Teac MC-D5 User manual

NOTES CONTENTS
CD/CASSETTE MICRO SYSTEM
NOTES CONTENTS
PC board shown are viewed from parts side.
The parts with no reference number or no parts number
in the exploded views are not supplied.
As regards the resistors and capacitors, refer to the
circuit diagrams contained in this manual.
Parts marked with this sign are safety critical
components. they must be replaced with identical
ensure exact replacement.
!
components - refer to the appropriate parts list and
1 SPECIFICATIONS
3 EXPLODED VIEW AND PARTS LIST
4 PC BOARDS AND PARTS LISTS
5 WIRING DIAGRAM
6 INCLUDED ACCESSORIES
2
5
10
16
18
2 ADJUSTMENT AND CHECKS 3
Parts of [ ] mark can be used only with the version designated.
[E]: EUROPE [UK]: U.K.
All manuals and user guides at all-guides.com
all-guides.com

1 SPECIFICATIONS
2
CD PLAYER Section
Pickup:
Wavelength :
Audio frequency response :
3-beam pick-up
790 nm
20 Hz ~ 22 kHz
CASSETTE DECK Section
Track System:
Tape Speed:
Wow and Flutter:
4 track, 2 channel stereo
4.76 cm/sec
0.4% or less
Design and specifications are subject to change without notice.
Photos and illustrations may differ slightly from production models.
MC-D5
TUNER Section
System :
Tuning range :
synthesizer system
PLL quartz-locked digital
Antenna : FM pigtail antenna
AM bar antenna (built-in)
SPEAKER SYSTEM Section
Impedance: 4 ohm
System: 2-way shielded box
4-3/16 lb (1.9 kg) x2
(5-3/4 x 9-3/16 x 7-7/8) inches
146 x 233 x 200 mm
Dimension (W x H x D ):
Weight:
GENERAL
Power requirements:
Power consumption:
Dimension (W x H x D ):
Standard Accessories: Remote Control Unit (RC-909) x 1
Owner's Manual x 1
Warranty Card x 1
230V AC, 50Hz
65W
150 x 233 x 223 mm
6-13/16 lb (3.1 kg)
Output power: 12.5W x 2
(5-7/8 x 9-3/16 x 8-3/4) inches
Weight:
FM : 87.50 ~ 108.0 MHz (50kHz step)
AM : 522 to 1620 kHz (9 kHz step)
All manuals and user guides at all-guides.com

3
2 ADJUSTMENTS AND CHECKS
Use a screwdriver with a plastic or ceramic grip for all adjustment.
2-1 TUNER SECTION
1. Set the function switch to the AM position.
2. Connect the test loop antenna across the output of the signal generator.
3. Connect the oscilloscope to the speaker terminal.
4. Set the signal generator as listed in the alignment chart.
2-1-2 AM adjustment
1. Set the function switch to the FM position.
2. Connect the signal generator output through a 75 ohm dummy
3. Connect the oscilloscope to the speaker terminal.
4. Set the signal generator as listed in the alignment chart.
2-1-1 FM adjustment
antenna to "ANT" on MAIN PCB.
MC-D5 TUNER PCB
L7 AM ANT COIL
L1
L2
CT2
CT1
T2
T3
MC-D5
All manuals and user guides at all-guides.com

4
2-1-3 FM/AM alignment chart
ITEM ADJUSTMENT POINT ADJUSTMENT
SG SETTING TUNER SETTING
1. FM band
2. Tracking
3. Tracking
106MHz 106MHz
Repeat step 2
90MHz 90MHz
87.5MHz 87.5MHz
1kHz, +/-22.5kHz dev.
1kHz, +/-22.5kHz dev.
1kHz, +/-22.5kHz dev.
L2
L1
CT1
FM
Adjust for max.output.
Adjust for max. output
and best waveform.
1. IF adjustment
2. AM band
450kHz
Repeat step 3
603kHz
1404kHz
1kHz, 30% mod
1kHz, 30% mod
1kHz, 30% mod
1kHz, 30% mod
T2
L7
CT2
T3
AM
Adjust for max.output.
Adjust for max. output.
Adjust for max. output
and best waveform.
2-2 CASSETTE SECTION
1. Set the FUNCTION SELECTOR SWITCH TO TAPE.
2. Connect a Scope & VTVM across the speaker output.
3. Insert the 8KHz tape in to cassette deck and push play BUTTON.
4. ADJUST HEAD for speaker maximum output.
2-3 CD SECTION
Auto alignment.
AM ANT COIL
SCREWDRIVER
SCREWDRIVER
ADJUSTING
SCREW
MOTOR
522kHz 522kHz
603kHz
1404kHz
1620kHz
MC-D5
All manuals and user guides at all-guides.com

1 1 3 3
2 2
4 4
6 6
5 5
8 8
7 7
7 7
7 7
7 7
7 7
3737
3434
3232
3535
1010
3030
99
1919
1818
3737
1212
11 11 1313
1313
1313
2929
1313
14 14
2929
1515
3737
3535
16 16
1717
2020
2121
2222
3131
3636
2323
3636
2828
2424
2626
3333
2525
2727
3636
3030
3737
3636
3636
MC-D5
3 EXPLODED VIEWS AND PARTS LIST
EXPLODED VIEW - 1
5
All manuals and user guides at all-guides.com

6
MC-D5
56-57EX0M101000 REMOTE LENS - SAN (BLACK)
20-70DA23000200 CD MECHANISM (SANYO)
56-04EX0M10B010
FRONT CABINET (SILVER)
56-24EX0M10B000 GEAR -A
56-24EX0M11B000
56-07EX0M12B000 CD DECK BRACKET
56-24EX0M12B000
56-24EX0M13B000 GEAR BRACKET-A
56-07EX0M119000 REMOTE BRACKET
FUNCTION KNOB-M
56-54EX0M10A000
56-54EX0M12B010
56-07EX0M17B000 PCB BRACKET
56-54EX0M11B010
1-1
1-2
1-3
1-4
1-5
1-7
1-8
1-9
1-10
1-6
1-12
1-13
1-14
1-15
1-11
1-17
1-18
1-19
1-20
1-16
1-22
1-23
1-24
1-25
1-21
1-27
1-28
1-29
1-30
1-26
1-32
1-33
1-34
1-35
1-31
1-37
1-36
REMARKS
REF. NO
EXPLODED VIEW-1
PARTS NO. DESCRIPTION
GEAR -B
GEAR -C
56-24EX0M14B000 GEAR BRACKET-B
FUNCTION KNOB-L (SILVER)
FUNCTION KNOB-R (SILVER)
05-02EX0M500000 TUNER PCB ASSY
05-05EX0M100000 KEY PCB ASSY
05-07EX0M500000 POWER PCB ASSY
05-09EX0M100000 H/P PCB ASSY
05-23EX0M100000 O/C SWITCH PCB ASSY
05-30EX0M500000 CD PCB ASSY
61-11V600000020 PCB BRACKET
66-120230140321 MACHINE SCREW MS/BH3x4
66-120330160321 MACHINE SCREW MS/PH3x6
66-140230214321 SELF-TAPPING SCREW TA/BH3x14
66-140330210321 SELF-TAPPING SCREW TA/BH3x10
66-140330180321 SELF-TAPPING SCREW TA/PH3x8
66-140330210321 SELF-TAPPING SCREW TA/PH3x10
66-140330212321 SELF-TAPPING SCREW TA/PH3x12
61-61D200000020 LOCK WASHER
58-61EX0M108120 SHOCK ABSORBER
58-263122300020 RUBBER FOOT (HARD)
58-44X200000020 CD MOTOR
56-760000000020 DOOR MOTOR PULLY
58-43X200000120 DRIVE BELT
68-112303100500 METAL WASHER 3X10X0.5MM
FIBRE WASHER
68-122301600400
68-112323101000 METAL WASHER 3.2X10X1MM
56-04EX0M10A040
FRONT CABINET (BLACK)
56-54EX0M11A010
FUNCTION KNOB-L (BLACK)
56-54EX0M12A010
FUNCTION KNOB-R (BLACK)
56-57EX0M102000 REMOTE LENS -SAN (SILVER)
All manuals and user guides at all-guides.com
all-guides.com

MC-D5
EXPLODED VIEW - 2
11
66 77
99
88
5050
1313
1414
1616
5151
1717
1919
4949
2020
2121
2222
5353
4646
2323
2424
5353
4646 4242
3131
3232
3030
2929
4343
2626
2727
5252
4848
3434
5252
4444
3535
3636
4747
3737
5151
4343
3939
4040
4343 2525
3838
4141
3333
2828
5151
1818
1515
4747
1111
1212
1010
4545
22
33
44
55
2525
7
54 54
All manuals and user guides at all-guides.com

!
56-57EX0M140000
56-57EX0M501000 CD DOOR LENS
56-07EX0M14B000
56-07EX0M18B000 POWER LED BRACKET
56-14EX0M10B020 CD DOOR (BLACK)
56-58EX0M500010 BADGE LOGO (M01241802A)
56-55EX0M10B000 CASS KNOB-6KEY (BLACK)
56-07EX0M109000 BACK LIGHT LENS BRACKET
CD DOOR SHAFT BRACKET-L
56-07EX0M13B000
56-14EX0M11B000 CD DOOR BASE (BLACK)
56-24EX0M16B000 CASS GEAR BRACKET
CASS GEAR
56-24EX0M158000
56-57EX0M129000 POWER LENS
56-05EX0M31A020 REAR CABINET (SILVER)
BATTERY DOOR (SILVER)
56-06EX0M10B000
BACK LIGHT LENS
56-06EX0M11B000
BATTERY BOX (SILVER)
56-07EX0M16A030 CASS DOOR BRACKET (SILVER)
56-13EX0M10B010 CASS DOOR (BLACK)
18-205EX0M30120 TRANSFORMER EI-66
56-69EX0M10B000 AC CORD PLATE
CD DOOR SHAFT BRACKET-R
05-04EX0M100000 DISPLAY PCB ASSY
05-16EX0M100000 LED PCB ASSY
05-20EX0M300000 R/P PCB ASSY
61-11EX0M100020 REC.PCB BRACKET
61-11EX0M110020 MTG-BRACKET CASS KNOB
58-63EX0M300020 SHIELDING PLATE
61-97EX0M100000 CASS DOOR SPRING
2-1
REF. NO
EXPLODED VIEW-2
PARTS NO. DESCRIPTION
2-2
2-3
2-4
2-5
2-6
2-7
2-8
2-9
2-10
2-11
2-12
2-13
2-14
2-15
2-16
2-17
2-18
2-19
2-20
2-21
2-22
2-23
2-24
2-25
2-26
2-27
2-28
2-29
2-30
2-31
2-32
2-33
2-34
2-35
2-36
2-37
2-38
56-57EX0M130020 DISPLAY LENS (BLACK)
57-26EX0M100000 FILTER SHEET
56-57EX0M160020 CASS DOOR LENS (BLACK)
20-06EX0M100021 F/CASS DECK
61-76SCD6600020 RECORDING PLATE
58-73EX0M500020
SPEAKER BOX ASSY (SILVER)
61-256600000020 BATTERY CONTACT PLATE (+)
61-26SX88000020 BATTERY SPRING (+/-)
61-266600000020 BATTERY CONTACT SPRING (-)
57-082222130520
PVC PLATE 22X13X0.3MM (SILVER)
57-08EX0M500120 FM ANT PLATE (SILVER)
REMARKS
8
MC-D5
56-14EX0M10A020 CD DOOR (SILVER)
56-58EX0M118000 BADGE LOGO (M01241801A)
56-57EX0M130010 DISPLAY LENS (SILVER)
56-14EX0M11A000 CD DOOR BASE (SILVER)
56-57EX0M160010 CASS DOOR LENS (SILVER)
56-13EX0M10A010 CASS DOOR (SILVER)
56-07EX0M16B010 CASS DOOR BRACKET (BLACK)
56-55EX0M10A000 CASS KNOB-6KEY (SILVER)
56-06EX0M11A000
BATTERY BOX (BLACK)
56-05EX0M31B000 REAR CABINET (BLACK)
57-082222130120
PVC PLATE 22X13X0.3MM (BALCK)
57-08EX0M500020 FM ANT PLATE (BLACK)
56-06EX0M10A000
BATTERY DOOR (BLACK)
58-73EX0M100020
SPEAKER BOX ASSY (BLACK)
All manuals and user guides at all-guides.com

REF. NO
EXPLODED VIEW-2
PARTS NO. DESCRIPTION REMARKS
MACHINE SCREW MS/KH3x8 (BLACK)
66-140230212321 SELF-TAPPING SCREW TA/BH3x12
66-140230218321 SELF-TAPPING SCREW TA/BH3x18
66-150330160321 SELF-TAPPING SCREW TB/PH3x6
66-140530210321 SELF-TAPPING SCREW TA/KH3x10
66-140530212121 SELF-TAPPING SCREW TA/KH3x12
66-140826212321 SELF-TAPPING SCREW TA/WH2.6x12
66-170220130321 HARDEN SCREW TT/BH2x3
2-40
2-41
2-42
2-43
2-44
2-45
2-46
2-47
2-48
2-49
2-50
2-51
2-52
AC CORD BS PLUG VDE APP [HK] (SILVER)
45-114200510008
METAL WASHER
68-112323101000
66-120330160321 MACHINE SCREW MS/PH3x6
66-120530180121
66-140330210321 SELF-TAPPING SCREW TA/BH3x10
66-140330212321 SELF-TAPPING SCREW TA/PH3x12
45-114200500005 AC CORD VDE APP CORD [EUR]
45-114200411008 AC CORD BS APP 2M (BES) [UK] (BLACK)
2-39 RUBBER FOOT (HARD)
58-263122300020
!
!
!
9
MC-D5
All manuals and user guides at all-guides.com

4 PC BOARDS AND PARTS LIST
10
TUNER PCB ASSY
REF. NO
MC-D5
DESCRIPTION
TUNER PCB ASSY
TUNER PCB
FERRITE BAR 10X80MM
REMARKS
PARTS NO.
05-02EX0M500000
48-02EX0M100220
32-022102800020
REF. NO
R/P PCB ASSY
Q5
Q4,6
IC3
T1
SW1
CON5
R/P PCB ASSY
DESCRIPTION
RECORDER PCB
TR-9014C
TR-9015C
IC-BA3308
IFT- 621 (BLK)
PUSH SWITCH
WAFER 4P P=2MM
SLIDE SWITCH
SW2
REMARKS
PARTS NO.
05-20EX0M300000
48-20EX0M100221
11-9014C0000021
11-9015C0000021
16-BA3308000012
40-016210000020
41-091020000020
43-012200140120
41-132203000920
Q2,8,9,10
D1,2
IC1
IC2
X5
ZD6
D3,4
D5,33
T2
Q3
CON2
X1
CF1
L7
T3
L1
L2,3
CF3
CT2
TR-9014C
DIODE - 1N4148
IC-LC72131
IC-LA1823
CRYSTAL 4.500MHZ
WAFER 7 PINS 180C
ZENER DIODE 6.8V
VAR DIODE SVC201SPA
VAR DIODE SVC321SPA
CDA 10.7MG1-A
CER.FILTER SFU450B
FM COIL 4.5X4.5TX0.8MM
AM COIL 68:20T
IFT 660R (RED)
IFT A049 (YELLOW)
TR-8050C
FM COIL 4.5X3.5TX0.8MM
CER.FILTER SFE10.7AM
TRIMMER 20PF
CT1
11-9014C0000021
12-1N4148000021
16-LC7213100021
16-LA1823000021
31-017450002010
43-012200170120
12-011680320121
12-SVC201SPA021
12-SVC321SPA021
31-038107000110
31-026450010110
40-351450145020
40-212680220520
40-01660R002020
40-01A049004020
11-8050C0000021
40-351450135020
31-028107000110
27-501802201020
27-501802101020 TRIMMER 10PF
43-420180000020 JACK R-018 FOR FM ANTENNA
45-194150000020 FM ANTENNA WIRE CE/75 #STV8-1H -1500
All manuals and user guides at all-guides.com

MC-D5
11
TUNER PCB
R/P PCB
All manuals and user guides at all-guides.com
all-guides.com

CD PCB ASSY
REF. NO PARTS NO. DESCRIPTION
05-30EX0M500000
REMARKS
O/C SWITCH PCB ASSY
REF. NO PARTS NO. DESCRIPTION
05-23EX0M100000
O/C SWITCH PCB ASSY
CD O/C SWITCH PCB
48-23EX0M100221
41-071100020020 MICRO SWITCH - 1120B
SW1,2
REF. NO PARTS NO. DESCRIPTION
H.P PCB ASSY
05-09EX0M100000 H.P PCB ASSY
48-09EX0M100220 H.P PCB
43-431355001020 PHONE JACK /SW D3.55MM
PH1
REMARKS
REMARKS
REF. NO PARTS NO. DESCRIPTION
LED PCB ASSY
05-16EX0M100000 LED PCB ASSY
48-16EX0M100220
13-011506122020 LED LAMP 5MM (S - BLUE)
LED PCB
LED1,LED2
REMARKS
11-2SA134600021 TR-2SA1346
48-30EX0M100223 CD PCB
Q401,402,405, 11-9014C0000021 TR-9014C
Q307-310 11-2SD1936T0021 TR-2SD1936T
Q311
11-9015C0000021 TR-9015C
12-011510320121 ZENER DIODE 5.1V
12-1N4148000021 DIODE 1N4148
16-LA6541D00021 IC-LA6541D
16-LA9241M00021 IC- LA9241M
16-LB1641000021 IC- LB1641
16-LC58P7000021 IC- LC58P7008-1P09
16-LC78622N0021 IC- LC78622NE
31-017400002010 CRYSTAL 4.0MHz
31-015320003310 CRYSTAL 32.768KHz
31-048169300120 RESONATOR - ZTT16.93MX
38-014100050020 INDUCTORS 100UH
43-012150160320 WAFER 6PIN P=1.5MM
43-022200150120 WAFER 5PIN P=2MM
Q301,302,403,
IC304
IC302
IC303
IC301
CON305
CN5
L301,302
X402
X301
D403,404,407,
ZD301
IC401
Q406,407,412
Q404,410,411
D408,409,411,
X401
43-022100216120 WAFER 16P P=1MM
CON410
43-012100230120 WAFER 30P P=1MM
CON413
D412,413,415-418
D420-423
ZD401 ZENER DIODE 5.6V
12-011560320121
CD PCB ASSY
12
MC-D5
All manuals and user guides at all-guides.com

GND
R323 R324
C334
R332C319
C389
R327
C391
C390
C320
R326
R325
J7
J6
CN6
D408
D410
D412
D414
CN401
D409
D411
D413
D415
CN402
Q405
J49
Q406
Q407
J428
Q408
R458
R451
R450
R461
D419
D418
D417
D416 D407
D406
D405
D404
J44
J43
R429
R427
R428
R130
R132
R125
R413
IC401
R414
J45
J46
R407
C411
C410
X402
X401
C405
C404
C406
J33
J32
C397
J47
R408
R409
R410
R411
J346
J37
J36
J35
R412
J48
C371
J31
R406 R405 R404 R403 R402
C336
J25
Q302
IC302
J21
R368
J26
R335
J22
J23
SW2
CN5
CN7
Q401
RGND
R441
J30
RESET
Q409
R401
SW1
CON406
C401
C412
C413
R460
C403
D421
J39
C402
J40
Q404
R444
Q402
D423
C414
D422
R418
R417
J41
D403
R419
CON413
J42
R468
Q410
R462
R421
R445 R448 R447 R446 R430 R431 R432 R434 R422
C349
C367
C359
C350
C351
R337
J57
R372 C346
R302
C357
R356 R375
D301
R373
C347
C360
C302
C415
J50
J51
J52
J53
R374
J55 J24
C318
R307
C305
R336
R306
J54
Q311 C372
C363
R306
R370C304
J432
R388
R309
C365
R385
C419
R304
R305
R303
R322
C303
C325
C418
J10
J430
J431
J8
C327
C326
J16
J17
C328
Q310
Q307
R364
R361
R360
R363
R359
Q301
R381
R384
Q309
R382
C369
L301
R328
R330
R311
R395
R394
R396
R397
R362
J9
C370
R379 R378 R380 R377
C322
C323 C324
C361
R329
R399
C321
R389
C313
C312
R319
R317
C315
R312
R314 IC304
C329
R301
R331
C330
R316
R358
R315
R318
C311
C308
C310
C342
R310
R313
C368 J3
J1
J2
CON412
C382
C385
J4
J5
R376
R465
L302
C332
C333
C335
C316
R321
R320
C317
B
X301
R449
C348
CON312
D420
CON404
R423
R424
R425
CON403
C409
C338
C339
J27
J38
J56
J34
Q403
R415
R463 PH1
R464
R420
R443
R459
R416
C407
C398
ZD401
C416
C417
R333
R369
J19
R367
R365
C364
C337
R400
C331
IC301
R391
J429
C341
R392
C343
Q411
ZD301
J13
J14
J15
B
Q412
R466
R467
R383
CON305
Q308
L303
J427
C301
CON410
J18
J20
C309
IC303
LED PCB
L
R
CD PCB
O/C SWITCH PCB H/P PCB
13
MC-D5
LED2 LED1
All manuals and user guides at all-guides.com

POWER PCB ASSY
REF. NO DESCRIPTION
POWER PCB ASSY
POWER PCB
CE-10V 1000UF
CE-25V 1000UF
!
!
C769
C808
REMARKS
CE-25V 6800UF
C757
!
DISPLAY PCB ASSY
REF. NO PARTS NO. DESCRIPTION
05-04EX0M100000
DISPLAY PCB ASSY
DISPLAY PCB
48-04EX0M100220
13-5EX0M100010 LCD DISPLAY IS06382P00
LCD401
13-011506122020 LED 5MM(BLUE)
D1,D2
KEY PCB ASSY
REF. NO PARTS NO. DESCRIPTION
05-05EX0M100000
KEY PCB ASSY
KEY PCB
48-05EX0M100221
43-022200130120 WAFER 3PIN P=2MM
17-05FM60380010 OPTIC SENSER
41-150010030020 TACT SWITCH H=5MM 4LEGS
43-022200140120 WAFER 4PIN P=2MM
43-022200170120 WAFER 7PIN P=2MM
IR1
CON501
CON502
CON503
REMARKS
REMARKS
TACT SWITCH H=5MM 5LEGS
41-150020000020
LED1,2 13-011506122020 LED 5MM - BLUE
PARTS NO.
05-07EX0M500000
48-07EX0M300121
26-017100650121
26-017100850121
26-017680850121
TR-KSB772YS
TR-9014C
TR-KSD882Y
ZENER DIODE 10V
IC - LC75342
IC - LA4725
DIODE 1N4001
DIODE 1N5401
DIODE 1N4148
ZENER DIODE 6.2V
ZENER DIODE 8.2V
WAFER 2PIN P=2MM
WAFER 3PIN P=2MM
WAFER 5PIN P=2MM
WAFER 7PIN P=2MM
WAFER 9PIN P=2MM
WAFER 4PIN P=2.5MM
DIODE - 1N5822
GLASS FUSE 6.3A 250V
Q723,729
Q715-717,721,
Q725-728,730,801
Q713
ZD704
ZD705
ZD703
D707-710
D711
D714-717
IC704
IC703
FUSE
CON706
CON705
CON702,704
CON701
CON703
CON707
D700
!
!
WAFER 5PIN P=2.5MM
CON708
IC - MC34063A
IC705
Q718 TR-8050C
ZENER DIODE6. 8V
ZD801
TR-8550C
Q724
L5
L6
CHOKE COIL 230UH
CHOKE COIL 20UH
11-KSB772YS0021
11-9014C0000021
11-KSD882Y00021
12-012100320121
16-LC7534200021
16-LA4725000021
12-011620320121
12-1N4001000021
12-1N5401000021
12-011820320121
12-1N4148000021
43-012200120120
43-012200130120
43-012200150120
43-012200170120
43-012200190120
43-012250140120
12-1N5822000021
46-055630300010
43-012250150120
16-MC34063A0021
11-8050C0000021
12-011680320121
11-8550C0000021
38-104230050020
38-103200050020
43-441400012020 SPEAKER JACK
JK2
!
14
MC-D5
All manuals and user guides at all-guides.com

MC-D5
15
KEY PCB
POWER
DISPLAY PCB
TIMER
EQ
CON501
CN502
TIME REPEAT
TUNER TAPE
MO / S T
MEMORY DN
CN503
FB
CD
FF
UP
IR1
STOP
OP / CL
PL / PA
D2
D1
LCD401
CON1
LED401
J2
J3
J4 J1
J13
J17 J12
J18
J119
POWER PCB
All manuals and user guides at all-guides.com

MC-D5
5 WIRING DIAGRAM
CD PCB
TO KEY PCB CON503
CN6
CN401
TO KEY PCB CON501
TO KEY PCB CON502
TO TUNER PCB CON2
CON403
CON404
TO POWER PCB CON702
TO POWER PCB CON705
CON312
CON412
TO POWER PCB CON701
TO DISPLAY PCB CON1
CON413
CON406
TO TUNER PCB CON1
TO CD DECK
CN5
CON410
TO CD DECK
CON305
TO O/C SW PCB CN7
16
All manuals and user guides at all-guides.com
all-guides.com

MC-D5
CON703
CON704
CON707
CON708
TO CASS DECK
TO TUNER PCB CON3
TO CASS DECK
17
POWER PCB
TO H/P PCB
AC1 AC2
TO TRANSFORMER
All manuals and user guides at all-guides.com

02-17EX0M500000 REMOTE CONTROL (BLACK)
6 INCLUDED ACCESSORIES
REF. NO PARTS NO. DESCRIPTION
INCLUDED ACCESSORIES
REMARKS
INSTRUCTION BOOK-E/F/S/I
77-20EX0M500020
02-17EX0M500001 REMOTE CONTROL (SILVER)
18
MC-D5
All manuals and user guides at all-guides.com

TEAC AUSTRALIA PTY., LTD.
A.B.N. 80 005 408 462
280 William Street, Melbourne VIC 3000, Australia Phone:[phone]
TEAC ITALIANA S.p.A.
TEAC BELGIUM NV/SA.
Via C, Cantu 11, 20092 Cinisello Balsamo, Milano, Italy Phone:[phone]
c/o TEAC NEDERLAND BV, Oeverkruid 15, NL-4941 W Raamsdonksveer, Nederland Phone:[phone]
TEAC CORPORATION 3-7-3 Nakacho, Musashino-shi, Tokyo 180-8550, Japan Phone:[phone]
TEAC AMERICA, INC.
TEAC CANADA LTD.
TEAC MEXICO, S.A.De C.V.
TEAC UK LIMITED
TEAC DEUTSCHLAND GmbH
TEAC FRANCE S.A.
TEAC NEDERLAND BV
7733 Telegraph Road, Montebello, California 90640 Phone: [phone]
5939 Wallace Street, Mississauga, Ontario L4Z 1Z8, Canada Phone: [phone]
Campesinos 184,Col. Granjas Esmeraida, 09810, Mexico Phone: [phone]
5 Marlin House, Croxley Business Park, Watford, Hertfordshire, WD18 8TE, U.K. Phone: [phone]
Bahnstrasse 12, 65205 Wlesbaden-Erbenheim, Germany Phone:[phone]
17, Rue Alexis-de-Tocqueville, CE 005 92182 Antony Cedex, France Phone:[phone]
Oeverkruid 15,NL-4941 W Raamsdonksveer, Nederland Phone:[phone]
PREPARED IN HONG KONG
All manuals and user guides at all-guides.com

CD/CASSETTE MICRO SYSTEM
All manuals and user guides at all-guides.com
