Taisync ViULinx Lite User manual

ViULinx Lite
User Manual
www.taisync.com

Contents
1. Package Contents ......................................................................................1
2. Product Description...................................................................................2
2.1. Parameters......................................................................................2
2.2. Air Unit Interfaces .........................................................................3
2.3. Ground Unit Interfaces ..................................................................5
3. Installation.................................................................................................8
3.1. Air Unit Installation.......................................................................8
3.1.1. Antenna installation............................................................8
3.1.2. Power supply......................................................................9
3.1.3. Connection to camera.........................................................9
3.1.4. Connection to flight controller (RC & telemetry) ............10
3.2. Ground Unit Installation ..............................................................11
3.2.1. Antenna installation..........................................................11
3.2.2. Power supply....................................................................12
3.2.3. Telemetry connection.......................................................13
3.2.4. Connection to remote controller.......................................14
3.2.5. Setup video output............................................................15
3.2.6. Use ViULinx LiteSystem.................................................16
4. Software ..................................................................................................18
4.1. Installation....................................................................................18
4.2. Language Selection......................................................................20
4.3. Device Info...................................................................................21
4.4. Status............................................................................................21
4.5. Configuration...............................................................................22
4.5.1. Mode configuration..........................................................22
4.5.2. Telemetry configuration...................................................24
4.5.3. Remote control mode configuration.................................24
4.5.4. Ground unit identity configuration...................................24
4.6. Frequency Scan............................................................................25
4.7. Upgrade........................................................................................26
4.8. View Live Video..........................................................................27
4.8.1. On phone/tablet ................................................................27
4.8.2. On monitor........................................................................27
5. Applications.............................................................................................27
5.1. Applications of system in detail...................................................27
5.2. Applications of RC ......................................................................28
5.2.1. FRSKY remote controller.................................................28

5.2.2. Futaba remote controller...................................................29
5.3. Video output on USB (standard)..................................................29
5.4. Video output on USB (optional, USB To ETH)..........................30
6. Notes........................................................................................................33
6.1. Link performance.........................................................................33
6.2. How to select Frequency..............................................................35
6.3. Firmware update ..........................................................................37
6.4. Bind operation..............................................................................38
6.5. Telemetry & RC...........................................................................38
7. FAQ.........................................................................................................39

1
1. Package Contents
Air Unit & Ground Unit
Air unit antenna ×2
Ground unit antenna×2
Air Unit Cables
Power cable x1
This is used to connect the output
of a battery to the power input of
the air unit.
HDMI cable (Micro to Micro) ×1
This is used to connect the HDMI
output of camera to the HDMI
input of the air unit.
RC cable x1
This is used to connect the
PPM/S.bus port of flight controller
to the RC port of the air unit.
Serial cable (UART) x1
This is used to connect the
telemetry port of flight controller
to the serial port of the air unit.
USB cable(Micro to Type-A)×1

2
This is used to connect the USB
port of a PC or a cell phone, to the
Micro USB port of the ground
unit.
Ground Unit Cables
Power cable x1
This is used to connect the output
of a battery to the power input of
the air unit.
HDMI cable (Type C-Type A) ×1
This is used to connect the HDMI
output of ground unit to the
HDMI input of the monitor.
RC cable x1
This is used to connect the
training port of a remote
controller to the RC port of the
ground unit.
Serial cable (UART) x1
This is used to connect the
telemetry port of ground station
to the serial port of the ground
unit.
USB cable (Micro to Type-A)×1
This is used to connect the USB
port of a PC or a cell phone, to
the Micro USB port of the ground
unit.
2. Product Description
2.1.Parameters
Frequency
2.4GHz-2.483GHz
Band width
2.5MHz (uplink), 10MHz(downlink)
Power
27dBm (FCC), 20dBm (CE)
Video format
720p@30fps, 720p@60fps, 1080p@30fps,
1080p@60fps
Modulation
OFDM

3
Constellation
BPSK, QPSK, 16QAM
FEC
LDPC (1/2, 2/3, 3/4, 5/6)
Duplex
TDD
Downlink throughput
2.3Mbps ~ 12Mbps
Uplink throughput
115.2kbps
Encryption
AES 128, AES 256
Interface
HDMI, USB, Serial, PPM/S.BUS
Video compression
H.264/H.265
Glass to glass latency
<300ms (Camera dependent)
Dimension
122.7X52.3X25.1 (Ground unit)
77.8X47.3X23.5mm (Air unit)
Weight
97g(air unit)
Rated voltage/current
DC12V/1.2A (or 3S lithium battery)
Working temperature
-20°C ~55°C
2.2.Air Unit Interfaces
①Power Input Port
Connect a 12V power source to this port. The power source can be from a battery, or can
be from a power adaptor when the ground unit is upgraded on the ground. The power
supply recommended 3s battery.
②Serial Port (UART)
Connect this port to the telemetry port of a flight controller for telemetry communication
with the ground unit. UART singal: LVCMOS-3.3V.
③Remote Control Port (RC)
Connect this port to the PPM/S.bus port of a flight controller for remote control
communication with the ground unit. Pin V + can provide 5V power supply.
④Micro USB Port

4
Connect this port to the USB port ofa PC or Laptop, and use the Taisync PC program to
upgrade firmware on the air unit.
①HDMI Port
Connect the HDMI output of a camera to the HDMI input of the air unit.
①LED 1
When this LED is on, it means the air-to-ground link is connected; when this LED is off, it
means the air-to-ground link is disconnected. (Not available for air unit)
②LED 2
When this LED is on, it means the ground -to-air link is connected; when this LED is off,
it means the ground -to-air link is disconnected. (Not available for air unit)
③Bind Button
Press this button to perform the binding operation.
①RF2 Port
Connect the 2nd air unit antenna to this port.
②RF1 Port
Connect the 1st air unit antenna to this port.
②
①
①

5
①Fan Ventilation Outlet
Don’t block this fan ventilation outlet to ensure effective cooling.
2.3.Ground Unit Interfaces
①HDMI Port
Connect this mini HDMI output port to the HDMI input port of a displaydevice using the
supplied Mini HDMI to HDMI cable.
②Micro USB Port
Connect this port to the USB port of a PC or Laptop, and use the Taisync PC program to
upgrade firmware and set parameters on the air unit.
③USB Port
Connect this port to the Lightning port of an iPhone, or to the USB port of an android phone and
use ViULinxTM cell phone APP to watch live video play and set parameters of the air and
ground unit.Video output interface can be connected to mobile phones or tablets for video play.
QGC is also supported.
④Serial Port (UART)
Connect this port to the telemetryport ofa remote controller, or the serial port ofa ground
control station tosetup a telemetry link between the drone and the remote controllerorthe
ground control station. UART singal: LVCMOS-3.3V.
⑤Remote Control Port (RC)
①
①
②
③
④
⑤

6
Connect this port to the training PPM/S.bus port of a remote controller. Remote controller can
use ViUlinxTM uplink to communicate with the drone. Pin V + can provide 5V power
supply.
①Charging Port
Connect this port to the supplied power adaptor to charge the battery in the ground unit.
The power supply recommended 3s battery.
①RF2 Port
Connect the 2nd ground unit antenna to this port.
②RF1 Port
Connect the 1st ground unit antenna to this port.
①Bind Button
Press this button to perform the binding operation.
②Fan Ventilation Outlet
Don’t block this fan ventilation outlet to ensure effective cooling.
①
①
②
①
②

7
①LED 1
When this LED is on, it means the ground-to-air link is connected; when this LED is off, it
means the ground-to-air link is disconnected.
②LED 2
When this LED is on, it means the air-to-ground link is connected; when this LED is off, it
means the air-to-ground link is disconnected.
③Fan Ventilation Outlet
Don’t block this fan ventilation outlet to ensure effective cooling.
①
②
③

8
3. Installation
3.1.Air Unit Installation
3.1.1. Antenna installation
Insert the air unit antennas into the RF ports. Antenna clicks in when properly installed.

9
3.1.2. Power supply
Pin-out: - - + +. Insert the four-pin connector of supplied power cable to the power port
of the air unit and connect the orange power connect of supplied power cable to a battery
output, or the power supply port of a drone. Recommended voltage is 12V.
Note:
(1)To avoid equipment damage, install antennas before powering on the units.
(2)Recommended rated voltage/current is DC12V/1.2A (or 3S lithium battery).
3.1.3. Connection to camera
Connect the HDMI video output port to the HDMI video input port of the air unit.

10
3.1.4. Connection to flight controller (RC & telemetry)
Insert the six-pin connector of supplied serial cable to the serial port of the air unit and
connect the other end of the serial cable to the telemetry port of a flight controller.
Insert the supplied RC cable to the RC port of the air unit and connect the other end of the
RC cable to the PPM/S.BUS port of a flight controller.

11
3.2.Ground Unit Installation
3.2.1. Antenna installation
Screw the ground unit antennas onto the RF ports. Make sure the antennas are tightly
installed.
Note:
(1) To avoid equipment damage, install antennas before powering on the units.
(2) Ensure the antenna connector is vertical to the module when it is screwed onto the RF
port. Screw the antenna tightly to avoid loose connection, but do not overtighten the
antenna to avoid damaging the antenna.
(3) Both antennas need to be installed.
(4) Adjust the antenna to be vertical to the ground during operation.

12
3.2.2. Power supply
Insert the power connector of the power adaptor into the charging port of the ground unit and
insert into the aerial plug into an electrical outlet to fully charge the battery of ground unit.
Recommended voltage is 12V.
Note:
(1) Recommended rated voltage/current is DC12V/1.2A (or 3S lithium battery).
(2) To avoid equipment damage, install antennas before powering on the units.

13
3.2.3. Telemetry connection
Insert the six-pin connector of supplied serial cable to the serial port of the ground unit and
connect the other end of supplied serial cable to the telemetry port of the ground control
station.
Note:
(1) Ensure the baud rate of ground station and the baud rate of Taisync module are
configured correctly.
(2) Ensure the serial cable sequence matches the interface definition of Taisync module.

14
3.2.4. Connection to remote controller
Using PPM mode: Insert the training connector of the supplied RC cable to the training port
of a remote controller and connect the six-pin connector of the RC cable to the RC port of
the ground unit.
Using S.BUS mode: Insert the six-pin connector of the RC cable to the RC port of the
ground unit, the other end connect the S.BUS receiver, and the S.BUS receiver
communicates with the remote controller in wireless communication.
Note:
(1) Ensure the remote controller is in training mode, it is configured to the PPM or S.
BUS working mode.
(2) Ensure the RC cable sequence matches the interface definition of Taisync module.
(3) If the S.BUS receiver is used, the working frequency of the receiver and the Taisync
module should be guaranteed with a certain degree of isolation.

15
3.2.5. Setup video output
The ground unit outputs video to the monitor via HDMI cable, or you can connect the
ground unit to the mobile phone or tablet via USB cable, and opens Viulinx APP to watch
the video. QGC is also supported.
Video outputting can be supported on QGC or MP by using USB-Ethernet connector and
connecting PC or laptop through ethernet cable.
Note:
(1) If you use mobile phones or tablets to watch videos, please use Taisync's APP
Viulinx. QGC can also be supported.
(2) Using the USB-Ethernet connector, the corresponding ground station configuration is
needed.

16
3.2.6. Use ViULinx LiteSystem
1. Connect antennas to RF ports of the air unit.
2. Connect camera HDMI output to HDMI port of the air unit.
3. Connect the PPM/S.bus port of the flight controller to the RC port of the air unit.
4. Connect the flight controller telemetry port to the serial port of the air unit.
5. Turn on the camera and set the video format to 720p or 1080p.
6. Connect a 12V DC power to the power port of the air unit and turn on the power.
7. If latest firmware is desired, connect the air unit to a PC or a Laptop using USB cable
and run ViuLinxTMPC program to upgrade the firmware of the air unit to the latest
one.

17
1. Connect antennas to RF ports of the ground unit.
2. Adjust the remote controller to the training mode, if PPM mode is used, the remote
controller interface at the ground end is connected to the training port of the remote
control. If S.BUS mode is used, the cable connection between the S.BUS receiver
and the ground end need to be established, and the connection between the receiver
and the remote control need to be established.
3. Connect the USB port of ground control station to the serial port of the ground unit
with TTL-USB cable if you want to use ViuLinx’s telemetry link.
4. Connect cell phone or tablet to the USB port of the ground unit.
5. If video view on a monitor is desired, connect a monitor to the HMDI port of the
ground unit.
6. Turn on the ground unit.
7. If latest firmware is desired, connect the ground unit to a PC or a Laptop using USB
cable and run ViULinxTMPC program to upgrade the firmware of the air unit to the
latest one.
8. After downlink and uplink are connected, both LEDs will be on.
9. Run ViuLinxTM APP on your phone or tablet. QGC is also supported. You can
watch the video on phone or tablet with ViuLinxTM or QGC APP.
