Tayama FTK-002 User manual

Electric Kettle
FTK-002
OPERATING INSTRUCTIONS
Dear users:
．Thank you for use of this product.
．This product is a well-designed, high-quality household appliances.
For your convenience, please read the instructions carefully
and operate according to this manual.
．This product is designed and manufactured according to household
appliances standards. Please don’t apply it for commercial or
industrial use.

Temperature controlled type
Kettle lid
Handle
Body
Switch
Bottom voltage selector switch
2

Product parameters：
Rated voltage
Rated frequency
Rated power
AC100-120V~
50/60Hz
850W
AC220-240V~
CAPACITY：0.6L
Precautions：
Safety warning:
.The supply voltage must be consistent with the one on the nameplate.
.Do not place kettle beside heat source, such as cooker, oven,
microwave oven, etc.
.In order to prevent leakage accidents, the products shall not be placed
in water or other liquids.
.Do not pull the power cord by force when pulling out the plug.
.Do not let the power cord hang on the edge of the table. Avoid the
power cable is contacted with the hot surface of the electric kettle or ties
a knot.
.This electric kettle is for household use only and shall not be used for
commercial or industrial purposes.
3

Notice for use：
.The electric kettle must be placed on a flat, dry surface when boiling
water.
.The electric kettle can only be used for boiling water, please do not use
it to make coffee, milk, tea and other drinks.
.When boiling water, the quantity of water should not be higher than the
maximum scale. If the water is too full, the boiling water may be ejected.
.The kettle must be supervised and placed beyond the reach of the
child to avoid scalding.
.During boiling water process, please do not open the lid to avoid
scalding by boiling steam.
.If there is no water in the kettle, please do not run it, or otherwise the
stainless-steel base will be discolored, dry burning for times will make
the service life of the kettle decreases sharply.
.In the process of boiling water, it is normal for the kettle getting
hot.When taking and pouring the boiling water, must pull out the power
plug and hold the handle to lift the kettle. .When not in use, please pull
out the plug.
Product characteristics：
This product is designed for convenient carrying by customer during
tourism.
It can be used in AC220-240V 50HZ power supply and AC100-120V
50/60HZ power supply (Operate according to the method of use)
4

Thermal insulated type FTK-002 (single switch mode)
1. Detachable silicone kettle, easy to hold and carry.
2. Automatic thermal insulation function
When the water is boiled, the kettle automatically stops power and
enters the heat preservation state. When the water is cooled to a
certain temperature, it begins to preserve heat and heat it to boiling
state, and then circulates this process.
(Special note: It is not recommended to drink the water after more than
three times of boiling.)
Note:
If you do not need heat preservation, please turn off the boiling
switch manually and unplug it after boiling water.
5

Temperature controlled type FTK-002
(adjustable temperature control mode)
1. Detachable silicone kettle, easy to hold and carry.
2. Automatic thermal insulation function
①When the option is lower than the suitable position of the boiling
degree, the product enters the continuous heat preservation state, and
when the water is cooled to a certain temperature, the water is heated,
and then circulate this process.(Note:This option must use pure water,
because the water in the kettle is not heated to boiling process during
this process.
②When the thermostat knob is set to “boiling”, the product is in a
continuous heat preservation state. When the water is boiling, please
adjust the thermostat knob indicator to the "heat preservation" scale to
prevent the water from boiling all the time.
Note:
1. If you do not need heat preservation, please turn the
thermostat knob to the "off" position or unplug the plug after the
water has boiled.
2. In winter or when the ambient temperature is low, the water
temperature in the kettle is low, and the knob works directly in
the "off" position.
That's because the product is designed that the “off” temperature
is 25 ℃, which is normal and does not affect the use of normal
functions.
6

Usage method：
Before use, make sure that the voltage of the local electric outlet is in
line with the set voltage of the kettle (the corresponding voltage value in
the direction of the black plastic “Ø”1 word at the bottom of the kettle,
the factory setting is the AC220-240V position."
Before the first use, the electric kettle should be filled to the highest
water level, boil, pour, rinse with clean water, repeat one or two times to
remove the dust which is generated during production, storage process.
Please use the product under the following steps:
1. Turn the bottom voltage selector switch to the matching voltage
(turn clockwise to AC100-120V or counterclockwise to AC220-240V),
open the lid of the kettle, inject adequate amount of water (water
cannot exceed the maximum water level), close the lid and plug the
electric plug.If the voltage isn’t matched, it will damage the electric
kettle or the product boils water very slowly.(The factory setting is in
AC220-240V position)
2. Press the boiling water switch to "I", the indicator lamp is on and the
product start heating.
3. When water is boiled, the power is cut off automatically, but the
boiling switch still points to the "1" position and the product is in heat
preservation state.
4. When the water is cooled to a certain temperature, the kettle begins
to preserve temperature and heat water.
5. If you do not need heat preservation, please turn off the boiling
switch manually to “O” position and unplug it after boiling water.
6. Due to different local voltage, climate, air pressure of various region,
the difference of boiling time is a normal phenomenon.
7

Cleaning and maintenance：
.Before cleaning, be sure to disconnect the power supply and wait for it
to cool. Do not plug in or unplug the electric cord when hands are wet,
so as to avoid danger.
.When cleaning the product, do not immerse it in water. Do not use a
highly corrosive or polishing cleaner to wash it.
.Because of the influence of water quality, calcium carbonate oxide will
be produced in the process of water heating; the light one will form
floating foam on the surface of water and the heavy one will precipitate
and form limescale at the bottom of the kettle.The limescale will
increase the water resonance volume and increase the boiling time.
Therefore, it must be cleaned regularly by use of citric acid detergent
cleaning.You can also use vinegar (preferably white vinegar). The
method is that add water and vinegar in the kettle at 2:1 proportion, boil
it and stay for one night, pour the solution out at the next day, and then
boil water once to clean it.
