Teac DC-D6800 User manual

3D0023800A
˛
DC-D6800
Thanks for buying a TEAC. Read this manual carefully to get the best performance from this unit.
Nous vous remercions pour l’achat d’un appareil TEAC.
Lire ce manuel avec attention pour obtenir les meilleures performances possibles de cet appareil.
Digital Compact Hi-Fi System
Système Disque Compact Hi-Fi
OWNER’S MANUAL . . . . . . . . . . 2
MANUEL DU PROPRIETAIRE . . . . 28

2
PreperationListening to CDs
Listening to the radio
Listening to tapesRecordingSetting the timer
Important Safety Instructions
CAUTION
<Read all of these Instructions.
<Save these Instructions for later use.
<Follow all Warnings and Instructions marked on the audio
equipment.
1) Read Instructions — All the safety and operating instructions
should be read before the product is operated.
2) Retain Instructions — The safety and operating instructions should
be retained for future reference.
3) Heed Warnings — All warnings on the product and in the operating
instructions should be adhered to.
4) Follow Instructions — All operating and use instructions should be
followed.
5) Cleaning — Unplug this product from the wall outlet before
cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp
cloth for cleaning.
6) Attachments — Do not use attachments not recommended by the
product manufacturer as they may cause hazards.
7) Water and Moisture — Do not use this product near water — for
example, near a bath tub, wash bowl, kitchen sink, or laundry tub; in a
wet basement; or near a swimming pool; and the like.
8) Accessories — Do not place this product on an unstable cart,
stand, tripod, bracket, or table. The product may fall, causing serious
injury to a child or adult, and serious damage to the product. Use only
with a cart, stand, tripod, bracket, or table recommended by the
manufacturer, or sold with the product. Any
mounting of the product should follow the
manufacturer’s instructions, and should use a
mounting accessory recommended by the
manufacturer.
9) A product and cart combination should be moved
with care. Quick stops, excessive force, and
uneven surfaces may cause the product and cart combination to
overturn.
10) Ventilation — Slots and openings in the cabinet are provided for
ventilation and to ensure reliable operation of the product and to
protect it from overheating, and these openings must not be blocked
or covered. The openings should never be blocked by placing the
product on a bed, sofa, rug, or other similar surface. This product
should not be placed in a built-in installation such as a bookcase or
rack unless proper ventilation is provided or the manufacturer’s
instructions have been adhered to.
11) Power Sources — This product should be operated only from the
type of power source indicated on the marking label. If you are not
sure of the type of power supply to your home, consult your product
dealer or local power company. For products intended to operate from
battery power, or other sources, refer to the operating instructions.
12) Grounding or Polarization — This product may be equipped with a
polarized alternating-current line plug (a plug having one blade wider
than the other). This plug will fit into the power outlet only one way.
This is a safety feature. If you are unable to insert the plug fully into
the outlet, try reversing the plug. If the plug should still fail to fit,
contact your electrician to replace your obsolete outlet. Do not defeat
the safety purpose of the polarized plug.
13) Power-Cord Protection — Power-supply cords should be routed
so that they are not likely to be walked on or pinched by items placed
upon or against them, paying particular attention to cords at plugs,
convenience receptacles, and the point where they exit from the
product.
14) Outdoor Antenna Grounding — If an outside antenna or cable
system is connected to the product, be sure the antenna or cable
system is grounded so as to provide some protection against voltage
surges and built-up static charges. Article 810 of the National
Electrical Code, ANSI/NFPA 70, provides information with regard to
proper grounding of the mast and supporting structure, grounding of
the lead-in wire to an antenna discharge unit, size of grounding
conductors, location of antenna-discharge unit, connection to
grounding electrodes, and requirements for the grounding electrode.
Note to CATV system installer:
This reminder is provided to call the CATV system installer’s attention
to Section 820-40 of the NEC which provides guidelines for proper
grounding and, in particular, specifies that the cable ground shall be
connected to the grounding system of the building, as close to the
point of cable entry as practical."
15) Lightning — For added protection for this product during a
lightning storm, or when it is left unattended and unused for long
periods of time, unplug it from the wall outlet and disconnect the
antenna or cable system. This will prevent damage to the product
due to lightning and power-line surges.
16) Power Lines — An outside antenna system should not be located
in the vicinity of overhead power lines or other electric light or power
circuits, or where it can fall into such power lines or circuits. When
installing an outside antenna system, extreme care should be taken
to keep from touching such power lines or circuits as contact with
them might be fatal.
17) Overloading — Do not overload wall outlets, extension cords, or
integral convenience receptacles as this can result in risk of fire or
electric shock.
18) Object and Liquid Entry — Never push objects of any kind into
this product through openings as they may touch dangerous voltage
points or short-out parts that could result in a fire or electric shock.
Never spill liquid of any kind on the product.
19) Servicing — Do not attempt to service this product yourself as
opening or removing covers may expose you to dangerous voltage or
other hazards. Refer all servicing to qualified service personnel.
20) Damage Requiring Service — Unplug this product from the wall
outlet and refer servicing to qualified service personnel under the
following conditions:
a ) when the power-supply cord or plug is damaged.
b ) if liquid has been spilled, or objects have fallen into the product.
c ) if the product has been exposed to rain or water.
d)if the product does not operate normally by following the
operating instructions. Adjust only those controls that are covered by
the operating instructions as an improper adjustment of other
controls may result in damage and will often require extensive work
by a qualified technician to restore the product to its normal
operation.
e) if the product has been dropped or damaged in any way.
f)when the product exhibits a distinct change in performance _ this
indicates a need for service.
21) Replacement Parts — When replacement parts are required, be
sure the service technician has used replacement parts specified by
the manufacturer or have the same characteristics as the original
part. Unauthorized substitutions may result in fire, electric shock, or
other hazards.
22) Safety Check — Upon completion of any service or repairs to this
product, ask the service technician to perform safety checks to
determine that the product is in proper operating condition.
23) Wall or Ceiling Mounting — The product should be mounted to a
wall or ceiling only as recommended by the manufacturer.
24) Heat — The product should be situated away from heat sources
such as radiators, heat registers, stoves, or other products
(including amplifiers) that produce heat.
ANTENNA
LEAD IN
WIRE
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250. PART H)
NEC - NATIONAL ELECTRICAL CODE
ELECTRIC
SERVICE
EQUIPMENT
Example of Antenna Grounding
as per National Electrical
Code, ANSI/NFPA 70
GROUND
CLAMP

3
Preperation Listening to CDs
Listening to the radio
Listening to tapes Recording Setting the timer
Precaution
Safety Information
This product has been designed and manufactured according to FDA regulations "title 21, CFR, chapter 1, subchapter J,
based on the Radiation Control for Health and Safety Act of 1968", and is classified as class 1 laser product. There is not
hazardous invisible laser radiation during operation because invisible laser radiation emitted inside of this product is
completely confined in the protective housings.
The label required in this regulation is shown ①.
CAUTION
<DO NOT REMOVE THE PROTECTIVE HOUSING USING SCREWDRIVER.
<USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN
MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
<IF THIS PRODUCT DEVELOPS TROUBLE, MAKE A CONTACT WITH OUR SERVICEMAN, AND DO NOT USE THE
PRODUCT IN A TROUBLED STATE.
For U.S.A.
①
Optical pickup:
Type : LTOH96MK
Manufacturer : SHARP Corporation
Laser output : Less than 0.5 mW on the objective lens
Wavelength : 770-795 nm
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR
BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
Y
E
RTHE EXCLAMATION POINT WITHIN AN EQUILATERAL TRIANGLE IS INTENDED TO ALERT THE USER TO THE PRESENCE
OF IMPORTANT OPERATING AND MAINTENANCE (SERVICING) INSTRUCTIONS IN THE LITERATURE ACCOMPANYING
THE APPLIANCE.
THE LIGHTNING FLASH WITH ARROWHEAD SYMBOL, WITHIN AN EQUILATERAL TRIANGLE, IS INTENDED TO ALERT
THE USER TO THE PRESENCE OF UNINSULATED "DANGEROUS VOLTAGE" WITHIN THE PRODUCT’S ENCLOSURE THAT
MAY BE OF SUFFICIENT MAGNITUDE TO CONSTITUTE A RISK OF ELECTRIC SHOCK TO PERSONS.
Optical pickup:
Type : SOH-AA
Manufacturer : SAMSUNG ELECTRO-MECHANICS CO.LTD
Laser output : Less than 0.5 mW on the objective lens
Wavelength : 770-810 nm

4
PreperationListening to CDs
Listening to the radio
Listening to tapesRecordingSetting the timer
Precaution
<Choose unit installation location carefully. Avoid
placing it in direct sunlight or close to a source of
heat. Also avoid locations subject to vibrations and
excessive dust, heat, cold or moisture. Keep away
from sources that hum, such as transformers or
motors.
<Do not open the cabinet as this might result in
damage to the circuitry or electrical shock. If a
foreign object should get into the set, contact your
dealer.
<When removing the power plug from the wall outlet,
always pull directly on the plug, never yank the cord.
<To keep the laser pickup clean, do not touch it, and
do not forget to close the disc tray.
<Do not attempt to clean the unit with chemical
solvents as this might damage the finish. Use a
clean, dry cloth.
<Keep this manual in a safe place for future
reference.
Beware of condensation
When the player (or a compact disc) is moved from a
cold to a warm place or used after a sudden
temperature change, there is the danger of
condensation. Water vapor in the air could condense
on the mechanism or the laser pickup. If droplets of
water form on these parts, correct playback will be
impossible because the laser cannot read the
information from the disc correctly. To prevent this, if
you are going to use the player in a condition where
condensation could occur, you should leave the
player for 1 or 2 hours after plugging it into an AC
outlet depending on the amount of condensation. If
this is done, the player will stabilize at the
temperature of its surroundings.
TO THE USER
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide reasonable protection against interference in a residential
area. This device generates and uses radio frequency energy and if not installed and used in accordance with the
instructions, it may cause interference to radio or TV reception. If this unit does cause interference with TV or radio
reception you can try to correct the interference by one or more of the following measures:
a) Reorient or relocate the receiving antenna.
b) Increase the separation between the equipment and the receiver.
c) Plug the equipment into a different outlet so that it is not on the same circuit as the receiver.
If necessary, consult the dealer or an experienced radio/TV technician for additional suggestions.
CAUTION:
Changes or modifications to this equipment not expressly approved by TEAC CORPORATION for compliance could
void the user's authority to operate this equipment.
AC POWER CORD CONNECTION
CAUTION:
TO PREVENT ELECTRIC SHOCK, MATCH WIDE
BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
CORDE DE CONNEXION CA
ATTENTION:
POUR ÉVITER LES CHOCS ÉLECTRIQUES,
INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE
DANS LA BORNE CORRESPONDANTE DE
LA PRISE ET POUSSER JUSQU’AU FOND.
For U.S.A.
For CANADA Pour le CANADA

5
Preperation Listening to CDs
Listening to the radio
Listening to tapes Recording Setting the timer
Connections
CAUTION Do not plug the power cord of any component into AC outlets and do not turn their POWER
switches on until all connections have been performed.
ANTENNA
AUX
coaxial cable
FM75Ω
GND
SPEAKERS
FM75Ω
GND
1
2
3
12 3
Connect the FM feeder antenna
to the FM antenna terminal.
Secure it in the location
providing optimum reception.
In an area where FM signals are
weak, 75-ohm unbalanced-type
outdoor FM antenna(3 elements
or more) is recommended.
VCR, MD deck, etc.
When all connections are completed, put the plug in an
AC outlet. "*INITIAL" blinks on the display and the CD
drawer becomes active. Then the demonstration starts.
To stop the demonstration, press the BBS[DEMO]
button. The demonstration stops and the time is
displayed (standby mode). To set the clock, please see
"Setting the Clock".
If the POWER switch is pressed during the
demonstration, the unit is turned on with the source
selected last time. The demonstration starts again
when the POWER switch is pressed to turn the unit off.
To stop the demonstration and enter standby mode,
press the BBS[DEMO] button.
When the POWER switch is pressed in the standby
mode, "HELLO" appears on the display and the unit is
turned on with the source selected last time.
If you press the TAPE, AUX, TUNER or CD button in the
standby mode, the unit is turned on with the selected
source.
AM Loop Antenna
To stand the antenna on a surface, fix the claw to the
slot. After standing it, position it to find the best
direction and position for radio reception.
FM feeder antenna FM outdoor antenna
AC Power
Please connect
the black cord
to _and the
cord with white
print to +.

PreperationListening to CDs
Listening to the radio
Listening to tapesRecordingSetting the timer
6
Remote Control Unit
Using the Remote Control Unit
The provided Remote Control Unit allows the unit to
be operated from a distance. When operating the
remote control unit, point it towards the REMOTE
SENSOR on the front panel of the unit.
<Even if the remote control unit is operated within the
effective range, remote control operation may be
impossible if there are any obstacles between the
unit and the remote control.
<If the remote control unit is operated near other
appliances which generate infrared rays, or if other
remote control devices using infrared rays are used
near the unit, it may operate incorrectly. Conversely,
the other appliances may operate incorrectly.
Compact Disc
Handling the Discs
This unit has been designed specifically for sound
reproduction from compact discs bearing the "?"
mark. No other discs can be used.
<Always place the compact disc in the disc tray with
the label facing upward. (Compact discs can be
played only on one side.)
<To remove a disc from its storage case, press down
on the center of the case and lift the disc out,
holding it carefully by the edges.
<Fingermarks and dust should be carefully wiped off
the disc's recorded surface with a soft cloth.
<Never use such chemicals as record sprays,
antistatic sprays or fluid, benzine or thinner to clean
compact discs. Such chemicals will do irreparable
damage to the disc's plastic surface.
<Discs should be returned to their cases after use to
avoid serious scratches that could cause the laser
pickup to "skip."
<Do not expose discs to direct sunlight or high
humidity and temperature for extended periods.
Long exposure to high temperatures can warp the
disc.
<Do not stick paper or write anything with a ballpoint
pen on the surface of the label side.
<Do not use irregular shape CDs (octagonal, heart-
shape, etc.). CDs of the sort can damage the unit.
How to remove the disc
How to hold the disc
Wipe radially
1
2
3
4
Before Use
Battery Replacement
<If the distance required between the remote control
unit and main unit decreases, the batteries are
exhausted. In this case replace the batteries with
new ones.
Precautions concerning batteries
<Be sure to insert two "AA" dry batteries with correct
positive "+" and negative "_" polarities.
<Use batteries of the same type. Never use different
types of batteries together.
<Rechargeable and non-rechargeable batteries can
be used. Refer to the precautions on their labels.
<When the remote control unit is not to be used for a
long time (more than a month), remove the batteries
from the remote control unit to prevent them from
leaking. If they leak, wipe away the liquid inside the
battery compartment and replace the batteries with
new ones.
<Do not heat or disassemble batteries and never
dispose of old batteries by throwing them in a fire.
Battery Installation

Preperation Listening to CDs
Listening to the radio
Listening to tapes Recording Setting the timer
7
Do not store tapes in the following places:
<On top of heaters, exposed to direct sunlight or in
any other places with high temperatures.
<Near speakers, on TV sets or amplifiers or where
they would be exposed to strong magnetic fields.
<Where humidity is high and in dirty, dusty places.
<Avoid dropping or subjecting cassettes to excessive
shocks.
<As C-120 tapes are physically weak and could
become entangled in the transport mechanism, do
not use them.
Cassette Tape
Tape Selection:
Metal and chrome (cobalt) tapes have identification
holes. You can use normal(Type!) or CrO2(Type@)
tape.
Demagnetizing Heads
Be sure that the power is off, then demagnetize the
heads using a demagnetizer. For details of its use,
read its instructions.
Maintenance
The heads and tape path should be cleaned and
demagnetized periodically.
Cleaning Tape Path
<Apply head cleaning fluid to a cotton swab or soft
cloth, and lightly rub the heads, capstan and all
metal parts in the tape path.
<Also clean the pinch roller using rubber cleaning
fluid.
Metal (Type%^)
CrO
2
(Type#)
Normal (Type%)
Tape Handling:
Use your finger or a pencil to turn the cassette's hub
and take up any slack tape.
<Avoid touching the tape. Fingerprints attract dust
and dirt.
Voltage Conversion
(General export models only)
Be sure to remove the power cord from the AC outlet
before repositioning the voltage converter switch.
1. Locate the voltage selector on the bottom of the
main unit.
2. Using a flat-bladed screwdriver, set to the
appropriate 230V or 120V position according to
your area.
IN NORTH AMERICA USE ONLY ON 120 V SUPPLY.

Preperation
Listening to CDs
Listening to the radio
Listening to tapesRecordingSetting the timer
B
F
C
D
A
C
D
EA
E
G
B
How to adjust the volume
The volume can be changed by 34 steps.
B
Bass Boost System
To emphasize bass, press the BBS button.
To turn it off, press the BBS button again.
C
8
How to change the source
Press the TAPE, AUX, TUNER or CD button (or the
FUNCTION button of the remote control unit) to
select the source.
A
<To select TAPE !or TAPE @, press the TAPE
button (or the BAND button of the remote control
unit) in the TAPE mode.
You cannot select TP1/2 when no cassette tape is
in it.
<To select FM or AM, press the TUNER button (or
the BAND button of the remote control unit) in the
TUNER mode.
TUNER → CD
↑ ↓
AUX ←TP(TAPE)
<Every time the FUNCTION button is pressed, the
mode is changed as follows:
Basic Operation

Preperation Listening to CDs
Listening to the radio
Listening to tapes Recording Setting the timer
9
Muting
To cut the sound temporarily, press the MUTING
button. Press the MUTING button again to restore
the sound. If you change the volume during the
muting, the muting will be canceled.
F
EEPS (Electronic EQ Preset System)
To enjoy different sound, press the EEPS button.
EListening through headphones
Insert the headphone plug into the PHONES jack,
and adjust the volume. The sound from speakers
will be cut off.
G
Every time the EEPS button of the remote control
unit is pressed, the mode is changed as follows:
Surround
Press the SURROUND button to enjoy the feeling
of presence.
To turn it off, press the SURROUND button again.
D
JAZZ : A balanced sound; suitable for jazz.
ROCK : Provides a heavy powerful sound;
suitable for rock music.
POPS : Ideal for popular music.
FLAT : EEPS is off.

10
PreperationListening to CDs
Listening to the radio
Listening to tapesRecordingSetting the timer
Press the CD button or the FUNCTION
button to select "CD".
"NO DISC" will be displayed if no disc is set.
1
Press the OPEN/CLOSE button.
2
Place a disc on a tray with the printed
surface upside.
3
<To place a disc on the hidden tray, press the DISC
SKIP button.
Press the OPEN/CLOSE button(L) to
close the disc drawer.
4
Press the PLAY button(G).
Playback starts from the first track. The number of
the track being played blinks in the music
calendar, and disappears when the playback is
finished.
5
The total number of the tracks and total play time of
the disc is displayed.
Up to 20 tracks are shown on the music calendar.
B
EC
D
1
1
2
4
3
A
B
C
D
5
5
A
Listening to CDs
total number of the tracks total play time
elapsed time
track number
music calendar

To skip to the next or a previous track
Press the SKIP button(.or/) several times
until the desired track is found. The selected track
will be played from the beginning.
C
To stop playback
Press the STOP button(H) to stop playback.
A
To suspend playback temporarily
(pause mode)
Press the PAUSE button(J). Playback stops at the
current position. To resume playback, press the
PAUSE button(J) or PLAY button(G).
B
<When the SKIP button(.) is pressed once
during playback, the track being played will be
played from the beginning.
To return to the beginning of the previous track,
press the SKIP button(.) twice.
Search for a part of a track
During playback, hold down the SEARCH
button(mor,) and release it when the part
you want to listen to is found.
D
Change CDs during playback
You can change discs that are not being played,
even if another disc is being played.
Press the OPEN/CLOSE button(L), open the tray,
change the disc and press the OPEN/CLOSE
button(L) again to close the tray.
E
11
Preperation Listening to CDs
Listening to the radio
Listening to tapes Recording Setting the timer

12
PreperationListening to CDs
Listening to the radio
Listening to tapesRecordingSetting the timer
How to select a disc
Press the DISC1,2,3 button or the DISC SKIP
button to select a disc.
Playback starts from the first track of the disc.
A
Direct playback
Press the numeric buttons of the remote control
unit. Playback starts from the selected track.
B
Example
Track number 7
Track number 23
ONE DISC/ALL DISC
Press the DISC 1/ALL button to select ONE DISC
or ALL DISC.
Every time the DISC 1/ALL button is pressed, the
mode is changed.
C
Intro Check
Press the INTRO CHECK button in the stop mode.
The beginning of each track is played for 10
seconds. When ALL DISC is selected, the
beginning of all the tracks of all the discs will be
played.
D
If PLAY button(y) is pressed during Intro Check
function, normal playback will start from the
current track.
<To skip to the next or a previous track, press the
SKIP button(.or/).
<To stop Intro Check function, press the INTRO
CHECK button again.
<Intro check doesn’t work with the program
playback.
ALL DISC
All the discs in the drawer will be played and stop.
ONE DISC
The selected disc will be played and stop.
B
D
C
A
Select a Disc and Track

Preperation Listening to CDs
Listening to the radio
Listening to tapes Recording Setting the timer
13
Press the SHUFFLE button in the stop or play mode.
<If you press the SKIP button(/) during shuffle
playback, next track will be randomly selected
and played. If you press the SKIP button(.),
the currently played track will be played from the
beginning. A track cannot be replayed during
shuffle playback.
<To stop shuffle playback, press the SHUFFLE,
STOP(H) or OPEN/CLOSE(L) button.
<The DISC 1,2,3 and DISC SKIP buttons doesn’t
work during shuffle playback.
<Shuffle playback doesn’t work with the program
playback and one repeat mode.
Every time the REPEAT button is pressed, the mode is
changed as follows:
Repeat one track [REP 1]
Press the REPEAT button and select "REP 1"
during playback. The track being played will be
played repeatedly. If you select another track in
REP 1 mode, the track you selected will be played
repeatedly.
It is also possible to select a track in the stop
mode. Press the REPEAT button and then select
the track number by the numeric buttons.
Repeat All [REP ALL]
When ONE DISC is selected, all the tracks of the
selected disc will be played repeatedly.
When ALL DISC is selected, all the tracks of all
the discs will be played repeatedly.
REP OFF REP ALL
REP 1
ONE DISC
The tracks of the selected disc will be played
randomly.
ALL DISC
The tracks of all the discs will be played
randomly.
REPEAT
SHUFFLE
<REP 1 doesn’t work with the program playback
and shuffle playback.
Repeat Playback Shuffle Playback

14
PreperationListening to CDs
Listening to the radio
Listening to tapesRecordingSetting the timer
Press the CD button or the FUNCTION
button to select "CD".
1
Up to 32 tracks from 3 discs can be programmed in the
desired order.
Shuffle playback and intro check function don’t work
during program playback.
Press the PROGRAM button of the
remote control unit.
2
Press the numeric buttons to select a
track.
4
<Repeat step and to program more tracks.
<If you made a mistake, press the CLEAR button;
the last track you programmed will be canceled.
<If you press the PLAY button with no track
programmed, program mode is canceled and the
normal playback starts from the first track.
<The DISC 1,2,3 and DISC SKIP buttons doesn’t
work during program playback.
43
Press DISC 1,2 or 3 to select a disc.
3
<When no button is pressed, the disc shown on the
display is selected automatically.
12
5
3
4
5
3A
B
B
A
1
Program Playback

Preperation Listening to ext sources
Listening to the radio
Listening to tapes Recording Setting the timer
15
Press the PLAY button(y) to start
program playback.
5
To clear program
Press the PROGRAM button or the OPEN/CLOSE
button(L).
A
To check the programmed order
Press the UP or DOWN button repeatedly. The
track number and program number will be shown
on the display.
B
You can connect external sources such as MD deck or
TV to the AUX input jacks.
Press the AUX or FUNCTION button to select "AUX".
AUX
Listening to the External Sources

16
PreperationListening to CDs
Listening to the radio
Listening to tapesRecordingSetting the timer
Press the TUNER[BAND] or FUNCTION
button to select "TUNER".
1
Select a station.
3
Hold down the UP or DOWN button more than 0.5
second, and then release the button. When a
station is tuned in, the tuning stops automatically.
Repeat this step till the desired station is found.
Press the UP, DOWN or CLEAR button to stop the
tuning.
<To select stations which cannot be tuned
automatically, press the UP or DOWN button
repeatedly.
<"STEREO" is displayed when a stereo broadcast is
tuned in.
If the reception is poor
A
Press the STEREO/MONO button. This button
changes the radio reception between stereo and
mono.
For a good reception, turn around the antenna so
that you can get the stations clearly.
How to select preset stations
Press the PRESET button or numeric buttons to
select a preset channel.
See next page to store the preset stations.
B
1
2
2
1
3
3
B
A
B
Press the TUNER[BAND] or BAND
button to select FM or AM.
2
Listening to the Radio

Up to 20 FM and 20 AM stations can be stored in preset
memories.
Press the TUNER[BAND] or BAND
button to select FM or AM.
1
Press the UP or DOWN button and tune
in a station to be stored as a preset
station.
2
Press the SET button.
3
Within 4 seconds, select a preset
channel to store the station using the
UP or DOWN button, and then press
the SET button.
4
The channel is shown on the music calendar.
To store more stations, repeat steps to .
41
1213
4
2 4
3
4
17
Preperation Listening to CDs
Listening to the radio
Listening to tapes Recording Setting the timer
Storing Preset Stations

18
PreperationListening to CDs
Listening to the radio
Listening to tapes
RecordingSetting the timer
Insert a cassette tape.
1
Press the TAPE or FUNCTION button to
select "TAPE".
2
Press the PLAY button(y).
4
Push the cassette holder to open, load a cassette
tape with its exposed side facing down, and close
the holder.
<You can use normal(Type!) or CrO2(Type@) tape.
<You can choose either TAPE !or TAPE @for
playback.
Press the TAPE or BAND(TAPE !/@)
button to select TP1(TAPE !) or
TP2(TAPE @).
You cannot select TP1/2 when no cassette tape is
in it.
3
If a cassette tape is inserted in the stop mode, the
deck select the latter inserted tape automatically.
B
2
3
3
2
4
4
B
1
A
A
2
Tape Counter
The counter of the selected TAPE is shown on the
display. During dubbing, counter of TAPE @is
shown. The counter can be cleared by pressing
the CLEAR button in the stop mode. The counter is
reset to "0000".
Listening to Tapes

Continuous Playback
Insert cassette tapes into TAPE !and TAPE @.
When the playback of TAPE !is finished, TAPE @
starts playback automatically.
To stop playback
Press the STOP button(H) to stop playback.
A
Fast forward and rewind
Press the UP or DOWN button.
BLoad a pre-recorded cassette tape into
TAPE !and a recordable cassette tape
into TAPE @.
You can use normal(Type!) or CrO2(Type@) tape.
1
Press the TAPE or FUNCTION button to
select "TAPE".
2
Press the dubbing button(HIGH or
NORM) to start dubbing.
NORM: Dubbing is performed at normal speed.
HIGH: Dubbing is performed at high speed.
3
<Fast forward nor rewind isn’t possible during
dubbing.
<To stop dubbing, press the STOP button(H).
2
2
1 1
3
19
Preperation Listening to CDs
Listening to the radio
Listening to tapes Recording Setting the timer
Dubbing (Copying from TAPE I to TAPE II)
Press the STOP button(H) to stop the fast forward
or rewind operation.

20
PreperationListening to CDs
Listening to the radio
Listening to tapes
Recording
Setting the timer
Load a recordable cassette tape into
TAPE @.
1
Select the source to be recorded by
pressing function buttons.
2
Press the REC button(K).
The recording starts.
3
To stop recording
Press the STOP button(H).
A
Record Muting Operation
If you press the REC MUTE button during
recording, the tape keeps on moving but nothing
is recorded. "REC" blinks in the display, and the
recording stops after 4 seconds. To continue
recording, press the REC MUTE button within 4
seconds.
B
If the safety tabs of the cassette
tape have been broken off, cover
the holes with adhesive tape.
When you select "TUNER", please tune in a station
before pressing the REC button.
<If you press the REC button(K) with CD playing,
the recording starts from the beginning of the
current track.
<It is possible to record during Shuffle playback or
program playback.
When you select "CD", the playback of CD starts
simultaneously.
2
32
1
B
A
A
<You can use normal(Type!) or CrO2(Type@) tape.
Recording (TAPE II only)
