TATA Motors Aria User manual

TATA
TATA
TATT
TT
TAA
AA
A ARIAARIA
ARIAARIA
ARIA
OWNER’S MANUAL & SERVICE BOOK
This owner’s manual is advised to be kept in the vehicle at all the times.
Passenger Vehicle Business Unit
•Mumbai •Pune •

INTRODUCTION
II
•Should any question or query exist regarding any aspect of your vehicle, please contact the nearest TATA
MOTORS dealer, who will be pleased to assist you.
•The recommended routine maintenance servicing along with any running repairs that may be required,
should be entrusted to TATA MOTORS dealership or to TATA Authorised Service centres (TASCS) or
TATAAuthorised Service Points (TASPS) toensurethat onlylatest methodsand genuineTATAMOTORS
replacement parts are used for the continued reliability, safety and performance of the vehicle.
•Some of the items / accessories / features shown / given in this book may not be fitted on your vehicle, but
they are applicable for other variants of TATAARIA.
•Copyright 2014 TATA MOTORS
•All rights reserved. The material in this manual may not be reproduced or copied, in whole or in part, in any
form without written permission from TATA MOTORS.
•Inthe event ofthe Vehiclebeing sold,please ensure thatthis manualis leftin thevehicle forthe reference of
the new owner.
This owner's manual & service book includes information on the operation and maintenance of various
equipment installed on the different variants of TATA ARIA. Please note that this manual applies to all the
modelsand explains allequipment includingoptions notinstalled onyour vehicle.
NOTE

INTRODUCTION
III
FORWARD
Dear Customer,
Thank you for choosing TATAARIA.
TATA ARIA is a crossover type of vehicle that has been built on a completely
new platform.
ARIA comes with TOD (Torque-On-Demand) transfercase. It automatically and
smoothly delivers four-wheel drive operation as and when the driving conditions
demand.
For enhanced safety of occupants, the ARIA has SRS (Air bag), ABS (Anti lock
Braking System), and ESP (Electronic Stability Program) in addition to having
disc brakes on all its four wheels. Advanced electronics are employed in the
ARIA tocontrol its various functions. Infotainment System providedinthe ARIA
is a source of both, information as well as entertainment to the passengers.
Reverse Parking Assist System helps in directing the car safely. The interiors
of theAria are luxury personified with the soft touch dashboard having matching
trim colour.
Powering the ARIA is TATA MOTORS proven 2.2 Litre VARICOR Engine that
aids drivability, especially while tackling rough hard-hitting roads.
This book gives you all the information necessary for making your drive a
wonderful experience.
We wish you a safe and wonderful driving experience.

INTRODUCTION
IV
CUSTOMERASSISTANCE

INTRODUCTION
V
CONTENTS
INTRODUCTION
VALUE ADDED SERVICE
1 24X7OnRoadAssistance 2
2 ExtendedWarranty 6
3 Anti-rust, Sound Deadening & Engine Waxing 8
4 Exterior & Interior Enrichment Program 10
ENVIRONMENT PROTECTION 13
WARRANTY-TERMS & CONDITIONS 15
GETTING STARTED 17
1 E-Key and Remote Keyless Entry 17
2 Door Locking / Unlocking 18
3 Child Lock & Tail gate Opening / Closing 19
4 Steering Lock cum Ignition Switch 20
5 Seat&SeatAdjustments 21
6 SeatBelt 27
7 Rear View Mirrors - Inner & Outer 31
8 SteeringHeightAdjustment 32
9 4X2 & 4X4Auto Mode Selection Switch 32
9 HeadLightControls 33
10 PowerWindows 35
11 Dashboard 36

INTRODUCTION
VI
CONTENTS
3 Tail Lamp 75
4 RegistrationPlateLamp 76
5 HighMountedStopLamp 76
6 PuddleLamp/DoorLamp 76
7 CargoLamp 76
8 ReflexReflectors 77
9 FuelFlapOpening/Closing/Emergency 77
10 Bonnet Opening / Closing 78
SPECIALFEATURES
1 Immobilizer 79
2 Air Bags (SRS) 81
3 ABS (Anti-lock Braking System) 86
4 ESP (Electronic Stability Program) 88
5 CruiseControl 89
6 TOD(TorqueOnDemand) 91
7 RainandLightSensor 92
7 ReverseParkingSystem 94
DRIVING
1 SafetyChecksBefore Driving 98
2 DrivingSafety 99
3 FuelEconomy 100
4 Starting / Stopping & Parking 101
5 Running-In 102
DRIVINGCONTROLS
1 GearShiftLever 37
2 ParkingBrake 37
3 Combi-Switch 38
4 InstrumentCluster-Gauges& Indicators 42
5 Facia Switches 57
6 SteeringWheelSwitches 58
7 HVAC - Manual & FATC 59
8 TFTDisplay 66
INTERIORS
1 Sun visors & Vanity Mirror 67
2 GrabHandle/CoatHook 68
3 GoggleCase& OverheadStorage Bin 68
4 CupHolders 69
5 Utility Pockets on Door Trims 69
6PowerSocket 70
7 GloveBox &Top Stowage Box 71
8 InteriorLamps 72
9 MusicSystem-Speakers/Antenna/USB port 73
EXTERIORS
1 Headlamp 75
2 FogLamp 75

INTRODUCTION
VII
CONTENTS
9 Intercooler 134
10 CatalyticConverter 135
11 Tyres 136
12 Battery 139
13 Window Glasses 140
14 Wiper 140
15 VehicleCare 141
TECHNICALINFORMATION
1 Fuel/Coolant&Lubricants 143
2 Technical Specification 146
3 VehicleDimensions 150
4 Chassis&AggregateNumberingLocations 151
VEHICLESERVICE
1 PDIService 152
2 ServiceSchedule 154
3 ServiceCoupons
6 Brakes & Braking 103
7 DrivingInAdverseCondition 104
INCASE OFEMERGENCY
1 AdvancedWarningTriangle / Jack /Tools 107
2 IfYouHaveFlatTyre 108
3 Jacking Points / Jack Location 109
4 TowingThe Vehicle 111
5 Startingthe engine withjumpleads 112
6 Fuses & Relays 113
7 BulbSpecification 118
9 Headlampbulb replacement 119
8 Tail lamp bulbreplacement 121
9 PreliminaryTrouble Shooting 122
MAINTENANCE&CAR CARE
1 EngineCompartment 131
2 Air Filter 132
3 EngineOilLevel Check 132
4 EngineCoolantLevelCheck 132
5 BrakeFluidLevel Check 133
6 PowerSteeringFluid Level Check 133
7 WindshieldWasherFluidLevel Check 133
8 Turbocharger 134

INTRODUCTION
VIII
SAFETY SYMBOL
In this manual, you will also see a circle with a slash. This
means "Do not", "Do not do this", or "Do not let this happen".
SAFETYAND VEHICLE DAMAGE WARNINGS
In this manual, you will see CAUTION and NOTICE
WARNINGS.
CAUTION
Thisisawarning. May causeinjurytopeopleif the warning
isignored.You are informed what you must or must not do
in order to avoid or reduce the risk to yourself and other
people.
NOTICE
This is a warning. May cause damage to the vehicle or its
equipmentifthewarning is ignored.You areinformedwhat
you must or must not do in order to avoid or reduce the
risk of damage to your vehicle and its equipment.
WARNING
Indicates a strong possibility of severe personal injury or
death if the instructions are not followed.
IMPORTANTINFORMATIONABOUTTHISMANUAL

VALUE ADDED SERVICES
1
Dear Customer,
It is our never ending responsibility and endeavor to ensure that our customer’s expectations are fulfilled
comprehensively. To fulfill your vehicle service needs, we recommend the following :
1) Extended Warranty
2) Anti Rust / Sound Deadening / Engine waxing treatment
3) Vehicle detailing programming : Exterior Enrichment and Interior Enrichment Program
These products shall help maintain optimum vehicle performance and shall enhance vehicle life.
We have tied up with best in the Class companies, who would bring you the above world class products at
affordable prices. The above products are available with all our Dealers, TASCs and TASPs.
Our Dealer Service marketing executive shall explain to you the benefits of the above mentioned products.
INTRODUCTION

VALUE ADDED SERVICES
2
24x7ONROADASSISTANCE
Dear Customer,
Itisourresponsibilityandourendeavourtoensure that you
have our complete service backup if ever, wherever and
whenever you need the same. When you have a road
networkthat spanswidearea, theprobabilityofabreakdown
happening within hailing distance of a TATA MOTORS
Authorized Workshop is very low. It is Precisely for this
reason,we havetiedup withMyTVS,who willprovidebreak-
down assistance including towing to the nearest TATA
MOTORS Authorized Workshop through their Authorized
Service Providers (ASP)
The24X7OnRoad Assistance Programshall beautomati-
cally available to your vehicle for the duration of Warranty
period.Theprogramshallalsobeavailable, ifyouavailthe
samepostwarranty.
Response Time ** for the On Road Assistance Program
Within City Limits 60minutes
OnStateor National Highways 90 minutes
Ghat Roadsand otherplaces 120 minutes +/-
**(The response time will depend on the location, terrain,
traffic density and the time of the day.)
Standard procedure when calling for On Road
Assistance in case of a breakdown:
•Dial the toll free help line number – 1 800 209 7979
•Identify your vehicle with the Vehicle chassis number
thatisavailableintheOwners Service manual.
•Explain your exact location with landmarks and tell us
about the problem you face with the vehicle.
•Park your vehicle on the edge of the road, open the
bonnet and put on the hazard warning signal.
•Place the advance warning triangle supplied with the
vehicleapprox.3 m fromthevehiclein the directionofon
comingtraffic.

VALUE ADDED SERVICES
3
COVERAGEUNDER THE 24X 7 ONROADASSISTANCE
PROGRAM
I. The24x7On RoadAssistanceProgramService covers
the following services on your vehicle during warranty
period.
•Wheelchangethrough spare wheel.
•Arrangementoffuel.(Fuelcostwillbechargeableatactual
cost)
•Re-opening the vehicle in cases of key lock out.
•Rectificationofelectricalproblemsrelatedtobattery,fuses
etc.
•On spot repairs for complaints repairable at site.^
•Vehicle to vehicle towing or winching & towing for non
accident cases up to the nearest TATA MOTORS
authorized workshop. Towing charges at actual cost
beyond the same to be paid to the ASP in cash. (Any
ferryortollchargeslevied in relation to the vehicle being
towed to be paid by the customers in actuals in cash).
For accident cases, towing charges to be borne by the
costomer.
II. The 24x7 On Road Assistance Program coverage on
availingthe24X7policy,postwarranty,i.e. uptomaximum
of6instance ofassistanceinone year forboththe plans-
BasicandPremium.In the premium plan, thisincludes1
instance of towing upto the nearest TATA MOTORS
authorisedworkshop.
EXCLUSIONS
24x7 On Road Assistance Program does not apply to
•Cost of parts consumables and labour for such repairs
not covered under warranty*. These charges are to be
settled with ASP in cash.
•Toll or ferry charges paid by ASP in reaching to the
breakdownsitetobesettledwithASPin actuals incash.
•Cases involving accident, fire, theft, vandalism, riots,
lightening,earthquake,windstorm,hail,tsunami, unusual
weather conditions, other acts of God, flood, etc.
•Vehicles that are unattended, un-registered,
impoundedorabandoned.
•Breakdown/defects caused by misuse, abuse,
negligence, alterations or modifications made to the ve-
hicle.
•Lack of maintenance as per the maintenance
scheduleasdetailedin the owner’s manual.
24x7ONROADASSISTANCE

VALUE ADDED SERVICES
4
•Cases involving racing, rallies, vehicle testing or
practiceforsuchevents..
DISCLAIMER:
•Theserviceisnotavailableinthesomepartof J&Kand
in Union Territories of Andaman & Nicobar Islands and
Lakshwadeep.
•**Thereach time isindicative&theactual reach time will
be conveyed by the call centre at the time of breakdown
call.
•Thereach timecanvarydependingon thetraffic density
& time of the day.
•The reach time indicated does not account for delays
due to but not limited to acts of God, laws, rules &
regulations for time being in force, orders of statutory or
Govt.authorities,industrialdisputes, inclement weather,
heavydown pour,floods,storms, naturalcalamities,road
blocks due to accidents, general strife and law & order
conditionsviz.fire,arson,riots,strikes,terroristattacks,
war etc.
•^Onspotrepairsatbreakdownsiteshalldependonnature
of complaints & will be as per the discretion of theASP.
•*Thedecisionfor free of charge repairs willbeasperthe
warranty policy & procedures of TATA MOTORS LTD.
andasper the interpretationof thesamebyASP.Youwill
bedulyinformedbytheASP& callcentreforthechange
applicableifany.
•Allchargeswhereverapplicableneedtobesettleddirectly
with theASP.
24x7ONROADASSISTANCE

VALUE ADDED SERVICES
5
EXCLUSION OF LIABILITIES :
•It is understood that TATA MOTORS shall be under no
liabilitywhatsoeverinrespectofanylossor damage
arising directly or indirectly out of any delay in or non
deliveryof,defect/deficiency inservice/partsprovidedby
ASP.
•In case vehicle cannot be repaired on-site, customers
areadvisedtousethetowingfacilityfortakingtheirvehicle
tothe nearestTATAMOTORSauthorized workshoponly.
In no condition will the vehicle be towed to any
unauthorized workshop. TATA MOTORS will not be
responsible for any repairs carried out in such
unauthorizedworkshop.
•Customerareadvisedto take acknowledgment from the
ASP for the list of accessories/extra fittings and other
belongingsinthevehicle as well as thecurrentcondition
relatedtodents/scratches breakages ofparts/fitmentsof
the vehicle at the time of ASP taking possession of the
vehicle&toverify theseitemswhendeliveryistakenback
by them, Claim for loss of or damage to items, if any
should be taken up with ASP directly. TATA MOTORS
shall not be responsible for any such claims, damages/
loss or any deficiency of service of theASP.
24x7ONROADASSISTANCE
•Vehicles will be handled, repaired & towed as per the
customer’s risk & TATA MOTORS shall not be liable for
any damages / claims as a result of the same.
•Services entitled to the customers can be refused or
cancelled on account of abusive behaviour, fraudulent
representation, malicious intent and refusal to pay the
chargesforany chargesrelatedservices andspareparts
during service or on previous occasion on part of the
customer.
•On site repairs may be temporary in nature. The
completion of repairs does not certify the road
worthiness of the vehicle. The customer is advised to
ensure temporary repairs carried out onsite is followed
by permanent repairs at TATA MOTORS Authorized
Workshop at the earliest.
•Terms and conditions and service coverage,
exclusions etc. are subject to change without notice.

VALUE ADDED SERVICES
6
EXTENDED WARRANTY
TATAMOTORS recommends the purchase of Extended its warranty program.
Coverage : Mechanical + Electrical + Emission
Benifits:
•Insures you against unforeseen break down repair bills.
•Documentation is simple and hassle free.
•Near cashless & speedy claim settlement.
Term :
•36 + 12 or 150000 kms whichever occurs first
Extended Warranty available in the dealership from where you have
purchased your vehicle. We strongly recommend purchase of Extended
Warranty at time of purchase of your vehicle. Surcharge applicable on
purchaseof Extended Warrantyafter90 daysofpurchase of vehicle.Extended
Warranty can be availed till 421 days from date of purchase of vehicle.
The Dealer Service Marketing Executive shall explain to you the Terms and
conditions, Coverage and Owner’s responsibility.
Extended Warranty Booklet & Cover Note :
TheExtended Warranty bookletandcover noteis the basisof thecontractbetween TATAMOTORS LIMITED and theOwner of thevehicle
shown on the Extended Warranty booklet. The Customer to retain this booklet and the same to be produced to the dealer while claiming
benefits under Extended Warranty.

VALUE ADDED SERVICES
7
EXTENDED WARRANTY
I / We have been explained the Terms and conditions, Coverage and Owner’s responsibility by the Dealer Service Marketing
Executive.
I wish to avail / Do not wish to avail extended warranty policy.
Customer’s Sign Dealer’s Sign
Note:
•The 12 month extended warranty does not follow the 36 month Manufacturer's warranty.
•The extended warranty comes into force once the manufacturer’s warranty expires e.g. after 36 Months.
•It is more restrictive as by the time it comes into force the vehicle is already 36 months old.
What is covered ?
•Mechanical / Emission / Electrical break down as defined in this warranty and confirmed by the dealer within the stipulated
terms and conditions.
•Tata Motors dealer shall either repair or replace any part found to be defective with a new part or an equivalent at no cost to
the owner for parts or labour.
•Such defective parts which have been replaced will become property of TATA MOTORS LIMITED.
•Comprehensive list of parts covered is mentioned in the page 9-12 of the Extended Warranty Booklet.
What is not covered ?
Please refer the Extended Warranty Booklet for details of the exclusion list.
Owner’s Responsibility :
•Proper use, maintenance and care of the vehicle in accordance with the instructions contained in the Owner’s Manual and
Service Booklet. The records of the same to be ensured in Owner’s Manual.
•Retention of maintenance service bills.

VALUE ADDED SERVICES
8
ANTI-RUST, SOUNDDEADENING& ENGINEWAXING
Why are Corrosion Protection Waxes necessary?
Corrosionis caused by:
Water / salt water acid rain & atmospheric fallouts.
Criticalareas are:
Cavities:joints,crevices,spotwelds,underbody
•Corrosion is the most important factor when we talk about the vehicle life. If you treat your car you can prolongthe
life.
•Itisverydangerousto drive around in a corrodedcar.
•The corrosion creeps onto the car from the inside and from the outside. The most dangerous kind of corrosion is
often not discovered until it is too late.
BenefitsofAnti -Rust treatment:
•Aprofessionallyappliedrangeofworldclassproductsofferingrealvaluetothenew andusedcarcustomer.
•Thetreatmenthasbeendeveloped to withstand the harshest environmental andclimaticconditions(rust.
Pollutants, stone and gravel impact, etc)
•Insulatecabinspacefromexternalnoises.
•Expensivetinworkand Denting / Painting avoided.
•Higherresalevalue for thecar.
•Highersafety– uncorrodedvehicle
•Upto60monthswarranty&10 free checkups available

VALUE ADDED SERVICES
9
ANTI-RUST, SOUNDDEADENING& ENGINEWAXING
Engine Wax Treatment :
Engine Wax is a beige coloured transparent lacquer coating on the engine compartment.
•Corrosion Prevention for the Engine compartment
•Neat, clean and New Look to Engine compartment
•No effect on MPFI vehicles
•Engine wax can withstand upto 200 degrees temp
•No need of cleaning the engine compartment with diesel once engine wax is sprayed
•Life of over a year
Sound Deadening System :
Door vibration deadeners - These pads when stuck on the insides of the sheet metal increase sheet metal rigidity, reduce
vibrations and increase riding comfort.
•Used for reducing the sheet metal vibration in a vehicle.
•Product to be used once in the life of the vehicle - Life Time Warranty
•Effect is Life long i.e. until & unless pads are physically removed.
•Negligible increase in Weight & hence no effect on fuel consumption.
•Areas covered - four doors, rear quarter panels & dicky. In case of diesel vehicles, can be used in the bonnet.
TATA MOTORS has tied up with M/s Wuerth , M/s Autokrom, M/s 3M India Ltd & M/s Bardahl for these world class
treatment at affordable prices. These treatments are available in all authorized workshops. The Dealer Service Marketing
Executive will explain to you the benefits and terms and conditions of this treatment.
I / We have been explained the Benefits, Terms and conditions and the prices of these treatments by the Dealer Service Marketing
Executive
I wish to avail / Do not wish to avail these treatment
Customer Signature Dealer Signature

VALUE ADDED SERVICES
10
Vehicle Exterior Enrichment :
Why vehicles are painted?
•ForCorrosionprotectionofthemetal surfaces.
•Easeofapplicationfromothercorrosion protection treatments.
•Cheaperthanother corrosion protectionmethodseg.galvanizing,anodizing.
•Fordecorationand identification.
Various Environmental Hazards affecting paints :
•Environmentalhazards:destroy your vehicle'sfinish.
•Even as your new vehicle rolls off the assembly line, the paint is not protected.
The enemy :
Ultraviolet Rays, Pollution, Tree Sap, Bird Droppings, Car Wash Chemicals, Road Salt,Acid Rain.
Benefits:Vehicle Exterior Enrichment
•Removal of medium scratches, orange peel, oxidation , dust nibs etc & swirl marks from painted surface.
•RestorationoforiginalglosslevelsUVprotectionafterglossisrestored.
•Cleaning & dressing of tyres, Bumpers & all exterior plastic moldings/trims.
Tata Motors has tied up with M/sAutokrom, M/s 3M & M/s Wuerth for this world class treatment at affordable prices. This
treatmentisavailablein all authorized workshops. TheDealerServiceMarketingExecutive will explain to youthebenefitsand
terms and conditions of this treatment.
EXTERIOR&INTERIORENRICHMENTPROGRAM
