tae SN1401/LEO Installation instructions manual

SN1401L-e.docx PT Änd.-Nr. 0001 Stand 07.05.2014
SN1401/LEO
Instruction & Operation manual
Valid for art.-no: 20107-1401F
Caution:
As with any form of electrical equipment, there is always a risk involved in the handling of
electrical machinery. The greatest care must always be exercised during installation and
maintenance, and it is recommended this be carried out by authorized personnel.

SN1401
Misprints and technial changes reserved Instruction & Operation manual 2
SN1401L-e.docx PT Änd.-Nr. 0001 Stand 07.05.2014
NOTE
Before use the device, please read the operating instruction.
Improper installation and operation could cause personal injury.
Install and ground in accordance with national electric code to prevent electric shock.
Disconnect all power circuits before servicing.

SN1401
3Inbetriebnahme- und Einstellanleitung Misprints and technial changes reserved
SN1401L-e.docx PT Änd.-Nr. 0001 Stand 07.05.2014
1.0 Technical Data
Input voltage
24V DC
Power pack
±10V DC, max. 5mA
Dimensions
(W x H x D) 72mm x 144mm x 222mm
Ambient Temperature
0-40°C
Amplifier
2 inverting amplifiers with a max. possible amplification
of 0,01 to 1000.
2.0 Connections
Terminal
1
+24V DC input voltage
2
-24V DC input voltage
3
Input, inverter 1, max. 10V
4
Output, inverter 1, max. 12V
5
Input, inverter 2, max. 10V
6
Output, inverter 2, max. 12V
7
ground
8
ground
9
+12V
3.0 Function
The power supply SN8306(LEO) has a power pack inside with the outputs of ±10V and
2 inverter amplifiers.
The amplifiers 1 and 2 have the same characteristic.
Voltage amplification
Amplifier 1
V1=(R15 + P2) / (R16 + R7)
Amplifier 2
V2=(R19 + P4) / (R18 + R10)
Both amplifiers have a potentiometer for the offset.
The max. load of the amplifieres output is 3mA.

SN1401
Misprints and technial changes reserved Instruction & Operation manual 4
SN1401L-e.docx PT Änd.-Nr. 0001 Stand 07.05.2014
4.0 Dimensions
