0English
PROTRONIC - A3000 open wash basin fitting with thermostat, 24 V DC
PR3O0020 ................. Finished installation kit
AQUA104 ................... Basic installation kit
Please refer to the graphics in the German installation and operating instructions.
0Table of contents
1. Abbreviations and units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2. Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3. Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
4. Important notes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Description of product
5. Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
6. Technical specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
7. Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
8. Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
9. Installation example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Assembly, function and commissioning
10. Assembly of basic installation set. . . . . . . . . . . . . . . . . . . . . . . . . 6
11. Installation of finished installation kit. . . . . . . . . . . . . . . . . . . . . . . 8
12. Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
13. Adjusting the range. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
14. Setting the hygiene flush . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
15. Thermal disinfection -manual- . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
16. Thermal disinfection -automatic- . . . . . . . . . . . . . . . . . . . . . . . . . 11
17. Setting the scald protector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Maintenance
18. Maintenance and care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
19. Replacing the filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
20. Replacing the solenoid valve cartridge. . . . . . . . . . . . . . . . . . . . . 13
21. Replace the thermal element . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
22. Replacing the flow rate regulator . . . . . . . . . . . . . . . . . . . . . . . . . 14
23. Replace the aerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
24. Replacing the non-return valve. . . . . . . . . . . . . . . . . . . . . . . . . . . 15
25. Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
26. Spare parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
EN

4
ZMI_001_2030018721-PR3O0020_#SEN_#AQU_#V1.fm
1. Abbreviations and units
2. Key
Warning!
Failure to observe can result in bodily injury or even death.
Caution!
Failure to observe can result in material damage.
☞Important!
Failure to observe can cause the product to malfunction.
☞Useful information for optimal handling of the product.
3. Warranty
Liability is accepted in accordance with the General Terms and Conditions of
Business and Supply.
Use only genuine spare parts!
4. Important notes
• Installation, commissioning and maintenance are to be performed only by a
qualified expert in accordance with the instructions provided, legal requirements
and recognised engineering standards.
• All technical connection regulations specified by the local water and electricity
supply companies must be observed.
• We reserve the right to make changes.
DN Nominal diameter in mm
RCD Residual current protective device,
Earth leakage circuit breaker
SELV Safety extra low voltage
EA-Nr. European article number
FAR-Best.-Nr. Franke Aquarotter order number
Conversion 1 mm = 0.03937 inches
1 inch = 25.4 mm
All length specifications in the graphics are in mm.

5
ZMI_001_2030018721-PR3O0020_#SEN_#AQU_#V1.fm
5. Application
PROTRONIC - A3000 open, non-contact, opto-electronically controlled DN 15
thermostat battery for wall-mounted wash basins, with the option of external control,
such as valve settings and communication via ECC function controller.
For connection to hot and cold water supply. The flow time can be set in one-second
steps.
With an integrated solenoid valve cartridge and a device for an optional bypass
solenoid valve cartridge for carrying out thermal disinfection, with the option of
manual thermal disinfection.
Integrated control functions:
– Hygiene flush (10 seconds), 24 hours after last operation
– Safety shutdown after 5 minutes of continuous activation
Additional functions with ECC function controller (Ethernet):
– Automatic thermal disinfection according to DVGW Work Sheet W 551 and
safety shutdown
– Cleaning deactivation
6. Technical specifications
Minimum flow pressure: 1.0 bar
Recommended flow
pressure:
1-5 bar
Maximum operating
pressure:
10 bar
Calculated flow rate: 0.07 l/s 0.07 l/s
Volumetric flow: 0.10 l/s at a flow pressure of 3 bar
Flow time at 38 °C 1–50 s
Operating voltage: 24 V DC
Power consumption: 2.5 W
Communication: Ethernet via ECC function controller
Protection class: IP 68

6
ZMI_001_2030018721-PR3O0020_#SEN_#AQU_#V1.fm
7. Scope of delivery
Basic installation kit
Installation kit
8. Dimensions
9. Installation example
10. Assembly of basic installation set
Warning!
• Operate the product only with safety extra low voltage (SELV). The components
must not be earthed.
• Place the power supply (not part of the delivery , see accessories, Chapter 26)
outside the wet area in a separate room.
• Protect the power supply with a residual current circuit breaker (RCD).
• Lay the system line (to be provided by the customer) in the empty pipe (to be
provided by the customer) from the power supply to the fittings and loop through.
Failure to observe this instruction can result in death or material damage due to
electric shock or fire, for example.
Quantity Name
1 Wall unit with lockable water quantity regulators
and flush connector
1 Electrical T-distributor with protective cap
1 Wall protection
1 Installation and operating instructions
Quantity Name
1 Cover plate with sensor module
1 Electronic module M3
1 Function block with thermostat mixer valve
1 Connection extension
2 Rosettes
1Outlet
1 Plastic bag with filters and seals
1 Installation and operating instructions

7
ZMI_001_2030018721-PR3O0020_#SEN_#AQU_#V1.fm
Caution!
The wall-mounting plate must be attached, as otherwise the outlet cannot be fixed
with the necessary stability.
☞If an installation frame is used, it should be ensured that the wall-mounting plate can
be attached.
10.1 Create a wall recess. Choose the depth of the wall recess so that the front edge of the
wall mounting box (d) is flush with the front edge of the masonry (in front of the tiles).
10.2 Remove the transport protection of the wall-mounting plate (a).
10.3 Separate the pipe (b) from the flush connector (c).
10.4 Place the wall mounting box (d) against the wall and mark the holes for the wall
mounting plate (a) and the wall mounting box (d).
10.5 Drill holes in accordance with these markings.
Insert the wall plugs.
10.6 Insert the wall mounting box (d) horizontally into the wall recess provided and screw
it in place.
10.7 Fasten the wall mounting plate (a).
10.8 Attach the pipe (b) to the flush connector.
Caution!
Use an open-ended wrench to hold the water quantity regulators (f) in position while
turning the cap nuts (e).
10.9 Establish the water connections.
10.10 Align the water volume regulators (f) so that the locking screw (g) and operating
element (h) are freely accessible. Loosen the flush connector for this purpose, if
required.
10.11 Install the system cable (i) in the empty pipe and pull it from fitting to fitting.
☞Allow approximately 50 cm of system cable to hang out of the wall mounted box.
10.12 Connect the electrical T-distributor (k).
Install the electrical T-distributor
☞Important!
The components of the electrical T-distributor may only be installed after the power
has been switched off.
☞Recommended system cable (see Chapter 26.), accessories.
When using cables other than the system cable, pay attention to the different colour
code. The outer diameter must not exceed 7.5 mm.
10.13 Remove the sheathing (l) of the system cable (approx. 40 mm).
10.14 Push the cap nut (n) onto the system cable (m) up to the limit stop.

8
ZMI_001_2030018721-PR3O0020_#SEN_#AQU_#V1.fm
☞The various wire guides are marked with numbers 1 to 4.
10.15 Push the wires (o) into the wire guides (p) according to their colours.
10.16 Cut off the projecting wire ends flush, i.e. without protrusions.
10.17 Push the union nut (n) onto the electrical T-distributor (k) and tighten it to the
required torque (1.2 Nm).
Caution!
Note the polarity.
The same wire colour must be in the same wire guide for both union nuts.
☞When tightening the union nut, the electrical contact and tension relief are created
automatically.
Special seals act as protection from dust and water.
10.18 Open the water volume regulator using an Allen key.
r: closed
s: open
10.19 Flush the pipes according to DIN 1988.
10.20 Check the water connections for leaks.
10.21 Insert the wall protection.
11. Installation of finished installation kit
Warning!
Only operate the fitting with non-return valves and the specified filters.
Failure to observe this instruction can result in an increased germ load in the
drinking water and thus pose a health or mortality risk.
☞Important!
Prior to the assembly process, flush the pipework in accordance with DIN 1988.
11.1 Remove the wall protection.
11.2 Close the water volume regulators (see Work step 10.18).
11.3 Open the locking screws (a) of the water quantity regulators (d).
☞Important!
Note the installation position of the filters (b).
11.4 Insert the filters (b).
11.5 Screw in the locking screws (a).
A: Union nut
B: FAR-Best.-Nr. 2000104272
FAR-Best.-Nr. 2000104274
FAR-Best.-Nr. 2000100801
FAR-Best.-Nr. 2000100852
AB
1brown red
2 white white
3 blue blue
4 black black

9
ZMI_001_2030018721-PR3O0020_#SEN_#AQU_#V1.fm
Caution!
Use an open-ended wrench to hold the water quantity regulators (d) in position while
turning the cap nuts (c).
11.6 Remove the T-type flush connector (e) and any seals that are present.
11.7 Install the function block (f) and the connection extension (g) with new seals.
11.8 Use an open-ended wrench to fasten the connection piece (h) until it seals to G½B level.
11.9 Slide the wall bracket (k) onto the connection piece (h).
11.10 Fasten the grub screw (i), using an Allen key.
11.11 Open the water volume regulators (see Work step 10.18).
11.12 Check the water connections for leaks.
11.13 Release the screw (n) with its disk.
11.14 Remove the temperature selector (m) and the stop ring (l).
11.15 Pull the protective foil off the cover plate.
11.16 Seal the cover plate, e.g. with Chromol (not part of the delivery scope, see Acces-
sories Chapter 26).
11.17 Connect the wires between the electronic module, the solenoid valve cartridge and
the optical sensor.
A: Solenoid valve cartridge for mixed water
B: Solenoid valve cartridge for thermal disinfection bypass (optional)
C:Cold water temperature sensor (optional)
D:Hot-water temperature sensor (optional)
E: Optical sensor
F: Electrical T-distributor system cable (power)
G:Electronic module
11.18 Fix the cover plate (r), using the safety screws (o).
11.19 Remove the locknuts (p).
11.20 Push on the rosette (s).
11.21 Push the headpiece (u) onto the wall bracket.
11.22 Fasten the grub screw (v), using an Allen key.
11.23 Fit the rosette (t) in such a way that the markings are at the top.
11.24 Turn the adjustment nut (w) so that the two markings (x) are aligned.
☞The maximum water temperature has been set to 38°C
11.25 If necessary, set the scald protection to another temperature (see Chapter 17.).
11.26 Mount the stop ring (l) in such a way that the marking (z) is centred below the stop
ring, centrally below the markings (y) for the rosette.
☞Important!
Mount the temperature selector (m) in such a way that the stop is flush against the
stop ring crosspiece.
11.27 Push the temperature selector (m) onto the stop ring (l).
11.28 Attach the temperature selector (m) and its screw and disk to the fitting.
11.29 Fit the cover platelet (n).
11.30 Check the range and adjust where necessary (see Chapter 13.).

10
ZMI_001_2030018721-PR3O0020_#SEN_#AQU_#V1.fm
12. Function
12.1 Approach the fitting.
• The water will flow.
12.2 Move away from the fitting.
• The water flow will stop automatically.
Temperature selection
13. Adjusting the range
The range can be adjusted using an ECC2 function controller via the web application.
14. Setting the hygiene flush
The hygiene flush can be adjusted with an ECC2 function controller via the web
application.
15. Thermal disinfection -manual-
This shower fitting offers thermal disinfection to reduce the risk of a legionella
infection.
The thermal disinfection process is triggered by overturning the thermostat.
Warning!
Personal protective measures (scald protection) must be implemented for the duration
of the thermal disinfection. This might include cordoning off the shower facilities.
Failure to observe this instruction can result in injuries due to scalding.
The operator is responsible for the execution, monitoring, and logging (room,
tapping point, date, time, temperature and duration).
The manufacturer does not accept any liability for claims by third parties relating to
the improper execution of thermal disinfection on the part of the operator.
The thermostat fitting has been prepared to carry out a thermal disinfection process
when the thermostat is overturned. The thermostat fitting can be manually thermally
disinfected (flushed with water at a temperature of 70°C) by unlocking the covered
stop on the temperature selector.

11
ZMI_001_2030018721-PR3O0020_#SEN_#AQU_#V1.fm
15.1 Turn the temperature selector (a) to the hot water stop.
15.2 Use the Allen key to push in the stop.
15.3 Turn the temperature selector (a) in an anti-clockwise direction up to the stop.
15.4 Trigger the fitting.
15.5 Measure the hot water temperature.
15.6 If the hot water temperature is > 70°C, the fitting should be flushed for at least
3 minutes. Trigger the fitting several times for this purpose.
☞The thermal disinfection process must be recorded (room, tapping point, date, time,
temperature, duration).
15.7 Turn the temperature selector (a) clockwise until it engages.
Caution!
The temperature selector (a) may not be turned beyond the stop in an anti-
clockwise direction.
15.8 Test the limit stop.
15.9 Trigger the fitting to drain the remaining hot water.
15.10 Measure the water temperature. The maximum water temperature may not exceed
40°C (see Chapter 17.).
☞Once thermal disinfection has been completed, the scald protector does not need to
be reset.
16. Thermal disinfection -automatic-
Caution!
The directions in the Thermal Disinfection Planning Aid (01805618) must be
adhered to.
Required accessories
ECC2 function controller (60 W)
with Ethernet connection . . . . . 2000108123
Bypass solenoid valve cartridge . . 2000100431

12
ZMI_001_2030018721-PR3O0020_#SEN_#AQU_#V1.fm
17. Setting the scald protector
Warning!
If the hot water supply temperature is above 45°C, the scald protector should be set.
Failure to observe this instruction can result in injuries due to scalding.
☞The scald protector (hot water stop) has been set to 38°C at the factory. Set the
system-specific parameters before use.
17.1 Remove the cover platelet (d).
17.2 Release the screw (c) with its disk.
17.3 Remove the temperature selector (b).
17.4 Remove the stop ring (a).
17.5 Trigger the fitting.
17.6 The temperature is freely selectable:
Set the maximum water temperature on the adjustment nut (e), e.g. to 40 °C.
17.7 Mount the stop ring (a) in such a way that the marking (f) is centred below the
markings (g) for the rosette.
☞Important!
Mount the temperature selector (a) in such a way that the stop is flush against the
stop ring crosspiece.
17.8 Slide the temperature selector (a) onto the stop ring (b).
17.9 Attach the temperature selector (b) and its screw (c) and disk to the fitting.
17.10 Fit the cover platelet (d).
18. Maintenance and care
The fitting must be checked and maintained at regular intervals, depending on the
water quality and in accordance with the local conditions and rules and regulations
applicable at the site.
Maintain the following components:
• Aerator (see Chapter 23.)
• Filters (see Chapter 19.)
• Non-return valve (see Chapter 24.)
Use suitable cleaning agents which do not attack the fitting in a proper manner and
rinse with water after use. Any cleaning and disinfection agents used must be
polycarbonate-compatible. High-pressure cleaners must not be used for cleaning.
Removing the cover plate
For some maintenance tasks, the cover plate must be removed.
18.1 Remove the cover platelet (d).

13
ZMI_001_2030018721-PR3O0020_#SEN_#AQU_#V1.fm
18.2 Release the screw (c) and the disk.
18.3 Remove the temperature selector (b).
18.4 Remove the rosette (a).
18.5 Undo the grub screw (f) with an Allen key.
18.6 Remove the headpiece (g) from the wall bracket.
18.7 Remove the rosette (e).
18.8 Remove the safety screws (k) and their locknuts (h) from the cover plate.
18.9 Loosen the cable connection between the optical sensor and the electronics module.
18.10 Remove the cover plate (i).
18.11 Close the water volume regulators (see Work step 10.18).
18.12 Trigger the fitting.
19. Replacing the filters
Water volume regulator filters
19.1 Remove the cover plate (see Chapter 18.).
19.2 Unscrew the locking screws (a) on the water volume regulators.
19.3 Replace the filters (b).
☞Important!
Note the installation position of the filters.
19.4 Reassemble in reverse order.
20. Replacing the solenoid valve cartridge
20.1 Remove the cover plate (see Chapter 18.).
20.2 Loosen the cable connection between the solenoid valve cartridge and the
electronics module.
20.3 Loosen the screws (a).
20.4 Remove and replace the solenoid valve cartridge (b).
20.5 Reassemble in reverse order.

14
ZMI_001_2030018721-PR3O0020_#SEN_#AQU_#V1.fm
21. Replace the thermal element
Warning!
Set the scald protection after installing the fitting or removing the thermal element.
Failure to observe this instruction can result in injuries due to scalding.
21.1 Remove the cover plate (see Chapter 18.).
21.2 Remove the screw (b)
Caution!
Apply the pliers to the area with the largest diameter (a) behind the small sprocket
wheel.
If the sprocket wheel is damaged, the temperature selector cannot be installed.
21.3 Use pliers to remove the thermal element (c).
☞Important!
Note the installation position of the thermal element.
21.4 Reassemble in reverse order.
21.5 Set the scald protection (see Chapter 17.).
22. Replacing the flow rate regulator
22.1 Remove the cover plate (see Chapter 18.).
22.2 Undo the grub screw (a), using an Allen key.
22.3 Remove the wall bracket (b) from the connection piece.
22.4 Remove the locking ring on the inside using appropriate pliers for locking rings.
22.5 Pull out the flow rate regulator using flat-nosed pliers.
☞Important!
Note the installation position of the flow rate regulator. The struts must point towards
the shower head.
22.6 Insert the flow rate regulator and secure with the locking ring.
c: Struts
d: Direction of flow
22.7 Slide the wall bracket (b) onto the connection piece.
22.8 Undo the grub screw (a), using an Allen key.
22.9 Reassemble in reverse order.

15
ZMI_001_2030018721-PR3O0020_#SEN_#AQU_#V1.fm
23. Replace the aerator
23.1 Use the special wrench (e) to loosen the entire aerator.
23.2 Remove the entire aerator from the headpiece (a).
23.3 Remove the seal (b).
23.4 Remove the casing (c).
23.5 Replace the aerator (d).
23.6 Reassemble in reverse order.
24. Replacing the non-return valve
Warning!
All non-return valves must be replaced at the same time.
Failure to observe this instruction can result in an increased germ load in the
drinking water and thus pose a health or mortality risk.
24.1 Remove the cover plate (see Chapter 18.).
Caution!
Use an open-ended wrench to hold the water quantity regulator (b) in position while
turning the cap nut (a).
24.2 Remove the function block (c).
24.3 Remove the existing seals.
24.4 Remove the locking ring on the inside using appropriate pliers for locking rings.
24.5 Pull the non-return valve (d) out of the function block using a special tool (e;
FAR-Best.-Nr. 2000105636).
Optional:
Fittings with optional thermal disinfection have a third non-return valve.
24.6 Remove the lock (f) using an Allen key.
24.7 Remove the spacer (g).
24.8 Pull the non-return valve (h) out of the function block using a special tool
(e; FAR-Best.-Nr. 2000105636).
Caution!
Note the installation position of the non-return valves.
24.9 Reassemble in reverse order.

16
ZMI_001_2030018721-PR3O0020_#SEN_#AQU_#V1.fm
25. Troubleshooting
If you cannot rectify a fault or if it is not in the list, please contact our customer
service department!
Fault Cause Remedy
Water does not flow – Water supply interrupted ➯Restore it
– Water volume regulator closed ➯Open it
– Power supply interrupted ➯Restore it
– Dirty filters ➯Replace it
– Non-return valve faulty ➯Replace it
– Optical sensor faulty ➯Replace it
– Electronics module faulty ➯Replace it
– Solenoid valve cartridge faulty ➯Replace it
Water flows
continuously
– Solenoid valve cartridge faulty ➯Replace it
Flow time too short or
too long
– Incorrect flow time setting ➯Set it
Water too hot – Scald protection set incorrectly ➯Set it
– Thermal element faulty ➯Replace it
Water too cold – Scald protection set incorrectly ➯Set it
– Hot water flow blocked ➯Open it
– Dirty filters ➯Replace it
– Non-return valve faulty ➯Replace it
– Hot water supply pressure too low ➯Check it
– Hot water temperature too low ➯Increase it
– Thermal element faulty ➯Replace it
Water volume too low – Water volume regulator not fully open ➯Open it
– Aerator calcified ➯Clean it
– Dirty filters ➯Clean it
– Supply pressure too low ➯Check it
Thermostat controls
unevenly
– Flow rate regulator in aerator blocked
with scale
➯Clean and replace
if necessary
– Thermal element dirty ➯Clean it

17
ZMI_001_2030018721-PR3O0020_#SEN_#AQU_#V1.fm
26. Spare parts
Description Order No.
Lockable
water volume regulator. . . . . . . 2000105782
M3* electronic module . . . . . . . . . . 84-100-17.110
Accessories Order No.
Special wrench. . . . . . . . . . . . . . . . 2000105960
Temperature sensor red. . . . . . . . . 2000100973
Temperature sensor blue . . . . . . . . 2000100974
Function controller with
Ethernet and CAN Bus connector (60 W)
ECC2 . . . . . . . . . . . . . . . . . . . . 2000108123
Power pack (12 W) . . . . . . . . . . . . 2000100375
Power pack (60 W) . . . . . . . . . . . . 2000101174
System cable for long-term use in water,
halogen-free
100 m . . . . . . . . . . . . . . . . . . . . 2000104272
25 m . . . . . . . . . . . . . . . . . . . . . 2000104274
System cable,
not halogen-free
100 m . . . . . . . . . . . . . . . . . . . . 2000100801
25 m . . . . . . . . . . . . . . . . . . . . . 2000100852
CHROMOL 0.5 l stainless steel
polish . . . . . . . . . . . . . . . . . . . . . . . 2000105091
Stainless steel maintenance set complete
CHROMOL 0.5 l
Abrasive sponge, coarse
Abrasive sponge, fine. . . . . . . . 2000109019
* When ordering please specify the fitting ID!
The fitting ID can be found on the side of the
electronic module.
Description Order No.
1 Temperature selector. . . . . . . . . . . 2030003254
1a Cover platelet . . . . . . . . . . . . . . . . 2030003258
2 Temperature stop . . . . . . . . . . . . . 2030003296
3 Thermal element . . . . . . . . . . . . . . 2030003300
4 Push-on rosette . . . . . . . . . . . . . . . 2030022722
5 Solenoid valve cartridge . . . . . . . . 2000100431
6 Optical sensor . . . . . . . . . . . . . . . . 2000105815
7 Cover plate . . . . . . . . . . . . . . . . . . 2000109489
8 Complete headpiece
with aerator . . . . . . . . . . . . . . . 2000105485
9 Aerator with special key . . . . . . . . 2000105959
10 Shower bracket 143 mm . . . . . . . . 2000109150
11 Mounting kit consisting of:
O rings
Grub screws. . . . . . . . . . . . . . . 2000104797
12 Flow rate regulator (packaging unit 10x)
0.10 l/s . . . . . . . . . . . . . . . . . . 2000104701
13 Push-on rosette . . . . . . . . . . . . . . . 2000105465
14 Service kit consisting of:
Non-return valve
O-rings
Filters
Seals . . . . . . . . . . . . . . . . . . . . 2000104856

18
ZMI_001_2030018721-PR3O0020_#SFR_#AQU_#V1.fm
0Français
Robinetterie de lavabo PROTRONIC - A3000 open avec thermostat, 24 V DC
PR3O0020 ................. Kit de montage final
AQUA104 ................... Kit de montage brut
Les graphiques figurent dans la notice de montage et de mise en service allemande.
0Table des matières
1. Abréviations et unités . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2. Pictogrammes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3. Garantie . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
4. Remarques importantes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Description du produit
5. Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
6. Caractéristiques techniques . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
7. Contenu de la livraison . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
8. Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
9. Exemple d'installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Montage, fonctionnement et mise en service
10. Montage du kit de montage brut. . . . . . . . . . . . . . . . . . . . . . . . . . 22
11. Montage du kit de montage final. . . . . . . . . . . . . . . . . . . . . . . . . . 24
12. Fonctionnement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
13. Réglage de la portée . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
14. Réglage du rinçage hygiénique . . . . . . . . . . . . . . . . . . . . . . . . . . 25
15. Désinfection thermique -manuelle-. . . . . . . . . . . . . . . . . . . . . . . . 26
16. Désinfection thermique -automatique- . . . . . . . . . . . . . . . . . . . . . 27
17. Régler la protection contre les brûlures . . . . . . . . . . . . . . . . . . . . 27
Entretien
18. Maintenance et entretien . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
19. Remplacement des filtres . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
20. Remplacement de la cartouche d'électrovanne . . . . . . . . . . . . . . 29
21. Remplacer le thermocouple . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
22. Remplacement du régulateur de débit d'eau . . . . . . . . . . . . . . . . 30
23. Remplacer le gazéificateur . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
24. Remplacement des clapets de non-retour . . . . . . . . . . . . . . . . . . 31
25. Dépannage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
26. Pièces de rechange . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
FR

19
ZMI_001_2030018721-PR3O0020_#SFR_#AQU_#V1.fm
1. Abréviations et unités
2. Pictogrammes
Avertissement !
Le non-respect des consignes est susceptible de présenter un danger de mort ou de
provoquer des blessures.
Attention !
Le non-respect des consignes est susceptible de provoquer des dommages
matériels.
☞Important !
Le non-respect des consignes est susceptible de provoquer des dysfonctionne-
ments sur le produit.
☞Informations utiles pour une utilisation optimale du produit.
3. Garantie
La responsabilité est conforme à celle décrite dans les conditions générales de
vente et de livraison.
Utiliser exclusivement des pièces de rechange d'origine !
DN Diamètre nominal en mm
RCD Residual Current Protective Device, interrupteur
de protection contre les courants de court-circuit
SELV Safety Extra Low Voltage, très basse tension de
sécurité
EA-Nr. Numéro d'article européen
FAR-Best.-Nr. Référence de commande Franke Aquarotter
Conversion 1 mm = 0,03937 pouce
1 pouce = 25,4 mm
Sur les graphiques, toutes les longueurs sont exprimées en mm.

20
ZMI_001_2030018721-PR3O0020_#SFR_#AQU_#V1.fm
4. Remarques importantes
• Seul un spécialiste est habilité à effectuer le montage, la mise en service et
l'entretien de l'installation, et ceci tout en veillant à ce que ces opérations soient
réalisées conformément aux instructions fournies, aux prescriptions légales et
aux règles techniques en usage.
• Les prescriptions techniques des sociétés de distribution d'eau et d'électricité
doivent également être respectées.
• Sous réserve de modifications.
5. Application
Mitigeur thermostatique DN 15 PROTRONIC - A3000 open, à commande opto-
électronique, sans contact pour montage mural dans des sanitaires, avec possibilité
de commande externe d'options telles que le réglage de la robinetterie ou la
communication via un contrôleur de fonction ECC. Pour un raccordement à l'eau
chaude et froide. Durée d'écoulement réglable à la seconde près.
Avec cartouche d'électrovanne intégrée et dispositif pour cartouche d'électrovanne
de dérivation en option pour la réalisation d'une désinfection thermique automatique
et la possibilité de réalisation d'une désinfection thermique manuelle.
Fonctions de commande intégrées :
– rinçage hygiénique (10 secondes), 24 heures après le dernier actionnement
– arrêt de sécurité après 5 min de réflexion continue
Fonctions supplémentaires avec le contrôleur de fonction ECC (Ethernet) :
– désinfection thermique automatique conformément à la fiche de travail W 551
de la DVGW et arrêt de sécurité
– arrêt pour nettoyage
