Tamarack Technologies HV1600 User manual

1
HV1600 Wi-Fi Hub Instruction Manual.
PERFORM THESE TASKS AFTER THE FAN HAS BEEN INSTALLED AND, HAS POWER.
Devices that must be present to control the Wi-Fi Hub.
An active 2.4 GHz wireless home network is required to control the HV1600 Hub with several
smart devices and, maintain internet access to the smart devices (recommended).
Without a wireless home network present the HV1600 Hub can be controlled directly
with the Tamarack app with a single (1) smart device at one time. To control the fan with one
smart device without a wireless home network complete only step one “Out of box”of the
instructions.
During the setup process “Out of the box” only one smart device can be used to setup
the Hub and configure it to the wireless home network.
Use the Tamarack app to provide the wireless network information to the HV1600
Hub. Adding the HV1600 Hub to your wireless home network will allow for several smart
devices to control the fan at the same time with the Tamarack app.
Compatible Smart Devices.
Phones: iOS and Android. An active phone account is not required to interact with the Hub over
Wi-Fi home network with the Tamarack app. The phone will need to have access to the Apple
Store or a Google Play account to download and use the Tamarack app.
Tablets: iOS and any Android device that has access to the Apple Store or a Google Play account
to download and use the Tamarack app.
Tamarack app Tamarack app
On iTunes Store. On Google play

2
Recommended:
Update the iOS and Android devices with any available operating system updates.
Update the home Wi-Fi network with any driver updates if needed.
Download the current version of the Tamarack app to the device that will be used to setup the HV1600 Hub to your
home Wi-Fi network.
After completing step 2. Connecting the iFan Hub to the wireless home network you may also download the
Tamarack app to any other compatible device to control the HV1600 Hub over the wireless home network.
The Wi-Fi Hub can only be accessed and controlled by the app while within range of the wireless home network.
The Hub is not accessible through the internet. The Hub is only controllable through your wireless local area
network. Timers may be set before leaving the WLAN and will count down if the smart device is no longer
connected to the network.
1. “Out of the box” Setup of the Hub is required to be performed with a smart phone or tablet.
Before you can connect your HV1600 to your wireless home network you must connect directly to the HV1600 Hub with
your smart device via Wi-Fi. ONLY ONE SMART DEVICE CAN INTERACT WITH THE HUB UNTIL IT HAS BEEN ADDED TO A
WIRELESS HOME NETWORK.
A. Confirm power to the HV1600 Hub is provided and, constant.
B. The Tamarack App must be present on the smart device.
C. With the smart device, navigate to the Wi-Fi settings utility on the phone or tablet.
D. In the “wireless networks available” location on the phone or tablet you will see the
Hub SSID listed as a Wi-Fi hot spot and, it will be identified as (WV-xxxxxxxxxx,). The
HV1600 Hub SSID network name is also located inside the Hub’s front cover on a label.
E. Select the HV1600 Hub network and, use the default password to join the network. The
default password to access the Hub is myfan.
F. After successfully connecting to the HV1600 Hub network you may now open the
Tamarack app and setup the fan. Select the fan listed on the home screen of the app.
The fan name will appear as WV-xxxxxxxxxxx.
E
F
G

3
G. On the “Setup Fan Controller” screen of the app select the default number of fan
speeds is (2) and should already be set to that value. Select SAVE after making no
changes.
H. The “Fan Speed” screen will then open and, select change speed. The app will now
return to the home screen of the app. The HV1600 can now be controlled with the app.
I. To operate the HV1600 with no wireless home network present or to test the fan
select the fan listed on the home page. On the next screen will be a dial to adjust the
timer.
J. Move the dial clockwise in increments of 30 minutes up to 8 hours and then select
“START”.Selecting start will activate the HV1600 and, then the insulated doors will start
to open. The doors will take approximately 30 seconds to open and, then the two fan
motors will activate after reaching open position. To turn the fan off select “TURN FAN
OFF”.If the fan is not manually turned off by selecting “TURN FAN OFF” the fan will run
for however long the dial timer was set to. Beyond 8:00, the time will display as Hold
(The fan will move air continuously until told to shut off manually).
K. On the second page of the Tamarack App in the center of the screen you can change the
speed of the fan by choosing high or low speed.
2. Connecting the HV1600 Hub to the wireless home network.
A. During this part of the setup process, disable any software that blocks ads on the
smart phone or tablet. This type of app will prevent the pairing of the hub to your
wireless home network.
B. The smart device must be connected to the Hub as directed on page 2 to add the Hub to
the wireless home network. Double check and confirm that the smart device is
currently connected to the Hub and, has not reconnected on its own to the wireless
home network.
H
I
J
K

4
C. Open the Tamarack App and select the fan listed on the home screen.
D. Select the GEAR icon in the upper right corner of the screen.
E. Select Network.
F. Select Wi-Fi and, then Wi-Fi mode to change the settings from Access Point to Station
Mode.
G. Select Network SSID and, enter the wireless home network name in the open field.
H. Select Password and delete the previous password (myfan or dots shown) and enter
the wireless home network password in the open field.
C
D
E
F
G
G&H
I
J
J

5
I. Page (4) Select Security and change from WEP to WPA. *If the wireless home network
does not have WPA security available then the security setting will need to be set to
WEP.
J. Page (4) Select SAVE on both pages of the app and, then close the app completely. To
close the app completely follow the instruction below per the smart device being
used.
iOS devices: Double press the home button, find the Tamarack app and, swipe it
up to close it completely.
Android devices: Open the “close all screen”and find the Tamarack App then
press Xto close it completely.
K. The Hub has now been instructed to connect to the wireless home network and, will no
longer appear as an “available wireless network”. The connecting process of the HV1600
Hub to the wireless home network may take approximately 90 seconds to complete.
*If any login information was entered incorrectly, e.g. Network Name, Password, and
the selection of WPA or WEP, the Wi-Fi Hub will revert back to Station Mode after 90
seconds has passed.
L. Open the Wi-Fi settings page on the smart device and, select the wireless home
network and reconnect to it.
M. Open the Tamarack App and, swipe the fan shown down on the main page of the app to
refresh the communication of the app to the Hub through the wireless home network.
Select the fan listed and, activate the fan as instructed previously to confirm
communication through the wireless home network to the Hub.
FAQ and Troubleshooting;
1. How do I operate the HV1600Hub?
A. Open the Tamarack app on your smart device.
B. Select the Hub on the Device Management screen.
C. Click the drop-down and select a fan speed.
D. Drag the selector around the circle to set the time from 0:30 to 8:00. Beyond 8:00, the time will
display as Hold (The fan will move air continuously until told to shut off).
2. How do I turn the fan ON/OFF without using the timer function?
1st Method: From the Device Management screen, press Menu on the upper-left corner.
Select ON/OFF. On the home screen a GREEN circle will appear around the fan image when
ON.
2nd Method: Rotate the timer dial clock wise past 8 hours. Select HOLD and then ON (the fan
will run until turned off). On the home screen a GREEN circle will be lit.
3. (Security) If you would like to change the default network password, go to the Network Settings within
the Tamarack app to change the password to the Hub. (Default PW is myfan).
4. Q. Can I control my Wi-Fi fan from anywhere?
A. The Wi-Fi Hub can only be accessed and controlled by the app while within range of the wireless
home network. The Hub is not accessible through the internet. The Hub is only controllable through
your wireless local area network. Timers may be set before leaving the WLAN and will count down
if the smart device is no longer connected to the network.

6
5. How do I check if software updates are available for the HV1600 Hub?
A. Select the Hub from the Device Management screen.
B. Select the Gear icon, located at the upper-right corner of the screen.
C. Select About.
D. The About screen will show the current firmware version installed.
E. If a software update is available for the Hub, the Upgrade button will be selectable.
F. To start the upgrade process, press Upgrade
6. How do I perform a “Factory Reset”?
A. Factory Reset allows you to return the Hub to the default factory settings. All information added
to the Hub will be forgotten after the reset is performed.
B. There are two methods of performing a factory reset to the Hub.
1st Method: From the Tamarack app, within the Diagnostics menu.
Select the Hub from the Device Management screen to be reset.
Select the Gear Icon, located at the upper-right of the screen.
Select Diagnostics.
Press Factory Reset.
Press Reset.
2nd Method: With access to the installed HV1600 Hub location.
Access the two buttons marked as Join and Fan on the face of the Hub.
Press and hold the two buttons until two LED’s start to blink.
Release the buttons, the Factory Reset is complete.
After a factory reset has been performed repeat the “Out of box” instructions to begin
the setup process from the beginning. Listed on page 2, Step 1.
Optional: Wiring manual switches to bypass the wireless Hub to control the fan.
There are wires located in the junction box hard mounted to the Wi-Fi Hub to allow for the use of two SP/ST (single pole /
single throw) wall switches to bypass the Wi-Fi Hub method of control. When the manual switches are in use the fan
cannot be turned off using the app or changed to low speed if the speed switch is set to high speed. See wiring instructions
portion of the installation manual for details.
