TaiDoc TD-5010 User manual

TaiDoc
TaiDoc
TaiDoc
TD-5010
LANCING DEVICE
and TWIST LANCET
FEATURES
•Twist-Release provides safer and easier operation for users.
•6-level depth selection. More noticeable clicks between each level.
•The lancet can be ejected anytime.
•Large contact area – provides steady and comfortable puncture.
•Better adjustable tip grip
•Large holding area on the cap
•Status display on the release button is more visible
•Less vibration less pain
Cap
Cocking Control
Release Button
Lancet Holder
Ejector
Arrow
Depth Indicator
Adjustable Tip
A Clear Cap
(For AST use only)
TaiDoc’s Lancing Device is designed with more comfortable grip,
different depth selections, and twist-release cap. It provides more
convenient, more comfortable, and easier operation for the users.
LANCING DEVICE
Model Number: TD-5010
Penetration Depth Setting: 6-level comfort dial
Penetration Range: 0.8 mm to 1.8 mm
Dimension: 118.7 (L) x 17.5 (D) mm
Weight: 16.5 g
Priming of Device:
Push button to prime with status display window
Lancet Ejection: Yes
Alternative Site Testing: Yes
TWIST LANCET
Model Number: TD-5084
Lancet Gauge: 30G
Weight: 0.4g
Dimension: 32.6mm x 6.4mm
Units per Carton: 100 pcs/box and 140 boxes/carton
Net Weight per Carton: 7.62 kg
Gross Weight per Carton: 8.62 kg
SPECIFICATIONS
ISTA 2A Compliance
ASTM E171, ASTM D4332,
ASTM D642, ASTM D999,
ASTM D5276
Quality Compliance
ISO 11137, ISO 11737,
ISO 10993-10:2002/Amd 1:2006,
ISO 10993-5:2009
Lancet

TaiDoc
TaiDoc
TaiDoc
INSTRUCTION FOR USE
1
Twist and pull o the cap of the
lancing device.
2
Insert a lancet into the lancet holder
and push down rmly until it is fully
secured.
3
Twist the protective disk o the
lancet.
4
Replace and twist the cap as shown in
the picture.
1
2
1
2
www.taidoc.com
B1-7F., No.127, Wugong 2nd Rd., Wugu Dist.,
New Taipei City 24888, Taiwan
Tel : [phone] Fax : [phone]
TaiDoc Technology Corp.
Copyright TaiDoc Technology Corporation. All rights reserved.
V2
9
Remove the lancet by pulling the cap
o rst. Safely dispose of the used
lancet by placing the protective disk
on a hard surface, and pushing the
exposed tip into the disk.
10
Slide the ejector forward to remove
the used lancet. Dispose of the lancet
according to your local regulations.
5
Select the depth of penetration by
turning the adjustable tip in either
direction so that the arrow on the cap
points to the desired depth.
6
Pull the cocking control back until it
clicks. You will see a color change
inside the release button when it is
ready.
7
Lancing the nger
Press the lancing device’s tip rmly
against the lower side of your
ngertip. Press the release button to
prick your nger, then a click
indicates that the puncture is
complete.
8
Remove the device from the puncture
site. After penetration, remove the rst
drop of blood with a clean cotton swab.
Gently squeeze the punctured area to
obtain another drop of blood. Be careful
NOT to smear the blood sample. Apply
the blood to the test strip.
Hold your ngers on the
body NOT the cap.
