Taski swingo 1255B Power User manual

Edition: V1.00/2010
Technical Manual

GTS Technical Manual
technical manual swingo 1255 B Power V1.00 2010.03IVZ.fm
19. April 2010 Edition: V1.00/2010
Copyright © 2010, Diversey Inc.
Index
1 Foreword
1.1 Target 2
1.2 Technical Training 2
1.3 Technical Manual 2
1.4 Conclusion 3
2 Elementary
2.1 Health & Safety 2
2.2 ESD 2
3 General
3.1 General information 2
3.1.1 Part reference 2
3.1.2 Consumable supplies 2
3.1.3 Direction description 2
3.1.4 Power source 2
3.2 Required material 3
3.2.1 Tools 3
3.2.2 Material 3
4 Technical data
4.1 Machine range 2
4.2 Technical Information 3
4.2.1 Machine profile 3
4.2.2 Technical data 3
4.2.3 Machine speed 4
4.2.4 Dimensions and weights 4
4.2.5 Battery 6
4.2.6.1 Battery compartment 6
4.2.7.2 Battery specifications 6
4.2.8 Charger 7
4.2.9 Brush system 7
4.2.10 Suction power 8
4.2.11 Additional 8
4.3 Accessories & Additional parts 9
4.3.1 Accessories 9
4.3.2 Additional parts 9
5Mechanical
5.1 Mechanical sequences 2
5.1.1 Handle/Upper part 2
5.1.2.1 Replacing of microswitch 2
5.1.3.2 Replacing of hall sensor board 3
5.1.4.3 Replacing of throttle lever 5
5.1.5.4 Replacing of vacuum motor 6
5.1.6.5 Replacing of tank cover 8
5.1.7 Squeegee lowering mechanism 11
5.1.8.1 Replacing of squeegee bracket spring 11
5.1.9.2 Replacing of swinging arm long 12

GTS Technical Manual
technical manual swingo 1255 B Power V1.00 2010.03IVZ.fm
19. April 2010 Edition: V1.00/2010
Copyright © 2010, Diversey Inc.
5.1.10 Squeegee 13
5.1.11.1 Replacing of fixation spring 13
5.1.12.2 Replacing of front blade 14
5.1.13.3 Replacing of back blade 15
5.1.14 Lower part & tank 16
5.1.15.1 Replacing of tank 16
5.1.16.2 Replacing of castor wheel 18
5.1.17.3 Replacing of filter 24V 19
5.1.18.4 Replacing of pump 20
5.1.19 Drive, Wheel group 22
5.1.20.1 Replacing of traction unit 22
5.1.21 Tool lowering unit 24
5.1.22.1 Replacing of foot lever 24
5.1.23.2 Replacing of pusher rack 26
5.1.24.3 Replacing of electrical brush unit (EBU) 27
5.1.25 Brush drive unit 28
5.1.26.1 Replacing of brush drive unit 28
5.1.27 Brush drive 30
5.1.28.1 Replacing of brush belt 30
5.1.29.2 Replacing of brush pulley 33
5.1.30.3 Replacing of motor & motor belt 35
5.1.31.4 Replacing of intermediate pulley 37
6Electrical
6.1 System architecture 2
6.1.1 General 2
6.1.2 System overview 2
6.1.3 Emergency loop 3
6.2 Electrical sequences 4
6.2.1 Dashboard 4
6.2.2.1 Replacing of dashboard 4
6.2.3.2 Connections 5
6.2.4 Dashboard service menu 9
6.2.5.1 Reset service LED 9
6.2.6 Power electronics 10
6.2.7.1 Replacing of power electronics 10
6.2.8.2 Connections 11
6.2.9 Charger 15
6.2.10.1 Replacing of charger 15
6.2.11.2 Connectors 15
6.3 Schematics/System 18
6.3.1 Battery connection 18
6.3.2 Electrical schematic 19
7 Additional information
7.1 Available GTS Newsletter/Instructions 2
8 Revision
9Appendix
10 Notes

19. April 2010 Edition: V1.00/2010
Copyright © 2010, Diversey Inc.
Technical Manual
1 Foreword

GTS Technical Manual
19. April 2010 Edition: V1.00/2010 1-2
Copyright © 2010, Diversey Inc.
01.0 swingo 1255 - foreword.fm
1 Foreword
1.1 Target
To serve our customers faster and more efficient it is important to achieve a general
standard of technical know how with our partners in the market.
Therefore we developed a new Technical Training concept which is based on e-spares.
The concept consists of a Technical Training and a Technical Manual.
These two tools will be produced for each newly launched machine with a certain com-
plexity. The Technical Manual will be available as PDF file and can be downloaded from
e-spares. The Technical Training documentation will be distributed after having at-
tended a the technical training.
1.2 Technical Training
The Technical Training is addressed as reference book for the technical training ses-
sions and will be distributed to the floor care responsible and/or to the technical train-
ing responsible after attending a training session provided by GTS (max. 2 persons
per country).
The intension is, that after this session, a technical trainer is able to perform technical
training for their local technical staff and in this way to transfer the knowledge to all
service technicians.
The Technical Training is not intended as manual for the service technicians and will
be distributed only to the training responsible of each country.
1.3 Technical Manual
The Technical Manual is addressed to the service technicians and should be translated
and distributed after a technical training.
It contains a summary of procedures, hints and suggestions etc. which are helpful and

GTS Technical Manual
19. April 2010 Edition: V1.00/2010 1-3
Copyright © 2010, Diversey Inc.
01.0 swingo 1255 - foreword.fm
essential for the daily business. The Technical Manual can be downloaded from e-
spares/documents.
1.4 Conclusion
We are convinced that the new Technical Training concept together with the Technical
Manual are powerful tools, which will help our service organisations to achieve a high-
er level of quality in repairs and customer satisfaction.
If you have any comments or questions do not hesitate to contact your country re-
sponsible.
Sincerely yours
GTS Team

19. April 2010 Edition: V1.00/2010
Copyright © 2010, Diversey Inc.
Technical Manual
2 Elementary

GTS Technical Manual
19. April 2010 Edition: V1.00/2010 2-2
Copyright © 2010, Diversey Inc.
02.0 swingo 1255 - elementary.fm
2Elementary
2.1 Health & Safety
Scrubber dryers may be powered by mains electricity or batteries. There are risks as-
sociated with both, which call for proper precautions, such as the provision of good
ventilation and the elimination of risk of ignition.
All work, implemented on such machines, should only be performed by trained per-
sonnel in accordance with local regulations.
Before working on such a machine, isolate it from any electrical source.
Always wear the required personal protective equipment (including gloves and gog-
gles that must be worn when potentially exposed to any hazardous material and when
carrying out hazardous work tasks).
Note that parts may be contaminated with chemical product. If possible flush hoses
out with fresh water prior to carrying out any maintenance. For information on chem-
ical products that are used in this machine, please carefully read the product label
and Material Safety Data Sheet (MSDS).
Empty water tanks prior to carrying out any maintenance. Ensure contaminated water
is emptied into an approved drain. Avoid pollution.
2.2 ESD
Static electricity is electricity at rest or the accumulation of electric charge, as op-
posed to an electric current which is the movement of electricity. The flow or move-
ment of people and/or materials in and through the environment causes separation
and therefore static electricity. A familiar example of static electricity is when a per-
son walks across a carpeted floor. Static electricity/electrostatic charge is generated
simply by the contact and separation of the soles of that individual's shoes from the
carpeted floor.
Electrostatic Discharge (ESD) occurs when the electrostatic charge is transferred from
a material that carries the charge to an electrostatic sensitive device. In the example
above, this electrostatic discharge is the „shock“ felt after walking across the carpeted

GTS Technical Manual
19. April 2010 Edition: V1.00/2010 2-3
Copyright © 2010, Diversey Inc.
02.0 swingo 1255 - elementary.fm
floor and then touching a door knob. It is this electrostatic discharge, which comes in
varying degrees, that can be most damaging to electrical devices and other industrial,
commercial and consumer products.
Static electricity, a natural phenomenon and consequently electrostatic discharge are
the primary causes of countless problems affecting industry, business and personal
life. These problems can be as simple as the shock resulting from walking across a
carpet; as costly as the destruction of sensitive electronic components or jamming of
machinery.
Almost any material can generate static electricity. The ability to store or unload the
charge depends on the type of material.
Static can damage devices, which can result in immediate product failure to operate.
In contrast, static damage can go undetected for a period of time and the results are
product failure once the product is in service.
Electrostatic fields are associated with charged objects.
The degree of severity of ESD events is contingent upon the type of discharge which
occurs. The three most common ESD charge transfers are:
• from an external object to the device
• from a device to another object
• resulting from electrostatic fields
Please do not store electronics without ESD bags at any time.

19. April 2010 Edition: V1.00/2010
Copyright © 2010, Diversey Inc.
Technical Manual
3 General

GTS Technical Manual
19. April 2010 Edition: V1.00/2010 3-2
Copyright © 2010, Diversey Inc.
02.5 swingo 1255 - general.fm
3 General
3.1 General information
3.1.1 Part reference
Explicitly mentioned parts are defined by references corresponding
to the e-spares spare parts list.
E.g. Tank axle (02/118) corresponds to the parts list on e-spares,
sub assembly 2, position 118.
3.1.2 Consumable supplies
If you have to remove cable ties then position the new ones at the
original place.
If you have to remove self locking nuts, you should replace them
by new ones.
3.1.3 Direction description
On the „RH“ always means on the right hand side of the machine in
working direction (when you are standing behind the machine).
On the „LH“ always means on the left hand side of the machine in
working direction (when you are standing behind the machine).
3.1.4 Power source
Depending on the work it might be required to remove the power
source (mains/batteries) from the machine.
The in here mentioned sequences (mechanical and electrical) are
based on the assumption that the power source (mains/batteries)
were removed from the machine before.

GTS Technical Manual
19. April 2010 Edition: V1.00/2010 3-3
Copyright © 2010, Diversey Inc.
02.5 swingo 1255 - general.fm
3.2 Required material
3.2.1 Tools
• A standard range of tools is required e.g.
• Fork spanners
• Allen keys
• Torx keys
3.2.2 Material
• No special tools are required.
The above listings are only a recommendation for the technical
training.

19. April 2010 Edition: V1.00/2010
Copyright © 2010, Diversey Inc.
Technical Manual
4 Technicaldata

GTS Technical Manual
19. April 2010 Edition: V1.00/2010 4-2
Copyright © 2010, Diversey Inc.
04.0 swingo 1255 B Power - technical data.fm
4TechnicalData
4.1 Machine range
SKU Description Version Series
7516829 TASKI swingo 1255
B Power
01
7516830 TASKI swingo 1255
B Power
BMS SEV 01
7516831 TASKI swingo 1255
B Power
BMS EURO 01
7517575 TASKI swingo 1255
B Power
BMS DK 01
7517715 TASKI swingo 1255
B Power
BMS NA 01
7516833 TASKI swingo 1255
B Power
BMS UK 01
7516832 TASKI swingo 1255
B Power
BMS EBU SEV 01
7516834 TASKI swingo 1255
B Power
BMS EBU EURO 01
7517576 TASKI swingo 1255
B Power
BMS EBU DK 01
7516836 TASKI swingo 1255
B Power
EBU 01
Table 1: Machine range

GTS Technical Manual
19. April 2010 Edition: V1.00/2010 4-3
Copyright © 2010, Diversey Inc.
04.0 swingo 1255 B Power - technical data.fm
4.2 Technical Information
4.2.1 Machine profile
4.2.2 Technical data
Pos. Value
Theoretical performance (at 4.5 km/h) (m²/h) 2475
Practical performance (m²/h) 1250
Working width (mm) 550
Squeegee width (mm) 800
Solution tank (l) 55
Recovery tank (l) 55
Table 2: Machine profile
Pos. Value
Noise level (ECO mode) dB(A) <60
Vibration (m/s2) < 0.5
Approvals ÖVE
Nominal consumption (W) 1000
Power drive motor (W) 200
Power suction motor (W) 490
Voltage (V) 24
Battery capacity max. (maintenance-free/wet) (Ah)/C5 50/70
Battery autonomy max.
(70 Ah maintenance free battery)
(h) up to 3.0
Internal charger only in BMS
Protection grade machine IPX3
Protection class charger (BMS model) I
Protection class charger (BMS model DK) II
Table 3: Technical Data

GTS Technical Manual
19. April 2010 Edition: V1.00/2010 4-4
Copyright © 2010, Diversey Inc.
04.0 swingo 1255 B Power - technical data.fm
4.2.3 Machine speed
4.2.4 Dimensions and weights
Pos. Value
Transportation speed (km/h) 4.5
Cleaning speed (km/h) 4.5
Ramp max. (%) 2
Table 4: Machine speed
Pos. Value
Dimensions L/W/H (mm) 1420/580/1170
Door pass through with squeegee (mm) 800
Battery compartment L/W/H (mm) 700 x 340 x 240
Net weight without batteries; empty tank (kg) 81
Weight, ready to use (kg) 260
Max. floor pressure (N/mm2) 0.39
Wheel diameter front (mm) 200
Wheel diameter - castor (mm) 100
Table 5: Dimensions and weights

GTS Technical Manual
19. April 2010 Edition: V1.00/2010 4-5
Copyright © 2010, Diversey Inc.
04.0 swingo 1255 B Power - technical data.fm
Picture 1: Dimensions

GTS Technical Manual
19. April 2010 Edition: V1.00/2010 4-6
Copyright © 2010, Diversey Inc.
04.0 swingo 1255 B Power - technical data.fm
4.2.5 Battery
4.2.5.1 Battery compartment
Picture 2: Battery compartment
4.2.5.2 Battery specifications
Please use batteries from Excide/Sonnenschein, as this is our
preferred partner.
BMS is only for dry (gel) batteries.
For the correct connection of the batteries, pay attention to the
voltage of each battery and the correct connection. Therefore refer
to e-spares.
Pos. Value
Battery compartment L/W/H (mm) 700 x 340 x 240
Table 6: Battery compartment

GTS Technical Manual
19. April 2010 Edition: V1.00/2010 4-7
Copyright © 2010, Diversey Inc.
04.0 swingo 1255 B Power - technical data.fm
4.2.6 Charger
4.2.7 Brush system
Supplier Type
Voltage Ah Length [mm] Width [mm] Height [mm] Weight [kg]
Excide Sonnenschein GF12050 12 50 278 175 190 20
Excide Sonnenschein GF12070 12 70 330 171 236 28
Table 7: Dry (gel) batteries
Pos. Value
Primary V 100 - 240
Primary Hz 50 - 60
Secondary V 24
Secondary A 20
Secondary (DK model) A 25
Protection class charger (BMS model) I
Protection class charger (BMS model DK) II
Approval CE
Cable length / BMS cable (m) 3
Table 8: Charger
Pos. Value
Brush system (mm) 2 x 280
Brush motor (W) 750
Brush speed (rpm) 195
Brush pressure max. (kg) 48
Table 9: Brush system

GTS Technical Manual
19. April 2010 Edition: V1.00/2010 4-8
Copyright © 2010, Diversey Inc.
04.0 swingo 1255 B Power - technical data.fm
4.2.8 Suction power
4.2.9 Additional
Pos. Value
Vacuum motor (W) 490
Max. air flow (l/s) 32
Max. vacuum (mbar) 118
Max. vacuum (kPa) 11.8
Table 10: Suction power
Pos. Value
Cleaning Solution Dosing CSD system
Brush lifting mechanical or
electrical (EBU)
Squeegee lifting mechanical
Table 11: Additional
