TAKAMA FLIP-ZIP User manual

TAKP4H58
FLIP-ZIP

TAKAMA FLIP-ZIP
MULTI-FUNCTIONAL TRIPOD MONOPOD KIT
INTRODUCTION
Thanks for choosing Takama!
The perfect hybrid accessory for photo and video cameras, this unique tripod will bring
stability and control to your stills and footage, both to traditional imaging and smartphone
based capture, making your nal product more appealing and professional.
The Takama brand represents consumer products of professional quality.
Make yourself familiar with all of the features of
the FlipZip. You’ll enjoy its use even more.
KEY FEATURES (Illustration - 1)
• Quick Flip Lock Legs
• Strong Aluminum Alloy 3 Section Rubber Tipped Legs
• Full Feature 2 Way Tripod Head
• Tilt Handle Opens to Reveal Smartphone Clip System
• Center Column Transforms into a Sele Stick
• Quick Release Camera Plate
• Trek Friendly Size and Weight
• Legs Assume Variable Angles
• Folds Down to a Mere 18.8”

SETTING UP THE TRIPOD
EXTENDING THE LEGS
Before spreading the legs apart, extend them to the desired
length, this will prevent tipping due to uneven leg extension.
To extend the legs, ip open the leg locks, pull the leg
extensions out, and ip closed the leg locks. Only work on one
leg lock at a time. Once all the legs are at the same length,
spread the legs apart to your chose angle.
Once the tripod is set up and the legs secured, several
adjustments can be made. These changes should be made
with extra care if the camera is mounted on the tripod.
HEIGHT
The center column can be raised and lowered. First loosen the center
column screw, then slide the column to raise or lower the center column.
Finish by tightening the center column screw.
ADJUSTABLE CENTER COLUMN (Illustration 3)
To release the center column, turn the center column locking knob
counterclockwise, adjust it to desired height, and then lock the column
by rotating the knob clockwise.
Now is also a good time to check that all the leg locks are tightened
before you put any equipment on the tripod.
On uneven surfaces and terrain, you can extend the legs to different
heights so that the camera is level and also stable.

ATTACHING YOUR CAMERA (Illustration 4)
To Use Quick Release Plate, rotate the lever to the right.
Pull the lever knob to release or lock the quick release plate
Now is a good time to tighten the tilt (vertical) control,
by tightening the tilt control knob clockwise, this will ensure that
your camera doesn’t tip off the plate when installed.
The QR plate has a screw. Locate your camera’s tripod screw
hole and align it with the QR plate screw. Tighten the screw as
far as possible by twisting the handle on the bottom of the QR
plate until the camera is rmly attached to the QR plate. Slide
the QR plate attached to the bottom of the camera back into its slot on the tripod head.
ENSURE THAT THE RELEASE HANDLE LOCKS FIRMLY INTO PLACE AFTER THE QR PLATE IS
RETURNED, SECURING THE CAMERA TO THE TRIPOD.
Do not let go of the camera until you are sure it is secured in place.
TILT
The camera can be tiled
downward or upward. Firmly grasp the tilt
control knob and loosen it by twisting it
counterclockwise. Position the camera at
the desired angle, then tighten by twist-
ing the tilt control knob clockwise. Test for
looseness before releasing.
PAN
The camera can be panned from side to side 360° by
loosening the pan control knob and then swiveling the
tripod head. The long handle should be used to pan for
more precise positioning of the camera. Tighten the pan
control knob to lock the camera position.

A HIDDEN SPRING HOOK (Illustration 7)
is located at the bottom of the Center Column.
For stable shooting, the hook can be used to hang sandbag or
equipment bag. Extend the spring loaded hook to the desired
position.
THE SMARTPHONE CLIP (Illustration 8)
Reveal the concealed smartphone clip by swinging out the tilt
lever handle pivot away from the shaft, according to the arrow
direction. The adjustable smartphone clip can be pulled up to
clamp a variety of sizes. Test the grasp the smartphone securely
on the clamp and use the head as you would with a camera.
CENTER COLUMN MONOPOD AND SELFIE STICK
The Center Column can be completely removed to create a
Monopod and Sele Stick using the Tripod Head Smartphone Clip
as the phone holder and a tripod leg as the extendable monopod.
First remove the bottom Spring Hook device from the column by
unscrewing it from the bottom. Loosen the center column
tightening knob enough so that the entire column is able to lift
free of the tripod. Now, replace the empty bottom end of the
column with the hole adapter cap. Unscrew the removable leg
from the tripod and attach it to the receiving hole threaded to
match the leg. Now you have an extendable monopod to hold
cameras or smartphones securely.

SAFETY & TIPS
Exceeding the suggested load of the tripod
can result in tipping or insufcient control when
panning/tilting. So don’t do it.
Always extend the legs to the widest area
possible. The wider the leg spread, the more
stable the tripod will be.
Ensure the head and camera is locked before
letting gravity take over.
Remove the camera, video device or
smartphone before moving the tripod
around or transport.
Do not shoot vertical video for monitors.
Except when your veiwing device is vertical,
of course.
Keep out of reach of children.
Question about our product line? Need Product Support?
We are proud of our products and celebrate our customers. We are with you, from product
selection to everyday use. Be secure with your purchase and reach us as you need.
Email us: [email protected]
Call: 212-647-9300
Address: Adorama Brands, 42 West 18th Street, New York, NY 10011
You can always contact us at [email protected]
for personal technical support.
Our web site contains a wide range of Support and FAQ pages
with valuable technical assistance.
Takama is a registered trademark of ADORAMA CAMERA.
© 2017 Adorama Camera, Corp. All Rights Reserved.

ONE YEAR TAKAMA LIMITED WARRANTY
Takama warrants to the original purchaser that your Takama product shall be free from defects in
material and workmanship for the period of one (1) year from the date of purchase (or delivery as may be
required in certain jurisdictions), or thirty (30) days after replacement, whichever comes later.
Takama’s entire liability and your exclusive remedy for any breach of warranty shall be, at Takama’s
option, to repair or replace the hardware, provided that the hardware is returned to the point of
purchase or such other place as Takama may direct with a copy of the sales receipt or dated item-
ized receipt. Takama may, at its option, replace your product, offer to provide a functionally equivalent
product, or repair any product with new, refurbished or used parts as long as such parts are in
compliance with the product’s technical specications. Any replacement hardware product will be
warranted for the remainder of the original warranty period or thirty (30) days, whichever is longer,
or for any additional period of time that may be applicable in your jurisdiction. If the product has been
discontinued, the warranty provider reserves the right to replace it with a model of equivalent quality
and function.
This warranty does not cover problems or damage resulting from accident, abuse, misapplication,
or any unauthorized repair, modication or disassembly, improper operation or maintenance, normal
wear and tear, or usage not in accordance with product instructions or connection to improper voltage
supply, use of consumables, such as replacement batteries, not supplied by Takama, except where such
restriction is prohibited by applicable law.
Except where prohibited by applicable law, this warranty is nontransferable and is limited to the original
purchaser and the country in which the product was purchased. This warranty gives you specic legal
rights, and you may also have other rights, including a longer warranty duration that may vary under
local laws.
To start a warranty claim contact the Takama Customer Service Department to obtain a return
merchandise authorization (“RMA”) number, and return the defective product to Takama, along with the
RMA number and proof of purchase.
