Taffio Tun Series User manual

QUICKGUIDE
TAFFIO®
Mercedes TUN-SERIES

1
Connection for NTG 4.0

2
Connection for NTG 4.5 / 4.7

3
Sound & Canbus for NTG 4.0 / 4.5 / 4.7
If the vehicle has FIBRE OPTIC CABLE (2 orange cables in the picture),
remove it and plug it into the back of the original radio as shown below.
Connect the Canbus connector depending on the original NTG version
If you cannot see AUX or AMI as a source in the original menu, please
activate it as described on page 12 below

4
Connection for NTG 5 or Higher

5
Sound Settings for NTG 5
1.Select Sound switching method USB
2.Connect the 3.5mm AUX jack to the USB to AUX adapter and plug it into the
USB slot of your vehicle
3.Select USB as source in the original NTG menu to have sound

6
Backup Cam Connection & Setting
Depending on the type of gear, there are different connection types and
settings so that the camera switches over correctlyAutomatic transmission
(camera type, select RETROFITTING CAMERA) page 7 point 5
Manual transmission (camera type selection 360 ° CAMERA) page 7 point 5

7
General Settings
To get to the general settings menu, please tap Settings in the main menu
Tap System in the main settings menu
Here you now have the following options
1. Mirror rear view camera
2. Lock or unlock video while driving
3. Show / hide parking lines
4. Switch the parking assistant (if your car have the function) on / off
5. Select the rear view camera type> Original or retrofit
6. Set the display brightness
7. Activate / deactivate the muting of other sound sources when reversing

8
Tap on Navigation in the Settings main menu
Select the standard navigation app that you want to use here
By default it should be iGO Navigation
Tap Volume in the main settings menu
Here you can select and set the individual volume ranges
Tap Sound in the main settings menu

9
Here you can make the equalizer settings and set the bass, middle, treble or
select finished settings
Tap Language in the main settings menu
Here you can select the language you want
Tap on Time in the main settings menu
Here you can either take the time from the Android system or
From your vehicle. You can also set the time format here

10
Tap on System info in the main settings menu
Here you can see the device information and can also reset the system
Tap Android in the main settings menu to access the general
Android settings

11
Car & Extra Settings
In the main menu, tap Settings and scroll down to the end
Now tap on Factory and enter the code 2018 then on the green enter button
Here you can make some important settings such as Original screen
resolution
Tap on Function and scroll down to see other settings
> Bluetooth selection: Select the Android Bluetooth here

12
>AUX switching: Choose whether automatic or manual AUX switching
> Speedometer: Select the maximum km / h number that is in your
speedometer> Gear selection: Choose whether you have manual or automatic
gearshift> Navi button option: Select whether the factory Navi or Android Navi
should open when the Navi button is pressed
Voice key selection: Select which action should be carried out when pressing
the voice button
If you do not have an AUX source in the Mercedes menu, you can set an
arrow for AUX activation.

13
Some car cannot active Aux, need go to "engineer mode ", press 1+#+hang
up, three buttons together on panel for 8seconds
Engineering mode-- 7 HW Setting--7.7 HU Parameter--4.Audio AUX :ON; then
Engineer mode --9. System Reset
Tap on Auto Display to set your factory menu resolution select your vehicle
from 1 - 20

14
Tap on CAN protocol to select your NTG version
After changing a setting in the advanced menu, scroll down and tap on
Configuration import> Restart so that the changes are saved
