Owner's Manual
This owner’s manual should be considered as a permanent part
of the vehicle and must remain with the vehicle.
Passenger Vehicle Business Unit (PVBU)
Mumbai Pune

2
Please read this Owner’s Manual carefully before you start driving your car
and always keep it safe in the car.
●The recommended routine maintenance servicing along with any
running repairs that may be required, should be entrusted to TATA
Authorised Workshop to ensure that only latest methods and genuine
TATA MOTORS replacementparts are used for the continued reliability,
safety and performance of the vehicle.
●Some of the items / accessories / features shown / given in this book
may not be fitted on your vehicle, these may be applicable for other
versions of TATA NANO.
●(C) Copyright 2013 TATA MOTORS
●All rights reserved. The material in this manual shall not be reproduced
or copied, in whole or in part, in any form without written permission
from TATA MOTORS.
●The information and specifications given in this book are valid as on
the date of printing. TATA MOTORS LIMITED reserves the right to
make changes in design and specifications and/or to make additions
to or improvements in this product without obligation to install them on
products previously sold.
●In the event of the Vehicle being sold, please ensure that this manual
is left in the vehicle for the reference of the new owner.
A NOTE
01.Owner’s Manual & Service
Book
02.First Aid Kit
03.Advance Warning Triangle
04.Jack & Wheel Spanner
05.Tow Hook
06.Spare Headlamp Bulbs
07.Spare Fuses
08.Pre-delivery Inspection and
Service
09.Complimentaryfuelinfuel tank
While taking delivery of your new car, you are priviledged to have the
following :

33
Dear Customer,
Thank you for selecting TATA NANO the most exciting car.
We welcome you to the world of advanced automotive engineering marvel
suited to your operating conditions.
This book gives you all the information necessary for making your ownership
of this car a delighting experience and help you in all situations.
To assist you in maintaining your car as per recommended service schedule,
we have a widespread network of dealers and service centres. Kindly refer
Service Network booklet provided alongwith the Owner’s Manual.
Please do not hesitate to call on our Regional / Area offices in case you
need any special assistance.
Please note that by adhering to the correct operating procedures and by
availing the scheduled maintenance services at our authorised service
centres, you can obtain the maximum performance from your car.
We request you to go through this book and derive many miles of motoring
pleasure.
We wish you Safe and Pleasant Motoring
FOREWORD

4
SAFETY SYMBOL
In this manual, you will
also see a circle with a
slash. This means "Do
not", "Do not do this", or
"Do not let this happen".
SAFETY SYMBOLS
In this manual, you will find
‘CAUTION’, ‘NOTICE’, ‘WARNING’
messages and ‘safety symbol’ at
appropriateplaces.Thesignificance
of these messages are explained
below. CAUTION
This is a warning which may
cause injury to people if it is
ignored. You are informed what
you must or must not do in order
to avoid or reduce the risk to
yourself and other people.
NOTICE
This is a warning which may
cause damage to the car or its
equipment if it is ignored. You are
informed what you must or must
not do in order to avoid or reduce
theriskof damagetoyour carand
its equipment.
WARNING
Indicates a strong possibility of
severe personal injury or death if
the instructions are not followed.
CUSTOMER ASSISTANCE

55
WARRANTY
Warranty - Terms & Conditions 07
ENVIRONMENT PROTECTION
Environment Protection 09
KNOW YOUR NANO 11
AN OVERVIEW
Driving Controls 13
Instrument Cluster 14
Gauges & Indicators 16
Steering Lock cum Ignition Switch 25
Combination Switch 26
Music System & Antenna 29
Heating, Ventilation & Air Conditioning 30
Lamps 34
Rear View Mirrors & Sun visor 36
Vanity Mirror,Grab Handle,Utility pocket/ 37
box
Cup holder, Window Winding & Power 38
Socket
Parking Brake,Gear Shift Lever & 39
Glove Box
Front Hood - Opening & Closing 40
Refuelling 41
GETTING STARTED
Door Locking / Unlocking 42
Door Locks 46
Front Seat & Seat Adjustment 47
Rear Seat & Seat Folding 48
Seat Belts 49
DRIVING
Before Driving & Safety Checks 52
Safety Checks & Driving Safety 53
Fuel Economy 54
Starting,Stopping & Running in Period 55
Gear Shifting, Braking & Parking 56
Driving In Adverse Conditions 57
INCASEOFEMERGENCY
Advance Warning Triangle
Hazard Warning Switch 59
If you have Flat tyre 60
Starting The Engine with Jump Leads 61
Towing the Car 64
Routine Service 66
Preliminary Trouble shooting 67
ELECTRICALMAINTENANCE
Fuses & Relays 72
Fuses & Relays Layout 73
Bulb Specification 77
Accessary Connectors Details 78
VEHICLECARE
Car Care 80
MAINTENANCE
Brake Fluid & Windshield Washer 83
Engine Compartment Cover 84
Engine, Oil & Coolant 84
Air Filter & Spark Plug 86
Tyre 87
Wheel Alignment & Catalytic converter 89
Battery 90
IMPORTANT TECHNICAL
INFORMATION
Fuel, Lubricants & Coolants 91
Oil Filling & Drain Points 93
Technical Specification 94
Dimensions 97
CAR IDENTIFICATION
Loctation of Aggregate Number 98
SERVICE MAINTENANCE
SCHEDULE 99
MUSIC SYSTEM
OPERATOR’S MANUAL 101
RECORD OF SERVICES
PERFORMED 128
RECORD OF REPAIRS
CARRIED OUT 129
CONTENTS

6
CONTENTS

77
We WARRANT each TATA NANO
and parts there of manufactured by
us to be free from defect in material
and workmanship subject to the
following terms and conditions :
1. Thiswarrantyshall befor4Years
or 60,000 kms,whicheveroccurs
earlier from the date of sale of
the car.
2. Ourobligation underthiswarranty
shall be limited to repairing or
replacing free of charge, such
parts of the car which, in our
opinion, are contributing to
improper operation, on the car
being brought to us or to our
dealers within the period. The
partssorepairedorreplacedshall
also be warranted for quality and
workmanship but such warranty
shall be co-terminus with this
original warranty.
3. Any part which is replaced by us
under the warranty shall be our
property.
4. As for parts like tyres, battery,
electrical equipment, fuel
injection equipment etc. not
manufactured by us but supplied
by other OE Manufacturers, this
warranty shall not apply. Buyers
of the car shall be entitled to, so
faraspermissible by law,allsuch
rights as we may have against
such parties under their
warranties in respect of such
parts.
5. This warranty shall not apply if
the car or any part thereof is
repairedoralteredotherwisethan
in accordance with our standard
repairprocedureorbyanyperson
other than from our sales or
service establishments, our
authorized dealers, service
centers or service points in any
waysoas,inour judgment which
shallbe finaland binding,to affect
its reliability, nor shall it apply if,
inouropinionwhichshallbefinal
and binding the car is subjected
to misuse, negligence, improper
or inadequate maintenance or
accident or loading in excess of
suchcarryingcapacityascertified
by us, or such services as
prescribedinourOwner’sManual
and Service Book are not carried
out by the buyer through our
sales or service establishments,
ourAuthorized Dealers, Service
Centers or Service points.
6. This warranty shall not cover
normal wear and tear or any
inherent normal deterioration of
the car or any of its parts arising
from the actual use of the car or
any damage due to negligent or
improper operation or storage of
the car. This warranty shall not
apply to normal maintenance
services like oils and fluid
changes, head lamp focusing,
fastener retightening, wheel
balancing, tyre rotation,
adjustment of valve clearance,
fuel timing, ignition timing and
consumables like bulbs, fuel
filters and oil filters etc. This
WARRANTY - TERMS & CONDITIONS

8
WARRANTY - TERMS & CONDITIONS
warranty shall not apply to any
damage or deterioration caused
byenvironmentalpollution or bird
droppings.Thiswarrantyshallnot
apply to V-belts, hoses and gas
leaks (in case of air conditioned
cars) & slight irregularities not
recognized as affecting the
function or quality of the vehicle
or parts such as slight noise or
vibration and defects appearing
only under particular or irregular
operations or items considered
characteristic of the vehicle.
7. This warranty shall be null and
void if the vehicle is subjected
toabnormalusesuchasrallying,
racingor participationinanyother
competitivesports.Thiswarranty
shall not apply to any repairs or
replacement as a result of
accident or collision.
8. This warranty is expressly in lieu
of all warranties, whether by law
or otherwise, expressed or
implied and all other obligations
or liabilities on our part and we
neitherassume norauthorizeany
person to assume on our behalf,
anyotherliabilityarisingfromthe
sale of the vehicle or any
agreement in relation thereto.
9. The buyer should have no other
rightsexcept those set out above
and have, in particular, no right
to repudiate the sale, or any
agreement or to claim any
reduction in the purchase price
of the vehicle, or to demand any
damages or compensation for
losses, incidental or indirect, or
inconvenience or consequential
damages, loss of vehicle, or loss
of time, or otherwise, incurred or
accrued.
10. Any claim arising from this
warrantyshall berecognizedonly
if it is noticed in writing to us or
to our concerned Dealer without
any delay soon after such defect
as covered and ascertained
under this warranty.
11. This warranty shall stand
terminated if the vehicle is
transferredor otherwisealienated
by the buyer without our prior
written consent.
12. We reserve our rights to make
anychangeormodificationinthe
design of the vehicle or its parts
or to introduce any improvement
therein or to incorporate in the
vehicle any additional part or
accessory at any time without
incurring any obligation to
incorporate the same in the
vehicles previously sold.

99
TATA MOTORS LTD. is committed
to produce vehicles using
environmentally sustainable
technology. Many features have
been incorporated in Tata Motors
passenger vehicles which have
been designed to ensure
environmental compatibility
throughout the life cycle of the
vehicle. We would like to inform
you that your car meets emission
norms and this is being regularly
validated at the manufacturing
stages.
As a user you too can protect the
environment by operating your car
in a proactive manner. A lot
depends on your driving style and
the way you maintain your car. We
have given a few tips for your
guidance.
DRIVING
•Avoid frequent and violent
accelerations / rev-ups.
•Avoid overloading of the
engine. Avoid using devices
requiring high power
consumption during slow city
traffic condition.
•Monitor the car’s fuel
consumption regularly and if
showing rising trend get the
car immediately attended at
the TATA Authorised Service
Outlets.
•Switch off the engine during
long stops at traffic jams or
signals. If you need to keep
the engine running, do not
unnecessarily rev-up.Avoid
stopping and starting.
•Do not rev-up the engine
before turning it off as it
unnecessarily burns the fuel.
•Shift to higher gears as soon
as it is possible without
overloading the engine. Use
each gear upto 2/3rd of it’s
maximum engine speed. A
chart indicating gear shifting
speeds is given in this book.
MAINTENANCE
•Ensure that recommended
maintenance is carried out on
the car regularly at the
Authorised Service Outlets.
•As soon as you see any
leakages of oil, fuel or coolant
in the car we recommend to
get it attended immediately.
•Use only recommended
grades and specified quantity
of lubricants.
•Get your car checked for
emission periodically by an
authorised dealer.
•Ensure periodic radiator fins
cleaning.
•Ensure that fuel filter, oil filter
and breather are checked
periodically and replaced, if
required, as recommended by
Tata Motors.
ENVIRONMENTAL CARE

10
•Do not pour used oils or
coolants into the sewage
drains, garden soil or open
streams. Dispose the used
filters and batteries in
compliance with the current
legislation.
•Do not allow unauthorised
person to tamper with engine
settings or to carry
modifications on the car.
•Never allow the car to run out
of fuel.
•Parts like brake liners, clutch
discs should be vacuum
cleaned. Do not use
compressed air for cleaning
these parts which may spread
dust in the atmosphere.
•While carrying out servicing or
repairs on your vehicle, you
should pay keen attention to
some of the important engine
components which greatly affect
emission. These components
are:
1. Fuel pump, Injectors and EMS
(Engine Managment System)
parts.
2. Air Intake and Exhaust systems
(especially for leakages).
3. Cylinder head/Valve leakages.
4. All filters such as air, oil & fuel
filter (check periodically).
5. Ignition system & Spark plug.
6. Catalytic converter.
7. Carbon Canister.
This Owner’s manual contains
further information on driving
precautions and maintenance care
leading to environment protection.
Please familiarise yourself with
these aspects before driving.
ENVIRONMENTAL CARE

1111
Your NANO comes from a family of
new generation cars of TATA
motors.It is the outcome of
extensive research and
development by Tata Motors
Limited. We are happy to present
the NANO to you and hope it brings
the joy, pride and utility of owning a
car for personal mobility.
The NANO’s design and features
combined with easy maneuverability
and economic life cycle cost make
it ideal for operating under a wide
range of conditions.
Stylish, comfortable
The Tata Nano, designed with a
family in mind, has a roomy
passenger compartment with
generous leg space and head room.
Four persons can comfortably sit
inside the car. Four doors with high
seating position make comfortable
ingress and egress. All new floor
console comes with well-designed
utility spaces and the glove box.
This is also equipped with music
system.
It can effortlessly maneuver on busy
roads in cities as well as in rural
areas. Its mono-volume design
ensure with Electric Power Steering
system.
The car is available in Standard,
Deluxe & Luxury versions. All
versions offer a wide range of body
colours, and other accessories so
that the car can be customised to
an individual’s preferences and
taste.
KNOW YOUR NANO

12
Fuel-efficient engine
The Tata Nano has a rear mounted
rear-wheel drive, all-aluminum, two-
cylinder, multi point fuel injection
petrol engine. The lean design
strategy has achieved minimum
weight and maximum performance
per unit of energy consumed and
delivers high fuel efficiency.
Performance is controlled by a
specially designed electronic engine
management system.
Meets all safety requirements
The Tata Nano’s safety performance
exceeds current regulatory
requirements. With an all sheet-
metal body, it has a strong
passenger compartment, with safety
features such as crumple zones,
intrusion-resistant doors, seat belts,
strong seats and anchorages, and
the rear tailgate glass bonded to the
body. Tubeless tyres further
enhance safety.
Environment-friendly
The Tata Nano’s exhaust emission
performance meets present
regulatory requirements. The high fuel
efficiency also ensures that the car
has low carbon dioxide emissions,
thereby providing the twin benefits of
an affordable transportation solution
with a low carbon footprint.
Besides all these, TATA vehicles are
backed by a well established service
network with trained and skilled
manpower that ensures proper
maintenance.
KNOW YOUR NANO

1313
DRIVING CONTROLS
DRIVING CONTROLS AN OVERVIEW
Note : a. HVAC orAC System is applicable to certain models.
b. Music System is part of accessories. It is applicable to certain models.
10. Accelerator Pedal
11. Brake pedal
12. Clutch pedal
13. Parking Brake
14. WindowWindingSwitch (iffitted)
15. Gear shifting lever
16. Music System (For LXM)
17. HVAC/ACsystemcontrols
18. CentralAirVents
1. Side air vents
2. Speakers on dashboard (For LXM)
3. Glove Box (Co-driver side)
4. Instrument Cluster
5. Hazard Warning Switch
6. Glove Box (Driver side)
7. Steering wheel
8. Combi switch
9. Horn Pad

14
INSTRUMENT CLUSTER (WITH EPS)
AN OVERVIEW
Some Indicators shown may not be applicable to all models.c
1. FuelGauge
2. Speedometer
3. TemperatureGauge
4. TellTales
5. MODEknob
6. LCD(DigitalDisplay)
7. SETKnob
8. TurnIndicator-Right
9. TurnIndicator-Left
12 3
7
4
5
6
4
4
4
98
INSTRUMENT CLUSTER - EPS

1515
AN OVERVIEW
INSTRUMENT CLUSTER (WITH NON-EPS)
Some Indicators shown may not be applicable to all models.c
INSTRUMENT CLUSTER - NON-EPS
1. TellTales
2. Speedometer
3. LCDDisplayforFuelLevel
&Odometer
4. Trip / Rest knob
21
3
1
4
1

16
GAUGES & INDICATORSAN OVERVIEW
Speedometer :
The speedometer indicates speed
of the vehicle in unit of km/h
Speedometer (EPS)
Speedometer (Non-EPS)
Vehicle Speed Limitation:
The vehicle is designed for a safe
speed of 105 kmph. If vehicle is
driven above this speed, MIL lamp
starts blinking and the vehicle fuel
supply will be cut off automatically
to restrict the vehicle speed.
Avoiddriving thevehicle at speeds
above 105 kmph.
Temperature Gauge: (Onlyon EPS
vehicle)
Temperature Gauge (EPS)
The Gauge indicates the
temperature level of the engine
coolant after Ignition ON .The red
zone at ‘H’ indicates temperature
higher than normal.
NOTICE
If the bar graph moves beyond the
normal range area toward the "H"
position i.e Red bar graph, it
indicates overheating that may
damage the engine. ,which may
beduetoinsufficient coolant in the
radiator or due to any other defect.
Take the car t the nearest TATA
MOTORS Authorised service
station.
FuelGauge(EPS) :
The fuel gauge indicates the
approximate amount of fuel
remaining in the fuel tank when the
ignition switch is ‘ON’.
When fuel on the tank is near to
empty position then 1st LED bar
(Red Color) start flashing and low
fuel warning tell tale turned ‘ON’.
NOTICE
At every start speedo needle
moves to MAX and come back to
‘0’ position. This is welcome
strategy and self check feature.

1717
In case of flashing of 1st and last
bar of the LED with low fuel warning
tell tale please contact Tata Motors
Authorized Service Outlet.
WARNING
Running the fuel tank too low or
empty can cause your engine to
stall and could endanger you and
your passengers.
You must stop and obtain additional
fuel as soon as possible after 1st
LED bar start flashing and low fuel
warning tell tale turned on.
On inclines ,curves, braking and
sudden acceleration due to the
movementoffuelinthe tank, the fuel
level display may fluctuate or the low
fuel level warning lamp may
illuminate earlier than usual. Always
check the fuel level when the vehicle
is on level road.
When the ignition switch is in the
“ON” position, this gauge gives an
approximate indication of the
amount of fuel in the fuel tank and it
takes few seconds to stabilize after
the ignition is turned ON .“F”stands
for full and “E” stands for Empty.
Do not continue adding fuel after the
automatic shut off function is
operated if it is eqqipped on the
gasoline pump. The sensor in the
fuel tank may misjudge the amount
of fuel remaining.
FuelGauge (Non-EPS)
Fuel Gauge (EPS)
The fuel gauge indicates the
approximate amount of fuel
remaining in the fuel tank when the
ignition switch is ON. When the fuel
tank is near empty position then "E"
symbol starts flashing.
If the "E" symbol starts flashing it is
recommendable to fill the fuel as
soon as possible. In case of flashing
fuel icon on display please contact
authorised Tata Motors distributor.
NOTICE
On inclines or curves, the fuel
gauge may fluctuate or the "E"
symbol may flash earlier than
usual due to the movement of fuel
in the tank.
WARNING
Running the fuel tank too low or
empty can cause your engine to
stall and could endanger you and
your passengers
AN OVERVIEW
GAUGES & INDICATORS

18
You must stop and obtain
additional fuel as soon as possible
after "E" flashing comes ON or
when the gauge indicator comes
close to the E level.
TELLTALES:
Electric Power Steering
Warning Indicator : (EPS)
It indicates the malfunctioning of
EPS (Electric Power Steering).
It will illuminate momentarily when
ignition is switched ‘ON’
It will continuously illuminate if
malfunctioning of EPS (Electric
Power Steering) occurs. Stop the
vehicle at safe place and restart the
engine, indicator should go off after
driving a short distance If it still
continue to illuminate again while
driving, contact nearest Tata
Authorised service centre. In case
of EPS malfunctioning, increased
steering effort will be required.
NOTICE
1. Electric power steering is
operational only when engine
is running.
2. In case of EPS malfunctioning
or engine switched ‘OFF’
condition, increased steering
effort will be required.
3. In case of continues use of
steering like driving in ghat
section or constraint parking,
the steering may become
GAUGES & INDICATORS
AN OVERVIEW
harder. This is normal to
protect the electric steering
motor from overheating. It will
automatically restore during
normal driving.
LowFuel
Indicator : (EPS)
This symbol lights up momentarily
when ignition is turned ‘ON’. The
symbol lights up continuously if fuel
level in the tank is low. Fuel needs to
be filled immediately. It will blink if
there is any fault in the system. Take
your car to the nearest Tata
authorized service station if the
symbol starts blinking.
Turn Signal
Indicator :
Turn signal indicators can be
operated only when ignition is ‘ON’.
They can be operated by using the
turn indicator switch on the combi-
switch. The direction indicator arrow
(LHS) and (RHS) on the
instrument cluster flashes along
with external indicators lights as per
selection.
CAUTION
If the turn signal indicators do not
blink, then there may be problem
in electrical system. If the
indicators “Blink rapidly”, then this
indicates that a side indicator
bulb has failed. Get it rectified
immediately.
