Targus Wireless Multi-Channel Mouse User manual

BRUSSELS HANNOVER BARCELONA TOKYO MILANO AMSTERDAM SINGAPORE LONDON PARIS NEW YORK LOS ANGELES TORONTO HONG KONG SYDNEY
Wireless Multi-Channel
Mouse
USER’S GUIDE
Visit our Web site at: www.targus.com
Features and specifications are subject to change without notice. © 2003 Targus Corp.
400-0116-001C

2
TARGUS WIRELESS
MULTI-CHANNEL MOUSE
Introduction
Congratulations on your purchase of a Targus Wireless Multi-
Channel Mouse. This ergonomically designed mouse uses
leading-edge radio frequency (RF) technology that enables you
to use the mouse anywhere up to three feet of its receiver, in a
360 degree range of operation. No line-of-sight between the
mouse and its receiver is required.
This mouse also features ten communication channels with
automatic channel-hopping capability. This feature reduces the
likelihood of interference from other RF devices. Using multi-
channels make it ideal for use in areas where more than one RF
device is used, such as a conference room or office area.
NOTE: This mouse is a high resolution device. For maximum
accuracy and efficiency, it is recommended that you set your
display resolution to 1024 x 768 pixels or higher while you are
using the mouse.
Packaging Contents
In addition to this user’s guide, this package contains:
• Mouse
• Receiver
• USB charge cable
• Three inch USB extension cable

3
Targus Wireless Multi-Channel Mouse
System Requirements
To use the mouse, your computer must meet the following
hardware requirements and run one of the operating systems
listed below.
Hardware
• PC with an Intel®Pentium®processor or equivalent
• USB interface
Operating System
• Windows®98/98SE/Me/2000/XP
NOTE: The third button and the scrolling wheel only work with
the operating systems listed above. If you use the mouse with
a different operating system, it will lose its enhanced features
and function as a standard, two-button mouse.
Charging the Mouse
This mouse comes with a non-replaceable Lithium polymer
battery. If properly maintained, the battery will last for as long
as you own the mouse.
For best results, you should charge the mouse at least 14 hours
before using it. You can do this via the supplied USB charge
cable. To do this:
1 Connect the cable’s USB connector into an available USB
port on your computer
2 Connect the other end to the mouse.
NOTE: To continuously charge the mouse via the USB charge
cable, your computer must be on and awake. For best results,
turn off your computer’s power management feature while
charging the mouse.

4
Targus Wireless Multi-Channel Mouse
Low Battery Indicator Light
When the battery charge is running low, the LED on the
scroller wheel glows.
NOTE: If the indicator light is glowing, it is highly
recommended that you charge the mouse as soon as
possible to properly maintain the battery.
Once the indicator light starts glowing, the mouse’s internal
controller begins monitoring the battery’s voltage level. When
this level reaches its lowest point, depending on how often you
use the mouse, the mouse enters power off mode. To power on
the mouse, fully charge the battery then press the mouse’s
connect button to resume normal operation.
Connecting the Mouse Receiver
To connect the mouse receiver:
1 Turn off your computer.
2 Plug the USB receiver into an available USB port on your
computer.
3 Turn on your computer and follow any on-screen
instructions to complete the default driver installation.
Establishing a Communications
Link
NOTE: For best results, place the mouse close to the receiver
when establishing a communications link, to avoid possible
interference from other RF devices.

5
Targus Wireless Multi-Channel Mouse
After your computer detects the USB receiver and the driver
software is installed, you must establish a communications link
between the mouse and its receiver BEFORE you can use the
mouse. To establish this link, you need to set the identification
code so that the mouse works properly. To do this:
1 Press and release the link button on the receiver.
Sample receiver
The receiver’s status light blinks when the receiver is
activated.
2 Press and release the connect button, located on the bottom
of the mouse.
Sample mouse bottom
The mouse’s light emitter diode (LED) stops glowing when
you press the connect button and resumes glowing when the
button is released.
When the communication link is established, the receiver’s
status light turns off.
You are now ready to use the mouse.
Link button
Connect button

6
Targus Wireless Multi-Channel Mouse
Mouse Power Management
Powering the Mouse Off and On
To power the mouse off, move the on/off switch to the off
position. To turn it back on, move the switch back to the on
position.
Power Save Modes
To conserve the battery, the mouse reduces its power
consumption gradually when not in use, via power saving
modes, as follows:
Standby mode When the mouse stops moving, it
immediately enters standby mode. It
stays in this mode for 30 seconds if
movement isn’t detected.
Flash mode After 30 seconds of non-operation, the
mouse enters flash mode. It stays in this
mode for 20 minutes if movement isn’t
detected.
While in flash mode, the mouse’s
optical sensor turns off and on
intermittently to not only conserve
battery power, but allow the user prompt
access to the cursor if movement is
resumed.
Sleep mode After 20 minutes of non-operation, the
mouse enters sleep mode and turns off
the optical sensor. You must wake the
mouse to resume normal operation from
this mode.

7
Targus Wireless Multi-Channel Mouse
Waking the Mouse To wake the mouse from sleep mode,
press any button on the mouse to resume
normal operation.
Operating Hints
For optimal performance and RF reception:
• Turn off your computer’s power management feature before
charging the mouse so that your computer doesn’t enter
sleep mode, which temporarily haults the charging process.
• Place the receiver at least 8 inches (20 cm) away from all
electrical devices, such as your monitor, speakers or external
storage devices.
If necessary, use the three-inch extension cable to keep the
receiver away from the computer. Plug the receiver into the
extension cable, and the extension cable to the computer.
• Avoid using the mouse on a metal surface. Metals, such as
iron, aluminum or copper, shield the radio frequency
transmission and may slow down the mouse’s response time
or cause the mouse to fail temporarily.
• The mouse will enter a suspend mode at the same time your
computer does. To activate the mouse, press any button.
• If your computer has a metal case that contains aluminum or
magnesium, use the mouse to the side. The display panel
may interfere with the radio frequency signal if you use the
mouse directly in front of the computer.
• Never use the mouse on a glass or mirrored surface as these
surfaces will cause the mouse to fail temporarily.
• To maximize battery life, use the mouse on a white, or light
colored surface. Dark surfaces cause the mouse’s light

8
Targus Wireless Multi-Channel Mouse
emitter diode (LED) light to glow brighter, which causes the
battery to discharge more rapidly.
Comfortable Usage
Research suggests that physical discomfort and injury to
nerves, tendons, and muscles may be related to repetitive
motion, an improperly set up work area, incorrect body
posture, and poor work habits.
To reduce the risk of injury, follow these precautions:
• Stand, stretch, and move around several times every hour.
• Switch hands while performing tasks. Use shortcut keys to
avoid repetitive or awkward mouse movements.
• Relax your shoulders and keep your elbows at your sides.
Adjust the keyboard’s position so that you don’t have to
stretch to reach it.
• Adjust your position so that you don’t have to bend your
wrists to type; avoid placing your wrists on a sharp edge.
If you feel discomfort or numbness in your hands, wrists, arms,
shoulders, neck, or back while typing, consult a qualified
medical professional.
Things to Remember
Batteries
• To extend the life of your batteries, turn off the mouse while
traveling.
Sleep Mode
• The mouse’s sleep mode feature activates after 20 minutes of
non-operation. To wake the mouse from sleep mode, press
any button.

9
Targus Wireless Multi-Channel Mouse
Specifications
Button Count 3 with scrolling wheel
ID Selections 256
Number of Channels 10 with automatic detect and switching
channels
Hardware Resolution 800 dpi
Electromagnetic
Characteristics (EMC)
CE - Type acceptance: ETS 300 220 short
range devices
Distance Between
Mouse and Receiver 3 feet (0.91 m)
Mouse Carrier
Frequency 27 MHz ISM band
Dimensions Mouse:
3.5 x 2.05 x 1.38 inches
(89.5 x 52.1 x 35 mm)
Receiver:
2.5 x 0.86 x 0.67 inches
(63 x 22 x 17 mm)
Weight Mouse (without batteries):
3.38 ounces (96 grams)
Receiver:
0.56 ounces (16 grams)
Receiver Interface USB version 1.1
Operating Voltage Mouse:
3.7V DC (powered by battery)
Receiver:
4.5 to 5.5V DC (powered by the USB
port)

10
Targus Wireless Multi-Channel Mouse
Troubleshooting
What do I do if the mouse does not work?
• Make sure that the mouse is fully charged.
• Verify that your computer’s power management feature is
turned off.
• Check that the receiver’s USB connector is firmly attached
to the USB port on your computer.
• Make sure you have established a radio link between the
mouse and its receiver. See “Establishing a Communications
Link” on page 4.
Batteries 1 internal lithium polymer
Operating Current Mouse:
35mA or lower
Receiver:
30mA (typical) (100mA maximum)
Mouse Standby
Current 4.5 mA (for 30 seconds of non-operation)
Mouse Flash Mode
Current
Below 2.8mA (for 20 minutes of non-
operation)
Mouse Sleep Mode
Current Below 8µA
Modulation Type FSK
Transmission Rate 5K bps
Transmission Type Digital radio frequency
Error Detection 8-bit CRC

11
Targus Wireless Multi-Channel Mouse
When I use the mouse, other wireless devices work more
slowly or fail temporarily – what should I do?
The mouse has ten channels and 256 identity codes per channel
to prevent interference. However, some interference may still
occur if there are multiple radio-based devices that operate at
27 MHz, such as a telephone, baby monitor, or toy.
To reduce interference, move the mouse’s receiver and the base
unit of the affected device as far away from each other as
possible.
What do I do if the response time of the mouse is slow or
the mouse intermittently stops working?
• Increase the distance between the mouse’s receiver and the
rest of your computer equipment.
• Increase the distance between the mouse’s receiver and the
base units of other wireless devices.
• Turn off any wireless devices and their base units that are
near the mouse’s receiver.
• If you are using the mouse on a metal surface, move it and
the receiver to a non-metal surface. Metals, such as iron,
aluminum or copper, shield the radio frequency transmission
and may slow down the mouse’s response time or cause the
mouse to fail temporarily.
I can’t use the mouse while another RF mouse is in use –
what should I do?
Reset the identification code. See “Establishing a
Communications Link” on page 4

12
Targus Wireless Multi-Channel Mouse
Technical Support
For technical questions, please visit:
Internet: http://www.targus.com/support.asp
Australia
Internet: www.targus.com.au
Email: [email protected]
Monday through Friday, 8:30 a.m. (08:30) to 5:30 p.m. (17:30)
Eastern time: 1-800-641-645
Canada
Monday through Friday, 9:00 a.m. (09:00) to 5:00 p.m. (17:00)
Eastern time: 888-827-4877
Europe
Belgium [phone]
Denmark [phone]
France [phone]
Germany [phone]
Italy [phone]
Netherlands [phone]
Spain [phone]
Sweden [phone]
Switzerland [phone]
United Kingdom [phone]
Eastern Europe & others [phone]

13
Targus Wireless Multi-Channel Mouse
Product Registration
For more efficient customer service and to activate the product’s
warranty, Targus recommends that you register your Targus accessory
shortly after purchasing it.
To register your Targus accessory, go to:
http://www.targus.com/registration.asp
You will need to provide your full name, email address, phone number,
and company information (if applicable).
Warranty
Targus warrants this product to be free from defects in materials and
workmanship for one year. If your Targus accessory is found to be
defective within that time, we will promptly repair or replace it. This
warranty does not cover accidental damage, wear and tear, or
consequential or incidental loss. Under no conditions is Targus liable for
loss of, or damage to a computer; nor loss of, or damage to, programs,
records, or data; nor any consequential or incidental damages, even if
Targus has been informed of their possibility. This warranty does not
affect your statutory rights.
Warranty Registration at:
http://www.targus.com/registration.asp
Regulatory Compliance
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) This device must accept any interference
received, including interference that may cause undesired operation.
FCC Statement
Tested to Comply
This equipment has been tested and found to comply with the limits of a
Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses,
and can radiate radio frequency energy and if not installed and used in
accordance with the instructions, may cause harmful interference to

14
Targus Wireless Multi-Channel Mouse
radio communications. However, there is no guarantee that interference
will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Move the computer away from the receiver
• Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
Intel and Pentium are registered trademarks of Intel Corporation. Windows is a
registered trademark of Microsoft Corporation. All other trademarks are the property of
their respective owners.
