TAKASAGO ZX-S-H Series User manual

Constant-Voltage／Constant-Current DC Power Supply
series
Instruction Manual

も
Safety Precautions
For your safety 󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 1
Exportin g 󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 1
About this Product
Features 󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 3
Part Names and Functions󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 4
Front Panel 󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 4
Display Panel 󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 6
Rear Panel 󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 7
Preparation & Connecting
Unpacking󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 8
Placement 󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 8
Connecting the Power Supply󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 10
Connecting Loads󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 11
Attaching the Output Terminal Cover󳞫󳞫󳞫󳞫󳞫󳞫 13
Basic Operations
Startup Display 󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 14
Default Settings 󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 14
Returning Factory Settings󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 15
Backing-Up Settings󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 15
Operating as Constant Voltage Power Supply󳞫16
Operating as Constant Current Power Supply 18
Remote Sensing 󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 20
Function Settings 󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 21
Setting Functions 󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 21
Settings Items List󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 22
Setting Output ON/OFF Mode󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 27
Over Voltage Protection Circuit󳞥OVP󳞦󳞫󳞫󳞫 28
Setting/Canceling Over Voltage Protection󳞫󳞫󳞫 28
Over Current Protection Circuit󳞥OCP󳞦󳞫󳞫󳞫 30
Setting/Canceling Over Current Protection󳞫󳞫󳞫 30
Error Codes 󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 32
Useful Function
Memory 󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 34
Saving in Memory 󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 34
Loading from Memory 󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 35
Panel Memory Savable Items List󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 36
Startup Mode Selection 󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 37
Variable Slew Rate 󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 38
Sequential ON/OFF󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 40
Key Lock󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 43
Key Lock Settings 󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 43
Canceling Key Lock 󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 43
Variable Internal Resistance (ZX-S Series Type-HA) 󳞫󳞫 44
Measurement Display Smoothing 󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 45
Linearity Compensation󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 46
Sequential Operation Function󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 48
Using via Digital Communication
Overview󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 56
Multiple Connections󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 57
Serial Port Settings 󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 58
Command Send Interval󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 58
Accessing 󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 59
Access Procedure󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 59
Communication with Multiple Connections󳞫󳞫󳞫󳞫󳞫󳞫 60
Communication Commands󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 61
󳟗󳟕 Standard Commands󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 61
󳟗󳟕 Standard Command Format󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 61
󳟗󳟕 Standard Command Details󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 64
󳟂󳟕 Compatibility Commands󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 101
Command Format󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 102
Command Group Sending󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 102
Alarm Response Trigger Factors󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 102
Delimiter󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 102
SET Commands󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 103
Read-Back Commands󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 107
Notes 󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 110

Table of Contents
Using in Series/Parallel Operation
Parallel Operation 󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 112
Connecting 󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 112
Operation 󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 113
Error Codes 󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 113
Series Operation󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 114
Connecting 󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 114
Operation 󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 114
Controlling with External Analog & Contact Signal
Toggling Output ON/OFF at External
Contact󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 118
Using External Control Terminals
󳞥ZX-S Series Type-HA󳞦󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 120
Toggling Output ON/OFF with External
Contact 󳞥ZX-S Series Type-HA󳞦󳞫122
Input Cut-Off with External Contact
󳞥ZX-S Series Type-HA󳞦󳞫123
Output Voltage Control󳞥ZX-S Series Type-HA󳞦󳞫124
Output Voltage Control with External Resistance 󳞫124
Output Voltage Control with External Voltage 󳞫󳞫󳞫 128
Output Current Control󳞥ZX-S Series Type-HA󳞦󳞫129
Output Current Control with External Resistance 󳞫129
Output Current Control with External Voltage 󳞫󳞫󳞫 133
Analog Output Monitor󳞥ZX-S Series Type-HA󳞦󳞫󳞫 134
Output Voltage Monitor󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 134
Output Current Monitor󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 134
Status Output󳞥ZX-S Series Type-HA󳞦󳞫󳞫󳞫󳞫󳞫󳞫 135
Output Circuit󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 135
Status List󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 135
Status Output Electric Specifications󳞫󳞫󳞫󳞫󳞫󳞫 135
󳟉󳟂󳟓󳟂󳟉_󳞾󳟉󳟊󳞮 Settings󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 136
Special Loads
Battery Charging/Discharging 󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫138
Charging Battery 󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫138
Discharging Battery󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫140
Loads with Reverse Current󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 141
Pulse Current Loads 󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 142
Maintenance
Warranty Period󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 144
Daily Maintenance & Inspection󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 144
Cleaning Air Filter 󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 145
Cleaning Panels󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 145
Inspecting Cables & Terminals 󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 145
Welded Fuses 󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 145
Replacing Fan Motor 󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 146
Lifespan of Parts󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 147
Calibration
Calibrating Output Settings󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 148
Offset/Full-Scale Calibration
of Output Voltage Settings󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 148
Offset/Full-Scale Calibration
of Output Current Settings󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 150
Offset/Full-Scale Calibration of Output Voltage
with External Analog Values 󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 152
Offset/Full-Scale Calibration of Output Current
with External Analog Values 󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 160
Calibrating Meters󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 168
Voltmeter Offset/Full-Scale Calibration󳞫󳞫󳞫󳞫󳞫 168
Ammeter Offset/Full-Scale Calibration󳞫󳞫󳞫󳞫󳞫 170
Offset/Full-Scale Calibration of
Output Voltage Monitor󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 172
Offset/Full-Scale Calibration of
Output Current Monitor 󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 174
Specifications
Output Specifications󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 176
Input Specifications󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 176
Constant Voltage Characteristics󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 177
Constant Current Characteristics󳞫󳞫󳞫󳞫󳞫󳞫󳞫 177
Measures/Displays󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 178
Protection Functions󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 179
Remote Sensing󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 179
Other Functions󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 180
External Control󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 180
Insulation/With Standing Voltage󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 181
Cooling 󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 181
Operational Environment󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 181
Dimensions/Weight󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 182
Accessories󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 183
Appendix
Exterior Diagrams 󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 184
Load current vs Cross section area󳞫󳞫󳞫󳞫󳞫󳞫󳞫󳞫 187

■This manual uses the following marks and symbols to assist you in the proper use of this product.
！
Danger
Failure to observe precautions indicated by this symbol and improper use or handling of
the product will result in serious injury or death.
！
Warning
Failure to observe precautions indicated by this symbol and improper use or handling of
the product may result in serious injury or death.
！
Caution
Failure to observe precautions indicated by this symbol and improper use or handling of
the product may result in injury or property damage.
■Items that must be observed are classified into the following marks.
■Symbols used within this manual are described below.
Contact with areas on the product indicated by this symbol may result in electric shock.
Unplug the power supply plug from the outlet. Continual use of the product if
󳓵Continual use of the product if there are abnormal noises or smells
󳓵Smoke appears 󳓵Water or foreign objects enters the product
may result in fire or electric shock.
Dismantling or modifications to the product is prohibited. Do not open the cover.
󳓵This may result in fire or electric shock. 󳓵For repairs and adjustments please contact your retailer.
Protective Earth Terminal. Please make a connection in earth.
Please connect for loads with earth terminals
Direct Current (DC)
Alternating Current (AC)
AC and DC
3-Phase Alternating Current
This mark indicates items that are 󳆟Prohibited󳆠.
！
This mark indicates items that are 󳆟Mandatory󳆠.
！
This mark indicates general 󳆟Caution󳆠.
This instruction manual uses the various symbols below to indicate areas of caution.
Please thoroughly read and understand these symbols and their significance prior to use.
The section 󳆟For your safety󳆠contains information on items not included with your purchased product.

Safety Precautions
------------------------------------------------------------------------------------
1
For your safety
󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪󳜪
This product is a power supply system for business use, which uses an input power of AC85V󳟻250V (single
phase).
Improper use of this product may result in injury, electric shock or death, and may also result in fire.
Please thoroughly read and understand this manual prior to use. Further, this product should only be handled by
a specialist knowledgeable in electricity safety, or under the supervision of such a person.
Please read through this manual to ensure the proper placement and use environment for this product before
turning on power.
If any problems arise, please unplug the power supply plug from the outlet power immediately and contact Takasago.
Exporting
Please contact Takasago in advance if wishing to export or carry this product outside of Japan.
Using this product near receivers (radios, televisions, etc.) may interfere with reception.
Please do not use this product in any medical, nuclear, or work involving human life.
Caution
󳞮󳞫Reproduction of the material contained within this manual without notice is strictly prohibited.
󳞯󳞫Information contained within this manual may be altered without notification.
󳞰󳞫All material contained within this manual has been thoroughly examined. If by chance, any errors,
suspicious items, or omitments are discovered, please contact Takasago.
󳞱󳞫Takasago Co., Ltd. shall undertake no responsibility, regardless of clause 2, for any impact this
product may have on results.
Caution

------------------------------------------------------------------------------------
2
The ZX-S Series is the Switching DC Constant Voltage/Constant Current Power Supply
capable of changing from zero-volt and zero-ampere.
By applying the Zoom method, an extension ratio of 8 times is possible within the range of the
rated output power. (See Note 1)
󳜪The ZX-S series allows the use of both the Constant Voltage and Constant Current modes,
along with the ability to be able to freely set the power from zero to full scale.
󳜪The ZX-S series, with full digital control, also grants settings with superior accurate
reproduction.
Note󳞮󳞫 Zoom method is the ability to output a high voltage in areas with low current, and high current in areas
with low voltage, while maintaining the output range for the rated power, as shown in the diagram below.
0
80
160
240
320
400
480
560
640
720
Output Voltage󳞥󳟓󳞦󳙘󳉜
Output Current󳞥󳞾󳞦󳙘󳉜
Rated Output Power Line
Circuit Output Voltage
Rated Output Current
00.625 1.25 1.875 2.5 3.125 3.75 4.375 55.625
01.25 2.5 3.75 5 6.25 7.5 8.75 10 11.25
0 2.5 5 7.5 10 12.5 15 17.5 20 22.5
󳉚󳙘400H/HA
󳉚󳙘800H/HA
󳉚󳙘1600H/HA
400H/HA
800H/HA
1600H/HA
󳞷400W
󳞷800W
󳞷1600W
󳙧Output Voltage/Current Range󳙨

About this Product
------------------------------------------------------------------------------------
3
Features
󳗔Multi-Functional Zoom Power Supply
Able to handle any combination of voltage and current.
Perfect for experiments requiring both voltage and current.
󳗔Serial Communication Port Standardized System
Equipped with a multi-drop communication port, one RS-
232C or RS-485 port is capable of controlling up to 31
ZX-S Series units.
󳆽For multiple connections, the KXC-300 cable (sold
separately) is required.
󳗔Improved Parallel Operation 󳞥New Master/Slave󳞦
CV transient recovery properties will not degrade, even when
increasing the number of parallel units, due to both the
master and slave units being controlled simultaneous.
󳗔Useful Functions
󳓶Memory
Saves and loads 3 set panel settings
Perform voltage variation tests and other tests
effortlessly.
󳓶Variable Slew Rate
Changes the slew rate for the rising and falling of the
voltage/current.
󳓶Startup Mode Selection
Equipped with a CC Priority Mode for loads with nonlinear
V-I characteristics similar to diodes, this function is
capable of preventing current overshoot when output is
ON.
󳓶Sequential 󳟌󳟋/󳟌󳟃󳟃
Sets the order outputs are toggled ON/OFF through a
multi-connection cable.
󳗔Protection Functions
Guards valuable loads and power supplies with Over Voltage
Protection, Over Current Protection, Over Power Protection,
Over Heating Protection, Excessive Input Current Protection,
etc
󳗔External Analog Control󳞥ZX-S Series Type-HA󳞦
Able to control ON-OFF output with external contact points,
and voltages and currents based on external DC voltage (0
󳟻10󳟓) and external resistance (0󳟻󳋓 or 0󳟻10󳟨󳁩)
󳆽Full-scale and offset adjustments can be performed with
the front panel dials.
󳗔Analog Monitor 󳞥ZX-S Series Type-HA󳞦
Outputs the output voltage and output current with 0󳟻10󳟓
DC.
󳆽Not suited for monitoring transient voltage/current
waveforms.
󳗔Status/Alarm Output󳞥ZX-S Series Type-HA󳞦
Outputs an alarm or operation status with a photocoupler
output (open collector) insulated from outputs and the earth.
󳗔Variable Internal Resistance
(ZX-S Series Type-HA)
Intentionally generates voltage drop through load current
when running in constant voltage mode.
With this function, the power supply is capable of
approximating an internal resistance of chemical batteries
(during electric discharge) and I-V characteristics of
solar/fuel cells.
󳆽Restricted to direct current operations. Not suited for
approximating transient effects.

About this Product
------------------------------------------------------------------------------------
4
Part Names and Functions
Front Panel
󳏀．STEP VOLTAGE/CURRENT
Setting/Selection Dial
Selects the voltage, current, OVP, OCP settings and
various other parameters. Press the dial to change the
settings number place.
󳏁．MEMORY
Memory Display/Settings Key
Saves and loads the panel settings with keys
󳆟A󳆠,󳆠B󳆠,and 󳆟C󳆠. Also, depending on the Function item
setting, this can be used to select One-Action or Two-
Action loading method.
󳏂．OUTPUT
Output ON󳞬OFF Toggle Key
Toggles output ON/OFF.
The factory default setting for the output, after inserting
power, is OFF.
󳏃．Output ON/OFF Display Lamp
Lights when the output is set to ON.
󳏄．LOCAL
LOCAL Key
Switches between 󳆟LOCAL󳆠, operated from the panel,
and 󳆟REMOTE󳆠, operated by control via serial data
communication.
󳆽This is the front panel of the ZX-S-800H
󳏅󳞫LOCK
LOCK Key
Locks panel from use.
Below are the 3 types of Lock settings. Each function
setting key (FUNC.) can be changed.
󳜪Locks everything but the LOCK key
󳠂Locks everything but the OUTPUT and LOCK key
󳜪Locks only the Voltage/Current Dial, PRESET, and
FUNC. keys.
󳏆󳞫FUNC󳞫
Function Key
Used for setting various functions
󳏇󳞫POWER
Input Power Switch
Toggles power ON/OFF
󳏈󳞫Ventilation Panels
Panels which allow cool air to enter and cool the
product internally.
OUTPUT
PRESETOVP OCP
POWER
FUNC.
LOCAL
LOCK
DISPLAY
A B C
STORE
MEMORY
CC
CV
OUTPUT POWE R (%) STEP
CURRENT
STEP
VOLTAGE
PRESET FUNC.REMOTE LOCK
ALARM RESET
20 60 100 LMT40 80
78
1
2
3
4
5
6
9
V

About this Product
------------------------------------------------------------------------------------
5
Front Panel
󳏉󳞫DISPLAY
Display Key
Toggles the displayed measurement information.
Can be toggled between 3 display modes:
Voltage/Current, Voltage/Power, Power/Current.
󳏊󳞫 OVP
Over Voltage Protection󳞥OVP󳞦Key
Sets the trigger point for the OVP circuit. Hold down
together with 󳏋(OCP) key for 1 second or more to
cancel and OVP alarm.
󳏋󳞫OCP
Over Current Protection󳞥OCP󳞦Key
Sets the trigger point for the OCP circuit. Hold down
together with 󳏊(OV) key for 1 second or more to
cancel and OCP alarm.
󳏌󳞫PRESET
Preset Key
Used to set the output voltage and output current.
󳆽Front panel diagram of ZX-S-800H
OUTPUT
PRE SE TOVP OCP
POWER
FUNC.
LOCAL
LOCK
DISPLAY
A B C
STORE
ME MO RY
CC
CV
OUTPUT POWER (%) STEP
CURRENT
STEP
VOLTAGE
PRESET FUNC. REMOTE LOCK
ALARM RESE T
20 60 100 LMT40 80
11
12
13
10

About this Product
------------------------------------------------------------------------------------
6
Display Panel
󳏎󳞫󳟨W󳙙󳟓󳙙󳟔
Measurement Unit Display Lamp
Lights when top Number Display displays a voltage/power
value.
󳏏󳞫CV
Constant Voltage Display Lamp
Lights when output is set to 󳆟ON󳆠during constant
voltage mode.
󳏐󳞫CC
Constant Current Display Lamp
Lights when output is set to 󳆟ON󳆠during constant
current mode.
󳏑󳞫󳟨W󳙙A󳙙󳟔
Measurement Unit Display Lamp
Lights when bottom Number Display displays a current/
power value.
󳏒󳞫LOCK
Key Lock Display Lamp
Lights when Lock has been enabled.
󳏓󳞫REMOTE
Remote Display Lamp
Lights when control has been transferred to an external
computer, etc. being accessed via serial interface.
.FUNC󳞫
Function Display Lamp
Lights when Function settings are available.
󳞫PRESET
Preset Display Lamp
Lights when Preset settings are available.
󳞫Number Display
Displays the output voltage, output current, and output
power.
When setting functions with the Function key, the item
number will be displayed on the top and its parameter will
be displayed on the bottom.
󳞫OUTPUT POWER
Output Bar Graph
Displays an approximate value of the output power (Output
Voltage󲼃Output Current) in 20% intervals.
LMT lamp will light when the output power Limiter has been
activated.
CC
CV
OUTPUT POWER (%) STEP
CURRENT
STEP
VOLTAGE
PRESET FUNC. REMOTE LOCK
20 60 100 LMT40 80
24
15
16
17
18
19
20
21
22
23

About this Product
------------------------------------------------------------------------------------
7
Rear Panel
󳆽Rear panel diagram of ZX-S-400HA
．Series Operation Control Connectors
(ZX-S Series Type-HA)
Connector for series connections.
When using the Slave unit, connect with the Master unit󳆜s
minus output terminal using wires.
．External Control Connector(ZX-S Series Type-HA󳞦
Connectors for the external analog control, analog monitor
output, and status/alarm output.
Use the included specialized connectors.
．Fan Motor
Cools the device internally.
The fan motor󳆜s rotation speed will change in response to
the output power and output current.
．DC OUTPUT
Output Terminal
Direct Current Output Terminal
A Crimp-Style Terminal must be used. Please be sure
to tighten all attachment screws.
After connecting, attach the output terminal cover
before use.
．LINE INPUT
Input Terminal
Inlet connector connects power to the device.
Use the included input power cable.
The nominal voltage for the power supply is indicated on the
rear panel.
Please use only the input power cable that is included.
Do not use the included input power cable with any other
products.
．SENSE
Sensing Terminal
Terminal for Remote Sensing
󳞫SERIAL I/F 1
Serial Port Connector
Connector for connecting computers etc. with serial
cables (RS-232C).
．SERIAL I/F 2
Multi-Channel Connectors
Connectors for when controlling multiple ZX series units
or for controlling RS-485 type, serial ports.
Connect using KXC󳞪300 󳞥300󳟪󳟪󳞦 cable.
．TERMINATION
Termination Resistor ON/OFF Switch
Sets the termination resistor settings.
When controlling one ZX series power supply via serial
port, please set the toggle switch to ON.
When using 2 or more power supplies, please set the first
and last ZX-S series DC power supply units󳆜termination
resistor ON/OFF switch to ON. (For all other units, set
to OFF)
．M/S CONTROL (IN)
Connector for Parallel Operation Control (Input)
and Output ON/OFF Control with External
Contacts
Slave Control Signal Input Connector for parallel operations.
Use for toggling the output ON/OFF with external contacts.
．M/S CONTROL (OUT)
Parallel Operation Control 󳞥Output󳞦
Connector for parallel connections.
Outputs parallel operation control signals
！
！
26
SERIAL I/F 1 SERIAL I/F 2 TERMINATION
OFF
ON
IN OUT
M/S CONTROL
SENSE
+DC OUTPUT -
+ -
100-240～,50/60Hｚ,7A MAX
LINE INPUT
27
28
29
30
31
32
33
34
35 25

------------------------------------------------------------------------------------
8
準備と接続
Unpacking
When unpacking, please verify the following accessory items are included. Also, please verify that there are no
scratches or indentations present on the power supply󳆜s exterior.
󳏀󳞫Input Power Cable 󳞥AC125V Rating󳞦1 item (400H/HA,800H/HA)
󳆽The included power cable cannot be used for AC200V inputs. Please contact Takasago Sales Department for the proper
power cable.
󳏁󳞫2P/3P Adapter (AC125V Rating) 1 item (400H/HA, 800H/HA)
󳏂󳞫Input Power Cable (3-conductors VCT cable 5.5mm2) 1 item (1600H/HA)
󳏃󳞫Output Terminal Cover 1 package
Output Terminal Cover 2 items (identical shape)
Support Post for attaching cover 1 item
M3󲼃6mm screws 2 items
󳏄󳞫Output Terminal Screws
M5󲼃12mm bolts (includes Flat washers and Spring washers) 2 packages
(Attached to power supply)
󳏅󳞫Dummy Connector (Attached to power supply) 󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣2 items
󳏆󳞫Instruction Manual 󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣1 copy
󳏇󳞫External Control Connector 󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣󲻣1 item 󳞥ZX-S Series Type-HA󳞦
Placement
To ensure proper and safe use of this product, please observe the following.
Warning
Do not use in areas exposed to rain and water.
Prohibited
Do not place in areas in which flammable gases are present.
Prohibited
Do not insert any metallic pins, wires, screws, etc. in the front ventilation panels and in the rear fan
motor. Doing so may result in electric shock and/or fire.
Prohibited

Preparation & Installation
------------------------------------------------------------------------------------
9
Caution
This product was designed to be used in stable areas. Do not use or place in areas prone to vibration.
Improper placement of the power supply may result in damage. Please see below for proper placement.
Prohibited How to place:
Correct Incorrect Incorrect
Caution
Use only in areas with a room temperature of 󳞭󳟻󳞲󳞭󳇾, humidity of 󳞯󳞭󳟻󳞵󳞭󳞣󳟏󳟅, and which is
absent of any corrosive gases.
Mandatory 󳞥However, in areas above 40󳇾a 2.5󳞣to 1󳇾ratio is required for derating the output power and
output current.
This power supply uses a forced air cooling system. Do not obstruct the front ventilation panels and
rear fan motor. If affixing to a rack, attach ventilation panels to the rear of the rack to prevent
Prohibited exhaust from the power supply from being released inside the rack.
Using this product near receivers (radios, televisions, etc.) may interfere with
Caution reception.
○
OUTPUT
PRESETOVP OCP
POWER
FUNC.
LOCAL
LOCK
DISPLAY A B C STORE
MEMORY
CC
CV
OUTPUT POWER (%) STEP
CURRENT
STEP
VOLTAGE
PRESET FUNC. REM OTE LOCK
ALARM RESET
20 60 100LMT40 80
DC OUTPUT +-
80A MAX
×
OUTPUT
PRESET
OVP OCP
POWER
FUNC.
LOCAL
LOCK
DISPLAY ABCSTORE
MEMORY
CC
CV
OUTPUT POWER (%) STEP
CURRENT
STEP
VOLTAGE
PRESET FUNC. REMOTE LOCK
ALARM RESET
20 60 100 LMT
40 80
DC OUTPUT +
-
80A MAX
×
OUTPUT
PRESET
OVP OCP
POWER
FUNC.
LOCAL
LOCK
DISPLAY ABCSTORE
MEMORY
CC
CV
OUTPUT POWER (%) STEP
CURRENT
STEP
VOLTAGE
PRESET FUNC. REMOTE LOCK
ALARM RESET
20 60 100 LMT
40 80
DC OUTPUT +
-
80A MAX

Preparation & Connecting
------------------------------------------------------------------------------------
10
Connecting the Power Supply
This product operates on a 󳞵󳞲󳟓󳟻󳞯󳞲󳞭󳟓 and 󳞱󳞲󳟅󳟷󳟻󳞳󳞲󳟅󳟷 single-phase AC power supply.
The maximum input current during rated output is approximately 7A when the AC power supply󳆜s voltage
is 󳞵󳞲󳟓.
To ensure proper and safe use of this produce, please observe the following.
Danger
Ground the green cord when using the 2P-3P adapter.
Mandatory
A noise filter is built into the device to prevent EMI (Electromagnetic Interference).
Due to this, even the slightest amount of leaked current may result in electric shock if not
Mandatory properly grounded.
For safety reasons, please ground the device.
Caution
Please use input power within ranges of 󳞵󳞲󳟓󳟻󳞯󳞲󳞭󳟓 and 󳞱󳞲󳟅󳟷󳟻󳞳󳞲󳟅󳟷 (single-phase).
Mandatory Nominal Power Supply Voltage is displayed near the rear panel inlet.
Please connect to a power supply capable of providing the maximum electric power consumption.
Mandatory
Please use the input power cable included with the product.
Do not use the input power cable with any other products.
Mandatory

Preparation & Connecting
------------------------------------------------------------------------------------
11
SERIAL I/F 1 SERIAL
LINE INPUT
SENSE
+DC OUTPUT -
+ -
Connecting Loads
For wiring to the output terminal, please attach the M5
crimp-style terminal and be sure to tightly fasten the M5
screws.󳞥󳆽󳞦
󳜪Twisting wires can minimize the ripple and noise at
the load terminal.
󳜪The noise level can be minimized smaller than the
standard value by connecting the C1 and C2 close to
the load terminal.
Using a small, high-frequency impedance for C1 and
C2, cut the lead wire as short as possible and
connect.
󳟀󳞮󳞷Electrolytic Capacitor 󳞮00󳟻1000󳁼F
󳟀󳞯󳞷Film Capacitor 󳞮󳟻10󳁼󳟃
MEMO
Please attach the terminal cover after wiring.
Mandatory

M5 Bolt
(includes spring and flat washers)
When grounding, use a load terminal
！
󲆨󱱕
󳚹󳚻󳛀󳚌󳚼
󳟊󳞲󰄞󱓵󱜤󰍫
配線材
+
－
C1 C2
Load
Twisted
Wires
M5 Crimp-Style Terminal
Terminal Cover

Preparation & Connecting
------------------------------------------------------------------------------------
12
Danger
Verify that the main power supply for the power supply is turned off when connecting loads.
Mandatory
Do not wire loads when voltage is being outputted from the power supply.
Prohibited
Caution
Use wires with sufficient cross section areas for load currents.
Mandatory Ex.󳞦See Appendix Load Current vs Cross section areas.
.
Attach crimp-style terminals to wires and securely fasten.
Mandatory If insecurely fastened, wires may become deformed or burn out due to the generated heat at
connection points.

Preparation & Connecting
------------------------------------------------------------------------------------
13
Attaching the Output Terminal Cover
󳞮󳞫Hook and attach one terminal cover (both covers are identical in shape) on the upper grooves of the Output
Terminal platform.
󳞯󳞫Attach the support rod to the remaining terminal cover (inserting it into the center part of the cover) and
affix the rod in place by screwing an M3x6mm into it from the bottom of the cover.
󳞰󳞫Hook the terminal cover (with attached support post) on the lower grooves of the Output Terminal platform,
then raise and snap the terminal cover in place with the upper-half.
M3 Screw Hole
󳞱󳞫Fasten a M3󲼃6mm screw from above.

------------------------------------------------------------------------------------
14
基本的な使い方
Startup Display
Once power is turned on (POWER switch pushed to ON), the power supply model will be displayed in the top Number
Display and the firmware version and number of parallel connected devices will be displayed in the bottom Number
Display.
If there is a disagreement in the number of parallel connected devices (if there is a difference
between the number of parallel devices used previously and now), the error code 󳆟E011󳆠will be
displayed in the top Number Display and the number of detected devices will be displayed blinking
in the bottom display. After confirming the number of parallel devices, hold down the FUNC. key
for more 2 seconds to approve and proceed to measurement display mode.
Default Settings
Factory settings and settings after initialization are as followed:
Settings Item
400H/400HA
800H/800HA
1600H/1600HA
Constant Voltage Set Value
󳞭.󳞭󳞭󳟓
󳞭.󳞭󳞭󳟓
󳞭.󳞭󳟓
Constant Current Set Value
󳞲󳞫󳞯󳞲󳞭󳞾
󳞮󳞭󳞫󳞲󳞭󳞾
󳞯󳞮󳞫󳞭󳞾
Over Voltage Protection (OVP)
Set Value
󳞴󳞭󳞱󳟓
󳞴󳞭󳞱󳟓
󳞴󳞭󳞱󳟓
Over Current Protection (OCP)
Set Value
󳞲󳞫󳞲󳞾
󳞮󳞮󳞫󳞭󳞾
󳞯󳞯󳞫󳞭󳞾
Settings Values in Memory
󳞾󳞩󳞿󳞩󳟀
Same with the above CV set values, CC set values, OVP set values, OCP set
values
Function Settings
See page 23 on Default Values for Function Settings (excluding section 20󳟻38
Calibration Values)
POWER
FUNC.
LOCAL
LOCK
ALARM RESET
POWER switch ON
Top Number Display/Displays Model
Bottom Number Display/Displays Fireware Version
Top Number Display/Displays Model
Bottom Number Display/No. of Parallel Devices
Measurement
Display
Models 󳔤ZX-S-400H󳞷04H󳔤ZX-S-800H󳞷08H 󳔤ZX-S-1600H󳞷16H
Displayed as: 󳔤ZX-S-400HA󳞷04HA 󳔤ZX-S-800HA󳞷08HA 󳔤ZX-S-1600HA󳞷16HA
MEMO
CC
CV
OUTPUT POWER (%) STEP
CURRENT
STEP
VOLTAGE
PRESET FUNC. REMOTE LOCK
20 60 100 LMT40 80
CC
CV
OUTPUT POWER (%) STEP
CURRENT
STEP
VOLTAGE
PRESET FUNC. REMOTE LOCK
20 60 100 LMT40 80

Basic Operations
------------------------------------------------------------------------------------
15
Returning Factory Settings
All power supply settings can be initialized.
To return settings to factory default settings, turn the POWER switch
ON while holding down the MEMORY keys󳆟A󳆠and 󳆟C󳆠. Release the keys
once the Number Display lights up.
Backing-Up Settings
This power supply saves all settings in non-volatile memory (EEPROM) just before the POWER switch is
turned off or immdeitely before power is cut off.
All previous settings will remain the same when power is turned on again.
󳆽No batteries are used. There is no need to replace batteries.
OUTPUT
PRESETOVP OCP
POWER
FUNC.
LOCAL
LOCK
DISPLAY
A B C
STORE
MEMORY
ALARM RESET

Basic Operations
------------------------------------------------------------------------------------
16
Operating as Constant Voltage Power Supply
Please verify that the settings for Over Voltage
Protection (OVP) circuit (page 29) and Over Current
Protection (OCP) circuit (page 31) are in effect.
Turn the POWER switch ON to startup the power supply.
The voltage measurement value will display in the top Number
Display, and the current measurement value will display in the
bottom Number Display. Lamp 󳆟V󳆠and 󳆟A󳆠will light. (If
parameters for FUNCTION settings item 52 is set to 1, PRESET
value will be displayed)
Press the PRESET key
PRESET lamp will light.
Press the PRESET key again if you wish to discontinue and
return to the measurement display mode.
The voltage PRESET value will display in the top Number Display
and the current limit PRESET value will display in the bottom
Number Display.
Turn the VOLTAGE dial to adjust the Constant Voltage
Set Value
(Turn the dial right to raise or left to lower the set value.)
If the parameter for FUNCTION item 50 is set to 0, press
the PRESET key again. The output voltage will be changed
once PRESET mode has been exited.
If the parameter for FUNCTION item 50 is set to 1, promptly
change the set value using the VOLTAGE dial.
Press the VOLTAGE dial to display the current number
position. The selected number will be brightened. Press to
change position. If all 4 places are brightened, numbers will
change from the lowest place.
MEMO
󳊜Continued on next page
OUTPUT
PRESETOVP OCP
FUNC.
ALARM RESET
When POWER is turned OFF the top and bottom
Number Displays will be displayed in the same
manner when POWER is turned ON again.
MEMO
CC
CV
OUTPUT POWER (%) STEP
CURRENT
STEP
VOLTAGE
PRESET FUNC. REMOTE LOCK
20 60 100 LMT40 80
CC
CV
OUTPUT POWER (%) STEP
CURRENT
STEP
VOLTAGE
PRESET FUNC. REMOTE LOCK
20 60 100 LMT40 80
CC
CV
OUTPUT POWER (%) STEP
CURRENT
STEP
VOLTAGE
PRESET FUNC. REMOTE LOCK
20 60 100 LMT40 80
