T3 Motion MotionTrak 330 4CH User manual

USER GUIDE
4CH
USER
GUIDE
VER 2.1.0
2
nd
Edition
zThank you for purchasing this Drive Recorder.
zBefore using the Drive Recorder, please ensure that you
read and understand this USER GUIDE.
zPlease store this USER GUIDE in an easily accessible location.
z
Before connecting and installing
this Drive Recorder
please
2
Edition
z
Before
connecting
and
installing
this
Drive
Recorder
,
please
refer to the appropriate instruction manual for proper operation.


FCC
INFORMATION TO THE USER
This equipment has been tested and found to comply with the limits for a Class
This
equipment
has
been
tested
and
found
to
comply
with
the
limits
for
a
Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and if not installed and operated in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception as determined by turning the equipment off and on the
television
reception
as
determined
by
turning
the
equipment
off
and
on
,
the
user is encouraged to try to correct the interference by one or more of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment to an outlet other than the one to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for assistance.
WARNING
Any changes or modifications not expressly approved by the
manufacturer could void the user’s authority to operate the equipment.
3

SAFETY ADVICE
CAUTION
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER.
NO USER
-
SERVICEABLE PARTS INSIDE
NO
USER
-
SERVICEABLE
PARTS
INSIDE
.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
Please make sure you follow the safety advice/instructions given in the user guide.
Caution
THERE IS A RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN
INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE
INSTRUCTIONS.
Caution
Damages due to production malfunction, loss of data or other damages occurring while
Caution
Install this product where it will not block the driver’s visibility and where an is
airbag installed. Improper installation could result in an accident or injury to the driver
or passengers in the event of an accident.
Battery for RTC (Real Time Clock) inside.
using this product shall not be the responsibility of the manufacturer. Although this
product is a device used for recording videos, in case of a malfunction this product may
not save all videos. In the event of an accident, the sensor may not recognize the shock
upon light impact and as a result may not begin recording automatically.
Caution
Upon light impact such as a minor bump in the road, the G-sensor may not
recognize the impact and as a result may not begin recording automatically.
Test and set the G
sensor level for the specific vehicle
WARNING:
TO PREVENT FIRE OR ELECTRIC SHOCK HAZARD, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR MOISTURE.
4
Test
and
set
the
G
-
sensor
level
for
the
specific
vehicle
.

GPS Reception
1. Activate this product in an area without large buildings
to im
p
rove GPS rece
p
tion.
pp
2. The temperature range for optimum operation of the GP
S receiver in a vehicle is -14 ~ 122°F (-14 10 ~ 50°C).
The commercial purpose GPS has the average rage error of more
than 15 meters and the range error could be more than 100 meters
due to environmental conditions like buildings, roadside trees etc.
3. When using this product for the first time or after a long
period (more than three days), it may take a little longer
to recognize your current location.
It may take between five and thirty minutes to get GPS reception.
GPS reception may be impaired under the following circumstances.
1) If there is an object at the end of the GPS antenna.
2) If the vehicle has metallic elements in the windshield.
3) If equipment generating electromagnetic waves that interfere with the GPS
signal is installed in the vehicle e.g.: Other GPS devices such as a certain
tfil titdl MP3CDl l
t
ype o
f
w
i
re
l
ess ac
ti
va
t
e
d
a
l
arms,
MP3
or
CD
p
l
ayers or camera a
l
arms
using GPS.
4) If using a receiver connected by a cable, electric interference can be
avoided by simply changing the location of the receiver (antenna).
5) On heavily overcast or cloudy days, if the vehicle is in a covered location
such as under a bridge or raised roadway, in a tunnel, an underground
roadway or
parking area inside a building or surrounded by high
-
rise
roadway
or
parking
area
,
inside
a
building
or
surrounded
by
high
-
rise
buildings.
6) If GPS signal reception is poor, it may take longer to locate the current
vehicle position when the vehicle is moving rather than when stationary.
5

CONTENTS
1. MotionTrak330 4CH unit
A set of the following items is included with each MotionTrak330 4CH order.
2. 4GB SD memory card
(The PC Viewer software is
in the provided SD card )
in
the
provided
SD
card
.
)
3. GPS Antenna module
4. Remote Controller
5. Audio/Video output cable
6. Power Cable
8. Wire Splice clip (5pcs)
7. Camera input cable
6
9. Sticker (double sided tape 1pc)
10. Velcro Sticker (1pc)

INTRODUCTION
FRONT
Audio/Video
Out
p
ut
REAR
SD Slot
SD Door
p
External MIC input
Camera3
Input
BUZZER
Internal Microphone Remote Control Input
GPS Input
Power Input
&
7
Camera1,2 Input
GPS
Input
&
Alarm (Car Signal)
Input
(Turn left, Turn right,
Brake, Speed pulse)
Rear View
Camera4 Input

INTODUCTION
REMOTE CONTROLLER
Record LED
BLUE LED
Overwrite LED
RED LED
SHUTTER BUTTON
RED
LED
PLAY BUTTON
PANIC BUTTON
Audio Video Output Cable
Audio out 1
8
Video out 1 Video out 2
[Note] The same screen will be shown through the Video out 1 & 2.

INTRODUCTION
Power & Vehicle Signal
Input
Red(+)
Black (Ground)
Yellow (Alarm 3)
FUSE
250V 3A
BLUE (Alarm 1)
White (Speed pulse)
Green
(
Alarm 2
)
()
9

FUNCTION (MAIN UNIT)
Automatic start
Make sure that peripherals including all cameras are properly connected.
Turn on the vehicle power the MotionTrak330 4CH automatically start
(Use
Turn
on
the
vehicle
power
,
the
MotionTrak330
4CH
automatically
start
.
(Use
the power cable provided.)
Event record
The Event recording will be started automatically by motion detection Alarm 1
Notice : The unit will not begin recording immediately after the power is
applied, it takes approximately 1 minute for the built-in power backup
system to charge. Thereafter, the internal flash memory will be ready to record.
The
Event
recording
will
be
started
automatically
by
motion
detection
,
Alarm
1
to 3 or by the G-sensor level.
The Panic recording can be started by pressing the [PANIC] button.
Normal record (Continuous record)
The Normal (continuous) recording will be automatically started after power on.
The MotionTrak330 4CH will not create a separate event file during the
continuous recording mode. It will mark the Event area as ‘Alarm 1~3’, G-sensor,
motion detection or [PANIC] button in the continuous recording file which can
motion
detection
or
[PANIC]
button
in
the
continuous
recording
file
,
which
can
be easily searched for during playback.
Dual record (Event & Normal record)
If different record modes are set for each camera, like camera1 set as Event
record and camera2 set as Normal record, then camera1 (Event record) will
work according to the record setting for example 10 frames per second
recording. However camera2 (Normal record) will record 1 frame per second, if
there is no event. If there is an Event, both cameras will record according to the
Live screen on Monitor
The MotionTrak330 4CH will display the live screen on the monitor.
The camera channel can be changed using the information OSD.
(Refer to page 13)
Playback in the car
record setting for example 10 frames per second recording.
10
Recorded files can be played back in the vehicle.
PC Viewer Software
This software is pre-loaded on the SD card [pcsw] folder.

SD Memory Card Format
Remove power from the unit, Press and hold the [PLAYBACK] & [PANIC]
FUNCTION (MAIN UNIT)
button. Then reconnect power to the unit.
Press and hold the [PLAYBACK] & [PANIC] for more than 2 seconds after
applying power. The SD card initialization will begin.
Once complete, all video & log files will be deleted and the configurations
will default to the factory settings.
Notice : PC Viewer software is pre-loaded on the SD card. Please ensure
you have installed the software to your PC before formatting this card.
Built-in power backup (Super Capacitor)
When power to the unit is interrupted, the MotionTrak330 4CH saves the last
file using an internal Super Capacitor.
BLUE LED (RECORD)
The Blue LED illuminates when power is applied and blinks during event
recording.
RED LED (Overwriting)
The Red LED is illuminated when overwriting.
Buzzer
A “Beep” sound will occur when event/panic recording begins (this feature can
be turned off in the setting menu on the PC Viewer software, if required).
Also this
“
Beep
”
sound signals any system error
Also
this
Beep
sound
signals
any
system
error
.
VIDEO LOSS (warning)
A “Beep” sound will occur continuously when video is lost.
Check the camera(s) and camera connection(s), turn off/on the unit to resolve.
Make sure all camera(s) are connected before turning on the unit.
The number of camera(s) can be set in the settings menu on the PC Viewer software
.
11

OPERATION
1. Make sure that the power cable is properly connected and turn on the
vehicle power.
2. The Blue LED & Red LED will illuminate and slowly blink simultaneously,
then the Blue LED will remain constantly on. The Blue LED light means the
MotionTrak330 4CH is now ready for the event recording and has started
the Normal recording (Continuous recording).
3. The normal recording (Continuous recording) will be automatically start if
set via the PC Viewer software.
4. The event recording will automatically begin when triggered by an event
such as motion detection, Alarm 1 to 3 or by the G-sensor and will be
signaled with one short “Beep” sound.
5. The panic recording can be started by pressing the [PANIC] button.
Removing the SD memory card
Turn off power to the unit and check the BLUE LED light. Once the BLUE
LED light is no longer illuminated, remove the SD memory card.
Inserting the SD memory card
System Error Buzzer
Turn off power to the unit and check the BLUE LED light. Once the BLUE
LED light is no longer illuminated, insert the SD memory card.
System
Error
Buzzer
Two “Beeps” will sound and the BLUE & RED LED lights will blink
simultaneously when there is a system error or the SD card is not inserted.
[Check the SD memory card when this occurs. To resolve the problem,
initialize or replace the SD card]
12

OPERATION
Press [PLAY] button then the INFORMATION OSD (the summary of setting)
INFORMATION OSD
Press
[PLAY]
button
then
the
INFORMATION
OSD
(the
summary
of
setting)
will show up on the monitor as below,
CAM1 CAM2 CAM3
Activated
RecordMode Normal Normal Event
√√√√√√
CAM4
Event
√√
System:NTSC
Quality:Super
Overwrite:ON
G‐SensorLevel:X:3,Y:3,Z:3
G‐SensorCalibration:
Firmware Version :2.0.1
Resolution:720X480
FPS:5
Audio:ON
√√
To change the live display channel, press [PANIC] button.
The INFORMATION OSD will automatically turn off after 30 seconds.
To turn off the live view, press [PLAY] button or [SHUTTER] button.
Firmware
Version
:
2.0.1
CurrentTime:14:50:0707JAN2012
LIVE VIEW
Turn on the MotionTrak330 4CH and press [PLAY] button to turn on the
INFORMATION OSD (the summary of setting). To change the live display
channel, press [PANIC] button to select the camera(s) and then press [PLAY] or
[SHUTTER] button to escape.
13
CAM 1 => CAM 2 => CAM 3 => CAM4 => 4 Cameras together

OPERATION
G-Sensor Calibration
G
-
Sensor Calibration is needed after installing the MotionTrak330 4CH
G
Sensor
Calibration
is
needed
after
installing
the
MotionTrak330
4CH
.
This calibration detects the installed direction of the MotionTrak330 4CH to
accurately record the journey direction.
Press and hold [PANIC] & [SHUTTER] button together and then power on
the unit, the G-Sensor Calibration screen will be displayed.
PressandholdthePanicandShutterbuttonssimultaneouslyfor
morethan2secforcalibration.pressanysinglebuttontoescape.
Parkthevehicleonaflatsurfacewithatleast50metersofspace
directlyaheadandpressPanicbuttononce.
Acceleratethevehicleinastraightforwarddirectionuntila
“Beep”soundoccurs.
Retry
A“Beep”soundindicatesthattheG‐Sensor
Calibrationhassuccessfullycompleted.
Pressanybuttonorwait30secondstoreboot.
G‐SensorCalibrationfailure,no“Beep”sound.
Parkvehicleonaflatsurfacewithatleast5meters
14
This G-Sensor calibration is only required the first time the MotionTrak330
4CH is used with the specific vehicle.
ofspacedirectlyaheadandpressPanicbuttononce
again

OPERATION
PANIC RECORD BY PANIC BUTTON
The panic recording by [PANIC] button is started by pressing the [PANIC]
The
panic
recording
by
[PANIC]
button
is
started
by
pressing
the
[PANIC]
button, one short “Beep” will sound. The Blue LED will blink during the panic
recording.
The MotionTrak330 4CH doesn’t make a separate panic file during the
continuous recording. It will mark the panic area by [PANIC] button in the
continuous recording file which can be easily searched for during playback.
SNAPSHOT RECORD BY SHUTTER BUTTON
Press [SHUTTER] button.
The MotionTrak330 4CH will take a snapshot of 1 image with 5 seconds audio,
one short “Beep” will sound.
15

OPERATION
PLAYBACK
Press and hold [PLAY] button for more than 2 seconds the latest recorded
Press
and
hold
[PLAY]
button
for
more
than
2
seconds
,
the
latest
recorded
file will playback on the screen.
[WARNING] Recording cannot be done during playback.
Explanation of PLAYBACK control button
Channel change: Press [PANIC] button.
Move to the previous file: Press and hold [SHUTTER] & [PLAY] button.
Move to the next file: Press and hold [PANIC] & [PLAY] button
Move
to
the
next
file:
Press
and
hold
[PANIC]
&
[PLAY]
button
.
PLAY/PAUSE: Press [PLAY] button.
SLOW PLAY: Press [PLAY] button more than 1seconds.
Return to record mode: Press and hold [SHUTTER] button more than 2seconds.
Playback logic at the main unit.
Panic data Event data Normal data Playback
----------------------------------------------------------------
(o)
(o)
(o)
Only Panic data playback
16
(o)
(o)
(o)
Only
Panic
data
playback
(o) (o) (x) Only Panic data playback
(o) (x) (x) Only Panic data playback
(x) (o) (o) Only Event data playback
(x) (o) (x) Event data playback
(x) (x) (o) Normal data playback

SOFTWARE USER GUIDE
MotionTrak330 4CH PC Viewer User Guide
[PC SYSTEM REQUIREMENT]
OS Windows 2000, Windows XP
Recommended PC specifications for PC Viewer software
Windows Vista, Windows 7
CPU Pentium4 2.6GHz or higher
RAM 512MB or higher
Interface SD Memory Card Reader
HDD
Free s
p
ace
Install 20MB or higher
Backu
p
2GB or hi
g
her
17
If the PC does not meet the minimum system requirement, the PC
Viewer may not function properly.
p
pg
Display 1,024 x 768 pixel/High Color(16bit) or higher

INSTALLING PROCEDURES
1 Connect the SD card to a PC (if the computer does not have SD card slot
PC Viewer software is loaded in the provided SD card.
1
.
Connect
the
SD
card
to
a
PC
(if
the
computer
does
not
have
SD
card
slot
use the USB SD card reader) and open the “My Computer”.
2. Right-click the “DRIVEREC4” drive and select [Open].
3. Double click [SETUP.EXE] in the [pcsw] folder.
4. Select the appropriate language and then follow the dialog box.
5. The “PCViewer” icon will be displayed on your desktop.
NOTE: To Un-install the “PC Viewer MotionTrak330 4CH”
Open the
“
Control Panel
”
Open
the
Control
Panel
.
Select [remove program] and remove [PC Viewer MotionTrak330 4CH].
18

Connect SD memory card
1. Connect SD memory card into the SD card reader.
2. Run “PC Viewer MotionTrak330 4CH”.
3. Select [File] and then click “Select Data Folder” or Click [OPEN] button.
[OPEN] button
4 Select SD memory card folder at the folder select window
4
.
Select
SD
memory
card
folder
at
the
folder
select
window
.
19

PC VIEWER SETTING
To set PC Viewer select [File] and then click” PC Viewer Setting”.
This setting is for the PC Viewer software itself.
To set the recorder, refer to page 27.
The ‘date’ formats and ‘speed’ unit will be set automatically according to the PC
Windows setting. However it can be changed with this PC viewer setting menu.
To see the better quality playback pictures on your PC, check [Deblocking] box.
20
Table of contents
Popular Measuring Instrument manuals by other brands

Primes
Primes MSM+ Original instructions

Rohde & Schwarz
Rohde & Schwarz HM8123 user manual

TE Connectivity
TE Connectivity Integra Ri3 Installation and operating instructions

Agilent Technologies
Agilent Technologies E4402BU installation guide

Michell Instruments
Michell Instruments OptiCal user manual

Kimo
Kimo Kigaz-150 user manual
