TCL PDP42U3H User manual

SERVICE MANUAL
PDP42U3H
1. Caution………………………………………………….2
2. Specification…………………………………………….6
3. BOM List………………………………………………..8
4. Alignment Procedure………………………………….18
5. Block Diagram………………………………………....22
6. Schematic Diagram……………………………………23
7. Explode View Diagram………………………………..45
This manual is the latest at the time of printing, and does not
include the modification which may be made after the
p
rintin
g,
b
y
the constant im
p
rovement of
p
roduct.

CA UTION: TO RE DUCE THE RIS K OF
ELECTR ICA L SHOCK, DO NOT RE MOVE
COVER (OR BACK). NO USER SERVICEABLE
PAR TS INSIDE . RE FER SER VIC ING TO
QUALIFIED SERVICE PERSONNEL.
The lighting flash with arrowhead symbol, with an equilateral triangle is intended to
alert the user to the presence of uninsulated voltage within the products
enclosure that may be of sufficient magnitude to constitute a risk of electric shock to
the person.
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
CAUTION:
Use of controls, adjustments or procedures other than those specified herein may result in
hazardous radiation exposure.
CA U T ION
RISK
RISK
OF ELECTRI
ELECTRI
C
SHOCK
SHOCK
DO NOT
NOT
OPEN.
OPEN.
2
dangerous
WARNING: TO REDUCE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
SCHNEIDER ELECTRONICS GMBH-GERMANY
1. CAUTION
2

1. When the power cord or plug is damaged or frayed, unplug this television set from the wall outlet and refer servicing to
qualified service personnel.
2. Do not overload wall outlets and extension cords as this can result in fire or electric shock.
3. Do not allow anything to rest on or roll over the power cord, and do not place the TV where power cord is subject to
traffic or abuse. This may result in a shock or fire hazard.
4. Do not attempt to service this television set yourself as opening or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to qualified service personnel.
5. Never push objects of any kind into this television set through cabinet slots as they may touch dangerous voltage
points or short out parts that could result in a fire or electric shock. Never spill liquid of any kind on the television set.
6. If the television set has been dropped or the cabinet has been damaged, unplug this television set from the wall outlet
and refer servicing to qualified service personnel.
7. If liquid has been spilled into the television set, unplug this television set from the wall outlet and refer servicing to
qualified service personnel.
8. Do not subject your television set to impact of any kind. Be particularly careful not to damage the picture tube surface.
9. Unplug this television set from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a
damp cloth for cleaning.
10.1. Do not place this television set on an unstable cart, stand, or table. The television set may fall, causing serious injury
to a child or an adult, and serious damage to the appliance. Use only with a cart or stand recommended by the
manufacturer, or sold with the television set. Wall or shelf mounting should follow the manufacturer s instructions, and
should use a mounting kit approved by the manufacturer.
10.2. An appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces
may cause the appliance and cart combination to overturn.
CAUTION:
Read all of these instructions. Sa ve these instructions for later use . Follo w all Warnings and
Instructions marked on the audio equipment.
1. Read Instructions-All the safety and operating instructionsshouldbe read before the productis operated.
2. Retain Instructions- The safety and operating instructions should be retained for future reference.
3. Heed Warnings- All warnings on the product and in the operating instructions should be adhered to.
4. Follow Instructions- All operating and use instructions should be followed.
3
SCHNEIDER ELECTRONICS GMBH-GERMANY
IMPORTANT SAFETY INSTRUCTIONS
FOR YOUR PERSONAL SAFETY
3

11. Do not use this television set near water ... for example, near a bathtub, washbowl, kitchen sink, or laundry tub, in a
wet basement, or near a swimming pool, etc.
Never expose the set to rain or water. If the set has been exposed to rain or water, unplug the set from the wall
outlet and refer servicing to qualified service personnel.
12. Choose a place where light (artificial or sunlight) does not shine directly on the screen.
13. Avoid dusty places, since piling up of dust inside TV chassis may cause failure of the set when high humidity persists.
14. The set has slots, or openings in the cabinet for ventilation purposes, to provide reliable operation of the receiver, to
protect it from overheating. These openings must not be blocked or covered.
Never cover the slots or openings with cloth or other material.
Never block the bottom ventilation slots of the set by placing it on a bed, sofa, rug, etc.
Never place the set near or over a radiator or heat register.
Never place the set in enclosure, unless proper ventilation is provided.
15.1. If an outside antenna is connected to the television set, be sure the antenna system is grounded so as to provide some
protection against voltage surges and built up static charges, Section 810 of the National Electrical Code, NFPA No.
70-1975, provides information with respect to proper grounding of the mast and supporting structure, grounding of the
lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna discharge unit, connection
to grounding electrode, and requirements for the grounding electrode.
15.2. Note to CATV system installer : (Only for the television set with CATV reception)
This reminder is provided to call the CATV system attention to Article 820-40 of the NEC that provides
guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding
system of the building, as close to the point of cable entry as practical.
16. An outside antenna system should not be located in the vicinity of overhead power lines or other electric lights or power
circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care
should be taken to keep from touching such power lines or circuits as contact with them might be fatal.
17. For added protection for this television set during a lightning storm, or when it is left unattended and unused for long
periods of time, unplug it from the wall outlet and disconnect the antenna. This will prevent damage due to lightning
and power-line surges.
ANTENNA
LEAD- IN WIRE
ANTENNA DISCHARGE
UNIT (NEC SECTION
810-20)
GROUNDING
CONDUCTORS
(NEC SECTION810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250. PART H)
ELECTRIC SERVICE
EQUIPMENT
GROUND CLAMP
NEC-NATIONAL ELECTRICAL CODE
EXAMPLE OF ANTENNA GROUNDING AS PER
NATIONAL ELECTRICAL CODE
EXAMPLE OF ANTENNA GROUNDING AS PER NATIONAL ELECTRICAL CODE INSTRUCTIONS
a built-in
installer s
4
SCHNEIDER ELECTRONICS GMBH-GERMANY
PROTECTION AND LOCATION OF YOUR SET
PROTECTION AND LOCATION OF YOUR SET
4

18. This television set should be operated only from the type of power source indicated on the marking label.If you are not
sure of the type of power supply at your home, consult your television dealer or local power company. For television
sets designed to operate from battery power, refer to the operating instructions.
19. If the television set does not operate normally by following the operating instructions, unplug this television set from the
wall outlet and refer servicing to qualified service personnel. Adjust only those controls that are covered in the operating
instructions as improper adjustment of other controls may result in damage and will often require extensive work by a
qualified technician to restore the television set to normal operation.
20. When going on a holiday : If your television set is to remain unused for a period of time, for instance, when you go on
a holiday, turn the television set and unplug the television set from the wall outlet.
21. If you are unable to restorenormal operation by followingthe detailedprocedurein your operatinginstructions,
do not attempt any further adjustment. Unplug the set and call your dealer or service technician.
22. Whenever the television set is damaged or fails, or a distinct change in performance indicates a need for
service, unplug the set and have it checked by a professional service technician.
23. It is normal for some TV sets to make occasional snapping or popping sounds, particularly when being
turned on or off. If the snapping or popping is continuous or frequent, unplug the set and consult your
dealer or service technician.
24. Do not use attachments not recommendedby the television set manufacturer as they may cause hazards.
25. When replacement parts are required, be sure the service technicianhas used replacementparts specified
by the manufacturer that have the same characteristics as the original part. Unauthorized substitutions
may result in fire, electric shock, or other hazards.
26. Upon completion of any service or repairs to the television set, ask the service technician to perform
routine safety checks to determine that the television is in safe operating condition.
off
5
SCHNEIDER ELECTRONICS GMBH-GERMANY
OPERATION OF YOUR SET
IF THE SET DOES NOT OPERATE PROPERLY
FOR SERVICE AND MODIFICATION
5

Environment
Operation Temperature（℃） 0～45
Store Temperature（℃） -10~60
Humidity Operation Humidity（%）20~80％
Store Humidity（%）20~90%
Air Pressure（kps) 86～106
Screen Parameter
Screen Size 42“ Angle of View (H/V) 160°/160°
Max. Resolution 852 x 480 Responsive Time um
Ratio ■16:9 □4:3 Image Size(mm x mm) 1.08 × 1.08
Contrast ( Darkness,
Nakedness）3000:1 Warm：9300
Luminance of Peak
Value(cd/m²) 1000 Cool：11000
Colors Supporting 16.7 M Max. V. Frequency(Hz) TV: 60Hz / PC: 85Hz
Max. H. Frequency(Hz) TV:15.7kHz / PC: 69kHz
Color System(AV)
■PAL □PAL - M ■NTSC 3,58 ■SECAM
□PAL - N ■NTSC 4,43 Comb-Filter: ■NTSC ■PAL
PC Signal
■VGA ■SVGA ■XGA □WXGA
□SXGA □True XGA
SDTV /HDTV Signal
■VGA ■720×480p ■720×576p ■1280×720p ■1920×1080i
■Y/Pr/pb ■720×480p ■720×576p ■1280×720p ■1920×1080i
Antenna（RF）
■PAL DK ■PAL I ■PAL BG ■NTSC-M
■SECAM DK ■SECAM I ■SECAM BG □SECAM L
Special Features
□100 Hz Progressive Scan ■Black and White Mode ■Smart Picture ■DLTI
■50/60 Hz Progressive Scan □Child Lock ■MADA ■DCTI
■Black Stretch ■PIP (PC 、DVI Mode）■Picture Dynamic Reduce Noise ■Timer On/Off
■Color Temperature Adjustment
Stereo
■Nicam □MTS □FM-FM ■German Stereo
□BTSC
Program
□Program Auto Mark ■Program Compositor ■Channels: 99
■Auto Searching ■Manual Searching ■Tuning
2.Product Specification
Environment Temperature
Color Temperature(°K)
6

Teletext
Type: Pages:
Audio
□Insert SPK. ■Insert Amplifier ■Sound Effect ■AVC
■Output Power(W）： 2×8W □DVSS
■Sound Effect Adjustment：■Bass ■Treble ■Balance ■Others：Five Bands Equalizer
Display
OSD(2 languages)
Adjustment via OSD
■Contrast ■Chroma ■H/V - size（PC）□Picture Rotation
■Brightness ■Tint ■H/V - place （PC）
Connector
□Antenna Input
Video Terminal
■VGA Input（Type：D-15 Pins Quantity：1）□VGA Output（Type：Quantity：
■DVI Input Type：DVI-I 29Pins Quantity：1）■RS-232 (Type：D-9PIN Quantity: 1）
■S-Video Input (Quantity：1 ) □S-Video Output（Quantity: 1 )
□SCART（□Full SCART □Video Input □YUV Input □S-Video □RGB□Video Output）
□Others Video or （AV）Output or Input：□The port connected with MFB: 15PIN
Audio Connector
■Audio Input（■RCA 2 , 1 for CVBS; 1 for Component/PC □others）□Bass Output（Audio Jack）
■Audio OutputL/R（■RCA □Others：1 ）□Audio Output 5.1
□Audio Digital Coaxial（RCA）□Audio digital optical ■Speaker Output (Insert Amplifier)
Power Supply
Max. Power
Consumption(W）:300 Voltage（V/Hz）:110/220VAC 50/60 Hz
Standby Power
Consumption(W): <3 ■Switch on/off ■Auto stand-by（Timer：15 Min）
Accessories
■Remote Controller ■VGA line (Type：DB15 ）■Power Supply LIne（1.8 m) □Scart Line ( m)
□Multifunction Box ■Antenna (1.8 m) ■Speakers（Optional）■Stand（Optional）
■Bracket（Optional）
Packing
Unit Size(w×h×d, mm) 1057×662×82 Net Weight(kg) 28KG
Packing Size(w×h×d, mm) 1170×383×817 Gross Weight(kg) 35KG
English,Chinese
Plasma Multimedia Monitor
□BNC ■IEC □Others：
■Y/Pb/Pr (Y/Cb/Cr) input (■RCA □BNC Quantity：1）
■AV Input（■RCA □BNC Quantity：1 Note: input from Y port of Y/Cb/Cr ）
7

ITEM DESCRIPTION LOCATION QTY.
06-0Y0938-B004X ASS'Y-REMOTE HANDSET 1
11-0BC337-0BX TRANSISTOR (NPN) BC337-40 Q1501 1
13-18L901-SCB IC MX18L901SC U1501 1
14-IRE05B-XX0 IR EMITTING DIODE TSAL6200 D1501 1
19-BB0105-JTX SMD. RES 1M OHM 1/10W +/-5% 0805 R1502 1
19-BB0472-JTX SMD. RES 4.7K OHM 1/10W +/-5% R1501;R1506;R1507 3
19-BB0229-JTX SMD. RES 2.2 OHM 1/10W +/-5% R1504 1
28-BB0101-JCX SMD CAP. 100 PF 50V C 0805 C1501;C1502 2
28-BB0220-JCX SMD.CAP 22 PF 50V C 0805 C1503;C1504 2
28-BD0105-ZFX SMD CAP 1UF 25V +80-20% C1505 1
40-DP4221-RMB P.C.B. REMOTE HANDSET BD 1
41-WJ0050-B00 WIRE BARE JUMPER 5MM J1;J21 2
41-WJ0060-B00 WIRE BARE JUMPER 6MM J2;J3;J4 3
45-COS455-KY0 CERAMIC RESONATOR 455KHZ X1501 1
45-OSC32K-7Y0 CRYSTAL 32.768KHZ X1502 1
49-HS38Y0-00X01 RUBBER PAD KEYS 1
55-HS38YB-0HA02 YREMOTEHANDSET-BOTTOMCABINET 1
55-HS38YD-0HA02 YBATT.DOOR 1
55-HS38YT-0HA YREMOTEHANDSET-FRONTCABINET 1
56-HS38YL-0HH02 LENS 1
63-F20070-AB2 S/T SCREW F 2 X 7 2
67-906670-0A009 ALUMINIUM FRONT PANEL 1
67-X90673-0E2 SPRING (+) 1
67-X90674-0E2 SPRING (-) 1
67-X90675-0E2 SPRING (+/-) 1
74-007030-60C POLYBAG (7CMX30CM) 1
71-270870-0A9 LABEL 1
08-DP4226-AMY ASS'Y-AUDIO AMPLIFIER BOARD 1
09-FM5817-STX SMD.DIODE FM5817 D601;D602;D603;D604 4
09-LL4148-ATX SMD. SWITCHING DIODE LL4148 D605;D607;D608;D609 4
10-1N5820-F0X DIODE 1N5820 D610 1
11-SA1015-YBX TRANSISTOR ST2SA1015Y (PNP) Q601 1
13-0L7809-CVS IC L7809 SGS (TO-220) U604 1
13-LM2596-12B IC LM2596S-12 P+ U603 1
13-NJW114-2MB IC JRC-NJW1142 U602 1
13-TA2024-00B IC TA2024 U601 1
19-BB0000-JTX SMD. RES 0 OHM 1/10W +/-5% R620;R650;R651;R652;R653;C657;C658;C659 8
19-BB0101-JTX SMD. RES 100 OHM 1/10W +/-5% R609;R610 2
19-BB0102-JTX SMD. RES 1K OHM 1/10W +/-5% R614;R626 2
19-BB0103-JTX SMD. RES 10K OHM 1/10W +/-5% R613;R615;R617 3
19-BB0109-JTX SMD. RES 1 OHM 1/10W +/-5% 0805 R627;R628 2
19-BB0202-JTX SMD. RES 2K OHM 1/10W +/-5% 0805 R602;R603;R605;R607 4
19-BB0203-JTX SMD. RES 20K OHM 1/10W +/-5% R612;R616 2
19-BB0222-JTX SMD. RES 2.2K OHM 1/10W +/-5% R618 1
19-BB0223-JTX SMD. RES 22K OHM 1/10W +/-5% R604;R601;R606;R608;R622;R623;R624;R625 8
19-BB0822-JTX SMD. RES 8.2K OHM 1/10W +/-5% R611 1
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% C631 1
25-BFB229-M1X CAP. ELEC 2.2 UF 50V +/-20% C653 1
25-BDN221-M1X CAP. ELEC 220UF 25V +/-20% C637;C643;C648;C651 4
3. BOM LIST
8

ITEM DESCRIPTION LOCATION QTY.
25-BFA471-M1X CAP. ELEC 470 UF 50V +/-20% C652 1
25-HCB220-M1X CAP. ELEC 22 UF 16V +/-20% C614 1
25-HCB470-M1X CAP. ELEC 47 UF 16V +/-20% C649 1
28-BB0104-ZFX SMD CAP. 0.1 UF 50V +80/-20% 0805 C605;C606;C607;C608;C611;C619;C622;C623; C624;C625;C626;C627;C628;C629;C633;C635;
C636;C641;C642;C647;C650;C654;C655 23
28-BB0222-KBX SMD CAP 0.0022UF 50V +/-10% C601;C602;C603;C604;C610;C620 6
28-BB0223-ZFX SMD CAP. 0.022 UF 50V F 0805 C609;C621 2
28-BB0224-ZFX SMD. CAP 0.22UF 50V +80%/-20% 0805 C638;C639;C644;C645 4
28-BB0334-ZFX SMD. CAP 0.33UF 50V +80%/-20% C618 1
28-BB0474-ZFX SMD. CAP 0.47UF 50V +80% -20%C640;C646 2
28-BD0105-ZFX SMD CAP 1UF 25V +80-20% C612;C613;C615;C616;C617;C634 6
28-XC0225-MTX TANTALUM CAP. 2.2 UF 16V +/-20% C630;C632 2
33-GLN300-NTX CHIP BEAD 30 OHM +/-25% L608;L609;L606 3
33-SLL330-MTX FILTER SLF12565T-33M2R8 L607 1
34-R100K2-10X COIL CHOKE SG9006 10UH +/-20% L602;L603;L604;L605 4
36-371620-00X NETWORK FILTER NF0801 T1 1
36-WID450-XX0 COIL WIDTH 45UH L601 1
40-DP4226-AMB2X P.C.B. AM BD 1
46-39299H-04X HS 4P 1007#26 500 EI-4Y/SCN-4Y J3 1
46-39445H-04X HS 4P 2547#24 200MM TJC3-4Y/SCN-4Y J2 1
46-CD015T-08L HS 8P 2547#24 150MM J1 1
47-SPK015-XX0 SOCKET WP4-4C J5 1
08-P42U3H-ANY ASS'Y-ANALOG BOARD 1
07-380FI5-NB3 TUNER TEDE9-289A TU1 1
09-0BA982-ATX SMD.DIODE BA982-GS08 D131 1
09-0BAV99-ATX HIGH SPEED DOUBLE DIODE BAV99 D102 1
09-55C33V-DTX SMD.DIODE BZV55-C33 D101 1
09-LL4148-ATX SMD. SWITCHING DIODE LL4148 D001;D002;D003;D004;D005;D006;D007;D008 8
09-RLZ8B2-DTX SMD. ZENER DIODE RLZ8.2B D904;D905;D906;D910 4
10-1N4001-EBX DIODE 1N4001 (RECTIFIER) D802 1
11-SC3779-DBX TRANSISTOR 2SC3779D (RF AMPL) Q121 1
12-BC846B-0BX TRANSISTOR BC846B Q111 1
12-BC847A-0BX SMD TRANSISTOR BC847A (NPN) Q131;Q202;Q203;Q204;Q205;Q206;Q263;Q271; Q272;Q281;Q902;Q905;Q906;Q912;Q913;Q914;
Q916;Q917 18
12-BC857A-0BX SMD TRANSISTOR BC857A (PNP) Q261;Q262 2
12-SK2158-0BX TRANSISTOR 2SK2158 Q012;Q013 2
13-0TDA91-78P IC TDA9178 IC202 1
13-00M24C-08B IC EEPROM 8K M24C08 IC003 1
13-0L7805-CVS +5V 1.5A IC L7805CV IC802 1
13-L7808C-D2B IC L7808CD2T-TR IC801 1
13-PT7825-MTB IC PTTM7825MT（5V）IC002 1
13-MSP341-0TB IC MSP3410G(64PINS) IC204 1
13-TDA918-1TB IC SM TDA9181T/N1 (PHSE) R IC203 1
13-TDA932-1HB IC SM TDA9321H/N2 (PHSE) R IC201 1
13-V212MV-64B IC MTV212MV64I MCU (WRITE) IC001 1
18-FH0120-JLX RES. M.O. 12 OHM 3W +/-5% R801 1
19-AA0000-FTX SMD. RES 0 OHM 1/16W +/-1% 0603 R109;R140;R220;R224;R232;R238 6
19-AA0101-JTX RES. SMD 100 OHM 1/16W +/-5% R016;R019;R020;R021;R026;R031;R032;R106; R107;R206;R207;R028;R212;R216;R217;R218;
R288;R284;R285;RN1;RN2 21
9

ITEM DESCRIPTION LOCATION QTY.
19-AA0102-JTX RES. SMD 1K OHM 1/16W +/-5% R111;R112;R123;R137;R139;R225;R233;R239; R243;R246;R262;R273;R282;R907;R928;R931;
R960;R965;R966;R971;R972;R973;R974 23
19-AA0103-JTX RES. SMD 10K OHM 1/16W +/-5% R010;R011;R012;R013;R015;R027;R079;R080;
R134;R213;R214;R215;R906;R927;R930;RN13 16
19-AA0473-JTX RES.SMD 47K 1/16W 0603 +/-5% R017;R014;R272 3
19-AA0104-JTX RES. SMD 100K OHM 1/16W +/-5% R110;R954;R958;R208 4
19-AA0151-JTX SMD RES. 150 OHM 1/16W +/-5% R122 1
19-AA0153-JTX RES.SMD 15K 1/16W 0603 +/-5% R209 1
19-AA0182-JTX SMD. RES 1.8K OHM 1/16W +/-5% 0603 R133 1
19-AA0222-JTX RES. SMD 2.2K OHM 1/16W +/-5% R132;RN10;RN11;RN7;RN8 5
19-AA0223-JTX RES.SMD 22K 1/16W 0603 +/-5% R135;R138;R271;R905;R926;R929 6
19-AA0224-JTX SMD. RES 220K OHM 1/16W +/-5% 0603 R963 1
19-AA0274-JTX RES.SMD 270K OHM 1/16W 5% R103 1
19-AA0301-JTX RES.SMD 300 OHM 1/16W +/-5% 0603 R245;R270 2
19-AA0330-JTX RES. SMD 33 OHM 1/16W +/-5% R124 1
19-AA0331-JTX RES. SMD 330 OHM 1/16W +/-5% R210;R211;R237;R265;R266;R268;R269 7
19-AA0332-JTX RES. SMD 3.3K OHM 1/16W +/-5% R263;R919;R922 3
19-AA0391-JTX RES.SMD 390 OHM 1/16W +/-5% 0603 R231;R261 2
19-AA0471-JTX RES. SMD 470 OHM 1/16W +/-5% R125;R230;R236;R275;R281;R939;R961;R964;
R967;R975 10
19-AA0472-JTX RES. SMD 4.7K OHM 1/16W +/-5% R029;R030;R033;R034 4
19-AA0560-JTX SMD RES. 56 OHM 1/16W +/-5% R121 1
19-AA0561-JTX RES SMD 560OHM 1/16W +/-5% R264;R267 2
19-AA0680-JTX RES. SMD 68 OHM 1/16W +/-5% R962 1
19-AA0682-JTX SMD. RES 6.8K 1/16W +/-5% 0603 R131;R920;R923 3
19-AA0820-JTX SMD. RES 82 OHM 1/16W +/-5% 0603 R904;R924;R925 3
19-BB0000-FTX SMD. RES O OHM 1/10W +/-1% R0001;R0002;R0003;R0004;R0005;R0006;
R0007;R0008;R0009;R0010;R0011;R0012; R0013 13
25-BDA471-M1X CAP. ELEC 470 UF 25V +/-20% C804 1
27-MBC104-J0X CAP. M.P.E 0.1 UF 63V +/-5% C226;C228;C263 3
27-PBC472-J0X CAP. P.E 0.0047UF 63V +/-5% C227 1
27-PBC682-J0X CAP. P.E 0.0068UF 63V +/-5% C233 1
28-AB0102-KBX SMD. CAP 1000 PF 50V +/-10% B C924;C925;C928;C930 4
28-AB0103-ZFX CAP.SMD 10NF 50V +80-20% 0603
C012;C013;C015;C044;C103;C106;C112;C122;
C131;C132;C133;C135;C202;C208;C214;C215;
C224;C230;C235;C236;C239;C242;C244;C265;
C285;C288;C802;C907;CN1;CN15;CN26;CN29;
CN30;CN33;C121
35
28-AB0104-ZFX CAP. SMD 0.1UF 50V +80%~-20% F C021;C110;C111;C136;C212;C216;C217;C238; C267;C281;C805;C909;C927;C933;C936;C938;
CN16;CN24;C807 19
28-AB0180-JCX SMD. CAP 18 PF 50V +/-5% 0603 C229;C232 2
28-AB0201-JCX CAP.SMD 200PF 50V +/-5% 0603 C109 1
28-AB0271-JCX SMD. CAP 270 PF 50V +/-5% C C108 1
28-AB0300-JCX SMD CAP. 30 PF 50V +/-5% 0603 C016;C017 2
28-AB0331-JCX SMD. CAP 330 PF 50V +/-5% 0603 C282 1
28-AB0339-JCX SMD.CAP. 50V 3.3PF +/-5% CN31;CN32 2
28-AB0472-KBX CAP.SMD 4700PF 50V +/-10% 0603 C113;CN6;CN7;CN9;CN10 5
28-AB0560-JCX SMD CAP. 56 PF 50V +/-5% 0603 CN28 1
28-AC0105-ZFX SMD. CAP 1 UF 16VDC +80%/-20% C018 1
28-AD0474-ZFX SMD. CAP 0.47 UF 25V +80/-20% C205;C207;C213;C266;C269;C287 6
28-RC0105-MAH SMD. CAP 1 UF 16V +/-20% C234;C107 2
10

ITEM DESCRIPTION LOCATION QTY.
28-RC0106-MAH SMD. CAP 10 UF 16V +/-20% C231;C241;C243;C280;C910;C926;C934;C935;
C937;CN11;CN12;CN22;CN23;CN25 14
28-RC0107-MAH SMD. CAP 100 UF 16V +/-20% C803 1
28-RC0225-MAH SMD. CAP 2.2 UF 16V +/-20% C261 1
28-RC0226-MAH SMD. CAP 22 UF 16V +/-20% C902;C908;C911;C922;C931;C932 6
28-RC0335-MAH SMD. CAP 3.3 UF 16V +/-20% CN17 1
28-RC0475-MAH SMD. CAP 4.7 UF 16V +/-20% C101 1
28-RC0476-MAH1 SMD. CAP 47 UF 16V +/-20% C014;C102;C201;C225;C240;CN14;CN2;C806 8
28-XC0225-MTX TANTALUM CAP. 2.2 UF 16V +/-20% C262 1
33-DLL220-KTX SMD. INDUCTOR 22 UH +/-10% 3225 L201;L203;L204;L205 4
33-ELL109-KTX SMD.COLL MGFI2012CIROKT L121 1
33-ELM100-KTX SMD. COIL 10UH +/-10% 0805 L105;L208;L209;L903;L904;L905;L906;L907 8
33-GLN121-NTX CHIP BEAD 120 OHM +/-25% FB1;FB2 2
33-GLN301-NTX CHIP BEAD 300 OHM +/-25% LN1;LN2;LN3 3
33-MLL101-MTX SMD. COIL 100 UH L001;L101 2
34-A100K0-1IX COIL CHOKE 10 UH +/-10% L261 1
34-R102K7-0EX COIL 1000 UH +/-10% L102;L103 2
34-R220J2-0EX COIL PL - 22 UH +/-5% L202 1
34-R220K2-1BX COIL CHOKE 22 UH +/-10% L801 1
38-350980-00X COIL I.F.T. 350980 FOR VCO T201 1
40-DP42U3-MAC4X P.C.B. BD 1
45-FIL4M5-0Y1 CERAMIC FILTER SFSH4.5MDB Z262 1
45-FIL5M5-0Y1 CER FILTER 5.5MHZ Z261 1
45-OSC12M-0Y2 CRYSTAL 12.0MHZ X010 1
45-OSC18M-4Y0 CRYSTAL 18.432M XN1 1
45-OSC3M5-8N0 CRYSTAL 3.58MHZ (CL=20PF) X204 1
45-OSC4M4-3N0 CRYSTAL 4.43MHZ (CL=20PF) X201 1
45-SAW376-0K0 SAW FILTER K3760K SAW1 1
46-CD040T-04B HS 4P 1007#24/1185#26 400MM TJC3-4Y JP2 1
46-FG010F-10001 HS 10P 2854#26 100MM PH-10Y/SAN-10Y JP3 1
46-FG040T-04G HS 4P 1185#26 400MM PH-4Y/SAN-4Y JP1 1
47-RCA111-HX0 3P RCA SOCKET AV-3.2-3W-X3 P901;P903 2
47-SVI008-XX0 S_VIDEO TERMINATOR P902 1
71-AV0000-T02 BARCODE LABEL 1
08-P42U3H-DIY ASS'Y-DIGITAL BOARD 1
09-0BAV99-ATX HIGH SPEED DOUBLE DIODE BAV99 D4;D5;D6;D7;D8;D12;D13;D14;D15 9
09-LL4148-ATX SMD. SWITCHING DIODE LL4148 D17;D18 2
09-RLZ5B6-DTX SMD DIODE RLZ5.6BTE11 D1;D2;D3;D9;D10;D11 6
12-BC847A-0BX SMD TRANSISTOR BC847A (NPN) Q7;Q18;Q001;Q002;Q003;Q19 6
12-BT3904-0BX SMD. TRANSISTOR MMBT3904LT1(NPN) Q1;Q2;Q3;Q4;Q5;Q6 6
12-SK3019-0BX SMD. TRANSISTOR 2SK3019 Q13;Q14;Q15;Q16 4
13-024LC1-6BB IC 24LC16B U29 1
13-024LC2-1AP IC 24LC21A (WRITE) U27;U16 2
13-LD1117-18B 1.8V REGULATOR IC LD1117S18TR U40 1
13-643220-T6B IC HY57V643220C(L)T-6 U13;U20;U21 3
13-89C205-12P IC AT89C2051-24PI(DIP) (WRITE) U35 1
13-BGA388-00B IC BGA388 U18 1
13-TFP401-APB IC TFP401APZP U26 1
13-63LVDM-83B IC THC63LVDM83R U44 1
13-EF4052-BTB IC HEF4052BT(D) U8 1
13-F040PC-90P IC 4M MX29F040PC-70(WRITE) U34 1
11

ITEM DESCRIPTION LOCATION QTY.
13-FLI230-00B IC FLI2300-BD U12 1
13-IC1084-CMB IC AIC1084-33CM 3.3V (TO-263) U37 1
13-0L7805-CVS +5V 1.5A IC L7805CV U36 1
13-LD1117-25B 2.5V REGULATOR IC LD1117S25(SOT-223) U41 1
13-LD1117-33B IC LD1117 3.3V U39;U42 2
13-ST232C-D0B IC ST232CD(SOP) U43 1
13-PT7825-MTB IC PTTM7825MT（5V）U30 1
13-PT7825-STB IC PTTM7825ST( 3.3V) U19 1
13-P80C32-UBB IC P80C32UBA(PLCC44) U31 1
13-PI5V33-0QB IC PI5V330Q (QSOP) U10 1
13-RT9172-N25 IC RT9172N-25CM5 U38 1
13-SN74AH-C1B IC SN74AHC139DR U32 1
13-SN74HC-14B IC SN74HC14D-SOP14 U3 1
13-SN74HC-37B IC SN74HC373 U33 1
13-T9883B-11B IC MST9883B110 U11 1
13-TB1274-BFBG IC TB1274BFG U4 1
15-LED20R-XX0 CHIP LED HMF0805POM-BR1 D22 1
18-FH0479-JLX RES. M.O. 4.7 OHM 3W +/-5% R335 1
18-FH0689-JLX RES.M.O. 3W 6.8 OHM +/-5% R336 1
19-BB0000-JTX SMD. RES 0 OHM 1/10W +/-5%
L16;R124;R125;RS1;0RS1;RS2;R12;0R12;R17;
0R19;R41;R72;R73;R74;R75;R76;R77;R78;
R79;R80;R81;R83;R85;R87;R89;R110;R111;
R112; R113;R175;R176;R188;R227;R228;R281;
R285; MR1;MR3;MR4;MR5;MR6;MR7;MR8;0R3;
R327; R328;R329;R282;R283;R284;R008;R010;
R012; R212;R117;R119;R121;R48;OR15;R123
60
19-BB0100-JTX RES. SMD 10 OHM 1/10W +/-5% 0R4;0R5;0R6;0R8;0R9;0R21;R108;R151;R152; R153;R154;R155;R179;R180;R181;R182;R184;
R114 18
19-BB0101-JTX SMD. RES 100 OHM 1/10W +/-5% R25;R26;R27;R28;R29;R45;R47;R49;R50;
R127;R128;R130;R132 13
19-BB0102-JTX SMD. RES 1K OHM 1/10W +/-5% R330;R5;R14;0R17;R20;R44;R3;R8;R13 9
19-BB0103-JTX SMD. RES 10K OHM 1/10W +/-5%
R11;R38;R42;R91;R94;R98;R135;R136;R145;
R146;R147;R157;R159;R161;R165;R167;R178;
R225;R235;R242;R243;R244;R245;R246;R247;
R248;R249;R250;R251;R252;R253;R254;R257;
R258;R260;R261;R1;R18;R21;R30;R018;R325;
R326
43
19-BB0104-JTX SMD. RES 100K OHM 1/10W +/-5% 0805 R226;R158 2
19-BB0121-JTX SMD. RES 120 OHM 1/10W +/-5% R2;R10;R95;R255;R256;R259;R262 7
19-BB0151-JTX RES. SMD 150 OHM 1/10W +/-5% R99;R100;R96;R97;R104 5
19-BB0220-JTX SMD. RES 22 OHM 1/10W +/-5%
R92;R93;R101;R102;R103;R150;R160;R162;
R163;R164;R166;R168;R169;R170;R171;R172;
R173;R174;R177;R185;R196;R287;R288;R319;
R320;R014;R331;R332;R333;R334
30
19-BB0272-JTX SMD. RES 2.7K OHM 1/10W +/-5% R52;R90 2
19-BB0273-JTX SMD. RES 27K OHM 1/10W +/-5% R40 1
19-BB0330-JTX SMD. RES 33 OHM 1/10W +/-5% 0805 R7 1
19-BB0332-JTX SMD. RES 3.3K OHM 1/10W +/-5% R4;R19;R23;R34;R37 5
19-BB0391-JTX RES. SMD 390 OHM 1/10W +/-5% R195 1
19-BB0470-JTX SMD. RES 47 OHM 1/10W +/-5% R183 1
19-BB0471-JTX SMD. RES 470 OHM 1/10W +/-5% R24;R35;R39;R46;R116;R300;R009;R011;R013 9
19-BB0472-JTX SMD. RES 4.7K OHM 1/10W +/-5% R6;R9;R31;R32;R187;R189;R191;R192;R193;R19 9;R201;R229;R230;R231;R232;R233;R234;R236;
R237;R238;R239;R240;R241;R131 24
12

ITEM DESCRIPTION LOCATION QTY.
19-BB0473-JTX SMD. RES 47K OHM 1/10W +/-5% 0805 R105;R156;R224 3
19-BB0682-JTX SMD. RES 6.8K OHM 1/10W +/-5% R51 1
19-BB0750-JTX SMD. RES 75 OHM 1/10W +/-5% R22;R33;R36;R118;R120;R122 6
23-A08220-JBX NETWORK RES. 22 OHM +/-5%
RP1;RP2;RP3;RP4;RP5;RP6;RP7;RP8;RP11;
RP12;RP13;RP15;RP17;RP25;RP26;RP27;
RP28;RP29;RP37;RP38;RP39;RP40;RP41;
RP42;RP24;RP007;RP008;RP009;RP010;
RP011;RP012
31
27-PBC103-J0X CAP. P.E. 0.01UF 63V +/-5% C25 1
27-PBC222-J0X CAP. P.E 0.0022UF 63V +/-5% C31 1
28-BB0100-JCX SMD. CAP. 10PF 50V +/-5% C116;C118;C197 3
28-BB0101-JCX SMD CAP. 100 PF 50V C 0805 C6;C11;C12;C13;C187;C188;C287;C288;C289;
C290;C292 11
28-BB0102-KBX SMD CAP. 0.001UF 50V B 0805 C101;C196;C198;C199;C204;C205;C207;C221 8
28-BB0103-ZFX SMD CAP. 0.01 UF 50V F 0805 C22;C38;C41;C44;C298;C299;C300;C301;
C302;C397;C399;C011 12
28-BB0104-ZFX SMD CAP. 0.1 UF 50V +80/-20% 0805
C271;C272;C273;C274;C275;C285;C293;C294;
C295;C297;C322;C331;C333;C334;C340;C342;
C345;C347;C350;C352;C356;C358;C364;C365;
C366;C367;C003;C337;C338;C383;C384;C386;
C387; C382;C394;C398;CS1;C385;CS2;C002;
CS4; C004;C005;C006;C007;C18;C19;C21;C27;
C28; C29;C30;C32;C35;C78;C82;C84;C89;C90;
C92;C93;C94;C95;C96;C107;C108;C109;C110;
C111;C112;C113;C114;C115;C119;C123;C125;
C127;C129;C130;C131;C132;C133;C134;C135;
C136;C137;C138;C139;C140;C141;C142;C143;
C147;C148;C149;C150;C151;C152;C153;C154;
C155;C156;C157;C158;C159;C160;C161;C162;
C164;C165;C166;C167;C168;C169;C170;C171;
C172;C173;C174;C175;C193;C200;C201;C202;
C203;C209;C210;C212;C213;C215;C217;C219;
C222;C223;C224;C226;C227;C228;C229;C230;
C231;C232;C234;C235;C236;C237;C238;C239;
C240;C241;C242;C243;C244;C245;C246;C247;
C248;C249;C250;C251;C252;C253;C254;C255;
C258;C259;C260;C261;C262;C263;C264;C265;
C266;C267;C268;C269;C270;CS3
178
28-BB0120-JCX SMD. CAP 12 PF 50VDC +/-5% C324;C325;C328;C329 4
28-BB0180-JCX SMD. CAP 18 PF 50V +/-5% C284 1
28-BB0200-JCX SMD. CAP 20 PF 50V +/-5% C117 1
28-BB0220-JCX SMD.CAP 22 PF 50V C 0805 C281;C282;C283 3
28-BB0272-KBX SMD. CAP 2700PF 50V +/-10% C373 1
28-BB0330-JCX SMD.CAP 33 PF 50V C 0805 C121;C122 2
28-BB0331-JCX SMD. CAP 330 PF 50V C 0805 C9;C3 2
28-BB0470-JCX SMD CAP. 47 PF 50V C 0805 C34;C36;C88;C91 4
28-BB0473-ZFX SMD. CAP 0.047UF 50V +80% -20%C97;C100;C104 3
28-BB0479-JCX SMD. CAP 4.7 PF 50V +/-5% C2;C5;C8;C23;C102;C105 6
28-BB0561-JCX SMD. CAP 560PF 50V +/-5% 0805 C103 1
28-BB0822-KBX CAP.SMD 8200PF 50V +/-10 0805 C87 1
28-BB0823-ZFX CAP.SMD 0.082UF 50V 80-20 0805 C85 1
28-BD0105-ZFX SMD CAP 1UF 25V +80-20% C233;C323 2
28-CC0476-MTX TANTALUM CAP. 47 UF 16V +/-20% 6032 C1;C4;C7;C20;C144;C145;C330;C335;C346;
C39;C42;C339 12
28-DC0107-MTX TANTALUM CAP. 100 UF 16VDC +/-20% C37;C128;C146;C326;C327;C344 6
28-RD0477-MAZ ALUMINIUM CAP. 470 UF 25V +/-20% C40;C43;C336 3
13

ITEM DESCRIPTION LOCATION QTY.
28-XC0106-MTX TANTALUM CAP.10 UF 16V +/-20%
C10;C14;C15;C77;C81;C120;C124;C126;C206;
C218;C220;C225;C286;C291;C296;C332;C341;
C343;C348;C349;C351;C353;C354;C355;C357;
C359;C360;C361;C362;C363;C163;C396;C395;
C010;C391
35
28-XC0225-MTX TANTALUM CAP. 2.2 UF 16V +/-20% C33 1
28-XC0226-MTX SMD. CAP 22 UF 16V +/-20% C83;C211;C214;C256;C257 5
28-XC0475-MTX TANTALUM CAP. 4.7 UF 16V +/-20% B C26;C208;C216 3
28-YC0474-MTX SMD.CAP. 0.47UF 16V +/-20% C24 1
33-ELL339-KTX SMD. COIL 3.3 UH +/-10% 0805 L1;L2;L3;L13;L15;L17;L18 7
33-ELN190-NTX CHIP BEAD 19 OHM +/-25% L26;L27;L23 3
33-ELN201-NTX CHIP BEAD 200 OHM +/-25%
FB1;FB001;FB2;FB002;FB3;FB003;FB9;FB11;
FB12;FB13;FB14;FB16;FB21;FB22;FB23;FB25;
FB26;FB28;FB29;FB31;FB32;FB33;FB34;FB35;
FB41;FB43;FB44;FB49;FB50;FB51;FB52;FB53;
FB54;FB55;FB56;FB57;FB58;FB59;FB301;FB302;
FB303;FB304
42
33-GLN190-NTX CHIP BEAD 19 OHM +/-25% (3216) L4;L5;L6;L7;L21;L28 6
40-P4226W-DIC6X P.C.B. DIGITAL 1
45-OSC13M-5Y0 CRYSTAL 13.5MHZ (SHORT FEET) X1 1
45-OSC14M-3N0 CRYSTAL 14.318MHZ U17 1
45-OSC16M-2Y0 CRYSTAL JAS16T 16.2M Y1 1
45-OSC24M-5N0 CRYSTAL 24.576 MHZ Y3 1
45-OSC27M-0Y3 CRYSTAL 27MHZ Y2 1
46-0D018F-07B01 HS 7P 1007#26 180MM EI-7Y/SCN-7Y J2 1
46-33079W-04X PIN BASE *4 TJC3-4A J6;P3;CN002 3
46-33079W-05X PIN BASE *5 TJC3-5A J8 1
46-33079W-06X PIN BASE *6 TJC3-6A J7 1
46-33079W-08X PIN BASE *8 TJC3-8A J5 1
46-35199W-04X CONN.PH-4A 4PIN PITCH=2.0MM CN003 1
46-35199W-05X CONN.PH-5A 5PIN PITCH=2.0MM P7 1
46-35199W-10X CONN. PH-10 10PIN PITCH=2.0MM CN001 1
46-39297H-12X HS 12P 1007#26 200 SCN-12Y P8 1
46-39519W-30X 30PIN BASE DF13-30DP-1.25V JH3 1
46-39539H-30X 30PIN TO 31PIN LVDS 500MM 1
47-DVI001-KX0 DVI SOCKET KL-DIV024-04A P6 1
47-ICS003-XX0 IC JACK FOR U34 1
47-RCA109-HX0 3P RCA SOCKET AV-3.2-3W-X1(R/B/G) P2 1
47-RCA123-XX0 RCA SOCKET AV-3.2-2W-G6 J4 1
47-VGA002-XX0 VGA JACKET D-SUB-15WP P4 1
47-VGA008-KX0 VGA SOCKET KL-PC09M-02 (FEMALE) JDP1 1
48-TAC001-XX0 TACT SWITCH SW1 1
67-387190-0A0 HEAT SINK FOR U18;FOR U12 2
67-387190-1A0 HEAT SINK FOR U13;FOR U20;FOR U21 3
67-387200-1A0 HEAT SINK FOR U11 1
67-387200-3A0 HEAT SINK FOR U4 1
71-AV0000-T02 BARCODE LABEL 1
08-P42U3H-DP2 ASS'Y-DISPLAY PART2 1
35-FB0101-00X FERR BEAD 1
35-FB0133-00X FERR. BEAD ZCAT3035-1330 1
4A-OPT42P-MS1 42"OPTICS FILTER 1
54-700150-000 SP0NGE BAR 2
54-807990-0U0 SPONGE 2
14

ITEM DESCRIPTION LOCATION QTY.
54-703860-2U0 SP0NGE BAR 2
54-703860-9U0 SP0NGE BAR 1
54-708640-0U0 PVC INLAY 1
54-710460-0U0 SPONGE (2MMX10MMX960MM) 2
54-710470-0U0 SPONGE (2MMX10MMX555MM) 2
54-714150-0U0 SPONGE 1
54-714170-0U0 INSULATION BOARD 1
54-714370-0U0 PVC TRANSPARENT INLAY 1
54-714380-1U0 SP0NGE BAR 1
54-714490-0U0 PC SCREW POST 4
54-715620-0U0 SPONGE 960X8X4 MM FOR UP & LOW SUPPORT 2
54-715620-1U0 SPONGE 520X8X4 FOR LEFT & RIGHT SUPPORT 2
54-716070-0U0 CONDUCTIVE FABRIC 35X50 4
54-716080-0U0 CONDUCTIVE FABRIC 2
54-804100-0U0 SP0NGE BAR RBCC3802-240-A 1
54-804110-0U0 SP0NGE BAR KRCF-002-15050 1
55-705160-1CN01 FORNT PANEL 1
56-4226PK-0HA02 POWER BUTTON 1
56-4226SL-0HC01 LENS 1
56-700090-1HA01 PUSH BUTTON 1
58-4U3HMP-JKTZ1 PLATE MODEL NO. 1
58-715610-1UI01 PVC 1
63-B30060-BF3 S/T SCREW B 3.0 X 6 BF MTG LED & FRONT FRAME 1
63-B30080-BT2 S/T SCREW B 3 X 8 BT
MTG BUTTON & M.FRAME;MTG COMTROL BD
& M.FRAME;MTG LED BD & M.FRAME;MTG
POWER BD & F.FRAME;MTG TERMINAL &
TERMINAL PLATE
19
63-T40160-BF2 S/T SCREW T 4 X 16 BF MTG MODULE & FRONT FRAME;MTG B.COVER & M.FRAME;MTG MODULE & FRONT
FRAME;MTG B.DISPLAY & MAIN SPEAKER 34
63-W30080-BT4 S/T SCREW W 3 X 8 BT MTG SUPPORTS & F.PANEL 26
64-B30080-104 M/C SCREW B 3 X 8 MTG TERMINAL & T.PLATE 2
64-B30100-104 M/C SCREW B 3 X 10 MTG SHIELD COVER & PCB BD BRACKET 3
64-Z30080-104 M/C SCREW 3.0 X 8 FOR DIGITAL BD/ ANY BD/ AMY BD 10
64-B30140-304 TRIANGLE M/C SCREW B 3 X 14 3
64-B40080-102 M/C SCREW B 4 X 8 MTG COVER & MAIN SUPPORTS 9
64-B40150-104 M/C SCREW B 4 X 15 MTG PCB BD BRACKET & MODULE 3
64-B50120-102 M/C SCREW B 5 X 12 MTG MODULE & SUPPORT 4
64-F30080-103 M/C SCERW F 3 X 8 MTG POWER & TERMINAL PLATE 2
64-S40080-104 M/C SCREW S 4 X 8 1
66-702620-0E2 SCREW POST FOR TERMINAL 2
67-715630-0B0 COPPERING 1
67-M70484-0A0 BRACKET "UP" 1
67-M70485-3A0 BRACKET "LOWER" 1
67-M70486-1A0 IRON BRACKET 2
67-M70515-2G0 MODULE LEFT BRACKET 1
67-M70515-3G0 MODULE RIGHT BRACKET 1
67-M71382-1A0 BRACKET 1
67-P70522-1A904 REAR BOARD 1
67-P70523-2A901 END SOM BOARD 1
67-S70634-0E7 SCREEN CAN 1
67-S70635-0E7 SCREEN CAN 1
15

ITEM DESCRIPTION LOCATION QTY.
67-S70636-0E7 SCREEN CAN 1
67-S71383-0E0 SHIELD CAN 1
67-S71384-0E7 SHIELD BOX (TOP) 1
57-10654X-00F TWIST TIE NY66 2
46-CC060F-06M01 5P UL2547#26 600MM 1
54-807980-0U0 SPONGE 2
54-808000-0U0 SPONGE 1
08-P42U3H-DP3 ASS'Y-PACKING PART+B380 1
41-UK3000-0JM EARPHONE SOCKET CHANGE RCA LINE 1
41-VK1800-9UU RF. LINE OF PIN 1800 +/-50MM 1
46-39286V-15X SIGNAL LINE 1
49-204260-BAT 7# BATT. UM4 R03P SIZE AAA 2
51-GC0180-0JG POWER CORD L=1800MM 1
58-PVC001-0UI INLAY HOLDER DOOR 2
70-271510-00A SERVICE CARD 1
70-PDP000-B01 WARRANTY CARD 1
70-PDP000-W01 SERVICE INDEX 1
71-270870-0A9 LABEL 2
71-BAR002-XX0 BAR CODE LABEL 1
71-DDHD00-X02 LABEL 1
71-DYP000-TZ1 HEAT SINK LABEL 1
71-TV0000-H03 PASS CARD 1
71-YSTZ00-111 WARNING LABEL 2
71-ZGMP00-Z11 LABEL 1
72-P42U3H-003 OPERATION MANUAL 1
74-022032-6WE POLYBAG (23CMX34CMX0.06MM) 2
74-165110-20H EPE+PO 1
75-42U3BT-CC0 POLYFOAM "BT" 1
75-42U3TP-CC0 POLYFOAM"TP" 1
76-P42U3H-1AT00 CARTON BOX 1
71-268390-0A0AF LABEL (QC) GREEN 3
08-P42U3H-IRY ASS'Y-IR RECEIVER BOARD 1
02-IRR009-XX0 IR RECEIVER MODULE AT138AT-07 IR001 1
11-SC1815-YBX TRANSISTOR 2SC1815-Y (NPN) Q001;Q002 2
14-LED03D-XX0 RED/BLUE LED BT-H603RBW-31 D001 1
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% R001;R002;R003;R004 4
25-BCB470-M1X CAP. ELEC 47 UF 16V +/-20% C002 1
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F C001 1
34-A100K0-1IX COIL CHOKE 10 UH +/-10% L001 1
40-P4226H-IRA0X P.C.B. IR RECEIVE BD 1
41-WJ0075-B00 WIRE BARE JUMPER 7.5MM J001;J002 2
46-CE040F-05001 HS 5P 2468#24/1185#26 400MM TJC3-5Y P002 1
08-P42U3H-KBY ASS'Y-KEYPAD BOARD 1
10-HS5V1B-DBX DIODE 500MW 5.1HSB Z001;Z002;Z003;Z004 4
18-CB0471-JNX RES. C.F. 470 OHM 1/6W +/-5% R001;R002;R003;R004 4
40-P42U3H-KEA1X P.C.B KEY BD 1
46-33079W-05X PIN BASE *5 TJC3-5A P001 1
48-TAC002-XX0 TACT SWITCH SW001;SW002;SW003;SW004 4
08-P42U3H-SWY ASS'Y-SWITCH BOARD 1
40-DP4226-SWC1X P.C.B. SWITCH BD 1
46-39210W-02X01 2PIN AMP BASE HORIZONTAL P801;P802 2
16

ITEM DESCRIPTION LOCATION QTY.
46-39317H-02X01 HS 2P 1617#18 450MM 2
48-POW001-XX0 SWITCH POWER KDC-A11 B2 SW800 1
57-702240-0UG NYLON RIVET 2
64-B30060-103 M/C SCREW B 3 X 6 2
67-M70527-0G0 SWITCH BRACKET 1
4A-SCR42P-LG4 PDP 42" KK MODULE PDP42V69001 1
V8-PU3H00-01D01 SOFTWARE CODE FOR U16 1
V8-PU3H00-01D02 SOFTWARE CODE FOR U27 1
V8-PU3H00-01M02 SOFTWARE CODE FOR U35 1
V8-PU3H00-01M01 SOFTWARE CODE FOR IC001 1
V8-PU3H00-02F01 SOFTWARE CODE FOR U34 1
17

4. Alignment Procedure
Flowchart of alignment procedure:
Voltage
adjustment White balance
Adjustment
VCO and AGC
adjustment
ALIGNMENT PROCEDURE:
D-mode:
1) Press “◀” key to reduce the volume to 0 and press “MUTE” key, then press “9”, “7”,
“3”, “5”” continually to enter the factory mode.
2) Press ▼/▲to select item ,press ◀/▶to change the settings.
3) Press “RECALL” key to quit.
After entering D-mode , you can adjust the settings:
Press “1” to enter Page1
Item Description Default data
STAND-BY 0:work directly; 1:Stand-by after power on 1
LOGO 0: LOGO off; 1: LOGO on 1
FACT-KEY 0: Enter D-mode as above;
1: Enter D-mode directly by pressing RECALL button. * 0
BKEY-LK 1: Lock the panel button. 0
TV-FREEZ 1: Image freezes when switching TV channel. 0
E2P-INIT Press “▶” key to initialize the data of E2PROM. NO
SCR-SAVE 1: Display a white pattern to clear the image remains. * 0
TIMELOCK 1: Enable the ON/OFF timer. 0
Press “2” to enter Page2: White Balance adjustment menu
Item Description Default data Default data Default data
RGB MODE AV MODE YPbPr
MODE
RCUT-9K3 Red cutoff at 9300k 225 249 208
GCUT-9K3 Green cutoff at 9300k 205 247 239
BCUT-9K3 BLUE cut off at 9300K 200 245 240
RGAIN-93 RED drive at 9300K 15 95 95
GGAIN-93 Green drive at 9300K 15 91 95
BGAIN-93 Blue drive at 9300K 15 100 100
RCUT-11K Red cutoff at 11000k 224 249 209
GCUT-11K Green cutoff at 11000k 220 247 237
BCUT-11K Blue cutoff at 11000k 245 100 245
RGAIN-11 RED drive at 11000K 13 86 88
GGAIN-11 Green drive at 11000K 14 88 90
BGAIN-11 Blue drive at 11000K 15 100 100
18

Press “3” to enter Page3: TV adjustment menu Press “4” to enter Page4: Geometry
picture geometry adjustment menu
Item DATA Item Default data
BLK-STRC 30 HB00-PAL 13
NOLINER 0 VB00-PAL 77
VGAMMA 32 HB00-NTS 29
LINE 10 VB00-NTS 75
STEEP 63 HPNL-PAL 5
CORING 10 VPNL-PAL 77
COLDELAY 7 HPNL-NTS 21
YDELAY 15 VPNL-NTS 73
AGC 4
FFA 1
FOB 1
VCO 63
LOCK OK
FREQ 471.25
I. Voltage adjustment at Vaand Vs: (the required values are labeled on the top right corner
of the panel)
1. Coarse adjustment
1) Unplug the output of the power panel, Apply 220VAC to mains power input.
2) Adjust VaAdj until voltage at Va reaches the required value(±1V).
3) Adjust VsAdj until voltage at Vs reaches the required value(±1V).
2. Fine adjustment
1) Apply a white signal.
2) Press “M“ button to select picture menu, press ▼/▲to select CONTRAST and
BRIGHTNESS, press ◀/▶to change the settings to 100.
3) The set warms up about 15 min, then adjust Vaand Vsrespectively.
Adjust VaAdj until voltage at Va reaches the required value (±0.5V).
Adjust VsAdj until voltage at Vs reaches the required value (±0.5V).
II. Adjustment of White balance
i. Adjustment of White balance under RGB mode
1. Receive the 16 Gray-scale pattern,
2. Press “PICTURE” key to select STANDARD mode.
3. Adjustment of Warm temperature( 9300K)
1) Set BCUT-9K3 to 200, BGAIN-93 to 15. Use a color analyzer to measure the black
side of the screen (the scale where the luminance is about 5±1nit). Set the reading of
the color analyzer to x=0.284±0.005, y=0.299±0.005 by adjusting the value of RCUT-
9K3 and GCUT-9K3 repeatedly.
2) Then measure the white side of the screen (the scale where the luminance is
100±5nit). By changing the value of GGAIN-93 and RGAIN-93, set the reading of the
color analyzer to x=0.284±0.005, y=0.299±0.005.
3) Repeat step 1) & 2) until you can get the correct reading for both black and white
sides.
4. Adjustment of Cool temperature (11000K)
1) Set BCUT-11K to 200, BGAIN-11 to15. Use a color analyzer to measure the black side
of the screen (where the luminance is 5±1nit). By changing the value of RCUT-11K
19

and GCUT-11K, set the reading of the color analyzer to x=0.265±0.005,
y=0.280±.0.005.
2) Then measure the white side of the screen where the luminance is 100±5nit. By
changing the value of GGAIN-11 and RGAIN-11, set the reading of the color analyzer
to x=0.265±0.005, y=0.280±.0.005.
3) Repeat step 1) & 2) until you can get the correct reading for both black and white
sides.
4) Press RECALL button to quit.
ii. Adjustment of White balance under AV mode
1. Receive the black/white pattern.
2. Press “PICTURE” key to select STANDARD mode.
3. Adjustment of Warm temperature( 9300K)
1) Set BCUT-9K3 to 240, BGAIN-93 to 100. Use a color analyzer to measure the black
side of the screen (the scale where the luminance is about 5±1nit). Change the value
of RCUT-9K3 and GCUT-9K3 until the reading of the color analyzer to
x=0.284±0.005, y=0.299±0.005.
2) Then measure the white side of the screen (the scale where the luminance is
100±5nit). By changing the value of GGAIN-93 and BGAIN-93, set the reading of the
color analyzer to x=0.284±0.005, y=0.299±0.005.
3) Repeat 1) & 2) until you can get the correct reading for both black and white sides.
4. Adjustment of Cool temperature(11000K)
1) Set BCUT-11K to 245, BGAIN-11 to 100. Use a color analyzer to measure the black
side of the screen (the scale where the luminance is about 5±1nit). By changing the
value of RCUT-11K and GCUT-11K, set the reading of the color analyzer to
x=0.265±0.005, y=0.280±.0.005.
2) Then measure the white side of the screen (the scale where the luminance is
100±5nit). By changing the value of GGAIN-11 and RGAIN-11, set the reading of the
color analyzer to x=0.265±0.005, y=0.280±.0.005.
3) Repeat 1) & 2) until you can get the correct reading for both black and white sides.
4) Press RECALL button to quit.
iii. Adjustment of White balance under YPbPr mode
1. Apply the 10 Gray-scale pattern to YPbPr.
2. Press “PICTURE” key to select STANDARD mode.
3. Adjustment of Warm temperature (9300K)
1) Set BCUT-9K3 to 240, BGAIN-93 to 100. Use a color analyzer to measure the black
side of the screen(the scale where the luminance is About 5±1nit ). Change the value of
RCUT-9K3 and GCUT-9K3 until the reading of the color analyzer to x=0.284±0.005,
y=0.299±0.005.
2) Then measure the white side of the screen. By changing the value of GGAIN-93 and
BGAIN-93, set the reading of the color analyzer to x=0.284±0.005, y=0.299±0.005.
3) Repeat 1) & 2) until you can get the correct reading for both black and white sides.
4. Adjustment of Cool temperature (11000K)
1) Set BCUT-11K to 245, BGAIN-11K to 100. Use a color analyzer to measure the black
side of the screen. By changing the value of RCUT-11K and GCUT-11K, set the reading of
the color analyzer to x=0.265±0.005, y=0.280±.0.005.
2) Then measure the white side of the screen. By changing the value of GGAIN-11 and
RGAIN-11, set the reading of the color analyzer to x=0.265±0.005, y=0.280±.0.005.
3) Repeat 1) & 2) until you can get the correct reading for both black and white sides.
4) Press RECALL button to quit.
20
