CP1030 Series
Variable Output
Regulated Power Supply
Product Manual
Description
The CP1030 is a powerful supply for Basys controls,
transmitters and interface devices. The CP1030 takes a
24 VAC input and provides a regulated and adjustable 2
to 27VDC @ 1 amp output.
CP1030
Mounting
The CP1030 is available in a snap track mounting
style. Remove the circuit board from the snap-track and
mount the snap-track with two #10 sheet metal screws
using the center screw access hole provided. Replace
the circuit board when finished.
Wiring
WARNING!!!
TCS Basys Controls products must be powered from a
separate transformer. All TCS Basys Controls devices
are "halfwave" rectified whereby the power ground is
common with the signal ground.
Power: Connect the AC voltage to the terminal blocks
labeled "INPUT" n the circuit board. The AC input
should not exceed 28 VAC. Terminal "1" is the positive
(+) lead and terminal "3" is the negative (-) lead.
Output: Connect the DC voltage output to terminals
labeled "+" and "-". Observe the correct polarity when
wiring transmitters or other devices to the CP1030
output.
Note: Disconnect power to the AC transformer before
wiring the CP1030, and when wiring transmitters or
other devices.
Caution: Wiring should not be run in the same conduit
as line voltage wiring or other conductors that supply
highly inductive loads such as generators, motors,
contractors etc.
L.E.D.
INPUT
+2 TO +27vdc OUTPUT
GROUND
ADJUST
HALF
WAVE
FULL
WAVE
OUTPUT
1 3
1Amp
Fuse
24VAC Transformer
110/220 VAC
110/220 VAC
R
2800 LAURA LANE • MIDDLETON, WI 53562 • (800) 288-9383 • FAX (608) 836-9044 • www.tcsbasys.com
2
Rev:1106
C396
Setup
Based on the application and the appropriate wiring
method, select either the half-wave rectification method.
Place two shorting blocks (in a horizontal position) next
to the appropriate label, as indicated in the following
diagram.
WARNING: Incorrect placement of rectification shorting
blocks, will cause serious damage to equipment!
2. Measure the output voltage prior to wiring and adjust
the output voltage accordingly. All wiring is low voltage
and should be in accordance with local regulations and
the National Electrical Code.
Voltage Adjustment
Application Notes
Because the CP1030 is powered with a 24 VAC
transformer, grounding problems can occur. Problems
can also occur when the same 24 VAC transformer is
used to power the CP1030 in addition to another device.
If it is known that the device is half-wave rectified, select
"HALF WAVE" rectification. If the rectification of the other
device is unknown, it is recommended that a separate
transformer is used to power the CP1030, it doesn't
matter whether half-wave or full-wave rectification is
selected.
The CP1030 features an L.E.D. supply power indicator.
When the CP1030 is correctly powered, an indicator
light is illuminated. If this indicator does not turn on,
immediately remove supply voltage and recheck all
electrical wiring connections.
DECREASE INCREASE
ADJUST ADJUST
HALF
WAVE
HALF
WAVE
FULL
WAVE
FULL
WAVE
FULL WAVE RECTIFICATION
HALF WAVE RECTIFICATION
