DP-Series Precision Dipole Antennas
Product Overview
TDK Precision Dipole Antennas are half-wave,
fixed length precision dipoles designed to gener-
ate traceable calibrated fields or to measure elec-
tric fields at their respective frequency. The DP-
series antennas offer low gain and essentially per-
fect cross-polarization rejection, and are typically
used as a reference or standard gain antenna, or
as a polarization standard.
Dipole Test Sets The DP-Series Dipole Antennas
are designed with operating frequencies matched
the operating frequencies of common mobile radio
devices, and are available in sets that correspond
to communication systems used in Europe, North
America, and Asia, including GSM, TDMA, PCS,
Bluetooth, and others. Custom frequencies are
available. TDK Dipole Antennas are specifi-
cally designed as calibration refer-
ence sources for transmitting and
receiving the optimum field
strength within each antenna’s
respective frequency range.
Applications
 Calibration
 Communications testing
 Antenna pattern measurements
Communication Applications
Communication System Frequency Range Model
GSM - NMT 453 MHz – 458 MHz DP-450
GSM - 900 880 MHz – 925 MHz DP-900
GSM - 1800 1710 MHz – 1785 MHz DP-1800
GSM 1900/TDMS PCS/CDMA PCS 1850 MHz – 1910 MHz DP-1900
TDMA (NADC)/AMPS 824 MHz – 849 MHz DP-800
W-CDMA 1920 MHz – 1980 MHz DP-2000
Korean CDMA 1715 MHz – 1780 MHz DP-1700

S
SYSTEMS
C
CHAMBERS
P
PRODUCTS
SW
SOFTWARE
TS
TEST SERVICES
TOTALIRF EXPERTISE™
www.tdkrfsolutions.com
To learn more about TDK’s wide range of innovative test products, solutions and services visit www.tdkrfsolutions.com
Copyright © TDK RF Solutions Inc. All rights reserved. Specifications subject to change without notice.
P
PRODUCTS
DP-Series Precision Dipole Antennas
Mechanical Specifications
Dimensions: Dependent on operating
frequency; approx. one-
half wavelength
Weight: Varies by model
Construction: Available in aluminum,
stainless steel or brass
RF Connector: SMA (female)
Electrical Specifications
Gain: See data graph
Impedance 50 Ω
Ordering Information
Product: Dipole Antenna
Model Number: DP-Series
Warranty: 1 year limited
To place an order or to learn more about the
TDK products that best meet your needs, con-
tact your TDK sales representative:
TDK RF Solutions Inc.
1101 Cypress Creek Rd.
Cedar Park, Texas 78613 USA
Phone: [phone]
Fax: [phone]
E-mail: [email protected]
World Wide Web: www.tdkrfsolutions.com
Rev. 2011-08-02
Communications Applications, continued
ISM (Bluetooth) 2400 – 2483.5 MHz DP2400
Japan - Low Band 898 MHz – 901 MHz DP-900-J1
915 MHz – 940 MHz DP-900-J2
940 MHz – 960 MHz DP-900-J3
Japan - High Band 1429 MHz – 1453 MHz DP-1400
Representative Data
