TATA Motors nano genX User manual

11
TATA
TATA
TATT
TT
TAA
AA
A
Owner's Manual
This owner’s manual should be considered as a permanent part
of the vehicle and must remain with the vehicle.
Passenger Vehicle Business Unit (PVBU)
Mumbai Pune

2
Please read this Owner’s Manual carefully before you start driving your car
and always keep it safe in the car.
••
••
•The recommended routine maintenance servicing along with any
running repairs that may be required, should be entrusted to TATA
MOTORSAuthorised Service Centre to ensure that only latest methods
and genuine TATA MOTORS replacement parts are used for the
continued reliability, safety and performance of the vehicle.
••
••
•Some of the items / accessories / features shown / given in this book
may not be fitted on your vehicle, these may be applicable for other
versions of TATANANO.
••
••
•(C) Copyright 2014 TATA MOTORS
••
••
•All rights reserved. The material in this manual shall not be reproduced
or copied, in whole or in part, in any form without written permission
fromTATAMOTORS.
••
••
•The information and specifications given in this book are valid as on
the date of printing. TATA MOTORS LIMITED reserves the right to
make changes in design and specifications and/or to make additions
to or improvements in this product without obligation to install them on
products previously sold.
••
••
•In the event of the Vehicle being sold, please ensure that this manual
is left in the vehicle for the reference of the new owner.
01.Owner’s Manual & Service
Book
02.First Aid Kit
03.Advance Warning Triangle
04.Jack & Wheel Spanner
05.Tow Hook
06.Spare Fuses
07.Pre-delivery Inspection and
Service
08.Complimentary fuel infueltank
09. Battery Warranty Card.
While taking delivery of your new car, you are priviledged to have the
following :
NOTE

33
Dear Customer,
Thank you for selecting TATA NANO the most exciting car.
We welcome you to the world of advanced automotive engineering marvel
suited to your operating conditions.
This book gives you all the information necessary for making your ownership
of this car a delighting experience and help you in all situations.
To assist you in maintaining your car as per recommended service schedule,
we have a widespread network of dealers and service centres. Kindly refer
Service Network booklet provided alongwith the Owner’s Manual.
Please do not hesitate to call on our Regional / Area offices in case you
need any special assistance.
Please note that by adhering to the correct operating procedures and by
availing the scheduled maintenance services at our authorised service
centres, you can obtain the maximum performance from your car.
We request you to go through this book and derive many miles of motoring
pleasure.
We wish you Safe and Pleasant Motoring
FOREWORD

4
SAFETY SYMBOL
In this manual, you will
also see a circle with a
slash. This means "Do
not", "Do not do this", or
"Do not let this happen".
SAFETY SYMBOLS
In this manual, you will find
‘CAUTION’, ‘NOTE’, ‘WARNING’
messages and ‘safety symbol’ at
appropriateplaces.The significance
of these messages are explained
below. CAUTION
This is a warning which may
cause injury to people if it is
ignored. You are informed what
you must or must not do in order
to avoid or reduce the risk to
yourself and other people.
NOTE
This is a warning which may
cause damage to the car or its
equipment if it is ignored. You are
informed what you must or must
not do in order to avoid or reduce
theriskof damage toyourcarand
its equipment.
WARNING
Indicates a strong possibility of
severe personal injury or death if
the instructions are not followed.
CUSTOMER ASSISTANCE

55
NOTE 02
FOREWORD 03
CUSTOMER ASSISTANCE 04
WARRANTY
Warranty - Terms & Conditions 07
ENVIRONMENT PROTECTION 09
24X7 ON ROAD ASSISTANCE 11
KNOW YOUR NANO 15
AN OVERVIEW
Driving Controls 17
Instrument Cluster 19
Gauges & Indicators 21
On Board Diagnostic System 33
Steering Lock cum Ignition Switch 34
Combination Switch 35
Music System & Antenna 39
Heating, Ventilation & Air Conditioning 40
Lamps 44
Rear View Mirrors & Sun visor 46
Vanity Mirror,Grab Handle,Utility pocket/ 47
box
Cup holder, Window Winding & Power 48
Socket
Parking Brake,Gear Shift Lever & 50
Glove Box
Front Hood - Opening & Closing 52
Refuelling 53
GETTING STARTED
Remote Keyless Entry 54
Door Locks 57
Front Seat & Seat Adjustment 59
Rear Seat & Seat Folding 60
Seat Belts & Child Restraint System 61
DRIVING
Before Driving & Safety Checks 66
Safety Checks & Driving Safety 68
Fuel Economy 69
Starting, Gear Shifting, Stopping & 71
Parking
Driving In Adverse Conditions 78
IN CASE OF EMERGENCY
Advance Warning Triangle 80
Hazard Warning Switch
If you have Flat tyre 81
Starting The Engine with Jump Leads 84
Towing the Vehicle 85
Routine Service 87
Preliminary Trouble shooting 88
ELECTRICALMAINTENANCE
Fuses & Relays 93
Bulb Specification 96
Accessory Connectors Details 97
VEHICLECARE
Car Care 99
MAINTENANCE
Brake Fluid Level 102
Windshield Washer Fluid Level 103
Engine Access Cover 103
Engine Oil Level 104
Engine Coolant Level 105
Air Filter & Spark Plug 106
Tyre 107
Wheel Alignment & Catalytic converter 109
Battery 110
IMPORTANT TECHNICAL
INFORMATION
Fuel, Lubricants & Coolants 111
Oil Filling & Drain Points 113
Technical Specification 114
Dimensions 117
CAR IDENTIFICATION
Location of Aggregate Number 118
SERVICE MAINTENANCE
SCHEDULE 119
MUSIC SYSTEM
OPERATOR’S MANUAL 121
RECORD OF SERVICES
PERFORMED 148
RECORD OF REPAIRS
CARRIED OUT 150
CONTENTS

6
CONTENTS

77
We WARRANT each TATA NANO
and parts there of manufactured by
us to be free from defect in material
and workmanship subject to the
following terms and conditions :
1. This warranty shallbe for 4Years
or 60,000 kms, whichever
occurs earlier from the date of
sale of the car.
2. Our obligation under this
warranty shall be limited to
repairing or replacing free of
charge, such parts of the car
which, in our opinion, are
contributing to improper
operation, on the car being
brought to us or to our dealers
within the period. The parts so
repaired or replaced shall also
be warranted for quality and
workmanship but such warranty
shall be co-terminus with this
original warranty.
3. Any part which is replaced by us
under the warranty shall be our
property.
4. As for parts like tyres, battery,
electrical equipment, fuel
injection equipment etc. not
manufactured by us but supplied
by other OE Manufacturers, this
warranty shall not apply. Buyers
of the car shall be entitled to, so
faraspermissibleby law, all such
rights as we may have against
such parties under their
warranties in respect of such
parts.
5. This warranty shall not apply if
the car or any part thereof is
repaired or altered otherwise
than in accordance with our
standard repair procedure or by
any person other than from our
sales or service establishments,
our authorized dealers, service
centers or service points in any
waysoas,inourjudgmentwhich
shallbefinal andbinding,to affect
its reliability, nor shall it apply if,
inouropinionwhichshallbefinal
and binding the car is subjected
to misuse, negligence, improper
or inadequate maintenance or
accident or loading in excess of
suchcarrying capacityas certified
by us, or such services as
prescribedin ourOwner’sManual
and Service Book are not carried
out by the buyer through our
sales or service establishments,
ourAuthorized Dealers, Service
Centers or Service points.
6. This warranty shall not cover
normal wear and tear or any
inherent normal deterioration of
the car or any of its parts arising
from the actual use of the car or
any damage due to negligent or
improper operation or storage of
the car. This warranty shall not
apply to normal maintenance
services like oils and fluid
changes, head lamp focusing,
fastener retightening, wheel
balancing, tyre rotation,
adjustment of valve clearance,
fuel timing, ignition timing and
consumables like bulbs, fuel
WARRANTY - TERMS & CONDITIONS

8
WARRANTY - TERMS & CONDITIONS
filters and oil filters etc. This
warranty shall not apply to any
damage or deterioration caused
byenvironmental pollution or bird
droppings.Thiswarrantyshallnot
apply to V-belts, hoses and gas
leaks (in case of air conditioned
cars) & slight irregularities not
recognized as affecting the
function or quality of the vehicle
or parts such as slight noise or
vibration and defects appearing
only under particular or irregular
operations or items considered
characteristic of the vehicle.
7. This warranty shall be null and
void if the vehicle is subjected
toabnormalusesuchasrallying,
racingorparticipationinany other
competitivesports.Thiswarranty
shall not apply to any repairs or
replacement as a result of
accident or collision.
8. This warranty is expressly in lieu
of all warranties, whether by law
or otherwise, expressed or
implied and all other obligations
or liabilities on our part and we
neitherassumenor authorizeany
person to assume on our behalf,
anyotherliabilityarisingfromthe
sale of the vehicle or any
agreement in relation thereto.
9. The buyer should have no other
rightsexcept those set out above
and have, in particular, no right
to repudiate the sale, or any
agreement or to claim any
reduction in the purchase price
of the vehicle, or to demand any
damages or compensation for
losses, incidental or indirect, or
inconvenience or consequential
damages, loss of vehicle, or loss
of time, or otherwise, incurred or
accrued.
10. Any claim arising from this
warrantyshallbe recognized only
if it is noticed in writing to us or
to our concerned Dealer without
any delay soon after such defect
as covered and ascertained
under this warranty.
11. This warranty shall stand
terminated if the vehicle is
transferredorotherwise alienated
by the buyer without our prior
written consent.
12. We reserve our rights to make
anychangeormodificationinthe
design of the vehicle or its parts
or to introduce any improvement
therein or to incorporate in the
vehicle any additional part or
accessory at any time without
incurring any obligation to
incorporate the same in the
vehicles previously sold.

99
TATA MOTORS LTD. is committed
to produce vehicles using
environmentally sustainable
technology. Many features have
been incorporated in Tata Motors
passenger vehicles which have
been designed to ensure
environmental compatibility
throughout the life cycle of the
vehicle. We would like to inform
you that your car meets emission
norms and this is being regularly
validated at the manufacturing
stages.
As a user you too can protect the
environment by operating your car
in a proactive manner. A lot
depends on your driving style and
the way you maintain your car. We
have given a few tips for your
guidance.
DRIVING
•Avoid frequent and violent
accelerations / rev-ups.
•Avoid overloading of the engine.
Avoid using devices requiring
high power consumption during
slow city traffic condition.
•Monitor the car’s fuel
consumption regularly and if
showing rising trend get the
car immediately attended at the
TATA MOTORS Authorised
Service Centre.
•Switch off the engine during
long stops at traffic jams or
signals. If you need to keep the
engine running, do not
unnecessarily rev-up.Avoid
stopping and starting.
•Do not rev-up the engine before
turning it off as it unnecessarily
burns the fuel.
•Shift to higher gears as soon
as it is possible without
overloading the engine. Use
each gear upto 2/3rd of it’s
maximum engine speed. A
chart indicating gear shifting
speeds is given in this book.
MAINTENANCE
•Ensure that recommended
maintenance is carried out on
the car regularly at the TATA
MOTORS Authorized Workshop.
•As soon as you see any
leakages of oil, fuel or coolant
in the car we recommend to get
it attended immediately.
•Use only recommended
grades and specified quantity
of lubricants.
•Get your car checked for
emission periodically by an
authorised dealer.
•Ensure periodic radiator fins
cleaning.
•Ensure that fuel filter, oil filter
and breather are checked
periodically and replaced, if
required, as recommended by
Tata Motors.
ENVIRONMENTAL CARE

10
•Do not pour used oils or
coolants into the sewage
drains, garden soil or open
streams. Dispose the used
filters and batteries in
compliance with the current
legislation.
•Do not allow unauthorised
person to tamper with engine
settings or to carry
modifications on the car.
•Never allow the car to run out
of fuel.
•Parts like brake liners, clutch
discs should be vacuum
cleaned. Do not use
compressed air for cleaning
these parts which may spread
dust in the atmosphere.
•While carrying out servicing or
repairs on your vehicle, you
should pay keen attention to
some of the important engine
components which greatly affect
emission. These components
are:
1. Fuel pump, Injectors and EMS
(Engine Management System)
parts.
2. Air Intake and Exhaust systems
(especially for leakages).
3. Cylinder head/Valve leakages.
4. All filters such as air, oil & fuel
filter (check periodically).
5. Ignition system & Spark plug.
6. Catalytic converter.
7. Carbon Canister.
This Owner’s manual contains
further information on driving
precautions and maintenance care
leading to environment protection.
Please familiarise yourself with
these aspects before driving.
ENVIRONMENTAL CARE

1111
24X7ROADASSISTANCE:
Dear Customer,
It is our responsibility and our
endeavour to ensure that you have
our complete service backup if ever,
wherever and whenever you need
the same. When you have a road
network that spans wide area, the
probability of a breakdown
happening within hailing distance of
a TATA MOTORS Authorized
Workshop is very low.
It is Precisely for this reason, we
have tied up with My TVS, who will
provide breakdown assistance
includingtowingtothe nearest TATA
MOTORS Authorized Workshop
through their Authorized Service
Providers (ASP)
The 24X7 On Road Assistance
Program shall be automatically
available to your vehicle for the
duration of Warranty period. The
program shall also be available, if
you avail the same post warranty.
Response Time ** for the On Road
Assistance Program
Within City Limits 60 minutes
On State or National 90 minutes
Highways
Ghat Roads and 120 min.+/-
other places
**(The response time will depend
onthelocation,terrain, traffic density
and the time of the day.)
24X7 ON ROAD ASSISTANCE
Standard procedure when calling
for On Road Assistance in case of
a breakdown:
•Dial the toll free help line number
– 1 800 209 7979
•Identify your vehicle with the
Vehicle chassis number that is
available in the Owners Service
manual.
•Explain your exact location with
landmarks and tell us about the
problem you face with the
vehicle.
•Park your vehicle on the edge of
the road, open the bonnet and
putonthehazardwarning signal.
•Place the advance warning
triangle supplied with the vehicle
approx. 3 m from the vehicle in
the direction of on coming traffic.

12
COVERAGEUNDER THE24 X7 ON
ROAD ASSISTANCE PROGRAM :
I. The 24x7 On Road Assistance
Program Service covers the
following services on your
vehicle during warranty period.
•Wheel change through spare
wheel.
•Arrangement of fuel. (Fuel cost
will be chargeable at actual cost)
•Re-opening the vehicle in cases
of key lock out.
•Rectification of electrical
problems related to battery,
fuses etc.
•On spot repairs for complaints
repairable at site.^
•Vehicle to vehicle towing or
winching & towing for non
accident cases up to the nearest
TATA MOTORS authorized
workshop. Towing charges at
actual cost beyond the same to
be paid to the ASP in cash. (Any
ferry or toll charges levied in
relation to the vehicle being
towed to be paid by the
customers in actuals in cash).
For accident cases, towing
charges to be borne by the
customer.
II. The 24x7 On Road Assistance
Program coverage on availing
the 24X7 policy, post warranty is
upto maximum of 6 instance of
assistance in one year for both
the plans- Basic and Premium.
In the premium plan, this
includes 1 instance of towing
upto the nearest TATA MOTORS
authorised workshop.
EXCLUSIONS
24x7On Road AssistanceProgram
does not apply to
•Cost of parts consumables and
labour for such repairs not
covered under warranty*. These
charges are to be settled with
ASP in cash.
•Toll or ferry charges paid byASP
in reaching to the breakdown site
to be settled with ASP in actuals
in cash.
•Cases involving accident, fire,
theft,vandalism,riots,lightening,
earthquake, windstorm, hail,
tsunami, unusual weather
conditions, other acts of God,
flood, etc.
•Vehiclesthatareunattended, un-
registered impounded or
abandoned.
•Breakdown/defects caused by
misuse, abuse, negligence,
alterations or modifications
made to the vehicle.
•Lack of maintenance as per the
maintenanc schedule as
detailed in the owner’s manual.
•Cases involving racing, rallies,
vehicle testing or practice for
such events..
24X7 ON ROAD ASSISTANCE

1313
Disclaimer
•The service is not available in
some part s of J&K and in Union
TerritoriesofAndaman& Nicobar
Islands and Lakshwadeep.
•**The reach time is indicative &
the actual reach time will be
conveyedbythe callcentreat the
time of breakdown call.
•The reach time can vary
dependingonthetraffic density
& time of the day.
•The reach time indicated does
not account for delays due to but
not limited to acts of God, laws,
rules & regulations for time
beinginforce,orders of statutory
or Govt. authorities, industrial
disputes, inclement weather,
heavydownpour,floods, storms,
natural calamities, road blocks
due to accidents, general strife
and law & order conditions viz.
fire, arson, riots, strikes, terrorist
attacks, war etc.
•^On spot repairs at breakdown
site shall depend on nature of
complaints & will be as per the
discretion of the ASP.
•*The decision for free of charge
repairs will be as per the
warranty policy & procedures of
TATA MOTORS LTD. and as per
the interpretation of the same by
ASP. You will be duly informed
by the ASP & call centre for the
change applicable if any.
•All charges wherever applicable
need to be settled directly with
theASP.
EXCLUSIONOFLIABILITIES:
•It is understood that TATA
MOTORS shall be under no
liability whatsoever in respect of
any loss or damage arising
directly or indirectly out of any
delayinor non deliveryof,defect/
deficiency in service/parts
providedbyASP.
•In case vehicle cannot be
repaired on-site, customers are
advised to use the towing facility
for taking their vehicle to the
nearest TATA MOTORS
authorized workshop only. In no
condition will the vehicle be
towed to any unauthorized
workshop. TATA MOTORS will
not be responsible for any
repairs carried out in such
unauthorized workshop.
•Customer are advised to take
acknowledgment from the ASP
for the list of accessories/extra
fittings and other belongings in
the vehicle as well as the current
condition related to dents/
scratches breakages of parts/
fitments of the vehicle at the time
of ASP taking possession of the
vehicle & to verify these items
when delivery is taken back by
them, Claim for loss of or
damage to items, if any should
be taken up with ASP directly.
24X7 ON ROAD ASSISTANCE

14
TATA MOTORS shall not be
responsible for any such claims,
damages/loss or any deficiency
of service of theASP.
•Vehicles will be handled,
repaired & towed as per the
customer’srisk& TATAMOTORS
shall not be liable for any
damages / claims as a result of
the same.
•Services entitled to the
customers can be refused or
cancelled on account of abusive
behaviour fraudulent
representation, malicious intent
and refusal to pay the charges
for any charges related services
and spare parts during service
or on previous occasion on part
24X7 ON ROAD ASSISTANCE

1515
Your NANO comes from a family of
new generation cars of TATA
motors.It is the outcome of
extensive research and
development by Tata Motors
Limited. We are happy to present
the NANO to you and hope it brings
the joy, pride and utility of owning a
car for personal mobility.
The NANO’s design and features
combined with easy maneuverability
and economic life cycle cost makes
it ideal for operating under a wide
range of conditions. Stylish, comfortable
The Tata Nano, designed with a
family in mind, has a roomy
passenger compartment with
generous leg space and head room.
Four persons can comfortably sit
inside the car. Five doors with high
seating position make comfortable
ingress and egress. All new floor
console comes with well-designed
utility spaces and the glove box.
This is also equipped with music
system.
It can effortlessly maneuver on busy
roads in cities as well as in rural
areas. Its mono-volume design
ensure with Electric Power Steering
system.
The car is available in various
versions. All versions offer a wide
range of body colours, and other
accessories so that the car can be
customised to an individual’s
preferences and taste.
KNOW YOUR NANO

16
Fuel-efficient engine
The Tata Nano has a rear mounted
rear-wheel drive, all-aluminum, two-
cylinder, multi point fuel injection
petrol engine. The lean design
strategy has achieved minimum
weight and maximum performance
per unit of energy consumed and
delivers high fuel efficiency.
Performance is controlled by a
specially designed electronic engine
management system.
Meets all safety requirements
The Tata Nano’s safety performance
exceeds current regulatory
requirements. With an all sheet-
metal body, it has a strong
passenger compartment, with safety
features such as crumple zones,
intrusion-resistant doors, seat belts,
strong seats and anchorages, and
the rear tailgate glass bonded to the
body. Tubeless tyres further
enhance safety.
Environment-friendly
The Tata Nano’s exhaust emission
performance meets present
regulatory requirements. The high fuel
efficiency also ensures that the car
has low carbon dioxide emissions,
thereby providing the twin benefits of
an affordable transportation solution
with a low carbon footprint.
Besides all these, TATA vehicles are
backed by a well established service
network with trained and skilled
manpower that ensures proper
maintenance.
KNOW YOUR NANO

1717
DRIVING CONTROLS AN OVERVIEW
DRIVING CONTROLS (MANUAL TRANSMISSION)
Note : a. HVAC or AC System is applicable to certain models.
b. Music System is part of accessories. It is applicable to certain models.
10. Brake pedal
11. Clutch pedal
12. Parking Brake
13. Window Winding Switch (if fitted)
14. Gear shifting lever
15. Music System
16. HVAC / AC system controls
17. Central Air Vents
1. Side air vents
2. Speakers on dashboard (For XT)
3. Glove Box (Co-driver side)
4. Instrument Cluster
5. Hazard Warning Switch
6. Glove Box (Driver side)
7. Steering wheel
8. Horn Pad
9. Accelerator Pedal

18
DRIVING CONTROLS
AN OVERVIEW
DRIVING CONTROLS (AUTOMATIC MANUAL TRANSMISSION)
Note : a. HVAC or AC System is applicable to certain models.
b. Music System is part of accessories. It is applicable to certain models.
10. Brake pedal
11. Parking Brake
12. Gear shifting lever
13. Plug Socket
14. Provision for Music System
15. HVAC / AC system controls
16. Central Air Vents
1. Side air vents
2. Speakers on dashboard (For XT)
3. Glove Box (Co-driver side)
4. Instrument Cluster
5. Hazard Warning Switch
6. Glove Box (Driver side)
7. Steering wheel
8. Horn Pad
9. Accelerator Pedal Module (APM)
