Tadiran Telecom Coral Sentinel Pro User manual

Coral
Sentinel Pro
Installation Procedure
and Reference Manual
Version 6.78
Document Edition 3.2

© Copyright by TADIRAN TELECOM (TTL) L.P., 2007-2015.
All rights reserved worldwide.
The Coral is Protected by U.S. Patents 6,594,255; 6,598,098; 6,608,895; 6,615,404
All trademarks contained herein are the property of their respective holders.
The information contained in this document is proprietary and is subject to all relevant
copyright, patent and other laws protecting intellectual property, as well as any specific
agreement protecting TADIRAN TELECOM (TTL) L.P.'s (herein referred to as the
"Manufacturer") rights in the aforesaid information. Neither this document nor the information
contained herein may be published, reproduced or disclosed to third parties, in whole or in part,
without the express, prior, written permission of the Manufacturer. In addition, any use of this
document or the information contained herein for any purposes other than those for which it
was disclosed is strictly forbidden.
The Manufacturer reserves the right, without prior notice or liability, to make changes in
equipment design or specifications.
Information supplied by the Manufacturer is believed to be accurate and reliable. However, no
responsibility is assumed by the Manufacturer for the use thereof nor for the rights of third
parties which may be effected in any way by the use thereof.
Any representation(s) in this document concerning performance of the Manufacturer's
product(s) are for informational purposes only and are not warranties of future performance,
either express or implied. The Manufacturer's standard limited warranty, stated in its sales
contract or order confirmation form, is the only warranty offered by the Manufacturer in
relation thereto.
This document may contain flaws, omissions or typesetting errors; no warranty is granted nor
liability assumed in relation thereto unless specifically undertaken in the Manufacturer's sales
contract or order confirmation. Information contained herein is periodically updated and
changes will be incorporated into subsequent editions. If you have encountered an error, please
notify the Manufacturer. All specifications are subject to change without prior notice.

NOTE:
For security reasons, Coral Sentinel Pro Software Version 6.78
or higher no longer supports SIP endpoints. Only MGCP
endpoints are supported.
For SIP endpoints use a 3rd party SBC.
CAUTION!
Do not upgrade the Coral Sentinel Pro to Software Version 6.78
in systems where Sentinel Pro units serve SIP endpoints.

Record of Changes
Edition
No. Issue Date Brief Description
3.2 24-June-2015 • New Tadiran logo
3.1 13-Jan-2015 • SIP removed from screens
3.0 14-Dec-2014 • Sentinel Pro Software Version 6.78
• Added PUGW-2G and PUGW-2Gipx
• Caution !
For security reasons, Sentinel Pro Software Version 6.78 or
higher is no longer support SIP endpoints. Only MGCP end-
points are supported. For SIP endpoints use a 3rd party SBC.
• Upgrading
“Be aware that Coral Sentinel Pro Software Version 6.76 or
lower supported MGCP and SIP endpoints. From Coral Sen-
tinel Pro Software Version 6.78 or higher, only MGCP end-
points are supported.” on page 47.
2.4 22-Apr-2010 Coral version 6.58
2.3 1-Oct-2009 Changes made for Specification pages (SIP end point requires
Coral version 15.8 or higher)
2.2 16-Sept-2009 Version 6.5, Deleted Chained (linked) units option
2.1 23-Aug-2009 Version 6.5
2.0 18-June-2009 Version 6.5
1.0 11-June-2007 Version 6

i
Canadian DOT Compliance Statement
NOTICE: The Industry Canada label identifies certified equipment. This certification means that the
equipment meets telecommunications network protective, operational and safety requirements as
prescribed in the appropriate Terminal Equipment Technical Requirements document(s). The
Department does not guarantee the equipment will operate to the user's satisfaction.
Before installing this equipment, users should ensure that it is permissible to be connected to the
facilities of the local telecommunications company. The equipment must also be installed using an
acceptable method of connection. The customer should be aware that compliance with the above
conditions may not prevent degradation of service in some situations.
Repairs to certified equipment should be coordinated by a representative designated by the supplier. Any
repairs or alterations made by the user to this equipment, or equipment malfunctions, may give the
telecommunications company cause to request the user to disconnect the equipment.
Users should ensure for their own protection that the electrical ground connections of the power utility,
telephone lines and internal metallic water pipe system, if present, are connected together. This
precaution may be particularly important in rural areas.
Caution: Users should not attempt to make such connections themselves, but should contact the
appropriate electric inspection authority, or electrician, as appropriate.
NOTICE: The Ringer Equivalence Number (REN) assigned to each terminal device provides an
indication of the maximum number of terminals allowed to be connected to a telephone interface. The
termination on an interface may consist of any combination of devices subject only to the requirement
that the sum of the Ringer Equivalence Numbers of all the devices does not exceed 5.

ii
TUV Safety of Information Technology
Equipment Compliance
Equipment certified according to TUV has been tested and complies with the following:
UL 60950-1 :2007
CAN / CSA-C22.2 No.60950-1-07
TUV Rheinland of North America is a Nationally Recognized Testing Laboratory (NRTL) in the
United States and is accredited by the Standards Council of Canada to test and certify products to
Canadian National Standards. Clients can demonstrate compliance for both U.S. and Canadian markets
through a single mark (TUV) on their product(s) which denotes compliance to U.S. and Canadian
National Standards.
CB SCHEME Compliance Statement
Equipment certified according to the CB SCHEME has been tested and complies with the following:
IEC60950-1 (Ed. 2, 2005), AM. 1 (2009)
CE Compliance Statement (R & TTE)
Equipment certified according to CE has been tested and complies with the following:
EN 60950-1 :2006, 2nd Edition + A11 :2009, A1: 2010, and A12: 2011
EN 55022 CISPR 22
EN 55024 CISPR 24
Australia and New Zealand Compliance Statement
Equipment certified for Australia and New Zealand has been tested and complies with the following:
AS/NZS 4117
AS/NZS 60950.1-2011
ACA TS002 TS003 TS004
AS/NZS CISPR22

iii
Federal Communications Commission
Part 15
The FCC Wants you to Know
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
a) Reorient or relocate the receiving antenna.
b) Increase the separation between the equipment and the receiver.
c) Connect the equipment on an outlet on a circuit different from that to which the receiver is connected.
d) Consult with the dealer or an experienced radio/TV technician.
To ensure continued compliance with specified radio energy emissions limits of FCC Rules, the
following precautions must be observed while installing and operating the equipment:
1. Install the equipment in strict accordance with the manufacturer's instructions.
2. Verify that the power supply and associated A.C. powered equipment are connected to a
properly grounded electrical supply, and that power cords, if used, are unmodified.
3. Verify that the system grounding, including Master Ground, D.C. power system, and equip-
ment cabinets, is in accordance with the manufacturer's instructions and connected to an
approved earth ground source.
4. Always replace the factory-supplied cover or keep the cabinet doors closed when not ser-
vicing the equipment.
5. Make no modification to the equipment that would affect its compliance with the specified
limits of FCC Rules.
6. Maintain the equipment in a satisfactory state of repair.
7. Verify that emissions limiting devices, such as ferrite blocks and radio frequency interfer-
ence modules, are properly installed and functional.
8. If necessary the operator should consult their supplier, or an experienced radio/television
engineer for additional suggestions. The following booklet prepared by the Federal Com-
munications Commission (FCC) may be of assistance: “How to Identify and Resolve
Radio-TV Interference Problems.”
This booklet is available from the U.S. Government Printing Office, Washington, D.C. 20402,
Stock No. 004-000-00345-4.

iv
FCC Warning
Modifications not expressly approved by the manufacturer could void the user authority to operate the
equipment under FCC rules.
Waste of Electrical and Electronic Equipment
(WEEE)
Directive 2002/96/EC of the European Parliament
It is the responsibility of the Distributor to fully comply with Directive 2002/96/EC dated 27 January
2003 of the European Parliament and of the Council on Waste of Electrical and Electronic Equipment
(WEEE) and with any applicable law and regulation promulgated in its respective Member State in
connection with such Directive. Accordingly, the Distributor is responsible for, and shall bear all costs
related to, the collection, treatment, recovery, reporting and environmentally sound disposal of all
electronic waste related to the products. For the purpose of this paragraph, the term “Distributor” shall
mean the person and/or entity engaged in the importation, distribution, sales, support or any other
activity carried out in the applicable jurisdiction in connection with products supplied by
Tadiran Telecom (TTL) L.P.

Coral Sentinel Pro Installation Procedure and Reference Manual - for Coral IPx / FlexiCom i
TOC
Table of Contents
1 About this Manual
Document Description.................................................................................... 1
Intended Audience ......................................................................................... 2
Related Documentation.................................................................................. 3
Special Symbols Used in this Manual ............................................................ 4
Conventions Used in this Manual................................................................... 5
Terminology Used in this Manual................................................................... 6
2 About the Coral Sentinel Pro
Coral Sentinel Pro .......................................................................................... 7
The Need for Sentinel Pro.............................................................................. 8
Technical Description................................................................................... 10
Sentinel Pro Exterior Description ................................................................. 13
Internal View ................................................................................................ 17
3 Sentinel Pro Installation Overview
Prerequisites ................................................................................................ 19
Installation Procedure .................................................................................. 20
4 Hardware Installation
Unpacking the Sentinel Pro Unit .................................................................. 22
Mounting the Sentinel Pro Unit .................................................................... 23
Sentinel Pro Ground Wiring (for Rack-mounted Units) ................................ 25
Powering the Sentinel Pro............................................................................ 28
Connecting the Sentinel Pro to the LAN ...................................................... 28

ii Coral Sentinel Pro Installation Procedure and Reference Manual - for Coral IPx / FlexiCom
TOC
5 Coral Sentinel Pro Web Portal
Getting Started ............................................................................................. 29
Displaying the Sentinel Pro Status............................................................... 32
Configuring the Sentinel Pro (Setup)............................................................ 33
Displaying Version Details............................................................................ 38
Monitoring Sentinel Pro Endpoints ............................................................... 39
Resetting the Sentinel Pro ........................................................................... 41
Common Sentinel Pro Configuration Errors ................................................. 42
6 Coral IPx and FlexiCom Registration
Overview and Minimum Requirements ........................................................ 43
Parameters for Reference............................................................................ 43
7 Upgrading Sentinel Pro via TFTP
Downloading the latest version from the manufacturer’s website ................ 48
Upgrading Sentinel Pro using its Web Portal ............................................... 49
Upgrading Sentinel Pro via the Coral PI (Route: ADMIN,1) ......................... 51
8 Troubleshooting
Power Supply Failures ................................................................................. 53
Replacing the Fuse in a Sentinel Pro Unit.................................................... 54
Restoring the Sentinel Pro Configuration to its Factory Settings ................. 56
9 Specifications
Physical Specifications................................................................................. 57
Network Specifications................................................................................. 58
Sentinel Pro Performance Specifications ..................................................... 58
Version ......................................................................................................... 59

Sentinel Pro Installation Procedure and Reference Manual - for Coral IPx / FlexiCom About this Manual 1
Document Description
1
1About this Manual
This chapter describes the structure, conventions, and terminology used in this
manual. It also defines its target audience and lists related documentation.
................................................................................................................
Document Description
The Sentinel Pro Installation Procedure and Reference Manual is designed for field
use by personnel who install these units.
This manual offers detailed information about the Sentinel Pro, including
specifications, internal hardware, interface circuit operation, and installation
procedures. The following table provides a detailed outline of each chapter.
Where
it is What it is about When to use it
Chapter 1 About this Manual
(this chapter) To learn about this manual. This chapter specifies the target audience, gives a list of related
documentation, and explains the conventions and
professional terms used in the manual.
Chapter 2 About the Coral
Sentinel Pro
For general information about the Sentinel Pro.
This chapter also includes the technical and
physical features of the Sentinel Pro unit.
Chapter 3 Sentinel Pro
Installation Overview
Before starting the Coral Sentinel Pro installation
and configuration. This chapter provides a
general outline of the Coral Sentinel Pro
installation and configuration procedures.
Chapter 4 Hardware
Installation
For instructions on how to install the Coral
Sentinel Pro hardware unit.
Chapter 5 Coral Sentinel Pro
Web Portal
For a detailed description of the Coral
Sentinel Pro Web portal. This chapter describes
how to define and view parameters of a Coral
Sentinel Pro unit.

2About this Manual Sentinel Pro Installation Procedure and Reference Manual - for Coral IPx / FlexiCom
Intended Audience
1
................................................................................................................
Intended Audience
The instructions in this manual are written for technical personnel installing and
configuring the Coral Sentinel Pro. The personnel must be acquainted with the
structure of the company’s network, and have thorough knowledge of the Coral
systems.
Chapter 6 Coral IPx and
FlexiCom
Registration
For a general description of the Coral program
interface (PI) parameters that need to be
programmed for Sentinel Pro units in Coral
FlexiCom and Coral IPx systems.
Chapter 7 Upgrading
Sentinel Pro via
TFTP
For a description of how to update the Coral
Sentinel Pro via TFTP.
Chapter 8 Troubleshooting For a description of Sentinel Pro troubleshooting
and reparation procedures.
Chapter 9 Specifications For Coral Sentinel Pro specifications.
Where
it is What it is about When to use it

Sentinel Pro Installation Procedure and Reference Manual - for Coral IPx / FlexiCom About this Manual 3
Related Documentation
1
................................................................................................................
Related Documentation
For further information regarding Sentinel Pro and Coralsystems that is not covered
by this manual, consult the following documentation.
Item Subject Manual
Coral IPx/FlexiCom Database
programming Program Interface (PI) and Database Reference Manual,
Version 15 or higher
Coral systems and
Coral Sentinel General descriptions Coral IPx and FlexiCom Product Description
C/PUGW card Descriptions and
Installation Coral IPx Office Installation
Manual
PUGW-2G card,
PUGW-2Gipx card
PUGW card,
PUGWipx card
Descriptions Coral IPx and FlexiCom Product
Description
Installation Coral Service and Peripheral
Cards Installation Manual,
Chapter 10
MRC card Descriptions and
Installation Coral Service and Peripheral
Cards Installation Manual,
Chapter 8
VoIP devices,
UGW-E card,
UGW card
Descriptions Coral IPx and FlexiCom Product
Description
Installation Coral VoIP Installation Manual
Sentinel Terminal
(FlexSet Casing) General descriptions Coral IPx and FlexiCom Product
Description, Chapter 3
Installation Coral VoIP Installation Manual
Sentinel-I
Sentinel-II General descriptions Coral IPx and FlexiCom Product
Description, Chapter 3

4About this Manual Sentinel Pro Installation Procedure and Reference Manual - for Coral IPx / FlexiCom
Special Symbols Used in this Manual
1
................................................................................................................
Special Symbols Used in this Manual
It is important to understand the symbols and typographical conventions used in this
manual. These conventions and symbols indicate information that requires special
attention, as illustrated in the following examples:
Indicates important information demanding special attention.
Tip:
Advice that makes it easier to follow the steps of a procedure.
There is a risk of danger to life or personal injury.
There is a risk of causing the Sentinel Pro service to malfunction.
NOTES:
A page that is intentionally left blank, and may be used for note-taking.

Sentinel Pro Installation Procedure and Reference Manual - for Coral IPx / FlexiCom About this Manual 5
Conventions Used in this Manual
1
................................................................................................................
Conventions Used in this Manual
The following typographical conventions are used throughout this manual.
Table 1 Typographical
Conventions
Convention Use
Italics Names of windows, Web pages, and dialog boxes
Titles of related documentation
Parameter values entered in windows
Directory path denotations
Bold type Emphasized text
Names of buttons, icons, and menus
Names of fields, parameters, and options in windows
Text usually displayed in italics when it appears in warnings,
cautions, notes, and tips
ALL CAPS Keyboard names, combinations, and sequences, such as CTRL
and SHIFT+P
Blue font Clickable cross-reference links

6About this Manual Sentinel Pro Installation Procedure and Reference Manual - for Coral IPx / FlexiCom
Terminology Used in this Manual
1
................................................................................................................
Terminology Used in this Manual
Table 2 Terminology
Used in this Manual Private IP address An IP address assigned to a host within the company’s
network.
Public IP address A unique IP address assigned by the network
administrator, which is mapped to the Sentinel Pro's
internal IP address. A public IP address can be accessed
and used worldwide.
NAT
(Network Address
Translation)
Mapping a private IP address to a public IP address (and
vice versa) on a one-to-one basis.
NAT overload Dynamic NAT that maps multiple private addresses to a
single public address by using different ports.
DMZ (DeMilitarized
Zone) A computer or small network area that sits between a
trusted internal network, such as a corporate private
LAN, and an untrusted external network, such as the
public Internet. Typically, the DMZ contains devices
accessible to Internet traffic, such as Web (HTTP )
servers, FTP servers, and DNS servers.
The DMZ term comes from military use, meaning a buffer
area between two enemies.
Firewall A security system consisting of a combination of hardware
and software that limits the exposure of a computer or
computer network (or trusted internal network) to attack
from crackers; commonly used on local area networks
(LAN) that are connected to the internet (WAN).

Sentinel Pro Installation Procedure and Reference Manual - for Coral IPx / FlexiCom About the Coral Sentinel Pro 7
Coral Sentinel Pro
2
2About the Coral Sentinel Pro
This chapter provides a functional and technical description of the Sentinel Pro. It also
describes the different areas of the Sentinel Pro unit.
................................................................................................................
Coral Sentinel Pro
The Coral Sentinel Pro is a Session Border Control (SBC) unit that enables the
connection of remote IP phones located behind NAT (Network Address Translation)
servers or firewalls. Its main purpose is to transfer signalling and RTP traffic through
the firewall or NAT server to the relevant endpoints in the LAN network.
The Sentinel Pro provides the following features:
Enables incoming traffic to be routed through a firewall, without the need to
open up a permanent channel to transmit and receive calls
Enables MGCP endpoints that are remotely located behind a NAT server to
transverse the server
Establishes local RTP sessions between remote MGCP endpoints located
behind the same NAT server, thereby freeing up Sentinel RTP resources
Enables NAT traversal and firewall penetration for real-time fax-based sessions
utilizing the T.38 protocol
Enables NAT traversal and firewall penetration for IP phones and softphones
with different media types such as Audio (high quality1G.722) and
Video (H.263)
The Sentinel Pro can operate with UCx, Coral FlexiCom, Coral IPx, and Aeonix
Systems.
For SIP endpoints use a 3rd party SBC.

8About the Coral Sentinel Pro Sentinel Pro Installation Procedure and Reference Manual - for Coral IPx / FlexiCom
The Need for Sentinel Pro
2
................................................................................................................
The Need for Sentinel Pro
Indirect Connection Caused by Firewalls
Firewalls do not allow direct connection from the outside world to the internal LAN,
as signalling and media traffic must first travel through the firewall.
The Coral Sentinel Pro acts as a transmission point, enabling all signalling and media
traffic to be routed to and from the remote IP endpoints.
Unique IP Sockets Assigned by NAT Devices
NAT devices assign a unique IP socket to every RTP session upon call setup. Coral (or
any other call agent or registrar) is unable to set up a session without knowing which
port the NAT will assign.
To address this, the Sentinel Pro acts as a meeting point. The IP endpoints direct their
RTP streams towards the Sentinel Pro, which detects the source IP socket, adjusting
the destination of the RTP streams it transmits accordingly.
Dedicated Ports for VoIP Signaling
Coral (as any call agent or registrar) assigns specific ports for the handling of VoIP
signaling data, as follows:
MGCP: 2427 or 2727
The IP sockets of incoming sessions have to be adjusted to contain the relevant port
number.
The Sentinel Pro acts like multiple virtual IP endpoints that receive the calls, redefine
the incoming IP sockets, and route them to the Coral unit through the relevant
signaling port.

Sentinel Pro Installation Procedure and Reference Manual - for Coral IPx / FlexiCom About the Coral Sentinel Pro 9
The Need for Sentinel Pro
2
Figure 1 Sentinel Pro
MGCP Signaling Flow
Coral IPx/FlexiCom
Internet
T200M series
T200M series
FlexSet-IP 280S
FlexSet-IP 280S
IP :2427
1
IP :2427
IP :2427
IP :2427
2
3
4
Coral Sentinel Pro
Port 2427 or 2722Port 2427 or 2722
Port 2427

10 About the Coral Sentinel Pro Sentinel Pro Installation Procedure and Reference Manual - for Coral IPx / FlexiCom
Technical Description
2
................................................................................................................
Technical Description
The Sentinel Pro supports up to 240 MGCP endpoints, and concurrent voice, T.38 fax,
and video RTP sessions. The maximum number of RTP sessions the Sentinel Pro can
handle in parallel depends on its model:
Sentinel Pro 25 supports up to 25 concurrent audio RTP sessions.
Sentinel Pro 75 supports up to 75 concurrent audio RTP sessions.
Sentinel Pro 150 supports up to 150 concurrent audio RTP sessions.
Sentinel Pro endpoints may consist of any of the Tadiran’s IP phones such as
FlexSet-IP 280S, T200M Series.
Sentinel Pro Location in the Network
Depending on the network configuration, the Sentinel Pro unit may be located
anywhere in the DMZ (DeMilitarized Zone), on the LAN, or outside of the LAN. The
following figures are examples of the Sentinel Pro location in a network.
The purpose of the following configuration examples is to provide a general
idea of where the Sentinel Pro can be placed in a network. They should not
be used as a guideline for your network configuration.
The configuration in Figure 2 is recommended for networks with a three-legged
firewall supporting DMZ. The Sentinel Pro unit is placed between the router and the
firewall of the network.
