Talk To Me Technologies wego A User manual

TTMT Switch Interface Guide
For wego A Speech-Generating Devices
Find more resources online:
talktometechnologies.com (click Support)
SWIUG 0421

Table of contents
Hardware, power buttons and features .............................2
Setup Instructions ..............................................4
Guided Access ................................................5
Setup with Proloquo2Go ........................................6
Setup with TouchChat, Grid, LAMP, Avaz & Speak for Yourself .........7
Setup with GoTalk Now.......................................... 8
Setup with Cough Drop ......................................... 9
FCC compliance information .................................... 10
User information, passwords and notes ........................... 12
Contact information ........................................... 16

2
wego 7A, 10A & 13A
If your wego A model does not have a Home button,
swipe up from the bottom of the screen.
4
3
1
2
wego A hardware and features
Power
Press and hold this button (plus a volume button on some models)
to turn the device on or off.
Note: Press this button one time while the wego A is on to put it into “Sleep” mode.
This feature will conserve battery life when the wego A is not in use.
You can also turn off the wego by going to Settings > General > Shut Down.
1
Volume
Press the volume toggle up or down to adjust volume levels.
2
Home
Tap to return to the home screen. If your wego A model does not
have a Home button, swipe up from the bottom of the screen.
3
Charging the device
Pull down the tab to reveal the device charging port. Charge device
and speaker at night or when not in use. Please only use a TTMT-
approved charger with your device.
4

3
TTMT Switch Interface hardware and features
Power
Flip switch into up position to turn on the Bluetooth device and ip
switch down to turn it off.
1
Power light indicator
When this light is on and red, the Bluetooth device is on.
2
Charging the TTMT Switch Interface
Plug charger into port to charge the switch interface. Please only use
a TTMT-approved charger with your device.
3
Switch Port 1
Plug switch cords into the switch ports.
4
Switch Port 2
Plug switch cords into the switch ports.
5

4
Setup Instructions
Turn on the TTMT Switch Interface, using the on/off switch located on
the side of the interface box. You will see a red power light to indicate the
interface is turned on.
Ensure the Switch Interface is connected to the wego via Bluetooth.
1. Exit the communication software (if you are unable to exit the software,
you may be in Guided Access. See Guided Access, page 5 for
instructions on leaving Guided Access).
2. Open the iOS Settings then select Bluetooth. Ensure Bluetooth
is toggled On. Under My Devices, you should see TTMT Switch listed
as Connected. If not, tap on “TTMT Switch” to connect. You may see a
pop-up Bluetooth Pairing Request, if so, press Pair.
3. Once the Switch Interface is connected via Bluetooth, you can plug in
your switches and begin setup. Connect your Switch or Switches to
the TTMT Switch Interface
The Switch Interface can be used with one or two switches. For single-
switch scanning, plug your switch to Switch Port 1. For two-step scanning,
plug in both switches, with your “chooser” in Port 1 and your “mover”
switch in Port 2.
Note – once all settings are adjusted, see instructions for resuming Guided Access
(Page 5).

5
End Resume
X
X
End Resume
Guided Access
1. Start Guided Access by quickly triple-clicking the home button. Note: if
your wego A model does not have a home button, use the Power button
as shown on page 2. Enter all 1’s when prompted for password. It will
open this screen.
3. Press Resume to continue Guided Access (top right).
4. Press End to stop Guided Access (top left).
5. Lock Menu (restrict use of the menu bar or specic buttons/pages):
Open Guided Access > Use your nger to draw a circle around area/
buttons to restrict.
In addition to being a dedicated communication device, the wego A has
Guided Access, which keeps the user locked into the vocabulary software.
All dedicated devices come with Guided Access enabled, but you may
disable Guided Access after receiving your device. The wego A will remain
dedicated to communication even with Guided Access disabled.

6
Setup with Proloquo2Go
Single-switch scanning (1 switch, connected to Port 1):
Mode - Automatic Scanning: (default) Highlighted selection advances
through items automatically. When item desired is highlighted, press the
switch.
Mode - Automatic Selecting: Advances automatically through items
when switch is held and selection occurs upon release.
1. Ensure desired Mode is selected. Adjust scan Pattern and Speed as
desired.
2. Under Switch, select External > Enter > Back.
3. When scanning settings are adjusted as preferred, close the Options by
tapping the gear icon. Tap the play button in the top left corner of the
screen to begin scanning. Press your switch to begin.
Two-switch scanning:
Mode - Step Scanning: (two switches required) hit “mover” switch to
move between items. When desired item is selected, hit “chooser” switch.
Mode - Automatic Step Scanning: Uses the screen as a “stepper”
switch and an external switch as the “picker” switch.
1. Under Mode, select Step Scanning. Adjust scan Pattern and Speed as
desired.
2. Under stepper switch, select External > Space > Back.
3. Under picker switch, select External > Enter > Back.
4. When scanning settings are adjusted as preferred, close the Options by
tapping the gear icon. Tap the play button in the top left corner of the
screen to begin scanning. Then, press your switch to begin.
Additional Notes on Scanning with Proloquo2Go:
Advanced setup options are available, for example changing visual cues,
auditory cues, looping settings and more.
Scanning options only apply to the current user and will need to be
adjusted if changing users.
Return to the communication app, Proloquo2Go. Open
Options > Access Method > and toggle on Scanning.
Select Conguration.
Now you can select your Scanning Mode and Pattern.

7
Setup with TouchChat, Grid, LAMP, Avaz & Speak for Yourself
1. In the iOS Settings, select Accessibility > Switch Control. Do
not toggle on Switch Control until setup is complete.
2. On the screen, select Switches > Add New Switch > External.
3. Activate the switch connected to Port 1.
4. When the keyboard pops up, title the switch (i.e. “Switch #1”).
5. Choose a switch action > Select Item.
6. Skip to Step 11 if you are single-switch scanning.
7. For two-switch scanning, again select Add New Switch > External.
8. Activate the switch connected to Port 2.
9. When the keyboard pops up, title the switch (i.e. “Switch #2”).
10. Choose a switch action > Move To Next Item.
11. Return to the Switch Control menu.
12. Ensure Recipes are labeled “None.” If there are recipes listed, remove
them (to remove a recipe – tap on Recipes > Edit > > Delete >
Back).
13. Under Scanning Style, choose Auto Scanning for single-switch
scanning or Manual Scanning for two-switch scanning.
14. Adjust Timing, Audio, visual and other settings as preferred.
15. Ensure that Tap Behavior is listed as “Always Tap.”
16. Once settings are set as preferred, toggle Switch Control On (Green),
and open your communication app (TouchChat, Grid, LAMP, Avaz,
Speak For Yourself).

8
Setup with GoTalk Now
1. Return to the communication app, GoTalk Now.
Open Settings and Scroll to Scanning.
2. Select Scanning Device Type > Space and Enter Switch.
3. Determine Scanning Mode.
a. For single-switch scanning, toggle on Auto Scan.
b. For two-switch scanning, toggle off Auto Scan.
4. Select Grouping Style (row, column, etc), Speed, Repeat, etc. as
preferred.
5. Press Done to close Settings and return to Player Mode.

9
Setup with Cough Drop
1. Return to the communication app, Cough Drop.
Tap on the User icon in the top right corner > Exit Speak Mode
> User Icon > Preferences. Scroll to and tap on Scanning Settings.
Check “Enable switch-activated scanning.”
2. Select your preferred Scanning Mode from the drop-down menu (Row-
Based, Column-Based, Button-Based, Region-Based, Axis-Based).
3. Check the box next to Scanning Start. Scanning will not start until a
switch is pressed.
4. Adjust Scanning Interval:
a. Single-switch scanning: Adjust timing with the + or – signs for auto-
scan timing.
b. Two-switch scanning: Adjust the Scanning Interval to 0.
5. Assign Scanning Key(s):
a. Single-switch Scanning: Tap the box next to Scanning “Select” Key
and then activate the switch connected to Port 1.
b. Two-switch Scanning: Tap the box next to Scanning “Select” Key
and then activate the switch connected to Port 1. Then, tap the box
next to Scanning “Next” Key and activate the switch connected to
Port 2.
6. If desired, adjust other settings to your preference.
7. Scroll to Save Preferences > return to your Home Board.

10
FCC Compliance Information
Note: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.

11
LAMP Words for Life ™ is a trademark of PRC-Saltillo. All rights reserved.
The LAMP Treatment Approach is a trademark of the Center for AAC &
Autism. All rights reserved. For more information about LAMP and its
features, please see https://aacapps.com/support
TouchChat ® is a registered trademark of PRC-Saltillo. For more
information about TouchChat and its features, https://touchchatapp.com/
support/articles/faq/quick-reference-guide
All rights reserved. SymbolsStix ®, Copyright 2020, SymbolStix, LLC. All
rights reserved. Used with permission.

User information and notes
Vocabulary account username:
Vocabulary account password:
Apple username:
Apple password:
Notes:
12

13

14

15

Join in the conversation…
Connect with us for resources, contests and more!
Need Help?
877.392.2299 Option 3
[e-mail]
talktometechnologies.com (click Support)
16
