Tait T02-00034-ABAA User manual

© Tait Limited November 2012
www.taitradio.com
402-00092-00
T02-00034-ABAA
Telemetry Cable/Horn Relay
Installation Instructions
Introduction
The T02-00034-ABAA cable can be used to
connect to the input and output lines of the
auxiliary connector of TM8000 and TM9000
mobile radios.
The cable also provides a line for ignition sense
and a relay driver for switching a 12V relay.
Notice The radio does not meet the IP54
protection standard once the bung covering the
radio’s auxiliary connector has been removed.
Notice The cable may not be suitable for use in high-temperature environments such
as the engine compartment.
Hardware Configuration for Ignition Sense
The radio hardware link LK2 (on the top-side of the radio’s main board) must be fitted for
ignition sense operation. The following table describes the configuration options.
LK2 is fitted by default.
Configuration of hardware links for ignition sense
Link required Voltages required for T02-00034-ABAA
LK2 in
(factory default)
Ignition signal ≤ 0.9V (or floating) = off
Ignition signal
≥ 5V = on
Ignition-sense compatible with 24V vehicular systems (34V max.)

2T02-00034-ABAA Telemetry Cable/Horn Relay
© Tait Limited November 2012
Relay and Relay Driver
The cable is supplied with a relay (rated 12V/30A,
with built-in suppression diode) and a relay socket
(including crimp terminals).
Although the product can drive any similar automotive
relay with a 12V coil that draws no more the 500mA in
operation, Tait recommends a type with a built-in suppres-
sion diode for EMC purposes but this is not required for
correct operation of the product.
The relay driver of the T02-00034-ABAA is controlled by AUX_GPIO4 which must be
programmed as an Active Low output. Refer to the Help of the radio programming
application for more information.
Interface Information
The relay outputs of the T02-00034-ABAA cable are protected by two SMD fuses located
on the circuit board inside the connector housing. For servicing information refer to the
radio’s service manual.
More Information
For more information on this product contact your radio provider.
T02-00034-ABAA interface information
Pin Signal Cable Color
8 +13V_SW (positive relay terminal) 3.3ft (1m) of red/black
twin pair cable
red
10 AUX_GPIO4 (via FET to negative relay terminal) black
4 AUX_GPI3 (ignition sense) 3.3ft (1m) single yellow cable yellow
12 AUX_GPI1 3.3ft (1m) of 6-core cable,
green cable not connected.
yellow
5 AUX_GPI2 (emergency) white
9AUX_GPIO6 red
1 AUX_GPIO7 blue
15 Ground black
–85 87 87a
+86 30
Relay terminal assignment:
