TaoTazon TWK-24A User manual

Telescoping Pressure Washer Wand
Operating Instruction and Parts List
READ & SAVE THESE INSTRUCTIONS
WARNING: Read carefully and understand all operating instruction before operating.
Failure to follow the safety rules and other basic safety precautions may result in serious
personal injury.

Table of Contents
Introduction
Introduction.................................................................................................1
Technical Specifications.............................................................................2
Package Contents......................................................................................2
Important Safety Information...............................................................3-4
Work Area Safety.................................................................................3
Personal Safety...................................................................................3
Wand Use & Care...............................................................................4
Operation Warnings............................................................................4
Preparation & Operation.......................................................................5-6
Before Each Use.................................................................................5
Operating Instructions.........................................................................5
After Each Use....................................................................................5
Installation And Operation Instruction..................................................6
Maintenance........................................................................................7
Troubleshooting..........................................................................................7
Thank you for your support for TaoTazon Telescoping Pressure Washer Wand!
You can be assured this wand kit was constructed and designed with quality and performance
in mind. Each component has been rigorously tested to ensure the high level of acceptance.
This extension wand kit is designed for high-pressure cleaning of hard-to-reach places such
as walls,gutters and fence,etc. Simply connect the telescoping pressure washer wand to your
pressure washer, pull the trigger and move for fast and efficient cleaning!
1
此页为封面內页

Technical Specifications
Important Safety Information
Work Area Safety
Model Name TWK-24A
Length 5 FT - 24 FT
Material Aluminum alloy, Engineering plastics
Max Pressure 4,000 PSI / 275 BAR
Max Flow Rate 6.0 GPM / 23.0 LPM
Max Temperature 140℉/ 60℃
Inlet Fitting 3/8'' Quick Plug / M22-14 mm Male / M22-15 mm Male
•Inspect the work area before each use. Keep work area clean, dry, free of clutter, and
well-lit. Cluttered, wet, or dark work areas can result in injury. Using the product in confined
work areas may put you dangerously close to cutting tools and rotating parts.
•Do not use the product where there is a risk of causing a fire or an explosion; e.g., in the
presence of flammable liquids, gases, or dust. The product can create sparks, which may
ignite the flammable liquids, gases, or dust.
•Do not allow the product to come into contact with an electrical source. The tool is not
insulated and contact will cause electrical shock.
•Keep children and bystanders away from the work area while operating the tool. Do not
allow children to handle the product.
•Be aware of all power lines, electrical circuits, water pipes, and other mechanical hazards
in your work area. Some of these hazards may be hidden from your view and may cause
personal injury and/or property damage if contacted.
Personal Safety
•Stay alert, watch what you are doing, and use common sense when operating the tool.
Donot use the tool while you are tired or under the influence of drugs, alcohol, or medication.
A moment of inattention while operating the tool may result in serious personal injury.
•Dress properly. Do not wear loose clothing, dangling objects, or jewelry. Keep your hair,
clothing and gloves away from moving parts. Loose clothes, jewelry, or long hair can be
caught in moving parts. Air vents on the tool often cover moving parts and should be avoided.
•Wear the proper personal protective equipment when necessary. Use ANSI Z87.1
compliant safety goggles (not safety glasses) with side shields, or when needed, a face
shield. Use a dust mask in dusty work conditions. Also use non-skid safety shoes,
hardhat, gloves, dust collection systems, and hearing protection when appropriate. This
applies to all persons in the work area.
•Do not overreach. Keep proper footing and balance at all times.
Package Contents
ITEM NO ITEM NAME DESCRIPTION
1 Pivoting Coupler Adjusts the direction of spray.Connects Item 2.
2 Inlet Adapter B Converts M22-14 mm Male into M22-15 mm Male.
3 Inlet Adapter A Converts 3/8'' Quick plug into M22-14 mm Male.
4 15 Degree Extension Wand Used for cleaning the wall.Connects Item 1.
5 Gutter Cleaner Attachment Used for cleaning the gutter in high place.Connects Item 1.
6 nylon tape Prevent water leakage
7 5 Spray Nozzle Tips Meet your need in different situations.
8 Support Belt Helps to distribute the weight of the telescoping wand.
9 Telescoping Wand with Lever Lock 5 stage for adjustable extending length.
23
14MM OD
3/8'' Quick-Connet
15MM OD
4
7
1
5
9
8
3
2
6

Preparation & Operation
Before Each Use
Connect the outlet of your pressure washer to the inlet port of the trigger gun of the wand
using appropriate quick couplers or fittings rated to handle high pressure.
Connect appropriate extension wands(Item2/3/4) to the outlet fitting of the telescoping wand.
And the extension wand quick connects an intended spray nozzle tip.
Be sure all fittings are tight. If there is leakage, please be sure use enough teflon tape.
After Each Use
Relieve pressure before disconnecting gun from pressure washer hose.
Perform the following inspections after each use to clean the wand and ready it for the next use.
•Clean out any dirt or foreign material from the top. If necessary, use a cloth or sponge to
wash the telescoping wand and rinse it with tap water.
•Check for loose parts and any damage.
•Fully retract, and store in safe place.
Operating Instructions
To Extend the Wand
Lift the lever locks rings and pull the wand out to the desired length. Clip the locks firmly
to hold the wand at the desired length.
To Retract the Wand
Lift the lever locks and slide the extension segment into the wand until the desired length
is reached and clip the locks firmly to hold the extension segments in place.
To Begin Spraying
Start the pressure washer. Raise the wand and keep the nozzle at least ten feet away
from the surface to be cleaned. Squeeze the trigger to begin spraying, maintain stable
footing, and move the wand in to the surface to be cleaned.
To Stop Spraying
Before releasing the trigger gun move the nozzle at least ten feet away from the surface
being cleaned and make sure you have solid footing. The wand will rebound when the
trigger is released or if pressure is lost. When you are clear of the work surface and in a
safearea - release the trigger.
Wand Use & Care
•Do not force the product. Products are safer and do a better job when used in the manner
for which they are designed. Plan your work, and use the correct product for the job.
•Check for damaged parts before each use. Carefully check that the wand will operate
properly and perform its intended function. Replace damaged or worn parts immediately.
Never operate the product with a damaged part.
•Do not use a product with a malfunctioning switch. Any power tool that cannot be controlled
with the power switch is dangerous and must be repaired by an authorized service
representative before using.
•Disconnect the power/air supply from the product and place the switch in the locked or
off position before making any adjustments, changing accessories, or storing the tool.
Such preventive safety measures reduce the risk of starting the tool accidentally.
•Store the product when it is not in use. Store it in a dry, secure place out of the reach of children.
•Inspect the tool for good working condition prior to storage and before re-use.
•Keep guards in place and in working order. Never operate the product without the
guards in place.
•Do not leave the tool running unattended.
Operation Warnings
•DO NOT exceed the rated PSI capacity.
•Never use near power lines.
•Never extend or retract the wand while spraying or while under pressure. Stop the
equipment and relieve pressure before making any adjustments to the wand.
•Never change nozzles or accessories while under pressure. Stop the equipment and
relieve pressure before making any changes.
•Never use while on ladders or scaffolding.
•Never use with unapproved accessories.
•Never exceed rated pressure or volume.
•Never use high-pressure to clean persons or animals.
•Never remove or alter warning labels or identification tags.
•Never use wand if damaged.
•Always read, understand, and follow operation instructions.
•Always maintain proper balance and control of extension wand.
4 5

Troubleshooting
If you meet the problem continues after troubleshooting,
or if you need technical assistance, please Email us at:
T[email protected]
Maintenance
Maintain the product by adopting a program of conscientious repair and maintenance. It
is recommended that the general condition of any tool be examined before it is used.
Keep your wand in good repair. Keep handles dry, clean, and free from oil and grease.
PROBLEM PROBABLE CAUSE CORRECTIVE ACTION
Contact our Customer Service for help
Tighten the hose
Rebuild the gun
Replace the gun
Reverse flush unit with water
The clamp is broken
The hose leaks
The gun leaks
Unit won't spray
The wand extends too much
There is over pressurization
The hose is loose at the fittings
This is normal wear and tear
There is over-pressurization
Unit is clogged
76
Installation And Operation Instruction
