDs indicating the error number
and will show the rotary guard sequence after.
Table 8 – LED behaviour table
8 Fault behaviour
Each error has a maximum number of retries allowed within a 30 minute window. After 30 minutes of no errors the
counts are reset. Errors are only counted when the motor is running or trying to run. Rotary Guard errors do not get
auto-reset after 30 minutes and stay forever until the reset fault command is sent. This is because at low speeds it can
take more than 30 minutes for the error to appear.
When an error occurs, the inverter will stop (except with Modbus communication error) and set the relay. If the inverter
is able to retry a start again (count < maxCount for that error) then it is considered a warning. In this case, the inverter
will inform with the warning LED sequence and will clear the relay when retrying. It will also set the warning bit in
WarningContents. The user must power reset or reset faults to clear the warnings (both LEDs and register). Modbus
communication error will never stop the inverter and will only show as a warning.
When an error has occurred enough that count >= maxCount then the inverter will stop trying to start. In this case it
will blink with the error LED sequence leave the relay set. At this point the inverter must be reset or the fault clear to
start operation again.
A summary of errors is given below.

Systemair NOVA drive 370 |13
Error Blinks Retries Flag bit Value in AlarmLog
Rotary guard Always on 3
(no auto reset)
8 9
Overcurrent stop 1 2 0 1
Overvoltage 2 2 1 2
Undervoltage 3 1 2 3
Hardware error (gate kill) 4 1 3 4
Modbus communication 5Unlimited 15 15
Overheating stop 6 1 4 5
Backend communication 7 0 5 6
CRC error 8 0 7 8
Table 9 – Summary of errors
9 NOVA drive features
9.1 Rotary guard
Rotary guards counts the time in between pulses given by the rotary guard sensor. The time is compared against the
maximum allowed time which is calculated based on the inverter speed. The time allowed at maximum speed given by
the dip switches is 12 seconds to permit 2 full rotations (2x5 seconds) and 2 extra seconds of tolerance.
When the rotary guard passes the rotary sensor an LED sequence is played (red-green-red-green). This will play even
if the inverter output is stopped.
The rotary guard sensor is connected to the Uout (10V), 0V and RUN, to give the signal to NOVA. See Figure 10 for the
connection diagram.
Rotary guard is by default enabled and will eventually stop (coast) the Motor if the pulse is not detected for enough
time. At this point the inverter will attempt to start again up to 3 times, after which it will stop.
It is possible to disable the rotary guard feature by connecting the RUN input (Rotary guard) to Uout (10V). Refer to
Figure 9 for a diagram. When the inverter is running the motor and the rotary input is high for more than 10 seconds
the functionality is disabled. At this point a power reset is needed, to enable it again.
9.2 Purge function
When the inverter has been stopped for 30 minutes the purge function is activated. During purge the inverter will start
the motor and set it to run at 10 rpm for 12 seconds. After this time the inverter is stopped again. The sequence is
repeated after 30 minutes of inactivity.
9.3 Brake functionality
If dip switch 4 is set to ON the brake functionality is activated. When the motor is stopped and if the brake functionality
is activated it will brake the rotor by shorting the windings. With brake activated it is harder to move the rotor, when
stopped. If brake functionality is activated it can take up to 10 seconds to start braking once the motor is stopped.
9.4 Direction input
It is possible to use the direction input to change the direction the motor is spinning. If nothing is connected, the direc-
tion input is pulled high. To reverse the direction connect the direction input to 0V. Refer to (B) in Figure 11 for a con-
nection diagram.
Note that direction will not change once the motor is running.
9.5 Automatic test
Activate dip switch 5 for more than 10 seconds to start the automatic test. During automatic test the motor will go to
maximum speed and wait there for 10 seconds. After this it will ramp down and stop for another 10 seconds. The pro-
cess is repeated again and again, until stopped by setting the dip switch 5 off.

14 | Systemair NOVA drive 370
10 Modbus control
10.1 Control
As soon as a valid message is received trough Modbus, NOVA will switch from analog to Modbus communication and
will continue operating in this manner until power is reset.
10.2 Connection
The interface to Modbus follows:
Interface RS485
Baudrate 9600
Data bits 8
Parity None
Stop bits 1
Default address 7
Table 3 – Modbus connection details
10.3 Addressing
The default address for the inverter is 7. The address can be changed trough Modbus. To change the address follow
the following steps:
1. Connect to the inverter using the current address
2. Change the address in register 0x4F to the desired one
3. Wait 10 seconds
4. Turn off the device (wait 60 seconds)
5. Turn on the device
6. You can connect using the new address specified in point 2
7. If unknown address has been set. A Modbus scan tool must be used to find the set address
10.4 Modbus registers
The following Modbus registers are available. All the registers are either input registers (16-bit read-only denoted by R)
or holding registers (16-bit read-write denoted by RW).
Register Address Type Description
Backwards compatible control
Operation 0x01 RW Bit 0: Run(1) / Stop(0)
Bit 3: Clear fault (it can be combined with Run)
SpeedSet 0x02 RW Speed set 0-100%, written 0-1000 for quantification
SupplyVoltage 0x03 RDC link voltage in [V]
FaultContents 0x04 RBits are set for each fault according to Table 9
OutputSpeed 0x05 REstimated motor speed in [rpm]
OutputVoltage 0x06 RMotor RMS voltage in [V]
OutputCurrent 0x07 RMotor RMS current in [mA]
OutputPower 0x08 RMotor power in [W]
InputPower 0x09 RAdded for compatibility reasons. Same as OutputPower
AccOperationTime 0x0A RTotal time the motor has been running x10 in hours. A value of 5
for example means 50 hours.
MaxSpeed 0x0B RMax speed as set in [rpm]
MinSpeed 0x0C RMin speed as set in [rpm]
SW version 0x0D RBackwards compatible SW version, always increasing
HW version 0x0E RHW version of PCB
Application type 0x0F RApplication type, for backwards compatibility, set as 0

Systemair NOVA drive 370 |15
New info features
ModbusAddress 0x4F RW Address used in Modbus. Default is 7
AlarmLog 0xC0 RLast 4 FaultContent alarm codes
ModuleTemperature 0xC1 RTemperature of the module in [ºC]
MceStatusFlags 0xC2 RStatus flags of the motor control software for internal usage
MceFaultFlags 0xC3 RFault flags of the motor control software for internal usage
PCBTemperature 0xC4 RPCB temperature in [ºC]
WarningContents 0xC5 RWarnings, which each bit as set for each according to Table 9
SpeedSetScaled 0xC7 RReference speed in [10*rpm]
Dip1 0x110 RDip 1 value, 0 (off) or 1 (on)
Dip2 0x111 RDip 2 value, 0 (off) or 1 (on)
Dip3 0x112 RDip 3 value, 0 (off) or 1 (on)
Dip4 0x113 RDip 4 value, 0 (off) or 1 (on)
Dip5 0x114 RDip 5 value, 0 (off) or 1 (on)
Guard in 0x115 RRotor guard value 0 or 1
Test running 0x116 R1 when test is running, 0 otherwise
Speed external 0-10V 0x117 R0 - 4095 speed input
Trimmer 0-10V 0x118 R0 – 4095 trimmer input
Extended SW version
FrontendVersion 0x320 –
0x333
RFrontend software version C string.
BackendVersion 0x334 –
0x347
RBackend software version C string.
Table 4 – Modbus registers
10.5 Normal operation
Write the speed reference in SpeedSet between 0 and 1000 (0-100%). Note that the conversion from SpeedSet to
rpm speed is non-linear. The reference in rpm can be read using register SpeedSetScaled. The minimum and maximum
speed can be read in registers MinSpeed and MaxSpeed.
Start the motor by setting Operation to 1. Stop it by setting it to 0. You can change the speed while the motor is run-
ning.
If communication with the device is stopped, a warning will appear after 10 seconds but the motor will keep running.
Faults and warnings can be reset by setting operation Bit 3.

16 | Systemair NOVA drive 370
11 Declaration of Conformity
Declaration of Conformance according to
2014/30/EU, Electromagnetic compatibility Directive.
2014/35/EU, Low Voltage Directive.
2015/863/EU, RoHS3 Directive
Apparatus / Fabricate :
Category
-
Type
-
Type No (Object)
NOVA-450 RHC. p/n : 320928xxxx.
Description
Manufacturer Eltwin A/S
The object of the declaration described above is in conformity with the relevant Union harmonisation legislation.
Certificate of Conformance according to following standards :
Description:
EN 60335-1:2012,
A1:2019, A11:2014, A2:2019,
A13:2017, A14:2019
Safety req. (Automatic electrical controls for household and similar use).
EN 60335-2-40:2004,
A11:2014, A12:2005.
Safety req.
(Particular requirements for electrical heat pumps, air-conditioners and
dehumidifiers)
EN 61800-5-1:2007,
A1:2017.
Safety req. (Electrical, thermal and energy)
EN 61800-3:2018
EMC req. (
Adjustable speed electrical power drive systems - Part 3:
“First environment / category C2”).
EN 61000-6-3:2007,
A1:2011
EMC req. Emission (/ residential, commercial and light industry)
EN 61000-6-2:2019
EMC req.
Immunity (/ Industrial environment)
This declaration of conformity is issued under the sole responsibility of the manufacturer.
Signatures Etc:
Eltwin A/S
Torsoevej 1b
DK-8240 Risskov.
http : www.eltwin.com email : [e-mail]
Date
02.12.2020
Signature
/ Christian Kühl, Manager R&D.

Systemair NOVA drive 370 |17
12 Appendix: Motor types
Motor model: 90TYD-S214M
Motor name: No gearbox Low Speed Motor
Motor Type: AC Synchronous Motor
Driver: AC Frequency Converter
Motor Parameters
Phase: 3ph
Supply Voltage: 133/230 V±10%
Rated Frequency: 50HZ
Frequency range: 0-1-50HZ
Speed Per Frequency: 4.286rpm
Current: 0.79/0.46A
Pole pairs: 14
Rated Speed: 214.3 rpm
Speed Range: 0-4.286-214 rpm
Rated Torque 2.8 N.m
Back Electromotive Force: 214 rpm = V
Rotor inertia:0.5±0.25Kg.cm
Connection mode: Y
Rotation direction:: CW CCW
temperature rise: 75℃
Working Time: S2 50%
Insulation Class: F
Insulation Resistance:＞200 MΩ
Protection: IP54
Operating condition temperature: -25℃~50 ℃
Relative humidity: ≤80% (No Dew)
Cooling: IC410（Self-cooling）
Motor Weight: 3.8±0.05 kg
Mounting Dimensions
Systemair Item No. 90801102
Max Torque: 3NM

18 | Systemair NOVA drive 370
Motor model: 120TYD-S214M
Motor name: No gearbox Low Speed Motor
Motor Type: AC Synchronous Motor
Driver: AC Frequency Converter
Motor Parameters
Phase: 3ph
Supply Voltage: 133/230 V±10%
Rated Frequency: 50HZ
Frequency range: 0-1-50HZ
Speed Per Frequency: 4.286rpm
Current: 1.37/0.79A
Pole pairs: 14
Rated Speed: 214.3 rpm
Speed Range: 0-4.286-214 rpm
Rated Torque 5.5 N.m
Back Electromotive Force: 214 rpm = V
Rotor inertia:0.5±0.25Kg.cm
Connection mode: Y/∆
Rotation direction:: CW CCW
temperature rise: 75℃
Working Time: S2 50%
Insulation Class: F
Insulation Resistance:＞200 MΩ
Protection: IP54
Operating condition temperature: -25℃~50 ℃
Relative humidity: ≤80% (No Dew)
Cooling: IC410（Self-cooling）
Motor Weight: 6±0.05 kg
Mounting Dimensions
Systemair Item No. 90801103
Max Torque: 6NM

Systemair NOVA drive 370 |19
Motor model: 120TYD-S214L
Motor name: No gearbox Low Speed Motor
Motor Type: AC Synchronous Motor
Driver: AC Frequency Converter
Motor Parameters
Phase: 3ph
Supply Voltage: 133/230 V±10%
Rated Frequency: 50HZ
Frequency range: 0-1-50HZ
Speed Per Frequency: 4.286rpm
Current: 2.04/1.18A
Pole pairs: 14
Rated Speed: 214.3 rpm
Speed Range: 0-4.286-214 rpm
Rated Torque 8 N.m
Back Electromotive Force: 214 rpm = V
Rotor inertia:0.5±0.25Kg.cm
Connection mode: Y/∆
Rotation direction:: CW CCW
temperature rise: 75℃
Working Time: S2 50%
Insulation Class: F
Insulation Resistance:＞200 MΩ
Protection: IP54
Operating condition temperature: -25℃~50 ℃
Relative humidity: ≤80% (No Dew)
Cooling: IC410（Self-cooling）
Motor Weight: 8±0.05 kg
Mounting Dimensions
Systemair Item No. 90801105
Max Torque: 10NM

Systemair DK • December 2021 • V2
Systemair A/S
Ved Milepælen 7
DK-8361 Hasselager,
DENMARK
Tel. [phone]
[e-mail]
www.systemair.dk
Systemair UAB
Linų st. 101
LT–20174 Ukmergė,
LITHUANIA
Tel. [phone]
[e-mail]
www.systemair.lt
Systemair AS
Industriveien 83
NO-2072 Dal,
NORWAY
Tel. [phone]
[e-mail]
www.systemair.no
Systemair B.V.
Zanddonkweg 7a
5144 NX Waalwijk,
NETHERLANDS
Tel. [phone]
[e-mail]
www.systemair.nl
Systemair HVAC Spain S.L.U
C/ Montecarlo 14, Fuenlabrada
ES–28942, Madrid,
SPAIN
Tel. [phone]
[e-mail]
www.systemair.es
Systemair HSK
Büyükdere Cd. No:121 Ercan Han Kat: 7
Esentepe – Şişli / İstanbul
TURKEY
Tel. [phone]
[e-mail]
www.systemair.com/tr
Systemair d.o.o.
Špelina ulica 2
SI-2000 Maribor,
SLOVENIA
Tel. + 386 (0)2 460 18 22
[e-mail]
www.systemair.si
