Tab e.module L5.1 User manual

TAB e.module L5.1
Li-ion Energy Storage System
OPERATION MANUAL

Contents
1. Symbol in label, manual and product 5
2. Safety Precautions 6
2.1 Before Connecting 6
2.2 In Using 7
3. Introduction 7
3.1 Features 7
3.2 Specication 8
3.3 Equipment interface instruction 10
4. Safe handling of lithium batteries guide 13
4.1 Schematic diagram of solution 13
4.2 Danger label 13
4.3 Tools 14
4.4 Safety Gear 14
5. Installation and operation 15
5.1 Package items 15
5.2 Installation location 16
5.3 Installation Direction 17
5.4 Grounding 18
5.5 Put into cabinet or rack 18
5.6 Suitable disconnection device 19
5.7 Power on 20
5.8 Power off 20
6. Trouble shooting 21
7. Emergency Situations 24
8. Remarks 25

This manual introduces L5.1 e.module from TAB. Please read this manual before using
and follow the instruction carefully during the installation process. Any confusion, please
contact TAB for advice and clarication.

1. Symbol in label, manual and product
Caution! Warning! Reminding. Safety related information.
Risk of battery system failure or life cycle reduces.
Do not reverse connection the positive and negative.
Do not place near open ame.
Do not place at the children and pet touchable area.
Warning electric shock.
Warning Fire.
Do not place near ammable material
Read the product and operation manual before operating the
battery system!
Grounding.
Recycle label.
The certicate label for EMC.
Label for Waste Electrical and Electronic Equipment (WEEE)
Directive (2012/19/EU).
The certicate label for Safety by SiQ
5

2. Safety Precautions
Reminding
1. It is important and necessary to read the user manual carefully before installing or
using battery. Failure to do so or to follow any of the instructions or warnings in this
document can result in electrical shock, serious injury, or death, or can damage bat-
tery, potentially rendering it inoperable.
2. If the battery is stored for long time, it is required to charge every six months, and the
SOC should be no less than 90%.
3. Battery needs to be recharged within 12 hours after fully discharged.
4. Do not install the product in outdoor environment, or an environment out of the oper-
ation temperature or humidity range listed in manual.
5. Do not expose cable outside.
6. Do not connect power terminal reversely.
7. All the battery terminals must be disconnected for maintenance.
8. Please contact the supplier within 24 hours if there is something abnormal.
9. Do not use cleaning solvents to clean battery.
10. Do not expose battery to ammable or harsh chemicals or vapors.
11. Do not paint any part of battery, include any internal or external components.
12. Do not connect battery with PV solar wiring directly.
13. Any foreign object is prohibited to insert into any part of battery.
14. The warranty claims are excluded for direct or indirect damage due to items above.
Warning
2.1 Before Connecting
1. After unpacking, please check product and packing list rst, if product is damaged or
lack of parts, please contact with the local retailer.
2. Before installation, be sure to cut off the grid power and make sure the battery is in
the turned-off mode.
3. Wiring must be correct, do not mistake the positive and negative cables, and ensure
no short circuit with the external device.
4. It is prohibited to connect the battery and AC power directly.
5. The embedded BMS in the battery is designed for 48VDC, please DO NOT connect
battery in series.
6. Battery must connect to ground and the resistance must be less than 0.1Ω
6

7. Please ensured the electrical parameters of battery system are compatible to related
equipment
8. Keep the battery away from water and re.
2.2 In Using
1. If the battery system needs to be moved or repaired, the power must be cut off and
the battery is completely shutdown.
2. It is prohibited to connect the battery with different type of battery.
3. It is prohibited to connect batteries with faulty or incompatible inverter.
4. It is prohibited to disassemble the battery (QC tab removed or damaged);
5. In case of re, dry powder re extinguisher or vast amount of water can be used.
6. Please do not open, repair or disassemble the battery except staffs from TAB or
authorized by TAB. We do not undertake any consequences or related responsibility
which because of violation of safety operation or violating of design, production and
equipment safety standards.
3. Introduction
L5.1 lithium iron phosphate battery is the new energy storage product developed and pro-
duced under TAB’s quality requirements, it can be used to support reliable high power for
various types of equipment and systems.
3.1 Features
1. Built-in soft-start function able to reduce current strike when inverter need to start
from battery.
2. Active protection on BMS level.
3. Automatic address setting when connect in parallel.
4. Enable 97% depth of discharge, available for the inverter which completely follow
TAB latest protocol to operate.
5. The module is non-toxic, non-pollution and environmentally friendly.
6. Cathode material is made from LiFePO4 with safety performance and long cycle life.
7. Battery management system (BMS) has protection functions including over-dis- char-
ge, over-charge, over-current and high/low temperature.
8. The system can automatically manage charge and discharge state and balance vol-
tage of each cell.
9. Flexible conguration, multiple battery modules can be in parallel for expanding capa-
7

city and power.
10. Adopted self-cooling mode rapidly reduced system entire noise.
11. The module has less self-discharge, up to 6 months without charging it on shelf, no
memory effect, excellent performance of shallow charge and discharge.
12. Small size and light weight, standard of 19-inch embedded designed module is
13. comfortable for installation and maintenance.
14. Compatible with the 48V e.module series battery of TAB.
3.2 Specication
8

Basic Parameters L5.1
Nominal Voltage (Vdc) 51.2
Nominal Capacity (Wh) 5120
Usable Capacity (Wh) 5000
Depth of discharge (%) 97
Dimension (mm) 459*482*160
Weight (Kg) 47.5
Discharge Voltage (Vdc) 44.8
Charge Voltage (Vdc) 58.4
Recommended Charge Current 50
Normal Charge/Discharge Current (A) 75*
Max. continuous Charge/Discharge Current (A) 100*
Peak Charge/Discharge Current (A) 140@15sec
Communication RS485, CAN
Conguration (max. in 1 battery group) 32pcs
Working Temperature 0°C ~55°C Charge
-20°C ~55°C Discharge
Shelf Temperature -20°C ~35°C
Short current/duration time <2000A/1ms
Cooling type Natural
IP rating of enclosure IP20
Humidity 5% ~ 95%(RH) No Condensation
Altitude(m) ≤3000
Certication IEC62619/CE/UN38.3
Design life 10+ Years (25°C /77°F)
Reference standards IEC62619, IEC63056, IEC61000-6-2,
IEC61000-6-3, UN38.3
*: The normal and max. continuous operation current is for a battery cell temperature within
10~35°C to consider, out of such temp. range will cause a derating on operation current.
9

3.3 Equipment interface instruction
L5.1 front panel
Start (SW)
Turn on: press the button for 1s to start the battery.
Turn off: press the button for 1s to turn off the battery.
RUN
Green LED ashing or lighting to show the battery running status.
Alarm (ALM)
Red LED ashing to show the battery has alarm; lighting to show the battery is under pro-
tection.
Warning: In case of a warning ALM LED starts blinking yellow.
Alarm: In case of an alarm ALM LED starts blinking red. The module disconnects itself from
the system, other modules in a string continue working.
Critical Alarm: In case of a critical error all leds start blinking. Color led starts blinking red.
The whole system stops operating for safety reasons.
SOC
LEDs to show the battery’s current capacity.
10

Dip Switch (ADD)
Dip1:
Dip2:
Dip3: Standalone mode, battery is working without connected inverter.
Dip4: CAN terminal resistance on BMS side. 1: NONE. 0: connected. After change, no re-
start required.
Contact
Pin1 Ground for DI/DO GND ISO
Pin2 VDD for DI/DO VDD ISO
Pin3 Not dened DO1
Pin4 Not dened DO2
Pin5 Not dened DI1
Pin6 Not dened DI2
Pin7
Low SOC Signal – Reay switches on when SOC drops below 15%.
Relay 1 COM
Pin8 Relay 1 NO
Pin9 Relay 1 NC
Pin10
Charge Enabled – Relay switches on when charging is enabled.
Relay 2 COM
Pin11 Relay 2 NO
Pin12 Relay 2 NC
CAN
500 Kbps. Recommended 120Ω. To inverter or upper battery.
Link Port 0, 1
For communication between multiple parallel batteries.
Denition of RJ45 Port Pin
COM Port
Pin1 Not used
Pin2 GND
Pin3 Not used
Pin4 CAN-H
Pin5 CAN-L
Pin6 Not used
Pin7 RS485_A
Pin8 RS485_B
11

Power Terminals
Power cable terminals: there are two pair of terminals with same
function, one connects to equipment, the other one paralleling to
other battery module for capacity expanding.
For power cables uses self-locked connectors. must keep
pressing this Lock Button while pulling out the power plug.
LED Status Indicators
Condition RUN ALR 1 2 345
Power off - - - - - - -
Power on - - Show Power on Animation
Idle/Normal - - Show SOC
Charge -Show SOC; highest LED ash
Discharge - Show SOC
Warning Show SOC
Alarm -Turned OFF
Critical Alarm -Blink with RED Blink with LEDs, 400ms period
Shutdown - - Show Shutdown Animation
12

BMS basic function
Protection and alarm Management and monitor
Charge/Discharge End Cells Balance
Charge Over Voltage Intelligent Charge Model
Discharge Under Voltage Charge/Discharge Current Limit
Charge/Discharge Over Current Capacity Retention Calculate
High/Low Temperature(cell/BMS) Administrator Monitor
Short Circuit Operation Record
Power Cable Reverse
Soft start of inverter
4. Safe handling of lithium batteries guide
4.1 Schematic diagram of solution
4.2 Danger label
13

4.3 Tools
The following tools are required to install the battery pack
Wire cutter Crimping Modular Plier Screwdriver
NOTE
Use properly insulated tools to prevent accidental electric shock or short circuits.
If insulated tools are not available, cover the entire exposed metal surfaces of the available
tools, except their tips, with electrical tape.
4.4 Safety Gear
It is recommended to wear the following safety gear when dealing with the battery pack.
Insulated gloves Safety goggles Safety shoes
14

5. Installation and operation
5.1 Package items
Unpacking and check:
1. For battery module package:
• Battery Module,
• 2 * 200mm 25mm2 power cables,
• 1 * 200mm RJ45 communication cable,
• 1 * 1000mm 6mm2 grounding cable.
2. For External cable kits:
NOTE
Power and communication cables connect to inverter belongs to an External Cable Kit,
NOT include in battery carton box. They are in another extra small cable box. If there is
anything missed, please contact dealer.
• 2 * 2000mm power cables (25mm2, peak current capacity 120A, constant
100A) and communication cable for each energy storage system.
• 1 * 2000mm RJ45 communication cable, specication as below:
15

SN of RJ45cable Mark Pin
– L5.1 RACK KIT CABLE
e.storage Battery-Inverter 1~8: pin to pin For connection to inverter
For the external cables, the length shall be less than 2 meters.
5.2 Installation location
Make sure that the installation location meets the following conditions:
1. The area is completely waterproof.
2. The oor is at and level.
3. There are no ammable or explosive materials.
4. The ambient temperature is within the range from 0°C to 50°C.
5. The temperature and humidity are maintained at a constant level.
6. There is minimal dust and dirt in the area.
7. The distance from heat source is more than 2 meters.
8. The distance from air outlet of inverter is more than 0.5 meters.
9. The installation areas shall avoid of direct sunlight.
10. There is no mandatory ventilation requirements for battery module, but please avo-
id of installation in conned area. The aeration shall avoid of high salinity, hu- midi-
ty or temperature.
Caution
If the ambient temperature is out of the operating range, the battery stops operating to pro-
tect itself. The optimal temperature range for the battery pack to operate is 10°C to 35°C.
Frequent exposure to harsh temperatures may deteriorate the performance and life of the
battery.
16

5.3 Installation Direction
NOT allowed:
Upside down Sidelong Sidelong
Recommended:
Note
A
Caution:
Do not stack
modules together
directly.
B
Caution:
Make sure there is
holder for more than
50kg weight at bot-
tom of each module.
Installed only rely on
two handles is NOT
allowed.
17

5.4 Grounding
Grounding cables shall be 6mm2 or higher yellow-green cables. After con- nection, the
resistance from battery grounding point to Ground con-
nection point of room or installed place shall smaller
than 0.1Ω.
1. based on metal directly touch between the mo-
dule’s surface and rack’s surface. If using painted rack,
the corresponding place shall remove the painting.
2. install a grounding cable to the grounding point of
the modules.
5.5 Put into cabinet or rack
Put battery modules into cabinet and connect the cables:
1. Put the battery into the cabinet.
2. Drive the 4 pcs screws.
3. Connect the cables between battery modules.
4. Connect the cables to inverter.
18

Caution
1. follow local electric safety and installation policy, a suitable disconnection device
between battery system and inverter could be required.
2. all the installation and operation must follow local electric standard.
5.6 Suitable disconnection device
It is recommended to have a disconnection device for protection between battery system
and inverter:
1. The rated voltage shall ≥60V DC. Do NOT use AC breaker.
2. The rated current shall match with system design:
shall consider:
• the maximum DC current on inverter side,
• the number of power cable: for instance, if only one pair of 25mm2 cable, the rated
current of breaker shall be 125A or smaller.
3. If using breaker, the type shall be type C (recommended) or type D.
The Icu required:
the maximum short circuit current for calculation of each module is 6500A.
For instance:
Icu of breaker
1~2 modules Must ≥15kA
3~8 modules Must ≥20kA
19

5.7 Power on
Double check all the power cable and communication cable between batteries and betwe-
en battery and inverter. Switch ON the disconnection device between battery and inverter if
available.
For L5.1:
1. The one with empty Link A is the Master Battery Module, others are slaves
(1 master battery congure with maximum 31 slave batteries):
2. Press the black SW button of master battery to power on, all the battery LED light
will be on one by one from the Master battery:
Note:
1. After the battery module powered on, the soft-start function takes 3sec to active.
After soft-starts battery ready to output high power.
2. During capacity expansion or replacement, when parallel different SOC/voltage of
module together, it is recommended to maintain the system in idle for ≥15mins or
till the SOC LEDs becomes similar (≤1dot difference) before normal operation.
5.8 Power off
1. Turn external power source off.
2. Press black SW switch of master battery. Then all batteries will off.
3. Switch OFF the disconnection device between battery system and inverter, if avail-
able, disconnect power cables.
20
