Installation procedure:
1. Prior to installation ush out the pipe work to
remove debris & then ensure that the water supply is
turned o.
2. Refer to diagram & check that all components
are present.
3. Fit the mixer to the bath using the brass nuts
and the washers provided as indicated in the
diagram.
4. Connect the hot & cold water supplies. The hot
supply should always be connected to the left hand
side.
5. Fully open mixer on both hot & cold sides &
allow water to run for approximately one minute to
further ush the system.
6. Check all connections for leaks.
Additional Instructions for Bath / Shower Mixers Only
7. Attach the end of the shower hose with the
smaller tting to the bottom of the diverter valve. The
other end should be attached to the shower head
(see diagram).
8. Establish the desired position for the shower
head wall-mounting bracket. Check that the bracket
is oriented correctly & that the shower head will
reach by placing it temporarily in position. Caution:
Before drilling, check for hidden power cables and
pipes. Take care using power tools, especially near
water. The use of a residual current device (RCD) is
recommended.
9. The bracket can now be installed using the
tting kit provided.
10. The shower head can now be stored in the wall
mounted bracket.
General notes
This mixer should be installed in accordance with water regulations. Approved check valves should be tted where
required. For further details please contact your local water authority. Should the mixer fail to operate eectively it
may be that there is insucient water pressure. Similarly, hot & cold water supplies should be relatively balanced for
optimum performance. A reputable plumber will be able to advise on each of these issues.
Aftercare instructions
Whilst this item has a high quality durable nish, it should nevertheless be treated with care. Surfaces should be
cleaned using only a soft damp cloth and clean water & dried using a soft cotton cloth. Bath cleaning products,
even non-scratch ones could damage the nished surface.
5-Year guarantee
We have complete condence in this Tavistock product and as such it is oered with a 5-year guarantee against
defects in manufacture. The guarantee requires that this product be used in the manner for which it was intended
and that it is installed & maintained in accordance with the tting instructions and local water bylaws. The
guarantee covers products in domestic use only. The guarantee is invalidated should the valve be damaged by
water borne debris. Make sure that supply pipes are clear of any debris prior to installation, this is particularly
important on new plumbing installations. In the unlikely event that this product should fail during the guarantee
period we will either replace the faulty part or the complete unit as appropriate.
Brass nut
Shower hose
Diverter valve
Shower head
Bath
Rubber
washer
Wall bracket
11. To use shower, lift and turn diverter valve.
Diverter valve
1
2
