Talkase T1 User manual

4.4 Contacts
Press "OK" to enter the contacts list when in the
contacts menu，press top or bottom key to select SIM
card contacts, Bluetooth contacts and add contacts.
4.4.1 Add Contacts
Press "OK" will show the pop-up circle in add
contacts menu, press top or bottom key to input
name and number to the input area, press “OK”to
save or cancel. Press “#” to choose input method.
4.4.2 Call SIM Card Contacts
Press top and bottom key to choose contacts from
SIM Card Contacts, then press “OK”will show “Find
Contacts”, “Send Message”, “Call the Contacts”,
“Edit Contacts”,”Delete Contacts”, “Choose the Save
Area”and so on. Press top or bottom key to select
“Call the Contacts”.
Play and Delete Record List
Press top or bottom key to select, press OK to enter
the record list, press top or bottom key to choose
that you want to play, press “OK”will show “play”or
“delete” , select by press top or bottom key, press
“OK”to confirm.
4.3 Bluetooth
4.3.1 Instrcution of Bluetooth
Open the Bluetooth, search the Talkase Bluetooth on
your smart phone, then pair it.
1. Instruction Before Use
1.1. Install SIM Card
1.2. Charging Method
2. Instruction of Buttons
3. Starter
3.1. Standby Interface
3.2. How to Use Dialer
4. Menu
4.1. Music Player
4.2. Record
4.3. Bluetooth
4.4. Contacts
4.5. Message
4.6. Call History
4.7. Setting
4.8. Calculator
4.9. Anti-Lost
4.10. Shortcut Key
Contents
1.1 Install SIM Card
The SIM card slot is on the right side of the back of
Talkase, first remove the cover as instructed, then
put the SIM card into the slot, close the cover, the
installing is done.
Only support micro SIM card.
1.2 Charging Method
Let the four metal contacts of charging slip
correspond to the four of Talkase, then press the
charging clip to ensure it is tightly attached to the
back of Talkase, connect the computer using USB
cable or an adapter for charging. Take out the clip
from down to up in vertical direction, sliding way is
not suggested for protecting the four contacts in
charging clip.
3.1.Standby Interface
Long press the power key to start up, standby
interface show the internet signal, Battery Capacity,
and the message notification when there is message
you have not read. When open the Bluetooth it will
show on the interface too. The middle of the
interface is the present time. Press top or bottom
menu key for changing different function.
Lock and Unlock
Press power on/off key and "#" simultaneously to
lock or unlock.
3.2 How to Use Dialer
Press the number key can make a call directly, or dial
by GSM SIM card, or use the BT call to make a dial
after connecting with your smart phone through
Bluetooth.（There must be a SIM card in your smart
phone, how to pair the Bluetooth please refer to
BT3.5）. If there is error in input number using the
delete key to correct.
4.1 Bluetooth Music Control
After connecting with the smart phone by Bluetooth
can use the music player.（Note：Only can control
music but can not play, control smart phone to play
the previous and next one.)
4.1.1 How to control music
Press "OK" to enter the function interface when in
the music control menu, press top and bottom key
to select the previous and the next one, press "OK"
to play or pause.
4.2 Record
Begin Recording
Press "OK" to enter the function interface when in
the recording menu, press top and bottom key to
select the function you want, choose the record
mark and begin to record.
Save/Pause/Give up
When recording the screen will show the record
time, press “OK”will show“save/pause/give up ”,
select function by press top and bottom key, press
“OK”to confirm, press recording key to continue
recording.
4.4.3 Dialer to Bluetooth Contacts
Press “OK”to enter the Bluetooth contacts, another
press to choose different functions, press top or
bottom key to “Text Message”, “Dial to the Contacts
“, “Save to the phone book”.
4.5 Message
Press "OK" to enter the message operation interface
when in the message menu, press top or bottom key
to “Text Message”,“Inbox”,“Drafts”,“Outbox”.
4.5.1 Text and Send Message
Choose “Text Message”, press “OK”when the
message is done and the screen will show “send”,
recipient could be choosed from contacts or input
number directly, press “OK”to send. Press top or
bottom key could choose“Save Message”,
”Punctuation”, “Input Method”and so on.
4.5.2 Inbox
Choose “Inbox”, press “OK” to enter the list, press
top and bottom key to select, press “OK”to read,
press again to “Reply”, “Add Contacts”, “Delete”,
“Forward”, “Dial”and so on.
4.5.3 Outbox
Choose “Outbox”, Press “OK” to the list, press top or
bottom key to choose, and press “OK”to read, press
“OK”again to “Forward”or “Delete”.
4.5.4 Drafts
Choose “Drafts”, press “OK”to the list, press top or
bottom key to choose, and press “OK”to read, “OK”
again to “Send”, ”Edit”, “Delete”and so on.
4.6 Call History
Press “OK” to the call history, another press to
choose and “OK”again to “Add contacts”, “Dial “,
“Send Message”, “Delete Call History ”.
4.7 Setting
4.7.1 Alarm Clock Setting
Enter setting-alarm, press “OK” begin to set time,
Press “OK”could enjoy the following functions after
setting done: “Ringtone Setting”, “Repeat Setting”,
“Save Alarm Clock”and so on. The circle could
become solid after successful setting.
4.7.1.1
How to turn off
Enter setting-Alarm Clock, choose the one you want
to delete, press “OK”to confirm, the circle would be
hollow.
4.7.2 Phone Setting
This including: “Date Setting”, “Time Setting”, “Zone
Setting”, “Time Format Setting”, “System Language
Setting”, “Ringtone Setting”, “Volume Setting”,
“Operator Manul Setting”, “Screen display Time
Setting”, Details See Below：
4.7.3 Profiles
It including: “Standard Mode”,“Silent Mode”,
“Conference Mode”, “Outdoors Mode”, “Airplane
Mode”. Press “OK” to confirm the one you like.
4.7.4 Restore Factory Setting
Enter setting- restore factory settings, press “OK” get
a notification and “OK” again could accomplish the
setting, press return button to cancel. It can be
restored to the initial status.
4.8 Calculator
Long press calculator key to enter when in standby
interface, then Talkase will be a calculator, input
number to count directly.
Anti-Lost
Press "OK" to enter Anti-Lost function, another press
to switch on or off (Only available after connected by
bluetooth).
Shortcut Key
1. When the Bluetooth is turned off, press return
botton on standby interface, "Connect by..." comes
out, press "OK" can activate Bluetooth rapidly,
otherwise it will be turned on by press the return
botton when the Bluetooth is turned off.
2. Press “#” could exchange input method, press “*”
could choose different punctuation mark when
texting message or edit the contacts’ name.
3. Press OK key to turn on/off the loudspeaker while
in the call status.

4.4 Contacts
Press "OK" to enter the contacts list when in the
contacts menu，press top or bottom key to select SIM
card contacts, Bluetooth contacts and add contacts.
4.4.1 Add Contacts
Press "OK" will show the pop-up circle in add
contacts menu, press top or bottom key to input
name and number to the input area, press “OK”to
save or cancel. Press “#” to choose input method.
4.4.2 Call SIM Card Contacts
Press top and bottom key to choose contacts from
SIM Card Contacts, then press “OK”will show “Find
Contacts”, “Send Message”, “Call the Contacts”,
“Edit Contacts”,”Delete Contacts”, “Choose the Save
Area”and so on. Press top or bottom key to select
“Call the Contacts”.
Play and Delete Record List
Press top or bottom key to select, press OK to enter
the record list, press top or bottom key to choose
that you want to play, press “OK”will show “play”or
“delete” , select by press top or bottom key, press
“OK”to confirm.
4.3 Bluetooth
4.3.1 Instrcution of Bluetooth
Open the Bluetooth, search the Talkase Bluetooth on
your smart phone, then pair it.
1. Instruction Before Use
1.1. Install SIM Card
1.2. Charging Method
2. Instruction of Buttons
3. Starter
3.1. Standby Interface
3.2. How to Use Dialer
4. Menu
4.1. Music Player
4.2. Record
4.3. Bluetooth
4.4. Contacts
4.5. Message
4.6. Call History
4.7. Setting
4.8. Calculator
4.9. Anti-Lost
4.10. Shortcut Key
1.1 Install SIM Card
The SIM card slot is on the right side of the back of
Talkase, first remove the cover as instructed, then
put the SIM card into the slot, close the cover, the
installing is done.
Only support micro SIM card.
Instruction before Use
SIM
Attention the
direction to insert card
1.2 Charging Method
Let the four metal contacts of charging slip
correspond to the four of Talkase, then press the
charging clip to ensure it is tightly attached to the
back of Talkase, connect the computer using USB
cable or an adapter for charging. Take out the clip
from down to up in vertical direction, sliding way is
not suggested for protecting the four contacts in
charging clip.
3.1.Standby Interface
Long press the power key to start up, standby
interface show the internet signal, Battery Capacity,
and the message notification when there is message
you have not read. When open the Bluetooth it will
show on the interface too. The middle of the
interface is the present time. Press top or bottom
menu key for changing different function.
Lock and Unlock
Press power on/off key and "#" simultaneously to
lock or unlock.
3.2 How to Use Dialer
Press the number key can make a call directly, or dial
by GSM SIM card, or use the BT call to make a dial
after connecting with your smart phone through
Bluetooth.（There must be a SIM card in your smart
phone, how to pair the Bluetooth please refer to
BT3.5）. If there is error in input number using the
delete key to correct.
4.1 Bluetooth Music Control
After connecting with the smart phone by Bluetooth
can use the music player.（Note：Only can control
music but can not play, control smart phone to play
the previous and next one.)
4.1.1 How to control music
Press "OK" to enter the function interface when in
the music control menu, press top and bottom key
to select the previous and the next one, press "OK"
to play or pause.
4.2 Record
Begin Recording
Press "OK" to enter the function interface when in
the recording menu, press top and bottom key to
select the function you want, choose the record
mark and begin to record.
Save/Pause/Give up
When recording the screen will show the record
time, press “OK”will show“save/pause/give up ”,
select function by press top and bottom key, press
“OK”to confirm, press recording key to continue
recording.
4.4.3 Dialer to Bluetooth Contacts
Press “OK”to enter the Bluetooth contacts, another
press to choose different functions, press top or
bottom key to “Text Message”, “Dial to the Contacts
“, “Save to the phone book”.
4.5 Message
Press "OK" to enter the message operation interface
when in the message menu, press top or bottom key
to “Text Message”,“Inbox”,“Drafts”,“Outbox”.
4.5.1 Text and Send Message
Choose “Text Message”, press “OK”when the
message is done and the screen will show “send”,
recipient could be choosed from contacts or input
number directly, press “OK”to send. Press top or
bottom key could choose“Save Message”,
”Punctuation”, “Input Method”and so on.
4.5.2 Inbox
Choose “Inbox”, press “OK” to enter the list, press
top and bottom key to select, press “OK”to read,
press again to “Reply”, “Add Contacts”, “Delete”,
“Forward”, “Dial”and so on.
4.5.3 Outbox
Choose “Outbox”, Press “OK” to the list, press top or
bottom key to choose, and press “OK”to read, press
“OK”again to “Forward”or “Delete”.
4.5.4 Drafts
Choose “Drafts”, press “OK”to the list, press top or
bottom key to choose, and press “OK”to read, “OK”
again to “Send”, ”Edit”, “Delete”and so on.
4.6 Call History
Press “OK” to the call history, another press to
choose and “OK”again to “Add contacts”, “Dial “,
“Send Message”, “Delete Call History ”.
4.7 Setting
4.7.1 Alarm Clock Setting
Enter setting-alarm, press “OK” begin to set time,
Press “OK”could enjoy the following functions after
setting done: “Ringtone Setting”, “Repeat Setting”,
“Save Alarm Clock”and so on. The circle could
become solid after successful setting.
4.7.1.1
How to turn off
Enter setting-Alarm Clock, choose the one you want
to delete, press “OK”to confirm, the circle would be
hollow.
4.7.2 Phone Setting
This including: “Date Setting”, “Time Setting”, “Zone
Setting”, “Time Format Setting”, “System Language
Setting”, “Ringtone Setting”, “Volume Setting”,
“Operator Manul Setting”, “Screen display Time
Setting”, Details See Below：
4.7.3 Profiles
It including: “Standard Mode”,“Silent Mode”,
“Conference Mode”, “Outdoors Mode”, “Airplane
Mode”. Press “OK” to confirm the one you like.
4.7.4 Restore Factory Setting
Enter setting- restore factory settings, press “OK” get
a notification and “OK” again could accomplish the
setting, press return button to cancel. It can be
restored to the initial status.
4.8 Calculator
Long press calculator key to enter when in standby
interface, then Talkase will be a calculator, input
number to count directly.
Anti-Lost
Press "OK" to enter Anti-Lost function, another press
to switch on or off (Only available after connected by
bluetooth).
Shortcut Key
1. When the Bluetooth is turned off, press return
botton on standby interface, "Connect by..." comes
out, press "OK" can activate Bluetooth rapidly,
otherwise it will be turned on by press the return
botton when the Bluetooth is turned off.
2. Press “#” could exchange input method, press “*”
could choose different punctuation mark when
texting message or edit the contacts’ name.
3. Press OK key to turn on/off the loudspeaker while
in the call status.
02

4.4 Contacts
Press "OK" to enter the contacts list when in the
contacts menu，press top or bottom key to select SIM
card contacts, Bluetooth contacts and add contacts.
4.4.1 Add Contacts
Press "OK" will show the pop-up circle in add
contacts menu, press top or bottom key to input
name and number to the input area, press “OK”to
save or cancel. Press “#” to choose input method.
4.4.2 Call SIM Card Contacts
Press top and bottom key to choose contacts from
SIM Card Contacts, then press “OK”will show “Find
Contacts”, “Send Message”, “Call the Contacts”,
“Edit Contacts”,”Delete Contacts”, “Choose the Save
Area”and so on. Press top or bottom key to select
“Call the Contacts”.
Play and Delete Record List
Press top or bottom key to select, press OK to enter
the record list, press top or bottom key to choose
that you want to play, press “OK”will show “play”or
“delete” , select by press top or bottom key, press
“OK”to confirm.
4.3 Bluetooth
4.3.1 Instrcution of Bluetooth
Open the Bluetooth, search the Talkase Bluetooth on
your smart phone, then pair it.
1. Instruction Before Use
1.1. Install SIM Card
1.2. Charging Method
2. Instruction of Buttons
3. Starter
3.1. Standby Interface
3.2. How to Use Dialer
4. Menu
4.1. Music Player
4.2. Record
4.3. Bluetooth
4.4. Contacts
4.5. Message
4.6. Call History
4.7. Setting
4.8. Calculator
4.9. Anti-Lost
4.10. Shortcut Key
1.1 Install SIM Card
The SIM card slot is on the right side of the back of
Talkase, first remove the cover as instructed, then
put the SIM card into the slot, close the cover, the
installing is done.
Only support micro SIM card.
1.2 Charging Method
Let the four metal contacts of charging slip
correspond to the four of Talkase, then press the
charging clip to ensure it is tightly attached to the
back of Talkase, connect the computer using USB
cable or an adapter for charging. Take out the clip
from down to up in vertical direction, sliding way is
not suggested for protecting the four contacts in
charging clip.
Wrong way of installing
charging clip
Right way of installing
charging clip
Install from
virtical direction
Slide up and down
is not allowed
3.1.Standby Interface
Long press the power key to start up, standby
interface show the internet signal, Battery Capacity,
and the message notification when there is message
you have not read. When open the Bluetooth it will
show on the interface too. The middle of the
interface is the present time. Press top or bottom
menu key for changing different function.
Lock and Unlock
Press power on/off key and "#" simultaneously to
lock or unlock.
3.2 How to Use Dialer
Press the number key can make a call directly, or dial
by GSM SIM card, or use the BT call to make a dial
after connecting with your smart phone through
Bluetooth.（There must be a SIM card in your smart
phone, how to pair the Bluetooth please refer to
BT3.5）. If there is error in input number using the
delete key to correct.
4.1 Bluetooth Music Control
After connecting with the smart phone by Bluetooth
can use the music player.（Note：Only can control
music but can not play, control smart phone to play
the previous and next one.)
4.1.1 How to control music
Press "OK" to enter the function interface when in
the music control menu, press top and bottom key
to select the previous and the next one, press "OK"
to play or pause.
4.2 Record
Begin Recording
Press "OK" to enter the function interface when in
the recording menu, press top and bottom key to
select the function you want, choose the record
mark and begin to record.
Save/Pause/Give up
When recording the screen will show the record
time, press “OK”will show“save/pause/give up ”,
select function by press top and bottom key, press
“OK”to confirm, press recording key to continue
recording.
4.4.3 Dialer to Bluetooth Contacts
Press “OK”to enter the Bluetooth contacts, another
press to choose different functions, press top or
bottom key to “Text Message”, “Dial to the Contacts
“, “Save to the phone book”.
4.5 Message
Press "OK" to enter the message operation interface
when in the message menu, press top or bottom key
to “Text Message”,“Inbox”,“Drafts”,“Outbox”.
4.5.1 Text and Send Message
Choose “Text Message”, press “OK”when the
message is done and the screen will show “send”,
recipient could be choosed from contacts or input
number directly, press “OK”to send. Press top or
bottom key could choose“Save Message”,
”Punctuation”, “Input Method”and so on.
4.5.2 Inbox
Choose “Inbox”, press “OK” to enter the list, press
top and bottom key to select, press “OK”to read,
press again to “Reply”, “Add Contacts”, “Delete”,
“Forward”, “Dial”and so on.
4.5.3 Outbox
Choose “Outbox”, Press “OK” to the list, press top or
bottom key to choose, and press “OK”to read, press
“OK”again to “Forward”or “Delete”.
4.5.4 Drafts
Choose “Drafts”, press “OK”to the list, press top or
bottom key to choose, and press “OK”to read, “OK”
again to “Send”, ”Edit”, “Delete”and so on.
4.6 Call History
Press “OK” to the call history, another press to
choose and “OK”again to “Add contacts”, “Dial “,
“Send Message”, “Delete Call History ”.
4.7 Setting
4.7.1 Alarm Clock Setting
Enter setting-alarm, press “OK” begin to set time,
Press “OK”could enjoy the following functions after
setting done: “Ringtone Setting”, “Repeat Setting”,
“Save Alarm Clock”and so on. The circle could
become solid after successful setting.
4.7.1.1
How to turn off
Enter setting-Alarm Clock, choose the one you want
to delete, press “OK”to confirm, the circle would be
hollow.
4.7.2 Phone Setting
This including: “Date Setting”, “Time Setting”, “Zone
Setting”, “Time Format Setting”, “System Language
Setting”, “Ringtone Setting”, “Volume Setting”,
“Operator Manul Setting”, “Screen display Time
Setting”, Details See Below：
4.7.3 Profiles
It including: “Standard Mode”,“Silent Mode”,
“Conference Mode”, “Outdoors Mode”, “Airplane
Mode”. Press “OK” to confirm the one you like.
4.7.4 Restore Factory Setting
Enter setting- restore factory settings, press “OK” get
a notification and “OK” again could accomplish the
setting, press return button to cancel. It can be
restored to the initial status.
4.8 Calculator
Long press calculator key to enter when in standby
interface, then Talkase will be a calculator, input
number to count directly.
Anti-Lost
Press "OK" to enter Anti-Lost function, another press
to switch on or off (Only available after connected by
bluetooth).
Shortcut Key
1. When the Bluetooth is turned off, press return
botton on standby interface, "Connect by..." comes
out, press "OK" can activate Bluetooth rapidly,
otherwise it will be turned on by press the return
botton when the Bluetooth is turned off.
2. Press “#” could exchange input method, press “*”
could choose different punctuation mark when
texting message or edit the contacts’ name.
3. Press OK key to turn on/off the loudspeaker while
in the call status.
03

4.4 Contacts
Press "OK" to enter the contacts list when in the
contacts menu，press top or bottom key to select SIM
card contacts, Bluetooth contacts and add contacts.
4.4.1 Add Contacts
Press "OK" will show the pop-up circle in add
contacts menu, press top or bottom key to input
name and number to the input area, press “OK”to
save or cancel. Press “#” to choose input method.
4.4.2 Call SIM Card Contacts
Press top and bottom key to choose contacts from
SIM Card Contacts, then press “OK”will show “Find
Contacts”, “Send Message”, “Call the Contacts”,
“Edit Contacts”,”Delete Contacts”, “Choose the Save
Area”and so on. Press top or bottom key to select
“Call the Contacts”.
Play and Delete Record List
Press top or bottom key to select, press OK to enter
the record list, press top or bottom key to choose
that you want to play, press “OK”will show “play”or
“delete” , select by press top or bottom key, press
“OK”to confirm.
4.3 Bluetooth
4.3.1 Instrcution of Bluetooth
Open the Bluetooth, search the Talkase Bluetooth on
your smart phone, then pair it.
1. Instruction Before Use
1.1. Install SIM Card
1.2. Charging Method
2. Instruction of Buttons
3. Starter
3.1. Standby Interface
3.2. How to Use Dialer
4. Menu
4.1. Music Player
4.2. Record
4.3. Bluetooth
4.4. Contacts
4.5. Message
4.6. Call History
4.7. Setting
4.8. Calculator
4.9. Anti-Lost
4.10. Shortcut Key
1.1 Install SIM Card
The SIM card slot is on the right side of the back of
Talkase, first remove the cover as instructed, then
put the SIM card into the slot, close the cover, the
installing is done.
Only support micro SIM card.
Instruction of Buttons
1.2 Charging Method
Let the four metal contacts of charging slip
correspond to the four of Talkase, then press the
charging clip to ensure it is tightly attached to the
back of Talkase, connect the computer using USB
cable or an adapter for charging. Take out the clip
from down to up in vertical direction, sliding way is
not suggested for protecting the four contacts in
charging clip.
Return Button
ON/OFF
Reject call
Main interface
Confirm
Bottom select
menu key
Top select
menu key
Bluetooth
dialer
Long press
to enter
voice mail
Screen Lock Key
GSM dialer
3.1.Standby Interface
Long press the power key to start up, standby
interface show the internet signal, Battery Capacity,
and the message notification when there is message
you have not read. When open the Bluetooth it will
show on the interface too. The middle of the
interface is the present time. Press top or bottom
menu key for changing different function.
Lock and Unlock
Press power on/off key and "#" simultaneously to
lock or unlock.
3.2 How to Use Dialer
Press the number key can make a call directly, or dial
by GSM SIM card, or use the BT call to make a dial
after connecting with your smart phone through
Bluetooth.（There must be a SIM card in your smart
phone, how to pair the Bluetooth please refer to
BT3.5）. If there is error in input number using the
delete key to correct.
4.1 Bluetooth Music Control
After connecting with the smart phone by Bluetooth
can use the music player.（Note：Only can control
music but can not play, control smart phone to play
the previous and next one.)
4.1.1 How to control music
Press "OK" to enter the function interface when in
the music control menu, press top and bottom key
to select the previous and the next one, press "OK"
to play or pause.
4.2 Record
Begin Recording
Press "OK" to enter the function interface when in
the recording menu, press top and bottom key to
select the function you want, choose the record
mark and begin to record.
Save/Pause/Give up
When recording the screen will show the record
time, press “OK”will show“save/pause/give up ”,
select function by press top and bottom key, press
“OK”to confirm, press recording key to continue
recording.
4.4.3 Dialer to Bluetooth Contacts
Press “OK”to enter the Bluetooth contacts, another
press to choose different functions, press top or
bottom key to “Text Message”, “Dial to the Contacts
“, “Save to the phone book”.
4.5 Message
Press "OK" to enter the message operation interface
when in the message menu, press top or bottom key
to “Text Message”,“Inbox”,“Drafts”,“Outbox”.
4.5.1 Text and Send Message
Choose “Text Message”, press “OK”when the
message is done and the screen will show “send”,
recipient could be choosed from contacts or input
number directly, press “OK”to send. Press top or
bottom key could choose“Save Message”,
”Punctuation”, “Input Method”and so on.
4.5.2 Inbox
Choose “Inbox”, press “OK” to enter the list, press
top and bottom key to select, press “OK”to read,
press again to “Reply”, “Add Contacts”, “Delete”,
“Forward”, “Dial”and so on.
4.5.3 Outbox
Choose “Outbox”, Press “OK” to the list, press top or
bottom key to choose, and press “OK”to read, press
“OK”again to “Forward”or “Delete”.
4.5.4 Drafts
Choose “Drafts”, press “OK”to the list, press top or
bottom key to choose, and press “OK”to read, “OK”
again to “Send”, ”Edit”, “Delete”and so on.
4.6 Call History
Press “OK” to the call history, another press to
choose and “OK”again to “Add contacts”, “Dial “,
“Send Message”, “Delete Call History ”.
4.7 Setting
4.7.1 Alarm Clock Setting
Enter setting-alarm, press “OK” begin to set time,
Press “OK”could enjoy the following functions after
setting done: “Ringtone Setting”, “Repeat Setting”,
“Save Alarm Clock”and so on. The circle could
become solid after successful setting.
4.7.1.1
How to turn off
Enter setting-Alarm Clock, choose the one you want
to delete, press “OK”to confirm, the circle would be
hollow.
4.7.2 Phone Setting
This including: “Date Setting”, “Time Setting”, “Zone
Setting”, “Time Format Setting”, “System Language
Setting”, “Ringtone Setting”, “Volume Setting”,
“Operator Manul Setting”, “Screen display Time
Setting”, Details See Below：
4.7.3 Profiles
It including: “Standard Mode”,“Silent Mode”,
“Conference Mode”, “Outdoors Mode”, “Airplane
Mode”. Press “OK” to confirm the one you like.
4.7.4 Restore Factory Setting
Enter setting- restore factory settings, press “OK” get
a notification and “OK” again could accomplish the
setting, press return button to cancel. It can be
restored to the initial status.
4.8 Calculator
Long press calculator key to enter when in standby
interface, then Talkase will be a calculator, input
number to count directly.
Anti-Lost
Press "OK" to enter Anti-Lost function, another press
to switch on or off (Only available after connected by
bluetooth).
Long press to
calculator
Short press to
delete
Shortcut Key
1. When the Bluetooth is turned off, press return
botton on standby interface, "Connect by..." comes
out, press "OK" can activate Bluetooth rapidly,
otherwise it will be turned on by press the return
botton when the Bluetooth is turned off.
2. Press “#” could exchange input method, press “*”
could choose different punctuation mark when
texting message or edit the contacts’ name.
3. Press OK key to turn on/off the loudspeaker while
in the call status.
04

4.4 Contacts
Press "OK" to enter the contacts list when in the
contacts menu，press top or bottom key to select SIM
card contacts, Bluetooth contacts and add contacts.
4.4.1 Add Contacts
Press "OK" will show the pop-up circle in add
contacts menu, press top or bottom key to input
name and number to the input area, press “OK”to
save or cancel. Press “#” to choose input method.
4.4.2 Call SIM Card Contacts
Press top and bottom key to choose contacts from
SIM Card Contacts, then press “OK”will show “Find
Contacts”, “Send Message”, “Call the Contacts”,
“Edit Contacts”,”Delete Contacts”, “Choose the Save
Area”and so on. Press top or bottom key to select
“Call the Contacts”.
Play and Delete Record List
Press top or bottom key to select, press OK to enter
the record list, press top or bottom key to choose
that you want to play, press “OK”will show “play”or
“delete” , select by press top or bottom key, press
“OK”to confirm.
4.3 Bluetooth
4.3.1 Instrcution of Bluetooth
Open the Bluetooth, search the Talkase Bluetooth on
your smart phone, then pair it.
1. Instruction Before Use
1.1. Install SIM Card
1.2. Charging Method
2. Instruction of Buttons
3. Starter
3.1. Standby Interface
3.2. How to Use Dialer
4. Menu
4.1. Music Player
4.2. Record
4.3. Bluetooth
4.4. Contacts
4.5. Message
4.6. Call History
4.7. Setting
4.8. Calculator
4.9. Anti-Lost
4.10. Shortcut Key
1.1 Install SIM Card
The SIM card slot is on the right side of the back of
Talkase, first remove the cover as instructed, then
put the SIM card into the slot, close the cover, the
installing is done.
Only support micro SIM card.
Starter
1.2 Charging Method
Let the four metal contacts of charging slip
correspond to the four of Talkase, then press the
charging clip to ensure it is tightly attached to the
back of Talkase, connect the computer using USB
cable or an adapter for charging. Take out the clip
from down to up in vertical direction, sliding way is
not suggested for protecting the four contacts in
charging clip.
3.1.Standby Interface
Long press the power key to start up, standby
interface show the internet signal, Battery Capacity,
and the message notification when there is message
you have not read. When open the Bluetooth it will
show on the interface too. The middle of the
interface is the present time. Press top or bottom
menu key for changing different function.
Lock and Unlock
Press power on/off key and "#" simultaneously to
lock or unlock.
3.2 How to Use Dialer
Press the number key can make a call directly, or dial
by GSM SIM card, or use the BT call to make a dial
after connecting with your smart phone through
Bluetooth.（There must be a SIM card in your smart
phone, how to pair the Bluetooth please refer to
BT3.5）. If there is error in input number using the
delete key to correct.
4.1 Bluetooth Music Control
After connecting with the smart phone by Bluetooth
can use the music player.（Note：Only can control
music but can not play, control smart phone to play
the previous and next one.)
4.1.1 How to control music
Press "OK" to enter the function interface when in
the music control menu, press top and bottom key
to select the previous and the next one, press "OK"
to play or pause.
4.2 Record
Begin Recording
Press "OK" to enter the function interface when in
the recording menu, press top and bottom key to
select the function you want, choose the record
mark and begin to record.
Save/Pause/Give up
When recording the screen will show the record
time, press “OK”will show“save/pause/give up ”,
select function by press top and bottom key, press
“OK”to confirm, press recording key to continue
recording.
4.4.3 Dialer to Bluetooth Contacts
Press “OK”to enter the Bluetooth contacts, another
press to choose different functions, press top or
bottom key to “Text Message”, “Dial to the Contacts
“, “Save to the phone book”.
4.5 Message
Press "OK" to enter the message operation interface
when in the message menu, press top or bottom key
to “Text Message”,“Inbox”,“Drafts”,“Outbox”.
4.5.1 Text and Send Message
Choose “Text Message”, press “OK”when the
message is done and the screen will show “send”,
recipient could be choosed from contacts or input
number directly, press “OK”to send. Press top or
bottom key could choose“Save Message”,
”Punctuation”, “Input Method”and so on.
4.5.2 Inbox
Choose “Inbox”, press “OK” to enter the list, press
top and bottom key to select, press “OK”to read,
press again to “Reply”, “Add Contacts”, “Delete”,
“Forward”, “Dial”and so on.
4.5.3 Outbox
Choose “Outbox”, Press “OK” to the list, press top or
bottom key to choose, and press “OK”to read, press
“OK”again to “Forward”or “Delete”.
4.5.4 Drafts
Choose “Drafts”, press “OK”to the list, press top or
bottom key to choose, and press “OK”to read, “OK”
again to “Send”, ”Edit”, “Delete”and so on.
4.6 Call History
Press “OK” to the call history, another press to
choose and “OK”again to “Add contacts”, “Dial “,
“Send Message”, “Delete Call History ”.
4.7 Setting
4.7.1 Alarm Clock Setting
Enter setting-alarm, press “OK” begin to set time,
Press “OK”could enjoy the following functions after
setting done: “Ringtone Setting”, “Repeat Setting”,
“Save Alarm Clock”and so on. The circle could
become solid after successful setting.
4.7.1.1
How to turn off
Enter setting-Alarm Clock, choose the one you want
to delete, press “OK”to confirm, the circle would be
hollow.
4.7.2 Phone Setting
This including: “Date Setting”, “Time Setting”, “Zone
Setting”, “Time Format Setting”, “System Language
Setting”, “Ringtone Setting”, “Volume Setting”,
“Operator Manul Setting”, “Screen display Time
Setting”, Details See Below：
4.7.3 Profiles
It including: “Standard Mode”,“Silent Mode”,
“Conference Mode”, “Outdoors Mode”, “Airplane
Mode”. Press “OK” to confirm the one you like.
4.7.4 Restore Factory Setting
Enter setting- restore factory settings, press “OK” get
a notification and “OK” again could accomplish the
setting, press return button to cancel. It can be
restored to the initial status.
4.8 Calculator
Long press calculator key to enter when in standby
interface, then Talkase will be a calculator, input
number to count directly.
Anti-Lost
Press "OK" to enter Anti-Lost function, another press
to switch on or off (Only available after connected by
bluetooth).
Shortcut Key
1. When the Bluetooth is turned off, press return
botton on standby interface, "Connect by..." comes
out, press "OK" can activate Bluetooth rapidly,
otherwise it will be turned on by press the return
botton when the Bluetooth is turned off.
2. Press “#” could exchange input method, press “*”
could choose different punctuation mark when
texting message or edit the contacts’ name.
3. Press OK key to turn on/off the loudspeaker while
in the call status.
05

4.4 Contacts
Press "OK" to enter the contacts list when in the
contacts menu，press top or bottom key to select SIM
card contacts, Bluetooth contacts and add contacts.
4.4.1 Add Contacts
Press "OK" will show the pop-up circle in add
contacts menu, press top or bottom key to input
name and number to the input area, press “OK”to
save or cancel. Press “#” to choose input method.
4.4.2 Call SIM Card Contacts
Press top and bottom key to choose contacts from
SIM Card Contacts, then press “OK”will show “Find
Contacts”, “Send Message”, “Call the Contacts”,
“Edit Contacts”,”Delete Contacts”, “Choose the Save
Area”and so on. Press top or bottom key to select
“Call the Contacts”.
Play and Delete Record List
Press top or bottom key to select, press OK to enter
the record list, press top or bottom key to choose
that you want to play, press “OK”will show “play”or
“delete” , select by press top or bottom key, press
“OK”to confirm.
4.3 Bluetooth
4.3.1 Instrcution of Bluetooth
Open the Bluetooth, search the Talkase Bluetooth on
your smart phone, then pair it.
1. Instruction Before Use
1.1. Install SIM Card
1.2. Charging Method
2. Instruction of Buttons
3. Starter
3.1. Standby Interface
3.2. How to Use Dialer
4. Menu
4.1. Music Player
4.2. Record
4.3. Bluetooth
4.4. Contacts
4.5. Message
4.6. Call History
4.7. Setting
4.8. Calculator
4.9. Anti-Lost
4.10. Shortcut Key
1.1 Install SIM Card
The SIM card slot is on the right side of the back of
Talkase, first remove the cover as instructed, then
put the SIM card into the slot, close the cover, the
installing is done.
Only support micro SIM card.
Menu
1.2 Charging Method
Let the four metal contacts of charging slip
correspond to the four of Talkase, then press the
charging clip to ensure it is tightly attached to the
back of Talkase, connect the computer using USB
cable or an adapter for charging. Take out the clip
from down to up in vertical direction, sliding way is
not suggested for protecting the four contacts in
charging clip.
3.1.Standby Interface
Long press the power key to start up, standby
interface show the internet signal, Battery Capacity,
and the message notification when there is message
you have not read. When open the Bluetooth it will
show on the interface too. The middle of the
interface is the present time. Press top or bottom
menu key for changing different function.
Lock and Unlock
Press power on/off key and "#" simultaneously to
lock or unlock.
3.2 How to Use Dialer
Press the number key can make a call directly, or dial
by GSM SIM card, or use the BT call to make a dial
after connecting with your smart phone through
Bluetooth.（There must be a SIM card in your smart
phone, how to pair the Bluetooth please refer to
BT3.5）. If there is error in input number using the
delete key to correct.
4.1 Bluetooth Music Control
After connecting with the smart phone by Bluetooth
can use the music player.（Note：Only can control
music but can not play, control smart phone to play
the previous and next one.)
4.1.1 How to control music
Press "OK" to enter the function interface when in
the music control menu, press top and bottom key
to select the previous and the next one, press "OK"
to play or pause.
4.2 Record
Begin Recording
Press "OK" to enter the function interface when in
the recording menu, press top and bottom key to
select the function you want, choose the record
mark and begin to record.
Save/Pause/Give up
When recording the screen will show the record
time, press “OK”will show“save/pause/give up ”,
select function by press top and bottom key, press
“OK”to confirm, press recording key to continue
recording.
Music Play Previous Play Next Previous NextPause
4.4.3 Dialer to Bluetooth Contacts
Press “OK”to enter the Bluetooth contacts, another
press to choose different functions, press top or
bottom key to “Text Message”, “Dial to the Contacts
“, “Save to the phone book”.
4.5 Message
Press "OK" to enter the message operation interface
when in the message menu, press top or bottom key
to “Text Message”,“Inbox”,“Drafts”,“Outbox”.
4.5.1 Text and Send Message
Choose “Text Message”, press “OK”when the
message is done and the screen will show “send”,
recipient could be choosed from contacts or input
number directly, press “OK”to send. Press top or
bottom key could choose“Save Message”,
”Punctuation”, “Input Method”and so on.
4.5.2 Inbox
Choose “Inbox”, press “OK” to enter the list, press
top and bottom key to select, press “OK”to read,
press again to “Reply”, “Add Contacts”, “Delete”,
“Forward”, “Dial”and so on.
4.5.3 Outbox
Choose “Outbox”, Press “OK” to the list, press top or
bottom key to choose, and press “OK”to read, press
“OK”again to “Forward”or “Delete”.
4.5.4 Drafts
Choose “Drafts”, press “OK”to the list, press top or
bottom key to choose, and press “OK”to read, “OK”
again to “Send”, ”Edit”, “Delete”and so on.
4.6 Call History
Press “OK” to the call history, another press to
choose and “OK”again to “Add contacts”, “Dial “,
“Send Message”, “Delete Call History ”.
4.7 Setting
4.7.1 Alarm Clock Setting
Enter setting-alarm, press “OK” begin to set time,
Press “OK”could enjoy the following functions after
setting done: “Ringtone Setting”, “Repeat Setting”,
“Save Alarm Clock”and so on. The circle could
become solid after successful setting.
4.7.1.1
How to turn off
Enter setting-Alarm Clock, choose the one you want
to delete, press “OK”to confirm, the circle would be
hollow.
4.7.2 Phone Setting
This including: “Date Setting”, “Time Setting”, “Zone
Setting”, “Time Format Setting”, “System Language
Setting”, “Ringtone Setting”, “Volume Setting”,
“Operator Manul Setting”, “Screen display Time
Setting”, Details See Below：
4.7.3 Profiles
It including: “Standard Mode”,“Silent Mode”,
“Conference Mode”, “Outdoors Mode”, “Airplane
Mode”. Press “OK” to confirm the one you like.
4.7.4 Restore Factory Setting
Enter setting- restore factory settings, press “OK” get
a notification and “OK” again could accomplish the
setting, press return button to cancel. It can be
restored to the initial status.
4.8 Calculator
Long press calculator key to enter when in standby
interface, then Talkase will be a calculator, input
number to count directly.
Anti-Lost
Press "OK" to enter Anti-Lost function, another press
to switch on or off (Only available after connected by
bluetooth).
Shortcut Key
1. When the Bluetooth is turned off, press return
botton on standby interface, "Connect by..." comes
out, press "OK" can activate Bluetooth rapidly,
otherwise it will be turned on by press the return
botton when the Bluetooth is turned off.
2. Press “#” could exchange input method, press “*”
could choose different punctuation mark when
texting message or edit the contacts’ name.
3. Press OK key to turn on/off the loudspeaker while
in the call status.
06

4.4 Contacts
Press "OK" to enter the contacts list when in the
contacts menu，press top or bottom key to select SIM
card contacts, Bluetooth contacts and add contacts.
4.4.1 Add Contacts
Press "OK" will show the pop-up circle in add
contacts menu, press top or bottom key to input
name and number to the input area, press “OK”to
save or cancel. Press “#” to choose input method.
4.4.2 Call SIM Card Contacts
Press top and bottom key to choose contacts from
SIM Card Contacts, then press “OK”will show “Find
Contacts”, “Send Message”, “Call the Contacts”,
“Edit Contacts”,”Delete Contacts”, “Choose the Save
Area”and so on. Press top or bottom key to select
“Call the Contacts”.
Play and Delete Record List
Press top or bottom key to select, press OK to enter
the record list, press top or bottom key to choose
that you want to play, press “OK”will show “play”or
“delete” , select by press top or bottom key, press
“OK”to confirm.
4.3 Bluetooth
4.3.1 Instrcution of Bluetooth
Open the Bluetooth, search the Talkase Bluetooth on
your smart phone, then pair it.
1. Instruction Before Use
1.1. Install SIM Card
1.2. Charging Method
2. Instruction of Buttons
3. Starter
3.1. Standby Interface
3.2. How to Use Dialer
4. Menu
4.1. Music Player
4.2. Record
4.3. Bluetooth
4.4. Contacts
4.5. Message
4.6. Call History
4.7. Setting
4.8. Calculator
4.9. Anti-Lost
4.10. Shortcut Key
1.1 Install SIM Card
The SIM card slot is on the right side of the back of
Talkase, first remove the cover as instructed, then
put the SIM card into the slot, close the cover, the
installing is done.
Only support micro SIM card.
1.2 Charging Method
Let the four metal contacts of charging slip
correspond to the four of Talkase, then press the
charging clip to ensure it is tightly attached to the
back of Talkase, connect the computer using USB
cable or an adapter for charging. Take out the clip
from down to up in vertical direction, sliding way is
not suggested for protecting the four contacts in
charging clip.
3.1.Standby Interface
Long press the power key to start up, standby
interface show the internet signal, Battery Capacity,
and the message notification when there is message
you have not read. When open the Bluetooth it will
show on the interface too. The middle of the
interface is the present time. Press top or bottom
menu key for changing different function.
Lock and Unlock
Press power on/off key and "#" simultaneously to
lock or unlock.
3.2 How to Use Dialer
Press the number key can make a call directly, or dial
by GSM SIM card, or use the BT call to make a dial
after connecting with your smart phone through
Bluetooth.（There must be a SIM card in your smart
phone, how to pair the Bluetooth please refer to
BT3.5）. If there is error in input number using the
delete key to correct.
4.1 Bluetooth Music Control
After connecting with the smart phone by Bluetooth
can use the music player.（Note：Only can control
music but can not play, control smart phone to play
the previous and next one.)
4.1.1 How to control music
Press "OK" to enter the function interface when in
the music control menu, press top and bottom key
to select the previous and the next one, press "OK"
to play or pause.
4.2 Record
Begin Recording
Press "OK" to enter the function interface when in
the recording menu, press top and bottom key to
select the function you want, choose the record
mark and begin to record.
Save/Pause/Give up
When recording the screen will show the record
time, press “OK”will show“save/pause/give up ”,
select function by press top and bottom key, press
“OK”to confirm, press recording key to continue
recording.
Record
Delete Play
Record Save DeletePause
Save DeleteRecord
Record List
On/Off Visibility Bluetooth Name
Search for Bluetooth
4.4.3 Dialer to Bluetooth Contacts
Press “OK”to enter the Bluetooth contacts, another
press to choose different functions, press top or
bottom key to “Text Message”, “Dial to the Contacts
“, “Save to the phone book”.
4.5 Message
Press "OK" to enter the message operation interface
when in the message menu, press top or bottom key
to “Text Message”,“Inbox”,“Drafts”,“Outbox”.
4.5.1 Text and Send Message
Choose “Text Message”, press “OK”when the
message is done and the screen will show “send”,
recipient could be choosed from contacts or input
number directly, press “OK”to send. Press top or
bottom key could choose“Save Message”,
”Punctuation”, “Input Method”and so on.
4.5.2 Inbox
Choose “Inbox”, press “OK” to enter the list, press
top and bottom key to select, press “OK”to read,
press again to “Reply”, “Add Contacts”, “Delete”,
“Forward”, “Dial”and so on.
4.5.3 Outbox
Choose “Outbox”, Press “OK” to the list, press top or
bottom key to choose, and press “OK”to read, press
“OK”again to “Forward”or “Delete”.
4.5.4 Drafts
Choose “Drafts”, press “OK”to the list, press top or
bottom key to choose, and press “OK”to read, “OK”
again to “Send”, ”Edit”, “Delete”and so on.
4.6 Call History
Press “OK” to the call history, another press to
choose and “OK”again to “Add contacts”, “Dial “,
“Send Message”, “Delete Call History ”.
4.7 Setting
4.7.1 Alarm Clock Setting
Enter setting-alarm, press “OK” begin to set time,
Press “OK”could enjoy the following functions after
setting done: “Ringtone Setting”, “Repeat Setting”,
“Save Alarm Clock”and so on. The circle could
become solid after successful setting.
4.7.1.1
How to turn off
Enter setting-Alarm Clock, choose the one you want
to delete, press “OK”to confirm, the circle would be
hollow.
4.7.2 Phone Setting
This including: “Date Setting”, “Time Setting”, “Zone
Setting”, “Time Format Setting”, “System Language
Setting”, “Ringtone Setting”, “Volume Setting”,
“Operator Manul Setting”, “Screen display Time
Setting”, Details See Below：
4.7.3 Profiles
It including: “Standard Mode”,“Silent Mode”,
“Conference Mode”, “Outdoors Mode”, “Airplane
Mode”. Press “OK” to confirm the one you like.
4.7.4 Restore Factory Setting
Enter setting- restore factory settings, press “OK” get
a notification and “OK” again could accomplish the
setting, press return button to cancel. It can be
restored to the initial status.
4.8 Calculator
Long press calculator key to enter when in standby
interface, then Talkase will be a calculator, input
number to count directly.
Anti-Lost
Press "OK" to enter Anti-Lost function, another press
to switch on or off (Only available after connected by
bluetooth).
Shortcut Key
1. When the Bluetooth is turned off, press return
botton on standby interface, "Connect by..." comes
out, press "OK" can activate Bluetooth rapidly,
otherwise it will be turned on by press the return
botton when the Bluetooth is turned off.
2. Press “#” could exchange input method, press “*”
could choose different punctuation mark when
texting message or edit the contacts’ name.
3. Press OK key to turn on/off the loudspeaker while
in the call status.
07

4.4 Contacts
Press "OK" to enter the contacts list when in the
contacts menu，press top or bottom key to select SIM
card contacts, Bluetooth contacts and add contacts.
4.4.1 Add Contacts
Press "OK" will show the pop-up circle in add
contacts menu, press top or bottom key to input
name and number to the input area, press “OK”to
save or cancel. Press “#” to choose input method.
4.4.2 Call SIM Card Contacts
Press top and bottom key to choose contacts from
SIM Card Contacts, then press “OK”will show “Find
Contacts”, “Send Message”, “Call the Contacts”,
“Edit Contacts”,”Delete Contacts”, “Choose the Save
Area”and so on. Press top or bottom key to select
“Call the Contacts”.
Play and Delete Record List
Press top or bottom key to select, press OK to enter
the record list, press top or bottom key to choose
that you want to play, press “OK”will show “play”or
“delete” , select by press top or bottom key, press
“OK”to confirm.
4.3 Bluetooth
4.3.1 Instrcution of Bluetooth
Open the Bluetooth, search the Talkase Bluetooth on
your smart phone, then pair it.
1. Instruction Before Use
1.1. Install SIM Card
1.2. Charging Method
2. Instruction of Buttons
3. Starter
3.1. Standby Interface
3.2. How to Use Dialer
4. Menu
4.1. Music Player
4.2. Record
4.3. Bluetooth
4.4. Contacts
4.5. Message
4.6. Call History
4.7. Setting
4.8. Calculator
4.9. Anti-Lost
4.10. Shortcut Key
1.1 Install SIM Card
The SIM card slot is on the right side of the back of
Talkase, first remove the cover as instructed, then
put the SIM card into the slot, close the cover, the
installing is done.
Only support micro SIM card.
1.2 Charging Method
Let the four metal contacts of charging slip
correspond to the four of Talkase, then press the
charging clip to ensure it is tightly attached to the
back of Talkase, connect the computer using USB
cable or an adapter for charging. Take out the clip
from down to up in vertical direction, sliding way is
not suggested for protecting the four contacts in
charging clip.
3.1.Standby Interface
Long press the power key to start up, standby
interface show the internet signal, Battery Capacity,
and the message notification when there is message
you have not read. When open the Bluetooth it will
show on the interface too. The middle of the
interface is the present time. Press top or bottom
menu key for changing different function.
Lock and Unlock
Press power on/off key and "#" simultaneously to
lock or unlock.
3.2 How to Use Dialer
Press the number key can make a call directly, or dial
by GSM SIM card, or use the BT call to make a dial
after connecting with your smart phone through
Bluetooth.（There must be a SIM card in your smart
phone, how to pair the Bluetooth please refer to
BT3.5）. If there is error in input number using the
delete key to correct.
4.1 Bluetooth Music Control
After connecting with the smart phone by Bluetooth
can use the music player.（Note：Only can control
music but can not play, control smart phone to play
the previous and next one.)
4.1.1 How to control music
Press "OK" to enter the function interface when in
the music control menu, press top and bottom key
to select the previous and the next one, press "OK"
to play or pause.
4.2 Record
Begin Recording
Press "OK" to enter the function interface when in
the recording menu, press top and bottom key to
select the function you want, choose the record
mark and begin to record.
Save/Pause/Give up
When recording the screen will show the record
time, press “OK”will show“save/pause/give up ”,
select function by press top and bottom key, press
“OK”to confirm, press recording key to continue
recording.
Contacts Bluetooth Contacts SIM Card Contacts
Add Contacts
Input Name Input Number Save
Cancel
ABC ABC
4.4.3 Dialer to Bluetooth Contacts
Press “OK”to enter the Bluetooth contacts, another
press to choose different functions, press top or
bottom key to “Text Message”, “Dial to the Contacts
“, “Save to the phone book”.
4.5 Message
Press "OK" to enter the message operation interface
when in the message menu, press top or bottom key
to “Text Message”,“Inbox”,“Drafts”,“Outbox”.
4.5.1 Text and Send Message
Choose “Text Message”, press “OK”when the
message is done and the screen will show “send”,
recipient could be choosed from contacts or input
number directly, press “OK”to send. Press top or
bottom key could choose“Save Message”,
”Punctuation”, “Input Method”and so on.
4.5.2 Inbox
Choose “Inbox”, press “OK” to enter the list, press
top and bottom key to select, press “OK”to read,
press again to “Reply”, “Add Contacts”, “Delete”,
“Forward”, “Dial”and so on.
4.5.3 Outbox
Choose “Outbox”, Press “OK” to the list, press top or
bottom key to choose, and press “OK”to read, press
“OK”again to “Forward”or “Delete”.
4.5.4 Drafts
Choose “Drafts”, press “OK”to the list, press top or
bottom key to choose, and press “OK”to read, “OK”
again to “Send”, ”Edit”, “Delete”and so on.
4.6 Call History
Press “OK” to the call history, another press to
choose and “OK”again to “Add contacts”, “Dial “,
“Send Message”, “Delete Call History ”.
4.7 Setting
4.7.1 Alarm Clock Setting
Enter setting-alarm, press “OK” begin to set time,
Press “OK”could enjoy the following functions after
setting done: “Ringtone Setting”, “Repeat Setting”,
“Save Alarm Clock”and so on. The circle could
become solid after successful setting.
4.7.1.1
How to turn off
Enter setting-Alarm Clock, choose the one you want
to delete, press “OK”to confirm, the circle would be
hollow.
4.7.2 Phone Setting
This including: “Date Setting”, “Time Setting”, “Zone
Setting”, “Time Format Setting”, “System Language
Setting”, “Ringtone Setting”, “Volume Setting”,
“Operator Manul Setting”, “Screen display Time
Setting”, Details See Below：
4.7.3 Profiles
It including: “Standard Mode”,“Silent Mode”,
“Conference Mode”, “Outdoors Mode”, “Airplane
Mode”. Press “OK” to confirm the one you like.
4.7.4 Restore Factory Setting
Enter setting- restore factory settings, press “OK” get
a notification and “OK” again could accomplish the
setting, press return button to cancel. It can be
restored to the initial status.
4.8 Calculator
Long press calculator key to enter when in standby
interface, then Talkase will be a calculator, input
number to count directly.
Anti-Lost
Press "OK" to enter Anti-Lost function, another press
to switch on or off (Only available after connected by
bluetooth).
Shortcut Key
1. When the Bluetooth is turned off, press return
botton on standby interface, "Connect by..." comes
out, press "OK" can activate Bluetooth rapidly,
otherwise it will be turned on by press the return
botton when the Bluetooth is turned off.
2. Press “#” could exchange input method, press “*”
could choose different punctuation mark when
texting message or edit the contacts’ name.
3. Press OK key to turn on/off the loudspeaker while
in the call status.
Name Phone Number
08

4.4 Contacts
Press "OK" to enter the contacts list when in the
contacts menu，press top or bottom key to select SIM
card contacts, Bluetooth contacts and add contacts.
4.4.1 Add Contacts
Press "OK" will show the pop-up circle in add
contacts menu, press top or bottom key to input
name and number to the input area, press “OK”to
save or cancel. Press “#” to choose input method.
4.4.2 Call SIM Card Contacts
Press top and bottom key to choose contacts from
SIM Card Contacts, then press “OK”will show “Find
Contacts”, “Send Message”, “Call the Contacts”,
“Edit Contacts”,”Delete Contacts”, “Choose the Save
Area”and so on. Press top or bottom key to select
“Call the Contacts”.
Play and Delete Record List
Press top or bottom key to select, press OK to enter
the record list, press top or bottom key to choose
that you want to play, press “OK”will show “play”or
“delete” , select by press top or bottom key, press
“OK”to confirm.
4.3 Bluetooth
4.3.1 Instrcution of Bluetooth
Open the Bluetooth, search the Talkase Bluetooth on
your smart phone, then pair it.
1. Instruction Before Use
1.1. Install SIM Card
1.2. Charging Method
2. Instruction of Buttons
3. Starter
3.1. Standby Interface
3.2. How to Use Dialer
4. Menu
4.1. Music Player
4.2. Record
4.3. Bluetooth
4.4. Contacts
4.5. Message
4.6. Call History
4.7. Setting
4.8. Calculator
4.9. Anti-Lost
4.10. Shortcut Key
1.1 Install SIM Card
The SIM card slot is on the right side of the back of
Talkase, first remove the cover as instructed, then
put the SIM card into the slot, close the cover, the
installing is done.
Only support micro SIM card.
1.2 Charging Method
Let the four metal contacts of charging slip
correspond to the four of Talkase, then press the
charging clip to ensure it is tightly attached to the
back of Talkase, connect the computer using USB
cable or an adapter for charging. Take out the clip
from down to up in vertical direction, sliding way is
not suggested for protecting the four contacts in
charging clip.
3.1.Standby Interface
Long press the power key to start up, standby
interface show the internet signal, Battery Capacity,
and the message notification when there is message
you have not read. When open the Bluetooth it will
show on the interface too. The middle of the
interface is the present time. Press top or bottom
menu key for changing different function.
Lock and Unlock
Press power on/off key and "#" simultaneously to
lock or unlock.
3.2 How to Use Dialer
Press the number key can make a call directly, or dial
by GSM SIM card, or use the BT call to make a dial
after connecting with your smart phone through
Bluetooth.（There must be a SIM card in your smart
phone, how to pair the Bluetooth please refer to
BT3.5）. If there is error in input number using the
delete key to correct.
4.1 Bluetooth Music Control
After connecting with the smart phone by Bluetooth
can use the music player.（Note：Only can control
music but can not play, control smart phone to play
the previous and next one.)
4.1.1 How to control music
Press "OK" to enter the function interface when in
the music control menu, press top and bottom key
to select the previous and the next one, press "OK"
to play or pause.
4.2 Record
Begin Recording
Press "OK" to enter the function interface when in
the recording menu, press top and bottom key to
select the function you want, choose the record
mark and begin to record.
Save/Pause/Give up
When recording the screen will show the record
time, press “OK”will show“save/pause/give up ”,
select function by press top and bottom key, press
“OK”to confirm, press recording key to continue
recording.
Text Message Call
Edit
Text Message Dial
Search
Delete transfer between
SIM and phone
4.4.3 Dialer to Bluetooth Contacts
Press “OK”to enter the Bluetooth contacts, another
press to choose different functions, press top or
bottom key to “Text Message”, “Dial to the Contacts
“, “Save to the phone book”.
4.5 Message
Press "OK" to enter the message operation interface
when in the message menu, press top or bottom key
to “Text Message”,“Inbox”,“Drafts”,“Outbox”.
4.5.1 Text and Send Message
Choose “Text Message”, press “OK”when the
message is done and the screen will show “send”,
recipient could be choosed from contacts or input
number directly, press “OK”to send. Press top or
bottom key could choose“Save Message”,
”Punctuation”, “Input Method”and so on.
4.5.2 Inbox
Choose “Inbox”, press “OK” to enter the list, press
top and bottom key to select, press “OK”to read,
press again to “Reply”, “Add Contacts”, “Delete”,
“Forward”, “Dial”and so on.
4.5.3 Outbox
Choose “Outbox”, Press “OK” to the list, press top or
bottom key to choose, and press “OK”to read, press
“OK”again to “Forward”or “Delete”.
4.5.4 Drafts
Choose “Drafts”, press “OK”to the list, press top or
bottom key to choose, and press “OK”to read, “OK”
again to “Send”, ”Edit”, “Delete”and so on.
4.6 Call History
Press “OK” to the call history, another press to
choose and “OK”again to “Add contacts”, “Dial “,
“Send Message”, “Delete Call History ”.
4.7 Setting
4.7.1 Alarm Clock Setting
Enter setting-alarm, press “OK” begin to set time,
Press “OK”could enjoy the following functions after
setting done: “Ringtone Setting”, “Repeat Setting”,
“Save Alarm Clock”and so on. The circle could
become solid after successful setting.
4.7.1.1
How to turn off
Enter setting-Alarm Clock, choose the one you want
to delete, press “OK”to confirm, the circle would be
hollow.
4.7.2 Phone Setting
This including: “Date Setting”, “Time Setting”, “Zone
Setting”, “Time Format Setting”, “System Language
Setting”, “Ringtone Setting”, “Volume Setting”,
“Operator Manul Setting”, “Screen display Time
Setting”, Details See Below：
4.7.3 Profiles
It including: “Standard Mode”,“Silent Mode”,
“Conference Mode”, “Outdoors Mode”, “Airplane
Mode”. Press “OK” to confirm the one you like.
4.7.4 Restore Factory Setting
Enter setting- restore factory settings, press “OK” get
a notification and “OK” again could accomplish the
setting, press return button to cancel. It can be
restored to the initial status.
4.8 Calculator
Long press calculator key to enter when in standby
interface, then Talkase will be a calculator, input
number to count directly.
Anti-Lost
Press "OK" to enter Anti-Lost function, another press
to switch on or off (Only available after connected by
bluetooth).
Shortcut Key
1. When the Bluetooth is turned off, press return
botton on standby interface, "Connect by..." comes
out, press "OK" can activate Bluetooth rapidly,
otherwise it will be turned on by press the return
botton when the Bluetooth is turned off.
2. Press “#” could exchange input method, press “*”
could choose different punctuation mark when
texting message or edit the contacts’ name.
3. Press OK key to turn on/off the loudspeaker while
in the call status.
09
Note: Press “#” could exchange input method,
press “*” could choose different punctuation
mark when texting message or edit the contacts’
name.
Note: select contacts in the contact list, dial the
BT Key or GSM Key to call directly.

4.4 Contacts
Press "OK" to enter the contacts list when in the
contacts menu，press top or bottom key to select SIM
card contacts, Bluetooth contacts and add contacts.
4.4.1 Add Contacts
Press "OK" will show the pop-up circle in add
contacts menu, press top or bottom key to input
name and number to the input area, press “OK”to
save or cancel. Press “#” to choose input method.
4.4.2 Call SIM Card Contacts
Press top and bottom key to choose contacts from
SIM Card Contacts, then press “OK”will show “Find
Contacts”, “Send Message”, “Call the Contacts”,
“Edit Contacts”,”Delete Contacts”, “Choose the Save
Area”and so on. Press top or bottom key to select
“Call the Contacts”.
Play and Delete Record List
Press top or bottom key to select, press OK to enter
the record list, press top or bottom key to choose
that you want to play, press “OK”will show “play”or
“delete” , select by press top or bottom key, press
“OK”to confirm.
4.3 Bluetooth
4.3.1 Instrcution of Bluetooth
Open the Bluetooth, search the Talkase Bluetooth on
your smart phone, then pair it.
1. Instruction Before Use
1.1. Install SIM Card
1.2. Charging Method
2. Instruction of Buttons
3. Starter
3.1. Standby Interface
3.2. How to Use Dialer
4. Menu
4.1. Music Player
4.2. Record
4.3. Bluetooth
4.4. Contacts
4.5. Message
4.6. Call History
4.7. Setting
4.8. Calculator
4.9. Anti-Lost
4.10. Shortcut Key
1.1 Install SIM Card
The SIM card slot is on the right side of the back of
Talkase, first remove the cover as instructed, then
put the SIM card into the slot, close the cover, the
installing is done.
Only support micro SIM card.
1.2 Charging Method
Let the four metal contacts of charging slip
correspond to the four of Talkase, then press the
charging clip to ensure it is tightly attached to the
back of Talkase, connect the computer using USB
cable or an adapter for charging. Take out the clip
from down to up in vertical direction, sliding way is
not suggested for protecting the four contacts in
charging clip.
3.1.Standby Interface
Long press the power key to start up, standby
interface show the internet signal, Battery Capacity,
and the message notification when there is message
you have not read. When open the Bluetooth it will
show on the interface too. The middle of the
interface is the present time. Press top or bottom
menu key for changing different function.
Lock and Unlock
Press power on/off key and "#" simultaneously to
lock or unlock.
3.2 How to Use Dialer
Press the number key can make a call directly, or dial
by GSM SIM card, or use the BT call to make a dial
after connecting with your smart phone through
Bluetooth.（There must be a SIM card in your smart
phone, how to pair the Bluetooth please refer to
BT3.5）. If there is error in input number using the
delete key to correct.
4.1 Bluetooth Music Control
After connecting with the smart phone by Bluetooth
can use the music player.（Note：Only can control
music but can not play, control smart phone to play
the previous and next one.)
4.1.1 How to control music
Press "OK" to enter the function interface when in
the music control menu, press top and bottom key
to select the previous and the next one, press "OK"
to play or pause.
4.2 Record
Begin Recording
Press "OK" to enter the function interface when in
the recording menu, press top and bottom key to
select the function you want, choose the record
mark and begin to record.
Save/Pause/Give up
When recording the screen will show the record
time, press “OK”will show“save/pause/give up ”,
select function by press top and bottom key, press
“OK”to confirm, press recording key to continue
recording.
Message
Inbox Drafts
Input Method
Save as Drafts
Send Punctuation
Text Message Outbox
4.4.3 Dialer to Bluetooth Contacts
Press “OK”to enter the Bluetooth contacts, another
press to choose different functions, press top or
bottom key to “Text Message”, “Dial to the Contacts
“, “Save to the phone book”.
4.5 Message
Press "OK" to enter the message operation interface
when in the message menu, press top or bottom key
to “Text Message”,“Inbox”,“Drafts”,“Outbox”.
4.5.1 Text and Send Message
Choose “Text Message”, press “OK”when the
message is done and the screen will show “send”,
recipient could be choosed from contacts or input
number directly, press “OK”to send. Press top or
bottom key could choose“Save Message”,
”Punctuation”, “Input Method”and so on.
4.5.2 Inbox
Choose “Inbox”, press “OK” to enter the list, press
top and bottom key to select, press “OK”to read,
press again to “Reply”, “Add Contacts”, “Delete”,
“Forward”, “Dial”and so on.
4.5.3 Outbox
Choose “Outbox”, Press “OK” to the list, press top or
bottom key to choose, and press “OK”to read, press
“OK”again to “Forward”or “Delete”.
4.5.4 Drafts
Choose “Drafts”, press “OK”to the list, press top or
bottom key to choose, and press “OK”to read, “OK”
again to “Send”, ”Edit”, “Delete”and so on.
4.6 Call History
Press “OK” to the call history, another press to
choose and “OK”again to “Add contacts”, “Dial “,
“Send Message”, “Delete Call History ”.
4.7 Setting
4.7.1 Alarm Clock Setting
Enter setting-alarm, press “OK” begin to set time,
Press “OK”could enjoy the following functions after
setting done: “Ringtone Setting”, “Repeat Setting”,
“Save Alarm Clock”and so on. The circle could
become solid after successful setting.
4.7.1.1
How to turn off
Enter setting-Alarm Clock, choose the one you want
to delete, press “OK”to confirm, the circle would be
hollow.
4.7.2 Phone Setting
This including: “Date Setting”, “Time Setting”, “Zone
Setting”, “Time Format Setting”, “System Language
Setting”, “Ringtone Setting”, “Volume Setting”,
“Operator Manul Setting”, “Screen display Time
Setting”, Details See Below：
4.7.3 Profiles
It including: “Standard Mode”,“Silent Mode”,
“Conference Mode”, “Outdoors Mode”, “Airplane
Mode”. Press “OK” to confirm the one you like.
4.7.4 Restore Factory Setting
Enter setting- restore factory settings, press “OK” get
a notification and “OK” again could accomplish the
setting, press return button to cancel. It can be
restored to the initial status.
4.8 Calculator
Long press calculator key to enter when in standby
interface, then Talkase will be a calculator, input
number to count directly.
Anti-Lost
Press "OK" to enter Anti-Lost function, another press
to switch on or off (Only available after connected by
bluetooth).
Shortcut Key
1. When the Bluetooth is turned off, press return
botton on standby interface, "Connect by..." comes
out, press "OK" can activate Bluetooth rapidly,
otherwise it will be turned on by press the return
botton when the Bluetooth is turned off.
2. Press “#” could exchange input method, press “*”
could choose different punctuation mark when
texting message or edit the contacts’ name.
3. Press OK key to turn on/off the loudspeaker while
in the call status.
10

4.4 Contacts
Press "OK" to enter the contacts list when in the
contacts menu，press top or bottom key to select SIM
card contacts, Bluetooth contacts and add contacts.
4.4.1 Add Contacts
Press "OK" will show the pop-up circle in add
contacts menu, press top or bottom key to input
name and number to the input area, press “OK”to
save or cancel. Press “#” to choose input method.
4.4.2 Call SIM Card Contacts
Press top and bottom key to choose contacts from
SIM Card Contacts, then press “OK”will show “Find
Contacts”, “Send Message”, “Call the Contacts”,
“Edit Contacts”,”Delete Contacts”, “Choose the Save
Area”and so on. Press top or bottom key to select
“Call the Contacts”.
Play and Delete Record List
Press top or bottom key to select, press OK to enter
the record list, press top or bottom key to choose
that you want to play, press “OK”will show “play”or
“delete” , select by press top or bottom key, press
“OK”to confirm.
4.3 Bluetooth
4.3.1 Instrcution of Bluetooth
Open the Bluetooth, search the Talkase Bluetooth on
your smart phone, then pair it.
1. Instruction Before Use
1.1. Install SIM Card
1.2. Charging Method
2. Instruction of Buttons
3. Starter
3.1. Standby Interface
3.2. How to Use Dialer
4. Menu
4.1. Music Player
4.2. Record
4.3. Bluetooth
4.4. Contacts
4.5. Message
4.6. Call History
4.7. Setting
4.8. Calculator
4.9. Anti-Lost
4.10. Shortcut Key
1.1 Install SIM Card
The SIM card slot is on the right side of the back of
Talkase, first remove the cover as instructed, then
put the SIM card into the slot, close the cover, the
installing is done.
Only support micro SIM card.
1.2 Charging Method
Let the four metal contacts of charging slip
correspond to the four of Talkase, then press the
charging clip to ensure it is tightly attached to the
back of Talkase, connect the computer using USB
cable or an adapter for charging. Take out the clip
from down to up in vertical direction, sliding way is
not suggested for protecting the four contacts in
charging clip.
3.1.Standby Interface
Long press the power key to start up, standby
interface show the internet signal, Battery Capacity,
and the message notification when there is message
you have not read. When open the Bluetooth it will
show on the interface too. The middle of the
interface is the present time. Press top or bottom
menu key for changing different function.
Lock and Unlock
Press power on/off key and "#" simultaneously to
lock or unlock.
3.2 How to Use Dialer
Press the number key can make a call directly, or dial
by GSM SIM card, or use the BT call to make a dial
after connecting with your smart phone through
Bluetooth.（There must be a SIM card in your smart
phone, how to pair the Bluetooth please refer to
BT3.5）. If there is error in input number using the
delete key to correct.
4.1 Bluetooth Music Control
After connecting with the smart phone by Bluetooth
can use the music player.（Note：Only can control
music but can not play, control smart phone to play
the previous and next one.)
4.1.1 How to control music
Press "OK" to enter the function interface when in
the music control menu, press top and bottom key
to select the previous and the next one, press "OK"
to play or pause.
4.2 Record
Begin Recording
Press "OK" to enter the function interface when in
the recording menu, press top and bottom key to
select the function you want, choose the record
mark and begin to record.
Save/Pause/Give up
When recording the screen will show the record
time, press “OK”will show“save/pause/give up ”,
select function by press top and bottom key, press
“OK”to confirm, press recording key to continue
recording.
Unread Read Reply
Add Contacts Delete Forward
4.4.3 Dialer to Bluetooth Contacts
Press “OK”to enter the Bluetooth contacts, another
press to choose different functions, press top or
bottom key to “Text Message”, “Dial to the Contacts
“, “Save to the phone book”.
4.5 Message
Press "OK" to enter the message operation interface
when in the message menu, press top or bottom key
to “Text Message”,“Inbox”,“Drafts”,“Outbox”.
4.5.1 Text and Send Message
Choose “Text Message”, press “OK”when the
message is done and the screen will show “send”,
recipient could be choosed from contacts or input
number directly, press “OK”to send. Press top or
bottom key could choose“Save Message”,
”Punctuation”, “Input Method”and so on.
4.5.2 Inbox
Choose “Inbox”, press “OK” to enter the list, press
top and bottom key to select, press “OK”to read,
press again to “Reply”, “Add Contacts”, “Delete”,
“Forward”, “Dial”and so on.
4.5.3 Outbox
Choose “Outbox”, Press “OK” to the list, press top or
bottom key to choose, and press “OK”to read, press
“OK”again to “Forward”or “Delete”.
4.5.4 Drafts
Choose “Drafts”, press “OK”to the list, press top or
bottom key to choose, and press “OK”to read, “OK”
again to “Send”, ”Edit”, “Delete”and so on.
Dial
4.6 Call History
Press “OK” to the call history, another press to
choose and “OK”again to “Add contacts”, “Dial “,
“Send Message”, “Delete Call History ”.
4.7 Setting
4.7.1 Alarm Clock Setting
Enter setting-alarm, press “OK” begin to set time,
Press “OK”could enjoy the following functions after
setting done: “Ringtone Setting”, “Repeat Setting”,
“Save Alarm Clock”and so on. The circle could
become solid after successful setting.
4.7.1.1
How to turn off
Enter setting-Alarm Clock, choose the one you want
to delete, press “OK”to confirm, the circle would be
hollow.
4.7.2 Phone Setting
This including: “Date Setting”, “Time Setting”, “Zone
Setting”, “Time Format Setting”, “System Language
Setting”, “Ringtone Setting”, “Volume Setting”,
“Operator Manul Setting”, “Screen display Time
Setting”, Details See Below：
4.7.3 Profiles
It including: “Standard Mode”,“Silent Mode”,
“Conference Mode”, “Outdoors Mode”, “Airplane
Mode”. Press “OK” to confirm the one you like.
4.7.4 Restore Factory Setting
Enter setting- restore factory settings, press “OK” get
a notification and “OK” again could accomplish the
setting, press return button to cancel. It can be
restored to the initial status.
4.8 Calculator
Long press calculator key to enter when in standby
interface, then Talkase will be a calculator, input
number to count directly.
Anti-Lost
Press "OK" to enter Anti-Lost function, another press
to switch on or off (Only available after connected by
bluetooth).
Shortcut Key
1. When the Bluetooth is turned off, press return
botton on standby interface, "Connect by..." comes
out, press "OK" can activate Bluetooth rapidly,
otherwise it will be turned on by press the return
botton when the Bluetooth is turned off.
2. Press “#” could exchange input method, press “*”
could choose different punctuation mark when
texting message or edit the contacts’ name.
3. Press OK key to turn on/off the loudspeaker while
in the call status.
11
Note: Press “#” could exchange input method,
press “*” could choose different punctuation
mark when texting message or edit the contacts’
name.

4.4 Contacts
Press "OK" to enter the contacts list when in the
contacts menu，press top or bottom key to select SIM
card contacts, Bluetooth contacts and add contacts.
4.4.1 Add Contacts
Press "OK" will show the pop-up circle in add
contacts menu, press top or bottom key to input
name and number to the input area, press “OK”to
save or cancel. Press “#” to choose input method.
4.4.2 Call SIM Card Contacts
Press top and bottom key to choose contacts from
SIM Card Contacts, then press “OK”will show “Find
Contacts”, “Send Message”, “Call the Contacts”,
“Edit Contacts”,”Delete Contacts”, “Choose the Save
Area”and so on. Press top or bottom key to select
“Call the Contacts”.
Play and Delete Record List
Press top or bottom key to select, press OK to enter
the record list, press top or bottom key to choose
that you want to play, press “OK”will show “play”or
“delete” , select by press top or bottom key, press
“OK”to confirm.
4.3 Bluetooth
4.3.1 Instrcution of Bluetooth
Open the Bluetooth, search the Talkase Bluetooth on
your smart phone, then pair it.
1. Instruction Before Use
1.1. Install SIM Card
1.2. Charging Method
2. Instruction of Buttons
3. Starter
3.1. Standby Interface
3.2. How to Use Dialer
4. Menu
4.1. Music Player
4.2. Record
4.3. Bluetooth
4.4. Contacts
4.5. Message
4.6. Call History
4.7. Setting
4.8. Calculator
4.9. Anti-Lost
4.10. Shortcut Key
1.1 Install SIM Card
The SIM card slot is on the right side of the back of
Talkase, first remove the cover as instructed, then
put the SIM card into the slot, close the cover, the
installing is done.
Only support micro SIM card.
1.2 Charging Method
Let the four metal contacts of charging slip
correspond to the four of Talkase, then press the
charging clip to ensure it is tightly attached to the
back of Talkase, connect the computer using USB
cable or an adapter for charging. Take out the clip
from down to up in vertical direction, sliding way is
not suggested for protecting the four contacts in
charging clip.
3.1.Standby Interface
Long press the power key to start up, standby
interface show the internet signal, Battery Capacity,
and the message notification when there is message
you have not read. When open the Bluetooth it will
show on the interface too. The middle of the
interface is the present time. Press top or bottom
menu key for changing different function.
Lock and Unlock
Press power on/off key and "#" simultaneously to
lock or unlock.
3.2 How to Use Dialer
Press the number key can make a call directly, or dial
by GSM SIM card, or use the BT call to make a dial
after connecting with your smart phone through
Bluetooth.（There must be a SIM card in your smart
phone, how to pair the Bluetooth please refer to
BT3.5）. If there is error in input number using the
delete key to correct.
4.1 Bluetooth Music Control
After connecting with the smart phone by Bluetooth
can use the music player.（Note：Only can control
music but can not play, control smart phone to play
the previous and next one.)
4.1.1 How to control music
Press "OK" to enter the function interface when in
the music control menu, press top and bottom key
to select the previous and the next one, press "OK"
to play or pause.
4.2 Record
Begin Recording
Press "OK" to enter the function interface when in
the recording menu, press top and bottom key to
select the function you want, choose the record
mark and begin to record.
Save/Pause/Give up
When recording the screen will show the record
time, press “OK”will show“save/pause/give up ”,
select function by press top and bottom key, press
“OK”to confirm, press recording key to continue
recording.
Call History
Missed Calls
Setting
Alarm Clock Setting
Received Calls Dialed Calls
4.4.3 Dialer to Bluetooth Contacts
Press “OK”to enter the Bluetooth contacts, another
press to choose different functions, press top or
bottom key to “Text Message”, “Dial to the Contacts
“, “Save to the phone book”.
4.5 Message
Press "OK" to enter the message operation interface
when in the message menu, press top or bottom key
to “Text Message”,“Inbox”,“Drafts”,“Outbox”.
4.5.1 Text and Send Message
Choose “Text Message”, press “OK”when the
message is done and the screen will show “send”,
recipient could be choosed from contacts or input
number directly, press “OK”to send. Press top or
bottom key could choose“Save Message”,
”Punctuation”, “Input Method”and so on.
4.5.2 Inbox
Choose “Inbox”, press “OK” to enter the list, press
top and bottom key to select, press “OK”to read,
press again to “Reply”, “Add Contacts”, “Delete”,
“Forward”, “Dial”and so on.
4.5.3 Outbox
Choose “Outbox”, Press “OK” to the list, press top or
bottom key to choose, and press “OK”to read, press
“OK”again to “Forward”or “Delete”.
4.5.4 Drafts
Choose “Drafts”, press “OK”to the list, press top or
bottom key to choose, and press “OK”to read, “OK”
again to “Send”, ”Edit”, “Delete”and so on.
4.6 Call History
Press “OK” to the call history, another press to
choose and “OK”again to “Add contacts”, “Dial “,
“Send Message”, “Delete Call History ”.
4.7 Setting
4.7.1 Alarm Clock Setting
Enter setting-alarm, press “OK” begin to set time,
Press “OK”could enjoy the following functions after
setting done: “Ringtone Setting”, “Repeat Setting”,
“Save Alarm Clock”and so on. The circle could
become solid after successful setting.
4.7.1.1
How to turn off
Enter setting-Alarm Clock, choose the one you want
to delete, press “OK”to confirm, the circle would be
hollow.
4.7.2 Phone Setting
This including: “Date Setting”, “Time Setting”, “Zone
Setting”, “Time Format Setting”, “System Language
Setting”, “Ringtone Setting”, “Volume Setting”,
“Operator Manul Setting”, “Screen display Time
Setting”, Details See Below：
4.7.3 Profiles
It including: “Standard Mode”,“Silent Mode”,
“Conference Mode”, “Outdoors Mode”, “Airplane
Mode”. Press “OK” to confirm the one you like.
4.7.4 Restore Factory Setting
Enter setting- restore factory settings, press “OK” get
a notification and “OK” again could accomplish the
setting, press return button to cancel. It can be
restored to the initial status.
4.8 Calculator
Long press calculator key to enter when in standby
interface, then Talkase will be a calculator, input
number to count directly.
Anti-Lost
Press "OK" to enter Anti-Lost function, another press
to switch on or off (Only available after connected by
bluetooth).
Shortcut Key
1. When the Bluetooth is turned off, press return
botton on standby interface, "Connect by..." comes
out, press "OK" can activate Bluetooth rapidly,
otherwise it will be turned on by press the return
botton when the Bluetooth is turned off.
2. Press “#” could exchange input method, press “*”
could choose different punctuation mark when
texting message or edit the contacts’ name.
3. Press OK key to turn on/off the loudspeaker while
in the call status.
12

4.4 Contacts
Press "OK" to enter the contacts list when in the
contacts menu，press top or bottom key to select SIM
card contacts, Bluetooth contacts and add contacts.
4.4.1 Add Contacts
Press "OK" will show the pop-up circle in add
contacts menu, press top or bottom key to input
name and number to the input area, press “OK”to
save or cancel. Press “#” to choose input method.
4.4.2 Call SIM Card Contacts
Press top and bottom key to choose contacts from
SIM Card Contacts, then press “OK”will show “Find
Contacts”, “Send Message”, “Call the Contacts”,
“Edit Contacts”,”Delete Contacts”, “Choose the Save
Area”and so on. Press top or bottom key to select
“Call the Contacts”.
Play and Delete Record List
Press top or bottom key to select, press OK to enter
the record list, press top or bottom key to choose
that you want to play, press “OK”will show “play”or
“delete” , select by press top or bottom key, press
“OK”to confirm.
4.3 Bluetooth
4.3.1 Instrcution of Bluetooth
Open the Bluetooth, search the Talkase Bluetooth on
your smart phone, then pair it.
1. Instruction Before Use
1.1. Install SIM Card
1.2. Charging Method
2. Instruction of Buttons
3. Starter
3.1. Standby Interface
3.2. How to Use Dialer
4. Menu
4.1. Music Player
4.2. Record
4.3. Bluetooth
4.4. Contacts
4.5. Message
4.6. Call History
4.7. Setting
4.8. Calculator
4.9. Anti-Lost
4.10. Shortcut Key
1.1 Install SIM Card
The SIM card slot is on the right side of the back of
Talkase, first remove the cover as instructed, then
put the SIM card into the slot, close the cover, the
installing is done.
Only support micro SIM card.
1.2 Charging Method
Let the four metal contacts of charging slip
correspond to the four of Talkase, then press the
charging clip to ensure it is tightly attached to the
back of Talkase, connect the computer using USB
cable or an adapter for charging. Take out the clip
from down to up in vertical direction, sliding way is
not suggested for protecting the four contacts in
charging clip.
3.1.Standby Interface
Long press the power key to start up, standby
interface show the internet signal, Battery Capacity,
and the message notification when there is message
you have not read. When open the Bluetooth it will
show on the interface too. The middle of the
interface is the present time. Press top or bottom
menu key for changing different function.
Lock and Unlock
Press power on/off key and "#" simultaneously to
lock or unlock.
3.2 How to Use Dialer
Press the number key can make a call directly, or dial
by GSM SIM card, or use the BT call to make a dial
after connecting with your smart phone through
Bluetooth.（There must be a SIM card in your smart
phone, how to pair the Bluetooth please refer to
BT3.5）. If there is error in input number using the
delete key to correct.
4.1 Bluetooth Music Control
After connecting with the smart phone by Bluetooth
can use the music player.（Note：Only can control
music but can not play, control smart phone to play
the previous and next one.)
4.1.1 How to control music
Press "OK" to enter the function interface when in
the music control menu, press top and bottom key
to select the previous and the next one, press "OK"
to play or pause.
4.2 Record
Begin Recording
Press "OK" to enter the function interface when in
the recording menu, press top and bottom key to
select the function you want, choose the record
mark and begin to record.
Save/Pause/Give up
When recording the screen will show the record
time, press “OK”will show“save/pause/give up ”,
select function by press top and bottom key, press
“OK”to confirm, press recording key to continue
recording.
Phone Setting
4.4.3 Dialer to Bluetooth Contacts
Press “OK”to enter the Bluetooth contacts, another
press to choose different functions, press top or
bottom key to “Text Message”, “Dial to the Contacts
“, “Save to the phone book”.
4.5 Message
Press "OK" to enter the message operation interface
when in the message menu, press top or bottom key
to “Text Message”,“Inbox”,“Drafts”,“Outbox”.
4.5.1 Text and Send Message
Choose “Text Message”, press “OK”when the
message is done and the screen will show “send”,
recipient could be choosed from contacts or input
number directly, press “OK”to send. Press top or
bottom key could choose“Save Message”,
”Punctuation”, “Input Method”and so on.
4.5.2 Inbox
Choose “Inbox”, press “OK” to enter the list, press
top and bottom key to select, press “OK”to read,
press again to “Reply”, “Add Contacts”, “Delete”,
“Forward”, “Dial”and so on.
4.5.3 Outbox
Choose “Outbox”, Press “OK” to the list, press top or
bottom key to choose, and press “OK”to read, press
“OK”again to “Forward”or “Delete”.
4.5.4 Drafts
Choose “Drafts”, press “OK”to the list, press top or
bottom key to choose, and press “OK”to read, “OK”
again to “Send”, ”Edit”, “Delete”and so on.
4.6 Call History
Press “OK” to the call history, another press to
choose and “OK”again to “Add contacts”, “Dial “,
“Send Message”, “Delete Call History ”.
4.7 Setting
4.7.1 Alarm Clock Setting
Enter setting-alarm, press “OK” begin to set time,
Press “OK”could enjoy the following functions after
setting done: “Ringtone Setting”, “Repeat Setting”,
“Save Alarm Clock”and so on. The circle could
become solid after successful setting.
4.7.1.1
How to turn off
Enter setting-Alarm Clock, choose the one you want
to delete, press “OK”to confirm, the circle would be
hollow.
4.7.2 Phone Setting
This including: “Date Setting”, “Time Setting”, “Zone
Setting”, “Time Format Setting”, “System Language
Setting”, “Ringtone Setting”, “Volume Setting”,
“Operator Manul Setting”, “Screen display Time
Setting”, Details See Below：
Input date by
keyboard
Date Setting
Top and bottom key to select
OK to confirm
Top and bottom key to select
OK to confirm
Top and bottom key to select
OK to confirm
Top and bottom key to select
OK to confirm
Top and bottom key to select
OK to confirm
Zone Setting
Input time by
keyboard
Time Setting
Time Format Setting
Volume up by top key
Volume down by bottom key
Volume Setting
Language Setting
Operator Manul Screen Display Time
4.7.3 Profiles
It including: “Standard Mode”,“Silent Mode”,
“Conference Mode”, “Outdoors Mode”, “Airplane
Mode”. Press “OK” to confirm the one you like.
4.7.4 Restore Factory Setting
Enter setting- restore factory settings, press “OK” get
a notification and “OK” again could accomplish the
setting, press return button to cancel. It can be
restored to the initial status.
4.8 Calculator
Long press calculator key to enter when in standby
interface, then Talkase will be a calculator, input
number to count directly.
Anti-Lost
Press "OK" to enter Anti-Lost function, another press
to switch on or off (Only available after connected by
bluetooth).
Shortcut Key
1. When the Bluetooth is turned off, press return
botton on standby interface, "Connect by..." comes
out, press "OK" can activate Bluetooth rapidly,
otherwise it will be turned on by press the return
botton when the Bluetooth is turned off.
2. Press “#” could exchange input method, press “*”
could choose different punctuation mark when
texting message or edit the contacts’ name.
3. Press OK key to turn on/off the loudspeaker while
in the call status.
15 Seco...AT&T
Washing.
English
13

4.4 Contacts
Press "OK" to enter the contacts list when in the
contacts menu，press top or bottom key to select SIM
card contacts, Bluetooth contacts and add contacts.
4.4.1 Add Contacts
Press "OK" will show the pop-up circle in add
contacts menu, press top or bottom key to input
name and number to the input area, press “OK”to
save or cancel. Press “#” to choose input method.
4.4.2 Call SIM Card Contacts
Press top and bottom key to choose contacts from
SIM Card Contacts, then press “OK”will show “Find
Contacts”, “Send Message”, “Call the Contacts”,
“Edit Contacts”,”Delete Contacts”, “Choose the Save
Area”and so on. Press top or bottom key to select
“Call the Contacts”.
Play and Delete Record List
Press top or bottom key to select, press OK to enter
the record list, press top or bottom key to choose
that you want to play, press “OK”will show “play”or
“delete” , select by press top or bottom key, press
“OK”to confirm.
4.3 Bluetooth
4.3.1 Instrcution of Bluetooth
Open the Bluetooth, search the Talkase Bluetooth on
your smart phone, then pair it.
1. Instruction Before Use
1.1. Install SIM Card
1.2. Charging Method
2. Instruction of Buttons
3. Starter
3.1. Standby Interface
3.2. How to Use Dialer
4. Menu
4.1. Music Player
4.2. Record
4.3. Bluetooth
4.4. Contacts
4.5. Message
4.6. Call History
4.7. Setting
4.8. Calculator
4.9. Anti-Lost
4.10. Shortcut Key
1.1 Install SIM Card
The SIM card slot is on the right side of the back of
Talkase, first remove the cover as instructed, then
put the SIM card into the slot, close the cover, the
installing is done.
Only support micro SIM card.
1.2 Charging Method
Let the four metal contacts of charging slip
correspond to the four of Talkase, then press the
charging clip to ensure it is tightly attached to the
back of Talkase, connect the computer using USB
cable or an adapter for charging. Take out the clip
from down to up in vertical direction, sliding way is
not suggested for protecting the four contacts in
charging clip.
3.1.Standby Interface
Long press the power key to start up, standby
interface show the internet signal, Battery Capacity,
and the message notification when there is message
you have not read. When open the Bluetooth it will
show on the interface too. The middle of the
interface is the present time. Press top or bottom
menu key for changing different function.
Lock and Unlock
Press power on/off key and "#" simultaneously to
lock or unlock.
3.2 How to Use Dialer
Press the number key can make a call directly, or dial
by GSM SIM card, or use the BT call to make a dial
after connecting with your smart phone through
Bluetooth.（There must be a SIM card in your smart
phone, how to pair the Bluetooth please refer to
BT3.5）. If there is error in input number using the
delete key to correct.
4.1 Bluetooth Music Control
After connecting with the smart phone by Bluetooth
can use the music player.（Note：Only can control
music but can not play, control smart phone to play
the previous and next one.)
4.1.1 How to control music
Press "OK" to enter the function interface when in
the music control menu, press top and bottom key
to select the previous and the next one, press "OK"
to play or pause.
4.2 Record
Begin Recording
Press "OK" to enter the function interface when in
the recording menu, press top and bottom key to
select the function you want, choose the record
mark and begin to record.
Save/Pause/Give up
When recording the screen will show the record
time, press “OK”will show“save/pause/give up ”,
select function by press top and bottom key, press
“OK”to confirm, press recording key to continue
recording.
Profiles
Outdoors Mode
Restore Factory Setting
Airplane Mode
Standard Mode Mute
Meeting mode
4.4.3 Dialer to Bluetooth Contacts
Press “OK”to enter the Bluetooth contacts, another
press to choose different functions, press top or
bottom key to “Text Message”, “Dial to the Contacts
“, “Save to the phone book”.
4.5 Message
Press "OK" to enter the message operation interface
when in the message menu, press top or bottom key
to “Text Message”,“Inbox”,“Drafts”,“Outbox”.
4.5.1 Text and Send Message
Choose “Text Message”, press “OK”when the
message is done and the screen will show “send”,
recipient could be choosed from contacts or input
number directly, press “OK”to send. Press top or
bottom key could choose“Save Message”,
”Punctuation”, “Input Method”and so on.
4.5.2 Inbox
Choose “Inbox”, press “OK” to enter the list, press
top and bottom key to select, press “OK”to read,
press again to “Reply”, “Add Contacts”, “Delete”,
“Forward”, “Dial”and so on.
4.5.3 Outbox
Choose “Outbox”, Press “OK” to the list, press top or
bottom key to choose, and press “OK”to read, press
“OK”again to “Forward”or “Delete”.
4.5.4 Drafts
Choose “Drafts”, press “OK”to the list, press top or
bottom key to choose, and press “OK”to read, “OK”
again to “Send”, ”Edit”, “Delete”and so on.
4.6 Call History
Press “OK” to the call history, another press to
choose and “OK”again to “Add contacts”, “Dial “,
“Send Message”, “Delete Call History ”.
4.7 Setting
4.7.1 Alarm Clock Setting
Enter setting-alarm, press “OK” begin to set time,
Press “OK”could enjoy the following functions after
setting done: “Ringtone Setting”, “Repeat Setting”,
“Save Alarm Clock”and so on. The circle could
become solid after successful setting.
4.7.1.1
How to turn off
Enter setting-Alarm Clock, choose the one you want
to delete, press “OK”to confirm, the circle would be
hollow.
4.7.2 Phone Setting
This including: “Date Setting”, “Time Setting”, “Zone
Setting”, “Time Format Setting”, “System Language
Setting”, “Ringtone Setting”, “Volume Setting”,
“Operator Manul Setting”, “Screen display Time
Setting”, Details See Below：
4.7.3 Profiles
It including: “Standard Mode”,“Silent Mode”,
“Conference Mode”, “Outdoors Mode”, “Airplane
Mode”. Press “OK” to confirm the one you like.
4.7.4 Restore Factory Setting
Enter setting- restore factory settings, press “OK” get
a notification and “OK” again could accomplish the
setting, press return button to cancel. It can be
restored to the initial status.
4.8 Calculator
Long press calculator key to enter when in standby
interface, then Talkase will be a calculator, input
number to count directly.
Anti-Lost
Press "OK" to enter Anti-Lost function, another press
to switch on or off (Only available after connected by
bluetooth).
Shortcut Key
1. When the Bluetooth is turned off, press return
botton on standby interface, "Connect by..." comes
out, press "OK" can activate Bluetooth rapidly,
otherwise it will be turned on by press the return
botton when the Bluetooth is turned off.
2. Press “#” could exchange input method, press “*”
could choose different punctuation mark when
texting message or edit the contacts’ name.
3. Press OK key to turn on/off the loudspeaker while
in the call status.
14

4.4 Contacts
Press "OK" to enter the contacts list when in the
contacts menu，press top or bottom key to select SIM
card contacts, Bluetooth contacts and add contacts.
4.4.1 Add Contacts
Press "OK" will show the pop-up circle in add
contacts menu, press top or bottom key to input
name and number to the input area, press “OK”to
save or cancel. Press “#” to choose input method.
4.4.2 Call SIM Card Contacts
Press top and bottom key to choose contacts from
SIM Card Contacts, then press “OK”will show “Find
Contacts”, “Send Message”, “Call the Contacts”,
“Edit Contacts”,”Delete Contacts”, “Choose the Save
Area”and so on. Press top or bottom key to select
“Call the Contacts”.
Play and Delete Record List
Press top or bottom key to select, press OK to enter
the record list, press top or bottom key to choose
that you want to play, press “OK”will show “play”or
“delete” , select by press top or bottom key, press
“OK”to confirm.
4.3 Bluetooth
4.3.1 Instrcution of Bluetooth
Open the Bluetooth, search the Talkase Bluetooth on
your smart phone, then pair it.
1. Instruction Before Use
1.1. Install SIM Card
1.2. Charging Method
2. Instruction of Buttons
3. Starter
3.1. Standby Interface
3.2. How to Use Dialer
4. Menu
4.1. Music Player
4.2. Record
4.3. Bluetooth
4.4. Contacts
4.5. Message
4.6. Call History
4.7. Setting
4.8. Calculator
4.9. Anti-Lost
4.10. Shortcut Key
1.1 Install SIM Card
The SIM card slot is on the right side of the back of
Talkase, first remove the cover as instructed, then
put the SIM card into the slot, close the cover, the
installing is done.
Only support micro SIM card.
1.2 Charging Method
Let the four metal contacts of charging slip
correspond to the four of Talkase, then press the
charging clip to ensure it is tightly attached to the
back of Talkase, connect the computer using USB
cable or an adapter for charging. Take out the clip
from down to up in vertical direction, sliding way is
not suggested for protecting the four contacts in
charging clip.
3.1.Standby Interface
Long press the power key to start up, standby
interface show the internet signal, Battery Capacity,
and the message notification when there is message
you have not read. When open the Bluetooth it will
show on the interface too. The middle of the
interface is the present time. Press top or bottom
menu key for changing different function.
Lock and Unlock
Press power on/off key and "#" simultaneously to
lock or unlock.
3.2 How to Use Dialer
Press the number key can make a call directly, or dial
by GSM SIM card, or use the BT call to make a dial
after connecting with your smart phone through
Bluetooth.（There must be a SIM card in your smart
phone, how to pair the Bluetooth please refer to
BT3.5）. If there is error in input number using the
delete key to correct.
4.1 Bluetooth Music Control
After connecting with the smart phone by Bluetooth
can use the music player.（Note：Only can control
music but can not play, control smart phone to play
the previous and next one.)
4.1.1 How to control music
Press "OK" to enter the function interface when in
the music control menu, press top and bottom key
to select the previous and the next one, press "OK"
to play or pause.
4.2 Record
Begin Recording
Press "OK" to enter the function interface when in
the recording menu, press top and bottom key to
select the function you want, choose the record
mark and begin to record.
Save/Pause/Give up
When recording the screen will show the record
time, press “OK”will show“save/pause/give up ”,
select function by press top and bottom key, press
“OK”to confirm, press recording key to continue
recording.
4.4.3 Dialer to Bluetooth Contacts
Press “OK”to enter the Bluetooth contacts, another
press to choose different functions, press top or
bottom key to “Text Message”, “Dial to the Contacts
“, “Save to the phone book”.
4.5 Message
Press "OK" to enter the message operation interface
when in the message menu, press top or bottom key
to “Text Message”,“Inbox”,“Drafts”,“Outbox”.
4.5.1 Text and Send Message
Choose “Text Message”, press “OK”when the
message is done and the screen will show “send”,
recipient could be choosed from contacts or input
number directly, press “OK”to send. Press top or
bottom key could choose“Save Message”,
”Punctuation”, “Input Method”and so on.
4.5.2 Inbox
Choose “Inbox”, press “OK” to enter the list, press
top and bottom key to select, press “OK”to read,
press again to “Reply”, “Add Contacts”, “Delete”,
“Forward”, “Dial”and so on.
4.5.3 Outbox
Choose “Outbox”, Press “OK” to the list, press top or
bottom key to choose, and press “OK”to read, press
“OK”again to “Forward”or “Delete”.
4.5.4 Drafts
Choose “Drafts”, press “OK”to the list, press top or
bottom key to choose, and press “OK”to read, “OK”
again to “Send”, ”Edit”, “Delete”and so on.
4.6 Call History
Press “OK” to the call history, another press to
choose and “OK”again to “Add contacts”, “Dial “,
“Send Message”, “Delete Call History ”.
4.7 Setting
4.7.1 Alarm Clock Setting
Enter setting-alarm, press “OK” begin to set time,
Press “OK”could enjoy the following functions after
setting done: “Ringtone Setting”, “Repeat Setting”,
“Save Alarm Clock”and so on. The circle could
become solid after successful setting.
4.7.1.1
How to turn off
Enter setting-Alarm Clock, choose the one you want
to delete, press “OK”to confirm, the circle would be
hollow.
4.7.2 Phone Setting
This including: “Date Setting”, “Time Setting”, “Zone
Setting”, “Time Format Setting”, “System Language
Setting”, “Ringtone Setting”, “Volume Setting”,
“Operator Manul Setting”, “Screen display Time
Setting”, Details See Below：
4.7.3 Profiles
It including: “Standard Mode”,“Silent Mode”,
“Conference Mode”, “Outdoors Mode”, “Airplane
Mode”. Press “OK” to confirm the one you like.
4.7.4 Restore Factory Setting
Enter setting- restore factory settings, press “OK” get
a notification and “OK” again could accomplish the
setting, press return button to cancel. It can be
restored to the initial status.
4.8 Calculator
Long press calculator key to enter when in standby
interface, then Talkase will be a calculator, input
number to count directly.
Anti-Lost
Press "OK" to enter Anti-Lost function, another press
to switch on or off (Only available after connected by
bluetooth).
8+9
Calculator
Long press to enter or
exit the calculator
Return to main menu
CE Zero Clearing
Anti-Lost On and Off
Shortcut Key
1. When the Bluetooth is turned off, press return
botton on standby interface, "Connect by..." comes
out, press "OK" can activate Bluetooth rapidly,
otherwise it will be turned on by press the return
botton when the Bluetooth is turned off.
2. Press “#” could exchange input method, press “*”
could choose different punctuation mark when
texting message or edit the contacts’ name.
3. Press OK key to turn on/off the loudspeaker while
in the call status.
15

4.4 Contacts
Press "OK" to enter the contacts list when in the
contacts menu，press top or bottom key to select SIM
card contacts, Bluetooth contacts and add contacts.
4.4.1 Add Contacts
Press "OK" will show the pop-up circle in add
contacts menu, press top or bottom key to input
name and number to the input area, press “OK”to
save or cancel. Press “#” to choose input method.
4.4.2 Call SIM Card Contacts
Press top and bottom key to choose contacts from
SIM Card Contacts, then press “OK”will show “Find
Contacts”, “Send Message”, “Call the Contacts”,
“Edit Contacts”,”Delete Contacts”, “Choose the Save
Area”and so on. Press top or bottom key to select
“Call the Contacts”.
Play and Delete Record List
Press top or bottom key to select, press OK to enter
the record list, press top or bottom key to choose
that you want to play, press “OK”will show “play”or
“delete” , select by press top or bottom key, press
“OK”to confirm.
4.3 Bluetooth
4.3.1 Instrcution of Bluetooth
Open the Bluetooth, search the Talkase Bluetooth on
your smart phone, then pair it.
1. Instruction Before Use
1.1. Install SIM Card
1.2. Charging Method
2. Instruction of Buttons
3. Starter
3.1. Standby Interface
3.2. How to Use Dialer
4. Menu
4.1. Music Player
4.2. Record
4.3. Bluetooth
4.4. Contacts
4.5. Message
4.6. Call History
4.7. Setting
4.8. Calculator
4.9. Anti-Lost
4.10. Shortcut Key
1.1 Install SIM Card
The SIM card slot is on the right side of the back of
Talkase, first remove the cover as instructed, then
put the SIM card into the slot, close the cover, the
installing is done.
Only support micro SIM card.
1.2 Charging Method
Let the four metal contacts of charging slip
correspond to the four of Talkase, then press the
charging clip to ensure it is tightly attached to the
back of Talkase, connect the computer using USB
cable or an adapter for charging. Take out the clip
from down to up in vertical direction, sliding way is
not suggested for protecting the four contacts in
charging clip.
3.1.Standby Interface
Long press the power key to start up, standby
interface show the internet signal, Battery Capacity,
and the message notification when there is message
you have not read. When open the Bluetooth it will
show on the interface too. The middle of the
interface is the present time. Press top or bottom
menu key for changing different function.
Lock and Unlock
Press power on/off key and "#" simultaneously to
lock or unlock.
3.2 How to Use Dialer
Press the number key can make a call directly, or dial
by GSM SIM card, or use the BT call to make a dial
after connecting with your smart phone through
Bluetooth.（There must be a SIM card in your smart
phone, how to pair the Bluetooth please refer to
BT3.5）. If there is error in input number using the
delete key to correct.
4.1 Bluetooth Music Control
After connecting with the smart phone by Bluetooth
can use the music player.（Note：Only can control
music but can not play, control smart phone to play
the previous and next one.)
4.1.1 How to control music
Press "OK" to enter the function interface when in
the music control menu, press top and bottom key
to select the previous and the next one, press "OK"
to play or pause.
4.2 Record
Begin Recording
Press "OK" to enter the function interface when in
the recording menu, press top and bottom key to
select the function you want, choose the record
mark and begin to record.
Save/Pause/Give up
When recording the screen will show the record
time, press “OK”will show“save/pause/give up ”,
select function by press top and bottom key, press
“OK”to confirm, press recording key to continue
recording.
4.4.3 Dialer to Bluetooth Contacts
Press “OK”to enter the Bluetooth contacts, another
press to choose different functions, press top or
bottom key to “Text Message”, “Dial to the Contacts
“, “Save to the phone book”.
4.5 Message
Press "OK" to enter the message operation interface
when in the message menu, press top or bottom key
to “Text Message”,“Inbox”,“Drafts”,“Outbox”.
4.5.1 Text and Send Message
Choose “Text Message”, press “OK”when the
message is done and the screen will show “send”,
recipient could be choosed from contacts or input
number directly, press “OK”to send. Press top or
bottom key could choose“Save Message”,
”Punctuation”, “Input Method”and so on.
4.5.2 Inbox
Choose “Inbox”, press “OK” to enter the list, press
top and bottom key to select, press “OK”to read,
press again to “Reply”, “Add Contacts”, “Delete”,
“Forward”, “Dial”and so on.
4.5.3 Outbox
Choose “Outbox”, Press “OK” to the list, press top or
bottom key to choose, and press “OK”to read, press
“OK”again to “Forward”or “Delete”.
4.5.4 Drafts
Choose “Drafts”, press “OK”to the list, press top or
bottom key to choose, and press “OK”to read, “OK”
again to “Send”, ”Edit”, “Delete”and so on.
4.6 Call History
Press “OK” to the call history, another press to
choose and “OK”again to “Add contacts”, “Dial “,
“Send Message”, “Delete Call History ”.
4.7 Setting
4.7.1 Alarm Clock Setting
Enter setting-alarm, press “OK” begin to set time,
Press “OK”could enjoy the following functions after
setting done: “Ringtone Setting”, “Repeat Setting”,
“Save Alarm Clock”and so on. The circle could
become solid after successful setting.
4.7.1.1
How to turn off
Enter setting-Alarm Clock, choose the one you want
to delete, press “OK”to confirm, the circle would be
hollow.
4.7.2 Phone Setting
This including: “Date Setting”, “Time Setting”, “Zone
Setting”, “Time Format Setting”, “System Language
Setting”, “Ringtone Setting”, “Volume Setting”,
“Operator Manul Setting”, “Screen display Time
Setting”, Details See Below：
4.7.3 Profiles
It including: “Standard Mode”,“Silent Mode”,
“Conference Mode”, “Outdoors Mode”, “Airplane
Mode”. Press “OK” to confirm the one you like.
4.7.4 Restore Factory Setting
Enter setting- restore factory settings, press “OK” get
a notification and “OK” again could accomplish the
setting, press return button to cancel. It can be
restored to the initial status.
4.8 Calculator
Long press calculator key to enter when in standby
interface, then Talkase will be a calculator, input
number to count directly.
Anti-Lost
Press "OK" to enter Anti-Lost function, another press
to switch on or off (Only available after connected by
bluetooth).
Shortcut Key
1. When the Bluetooth is turned off, press return
botton on standby interface, "Connect by..." comes
out, press "OK" can activate Bluetooth rapidly,
otherwise it will be turned on by press the return
botton when the Bluetooth is turned off.
2. Press “#” could exchange input method, press “*”
could choose different punctuation mark when
texting message or edit the contacts’ name.
3. Press OK key to turn on/off the loudspeaker while
in the call status.
16

NOTICE
This product complies with the requirement of the 1999/5/EC directive.
The maximum operating temperature of the product is 40 ℃.
FCC Statement
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired
operation.
The grantee is not responsible for any changes or modifications not expressly approved by the party responsible
for compliance. Such modifications could void the user’s authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
Specific Absorption Rate(SAR)
Information SAR tests are conducted using standard operating positions accepted by the FCC with the Phone
transmitting at its highest certified power level in all tested frequency bands, although the SAR is determined at
the highest certified power level, the actual SAR level of the phone While operating can be well below the
maximum value, in general,the closer you are to a Wireless base station antenna, the lower the power
output.Before a new model phone is available for sale to the public, it must be tested and certified to the FCC
that it does not exceed the exposure limit established by the FCC, Tests for each the FCC that it does not exceed
the exposure limit established by the FCC,Tests for each required by the FCC.
For body worn operation, this phone has been tested and meets FCC RF exposure guidelines when
used with an accessory that contains no metal and that positions the handset a minimum of 1.0cm
from the body. Use of other accessories may not ensure compliance with FCC RF exposure
guidelines.
