Tait TB7300 User manual

TB7300 Base Station
Installation and Operation Manual
MBD-00001-20 · Issue 20 · December 2022

2TB7300 Installation and Operation Manual
© Tait International Limited December 2022
Contact Information
Tait Communications
Corporate Head Office
Tait International Limited
P.O. Box 1645
Christchurch
New Zealand
Imported into the EU by:
Tait Communications GmbH
Stipcakgasse 40
1230 Vienna
Austria
Imported into the UK by:
Tait Europe Limited
Unit A, Buckingham Business Park, Anderson Road
Swavesey
Cambridge, CB24 4UQ
United Kingdom
For the address and telephone number of regional
offices, refer to our website:
www.taitcommunications.com
Copyright and Trademarks
All information contained in this manual is the
property of Tait International Limited. All rights
reserved. This manual may not, in whole or in part, be
copied, photocopied, reproduced, translated, stored, or
reduced to any electronic medium or machine-readable
form, without prior written permission from
Tait International Limited.
The words TAIT, TAITNET and the TAIT logo are
registered trademarks of Tait International Limited.
All trade names referenced are the service mark,
trademark or registered trademark of the
respective manufacturers.
By using a Tait product you are agreeing to be bound
by the terms of the Tait Software Licence
Agreement.Please read the Tait Software Licence
Agreement carefully before using this Tait product. If
you do not agree to the terms of the Tait Software
Licence Agreement, do not use the Tait Product. The
full agreement is available at
www.taitcommunications.com/our-resources/
legal#Tait_Software_Licence_Agreement.
Disclaimer
There are no warranties extended or granted by this
document. Tait International Limited accepts no
responsibility for damage arising from use of the
information contained in the document or of the
equipment and software it describes. It is the
responsibility of the user to ensure that use of such
information, equipment and software complies with the
laws, rules and regulations of the applicable
jurisdictions.
Enquiries and Comments
If you have any enquiries regarding this document, or
any comments, suggestions and notifications of errors,
please contact your regional Tait office.
Updates of Manual and Equipment
In the interests of improving the performance,
reliability or servicing of the equipment, Tait
International Limited reserves the right to update the
equipment or this document or both without
prior notice.
Intellectual Property Rights
This product may be protected by one or more patents
or designs of Tait International Limited together with
their international equivalents, pending patent or
design applications, and registered trade marks, for a
complete list please check
www.taitcommunications.com/our-resources/
legal#Intellectual_Property
Environmental Responsibilities
Tait International Limited is an
environmentally responsible company
which supports waste minimization,
material recovery and restrictions in
the use of hazardous materials.
The European Union’s Waste
Electrical and Electronic Equipment
(WEEE) Directive requires that this product be
disposed of separately from the general waste stream
when its service life is over. For more information
about how to dispose of your unwanted Tait product,
visit the Tait WEEE website at
www.taitcommunications.com/our-resources/
compliance#WEEE. Please be environmentally
responsible and dispose through the original supplier,
or contact Tait International Limited.
Tait will comply with environmental requirements in
other markets as they are introduced.

TB7300 Installation and Operation Manual 3
© Tait International Limited December 2022
Contents
Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Scope of Manual. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Document Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Associated Documentation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Publication Record . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1 Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1.1 Series 2 and Series 1 Reciters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1.1.1 Identifying a Series 2 Reciter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1.1.2 New Reciters and Repairs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
1.1.3 Firmware Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
1.2 Software Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
1.2.1 Base Station Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
1.3 Frequency Bands and Sub-bands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
1.4 Software Application Details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
1.4.1 P25/AS-IP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
1.4.2 P25 Gateway Key Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
1.4.3 DMR/MPT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
1.5 Licenses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
1.5.1 Compatibility. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
1.5.2 Feature licenses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
1.6 Theory of Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
1.6.1 Signal Paths . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
1.6.2 Online and Offline Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
1.6.3 Power Supply. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
1.6.4 Front Panel Fans . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
2 General Safety and Regulatory Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
2.1 Personal Safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
2.1.1 Explosive Environments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
2.1.2 High Temperatures. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
2.1.3 LED Safety (EN60825-1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
2.1.4 Proximity to RF Transmissions / A proximité des émissions RF . . . . . 26
2.2 Equipment Safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
2.2.1 Installation and Servicing Personnel . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
2.2.2 Preventing Damage to the PA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
2.2.3 ESD Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
2.3 Environmental Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
2.3.1 Operating Temperature Range. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
2.3.2 Humidity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
2.3.3 Dust and Dirt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

4TB7300 Installation and Operation Manual
© Tait International Limited December 2022
2.4 Regulatory Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
2.4.1 Distress Frequencies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
2.4.2 Compliance Standards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
2.4.3 Unauthorized Modifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
2.4.4 Health, Safety and Electromagnetic Compatibility in Europe. . . . . . . . 29
2.4.5 For Customers in Canada. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
2.5 Device and Network Security. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
3 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
3.1 Front Panel LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
3.2 Rear Panel LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
3.2.1 Ethernet Connector LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
4 Connecting to the Base Station . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
4.1 PC Recommendations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
4.2 Connecting Your PC to the Base Station . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
4.2.1 Logging In . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
4.2.2 Setting the IP Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
4.2.3 Security Certificates. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
4.2.4 Local Connection to a Base Station . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
4.2.5 Troubleshooting Connection Problems . . . . . . . . . . . . . . . . . . . . . . . . . 36
4.2.6 Finding a Lost or Forgotten IP Address. . . . . . . . . . . . . . . . . . . . . . . . . 37
4.2.7 Setting Up Authentication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
4.3 Working with the Web Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
4.3.1 Monitoring Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
4.3.2 Viewing Configuration Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
4.3.3 Viewing the Base Station and Network Identity . . . . . . . . . . . . . . . . . . 41
4.4 Basic Tasks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
4.4.1 User Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
4.4.2 Taking the Base Station Offline . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
4.4.3 Troubleshooting Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
4.4.4 Working with Configuration Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
4.4.5 Single or Channel Group Base Stations. . . . . . . . . . . . . . . . . . . . . . . . . 46
4.4.6 Marshaling or Transmit Delay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
4.4.7 Configuring Receive-Only Base Stations . . . . . . . . . . . . . . . . . . . . . . . 47
4.4.8 Setting Up Custom Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
4.4.9 Updating Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
4.4.10 Firmware Upload . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
4.4.11 Downloading Firmware from a Package Server . . . . . . . . . . . . . . . . . . 50
4.4.12 Activating New Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
4.4.13 Switching Application Packages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
4.4.14 Subaudible Signaling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
4.4.15 SNMP Network Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
5 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
5.1 Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
5.1.1 Equipment Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

TB7300 Installation and Operation Manual 5
© Tait International Limited December 2022
5.1.2 Grounding and Lightning Protection. . . . . . . . . . . . . . . . . . . . . . . . . . . 54
5.1.3 Equipment Ventilation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
5.1.4 Ambient Temperature Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
5.1.5 Cabinet and Rack Ventilation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
5.2 Unpacking the Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
5.3 Identifying the Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
5.4 Initial Setting Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
5.4.1 Confirming Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
5.4.2 Working with Configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
5.4.3 Customizing the Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
5.4.4 Restricted Port Numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
5.4.5 Changing the Root Password. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
5.4.6 Tuning the Receiver. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
5.5 Installing the Base Station on Site . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
5.5.1 Base Stations for Trunked Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
5.5.2 Equipment Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
5.6 Mounting the Base Station. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
5.6.1 Mounting and Support Kits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
5.7 Connecting the Base Station . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
5.7.1 Connection Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
5.7.2 Connecting DC Power (12V DC variant) . . . . . . . . . . . . . . . . . . . . . . . 70
5.7.3 Connecting AC Power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
5.7.4 Connecting RF. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
5.7.5 Connecting an External Frequency Reference . . . . . . . . . . . . . . . . . . . 73
5.7.6 Connecting a 1PPS Source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
5.7.7 Ethernet Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
5.7.8 Connecting General Purpose Inputs and Outputs . . . . . . . . . . . . . . . . . 75
5.7.9 Setting Up Simplex Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
6 Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
7 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Appendix A Interface Pin Allocations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
System Interface Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Ethernet Connector. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Serial Connector. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Appendix B Installing the Firmware Package . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Mongoose Installation Package . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Setting Up a Central Package Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Appendix C Testing with the TBA0STU Calibration Test Unit . . . . . . . . . . . . . . . . . . . . . . 83
CTU Connections and Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Available Tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

6TB7300 Installation and Operation Manual
© Tait International Limited December 2022
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
Simplified EU Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

TB7300 Installation and Operation Manual Preface 7
© Tait International Limited December 2022
Preface
Scope of Manual
This manual provides information on installing and operating the TB7300
base station. It is intended for use by experienced technicians familiar with
installing and operating base station equipment. It also includes
configuration, maintenance and troubleshooting information.
Document Conventions
The TB7300 base station has a web interface with an accordion menu on
the left side of the screen. “Configure > Base Station > Channels” means
click Configure in the top-level menu, then in the expanded Configure
menu click Base Station, and finally click on the Channels tab on that page.
Within this manual, four types of alerts may be given to the reader. The
following paragraphs illustrate each type of alert and its associated symbol.
Warning This alert is used when there is a hazardous situation
which, if not avoided, could result in death or serious injury.
Caution This alert is used when there is a hazardous situation which,
if not avoided, could result in minor or moderate injury.
Notice This alert is used to highlight information that is required to
ensure procedures are performed correctly. Incorrectly performed pro-
cedures could result in equipment damage or malfunction.
This icon is used to draw your attention to information that may
improve your understanding of the equipment or procedure.

8 Preface TB7300 Installation and Operation Manual
© Tait International Limited December 2022
Associated Documentation
The current set of TB7300 product documentation is available on the Tait
Partner Portal website (https://partnerinfo.taitcommunications.com).
■TB7300 Specifications Manual (MBD-00002-xx).
■TN9300 DMR Radio Network System Manual (MNB-00003-xx).
■Tait Core Networks Installation and Configuration Manual (MNB-
00012-xx).
■Safety and Compliance Information (MBA-00012-xx).
■TN9400 P25 Trunked Network Maintenance Manual (MNC-00001-xx)
■P25 and AS-IP Channel Group System Manual (MND-00002-xx)
Technical notes are also published from time to time to describe
applications for Tait products, to provide technical details not included in
manuals, and to offer solutions for any problems that arise.
Publication Record
Issue Publication Date Description
20 December 2022 Updated for release 3.40 and later
■K4 frequency band added
■Section 1.4.2 P25 Gateway Key Management added
■Section 5.7.2 Connecting DC Power (12V DC variant)
updated
■Section 5.7.8 Connecting General Purpose Inputs and
Outputs table updated
19 August 2022 Updated for release 3.35 and later
■Section 1 Description updated for P25 analog line
vocoder
■Section 1.1.3 Firmware Information updated
18 April 2022 Updated for release 3.30 and later
■Section 4.2.3 Security Certificates updated
■Appendix C Testing with the TBA0STU Calibration Test
Unit added
17 November 2021 Updated for release 3.25
■Section 1.1 Series 2 and Series 1 Reciters added
■Section 5.2 Unpacking the Equipment updated
■BNC goal post adaptor (part number 240-06913-00)
added to Section 5.7.5 Connecting an External
Frequency Reference and Section 5.7.6 Connecting a
1PPS Source
■Section 5.7.8 Connecting General Purpose Inputs and
Outputs table updated
■Section 5.7.9 Setting Up Simplex Operation updated

TB7300 Installation and Operation Manual Preface 9
© Tait International Limited December 2022
16 April 2021 Updated for release 3.20
■B1 frequency band added
■AC power variant added
■Section 2.4.5 For Customers in Canada added
■Section 3.2.1 Ethernet Connector LEDs updated
■Section 4.4.14 Subaudible Signaling updated
15 November 2020 General updates for release version 3.15.
■Minor updates throughout
■Added notice about base station being offline before
restoring
■Added TB Logic feature license
14 June 2020 General updates for Non-Patch Release version 3.10.
■Updating Firmware section features Reciter 2 content
■Tables added with Reciter 1 and 2 comparisons
■Activating Firmware section features Reciter 2 content
■Minor updates throughout
14* May 2020 General updates for Patch Release version 3.05.01.
■Added H-band electronic tuning
■Minor updates throughout
13 November 2019 General updates for release version 3.05.
■Minor updates throughout
■Wideband license added
12 July 2019 General updates for release version 3.00.
■Interoperability between P25/AS-IP and DMR/MPT
software applications
■Terminology
■List of channels
■Loading channels and setting up firmware
■Simplex operation
■SNMP management and MIBs
11 March 2019 General updates for release version 2.60.
■Updated licenses table to include MPT Trunked
■Updated network connection screenshots
■Included security risk information about Mongoose
■Updated default configuration parameters
■Mounting and Support Kits section added
■Equipment section updated to include CTU and cable
10 December 2018 General updates for release version 2.55.
■Updated root password information
■Added that external reference is required for Simulcast
■Web UI tab changed to Analog RF
■Working with Configurations section now matches the
TB9300 equivalent
Issue Publication Date Description

10 Description TB7300 Installation and Operation Manual
© Tait International Limited December 2022
1 Description
The Tait TB7300 base station is a robust state-of-the-art digital fixed
station that combines Tait’s proven strengths in reliability and high
performance with software-based configurability and operation, digital
signal processing and Voice over IP (VoIP) technology.
Its Ethernet interface provides built-in network connectivity that allows the
base station to join with other base stations to form a channel group. This
network supports voice-over-IP and remote management of all base
stations via a web browser.
1.1 Series 2 and Series 1 Reciters
Ongoing product improvements have meant that the processor in the reciter
control board has been upgraded with a SMARC (Smart Mobility
ARChitecture) module that provides faster start up times, as well as
capacity for future upgrades.
Due to this hardware change, series 2 reciters require version 3.10 or later
firmware, and cannot be downgraded to earlier firmware. Version 3.10
was released on 31 July 2020 and production was changed over to series 2
during August 2020.
Series 1 control boards are now out of production.
1.1.1 Identifying a Series 2 Reciter
Series 2 reciters can be identified by the label on the back of the reciter.
Together with the type code and serial number is this graphic indicating
that this is a series 2 reciter:

TB7300 Installation and Operation Manual Description 11
© Tait International Limited December 2022
The WebUI Monitor > Modules > Module Details tab also lists the series
number and hardware version of the reciter:
1.1.2 New Reciters and Repairs
Tait only provides new and replacement series 2 reciters. There is no
further production of series 1 reciters. Repairs needing a new control board
will also use a series 2 control board.
Using Series 2
Reciters in an
Existing Channel
Group
If you are adding a new or replacement reciter, Tait strongly recommend
that all the existing series 1 reciters be upgraded to version 3.10 or later, so
that all the reciters in the channel group have the same firmware version.
Failure to do so may lead to problems with channel group operation.
Reciter Repairs
Needing a
Replacement
Control Board
Series 1 reciter repairs needing a new control board will be returned as
series 2 reciters running version 3.10 or later firmware. Returned
equipment will include a notification sticker that this reciter is now series
2 and warns of possible channel group compatibility issues with reciters in
the network running older firmware.
1.1.3 Firmware Information
Series 2 reciters can only run on version 3.10 or later firmware1. There are
now separate firmware packages for series 1 and series 2 reciters as they
run different processors.
1. Later versions of series 2 reciters will require firmware versions later than 3.10.

12 Description TB7300 Installation and Operation Manual
© Tait International Limited December 2022
Upgrading from a PC using Mongoose as the local feed server from version
3.05 or earlier will display 2 versions for version 3.10 and later. The
version ending in ‘-02’ is series 2 reciter firmware:
Attempting to download -02 firmware to a series 1 reciter will fail, with a
status of ‘Error’ within a few seconds.
Upgrading from a PC using Mongoose as the local feed server with a reciter
running version 3.10 or later will select the correct firmware package for
the reciter automatically. The list of firmware presented in the lower
section is filtered by the P25/AS-IP, DMR/MPT or All radio buttons at the
top of the Tools > Firmware > Upload/Download tab WebUI page.
If you are using the direct firmware upload option, the series 1 firmware
file has the suffix .tbc and series 2 has the suffix .tbc02. File selection
has a filter for the correct file extension.
Uploading the incorrect firmware version for the series of reciter will fail
with the message ‘Information Failed Configuration’ in the Direct upload
section.

TB7300 Installation and Operation Manual Description 13
© Tait International Limited December 2022
1.2 Software Applications
The TB7300 operates in both P25/AS-IP and DMR/MPT networks. Within
these networks, the base station utilizes distinct P25/AS-IP and DMR/MPT
software applications.
1.2.1 Base Station Features
The following is a list of base station features for both P25/AS-IP and
DMR/MPT/MPT software applications:
P25/AS-IP ■Fully compliant with the P25 Common Air Interface. Can therefore
interoperate with any similarly compliant radios
■Supports P25 Phase 1 conventional operation with C4FM modulation
on the transmitter
■Supports simulcast operation with P25 phase 1
■Analog conventional repeater operation
■Analog conventional simulcast operation on an IP backbone requiring
no audio calibration or training
■Analog or digital console support in analog FM and digital P25 modes
■Integrated built-in voting facility. No external voter is needed.
DMR/MPT ■Fully compliant with the DMR Tier 2 conventional and Tier 3 trunked
standards. Can therefore interoperate with any similarly compliant
radios.
■Analog conventional repeater operation
■Operation as control channel or traffic channel transceiver in MPT/
MPT-IP networks, including standalone operation
■Digital simulcast operation
DMR firmware does not support simplex operation.
Non-Application
Specific
■Can be completely managed remotely from a PC running a web
browser: configuration, alarm monitoring, fault diagnosis, syslog,
feature and firmware upgrades. Alarms can also be reported via SNMP
traps, allowing integration with an SNMP-based network management
system.
■Rugged construction with generous heatsinks and fan-forced cooling
for continuous operation from –30°C to +60°C (–22°F to +140°F)
■Supports an analog 600 Ohm connected repeater in an analog
conventional network with CTCSS or DCS subaudible signaling1
1. CTCSS - Continuous Tone Coded Squelch System - commonly referred to as PL, an
acronym for Private Line
DCS - Digital Code Squelch - commonly referred to as Digital Private Line

14 Description TB7300 Installation and Operation Manual
© Tait International Limited December 2022
1.3 Frequency Bands and Sub-bands
Much of the circuitry in the base station is common to all frequency bands,
and is therefore covered by a single description in this manual. In some
cases the descriptions refer to specific bands or sub-bands, and these are
identified with the letters listed in the following table.
Frequency
Identification Frequency Band and Sub-band 35W 40W 50W
B band B1 = 136MHz to 174MHz
B3 = 148MHz to 174MHz
✗
✗
✗
✗
✓
✓
H band H3 = 470MHz to 520MHz
H5 = 400MHz to 470MHza
a. The 406 to 406.1 MHz frequency range is reserved worldwide for use by distress
beacons. It is not legal to program transmitters to operate in this frequency range.
✗
✗
✓
✓
✗
✗
K bandb
b. In Brazil, for K band, the TB7300 is considered to be configured as a base
station with retransmission of receive frequencies.
K4 = 762MHz to 870MHzc
c. The actual frequency coverage in this band is:
Transmit: 762MHz to 776MHz, and 850MHz to 870MHz
Receive: 792MHz to 824MHz
✓✗ ✗

TB7300 Installation and Operation Manual Description 15
© Tait International Limited December 2022
1.4 Software Application Details
1.4.1 P25/AS-IP
With the P25/AS-IP software application, the TB7300 is interoperable with
TB9400 base stations, and therefore operates in P25 conventional networks
and analog conventional networks. It operates as a stand-alone repeater/
base station, or as part of a channel group, providing receiver voting and
simulcast transmission. All air interfaces and system types support
simulcast operation.
In a P25 conventional network, the TB7300 operates as a single or wide
area conventional repeater, with receiver voting and optional simulcast.
Dispatch connection is via three distinct interfaces:
■P25 standard DFSI connection (up to three connections simultaneously)
■Analog line
■Tait P25 Console Gateway, supporting conversion between P25 and
analog consoles with MDC1200 signaling
In an analog conventional network, the base station can operate as a
repeater with CTCSS or DCS subaudible signaling.
The base station can also operate as part of an analog conventional
simulcast network and is fully IP-connected. The base station also features
an internally integrated voter, and therefore requires no external voter.
For more information on these applications, refer to the Help and
appropriate Tait System Manual.
1.4.2 P25 Gateway Key Management
The base station has a P25 gateway function which allows an analog
console to be part of a P25 talkgroup. The gateway performs P25 vocoding
and encryption as part of the conversion between the balanced analog line
console connection and the P25 air interface. The functions supported are:
■A call profile on the WebUI defines the conversion details. The
gateway has one single call profile in this release.
■The technician defines the call type (analog or P25), the talkgroup
address, network access code (NAC), clear or encrypted operation as
part of the profile
■The gateway supports a single P25 talkgroup, with or without
encryption
■The gateway does not support individual calling, although the gateway
can send uplink individual call audio to the console (if it is clear audio
or if it has the decryption key)
■The gateway supports both AES-256 and single-DES encryption

16 Description TB7300 Installation and Operation Manual
© Tait International Limited December 2022
■Encryption and decryption are performed in the hardware. You need
reciter hardware version 6.01 to use encryption.
■The Tait Key Fill Device (KFD) can create and export keystore files.
The technician can upload a keystore file containing the encryption key
for encrypted operation. The KFD users guide (MNE-00010-xx) has
more detail.
■The gateway can store an active key and an inactive key to allow for key
change-over
For a complete introduction to key management refer to the KMF Key
Management Manual (MBA-00048-xx).
The base station WebUI help also provides more detailed information.
1.4.3 DMR/MPT
The TB7300 is designed for operation in a Tait TN9300 DMR conventional
radio network, a Tait TN9300 DMR trunked radio network, an MPT
network, or as an analog conventional repeater.
In a DMR conventional network, the TB7300 can operate as a stand-alone
repeater, or as a member of a multi-site system (under the supervision of a
DMR conventional channel controller). Since DMR provides two logical
channels (timeslots) simultaneously for each radio frequency (physical
channel), two users can alternately access the same frequency, one in each
timeslot. Base stations on different sites can be linked together to form
channel groups. A base station can support two channel groups, one in each
timeslot.
In a DMR/MPT trunked network the TB7300 can operate as a control
channel or as a traffic channel. With two logical channels for each radio
frequency, a single TB7300 base station can provide two traffic channels,
two control channels, or both a traffic channel and a control channel.
In an MPT network, the TB7300 operates as a control channel or as a traffic
channel. The TB7300 operates with a trunking node, or in fallback
operation it can operate in either trunked or conventional mode.
In analog operation it can operate as a conventional repeater with CTCSS
subaudible signaling and DCS subaudible signaling.
For more information, refer to the DMR/MPT/MPT-IP System Manuals.

TB7300 Installation and Operation Manual Description 17
© Tait International Limited December 2022
1.5 Licenses
Some operational functions of the base station are controlled by licenses.
These functions will not work unless you purchase the appropriate feature
license and enable the feature set controlled by that license.
Regardless of which software application you have configured on the
TB7300, you can add and remove both P25/AS-IP and DMR/MPT
licenses.
Note that only licenses associated with your currently configured appli-
cation will be enabled.
For more detailed information, please see the base station help.
1.5.1 Compatibility
The compatibility rules for P25/AS-IP and DMR/MPT are defined in the
following tables:
The base stations in a Tait DMR trunked network are controlled by a
node (DMR trunking node controller). Tait sells three types of node:
Full, Express20 and Express6. Each type of node has different capabil-
ities. Refer to TN-2134 for more information
TN9400 - Site Controller
Access Express6 Full System
Base Station
P25 Access Trunking ✓✗✗
P25 Express6 Trunking
Operation
✓✓ ✗
P25 Trunking Operation ✓✓✓
DMR/MPT - Node Controller
Full Express20 Express6 Standalone
Access
Base Station
Full ✓✓✓✓
Express20 ✗✓✓✓
Express6 ✗✗
✓✓
Access ✗✗✗✓

18 Description TB7300 Installation and Operation Manual
© Tait International Limited December 2022
1.5.2 Feature licenses
The following section lists each of the available feature licenses for both
P25/AS-IP and DMR/MPT.
P25/AS-IP Feature licenses
Feature license Description
Analog Air Interface
(TBAS041)
A base station with this license can operate as a repeater in an analog
conventional network
P25 Common Air Interface
(TBAS050)
Allows a base station to transmit and receive P25 Phase 1 C4FM digital
voice transmissions
P25 DFSI
(TBAS060)
Allows the base station to integrate with dispatch consoles supporting DFSI
(Digital Fixed Station Interface)
P25 AS-IP Central Voter
(TBAS061)
P25 and analog. This feature allows a base station to act as a central voter.
P25 AS-IP Simulcast
(TBAS062)
This feature is required in base stations that have transmitters and belong
to a P25 Phase 1 simulcast or analog simulcast networka. It is also required
in the central voter of a simulcast channel.
P25 AS-IP IP Networking
Satellite
(TBAS071)
All system types and all air interface types. This feature allows a base
station to be part of a channel group without requiring the Central Voter
(TBAS061) license.
TB Logic programming
(TBAS073)
Allows for TB Logic programming
20/25 kHz Unrestricted
Wideband
(TBAS083)
Allows a base station to be configured to operate in wideband mode on an
analog channel, which provides a maximum deviation of 5KHz, and a
25KHz channel spacing
P25 Analog Line Vocoder
(TBAS093)
Allows analog consoles with P25 conventional network operation
a. Not needed for receive-only base stations.

TB7300 Installation and Operation Manual Description 19
© Tait International Limited December 2022
DMR/MPT Feature licenses
Feature license Description
Analog Air Interface
(TBAS301 - Default License)
A base station with this license can operate as an MPT transceiver or an
analog conventional repeater
DMR Conventional
(TBAS304)
A base station with this license can operate in a Tait DMR conventional
network. It can also operate as a stand-alone repeater, or as a member
of a multi-site system (under the supervision of a DMR conventional
channel controller).
DMR Trunking Access
(TBAS303)
A base station with this license can accept connections only from an
Access standalone node. This license entitles a standalone node to
control a single site of up to four physical channels.
DMR Trunking Express6
(TBAS302)
A base station with this license can accept connections from any Express
node/standalone node or Access standalone node. In single-site trunking
and fallback modes, this license entitles a standalone node to control a
single site of up to 6 physical channels.
DMR Trunking Express20
TBAS305
A base station with this license can accept connections from:
■An Express20 node
■An Express6 node
■A Standalone node
■A Standalone Access node
A base station with both a DMR conventional license and a valid DMR
trunking license (such as Express or Access) can be configured to
operate in either mode. This enables a DMR Tier 2 base station to be
reconfigured and re-used in a DMR Tier 3 trunked network.
DMR Trunking Full
(TBAS300)
A base station with this license can accept connections from any node/
standalone nodea
DMR Central Voter
(TBAS306)
This feature allows a base station to act as a DMR central voter
DMR IP Networking Satellite
(TBAS307)
This feature allows a DMR base station to be part of a channel group
a. The base station itself can act as a DMR trunking controller, but with limited functionality. The base station is
then said to be a standalone node.
Licenses are not lost or changed under software upgrades, downgrades, and changes of system
type. Older software may not display all licenses.

20 Description TB7300 Installation and Operation Manual
© Tait International Limited December 2022
License Name Air Interface System Type
TBAS041 Analog Air Interface Analog Conventional
TBAS050 P25 Common Air Interface P25 Phase 1 Conventional
TBAS060 Digital Fixed Station Interface Analog & P25 Phase 1 Conventional
TBAS061 P25 AS-IP Central Voter Analog & P25 Phase 1 Conventional
TBAS071 P25 AS-IP IP Networking
Satellite
Analog & P25 Phase 1 Conventional
TBAS062 P25 AS-IP Simulcast Analog & P25 Phase 1 Conventional
TBAS301 Analog Air Interface Analog Conventional/MPT Trunked
TBAS304 DMR Conventional DMR Conventional
TBAS303 DMR Trunking Access DMR Trunked
TBAS302 DMR Trunking Express6 DMR Trunked
TBAS305 DMR Trunking Express20 DMR Trunked
TBAS300 DMR Trunking Full DMR Trunked
TBAS306 DMR Central Voter DMR Trunked/Conventional
TBAS307 DMR IP Networking Satellite DMR Trunked/Conventional
