TDK TP-02 User manual

Data Sheet
1101 Cypress Creek Road Cedar Park, Texas 78613, USA 1-512-258-9478 FAX [phone]
P
PRODUCTS
Product Overview
Performance The TDK TP-02 Triplate is an E-field
generator designed to perform EMC measure-
ments according to SAE and other automotive
component test regulations. The Triplate has a
linear response in the operating range of DC to
500 MHz with extended operation to 1 GHz.
The feed section is designed to handle high pow-
er.
Integrated Test Table The TP-02 Triplate is of-
fered with an integrated test table. The test table is
supplied wtih a ground plane that is bonded to the
bottom section of the triplate. The test table is
mounted on casters and features a unique folding
design which allows the triplate to be easily
moved. The support assembly is constructed of
wood and fiberglass.
Features
 Excellent linear response
 Designed to SAE specifications
 Capable of handling high power
 Integrated test table
Applications
 Immunity measurements to automotive test reg-
ulations
The TDK TP-02 Triplate and integrated table is
specifically designed to generate fields for
EMC testing in automotive component test en-
vironments.
TP-02 Triplate with Integrated Table

Copyright © TDK RF Solutions Inc. All rights reserved. Specifications subject to change without notice.
P
PRODUCTS
S
SYSTEMS
C
CHAMBERS
P
PRODUCTS
SW
SOFTWARE
TS
TEST SERVICES
TOTALIRF EXPERTISE™
www.tdkrfsolutions.com
To learn more about TDK’s wide range of innovative test products, solutions and services visit www.tdkrfsolutions.com
TP-02 Triplate with Integrated Table
Mechanical Specifications
Overall Size:
Length: 122 in.
Width: 24 in.
Height: 64 in.
Construction: Wood, aluminum, fiber-
glass, delrin
RF Connector: N type or SC
Environmental Specifications
Operating Range: 0° to +40° C
Storage Range: -10° to +50°
Humidity: Up to 95% non-
condensing
Storage: -10° to +50° C
Ordering Information
Product: Triplate
Model Number: TP-02
Warranty: 1 year
To place an order or to learn more about the
TDK products that best meet your needs, con-
tact your TDK sales representative:
TDK RF Solutions Inc.
1101 Cypress Creek Rd.
Cedar Park, Texas 78613 USA
Phone: [phone]
Fax: [phone]
E-mail: [email protected]
World Wide Web: www.tdkrfsolutions.com
Rev. 2011-08-02
