Tannoy AMS 8DC User manual

Quick Start Guide
AMS Series
AMS 8DC
8" Dual Concentric Surface-Mount Loudspeaker for Installation Applications
AMS 6DC, AMS 6ICT, AMS 6ICT LS
6" Dual Concentric/ICT Surface-Mount Loudspeaker for Installation
& Life Safety Installation Applications
AMS 5DC, AMS 5ICT, AMS 5ICT LS
5" Dual Concentric/ICT Surface-Mount Loudspeaker for Installation
& Life Safety Installation Applications

LEGAL DISCLAIMER
Important Safety
Instructions
Terminals marked with
this symbol carry
electrical current of
sucient magnitude to constitute risk
of electric shock. Use only high-quality
professional speaker cables with ¼" TS
or twist-locking plugs pre-installed.
Allother installation or modication
should be performed only by
qualiedpersonnel.
This symbol, wherever it
appears, alerts you to the
presence of uninsulated
dangerous voltage inside the enclosure
- voltage that may be sucient to
constitute a risk ofshock.
This symbol, wherever it
appears, alerts you to
important operating and
maintenance instructions in the
accompanying literature. Please read
themanual.
Caution
To reduce the risk of
electric shock, do not
remove the top cover (or the rear
section). No user serviceable parts inside.
Refer servicing to qualiedpersonnel.
Caution
To reduce the risk of
re or electric shock, do
not expose this appliance to rain and
moisture. Theapparatus shall not
be exposed to dripping or splashing
liquids and no objects lled with
liquids, such as vases, shall be placed
on the apparatus.
Caution
These service instructions
are for use by qualied
service personnel only. Toreduce
the risk of electric shock do not
perform any servicing other than that
contained in the operation instructions.
Repairshave to be performed by
qualied servicepersonnel.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus
near water.
6. Clean only with dry cloth.
7. Do not block any ventilation
openings. Install in accordance with the
manufacturer’s instructions.
8. Do not install near any heat
sources such as radiators, heat registers,
stoves, or other apparatus (including
ampliers) that produce heat.
9. Do not defeat the safety purpose
of the polarized or grounding-type
plug. A polarized plug has two blades
with one wider than the other.
A grounding-type plug has two blades
and a third grounding prong. The wide
blade or the third prong are provided
for your safety. Ifthe provided plug
does not t into your outlet, consult
an electrician for replacement of the
obsolete outlet.
10. Protect the power cord from being
walked on or pinched particularly
at plugs, convenience receptacles,
and the point where they exit from
the apparatus.
11. Use only attachments/accessories
specied by themanufacturer.
12. Use only with
the cart, stand,
tripod, bracket, or
table specied by
the manufacturer,
orsold with
the apparatus. When a cart is used,
use caution when moving the cart/
apparatus combination to avoid injury
from tip-over.
13. Unplug this apparatus during
lightning storms or when unused for
long periods of time.
14. Refer all servicing to qualied
service personnel. Servicing is required
when the apparatus has been damaged
in any way, such as power supply cord
or plug is damaged, liquid has been
spilled or objects have fallen into the
apparatus, the apparatus has been
exposed to rain or moisture, does not
operate normally, or has beendropped.
15. The apparatus shall be connected
to a MAINS socket outlet with a
protective earthing connection.
16. Where the MAINS plug or an
appliance coupler is used as the
disconnect device, the disconnect
device shall remain readily operable.
17. Correct disposal of
this product: This
symbol indicates that
this product must not
be disposed of with
household waste, according to the
WEEE Directive (2012/19/EU) and your
national law. This product should be
taken to a collection center licensed for
the recycling of waste electrical and
electronic equipment (EEE).
The mishandling of this type of waste
could have a possible negative impact
on the environment and human health
due to potentially hazardous
substances that are generally
associated with EEE. At the same time,
your cooperation in the correct disposal
of this product will contribute to the
ecient use of natural resources. For
more information about where you can
take your waste equipment for
recycling, please contact your local city
oce, or your household waste
collection service.
18. Do not install in a conned space,
such as a book case or similar unit.
19. Do not place naked ame
sources, such as lighted candles,
on the apparatus.
20. Please keep the environmental
aspects of battery disposal in mind.
Batteries must be disposed-of at a
battery collection point.
21. Use this apparatus in tropical
and/or moderate climates.
Music Tribe accepts no liability for
any loss which may be suered by
any person who relies either wholly
or in part upon any description,
photograph, or statement contained
herein. Technical specications,
appearances and other information
are subject to change without notice.
2 3Quick Start GuideAMS Series
All trademarks are the property
of their respective owners. Midas,
Klark Teknik, Lab Gruppen, Lake,
Tannoy, Turbosound, TC Electronic,
TC Helicon, Behringer, Bugera and
Coolaudio are trademarks or registered
trademarks of Music Tribe Global
Brands Ltd. © Music Tribe Global
Brands Ltd. 2018 All rights reserved.
For the applicable warranty terms and
conditions and additional information
regarding Music Tribe’s Limited
Warranty, please see complete details
online at musictribe.com/warranty.
Zhongshan Eurotec
Electronics Limited
No. 10 Wanmei Road, South China
Modern Chinese Medicine Park,
Nanlang Town, 528451, Zhongshan
City, Guangdong Province, China
Las terminales marcadas
con este símbolo
transportan corriente
eléctrica de magnitud suciente como
para constituir un riesgo de descarga
eléctrica. Utilicesolo cables de altavoz
profesionales y de alta calidad con
conectores TS de 6,3 mm o de bayoneta
prejados. Cualquier otra instalación o
modicación debe ser realizada
únicamente por un técnicocualicado.
Este símbolo, siempre que
aparece, leadvierte de la
presencia de voltaje
peligroso sin aislar dentro de la caja;
estevoltaje puede ser suciente para
constituir un riesgo dedescarga.
Este símbolo, siempre que
aparece, leadvierte sobre
instrucciones operativas y
de mantenimiento que aparecen en la
documentación adjunta. Por favor,
leaelmanual.
Atención
Para reducir el riesgo de
descarga eléctrica, no
quite la tapa (olaparte posterior).
Nohay piezas en el interior del equipo
que puedan ser reparadas por el
usuario. Sies necesario, póngase en
contacto con personal cualicado.
Atención
Para reducir el riesgo
de incendio o descarga
eléctrica, no exponga este aparato a la
lluvia, humedad o alguna otra fuente
que pueda salpicar o derramar algún
líquido sobre el aparato. Nocoloque
ningún tipo de recipiente para líquidos
sobre elaparato.
Atención
Las instrucciones
de servicio deben
llevarlas a cabo exclusivamente
personal cualicado. Paraevitar el
riesgo de una descarga eléctrica,
no realice reparaciones que no se
encuentren descritas en el manual de
operaciones. Lasreparaciones deben
ser realizadas exclusivamente por
personalcualicado.
1. Lea las instrucciones.
2. Conserve estas instrucciones.
3. Preste atención a todas
las advertencias.
4. Siga todas las instrucciones.
5. No use este aparato cerca
del agua.
6. Limpie este aparato con un
paño seco.
7. No bloquee las aberturas
de ventilación. Instale el equipo
de acuerdo con las instrucciones
del fabricante.
8. No instale este equipo cerca de
fuentes de calor tales como radiadores,
acumuladores de calor, estufas u otros
aparatos (incluyendo amplicadores)
que puedan producir calor.
9. No elimine o deshabilite nunca
la conexión a tierra del aparato o del
cable de alimentación de corriente.
Unenchufe polarizado tiene dos polos,
uno de los cuales tiene un contacto
más ancho que el otro. Una clavija
con puesta a tierra dispone de tres
contactos: dos polos y la puesta a
tierra. El contacto ancho y el tercer
contacto, respectivamente, son los que
garantizan una mayor seguridad. Si el
enchufe suministrado con el equipo
no concuerda con la toma de corriente,
consulte con un electricista para
cambiar la toma de corriente obsoleta.
10. Coloque el cable de suministro de
energía de manera que no pueda ser
pisado y que esté protegido de objetos
alados. Asegúrese de que el cable de
suministro de energía esté protegido,
especialmente en la zona de la clavija y
en el punto donde sale del aparato.
11. Use únicamente los dispositivos
o accesorios especicados por
el fabricante.
12. Use
únicamente la
carretilla,
plataforma,
trípode, soporte o
mesa especicados
por el fabricante o suministrados junto
con el equipo. Altransportar el equipo,
tenga cuidado para evitar daños y
caídas al tropezar con algún obstáculo.
13. Desenchufe el equipo durante
tormentas o si no va a utilizarlo durante
un periodo largo.
14. Confíe las reparaciones
únicamente a servicios técnicos
cualicados. La unidad requiere
mantenimiento siempre que haya
sufrido algún daño, si el cable de
suministro de energía o el enchufe
presentaran daños, sehubiera
derramado un líquido o hubieran caído
objetos dentro del equipo, si el aparato
hubiera estado expuesto a la humedad
o la lluvia, si ha dejado de funcionar de
manera normal o si ha sufrido algún
golpe o caída.
15. Al conectar la unidad a la toma de
corriente eléctrica asegúrese de que
la conexión disponga de una unión
atierra.
LIMITED WARRANTY
Instrucciones de
seguridad

4 5Quick Start GuideAMS Series
16. Si el enchufe o conector
de red sirve como único medio
de desconexión, éste debe ser
accesiblefácilmente.
17. Cómo debe
deshacerse de este
aparato: Este símbolo
indica que este aparato
no debe ser tratado
como basura orgánica, según lo
indicado en la Directiva WEEE (2012/19/
EU) y a las normativas aplicables en su
país. En lugar de ello deberá llevarlo al
punto limpio más cercano para el
reciclaje de sus elementos eléctricos/
electrónicos (EEE). Al hacer esto estará
ayudando a prevenir las posibles
consecuencias negativas para el medio
ambiente y la salud que podrían ser
provocadas por una gestión inadecuada
de este tipo de aparatos. Además,
el reciclaje de materiales ayudará a
conservar los recursos naturales. Para
más información acerca del reciclaje de
este aparato, póngase en contacto con
el Ayuntamiento de su ciudad o con el
punto limpio local.
18. No instale esta unidad en un
espacio muy reducido, tal como
encastrada en una librería o similar.
19. No coloque objetos con
llama, como una vela encendida,
sobre este aparato.
20. Tenga presentes todas las
advertencias relativas al reciclaje
y correcta eliminación de las pilas.
Las pilas deben ser siempre eliminadas
en un punto limpio y nunca con el resto
de la basura orgánica.
21. Use este aparato en rangos de
temperatura moderados y/o tropicales.
Music Tribe no admite ningún tipo
de responsabilidad por cualquier
daño o pérdida que pudiera sufrir
cualquier persona por conar total
o parcialmente en la descripciones,
fotografías o armaciones
contenidas en este documento.
Las especicaciones técnicas,
imágenes y otras informaciones
contenidas en este documento están
sujetas a modicaciones sin previo
aviso. Todas las marcas comerciales
que aparecen aquí son propiedad
de sus respectivos dueños. Midas,
Klark Teknik, Lab Gruppen, Lake,
Tannoy, Turbosound, TC Electronic,
TC Helicon, Behringer, Bugera y
Coolaudio son marcas comerciales
o marcas registradas de Music Tribe
Global Brands Ltd. © Music Tribe Global
Brands Ltd. 2018 Reservados todos
los derechos.
Si quiere conocer los detalles y
condiciones aplicables de la garantía
así como información adicional sobre
la Garantía limitada de Music Tribe,
consulte online toda la información en
la web musictribe.com/warranty.
Les points repérés par ce
symbole portent une
tension électrique
susante pour constituer un risque
d’électrocution. Utilisez uniquement
des câbles d’enceintes professionnels
de haute qualité avec ches Jack mono
6,35 mm ou ches à verrouillages déjà
installées. Touteautre installation ou
modication doit être eectuée
uniquement par un personnel qualié.
Ce symbole avertit de la
présence d’une tension
dangereuse et non isolée à
l’intérieur de l’appareil - elle peut
provoquer des chocs électriques.
Attention
Ce symbol signale les
consignes d’utilisation
et d’entre ! Tienimportantes dans
la documentation fournie. Lisez les
consignes de sécurité du manuel
d’utilisation del’appareil.
Attention
Pour éviter tout risque
de choc électrique,
ne pas ouvrir le capot de l’appareil
ni démonter le panneau arrière.
L’intérieur de l’appareil ne possède
aucun élément réparable par
l’utilisateur. Laissertoute réparation à
un professionnelqualié.
Attention
Pour réduire les risques
de feu et de choc
électrique, n’exposez pas cet appareil
à la pluie, à la moisissure, auxgouttes
ou aux éclaboussures. Ne posez pas
de récipient contenant un liquide sur
l’appareil (unvase par exemple).
Attention
Ces consignes de
sécurité et d’entretien
sont destinées à un personnel
qualié. Pour éviter tout risque de
choc électrique, n’eectuez aucune
réparation sur l’appareil qui ne soit
décrite par le manuel d’utilisation.
Les éventuelles réparations doivent
être eectuées uniquement par un
technicienspécialisé.
1. Lisez ces consignes.
2. Conservez ces consignes.
3. Respectez tous les avertissements.
4. Respectez toutes les
consignes d’utilisation.
5. N’utilisez jamais l’appareil à
proximité d’un liquide.
6. Nettoyez l’appareil avec un
chion sec.
7. Veillez à ne pas empêcher la
bonne ventilation de l’appareil via ses
ouïes de ventilation. Respectezles
consignes du fabricant concernant
l’installation del’appareil.
8. Ne placez pas l’appareil à
proximité d’une source de chaleur telle
qu’un chauage, une cuisinière ou tout
appareil dégageant de la chaleur (y
compris un ampli depuissance).
9. Ne supprimez jamais la sécurité
des prises bipolaires ou des prises
terre. Les prises bipolaires possèdent
deux contacts de largeur diérente.
Leplus large est le contact de sécurité.
Les prises terre possèdent deux
contacts plus une mise à la terre
servant de sécurité. Si la prise du bloc
d’alimentation ou du cordon d’ali-
mentation fourni ne correspond pas à
celles de votre installation électrique,
faites appel à un électricien pour
eectuer le changement de prise.
10. Installez le cordon d’alimentation
de telle façon que personne ne puisse
marcher dessus et qu’il soit protégé
d’arêtes coupantes. Assurez-vous
que le cordon d’alimentation est
sufsamment protégé, notamment
au niveau de sa prise électrique et
de l’endroit où il est relié à l’appareil;
cela est également valable pour une
éventuelle rallonge électrique.
11. Utilisez exclusivement
des accessoires et des appareils
supplémentaires recommandés par
lefabricant.
12. Utilisez
exclusivement des
chariots, des
diables,
desprésentoirs,
despieds et des
surfaces de travail recommandés par le
fabricant ou livrés avec le produit.
Déplacezprécautionneusement tout
chariot ou diable chargé pour éviter
d’éventuelles blessures en cas dechute.
13. Débranchez l’appareil de la
tension secteur en cas d’orage ou si
l’appareil reste inutilisé pendant une
longue période de temps.
14. Les travaux d’entretien de
l’appareil doivent être eectués
uniquement par du personnel qualié.
Aucunentretien n’est nécessaire sauf si
l’appareil est endommagé de quelque
façon que ce soit (dommagessur le
cordon d’alimentation ou la prise par
exemple), siun liquide ou un objet
a pénétré à l’intérieur du châssis, si
l’appareil a été exposé à la pluie ou
à l’humidité, s’il ne fonctionne pas
correctement ou à la suite d’une chute.
15. L’appareil doit être connecté à une
prise secteur dotée d’une protection
par mise à la terre.
16. La prise électrique ou la prise
IEC de tout appareil dénué de bouton
marche/arrêt doit rester accessible
enpermanence.
17. Mise au rebut
appropriée de ce
produit: Ce symbole
indique qu’en accord
avec la directive DEEE
(2012/19/EU) et les lois en vigueur dans
votre pays, ce produit ne doit pas être
jeté avec les déchets ménagers.
Ce produit doit être déposé dans un
point de collecte agréé pour le
recyclage des déchets d’équipements
électriques et électroniques (EEE).
Une mauvaise manipulation de ce type
de déchets pourrait avoir un impact
négatif sur l’environnement et la santé
à cause des substances potentiellement
dangereuses généralement associées à
ces équipements. En même temps,
votre coopération dans la mise au rebut
de ce produit contribuera à l’utilisation
ecace des ressources naturelles.
Pour plus d’informations sur l’endroit
où vous pouvez déposer vos déchets
d’équipements pour le recyclage,
veuillez contacter votre mairie ou votre
centre local de collecte des déchets.
18. N’installez pas l’appareil dans un
espace conné tel qu’une bibliothèque
ou meuble similaire.
19. Ne placez jamais d’objets
enammés, tels que des bougies
allumées, sur l’appareil.
20. Gardez à l’esprit l’impact
environnemental lorsque vous mettez
des piles au rebus. Les piles usées
doivent être déposées dans un point de
collecte adapté.
21. Utilisez l’appareil dans un climat
tropical et/ou modéré.
Music Tribe ne peut être tenu pour
responsable pour toute perte pouvant
être subie par toute personne se
ant en partie ou en totalité à
toute description, photographie
ou armation contenue dans ce
document. Les caractéristiques,
l’apparence et d’autres informations
peuvent faire l’objet de modications
sans notication. Toutes les marques
appartiennent à leurs propriétaires
respectifs. Midas, Klark Teknik,
Lab Gruppen, Lake, Tannoy,
Turbosound, TC Electronic, TC Helicon,
Behringer, Bugera et Coolaudio sont
des marques ou marques déposées
de Music Tribe Global Brands Ltd.
© Music Tribe Global Brands Ltd.
2018 Tous droits réservés.
Pour connaître les termes et conditions
de garantie applicables, ainsi que
les informations supplémentaires et
détaillées sur la Garantie Limitée de
Music Tribe, consultez le site Internet
musictribe.com/warranty.
Vorsicht
Die mit dem Symbol
markierten Anschlüsse
führen so viel Spannung, dassdie
Gefahr eines Stromschlags besteht.
Verwenden Sie nur hochwertige,
professionelle Lautsprecherkabel
mit vorinstallierten 6,35 mm
MONO-Klinkensteckern oder
Lautsprecherstecker mit
Drehverriegelung. Alle anderen
Installationen oder Modikationen
sollten nur von qualiziertem
Fachpersonal ausgeführt werden.
Achtung
Um eine Gefährdung
durch Stromschlag
auszuschließen, darf die
Geräteabdeckung bzw.
Geräterückwandnicht abgenommen
werden. ImInnern des Geräts benden
sich keine vom Benutzer reparierbaren
Teile. Reparaturarbeiten dürfen
nur von qualiziertem Personal
ausgeführtwerden.
Consignes de sécurité
DÉNI LÉGAL
GARANTIE LIMITÉE
Wichtige
Sicherheitshinweise
NEGACIÓN LEGAL
GARANTÍA LIMITADA

BESCHRÄNKTE GARANTIE
HAFTUNGSAUSSCHLUSS
Instruções de
Segurança Importantes
Achtung
Um eine Gefährdung
durch Feuer bzw.
Stromschlag auszuschließen, darf
dieses Gerät weder Regen oder
Feuchtigkeit ausgesetzt werden
noch sollten Spritzwasser oder
tropfende Flüssigkeiten in das Gerät
gelangen können. Stellen Sie keine
mit Flüssigkeit gefüllten Gegenstände,
wie z. B. Vasen, aufdasGerät.
Achtung
Die Service-Hinweise sind
nur durch qualiziertes
Personal zu befolgen. Umeine
Gefährdung durch Stromschlag zu
vermeiden, führen Sie bitte keinerlei
Reparaturen an dem Gerät durch,
dienicht in der Bedienungsanleitung
beschrieben sind. Reparaturen
sind nur von qualiziertem
Fachpersonaldurchzuführen.
1. Lesen Sie diese Hinweise.
2. Bewahren Sie diese Hinweise auf.
3. Beachten Sie alle Warnhinweise.
4. Befolgen Sie alle
Bedienungshinweise.
5. Betreiben Sie das Gerät nicht in
der Nähe vonWasser.
6. Reinigen Sie das Gerät mit einem
trockenen Tuch.
7. Blockieren Sie nicht die
Belüftungsschlitze. Beachten
Sie beim Einbau des Gerätes die
Herstellerhinweise.
8. Stellen Sie das Gerät nicht in der
Nähe von Wärmequellen auf. Solche
Wärmequellen sind z. B. Heizkörper,
Herde oder andere Wärme erzeugende
Geräte (auch Verstärker).
9. Entfernen Sie in keinem Fall
die Sicherheitsvorrichtung von
Zweipol- oder geerdeten Steckern. Ein
Zweipolstecker hat zwei unterschiedlich
breite Steckkontakte. Ein geerdeter
Stecker hat zwei Steckkontakte
und einen dritten Erdungskontakt.
Derbreitere Steckkontakt oder der
zusätzliche Erdungskontakt dient
Ihrer Sicherheit. Falls das mitgelieferte
Steckerformat nicht zu Ihrer Steckdose
passt, wenden Sie sich bitte an
einen Elektriker, damit die Steckdose
entsprechend ausgetauscht wird.
10. Verlegen Sie das Netzkabel so,
dass es vor Tritten und scharfen Kanten
geschützt ist und nicht beschädigt
werden kann. Achten Sie bitte
insbesondere im Bereich der Stecker,
Verlängerungskabel und an der Stelle,
an der das Netzkabel das Gerät verlässt,
aufausreichendenSchutz.
11. Das Gerät muss jederzeit mit
intaktem Schutzleiter an das Stromnetz
angeschlossen sein.
12. Sollte der Hauptnetzstecker
oder eine Gerätesteckdose die
Funktionseinheit zum Abschalten sein,
muss diese immer zugänglich sein.
13. Verwenden Sie nur Zusatzgeräte/
Zubehörteile, dielaut Hersteller
geeignet sind.
14. Verwenden
Sie nur Wagen,
Standvorrich-
tungen, Stative,
Halter oder Tische,
die vom Hersteller
benannt oder im Lieferumfang des
Geräts enthalten sind. Falls Sie einen
Wagen benutzen, seien Sie vorsichtig
beim Bewegen der
Wagen-Gerätkombination,
umVerletzungen durch Stolpern
zuvermeiden.
15. Ziehen Sie den Netzstecker bei
Gewitter oder wenn Sie das Gerät
längere Zeit nicht benutzen.
16. Lassen Sie alle Wartungsarbeiten
nur von qualiziertem Service-
Personal ausführen. EineWartung
ist notwendig, wenn das Gerät in
irgendeiner Weise beschädigt wurde
(z. B. Beschädigung des Netzkabels
oder Steckers), Gegenstände oder
Flüssigkeit in das Geräteinnere gelangt
sind, das Gerät Regen oder Feuchtigkeit
ausgesetzt wurde, das Gerät nicht
ordnungsgemäß funktioniert oder auf
den Boden gefallen ist.
17. Korrekte
Entsorgung dieses
Produkts: Dieses Symbol
weist darauf hin, das
Produkt entsprechend
der WEEE Direktive (2012/19/EU) und
der jeweiligen nationalen Gesetze nicht
zusammen mit Ihren Haushaltsabfällen
zu entsorgen. DiesesProdukt sollte bei
einer autorisierten Sammelstelle für
Recycling elektrischer und
elektronischer Geräte (EEE) abgegeben
werden. Wegen bedenklicher
Substanzen, diegenerell mit
elektrischen und elektronischen
Geräten in Verbindung stehen, könnte
eine unsachgemäße Behandlung dieser
Abfallart eine negative Auswirkung auf
Umwelt und Gesundheit haben.
Gleichzeitig gewährleistet Ihr Beitrag
zur richtigen Entsorgung dieses
Produkts die eektive Nutzung
natürlicher Ressourcen. Fürweitere
Informationen zur Entsorgung Ihrer
Geräte bei einer Recycling-Stelle
nehmen Sie bitte Kontakt zum
zuständigen städtischen Büro,
Entsorgungsamt oder zu Ihrem
Haushaltsabfallentsorgerauf.
18. Installieren Sie das Gerät nicht
in einer beengten Umgebung, zum
Beispiel Bücherregal oder ähnliches.
19. Stellen Sie keine Gegenstände mit
oenen Flammen, etwa brennende
Kerzen, auf das Gerät.
20. Beachten Sie bei der Entsorgung
von Batterien den Umweltschutz-
Aspekt. Batterien müssen bei einer
Batterie-Sammelstelle entsorgt
werden.
21. Verwenden Sie das Gerät in
tropischen und/oder gemäßigten
Klimazonen.
Music Tribe übernimmt keine
Haftung für Verluste, die Personen
entstanden sind, die sich ganz
oder teilweise auf hier enthaltene
Beschreibungen, Fotos oder Aussagen
verlassen haben. Technische Daten,
Erscheinungsbild und andere
Informationen können ohne vorherige
Ankündigung geändert werden.
Alle Warenzeichen sind Eigentum
der jeweiligen Inhaber. Midas,
Klark Teknik, Lab Gruppen, Lake,
Tannoy, Turbosound, TC Electronic,
TC Helicon, Behringer, Bugera und
Coolaudio sind Warenzeichen oder
eingetragene Warenzeichen der
Music Tribe Global Brands Ltd.
© Music Tribe Global Brands Ltd.
2018 Alle Rechte vorbehalten.
Die geltenden Garantiebedingungen
und zusätzliche Informationen
bezüglich der von Music Tribe
gewährten beschränkten
Garantie nden Sie online unter
musictribe.com/warranty.
Aviso!
Terminais marcados
com o símbolo carregam
corrente elétrica de magnitude
suciente para constituir um risco de
choque elétrico. Use apenas cabos
de alto-falantes de alta qualidade
com plugues TS de ¼" ou plugues
com trava de torção pré-instalados.
Todas as outras instalações e
modicações devem ser efetuadas por
pessoasqualicadas.
Este símbolo, onde quer
que o encontre, alerta-o
para a leitura das
instruções de manuseamento que
acompanham o equipamento. Por favor
leia o manual deinstruções.
Atenção
De forma a diminuir
o risco de choque
eléctrico, nãoremover a cobertura
(ouasecção de trás). Não existem peças
substituíveis por parte do utilizador no
seu interior. Para esse efeito recorrer a
um técnicoqualicado.
Atenção
Para reduzir o risco de
incêndios ou choques
eléctricos o aparelho não deve ser
exposto à chuva nem à humidade.
Alémdisso, não deve ser sujeito a
salpicos, nem devem ser colocados em
cima do aparelho objectos contendo
líquidos, taiscomojarras.
Atenção
Estas instruções de
operação devem ser
utilizadas, emexclusivo, por técnicos
de assistência qualicados. Para evitar
choques eléctricos não proceda a
reparações ou intervenções, que
não as indicadas nas instruções
de operação, salvo se possuir as
quali-cações necessárias. Para evitar
choques eléctricos não proceda a
reparações ou intervenções, que
não as indicadas nas instruções de
operação. Só o deverá fazer se possuir
as qualicaçõesnecessárias.
1. Leia estas instruções.
2. Guarde estas instruções.
3. Preste atenção a todos os avisos.
4. Siga todas as instruções.
5. Não utilize este dispositivo perto
de água.
6. Limpe apenas com um pano seco.
7. Não obstrua as entradas de
ventilação. Instale de acordo com as
instruções do fabricante.
8. Não instale perto de quaisquer
fontes de calor tais como radiadores,
bocas de ar quente, fogões de sala
ou outros aparelhos (incluindo
amplicadores) que produzam calor.
9. Não anule o objectivo de
segurança das chas polarizadas ou
do tipo de ligação à terra. Uma cha
polarizada dispõe de duas palhetas
sendo uma mais larga do que a outra.
Uma cha do tipo ligação à terra dispõe
de duas palhetas e um terceiro dente
de ligação à terra. A palheta larga ou
o terceiro dente são fornecidos para
sua segurança. Se a cha fornecida
não encaixar na sua tomada, consulte
um electricista para a substituição da
tomada obsoleta.
10. Proteja o cabo de alimentação de
pisadelas ou apertos, especialmente
nas chas, extensões, e no local de
saída da unidade. Certique-se de
que o cabo eléctrico está protegido.
Verique particularmente nas chas,
nos receptáculos e no ponto em que o
cabo sai doaparelho.
11. O aparelho tem de estar sempre
conectado à rede eléctrica com o
condutor de protecção intacto.
12. Se utilizar uma cha de
rede principal ou uma tomada de
aparelhos para desligar a unidade
de funcionamento, esta deve estar
sempre acessível.
13. Utilize apenas ligações/acessórios
especicados pelofabricante.
14. Utilize apenas
com o carrinho,
estrutura, tripé,
suporte, ou mesa
especicados pelo
fabricante ou
vendidos com o dispositivo.
Quandoutilizar um carrinho, tenha
cuidado ao mover o conjunto carrinho/
dispositivopara evitardanos provocados
pela terpidação.
15. Desligue este dispositivo durante
as trovoadas ou quando não for
utilizado durante longos períodos
detempo.
16. Qualquer tipo de reparação
deve ser sempre efectuado por
pessoal qualicado. É necessária uma
reparação sempre que a unidade tiver
sido de alguma forma danicada,
como por exemplo: no caso do cabo de
alimentação ou cha se encontrarem
danicados; naeventualidade de
líquido ter sido derramado ou objectos
terem caído para dentro do dispositivo;
no caso da unidade ter estado exposta
à chuva ou à humidade; seesta
não funcionar normalmente, ou se
tiver caído.
17. Correcta eliminação
deste produto: este
símbolo indica que o
produto não deve ser
eliminado juntamente
com os resíduos domésticos, segundo a
Directiva REEE (2012/19/EU) e a legislação
nacional. Este produto deverá ser levado
para um centro de recolha licenciado para
a reciclagem de resíduos de
equipamentos eléctricos e electrónicos
(EEE). O tratamento incorrecto deste tipo
de resíduos pode ter um eventual
6 7Quick Start GuideAMS Series

GARANTIA LIMITADA
LEGAL RENUNCIANTE
impacto negativo no ambiente e na
saúde humana devido a substâncias
potencialmente perigosas que estão
geralmente associadas aos EEE. Ao
mesmo tempo, a sua colaboração para a
eliminação correcta deste produto irá
contribuir para a utilização eciente dos
recursos naturais. Paramais informação
acerca dos locais onde poderá deixar o
seu equipamento usado para reciclagem,
é favor contactar os serviços municipais
locais, a entidade de gestão de resíduos
ou os serviços de recolha de
resíduosdomésticos.
18. Não instale em lugares
connados, tais como estantes ou
unidades similares.
19. Não coloque fontes de
chama, tais como velas acesas,
sobre o aparelho.
20. Favor, obedecer os aspectos
ambientais de descarte de bateria.
Baterias devem ser descartadas em um
ponto de coletas de baterias.
21. Use este aparelho em climas
tropicais e/ou moderados.
O Music Tribe não se responsabiliza
por perda alguma que possa ser
sofrida por qualquer pessoa que
dependa, seja de maneira completa
ou parcial, de qualquer descrição,
fotograa, ou declaração aqui
contidas. Dados técnicos, aparências
e outras informações estão sujeitas
a modicações sem aviso prévio.
Todas as marcas são propriedade de seus
respectivos donos. Midas, Klark Teknik,
Lab Gruppen, Lake, Tannoy, Turbosound,
TC Electronic, TC Helicon, Behringer,
Bugera e Coolaudio são marcas ou
marcas registradas do Music Tribe Global
Brands Ltd. © Music Tribe Global Brands
Ltd. 2018 Todos direitos reservados.
Para obter os termos de garantia
aplicáveis e condições e informações
adicionais a respeito da garantia
limitada do Music Tribe, favor vericar
detalhes na íntegra através do website
musictribe.com/warranty.
8 9Quick Start GuideAMS Series
1. Introduction
Thank you for purchasing this new AMS Series product. Designed for both speech and music program material, the Tannoy AMS range
provides exceptional sonic quality and long-term reliability in all surface mount applications. The AMS range oers ve models: three
featuring a new generation of Dual Concentric drivers and two with an improved version of Tannoy’s ICT technology. All new drivers have
16 ohm nominal impedance for optimized use with Lab.gruppen ampliers. Other features include IP65 rating for outdoor use, high-
temperature molded cabinets and custom color options. All AMS loudspeakers include a built-in line transformer.
Because all AMS models are true point-source loudspeakers, they may be mounted horizontally or vertically without aecting
performance. All models include a standard mounting yoke; a multi-angle VariBall accessory bracket is available as an option.
2. Safety Notices
Installation Safety Notice
1. The user is responsible for xing the hardware to the surface to ensure safe operation. The xings must support the weight of the
product. Please consult the manual’s specication page for the appropriate weights. Please consult the relevant construction codes
in your region for further information on suitable hardware xing methods.
2. Some regional construction codes require the use of a secondary method of securing loudspeakers to surfaces to provide security of a
back-up support. A secondary support line should be attached from the safety loop on the rear of the product to a source point on the
wall. Please consult the relevant construction codes in your region.
3. Tannoy will not be held accountable for any damage caused by incorrect installation.
Electrical Safety Notice: To comply with the standard UL1480, metal-clad exible conduit (BX) is required for connection to the
terminal block for proper earth grounding.
Safety Note: In order to comply with the relevant re safety regulations (i.e. BS 5839:1998), it is required that in the event of
re, that failure of the circuit to which the loudspeaker is connected does not occur before evacuation of the building is complete.
Suitable measures include:
• Use of terminal blocks (for connection to primary) with a melting point of not less than 650°C, for example constructed from ceramic materials;
• Use of terminal blocks of a lower melting point but protected with thermal insulation;
• Use of terminal blocks such that, on melting, an open-circuit or a short-circuit does not occur.

3. Unpacking
Every Tannoy product is carefully inspected before shipment. After unpacking, please inspect your product to ensure no damage has
occurred in transit. In the unlikely event of damage, please notify your dealer and retain all shipping materials as your dealer may require
return shipment.
4. Installation
Installation using included yoke bracket
1. Fix the yoke bracket to an appropriate structural surface using a suitable xing method.
2. Remove the yoke trims from the product to access the bracket xing points.
3. Set the transformer tap as detailed in Chapter 5.
4. For indoor installation (proceed to step 5 for outdoor installation): Connect the euro-style plug to the wires, observing correct
polarity. Use pins 1(+) and 2 (–) for connection of the loudspeaker. Use pins 3 (–) and 4 (+) for connection of additional loudspeakers in a
distributed line. NOTE: Tighten pins 3 and 4 even if not used to prevent vibration of the screws.
5. For outdoor installation: Feed the loudspeaker wire(s) through the opening in the neck of the cable entry cover included with the
product.
Connect the euro-style plug to the wires, observing correct polarity. Use pins 1(+) and 2 ( – ) for connection of the loudspeaker. Use
pins 3 ( – ) and 4 (+) for connection of additional loudspeakers in a distributed line. NOTE: Tighten pins 3 and 4 even if not used to
prevent vibration of the screws.
6. Place the loudspeaker inside the yoke bracket. Position buers between bracket and loudspeaker as shown. Attach with supplied xings
using a 5 mm Allen key. Use the longer hex screws supplied when mounting the yoke bracket.
7. Connect the euro plug to the loudspeaker. For outdoor installation, attach the cable entry cover using a 3 mm Allen key and the included
screws. Orient the cover plate so that the neck opening is facing downward to minimise entry of moisture or particulates.
8. Connect a secondary support line to the safety tab at the rear of the cabinet.
Optional multi-angle VariBall bracket
The optional multi-angle accessory bracket utilises a ball-in-socket design to enable free orientation of the loudspeaker at any angle on
either the horizontal or vertical axis. If desired, the loudspeaker orientation can be easily changed within minutes. Download the AMS
VariBall accessory bracket documentation for more details.
AMS 5 Multi-Angle Bracket AMS 6 & 8 Multi-Angle Bracket
10 11Quick Start GuideAMS Series

5. Setting transformer taps
1. The rotary transformer tapping switch is located directly above the wiring connector.
CAUTION: THE LOUDSPEAKER IS SUPPLIED WITH THE TAP SWITCH IN LOW IMPEDANCE MODE. NEVER CONNECT THE
LOUDSPEAKER TO A 70/100 V AMPLIFIER OUTPUT WHILE SWITCHED TO LOW IMPEDANCE MODE.
2. Set the rotary switch to the appropriate position for low impedance operation or for use in 70/100 V distributed systems.
Models with 5-inch drivers are tted with 30 W transformers. In distributed line applications, the transformer can be tapped at 30
W, 15 W and 7.5 W, with an additional 3.75 W tap for 70 V line systems.
Models with 6-inch and 8-inch drivers are tted with 60W transformers. In distributed line applications, the transformer can be
tapped at 60 W, 30 W and 15 W, with an additional 7.5 W tap for 70 V line systems.
6. Product Dimensions
AMS 8DC
AMS 6DC
259.7
[10.22"]
306.3
[12.06"]
407.5
[16.04"]
35.0
[1.38"]
90.0
[3.54"]
90.0
[3.54"]
Ø22.0
[Ø0.87"]
Ø11.0
[Ø0.43"]
6.0
[0.24"]
CABLE ENTRY COVER FOR EXTERNAL USE.
THIS CAN BE ROTATED FOR NORTH, SOUTH,
EAST OR WEST ENTRY.
54.0
[2.13"]
409.8
[16.13"]
260.0
[10.24"]
223.7
[8.81"]
268.8
[10.58"]
360.9
[14.21"]
54.0
[2.13"]
Ø22.0
[Ø0.87"]
Ø11.0
[Ø0.43"]
90.0
[3.54"]
90.0
[3.54"]
35.0
[1.38"]
364.8
[14.36"]
CABLE ENTRY COVER FOR EXTERNAL USE.
THIS CAN BE ROTATED FOR NORTH, SOUTH,
EAST OR WEST ENTRY.
6.0
[0.24"]
230.0
[9.05"]
12 13Quick Start GuideAMS Series

AMS 6ICT
AMS 6ICT LS
223.7
[8.81"]
268.8
[10.58"]
360.9
[14.21"]
54.0
[2.13"]
Ø22.0
[Ø0.87"]
Ø11.0
[Ø0.43"]
90.0
[3.54"]
90.0
[3.54"]
35.0
[1.38"]
364.8
[14.36"]
CABLE ENTRY COVER FOR EXTERNAL USE.
THIS CAN BE ROTATED FOR NORTH, SOUTH,
EAST OR WEST ENTRY.
6.0
[0.24"]
230.0
[9.05"]
223.7
[8.81"]
268.8
[10.58"]
360.9
[14.21"]
54.0
[2.13"]
Ø22.0
[Ø0.87"]
Ø11.0
[Ø0.43"]
90.0
[3.54"]
90.0
[3.54"]
35.0
[1.38"]
364.8
[14.36"]
CABLE ENTRY COVER FOR EXTERNAL USE.
THIS CAN BE ROTATED FOR NORTH, SOUTH,
EAST OR WEST ENTRY.
6.0
[0.24"]
230.0
[9.05"]
AMS 5DC
AMS 5ICT
159.5
[6.28"]
240.0
[9.45"]
155.0
[6.10"]
54.0
[2.13"]
203.9
[8.03"]
90.0
[3.54"]
90.0
[3.54"]
Ø11.0
[Ø0.43"]
Ø22.0
[Ø0.87"]
6.0
[0.24"]
248.0
[9.77"]
CABLE ENTRY COVER FOR EXTERNAL USE.
THIS CAN BE ROTATED FOR NORTH, SOUTH,
EAST OR WEST ENTRY.
35.0
[1.38"]
159.5
[6.28"]
240.0
[9.45"]
155.0
[6.10"]
54.0
[2.13"]
203.9
[8.03"]
90.0
[3.54"]
90.0
[3.54"]
Ø11.0
[Ø0.43"]
Ø22.0
[Ø0.87"]
6.0
[0.24"]
248.0
[9.77"]
CABLE ENTRY COVER FOR EXTERNAL USE.
THIS CAN BE ROTATED FOR NORTH, SOUTH,
EAST OR WEST ENTRY.
35.0
[1.38"]
14 15Quick Start GuideAMS Series

AMS 5ICT LS
159.5
[6.28"]
240.0
[9.45"]
155.0
[6.10"]
54.0
[2.13"]
203.9
[8.03"]
90.0
[3.54"]
90.0
[3.54"]
Ø11.0
[Ø0.43"]
Ø22.0
[Ø0.87"]
6.0
[0.24"]
248.0
[9.77"]
CABLE ENTRY COVER FOR EXTERNAL USE.
THIS CAN BE ROTATED FOR NORTH, SOUTH,
EAST OR WEST ENTRY.
35.0
[1.38"]
Specications
System AMS 8DC
Performance
Frequency response (-3 dB) (1) 65 Hz - 30 kHz
Frequency range (-10 dB) (1) 53 Hz - 40 kHz
System sensitivity (1 W @ 1m)(2) 92 dB (1 W = 4 V for 16 ohms)
Nominal Coverage Angle 90 degrees conical
Power Handling (3)
Average 90 W
Programme 180 W
Peak 360 W
Recommended Amplier Power 180 W @ 16 ohms
Nominal Impedance (Lo, Z) 16 ohms
Rated Maximum SPL
Average 111 dB
Peak 117 dB
Transformer Taps (via front rotary switch)
70 V 60 W / 30 W / 15 W / 7.5 W / OFF & Low impedance operation
100 V 60 W / 30 W / 15 W / OFF & Low impedance operation
Transducers
Dual Concentric point source driver 1x 200 mm (8.00") Dual Concentric driver, using Omnimagnet
technology
Low Frequency 44 mm (1.75" ) voice coil, treated multi bre paper pulp cone
High Frequency 25 mm (1.00") PEI dome
Physical
Enclosure ABS
Grille Steel, plated and painted
Connectors Removable locking connector with screw terminals
Transformer setting Rotary switch
Dimensions (H x W x D) 409.8 x 260.0 x 306.3 mm (16.13 x 10.24 x 12.06")
Net Weight (ea) 7.8 kg (17.20 lbs)
Shipped weight 8.8 kg (19.40 lbs)
Included Accessories Yoke bracket
Packed Quantity 2
16 17Quick Start GuideAMS Series

System AMS 6DC AMS 6ICT AMS 6ICT LS
Performance
Frequency response
(-3 dB) (1) 75 Hz - 30 kHz 75 Hz - 22 kHz 75 Hz - 30 kHz
Frequency range
(-10 dB) (1) 55 Hz - 40 kHz 55 Hz - 30 kHz
System sensitivity
(1 W @ 1m) (2) 89 dB (1 W = 4 V for 16 ohms) 90 dB (1 W = 4 V for 16 ohms)
Nominal Coverage Angle 90 degrees conical
Power Handling(3)
Average 80 W 60 W
Programme 160 W 120 W
Peak 320 W 240 W
Recommended Amplier
Power 160 W @ 16 ohms 120 W @ 16 ohms
Nominal Impedance (Lo, Z) 16 ohms
Rated Maximum SPL
Average 108 dB
Peak 114 dB
Transformer Taps (via front rotary switch)
70 V 60 W / 30 W / 15 W / 7.5 W / OFF & Low impedance operation
100 V 60 W / 30 W / 15 W / OFF & Low impedance operation
Transducers
Dual Concentric point
source driver
1x 165 mm (6.50") Dual
Concentric driver, using
Omnimagnet technology —
Low Frequency 44 mm (1.75" ) voice coil, treated multi bre paper
pulp cone 1 x 165 mm (6.50") treated multi bre paper pulp cone
High Frequency 25 mm (1.00") PEI dome ICT
Physical
Enclosure ABS
Grille Steel, plated and painted
Connectors Removable locking connector with screw terminals
Transformer setting Rotary switch
Dimensions (H x W x D) 364.8 x 230.0 x 268.8 mm (14.36 x 9.05 x 10.58")
Net Weight (ea) 6.25 kg (13.78 lbs) 5.25 kg (11.57 lbs) 5.4 kg (11.90 lbs)
Shipped weight 7.1 kg (15.6 lbs) 6.1 kg (13.4 lbs) 6.25 kg (13.77 lbs)
Included Accessories Yoke bracket
Packed Quantity 2
System AMS 5DC AMS 5ICT AMS 5ICT LS
Performance
Frequency response
(-3 dB) (1) 90 Hz - 30 kHz 90 Hz - 22 kHz
Frequency range
(-10 dB) (1) 80 Hz - 40 kHz 80 Hz - 30 kHz
System sensitivity
(1 W @ 1m) (2) 87 dB (1 W = 4 V for 16 Ohms) 88 dB (1 W = 4 V for 16 Ohms)
Nominal Coverage Angle 90 degrees conical
Power Handling(3)
Average 60 W 50 W
Programme 120 W 100 W
Peak 240 W 200 W
Recommended Amplier
Power 120 W @ 16 ohms 100 W @ 16 ohms
Nominal Impedance (Lo, Z) 16 ohms
Rated Maximum SPL
Average 105 dB
Peak 111 dB
Transformer Taps (via front rotary switch)
70 V 30 W / 15 W / 7.5 W / 3.75 W / OFF & Low impedance operation
100 V 30 W / 15 W / 7.5 W / OFF & Low impedance operation
Transducers
Dual Concentric point
source driver
1x 130 mm (5.0") Dual
Concentric driver, using
Omnimagnet technology —
Low Frequency 35 mm (1.38" ) voice coil, treated multi bre paper
pulp cone 1 x 130 mm (5.00") treated multi bre paper pulp cone
High Frequency 20 mm (0.79") PEI dome ICT
Physical
Enclosure ABS
Grille Steel, plated and painted
Connectors Removable locking connector with screw terminals
Transformer setting Rotary switch
Dimensions (H x W x D) 248.0 x 155.0 x 203.9 mm (9.77 x 6.10 x 8.03")
Net Weight (ea) 3.6 kg (7.9 lbs) 3.4 kg (7.5 lbs) 3.45 kg (7.60 lbs)
Shipped weight 4.15 kg (9.15 lbs) 3.95 kg (8.70 lbs) 4.0 kg (8.82 lbs)
Included Accessories Yoke bracket
Packed Quantity 2
18 19Quick Start GuideAMS Series
