TATA Motors Safari 2021 User manual

Revision: Rev 01/AUG 2021
OWNER’S MANUAL

ii
CUSTOMER ASSISTANCE
In our constant endeavour to provide assistance and complete
service backup, TATA MOTORS has established an all India cus-
tomer assistance centre.
In case you have a query regarding any aspect of your vehicle,
our Customer Assistance Centre will be glad to assist you on our
Toll Free no. 1800 209 8282
You can also approach nearest TATA MOTORS dealer.
A separate Dealer network address booklet is provided with the
Owner’s manual.
TATA MOTORS 24X7 Roadside Assistance Program offers tech-
nical help in the event of a breakdown. Call the toll-free Road-
side Assistance.
For additional information, refer to "24X7 Roadside Assis-
tance" section in the Owner’s manual.

FOREWORD
iii
Dear Customer,
Welcome to the TATA MOTORS family.
We congratulate you on the purchase of your new vehicle and are privileged to have you as our valued customer.
We urge you to read this Owner's Manual carefully and familiarize yourself with the equipment descriptions and operating instructions
before driving.
Always carry out prescribed service / maintenance work as well as any required repairs at an authorized TATA MOTORS Dealers or
Authorized Service Centre’s (TASCs). Use only genuine parts for continued reliability, safety and performance of your vehicle.
You are welcome to contact our dealer or Customer Assistance toll free no. (1800 209 8282) in case of any query or support required.
We wish you a safe and pleasant driving experience.

iv
IMPORTANT INFORMATION
•
Before driving, read this Owner’smanualcarefullyandfamiliarizeyourselfwithyourvehicle.For yourownsafetyand a longer
ve-hicle life, follow the instructions,‘Warnings’and‘Notes’ in this manual. Ignoringthemcouldresultin damage to the or
personal injury to you or others.
•The Owner’s manual and other booklets areimportant documentsandshould always be kept inthe vehicle. If you sellthe
vehicle, always pass on the documents to the new owner.
•This Owner's Manual describes all variants of the model andall standard/optional equipment of your vehicle available at the time
of printing. Please note that your vehicle may not be equipped with all features described.
•TATA MOTORS PASSENGER VEHICLE LIMITED reserves the right to introduce changes inthe design, equipment and
technical features without any obligation to install them on the vehicles previously sold. The equipment in your vehicle may
therefore differ from that shown in the descriptions and illustrations.
•Do not carry out any modification including fitment of non-genuine accessories on your vehicle. Safety, handling, performance and
durability, may otherwise be adverselyaffected and may violate governmentregulations. TATA MOTORS PASSENGER
VEHICLE LIMITED no liability for damage resulting from the modifications or use of non-genuine accessories.
•All rights reserved. The information in this manual shall not be copied, translated or otherwise reproduced,in whole or inpart
without written permission from TATA MOTORS.
Copyright 2021TATA MOTORS

01. SAFETY
Important Information 1
Seat Belts 4
Child Restraint System (CRS) 8
Supplementary Restraint System (SRS -
Airbags) (if equipped) 12
Child Lock (if equipped) 18
Anti-theft Device Immobilizer / PEPS 20
Anti-lock Braking System (ABS) (if equipped) 21
Electronic Brake Force Distribution (EBD) 22
Additional Safety Features (as available) 22
02. OPENING AND CLOSING
Keys (as available) 25
Smart Key (PEPS) 27
Smart Key Features 29
Flip Key 30
Flip Key Features 31
Door 32
Windows 33
Bonnet 35
Tailgate Opening (as available) 37
Fuel Lid 39
Power Sunroof (if available) 40
03. DASHBOARD AND FEATURES
Cockpit 47
Instrument Cluster (TFT Screen) 48
Instrument Cluster (LCD Screen) 70
Tell Tales 83
Audio Reminders (if available) 92
Combi-switch (RH Stalk) 93
Combi-switch (LH Stalk) 95
Fascia Switches 96
Steering Wheel Switches (LHS) (if available) 97
Steering Wheel Switches (RHS) (if available) 98
Mic (if available) 99
Infotainment System Display (if available) 99
Speakers & Tweeter (if available) 101
USB Charger (if available) 101
CONTENTS
v

vi
Power Socket 102
Antenna (if available) 103
Shark Fin Antenna (if available) 103
Roof Grab Handle (if available) 104
Front Fog Lamps (if available) 104
Rear Fog Lamps (if available) 105
Puddle / Ajar Lamp 105
Roof Lamp 105
Boot Lamp 107
Side Indicator Lamp On Orvm 107
Front Lamp 108
Tail Lamp 108
Ambient Lights (if available) 109
iRA (iNtelligent Real-time Assist) Connected
Car Service 109
Wireless Power Charging 110
04. STOWAGE AREAS
Storage Compartment 119
05. CLIMATE CONTROL
Air Distribution 125
Air Vents 126
HVAC Controls (if available)
127
Fully Automatic Temperature Control (FATC) (if
available) 132
Cabin Air Purification 139
06. STARTING AND DRIVING
Pre Driving Checks 141
Driving Tips 142
Seat Adjustments 145
Rear View Mirrors 157
Sun Visors 159
Steering Wheel Adjustment (if available) 159
Steering Lock And Ignition Switch (if available) 160
Starting And Stopping (without PEPS) 161
Starting And Stopping (PEPS) (if available) 171
Engine Passive Start - Conditions 172
Engine Passive Stop - Conditions 173
CONTENTS

Manual Transmission (MT) 173
Driving 176
Stopping The Vehicle 177
Braking 177
Parking Brake 178
Automatic Vehicle Hold (if equipped) 184
Reverse Park Assist (if available) 186
Rear Park Assist With Camera (if available) 191
Drive Mode (if available) 197
Terrain Response Mode (if available) 198
07. EMERGENCY AND BREAKDOWN ASSISTANCE
Emergency Equipment 201
Spare Wheel Removal Process 203
In Case Of Flat Tyre 205
Puncture Repair Kit (if available) 208
Jump Lead Starting 215
Towing 216
Fuses 219
Bulb Specification 229
24 X 7 Road Assistance 231
08. MAINTENANCE AND SERVICES
Maintenance And Service 235
Engine Compartment 236
Tyres 242
Remote Key Battery Replacement (for Flip key) 245
Smart Key Battery Replacement (for PEPS vari-
ant) 246
On Board Diagnostic (OBD II) System 247
Diesel Particulate Filter (DPF) 248
Exhaust After Treatment System 249
Regeneration Process 250
Diesel Exhaust Fluid (DEF) 251
Service Instructions 256
Service Schedule 257
Vehicle Parking For Long Duration 264
09. TECHNICAL INFORMATION
Fuel Specification 265
CONTENTS
vii

viii
Lubricant Specification 266
Technical Specifications 267
Vehicle Dimensions 271
Aggregate Identification Numbers 272
10. CAR CARE
Car Care 273
Fast Tag 275
Value Care - AMC 276
Extended Warranty 280
Value Added Services 282
Vehicle Exterior Enrichment 284
Vehicle Interior Enrichment 285
11. WARRANTY - TERMS AND CONDITIONS
Vehicle Warranty: Terms And Conditions 287
12. ENVIRONMENT SAFETY
Environmental Safety 289
CONTENTS

IMPORTANT INFORMATION
In this Owner’s Manual, you will find the
text under the heading “WARNING” and
“NOTE” which highlights important infor-
mation. Pay particular attention to these
highlighted messages.
Safe Driving
Safety consciousness not only ensures
your safety and the safety of other road
users, but it also helps to reduce the wear
and tear on your vehicle.
Safe driving depends on:
How quickly you make decisions to•
avoid an accident.
Your ability to concentrate.•
How well you can see and judge ob-•
jects.
How well familiar you are with your ve-•
hicle controls and its capabilities.
Safety Tips
Always take into account the road con-•
ditions, weather conditions, vehicle
speed in order to prevent accidents.
Turn ‘ON’ the side indicators at least•
30 meters before taking a turn or
changing the lane.
Decelerate to a safe speed before tak-•
ing turn. Do not apply brakes during
cornering.
When overtaking other vehicles, watch•
out for the oncoming vehicle.
Never drive under the influence of al-•
cohol or drugs.
If your vehicle is equipped with info-•
tainment/navigation system, set and
make changes to your travel route only
when the vehicle is parked.
Program radio presets with the vehicle•
parked, and use your programmed
presets to make radio use quicker and
simpler.
NOTE
Indicates additional information that will
assist you in gaining the optimum ben-
efit and care for your vehicle.
WARNING
Indicates procedures or information that
must be followed precisely in order to
avoid the possibility of severe personal
injury and serious damage to the vehi-
cle.
NOTE
Fatigue is a result of physical or mental
exertion that impairs judgment. Driver
fatigue may be due to inadequate
sleep, extended work hours, strenuous
work or non-work activities or combina-
tion of other factors. Take rest at regular
intervals.
SAFETY
1

2
Driving Through Water
Do not drive through flooded areas. Judge
the depth of water before driving through
it. Otherwise, water may enter the vehicle
interior or the engine compartment.
If at all the situation demands that you
have to drive through water then;
Keep engine in higher RPM and crawl•
the vehicle in low gear.
Flowing or rushing water creates•
strong forces. Driving through flowing
water could cause the vehicle to about
trying to drive through flowing water.
Lightly apply the brake pedal to dry the•
liners until the brakes work normally
once you are out of water.
Driving on a Rainy Day
Check wiper blades, lights and brakes•
for proper functioning and condition.
Check the tyre treads depth, the con-•
dition of the tread and tyre.
Avoid harsh braking and sharp turns. It•
may cause loss of control and lead to
a skid.
For slowing down, shift to lower gears•
and brake gently.
Keep lights ‘ON’ if visibility is poor.•
Driving on Wet Roads
On wet road or during light showers,
“Aquaplaning” can occur. “Aquaplaning” is
the loss of direct contact between the road
surface and the vehicle’s tires due to a
water film forming between them. Steering
or braking the vehicle can be very difficult,
and loss of control can occur.
There is no hard and fast rule about aqua-
planing. The best advice is to slow down
when the road is wet.
Driving on Snowy Roads
While driving in snow, it is advisable to use
the snow chain on roads. Follow assembly
and safety instruction provided by the
snow chain manufacturers.
WARNING
Do not attempt to start the engine if ve-
hicle gets flooded due to water. Tow the
vehicle to a safe place. Contact a near-
est TATA MOTORS Authorised Service
Centre
NOTE
If you have driven for a long time in
heavy rain without braking, there may
be a delayed reaction from the brakes
when braking for the first time. You have
to press the brake pedal more firmly.
Maintain a greater distance from the ve-
hicle in front.
SAFETY

Night Driving
Ensure that all lights are working and•
windshield, window glasses are clean.
Drive more slowly at night than in the•
daytime, as the visual range is re-
stricted at night. Maintain a speed such
that you can stop within illuminated
distance of head lamps.
Do not use the high beam unless in-•
evitable. It may dazzle the driver of the
oncoming vehicle, thus causing an ac-
cident.
Use head lamp main/dip beam to alert•
other road users on turns/ cross roads
etc.
Use side indicators for lane change or•
turning.
Driving on Gradients
When climbing gradient, the vehicle may
begin to slow down and show a lack of
power. If this happens, shift to a lower gear
and apply power smoothly so that there is
no loss of traction.
When driving down a hill, the engine brak-
ing should be used by shifting into a lower
gear. Do not drive in neutral gear or switch
off the engine.
Driving on Highway
Stopping distance progressively, in-
creases with vehicle speed. Maintain a
sufficient distance between your vehicle
and the vehicle ahead.
For long distance driving, perform safety
checks before starting a trip and take rest
at certain intervals to prevent fatigue.
WARNING
On long and steep gradients you must
reduce the load on the brakes by shift-
ing early to a lower gear. This allows
you to take advantage of the engine
braking effect and helps avoid over-
heating of service brakes resulting in re-
duced braking efficiency.
SAFETY
3

4
SEAT BELTS
This section of user manual describes
your vehicle seat belt, airbag and Child re-
straints system. Please read and follow all
these instructions carefully to minimize risk
of severe injury or death.
Seat belts are the primary restraints•
system in the vehicle. All occupants,
including the driver, should always
wear their seat belts to minimize the
risk of injury.
Sit back and adjust (if equipped), the•
seat. Make sure that your seat is ad-
justed to a good driving position and
the back of the seat is upright.
Buckling the Shoulder Seat Belt
Grasp the tongue then slowly pull out•
the seat belt over the shoulder and
across the chest. When the seat belt is
long enough to fit, insert the tongue
into the lock buckle until you hear a
“CLICK” which indicates that the seat
belt is securely locked.
Position the lap portion of seat belt•
across your thighs, below your ab-
domen. To remove slack, pull up a bit
on the shoulder seat belt. To loosen
the lap portion seat belt if it is too tight,
tilt the tongue and pull on the lap seat
belt. A snug seat belt reduces the risk
of sliding under the seat belt in a colli-
sion. Ensure that the seat belt running
over the body (shoulder segment and
lap segment) does not have any twist.
Twisted seat belt may not offer effec-
tive protection when required.
Releasing the Seat Belt
To release the seat belt, push the red but-
ton on the lock buckle. The seat belt will
automatically retract to its stowed position.
If necessary, slide the tongue down the
webbing to allow the seat belt to retract
fully.
NOTE
The above image is for reference pur-
pose only.
SAFETY

Fixed Rear Centre Lap Seat Belt
When buckling, make sure you hear a
click confirming that the tab is latched into
the seat belt lock. To tighten it, pull the
loose end through the buckle until the seat
belt is comfortably adjusted around the
pelvic bone (hips).
Seat Belts with Pre - Tensioner (if
equipped)
You can use pre-tensioner seat belts in the
same manner as ordinary seat belts.
The seat belt pre-tensioner system works
in conjunction with the SUPPLEMENTARY
RESTRAINTS SYSTEM (SRS-Airbags).
In the event of a collision, as may be nec-
essary, pre-tensioner tightens the seat belt
so that it fits the occupant’s body more
snugly. When pre-tensioner activates,
there could be some noise and release of
smoke. This is normal and there are no
health hazards or fire risk.
If the vehicle has been involved in a colli-
sion, get it inspected immediately at au-
thorized TATA MOTORS SERVICE
Center.
WARNING
Each seating position and seat belt•
assembly must be used by one oc-
cupant. It is not recommended to
put a seat belt around a child, being
carried on an occupant’s lap.
Be careful not to damage or tamper•
the seat belt webbing or hardware.
Inspect the seat belt system period-
ically, checking for cuts, frays, or
loose parts. A frayed or torn seat
belt could rip apart in a collision and
leave you with no protection.
If the seat belt webbing or hardware•
is damaged, get it replaced immedi-
ately at TATA Motors Authorized
service centre.
Do not insert any items such as•
coins, clips, etc. into the seat belt
buckles, and be careful not to spill
liquids into these parts. If foreign
materials get into a seat belt buckle,
the seat belt will not work properly.
Do not wear seat belts over hard,•
sharp or fragile items in clothing,
such as pens, keys, spectacles etc.
Do not use any accessories on seat•
belts or modify in any way the seat
belt system. Devices claiming to im-
prove occupant comfort or reposi-
tioning the seat belt, can reduce the
protection provided by the seat belt
and increase the chance of serious
injury in a collision.
WARNING
In a collision, the pre-tensioner seat belt
assembly mechanisms become hot dur-
ing activation. Do not touch the pre-ten-
sioner seat belt assemblies for several
minutes after they have been activated.
SAFETY
5

6
Seat Belt with Load Limiter (if
equipped)
You can use the load limiter seat belts in
the same manner as ordinary seat belts.
The seat belt load limiter system works in
conjunction with the SUPPLEMEN-TARY
RESTRAINTS SYSTEM (SRS-Airbags).
In the event of a collision, as may be nec-
essary, load limiter reduces the load on the
rib cage region of the occupant.
If the vehicle has been involved in a colli-
sion, get it inspected immediately at Au-
thorized TATA MOTORS SERVICE
Center.
Use of Seat Belts for Pregnant
Woman
WARNING
Pregnant woman must wear a cor-•
rectly positioned seat belt. It is safer
for mother as well as unborn child.
Pregnant woman should wear the•
lap part of the seat belt across the
pelvic bone (hips) and as snug
across the hips as possible. Keep
the seat belt low so that it does not
come across the abdomen. That
way the strong bones of the hips will
take the force if there is a collision.
SAFETY

Seat Belt Warning Lamp
For Driver For Front
Passenger
The seat belt warning lamp reminds you to
fasten the seat belt.
If the driver does not fasten seat belt,•
seat belt reminder lamp will blink and
a buzzer will sound for pre-defined du-
ration until the driver’s seat belt is
buckled.
If front passenger seat is occupied by•
adult and does not fasten seat belt,
seat belt reminder lamp will blink and
a buzzer will sound for pre-defined du-
ration until the front passenger seat
belt is buckled.
If this system is also provided for other•
than Front row seats, applicable above
warnings will appear until seat belts
are buckled.
If front passenger seat is occupied by•
child, system may detect occupancy
and warn with front passenger seat
belt warning. It is not taken to mean
child can occupy front passenger seat
and use seat belt. Please refer CRS
section for recommended seating po-
sition.
NOTE
Using unauthorized after-market seat
cover may affect function of occupant
sensor. TATA motors does not recom-
mend any non-validated seat covers on
seats.
SAFETY
7

8
CHILD RESTRAINT SYSTEM (CRS)
TATA MOTORS strongly recommends the
use of Child Restraint Systems (CRS) for
all children up to age of 12 years and to be
placed at recom-mended positions only.
Children travel-ling without recommended
CRS and seated at other positions may
face serious injuries in case of a collision.
CRS can be installed in the vehicle using
seat belts and/or ISOFIX only (if equipped)
or ISOFIX with Top Tether (if equipped).
The harness system of CRS holds the
child in place, and in a collision, acts to
keep the child positioned in the seat and
reduce the risk of injuries.
All children below age of one year must al-
ways ride in a rear-facing infant CRS.
Keep children above age of one year, in a
forward-facing CRS with a harness until
they reach the size or weight limit allowed
by your CRS manufacturer.
Once your child outgrows the forward-fac-
ing CRS, your child is ready for a booster
seat.
Selection and Installation of CRS
Always select the CRS that complies with
latest safety standards (AIS072 / ECE
R44). The CRS are classified according to
the child’s size, height and weight. Select
the appropriate CRS for your child. Ensure
that the child fits properly in the CRS and
it is securely installed in the vehicle. For
installation, please refer CRS manufac-
turer’s instruction manual.
NOTE
The above images are for reference
purpose only.
SAFETY

Recommended CRS Position as Per
the Vehicle Matrix
The suitability of seat position for carriage
of children and recommended category of
CRS is shown in the table below as per the
child group.
X - Seat Position not suitable for children
in this age group.
U - Suitable for “universal” category re-
straints approved for use in this age group.
Universal is a category in the AIS072 /
ECE R44 norm
WARNING
If a child is seated in the front seat it
may cause serious injury or even death
during any collision.
SAFETY
9
Group Mass
Group Age Group
Front
Pas-
sen-
ger
Rear
Out-
board
(rh/lh)
Rear
Cen-
ter
Interme-
diate Out-
board
Second
Row
Lh/rh
Inter-
medi-
ate
Centre
0Up to 10
kg
Up to 9
months X X X U NA
0+ Up to 13
kg
Up to 24
months X X X U NA
I 9 tp 18 kg 9 months to
48 months X X X U NA
II 15 to 25 kg Approx. 3 to 7
years X X X U NA
III 22 to 36 kg Approx. 6 to
12 years X X X U NA

10
If you install a CRS in the rear seat, slide
the front seat far enough forward so that
the child’s feet do not touch the front seat-
back. This will help avoid injury to the child
in the event of a collision.
After a collision, we recommend to get
seat belts, seats, ISOFIX and top-tether
anchorages (as may be applicable) inves-
tigated at TATA MOTORS Authorized serv-
ice center.
WARNING
If your vehicle is equipped with a front
passenger airbag (PAB) and does not
have PAB deactivation switch, do not in-
stall a rear-facing CRS in the front pas-
senger seat. If the PAB inflates, a child
in a rear facing CRS could be seriously
injured or killed.
NOTE
Children could be endangered in a col-
lision if their CRS is not properly se-
cured in the vehicle. Be sure to secure
the child in the restraint system accord-
ing to the manufacturer’s instructions.
WARNING
Do not use an infant carrier or a child
safety seat that “hooks” over a seat
back, it will not provide adequate pro-
tection in a collision.
NOTE
A CRS in a closed vehicle can become
very hot. To prevent burns, check the
seating surface and buckles before
placing your child in CRS.
WARNING
Do not leave unattended children in•
your vehicle.
Do not modify CRS in any way.•
NOTE
Do not install a booster seat or a•
booster cushion with only the lap
strap of the seat belt.
Do not install a booster seat or a•
booster cushion with a seat belt that
is slack or twisted.
Do not put the safety seat belt under•
your child’s arm or behind its back.
Do not use pillows, books or towels•
to boost your child’s height.
Make sure that your children sit in•
an upright position.
Do not allow children to stand up or•
kneel on either the rear or the front
seats. An unrestrained child could
suffer serious or fatal injuries during
a collision.
Do not leave any toys or other ob-•
jects loose in the CRS or on the seat
while the vehicle is in motion.
SAFETY

Each CRS should be used for one child
only.
When PAB deactivation switch (if pro-
vided) is turned ‘OFF’, make sure ‘PAB’
operational status lamp illuminates with ig-
nition ‘ON’, indicating that the passenger
airbag is NOT operational. If the airbag
SRS warning indicator in the instrument
cluster illuminates continuously, it means
that there is malfunction in the system. Re-
move the CRS from front passenger seat
and contact your TATA MOTORS author-
ized service center.
NOTE
The above images are for reference
purpose only.
SAFETY
11

12
SUPPLEMENTARY RESTRAINT
SYSTEM (SRS - Airbags) (if
equipped)
The airbag ‘SRS’ system comprises of the
following components depending upon the
provided safety features in vehicle.
Seat belt Pre-tensioners•
Seat belt with load limiters•
Driver Airbag•
Front Passenger Airbag•
Side Airbags (if equipped)•
Curtain Airbag (if equipped)•
Airbag ‘SRS’ ECU (Electronic Control•
Unit)
Collision Sensors•
SRS wiring harness•
SRS Warning lamp•
The System is active when ignition switch
is in the “ON” position or the ignition mode
is “ON”. Airbags are designed to inflate in
severe collisions. In the event of a colli-
sion, the collision sensors will detect sig-
nals, and if the Airbag ECU judges that the
signals represent a severe collision, will
trigger the airbags. The inflated Airbags
provide a cushion to the occupants. The
Airbag inflates and deflates so quickly that
you may not even realize that it has acti-
vated. The Airbag will neither hinder your
view nor make it hurdle to exit the vehicle.
Airbag inflation is virtually instantaneous
and occurs with considerable force, ac-
companied by loud noise and smoke,
which is normal. The inflated airbag, to-
gether with seat belts, limit the movement
of an occupant, thereby reducing the risk
of injury.
When an airbag inflates, you may see
some smoke-like particles. The particles
are a normal by-product of the process
that generates the non-toxic gas used for
airbag inflation. These airborne particles
may irritate the skin, eyes, nose, or throat.
If you have skin or eye irritation, rinse the
area with water. For nose or throat irrita-
tion, move to fresh air. Also sometimes the
smoke can cause breathing problems, in
such cases get fresh air promptly.
After inflation, airbag provides a gradual
cushioning effect for the occupant there-
after deflates. It is not advisable to drive
your vehicle after the airbags have been
deployed. If you are involved in another
collision, the airbags will not be in place to
protect you.
NOTE
The above images are for reference
purpose only.
SAFETY
