Tannoy CMS503ICT PI User manual

Quick Start Guide
CMS 3.0 SERIES
In-Ceiling loudspeakers
CMS 503ICT PI
CMS 603ICT PI

3 Unpacking
Every Tannoy product is carefully inspected before
shipment. After unpacking, please inspect your
product to ensure no damage has occurred in
transit. In the unlikely event of damage, please
notify your dealer and retain all shipping materials
as your dealer may require return shipment. All
CMS loudspeakers are shipped in pairs and
provided with the following accessories as
standard: C-ring, tile-bridge kit, cut-out template
and paint mask. A plaster (mud) ring is available as
an optional accessory.
4 InstallationinSuspended Ceilings
An optional pre-install backcan is available for all
pre-install (PI) models. The backcan is designed
for pre-installation in newly constructed, non-
suspended ceilings.
NOTE: The CMS 603ICT models have the
transformer pre-attached to the inside of the
backcan; the CMS 503ICT models have the
transformer pre-attached to the loudspeaker
assembly.
1. Attach the backcan to a secure xing point.
This can be done one of three ways:
METHOD 1: Fix to a secure point using suitable
xings attached to the four xing holes on the PI
backcan. (Fig.1)
METHOD 2: Fix to a secure point using suitable
xings and the exible straps attached to the PI
backcan. (Fig. 2)
1 Introduction
This Quick Start Guide (QSG) provides the basic
information required to install and connect the pre-
install (PI) versions of Tannoy CMS Series in-ceiling
loudspeakers.
For additional information, including product
technology, photo identication of product features,
dimensional drawings, and complete technical
specications, please refer to the full CMS Series
Operation Manual.
For installation of CMS Series blind-mount
versions, please refer to either the CMS BM Quick
Start Guide or the full CMS Operation Manual.
2 Safety Notices
Some regional construction codes require the use
of a secondary method of securing loudspeakers
in ceiling to provide security of a back-up support.
A secondary support line should be attached
from the safety loop on the rear of the product to
a source point on the ceiling. For PI models, the
secondary support line should be attached from
the back of the driver chassis to a source point on
the ceiling. Please consult the relevant construction
codes in your region.
When using a power driver to install the product, it
is essential to use the correct torque level settings
to avoid over tightening and damage to the ceiling
material or clamps. Recommended torque setting:
1.5 Nm Tannoy will not be held responsible for any
damages caused by the improper installation of
these loudspeakers.
Electrical Safety Notice: to comply with the
standard UL1480, metal-clad exible conduit (BX)
is required for connection to the terminal block for
proper earth grounding.
SAFETY NOTE: In order to comply with the
relevant re safety regulations (i.e. BS 5839:1998),
it is required that in the event of re, that failure of
the circuit to which the loudspeaker is connected
does not occur before evacuation of the building is
complete. Suitable measures include:
• Use of terminal blocks (for connection to
primary) with a melting point of not less than
650°C, for example constructed from ceramic
materials;
• Use of terminal blocks of a lower melting point
but protected with thermal insulation;
• Use of terminal blocks such that, on melting, an
open-circuit or a short-circuit does not occur.
Fig.1
Fig.2

Fig.2
METHOD 3:
a. Attach the PI backcan to the optional pre-mount
plaster ring using the xing points provided with the
pre-mount ring. (Fig 3).
b. Secure the wings of the pre-mount ring to a
secure xing point using suitable xings.
2. Attach conduit to the backcan using one of
two methods:
METHOD 1: Use the clamp at the back of the
pre-install backcan. The product will accept a
squeeze connector with a thread size of up to 22
mm. To remove the cable clamp, simply unscrew
the threaded washer (under the wiring cover) which
holds the cable clamp in place and replace it with a
conduit squeeze connector. (Fig.4)
METHOD 2: Use any of the three knock-out points
at the sides of the backcan (19 mm, 22 mm or
28 mm diameter). (Fig 5)
3. If conduit not used, run approved speaker cable
to the installed can. Terminate in the top-mounted
cable clamp or with an approved cable connector
in one of the three knock-out points at the sides of
the backcan.
4. Cut a hole in the proper ceiling location using the
supplied cut-out template (self-adhesive backing)
and a pad saw. Place the pre-install backcan over
the hole.
5. Proceed to Section 5 following on wiring and
setting up. Return to Step 6 below.
6. Slide the speaker assembly through the hole.
Turn the screws (denoted “Screw Fix”) clock-
wise on the front of the speaker to extend the
mounting wings. Tighten the screws until a rm
grip is achieved.
(NOTE: Screws have a PoziDriv head; use of a
PoziDriv driver is recommended). If using a power
driver, Tannoy recommends a torque setting of
1.5 Nm. (Fig.6)
Fig.1
Fig.2
Fig.3
Fig.4
Fig.5
Fig.6

5 Wiring and Setting Up
1. Open the wiring cover (if applicable) and locate
the Euro-type connector plug and socket at the
back of the speaker. (Fig.1)
2. For connection to an amplier, use Pins 1 and 2
3. Close the wiring cover and tighten both screws
on the cable clamp (if applicable).
4. Use the rotary switch on the front of the
unit to select low impedance (LoZ) mode
or high impedance (70 V or 100 V) for
distributed applications.
The speaker is supplied in low impedance
mode. Never connect the speaker to a
70 / 100 Volt amplier while it is set for
low impedance.
CMS 503ICT models (all variants) use a 30 W
transformer. In distributed line applications, the
transformer can be tapped at 30 W, 15 W and
7.5 W, with an additional 3.75 W tap for 70 V
line systems.
CMS 603ICT models (all variants) use a 60 W
transformer. In distributed Line applications, the
transformer can be tapped at 60 W, 30 W and
15 W with an additional 7.5 W tap for 70 V
line systems.
6 CMS Series PI Dimensions
Please refer to the full CMS Series Operation
Manual for dimensional drawings.
CMS 503ICT PI
Hole cut-out: 190 mm
Diameter1: 205.9 mm (8.11”)
Height2: 131.7 mm (5.19 ”)
CMS 503 PI BACKCAN
Diameter: 288.0 mm (11.34”)
Height: 153.5 mm (6.04”)
CMS 603ICT PI
Hole cut-out: 253 mm
Diameter1:274 mm (10.79”)
Height2: 100 mm (3.94”)
CMS 603 PI BACKCAN
Diameter: 351 mm (13.82”)
Height: 168.5 mm (6.63”)
1 Maximum, including bezel ring
2 Maximum to top of connector, from lower
ceiling surface
tannoypro.com
6481 0667 / 231115
• Pin 1 is positive
• Pin 2 is negative
For connection to
additional speakers
in a distributed line,
Pins 3 and 4 are in
parallel where:
• Pin 3 is negative
• Pin 4 is positive
Fig.1
Fig.2
