System air FRQS-E-6A User manual

FRQS-E-6/10A
Frequency inverter with sine lter for 1 ~ fans
Operating Instructions
Speed controller with 0...10 V input for presetting the fan speed
Keep for reference!
Software version: D1628A from Version 11.03
L-BAL-E246-GB 1512 Index 001 Part.-No. 00163443-42
english

Content
1 General notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.1 Structure of the operating instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.2 Target group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.3 Exclusion of liability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.4 Copyright . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.1 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.2 Explanations of symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.3 Product safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.4 Requirements placed on the personnel / due diligence . . . . . . . . . . . . . . . . . . . . . . . . 5
2.5 Start-up and during operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.6 Working on device / Hazards through “residual voltage” . . . . . . . . . . . . . . . . . . . . . . . 5
2.7 Modifications / interventions in the device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.8 Operator’s obligation of diligence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.9 Employment of external personnel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3 Product overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.1 Operational area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.2 Functional description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.3 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.4 Transport . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.5 Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.6 Disposal / recycling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4 Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4.1 General notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4.2 Minimum space requirement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
4.3 Outdoor installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
4.4 Installation location for agriculture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
4.5 Temperature influences during commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
5 Electrical installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
5.1 Safety precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
5.2 EMC-compatible installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
5.2.1 Motor cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
5.2.2 Control cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
5.3 Mains connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
5.3.1 Line voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
5.3.2 Required quality attributes for the mains voltage . . . . . . . . . . . . . . . . . . . . . . . . . . 9
5.3.3 Leakage current, securely attached, protective earth conductor . . . . . . . . . . . . . . 10
5.4 Residual-current-operated protective device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
5.5 Inverter output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
5.5.1 Motor connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
5.5.2 Disconnection between controller and motor (repair switch) . . . . . . . . . . . . . . . . . 10
5.5.3 U/f-characteristic curve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
5.6 Motor protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
5.7 Analog input “E1” for setting fan speed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
5.8 Output 10 V (A2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
5.9 Enable, Device ON / OFF (Digital In 1 D1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
5.10 Relay outputs (K2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
5.11 Bypass circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
5.12 Potential at control voltage connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Operating Instructions FRQS-E-6/10A
L-BAL-E246-GB 1512 Index 001 Part.-No. 00163443-42
2/17

6 Start-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
6.1 Prerequisites for commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
7 Diagnostics / Faults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
8 Enclosure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
8.1 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
8.1.1 Max. load dependent on ambient temperature and line voltage. . . . . . . . . . . . . . . . 15
8.2 Connection diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
8.3 Dimensions [mm] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
8.4 Manufacturer reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Operating Instructions FRQS-E-6/10A
L-BAL-E246-GB 1512 Index 001 Part.-No. 00163443-42
3/17

1 General notes
1.1 Structure of the operating instructions
Before installation and start-up, read this manual carefully to ensure correct use!
We emphasize that these operating instructions apply to specific units only, and are in no way
valid for the complete system!
Use these operating instructions to work safely with and on the device. They contain safety instruc-
tions that must be complied with as well as information that is required for failure-free operation of the
device.
Keep these operating instructions together with the device. It must be ensured that all persons that
are to work on the device can refer to the operating instructions at any time.
Keep the operating instructions for continued use. They must be passed-on to all successive owners,
users and final customers.
1.2 Target group
The operating instructions address persons entrusted with planning, installation, commissioning and
maintenance and servicing and who have the corresponding qualifications and skills for their job.
1.3 Exclusion of liability
Concurrence between the contents of these operating instructions and the described hardware and
software in the device has been examined. It is still possible that non-compliances exist; no guarantee
is assumed for complete conformity. To allow for future developments, construction methods and
technical data given are subject to alteration. We do not accept any liability for possible errors or
omissions in the information contained in data, illustrations or drawings provided.
We accept no liability for damage caused by misuse, incorrect use, improper use or as a consequence
of unauthorized repairs or modifications.
1.4 Copyright
These operating instructions contain copyright protected information. The operating instructions may
be neither completely nor partially photocopied, reproduced, translated or put on data medium without
previous explicit consent. Infringements are liable for damages. All rights reserved, including those
that arise through patent issue or registration on a utility model.
2 Safety instructions
This chapter contains instructions to prevent personal injury and property damage. These instructions
do not lay claim to completeness. In case of questions and problems, please consult our company
technicians.
2.1 Intended use
The equipment is to be used solely for the purposes specified and confirmed in the order. Other uses
which do not coincide with, or which exceed those specified will be deemed unauthorised unless
contractually agreed. Damages resulting from such unauthorised uses will not be the liability of the
manufacturer. The user will assume sole liability.
Reading these operating instructions and complying with all contained instructions - especially the
safety notifications contained therein - are considered part of intended use. To consider is also the
manual of attached components. Not the manufacturer, rather the operator of the device is liable for
any personal harm or material damage arising from non-intended use!
2.2 Explanations of symbols
Safety instructions are highlighted with warning triangles and are depicted according to the degree of
hazard as follows.
Attention!
General hazardous area. Death or severe injury or significant property damage can occur if the
corresponding precautions are not taken!
Operating Instructions FRQS-E-6/10A General notes
L-BAL-E246-GB 1512 Index 001 Part.-No. 00163443-42
4/17

Danger due to electric current
Danger by dangerous, electric voltage! Death or severe injury can occur if the corresponding
precautions are not taken!
Information
Important additional information and advice for user.
2.3 Product safety
The device conforms to the state of the art at the time of delivery and is fundamentally considered to
be reliable. The device and its accessories must only be used in a flawless condition and installed and
operated in compliance with the assembly instructions and/or operating instructions. Operating out-
side the device's technical specifications (
name plate and attachment / technical data) can lead to
a defect in the device and additional damage!
In the case of a malfunction or a failure of the equipment check all functions with alarms in
order to prevent injury to persons or property. Note possibility of back-up operation. If used in
intensive animal environments, any malfunctions in the air supply must be detected as soon
as possible to prevent the development of a life-threatening situation for the animals. The
design and installation of the system must comply with local regulations and directives. In
Germany these include DIN VDE 0100, the animal protection and the keeping of working
animals ordinance and the pig-keeping ordinance etc. Also note the instructions of AEL, DLG,
VdS.
2.4 Requirements placed on the personnel / due diligence
Persons entrusted with the planning, installation, commissioning and maintenance and servicing in
connection with the frequency inverter must have the corresponding qualifications and skills for these
jobs.
In addition, they must be knowledgeable about the safety regulations, EU directives, rules for the
prevention of accidents and the corresponding national as well as regional and in-house regulations.
Personnel to be trained or instructed and apprentices are only permitted to work on the device under
the supervision of an experienced person. This also applies to personnel undergoing general training.
Comply with the legal minimum age.
This device is not intended to be used by people (including children) who have restricted mental,
sensory or intellectual abilities or who have a lack of experience and/or knowledge.
2.5 Start-up and during operation
Attention!
•During commissioning, unexpected and hazardous conditions can arise in the entire installation
due to defective adjustments, defective components or incorrect electrical connections. Remove all
persons and objects from the hazardous area.
•During operation, the device must be closed or installed in a control cabinet. Fuses may only be
replaced by new ones and must not be repaired or bypassed. The data for the maximum line fuse
are to be considered absolutely (
Technical data). Use only fuses specified in schematic dia-
grams.
•Any faults detected in the electric system/modules/operating equipment must be corrected immedi-
ately. If these faults are not corrected, the device/system is potentially very dangerous. The
device/system must therefore not be operated when it is faulty.
•Pay attention to smooth, low vibration running of the motor/fan, the appropriate instructions in the
drive documentation must be observed!
2.6 Working on device / Hazards through “residual voltage”
Information
Mounting, electrical connection, and start-up operation may only be carried out by an electrical
specialist in accordance with electrotechnical regulations (e.g. EN 50110 or EN 60204)!
Operating Instructions FRQS-E-6/10A Safety instructions
L-BAL-E246-GB 1512 Index 001 Part.-No. 00163443-42
5/17

Danger due to electric current
•It is generally forbidden to carry out work on electrical live parts. Protection class of the device
when open is IP00! It is possible to touch hazardous voltages directly.
•The safe isolation from the supply must be checked using a two-pole voltage detector.
•Even after disconnecting the mains voltage, life-threatening charges can appear between the
protective ground “PE” and the mains connection.
•The protective earth is conducting high discharge currents (dependent on the switching frequency,
current-source voltage and motor capacity). Earthing in compliance with EN specifications shall
therefore be observed even for testing and trial conditions (EN 50 178, Art. 5.2.11). Without
earthing, dangerous voltages can be present on the motor housing.
Waiting period at least 3 minutes!
Through use of capacitors, danger of death exists even after switching off the device through directly
touching the energized parts or due to parts that have become energized due to faults.
It is only permitted to remove the housing cover after waiting for 3 minutes once the line supply cable
has been shut down. Should measurement or adjustment work be unavoidable on the opened unit
while still powered, then this may only be performed by qualified personnel acquainted with the
thereby associated hazards.
Attention!
Automatically restart after a power failure or mains disconnection!
2.7 Modifications / interventions in the device
Attention!
For reasons of safety, no unauthorized interventions or modifications may be made on the device. All
planned modifications must be authorized by the manufacturer in writing.
Only use the manufacturer’s original spare parts / wearing parts / accessories. These parts are
specially designed for this device. If parts from other sources are used, there is no guarantee that they
are designed and produced for the proper loads and with the required level of safety.
Parts and special equipment not supplied by the manufacturer are not approved for use.
2.8 Operator’s obligation of diligence
•The contractor or owner must also ensure that the electric systems and equipment are operated
and maintained in accordance with electro-technical regulations.
•The owner is obliged to ensure that the device is operated in perfect working order only.
•The device may only be used as intended (
“Application”).
•You must periodically examine the safety equipment for their properly functioning condition.
•The assembly instructions and/or operating instructions are always readily available at the location
where the device is being used, are complete and are in legible condition.
•These persons are regularly instructed in all applicable questions regarding occupational safety
and environmental protection and are knowledgeable regarding the assembly instructions and/or
operating instructions and, especially, are familiar with the safety instructions contained therein.
•All safety and warning notices attached to the device are never removed and remain legible.
2.9 Employment of external personnel
Maintenance and service work are frequently carried out by external employees who often do not
recognize the specific situations and the thus resulting dangers.These persons must be comprehen-
sively informed about the hazards in their area of activity.
You must monitor their working methods in order to intervene in good time if necessary.
Operating Instructions FRQS-E-6/10A Safety instructions
L-BAL-E246-GB 1512 Index 001 Part.-No. 00163443-42
6/17

3 Product overview
3.1 Operational area
Frequency inverter designed for a stepless control of fans without additional (electromagnetic) motor
noise.
By using the integrated all-pole effective Sine filter (phase to phase and phase to ground), an absolute
parallel control of fans without risk of damage for motors is possible. Screened motor cables are not
required!
Only suitable for drives with low set-off torque (e.g.: fans or pumps).
3.2 Functional description
Frequency inverters of these series generate their 3 ~ output with variable voltage and frequency from
the 1 ~ AC mains network on the input.
The devices are constructed in accordance with the general requirement in EN 61800-2 for adjustable
speed electrical power systems and is intended for one-quadrantdrives.
The PFC (Power Factor Controller) makes the output voltage mostly independent of the mains
voltage.
The output frequency is set by an external signal (0 - 10 V).
3.3 Maintenance
The device must be checked for soiling and, if necessary, cleaned in periodic intervals.
3.4 Transport
•The device is packed ex factory to suit the transport method previously agreed.
•Always use the original packaging materials when transporting the device.
•Avoid shocks and impacts to the device during the transport.
•During manual handling the human lifting and carrying restrictions must be observed and adhered
to.
3.5 Storage
•The device must be stored in its original packaging in a dry and weather-proof room.
•Avoid exposure to extreme heat and cold.
•Avoid prolonged storage; we recommend a maximum of one year (consult the manufacturer before
starting if stored for longer).
3.6 Disposal / recycling
Disposal must be carried out professionally and environmentally friendly in accordance with the legal
stipulations.
4 Mounting
4.1 General notes
Attention!
The following points must be complied with during the mechanical installation to avoid causing a defect
in the device due to assembly errors or environmental influences:
•Before installation remove the device from the packing and check for any possible shipping
damage!
•Assemble the device on a clean and stable base. Do not distort during assembly! Use the
appropriate mounting devices for proper installation of the unit!
•A mounting on vibrating base is not permissible, if no data to the vibration strength is made (
Technical data)!
•When mounted onto lightweight walls, there must be no impermissibly high vibrations or shock
loads. Any banging shut of doors that are integrated into these lightweight walls, can result in
extremely high shock loads. Therefore, we advise you to decouple the devices from the wall.
•Do not allow drilling chips, screws and other foreign bodies to reach the device interior!
Operating Instructions FRQS-E-6/10A Product overview
L-BAL-E246-GB 1512 Index 001 Part.-No. 00163443-42
7/17

•Maintain the stated minimum clearances to ensure unobstructed cooling- air feed as well as
unobstructed outgoing air discharge (
minimum space requirement)!
•The device should be installed in a location where it will not be disturbed, but at the same time can
be easily accessed!
•Depending on the housing model cut off necessary cable inlets respectively to the cable diameter.
Or alternative use cable inlet for cable glands. Metal sheet housings are supplied with stoppers.
Any cable ducts openings not used must be sealed!
•Care must be taken to avoid direct radiation from the sun!
•The device is designed for vertical installation (cable inlet down). A horizontal or reclined installation
is only permissible after technical release of the manufacturer!
•Be sure to observe proper heat dissipation (
Technical data, heat dissipation).
4.2 Minimum space requirement
In order to ensure sufficient ventilation of the device, clearance on all sides of at least 50 mm has to
be maintained to the housing walls, switch cabinet doors, wiring ducts, etc. The same clearance
applies to the installation of several devices next to each other.
When installing several devices on top of each other, the danger of reciprocal heating exists. This
layout is only then permissible when the air suctioned from the upper unit does not become warmer
than the permissible ambient temperature ( Technical data). I.e., a correspondingly larger clearance
or thermal shielding is required.
4.3 Outdoor installation
Outdoor installation is possible up to -20 °C when the controller supply is not switched off. Installation
must be protected from the effects of weather as much as possible, including protection from direct
sunlight!
4.4 Installation location for agriculture
In order to avoid damage caused by ammoniac vapours, the controller shall not be installed in the
stable, but rather in an outhouse wherever possible.
4.5 Temperature influences during commissioning
Avoid condensation in the controller and functional faults attributable to condensation by storing the
controller at room temperature!
Operating Instructions FRQS-E-6/10A Mounting
L-BAL-E246-GB 1512 Index 001 Part.-No. 00163443-42
8/17

5 Electrical installation
5.1 Safety precautions
Danger due to electric current
•Work on electric components may only be carried out by trained electricians or by persons
instructed in electricity under the supervision of an electrician in accordance with electrical
engineering regulations.
•The 5 electrical safety rules must be observed!
•It is forbidden to carry out work on electrically live parts. Even after disconnection, the dc-link is still
live. Always wait at least 3 minutes.
•Other measures may be necessary to achieve safe electrical isolation.
•A second person must always be present when working on energized parts or lines who discon-
nects in case of emergency.
•Inspect electrical equipment periodically: retighten loose connections – immediately replace dam-
aged lines and cables.
•Always keep switch cabinets and all electrical supply facilities locked. Access is only allowed for
authorized persons using a key or special tool.
•Operating the device with the housing cover removed is prohibited because energized, exposed
parts are present inside the device. Disregarding this regulation can lead to severe personal injury.
•For metal cable inlets the necessary protective earth connection to the bottom of the housing is
made by screws. The device may only be started up when these screws are fitted properly.
•The device owner is responsible for the EMC of the entire plant according to the locally applicable
standards.
•Never clean electrical equipment with water or similar liquids.
Information
The respective connections are represented in the enclosure of this manual ( Connection diagram)!
5.2 EMC-compatible installation
5.2.1 Motor cable
The applicable standard for interference emissions is EN 61000-6-3. Compliance with this standard is
achieved through the use of an unscreened motor feed cable.
5.2.2 Control cables
Pay attention to sufficient distance from powerlines and motor wires to prevent interferences. The
control cable may not be longer than 30 m. Screened control cables must be used when the cable
length is longer than 20 m. When using a shielded cable connect the shielding to one side only, i.e.
only to the control unit with the protective ground (keep cable short and with as little inductance as
possible!).
5.3 Mains connection
5.3.1 Line voltage
Power from the mains is connected to terminals: PE, L1 and N. Here, it must be strictly observed that
the mains voltage lies within the allowable tolerance specifications (
Technical data and nameplate
affixed to the side).
A connection between two phase conductors is possible for 3 ~ 230 V supply networks.
Attention!
To activate the on current limitation, you must wait at least 90 seconds after switching off the line
voltage before switching back on!
5.3.2 Required quality attributes for the mains voltage
Danger due to electric current
The mains voltage must comply with the EN 50160 quality characteristics and the defined standard
voltages in IEC 60038!
Operating Instructions FRQS-E-6/10A Electrical installation
L-BAL-E246-GB 1512 Index 001 Part.-No. 00163443-42
9/17

5.3.3 Leakage current, securely attached, protective earth conductor
Danger due to electric current
The maximum leakage current depends on the type of device and the connected mains voltage
(
Technical Data). With regard to fixed connection and the type of PE conductor connection,
the specification for the leakage current must be observed under consideration of the locally
valid standards (for Europe EN 50178 Section 5.2.11 or 5.3.2.1 etc.).
Minimum cross-section for PE conductor for fixed connection 1.5 mm
2
!
5.4 Residual-current-operated protective device
Danger due to electric current
To ensure as high a degree of reliability as possible we recommend a release current of 300 mA,
where a residual current circuit breaker (type A) is used.
Residual current circuit breaker (type A)
Exception: All-current-sensitive fault current circuit breaker on the 3 ~ 230 V line
When connecting the device between two outer conductors, “all-current-sensitive” fault current circuit
breakers must be used (
EN 50 178, Art. 5.2).
5.5 Inverter output
5.5.1 Motor connection
The motor leads are connected to the terminals: U1, U2. Several fans can be connected to the
controller-the maximum total current of all motors must not exceed the current rating for the controller.
Change direction of rotation
wiring diagram fan!
Information
•It is recommended that a separate motor protection unit be foreseen for each fan.
•For motors with thermistors “TB” e.g. type S-ET10.
5.5.2 Disconnection between controller and motor (repair switch)
Ideally, a repair switch should be installed before the controller (supply line disconnect).
In the case of complete disconnection (entire load) after the controller, the enable (controller OFF /
ON) must be disconnected simultaneously. I.e., an additional control contact is needed. Switching on
the motor while simultaneously issuing the enable (ON) achieves secure energizing with low
saturation of the controller.
Attention!
When switching on the motor plus existing release: under certain circumstances, this can occur under
full modulation of the controller.
Operating Instructions FRQS-E-6/10A Electrical installation
L-BAL-E246-GB 1512 Index 001 Part.-No. 00163443-42
10/17

5.5.3 U/f-characteristic curve
Diagram setting signal and U/f curve (quadratic)
16.03.2015
v_u_f_frqs-e_0_10v.vsd
01 2 34 5 67 8 910
Analog In [V]
045 50
403530
25
2015
10
5
100 %
U
out
U
start
F
edge
= F
max
F
out
[Hz]
Fon
Foff
Analog In: Speed setting signal 0 - 10 V
Fout: Output frequency
Uout: Output voltage
Ustart: Start-up voltage
Foff: Shutdown Freq.
Fon: Switch on Freq.
Fedge: Edgefrequency
Fmax: Maximum frequency
5.6 Motor protection
The motor can be protected by connecting thermostats “TB”.
When multiple motors are connected, it is essential to ensure that thermostats “TB” are always
connected in series.
If a connected thermostat is tripped (break between the two terminals “TB”), the device is switched off
and is not switched back on.
Relais “K2” is de-energized, terminals “21” - “22” bridged. The signal lamp flashes in code
| 2 | (
Diagnostics / faults).
Possibilities for re-starting after the drive has cooled down (terminals “TB” bridged) by:
•By switching the mains voltage off and then on again.
•Via a digital input for remote control (ON / OFF enable).
Danger due to electric current
An outside voltage may never be connected to the terminals “TB”!
If a bypass circuit is installed, or in the “100 %” position on devices with a main switch, the motor
protection inside the controller has no function. In this case, additional motor monitoring may be
required.
5.7 Analog input “E1” for setting fan speed
The device has an analog input for setting the fan speed. Connection “E1” / “GND” (Analog In 1).
Danger due to electric current
•Make sure the signal has the correct polarity!
•Never apply line voltage to analog inputs!
Operating Instructions FRQS-E-6/10A Electrical installation
L-BAL-E246-GB 1512 Index 001 Part.-No. 00163443-42
11/17

5.8 Output 10 V (A2)
Constant voltage +10 V e.g. for external potentiometer. Connection to terminals “A2” - “GND”
“Analog Out 2” (I
max
6 mA).
It is not permissible to connect outputs of several devices to each other!
5.9 Enable, Device ON / OFF (Digital In 1 D1)
Electronic disconnection and Reset after motor fault via floating contact at terminals “D1” - “D1”
•Device “ON” for closed contact.
•Controller “OFF” with opened contact.
Activation via floating contacts, a low voltage of approx. 24 V DC is connected.
Danger due to electric current
•No disconnection (isolation) when turned off by remote, in accordance with VBG4 §6)!
•Never apply line voltage to the digital input!
5.10 Relay outputs (K2)
An operating message or activation of a damper control motor is possible via the potential-free
contacts of the relay “K2” (max. contact load
technical data and connection diagram).
At a modulation above 5 Hz the relay energizes, i.e. the terminals “21” and “24” are bridged.
At low modulation (below 3 Hz), switch off by the enable, switch off of line voltage or in case of a fault,
the relay de-energizes.
5.11 Bypass circuit
Please observe the following during bypass switching (controller shunt with mains voltage):
•Mutual locking of mains contactor and bypass protection.
•Time delay of at least 1 second during switching.
•When the contactor is switched off at the inverter output, the “enable” (ON / OFF) must also be
opened and closed again when it is switched back on. When switching off, wait at least 90 seconds
before switching back on!
•Never apply line voltage to the inverter output!
5.12 Potential at control voltage connections
The control voltage connections (< 50 V) relate to the joint GND potential (Exception: Relay contacts
are potential free). There is a potential separation between the control voltage connections and the
protective earth. It must be ensured that the maximum external voltage at the control voltage
connections cannot exceed 50 V (between “GND” terminals and “PE” protective earth). If necessary, a
connection to the protective earth potential can be established, install bridge between “GND” terminal
and the “PE” connection (terminal for screening).
6 Start-up
6.1 Prerequisites for commissioning
Attention!
1. You must mount and connect the device in accordance with the operating instructions.
2. Double check that all connections are correct.
3. The mains voltage must match the information on the rating plate.
4. The rated current on the rating plate will not be exceeded.
5. Make sure that no persons or objects are in the hazardous area.
Operating Instructions FRQS-E-6/10A Start-up
L-BAL-E246-GB 1512 Index 001 Part.-No. 00163443-42
12/17

7 Diagnostics / Faults
Operating conditions are indicated by the status LED with flashing code.
04.01.2012
v_flash_explain1_8.VSD
3 x
2 x
ON
OFF
5 x
1 x
7 x
8 x
Code Relay
K2 Explanation Reaction of Controller
Adjustment
OFF de-energized
terminals 21 - 22 bridged No line voltage
In the event of a mains interruption the
unit switches “OFF” and automatically
“ON” when the voltage has been re-
stored.
Check line voltage and pre-fusing.
ON
Energized at modulation
above 5 Hz (terminals 21 -
24 bridged).
De-energized at modula-
tion below 3 Hz (21 - 22
bridged).
Normal operation without fault
1de-energized, 21 - 22
bridged
No enable OFF
Terminals “D1” - “D1” (Digital In 1) not
bridged.
Switch off by external contact (
enable,
device ON / OFF).
2de-energized
terminals 21 - 22 bridged
Motor fault
Tripping of connected thermostat or
break between terminals “TB”.
The unit cuts out and does not switch on
again.
Check motor and connection then reset
(
Motor protection).
3
Energized at modulation
above 5 Hz (terminals 21 -
24 bridged).
De-energized at modula-
tion below 3 Hz (21 - 22
bridged).
Temperature management active
The device has an active temperature
management to protect it from damage
due to too high inside temperatures. In
case of a temperature rise above the
fixed limits, the modulation is reduced lin-
early. To prevent the complete system
being switched off externally (in this oper-
ation permissible for the controller) in
case of reduced operation due to too high
an internal temperature, no fault message
is sent via the relay.
With a drop in temperature the modula-
tion rises again llinear.
Check cooling of the controller
5de-energized
terminals 21 - 22 bridged
Overcurrent
The controller was switched off by the
current limitation.
Delay: 1.25 sec by continous overcurren-
t.Immediately switch of after 16th short (<
1.25s) overcurrent.
If for 60seconds no short fault the fault
counter goes back to 0 .Switch back time:
60 sec.
Controller turns the motor off. There is a
renewed attempt to start after about one
minute.
Check motor
Operating Instructions FRQS-E-6/10A Diagnostics / Faults
L-BAL-E246-GB 1512 Index 001 Part.-No. 00163443-42
13/17

Code Relay
K2 Explanation Reaction of Controller
Adjustment
7de-energized
terminals 21 - 22 bridged
Earth fault
Shortcut between one motor wire and PE
The unit cuts out and does not switch on
again.
Disconnect the device from mains.
Check motor wires
A permanent shortcut earth can dam-
age the device!
8-
Overvoltage
DC overvoltage because of shortcut earth
at switch-on.
The unit cuts out.
Disconnect the device from mains.
Check motor wires
8 Enclosure
8.1 Technical data
Type FRQS-E-6A FRQS-E-10A
Part-No. 37419
(308305-42)
37420
(308306-42)
Rated current output {1} 6 A 10 A
Rated current input {2} 6.3 A 10.8 A
Max. load limit integral of cut-in current {2} 0,7 1,3
Max. line fuse {3} 10 A 16 A
Max. leakage current according to the dened networks of
DIN EN 60990 (depending on connected line voltage *)
2.6 mA (U
typ
230 V)
3.5 mA (U
max
305 V)
3.0 mA (U
type
230 V)
4.0 mA (U
max
305 V)
Max. heat dissipation approx. {2} 103 W 187 W
Rated temperature 40 °C 50 °C
Weight 5.6 kg 6.6 kg
{1} Rated current output
current indication rating plate @ rated voltage, @ rated temperature (cos φ 0.8 at the output)
{2} At rated voltage (cos φ 0.8 at the output), values for different specifications on request.
{3} Max. supply side line fuse according to DIN EN 60204-1 classification VDE0113 chapter 1
Line voltage* 1 ~ 208...277 V (-10...+10 %), 50/60 Hz
Rated voltage 230 V
Maximal output voltage 1 ~ 230 V
The PFC (Power Factor Controller) makes it mostly independent of the mains
voltage
Maximal output frequency 50 Hz
Edgefrequency 50 Hz
U/f-characteristic curve square
Switching frequency 16 kHz
Rampup time 20 sec
Rampdown time 20 sec
Power factor > 0.9
Input resistance for speed setting signal for 0... 10 V input: R
i
> 100 kΩ
Heat dissipation in standby operation approx. 2.6 W
Output 10 V I
max
6 mA (short-circuit-proof)
Max. contact rating of the internal relay 2 A / 250 VAC
Max. permissible ambient temperature 55 °C
Min. permissible ambient temperature 0 °C (if mains voltage is not switched off up to -20 °C)
Max. permissible installation height 0...4000 m amsl
above 1000 m amsl the rated current is to be reduced by 5 % / 1000 m
Permissible rel. humidity 85 % no condensation
Operating Instructions FRQS-E-6/10A Enclosure
L-BAL-E246-GB 1512 Index 001 Part.-No. 00163443-42
14/17

Electromagnetic compatibility for the
standard voltage 230 / 400 V according
to DIN IEC 60038
Interference emission EN 61000-6-3 (domestic household applications)
Interference immunity EN 61000-6-2 (industrial applications)
Harmonics current Active power factor adjustment for sinusoidal input current (PFC Power Factor
controller), harmonic current in accordance with EN 61000-3-2 are guaranteed
Vibratory strength
(for vertical installation, i.e. cable inlet
down).
Broadband noise (simulated life-endurance test) in accordance with EN 61373,
category 1 class B.
Shock test according to EN 61373, category 1
Housing protection IP54
* Regarding the mains connection, these devices are to be classified as category “C2” devices according to the relevant
DIN EN 61800-3. The increased requirements placed on electrical interference > 2 kHz for category “C1” devices are
complied with in addition.
8.1.1 Max. load dependent on ambient temperature and line voltage.
The maximum permissible temperature for the rated current at rated voltage is specified as rated
temperature.
Since the dissipation of the power loss (heat development) in the device is decisively dependent on
the ambient temperature, the max. load must be reduced at an ambient temperature above the rated
temperature (
following table)!
The average value measured during a 24 h period must be 5 K under the max. ambient temperature.
For installation in a switch cabinet, the device’s dissipation and its possible affect on the ambient
temperature must be taken into consideration!
Type
Maximal motor current depending on ambient temperature
@ 40 °C
[A]
@ 45 °C
[A]
@ 50 °C
[A]
@ 55 °C
[A]
FRQ(5)-E-6A 6.0 5.5 4.5 4.0
FRQ(5)-E-10A 10.0 10.0 10.0 9.0
Operating Instructions FRQS-E-6/10A Enclosure
L-BAL-E246-GB 1512 Index 001 Part.-No. 00163443-42
15/17

8.2 Connection diagram
NNL1
NL1
PE
Netz
Line
1 ~ 208...277 V 50/60 Hz
L1 U1 U1 U2 U2
+
K2
E1
GND
Ausgang
Output
10 V
(Imax = 6 mA)
TB
TB
D1
D1
GND
A2
Digital
In 1
Eingang
Input
0...10 V
+
Analog
In 1
Analog
Out 2
01
Aus / Ein
Off / On
M
1 ~
U1 U2PE TB
q
1 ~ Motor
mit eingebauten Thermostatschaltern
with internal thermostats
2
TB
1
Kontaktbelastung
Contact rating
max. AC 250 V 2 A
6
3
4
5
UMPO09K12
17.03.2015
FRQS-E-6/10A
22
24
21
1 Line 1 ~ 208...277 V, 50/60 Hz
2 1 ~ Motor with internal thermostats
3 Enable off / on
4 Output 10 V (I
max
6 mA)
5 input: 0...10 V
6 Contact rating max. AC 250 V 2 A
8.3 Dimensions [mm]
Operating Instructions FRQS-E-6/10A Enclosure
L-BAL-E246-GB 1512 Index 001 Part.-No. 00163443-42
16/17

8.4 Manufacturer reference
Our products are manufactured in accordance with the relevant international regulations. If you have
any questions concerning the use of our products or plan special uses, please contact:
Systemair
Industrievägen 3
73930 Skinnskatteberg
Telefon:[phone]
Telefax:[phone]
[e-mail]
www.systemair.se
Operating Instructions FRQS-E-6/10A Enclosure
L-BAL-E246-GB 1512 Index 001 Part.-No. 00163443-42
17/17
