Data Sheet
VLA-2001 V-Log Periodic Antenna
Options
Manual Vertical Mast MVM-200R
TDK RF Solutions’ MVM-200R antenna mast
provides manual control of the height, tilt,
and polarization. The MVM-200R adjusts
from 1 m to 1.5 m in height and supports
antennas up to 18 kg.
Product Overview
Performance The TDK RF Solutions VLA-2001 V-
Log Periodic Antenna is designed for radiated
immunity testing in chambers and open area test
sites. The VLA-2001 offers a wide frequency range
of 200 MHz to 1 GHz with enhanced gain over
standard log periodic dipole array antennas.
State-of-the-Art Design The VLA-2001 features
equalized E and H plane beamwidths, and its
unique, feed design (patent pending) provides
improved high frequency response and greater
power handling. The VLA-2001’s enhanced
symmetry provides minimal cross polarization.
Robust Construction The VLA-2001 is built for
the harsh environments associated with EMC
testing. It features an ultra-robust mechanical
design and a highly durable feed to withstand the
rigors of daily use.
The TDK RF Solutions VLA-2001 V-Log Periodic
Antenna covers the operating frequency range
of 200 MHz to 1 GHz and features a unique
feed design (patent pending) that provides
superior high frequency response.
Features
High power up to 2500 W
Frequency range of 200 MHz to 1 GHz
Enhanced gain over LPDA designs
Equalized E and H plane beamwidths
Unique feed design (patent pending) provides
improved high frequency response
Robust mechanical design
Minimal cross polarization
Applications
Immunity Testing
MIL-STD 461/462
SAE/ISO Automotive Immunity Testing

A
ANTENNAS
To learn more about TDK RF Solutions’ wide range of innovative products and services visit www.tdkrfsolutions.com
©Copyright 2004 TDK RF Solutions Inc. All rights reserved. Specifications subject to change without notice. DSVLA2001072604
VLA-2001 V-Log Periodic Array
Ordering Information
Product: V-Log Periodic Antenna
Model Number: VLA-2001
Warranty: 1 year limited
To place an order or to learn more about the
TDK RF Solutions products that best meet your
needs, contact your TDK sales representative:
TDK RF Solutions Inc.
1101 Cypress Creek Rd.
Cedar Park, Texas 78613 USA
Phone: [phone]
Fax: [phone]
E-mail: [email protected]
World Wide Web: www.tdkrfsolutions.com
TDK Electronics Europe
TDK House, Queensway 5 - 7
RH1 1YB, Redhill, Surrey
United Kingdom
Phone: [phone]
Fax: [phone]
Mechanical Specifications
Overall Dimensions:
Height: 40 in. (102 cm)
Width: 37 in. (94 cm)
Length: 39.5 in. (100 cm)
Weight: 13 lbs (5.9 kg)
Connector: N type female or
SC female
Construction: Aluminum with gold
chromate finish
Electrical Specifications
Frequency Range: 200 MHz to 1 GHz
Gain: 8 dBi
VSWR: 1.5:1 average
Polarization: Linear
Power Handling: 2.5 kw
Impedance: 50 ohm nominal
Environmental Specifications
Operating Range: 0° to +40° C
Storage Range: -10° to +50°
Humidity: Up to 95% non-condens-
ing
