Targus Wireless
RF Mouse
USER’S GUIDE
Making Your Mobile Life Easier.
Making Your Mobile Life Easier.
Visit our Web site at: www.targus.com
Features and specifications are subject to change without notice. © 2003 Targus Corp.
400-0110-001A

3
TARGUS WIRELESS RF
MOUSE
Introduction
Congratulations on your purchase of a Targus Wireless RF
Mouse. This ergonomically designed mouse uses a radio
frequency (RF) link that enables you to use the mouse
anywhere within four feet of its receiver. No line-of-sight
between the mouse and its receiver is required.
This user’s guide describes how to connect the mouse receiver
to your computer, install default software drivers and set up the
radio link for the following RF mouse models:
•PAWM10 – Wireless Mini Optical Mouse with Power
Management
In addition to this user’s guide, depending on the RF mouse
model that you purchased, this package contains:
PAWM10
•Mouse
•Receiver
•2 AAAbatteries
•Three inch USB extension cable
•Carrying pouch

4
Targus Wireless RF Mouse
System Requirements
To use the RF mouse, your computer must meet the following
hardware requirements and run one of the operating systems
listed below.
Hardware
• PC with a Pentium®processor or equivalent and a hard disk
drive
• USB interface
Operating System
• Windows®98/Me/2000/XP
NOTE: The third button and the scrolling wheel only work with
the operating systems listed above. If you use the RF mouse
with a different operating system, it will lose its enhanced
features and function as a standard, two-button mouse.
Connecting the Mouse Receiver
To connect the mouse receiver:
1 Turn off your computer.
2 Plug the USB receiver into an available USB port on your
computer.

5
Targus Wireless RF Mouse
Using the RF Mouse
Installing the Batteries
1 If the mouse is on, slide the on/off switch on the bottom of
the mouse to the “off” position.
2 Remove the battery cover from the top of the mouse by
pressing the battery cover hinge located on the bottom of
the mouse and sliding it off.
NOTE: The battery cover is also the top cover of the mouse.
3 Insert the supplied batteries, making sure that the positive
(+) and negative (-) ends of each battery match the polarity
indicators inside the battery housing.
WARNINGS: When replacing the batteries, you may use
alkaline or other heavy-duty NiMH batteries. Never use an
alkaline with a NiMH battery in a device.
Avoid mixing new and used batteries in a device.
4 Slide the battery cover back into position until it “clicks”
firmly into place.
5 Turn on the mouse be sliding the on/off switch on the
bottom of the mouse to the “on” position.
The optical sensor, located on the bottom of the mouse,
glows red.

6
Targus Wireless RF Mouse
Establishing a Communications Link
(All RF Mouse Models)
The RF mouse has 256 identification codes that allow the
mouse and its receiver to operate without interference from
other radio frequency devices.
After your computer detects the USB receiver and the driver
software is installed, you must establish a communications link
between the mouse and its receiver BEFORE you can use the
mouse. To establish this link, you need to set the identification
code so that the mouse works properly. To do this, follow the
instructions for your mouse model.
Mouse Model PAWM10
Make sure that your computer is turned on and has detected the
USB receiver before you establish a communications link.
1 Press and release the link button on the receiver.
Receiver
The USB connector rotates 90 degrees to facilitate easy
connection to your computer.
The receiver’s red status light blinks when the receiver is
activated.
2 Press and release the reset button, located on the bottom of
the mouse.
You are now ready to use the RF mouse.
90° rotation Red status light
Link button

7
Targus Wireless RF Mouse
Mouse Power Management
To power the mouse on and off, slide the on/off switch at the
bottom of the mouse to the desired position.
PAWM10 Mouse
When power is on, the mouse goes into "sleep mode" after 8
minutes of no use. To activate the mouse, touch the sensor
strips on the side with your hand.
To save battery power, turn off the mouse while traveling or
when you’re not using it.
CAUTION: Turning off the mouse will require you to
synchronize again the next time you turn it back on.
Operating Hints
For optimal performance and RF reception:
• Place the receiver at least 8 inches (20 cm) away from all
electrical devices, such as your monitor, speakers or external
storage devices.
If necessary, use a three-inch extension cable to keep the
receiver away from the computer. Plug the receiver into the
extension cable, and the extension cable to the computer.
• Avoid using the RF mouse on a metal surface. Metals, such
as iron, aluminum or copper, shield the radio frequency
transmission and may slow down the mouse’s response time
or cause the mouse to fail temporarily.
Sensor strips
Low battery indicator

8
Targus Wireless RF Mouse
• The RF mouse will enter a suspend mode at the same time
your computer does. To activate the mouse, touch the sensor
strips on the side of the mouse.
• If your computer has a metal case that contains aluminum or
magnesium, use the RF mouse to the side. The display panel
may interfere with the radio frequency signal if you use the
mouse directly in front of the computer.
• Never use the RF mouse on a glass or mirrored surface as
these surfaces will cause the mouse to fail temporarily.
• To maximize battery life, use the RF mouse on a white, or
light colored surface. Dark surfaces cause the mouse’s light
emitter diode (LED) light to glow brighter, which causes the
battery to discharge more rapidly.
Comfortable Usage
Research suggests that physical discomfort and injury to
nerves, tendons, and muscles may be related to repetitive
motion, an improperly set up work area, incorrect body
posture, and poor work habits.
To reduce the risk of injury, follow these precautions:
• Stand, stretch, and move around several times every hour.
• Switch hands while performing tasks. Use shortcut keys to
avoid repetitive or awkward mouse movements.
• Relax your shoulders and keep your elbows at your sides.
Adjust the keyboard’s position so that you don’t have to
stretch to reach it.
• Adjust your position so that you don’t have to bend your
wrists to type; avoid placing your wrists on a sharp edge.

9
Targus Wireless RF Mouse
If you feel discomfort or numbness in your hands, wrists, arms,
shoulders, neck, or back while typing, consult a qualified
medical professional.
Things to Remember
Batteries
General
• You must establish a communications link every time you
change the batteries.
• To extend the life of your batteries, turn off the mouse while
traveling.
Sleep Mode (All RF Mouse Models)
• The mouse’s sleep mode feature activates after 8 minutes of
non-operation.
• To wake the mouse from sleep mode, touch the sensor strips
on the side of the mouse.

10
Targus Wireless RF Mouse
Specifications
Model PAWM10
Button Count 3 with scrolling wheel
ID Selections 256
Electromagnetic
Characteristics
(EMC)
CE - Type acceptance: ETS 300 220 short
range devices
Distance Between
Mouse and Receiver 4 feet (1.2 m)
Mouse Carrier
Frequency
27.045 MHz
27.145 MHz
Dimensions Mouse:
4.09 x 2.2 x 1.44 inches
(104 x 56 x 36.5 mm)
Receiver:
2.75 x 0.95 x 0.55 inches
(70 x 24.2 x 14 mm)
Weight Mouse (without batteries):
3.74 ounces (106 grams)
Receiver:
0.56 ounces (16 grams)
Receiver Interface USB version 1.1
Operating Voltage Mouse: 1.6~5V
Receiver: 5V (powered by the USB port)
Batteries 2 AAA Alkaline
Operating Current Mouse: 26mA or lower
Receiver: Below 15mA

11
Targus Wireless RF Mouse
Troubleshooting
What do I do if the RF mouse does not work?
• Make sure that the polarity of the batteries is correct. The
positive (+) and negative (-) ends of each battery must match
the positive (+) and negative (-) connections in the battery
housing.
• Check that the receiver’s USB connector is firmly attached
to the USB port on your computer.
• Verify that the device drivers are installed.
• Make sure you have established a radio link between the
mouse and its receiver. See “Establishing a Communications
Link (All RF Mouse Models)” on page 6
When I use the RF mouse, other wireless devices work
more slowly or fail temporarily – what should I do?
The mouse may cause interference with any cordless,
radio-based device that operates at 27 MHz, such as a
telephone, baby monitor, or toy. To reduce interference, move
the mouse’s receiver and the base unit of the affected device as
far away from each other as possible.
Mouse Standby
Current Below 4mA
Mouse Sleep Mode
Current Below 50uA
Modulation Type FSK
Transmission Rate 4K bps
Error Detection 8-bit CRC

12
Targus Wireless RF Mouse
What do I do if the response time of the RF mouse is slow
or the mouse intermittently stops working?
• Increase the distance between the mouse’s receiver and the
rest of your computer equipment.
• Increase the distance between the mouse’s receiver and the
base units of other wireless devices.
• Turn off any wireless devices and their base units that are
near the mouse’s receiver.
• If you are using the RF mouse on a metal surface, move it
and the receiver to a non-metal surface. Metals, such as iron,
aluminum or copper, shield the radio frequency transmission
and may slow down the mouse’s response time or cause the
mouse to fail temporarily.
I can’t use the RF mouse while another RF mouse is in use
– what should I do?
Reset the identification code. See “Establishing a
Communications Link (All RF Mouse Models)” on page 6
Technical Support
For technical questions, please visit:
http://www.targus.com/support
Canada
Monday through Friday, 9:00 a.m. (09:00) to 5:00 p.m. (17:00)
Eastern time: 888-827-4877

13
Targus Wireless RF Mouse
Europe
Belgium [phone]
Denmark [phone]
France [phone]
Germany [phone]
Italy [phone]
Netherlands [phone]
Spain [phone]
Sweden [phone]
Switzerland [phone]
United Kingdom [phone]
Eastern Europe & others [phone]
Product Registration
For more efficient customer service and to activate the product’s
warranty, Targus recommends that you register your Targus accessory
shortly after purchasing it.
To register your Targus accessory, go to:
http://www.targus.com/registration.asp
You will need to provide your full name, email address, phone number,
and company information (if applicable).
Warranty
Targus warrants this product to be free from defects in materials and
workmanship for one year. If your Targus accessory is found to be
defective within that time, we will promptly repair or replace it. This
warranty does not cover accidental damage, wear and tear, or
consequential or incidental loss. Under no conditions is Targus liable for
loss of, or damage to a computer; nor loss of, or damage to, programs,
records, or data; nor any consequential or incidental damages, even if
Targus has been informed of their possibility. This warranty does not
affect your statutory rights.
Warranty Registration at:
http://www.targus.com/registration.asp

14
Targus Wireless RF Mouse
Regulatory Compliance
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) This device must accept any interference
received, including interference that may cause undesired operation.
FCC Statement
Tested to Comply
This equipment has been tested and found to comply with the limits of a
Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses,
and can radiate radio frequency energy and if not installed and used in
accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference
will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Move the computer away from the receiver
• Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
Windows is a registered trademark of Microsoft Corporation. All other trademarks are the
property of their respective owners.
