Tactix 326250 User manual

Operator’s Manual
#326250
68CM / 26-1/2” 2 DOOR TALL CABINET
Meridian International Co., Ltd.
1886 Laiyin Road, Songjiang, Shanghai, China
www.meridianintl.com
Distributed by:
left panel
right panel
top panel
bottom panel
back panel
left door
right door
shelf
foot
Components:
A
B
C
D
E
F
G
H
I
Hardware & Fittings:
AA M6 X 12 Hex socket bolt set
BB M6 x 16 square neck pan head bolt set
CC M4 x 8 self-tap screw
1
1
1
1
2
1
1
3
4
32
14
12
AG
B
I
C
F
H
D

A
G
B
I
C
F
H
D
E
E
1put two E & E together with 4 AA. 2put E to A & B with 4 AA each side. 3attach C to the assembly with 10 AA and 4 BB,
BB at front side.
4attach D to the assembly with 10 AA and 4 BB,
BB at front side.
5attach H to the assembly with 2 BB each. 6attach F & G to the assembly with 6 CC each. 7screw I to the bottom.
CC
AA
