T-SoX So-exercise TX7 User manual

Thank you for choosing our product. Please read this Installation & Owner’s Manual
carefully before operation and retain it for future reference. If you lose this Manual, please
contact your local distributor or visit www.ehuntsun-tsox.com now to download and file
the electronic version.
Contact information
eHuntSun Health Technology Co., Ltd.
2F., No. 88, Shuren 6th St., Wufeng Dist., Taichung City 413015, Taiwan (R.O.C.)
TEL: [phone] Fax: [phone]
E-mail: [e-mail]
Indoor Bike Trainer
Model：So-exercise TX7
Before installation, please read the original manufacturer's manual carefully and follow the instructions
Manual Version: 2021/08

1
Specification：
Package Weight：G.W. 24.0 kg
Weight：N.W. 17.5 kg
Box Dims. (LWH)：700 × 280 × 600 (mm)
Product Dims. (LWH)：
622 × 604 × 554 (mm)
Drivetrain：PJ Belt
Resistance Type：Daul EMS
Accuracy：3%
Max User Weight/：110.0 kg
Flywheel Weight：4.0 kg
Max of Power Output：2200 watts
Power Adaptor：
input AC 100-240V, 50-60 Hz
output DC 24V, 4A
Country of Origin：Taiwan
Simulated Grade：
0-15%
Noise interference：
When the speed is 60 rpm, the noise does
not exceed 60 decibels (measured at 1
meter at the back of the car)
Rear Wheel Size：
Road：650c、700c、24",
MTB：650b、24"、26"、29"
Cassette(includes the flywheel)：
11-12-13-14-15-16-17-19-21-24-28T (11S)
Support for Ascension：
Frameset support, can be used with
purchased ascending frame accessories
Firmware Updates：
T-SOX App
Connectivity：BLE FTMS, ANT+/FE-C
Software compatible device：
iOS、Android、PC (Mac & Windows)
App support：
Kinomap、ZWIFT、FTMS compatible App
Remarks:
To apply the competition-interactive
App, it is recommended to purchase an
external cadence/speed device.

2
android ios
For detailed steps of spin down, please
refer to the official website
(www.ehuntsun-tsox.com).

3
(1)
(2) Stabilizer Pad kit
EAN-13: 4711404559044
(60-day warranty)
(3)
(4)
(5)
I ：Power adaptor with power cable and
US plug or EU plug
T-SOX
EAN-13:4711404559020
(2-year warranty)
Hardware kit
EAN-13: 4711404559037
(60-day warranty)
Power Adapter(US/EU)( 60-day warranty)
EAN-13: 4711404559051(US) or
EAN-13: 4711404559068(EU)
B：4 sets of stabilizer pad (soft pad/ pad
cover/ flat head hexagon socket screw/
hexagon nut/ flat washer)
C：M10 adjustment stabilizer pad
○
○
○
D：130/135 left-end cap
E：bicycle quick release rod
F：142/148 right-end cap
H：142/148 left-end cap
○
○
○
○

4
Precautions：
◎ Before beginning or modifying any exercise program please consult your physician and do not
ride if you have any discomfort.
◎ Do not put hands or objects near moving parts of the T-SOX to avoid improper involvement or
injury.
◎ The T-SOX is not recommended to be used outdoors, and keep the space around T-SOX at least
30 cm.
◎ The T-SOX may become hot to the touch when used for extended periods of time.
◎ Do not try to disassemble the bicycle while the flywheel is running.
◎ Keep children and pets away from the T-SOX while in use.
◎ Only use the T-SOX on a stable and saft surface, adjust the stabilizer pads correctly and stabilize
the machine.
◎ The user’s weight limit is less than 110KG. Use caution when standing while riding on the
T-SOX.
◎ Do not operate the T-SOX near water sources or operate in an excessively humid environment.
◎ Only use the power adapter that comes with the T-SOX.
◎ Make sure that the bicycle is properly fixed on the T-SOX before riding each time, and do not
shake it excessively during riding.
◎ eHuntSun warrants its main-unit T-SOX for a period of two years from the date of purchase, this
applies only for the original owner. Other consumables are regarded as consumables, and the
warranty is 60 days. The following dates are then calculated for the purchase
◎ Repairs during the warranty period are free of charge. However, the shipping costs for the T-SOX
shall be borne by the buyer himself for all shipping costs and possible customs duties.

5
Installation Notes:
STEP 1.
Place your T-SOX on a stable surface, and slightly pull up the knob A in the direction
of the arrow. Unfold the two legs in the direction of the arrows. Tighten the legs by
turning the knob A in the arrow direction.
○
○
STEP 2.
Using the stabilizer pad kit, place 4 sets of stabilizer pad B and 1 set of M10 adjust-
ment stabilizer pad C in the relative position of the main unit, and screw them up
into the front and rear legs and the frame.
○
○
STEP 3.
Assemble the 130 mm or 135 mm left-end cap. T-SOX comes pre-configured out of
the box for bicycles with 130/135 right-end cap. Press the 130/135 left-end cover D
into the axle hole of the frame, and then insert the bicycle quick release rod E into
the axle hole of the frame.
○
○

Description of LED Light description:
6
Note!
Failure to correctly install the machine in accordance with the instructions, or improper
quick disassembly and installation may cause property damage or personal injury. If
you are not sure whether the quick-release installation tightness is appropriate, please
consult your local dealer or contact our company for help. Do not ride the T-SOX until
the bicycle quick release rod or left-end cap is stuck.
STEP 4.
(If necessary) Replace the 142- or 148-mm cap set. Use a 5-mm hexagonal wrench
counterclockwise to remove the 130/135 right-end cap F. Use a 17-mm open-end wrench
to screw the 142/148 right-end cap G into the frame and lock it in a clockwise direction.
Press the 142/148 left-end cap H into the axle hole of the frame.
○
○
○
STEP 5.
Remove the rear wheel of the bicycle, install the T-SOX, and use the bicycle quick release
lever to properly lock it. Insert the DC connector of the power adaptor I into the corre-
sponding hole on the right cover and power on.
○
Setup:
(1) Place the T-SOX training platform on a stable ground, unscrew the left and right legs outwards and adjust the stabilizer pads to make the machine stable.
(2) Use the included AC to DC power adaptor to connect the T-SOX and the wall power outlet.
(3) Before each ride, please check whether the bicycle and T-SOX are stable after loading, and readjust the stabilizer pads if necessary.
(4) Download the T-SOX app for free from the Apple App Store or Android Google Play store to perform spin down and calibration.
(5) Spin down and calibration -Before using the T-SOX for the first time, perform calibration. In addition, the calibration is repeated through the T-SOX app
approximately every two weeks to ensure the most accurate power. For detailed steps of spin down, please refer to the official website (www.ehuntsun-tsox.com).
1. Light description:
1-1. BLE: blue light
1-2. ANT+: yellow light
1-3. Power: green light
2.BLE function description:
2-1. Connecting search: flashing
2-2. Connection established successfully: Constant light
3.ANT+ function description:
3-1. Connecting search: flashing
3-2. Connection established successfully: Constant light
4.PWR function description:
4-1. Connect the DC power cord: Constant light
